FUJIFILM XP20 User Manual

BL01299-200

DIGITAL CAMERA

FINEPIX XP20 Series

Owner’s Manual

Thank you for your purchase of this product. This manual describes how to use your FUJIFILM digital camera and the supplied software. Be sure that you have read and understood its contents and the warnings in “For Your Safety” (P ii) before using the camera.

For information on related products, visit our website at

http://www.fujifilm.com/products/digital_cameras/index.html

Before You Begin

First Steps

Basic Photography and Playback

More on Photography

More on Playback

Movies

Connections

Menus

Technical Notes

Troubleshooting

Appendix

For Your Safety

Installation

For Your Safety

IMPORTANT SAFETY INSTRUCTIONS

• Read Instructions: All the safety and operating instructions should be read before the appliance is operated.

• Retain Instructions: The safety and operating instructions should be retained for future reference.

• Heed Warnings: All warnings on the appliance and in the operating instructions should be adhered to.

• Follow Instructions: All operating and use instructions should be followed.

Installation

Power Sources: This video product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For video products intended to operate from battery power, or other sources, refer to the operating instructions.

Grounding or Polarization: This video product is equipped with a polarized alternatingcurrent line plug (a plug having one blade wider than the other). This plug will ﬁ t into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to ﬁ t, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

Alternate Warnings: This video product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only ﬁ t into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding type plug.

Overloading: Do not overload wall outlets and extension cords as this can result in a risk of ﬁ re or electric shock.

Ventilation: Slots and openings in the cabinet are provided for ventilation, to ensure reliable operation of the video product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the video product on a bed, sofa, rug, or other similar surface.

This video product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. This video product should never be placed near or over a radiator or heat register.

Attachments: Do not use attachments not recommended by the video product manufacturer as they may cause hazards.

Water and Moisture: Do not use this video product near water—for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

Power-Cord Protection: Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

Accessories: Do not place this video product on an unstable cart, stand, tripod, bracket, or table. The video product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the video product. Any mounting of the appliance should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

Antennas

Use

Service

Antennas

Outdoor Antenna Grounding: If an outside antenna or cable system is connected to the video product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and builtup static charges. Section 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

Ground Clamp

Electric Service

Equipment

Ground Clamps

Power Service Grounding Electrode System (NEC ART

250. PART H)

Power Lines: An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Antenna Lead in Wire

Antenna Discharge Unit (NEC SECTION 810-20)

Grounding

Conductors

(NEC SECTION

810-21)

Use

Cleaning: Unplug this video product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Object and Liquid Entry: Never push objects of any kind into this video product through openings as they may touch dangerous voltage points or short out parts that could result in a ﬁ re or electric shock. Never spill liquid of any kind on the video product.

Lightning: For added protection for this video product receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the video product due to lightning and powerline surges.

Service

Servicing: Do not attempt to service this video product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualiﬁ ed service personnel.

Damage Requiring Service: Unplug this video product from the wall outlet and refer servicing to qualiﬁ ed service personnel under the following conditions:

• When the power-supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen into the video product.

• If the video product has been exposed to rain or water.

• If the video product has been dropped or the cabinet has been damaged.

If the video product does not operate nor-

For Your Safety

mally follow the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualiﬁ ed technician to restore the video product to its normal operation.

When the video product exhibits a distinct change in performance—this indicates a need for service.

Replacement Parts: When replacement parts are required, be sure the service technician has used replacement parts speciﬁ ed by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in ﬁ re, electric shock or other hazards.

Safety Check: Upon completion of any service or repairs to this video product, ask the service technician to perform safety checks to determine that the video product is in proper operating condition.

iii

For Your Safety

WARNING

Be sure to read these notes before use

Safety Notes

• Make sure that you use your camera correctly. Read these safety

notes and your Owner’s Manual carefully before use.

• After reading these safety notes, store them in a safe place.

About the Icons

The icons shown below are used in this document to indicate the severity of the injury or damage that can result if the information indicated by the icon is ignored and the product is used incorrectly as a result.

This icon indicates that death or serious injury can result if the information is ignored.

WARNING

This icon indicates that personal injury or material damage can result if the information is ignored.

CAUTION

The icons shown below are used to indicate the nature of the instructions which are to be observed.

Triangular icons tell you that this information requires attention (“Important”).

Circular icons with a diagonal bar tell you that the action indicated is prohibited (“Prohibited”).

Filled circles with an exclamation mark indicate an action that must be performed (“Required”).

If a problem arises, turn the camera o , remove the battery, and disconnect and unplug the AC power adapter. Continued use of

the camera when it is emitting smoke, is emitting any unusual

Unplug from

odor, or is in any other abnormal state can cause a ﬁ re or elec-

power socket

tric shock. Contact your FUJIFILM dealer. Do not allow water or foreign objects to enter the camera. If water

or foreign objects get inside the camera, turn the camera oﬀ , remove the battery, and disconnect and unplug the AC power

Avoid exposure

adapter. Continued use of the camera can cause a ﬁ re or elec-

to water

tric shock. Contact your FUJIFILM dealer.

WARNING

Do not use the camera in the bathroom or shower (excluding water-

Do not use in

proof products). This can cause a ﬁ re or electric shock.

the bathroom or

shower

Never attempt to change or take apart the camera (never open the case). Failure to observe this precaution can cause ﬁ re or

Do not

electric shock.

disassemble

Should the case break open as the result of a fall or other accident, do not touch the exposed parts. Failure to observe this precau-

tion could result in electric shock or in injury from touching the damaged parts. Remove the battery immediately, taking care

Do not touch

to avoid injury or electric shock, and take the product to the

internal parts

point of purchase for consultation.

Do not change, heat or unduly twist or pull the connection cord and do not place heavy objects on the connection cord. These actions

could damage the cord and cause a ﬁ re or electric shock . If the cord is damaged, contact your FUJIFILM dealer.

Do not place the camera on an unstable surface. This can cause the camera to fall or tip over and cause injury.

Never attempt to take pictures while in motion. Do not use the camera while you are walking or driving a vehicle. This can result in you falling down or being involved in a traﬃ c accident.

Do not touch any metal parts of the camera during a thunderstorm. This can cause an electric shock due to induced current from the lightning discharge.

Do not use the battery except as speci ed. Load the battery as shown by the indicator.

Do not heat, change or take apart the battery. Do not drop or subject the battery to impacts. Do not store the battery with metallic products. Any of these actions can cause the battery to burst or leak

and cause ﬁ re or injury as a result.

Use only the battery or AC power adapters speci ed for use with this camera. Do not use voltages other than the power supply voltage shown. The use of other power sources can cause a ﬁ re.

If the battery leaks and  uid gets in contact with your eyes, skin or clothing,  ush the a ected area with clean water and seek medical attention or call an emergency number right away.

WARNING

CAUTION

Do not use the charger to charge batteries other than those speci ed here. The supplied battery charger is for use only with the

type of battery supplied with the camera. Using the charger to charge conventional batteries or other types of rechargeable batteries can cause the battery to leak ﬂ uid, overheat or burst.

When carrying the battery, install it in a digital camera or keep it in the hard case. When storing the battery, keep it in the hard case. When discarding, cover the battery terminals with insulation tape.

Contact with other metallic objects or batteries could cause the battery to ignite or burst.

Keep memory cards out of the reach of small children. Because memory cards are small, they can be swallowed by children. Be sure to store memory cards out of the reach of small children. If a child swallows a memory card, seek medical attention or call an emergency number.

Do not use this camera in locations a ected by oil fumes, steam, humidity or dust. This can cause a ﬁ re or electric shock.

Do not leave this camera in places subject to extremely high temperatures. Do not leave the camera in locations such as a sealed

vehicle or in direct sunlight. This can cause a ﬁ re.

Keep out of the reach of small children. This product could cause injury in the hands of a child.

Do not place heavy objects on the camera. This can cause the heavy object to tip over or fall and cause injury.

Do not move the camera while the AC power adapter is still connected. Do not pull on the connection cord to disconnect the AC power adapter. This can damage the power cord or cables and cause

a ﬁ re or electric shock.

Do not use the AC power adapter when the plug is damaged or the plug socket connection is loose. This could cause a ﬁ re or electric

shock.

Do not cover or wrap the camera or the AC power adapter in a cloth or blanket. This can cause heat to build up and distort the cas-

ing or cause a ﬁ re.

WARNING

CAUTION

For Your Safety

When you are cleaning the camera or you do not plan to use the camera for an extended period, remove the battery and disconnect and unplug the AC power adapter. Failure to do so can cause a

ﬁ re or electric shock.

When charging ends, unplug the charger from the power socket. Leaving the charger plugged into the power socket can cause

Unplug from

a ﬁ re.

power socket

Using a  ash too close to a person’s eyes may temporarily a ect the eyesight. Take particular care when photographing infants and

young children.

When a memory card is removed, the card could come out of the slot too quickly. Use your  nger to hold it and gently release the card.

Injury could result to those struck by the ejected card. Request regular internal testing and cleaning for your camera.

Build-up of dust in your camera can cause a ﬁ re or electric shock. Contact your FUJIFILM dealer to request internal cleaning every two years. Please note that this service is not free of charge.

CAUTION

For Your Safety

Li-ion Batteries

AA Alkaline/Rechargeable NiMH Batteries

The Battery and Power Supply

Note: Check the type of battery used in your camera and read the appropriate sections.

The following describes the proper use of batteries and how to prolong their life. Incorrect use can shorten battery life or cause leakage, overheating, ﬁ re, or explosion.

Li-ion Batteries

Read this section if your camera uses a rechargeable Li-ion battery.

The battery is not charged at shipment. Charge the battery before use. Keep the battery in its case when not in use.

■ Notes on the Battery

The battery gradually loses its charge when not in use. Charge the battery one or two days before use.

Battery life can be extended by turning the camera oﬀ when not in use.

Battery capacity decreases at low temperatures; a depleted battery may not function at when cold. Keep a fully charged spare battery in a warm place and exchange as necessary, or keep the battery in your pocket or other warm place and insert it in the camera only when shooting. Do not place the battery in direct contact with hand warmers or other heating devices.

■ C harging the Battery

Charge the battery in the supplied battery charger. Charging times will increase at ambient temperatures below +10 °C (+50 °F) or above +35 °C (+95 °F). Do not attempt to charge the battery at temperatures above 40 °C (+104 °F); at temperatures below 0 °C (+32 °F), the battery will not charge.

Do not attempt to recharge a fully charged battery. The battery does not however need to be fully discharged before charging.

The battery may be warm to the touch immediately after charging or use. This is normal.

■ Battery Life

At normal temperatures, the battery can be recharged about 300 times. A noticeable decrease in the length of time the battery will hold a charge indicates that it has reached the end of its service life and should be replaced.

■ Storage

Performance may be impaired if the battery is left unused for extended periods when fully charged. Run the battery ﬂ at before storing it.

If the camera will not be used for an extended period, remove the battery and store it in a dry place with an ambient temperature of from +15 °C to +25 °C (+59 °F to +77 °F). Do not store in locations exposed to extremes of temperature.

■ Cautions: Handling the Battery

• Do not transport or store with metal objects such as necklaces or hairpins.

• Do not expose to ﬂ ame or heat.

• Do not disassemble or modify.

• Use with designated chargers only.

• Do not drop or subject to strong physical shocks.

• Do not expose to water.

• Keep the terminals clean.

• The battery and camera body may become warm to the touch after extended use. This is normal.

AA Alkaline/Rechargeable NiMH Batteries

Read this section if your camera uses AA alkaline or rechargeable AA NiMH batteries. Information on compatible battery

types may be found elsewhere in the camera manual.

■ Cautions: Handling the Batteries

• Do not expose to water, ﬂ ame, or heat, or store in warm or humid conditions.

• Do not transport or store with metal objects such as necklaces or hairpins.

• Do not disassemble or modify the batteries or battery casing.

• Do not subject to strong physical shocks.

• Do not use batteries that are leaking, deformed, or discolored.

• Keep out of reach of infants and small children.

• Insert in the correct orientation.

• Do not mix old and new batteries, batteries

AC Power Adapters (Available Separately)

with diﬀ erent charge levels, or batteries of diﬀ erent types.

• If the camera will not be used for an extended period, remove the batteries. Note that the camera clock will be reset.

• The batteries may be warm to the touch immediately after use. Turn the camera oﬀ and allow the batteries to cool before handling.

• Battery capacity tends to decrease at low temperatures. Keep spare batteries in a pocket or other warm place and exchange as necessary. Cold batteries may recover some of their charge when warmed.

• Fingerprints and other stains on the battery terminals can impair battery performance. Thoroughly clean the terminals with a soft, dry cloth before inserting them in the camera.

If the batteries leak, clean the battery compartment thoroughly before inserting new batteries.

If ﬂ uid from the battery comes into contact with skin or clothing, ﬂ ush the aﬀ ected area with water. If  uid

enters your eyes, immediately  ush the a ected area with water and seek medical attention. Do not rub your eyes. Failure to observe this precaution could result in permanent visual impairment.

■ NiMH Batteries

The capacity of Ni-MH batteries may be temporarily reduced when new, after long periods of disuse, or if they are repeatedly recharged before being fully discharged. This is normal and does not indicate a malfunction. Capacity can be increased by repeatedly discharging the batteries using the discharge option in the camera setup menu and recharging them using a battery charger.

Q C AUTION: Do not use the discharge option

with alkaline batteries.

The camera draws a small amount of current even when oﬀ . Ni-MH batteries that have been left in the camera for an extended period may be drawn down to the point that they no longer hold a charge. Battery performance may also drop if the batteries are run down in a device such as a ﬂ ashlight. Use the discharge option in the camera setup menu to discharge Ni-MH batteries. Batteries that no longer hold a charge even after repeatedly being discharged and recharged have reached the end of their service life and must be replaced.

Ni-MH batteries can be recharged in a battery charger (sold separately). Batteries may become warm to the touch after charging. Refer to the instructions provided with the charger for more information. Use the charger with compatible batteries only.

Ni-MH batteries gradually lose their charge when not in use.

■ Disposal

Dispose of used batteries in accord with local regulations.

For Your Safety

AC Power Adapters (Available Separately)

This section applies to all camera models. Use only FUJIFILM AC power adapters designated for use with this camera. Other adapters could damage the camera.

• The AC power adapter is for indoor use only.

• Be sure the DC plug is securely connected to the camera.

• Turn the camera oﬀ before disconnecting the adapter. Disconnect the adapter by the plug, not the cable.

• Do not use with other devices.

• Do not disassemble.

• Do not expose to high heat and humidity.

• Do not subject to strong physical shocks.

• The adapter may hum or become hot to the touch during use. This is normal.

• If the adapter causes radio interference, reorient or relocate the receiving antenna.

vii

For Your Safety

Take Test Shots

Notes on Copyright

Handling

Liquid Crystal

Trademark Information

Electrical Interference

Color Television Systems

Exif Print (Exif Version 2.3)

Take Test Shots

Notes on Copyright

Handling

Using the Camera

Do not aim the camera at extremely bright light sources, such as the sun in a cloudless sky. Failure to observe this precaution could damage the camera image sensor.

Before taking photographs on important occasions (such as at weddings or before taking the camera on a trip), take a test shot and view the result in the LCD monitor to ensure that the camera is functioning normally. FUJIFILM Corporation can not accept liability for damages or lost proﬁ ts incurred as a result of product malfunction.

Unless intended solely for personal use, images recorded using your digital camera system cannot be used in ways that infringe copyright laws without the consent of the owner. Note that some restrictions apply to the photographing of stage performances, entertainments, and exhibits, even when intended purely for personal use. Users are also asked to note that the transfer of memory cards containing images or data protected under copyright laws is only permissible within the restrictions imposed by those copyright laws.

To ensure that images are recorded correctly, do not subject the camera to impact or physical shocks while images are being recorded.

viii

Liquid Crystal

In the event that the LCD monitor is damaged, care should be taken to avoid contact with liquid crystal. Take the urgent action indicated should any of the following situations arise:

• If liquid crystal comes in contact with your skin, clean the area with a cloth and then wash thoroughly with soap and running water.

• If liquid crystal enters your eyes, ﬂ ush the affected eye with clean water for at least 15 minutes and then seek medical assistance.

• If liquid crystal is swallowed, rinse your mouth thoroughly with water. Drink large quantities of water and induce vomiting, then seek medical assistance.

Although the display is manufactured using extremely high-precision technology, it may contain pixels that are always lit or that do not light. This is not a malfunction, and images recorded with the product are unaﬀ ected.

Trademark Information

xD-Picture Card and E are trademarks of FUJIFILM Corporation. The typefaces included herein are solely developed by DynaComware Taiwan Inc. Macintosh, QuickTime, and Mac OS are trademarks of Apple Inc. in the U.S.A. and other countries. Windows 7, Windows Vista, and the Windows logo are trademarks of the Microsoft group of companies. Adobe and Adobe Reader are either trademarks or registered trademarks of Adobe Systems Incorporated in the U.S.A. and/or other countries. The SDHC and SDXC logos are trademarks of SD-3C, LLC. The HDMI logo is a trademark. YouTube is a trademark of Google Inc. All other trade names mentioned in this manual are the trademarks or registered trademarks of their respective owners.

Electrical Interference

This camera may interfere with hospital or aviation equipment. Consult with hospital or airline staﬀ before using the camera in a hospital or on an aircraft.

Color Television Systems

NTSC (National Television System Committee) is a color television telecasting speciﬁ cation adopted mainly in the U.S.A., Canada, and Japan. PAL (Phases Alternation by Line) is a color television system adopted mainly in European countries and China.

Exif Print (Exif Version 2.3)

Exif Print is a newly revised digital camera ﬁ le format in which information stored with photographs is used for optimal color reproduction during printing.

IMPORTANT NOTICE:

Read Before Using the Software

Direct or indirect export, in whole or in part, of licensed software without the permission of the applicable governing bodies is prohibited.

About This Manual

Table of Contents

...........................

xiii

Troubleshooting

............................

Warning Messages and Displays

.....

Memory Cards

About This Manual

Before using the camera, read this manual and the warnings in “For Your Safety” (P ii). For information on speci c topics, consult the sources below.

Table of Contents

The “Table of Contents” gives an overview of the entire manual. The

...........................PP

xiii

Troubleshooting

............................PP

Having a speci c problem with the camera? Find the answer here.

principal camera operations are listed here.

Warning Messages and Displays

.....PP

Find out what’s behind that  ashing icon or error message in the display.

Memory Cards

Pictures can be stored in the camera’s internal memory or on optional SD, SDHC, and SDXC memory cards (P 14), referred to in this manual as “memory cards.”

Frequently-Used Buttons

■■ Deleting Pictures

■■Taking Pictures During Playback

■■ Silent Mode

■■Turning the Camera on in Playback Mode

Frequently-Used Buttons

Deleting Pictures

y Press the selector up (b) to display

deletion options.

Taking Pictures During Playback

y To return instantly to shooting mode,

press the shutter button halfway.

Turning the Camera on in Playback Mode

y When the camera is

o , playback can be started by pressing the a button for about a second.

View

Silent Mode y Press and hold the DISP/

BACK button to disable

camera lights and sounds.

Shoot

Product Features and Precautions for Use

■■Water, Dust, and Shock Resistance

QQThe camera complies with JIS Class 8 water resistance and JIS Class 6 (IP68) dust resistance

standards, and has passed FUJIFILM drop tests (drop height: 1.5m/4.9ft.; impact surface: plywood, thickness 5cm/2.0in.) compliant with MIL-STD 810F Method 516.5: Shock. These results were obtained through in-house testing and are not a blanket guarantee of water resistance or invulnerability to damage or destruction. The accessories supplied with the camera are not water resistant.

■■Before Use

QQThe front surface of the camera lens is protected by a sheet of glass. Foreign matter on the

glass will appear in photographs; keep the glass clean at all times.

QQBe sure that the battery-chamber and connector covers are fully latched. The presence of wa-

ter, mud, or sand in the camera could cause malfunction.

QQDo not open or close the battery-chamber or connector cover with wet hands or near water,

for example while on or by a body of water.

QQBe sure the camera is completely dry before inserting or removing batteries or memory cards

or connecting the USB or A/V cable.

QQThe camera does not  oat. Be sure to attach the strap and keep it around your wrist when

using the camera.

■■During Use

QQRestrict underwater use to depths of 5 m (16ft.) or less and periods shorter than 120 minutes. QQDo not open or close the battery-chamber cover while under water. QQDo not use in hot springs or heated pools. QQDo not dive into water with the camera or otherwise subject it to excessive force. QQIf the camera is left on the sand, its temperature may exceed operating limits and sand may

get into the speaker or microphone.

QQSunscreen, suntan lotion, or other oily substances may discolor the camera body and should

be removed with a damp cloth.

QQThe camera may lose water resistance if subjected to excessive force or vibration. Consult your

retailer or a FUJIFILM-authorized repair technician.

Product Features and Precautions for Use

Water, Dust, and Shock Resistance

The camera complies with JIS Class 8 water resistance and JIS Class 6 (IP68) dust resistance standards, and has passed FUJIFILM drop tests (drop height: 1.5m/4.9ft.; impact surface: plywood, thickness 5cm/2.0in.) compliant with MIL-STD 810F Method 516.5: Shock. These results were obtained through in-house testing and are not a blanket guarantee of water resistance or invulnerability to damage or destruction. The accessories supplied with the camera are not water resistant.

Before Use

The front surface of the camera lens is protected by a sheet of glass. Foreign matter on the glass will appear in photographs; keep the glass clean at all times. Be sure that the battery-chamber and connector covers are fully latched. The presence of water, mud, or sand in the camera could cause malfunction. Do not open or close the battery-chamber or connector cover with wet hands or near water, for example while on or by a body of water. Be sure the camera is completely dry before inserting or removing batteries or memory cards or connecting the USB or A/V cable. The camera does not  oat. Be sure to attach the strap and keep it around your wrist when using the camera.

During Use

Restrict underwater use to depths of 5 m (16ft.) or less and periods shorter than 120 minutes. Do not open or close the battery-chamber cover while under water. Do not use in hot springs or heated pools. Do not dive into water with the camera or otherwise subject it to excessive force. If the camera is left on the sand, its temperature may exceed operating limits and sand may get into the speaker or microphone. Sunscreen, suntan lotion, or other oily substances may discolor the camera body and should be removed with a damp cloth. The camera may lose water resistance if subjected to excessive force or vibration. Consult your retailer or a FUJIFILM-authorized repair technician.

Product Features and Precautions for Use

■■After Use

QQRemove any foreign matter from the water-resistant seal and adjacent surfaces. Foreign mat-

ter could damage the seal, lowering water resistance.

QQAfter using the camera underwater or in locations where foreign matter might adhere to the

camera body, rinse the camera under the tap or leave it in a basin of fresh water for two to three minutes.

QQLiquid soaps, detergents, alcohol, and other cleansers may a ect water resistance and should

never be used.

QQAfter use, remove water droplets and foreign matter with a dry cloth,  rmly latch the battery-

chamber cover, and soak the camera in fresh water for about ten minutes. Dry the camera thoroughly after removing it from the water.

■■Storage and Maintenance

QQDo not store at temperatures below 0°C (32°F) or above 40°C (104°F). QQTo ensure continued water resistance, it is recommended that you have the water-resistant

seal replaced about once a year (a fee is charged for this service). Contact your retailer or a FUJIFILM-authorized repair technician for more information.

■■Cold Climates

QQBattery performance drops at low temperatures, reducing the number of pictures that can be

taken. Insulate the camera to keep it warm or place it in your clothing. QQUse an NP-45A battery. QQDisplay response may slow at low temperatures. This is not a malfunction.

After Use

Remove any foreign matter from the water-resistant seal and adjacent surfaces. Foreign mat-

ter could damage the seal, lowering water resistance.

After using the camera underwater or in locations where foreign matter might adhere to the

camera body, rinse the camera under the tap or leave it in a basin of fresh water for two to

three minutes.

Liquid soaps, detergents, alcohol, and other cleansers may a ect water resistance and should

never be used.

After use, remove water droplets and foreign matter with a dry cloth,  rmly latch the battery-

chamber cover, and soak the camera in fresh water for about ten minutes. Dry the camera

thoroughly after removing it from the water.

Storage and Maintenance

Do not store at temperatures below 0°C (32°F) or above 40°C (104°F).

To ensure continued water resistance, it is recommended that you have the water-resistant

seal replaced about once a year (a fee is charged for this service). Contact your retailer or a

FUJIFILM-authorized repair technician for more information.

Cold Climates

Battery performance drops at low temperatures, reducing the number of pictures that can be

taken. Insulate the camera to keep it warm or place it in your clothing.

Use an NP-45A battery.

Display response may slow at low temperatures. This is not a malfunction.

xii

Table of Contents

Before You Begin

First Steps

Basic Photography and Playback

More on Photography

Table of Contents

For Your Safety ..................................................................ii

IMPORTANT SAFETY INSTRUCTIONS ..................................ii

Safety Notes ....................................................................iv

About This Manual ...........................................................ix

Frequently-Used Buttons .................................................x

Product Features and Precautions for Use......................xi

Before You Begin

Symbols and Conventions .................................................1

Supplied Accessories .........................................................1

Parts of the Camera ..........................................................2

Camera Displays ...............................................................4

Shooting ........................................................................4

Playback .........................................................................5

First Steps

Charging the Battery ........................................................7

Inserting the Battery and a Memory Card .......................9

Compatible Memory Cards .............................................14

Turning the Camera on and O ......................................16

Shooting Mode ..............................................................16

Playback Mode ...............................................................16

Basic Setup ......................................................................18

Basic Photography and Playback

Taking Pictures in Q (Scene Recognition) Mode ......19

Viewing Pictures .............................................................23

More on Photography

Shooting Mode ................................................................24

Choosing a Shooting Mode ............................................24

Shooting Mode Options .................................................25

r MOTION PANORAMA ..............................................27

b Intelligent Face Detection .......................................29

Focus Lock ........................................................................30

d Exposure Compensation ..........................................32

F Macro Mode (Close-ups) ...........................................33

N Using the Flash (Intelligent Flash) ............................34

h Using the Self-Timer .................................................36

xiii

Table of Contents

More on Playback

Movies

Connections

Menus

More on Playback

Playback Options .............................................................37

I Favorites: Rating Pictures .........................................37

Playback Zoom ...............................................................38

Multi-Frame Playback ....................................................39

A Deleting Pictures ......................................................40

b Image Search ............................................................41

k PhotoBook Assist......................................................42

Creating a PhotoBook.....................................................42

Viewing Photobooks ......................................................43

Editing and Deleting Photobooks ...................................43

Viewing Panoramas ........................................................44

Movies

Recording Movies ............................................................45

Viewing Movies ...............................................................47

Connections

Viewing Pictures on TV ...................................................48

Printing Pictures via USB ................................................49

Printing the DPOF Print Order.........................................51

Viewing Pictures on a Computer ....................................53

Windows: Installing MyFinePix Studio ...........................53

Macintosh: Installing FinePixViewer...............................55

Connecting the Camera ..................................................57

Menus

Using the Menus: Shooting Mode ..................................60

Using the Shooting Menu...............................................60

Shooting Menu Options .................................................60

A SHOOTING MODE ....................................................60

N ISO ........................................................................61

O IMAGE SIZE ............................................................62

T IMAGE QUALITY .....................................................63

P FINEPIX COLOR .......................................................63

D WHITE BALANCE ....................................................64

R CONTINUOUS .........................................................65

b FACE DETECTION .....................................................65

F AF MODE ...............................................................66

V MOVIE QUALITY .....................................................66

q LED ILLUMINATOR...................................................66

xiv

Using the Menus: Playback Mode ..................................67

Using the Pla

Playback Menu Options ..................................................67

yback Menu ...............................................67

k PHOTOBOOK ASSIST ................................................67

b IMAGE SEARCH ......................................................67

A ERASE ...................................................................67

c EDIT ......................................................................68

j MARK FOR UPLOAD TO ............................................69

I SLIDE SHOW ..........................................................70

B RED EYE REMOVAL .................................................71

D PROTECT ................................................................71

G CROP .....................................................................72

O RESIZE ...................................................................72

C IMAGE ROTATE .......................................................73

E COPY .....................................................................73

S TRANSITION ...........................................................74

L MOVIE TRIMMING ...................................................74

P MOVIE JOIN ...........................................................75

K PRINT ORDER (DPOF) ..............................................75

Table of Contents

The Setup Menu ..............................................................76

Using the Setup Menu ....................................................76

Setup Menu Options ......................................................77

F DATE/TIME .............................................................77

N TIME DIFFERENCE ...................................................77

L a ......................................................77

o SILENT MODE .........................................................77

R RESET ....................................................................78

K FORMAT ................................................................78

A IMAGE DISP. ...........................................................78

B FRAME NO. ............................................................79

G OPERATION VOL. .....................................................80

H SHUTTER VOLUME ..................................................80

e SOUND ..................................................................80

I PLAYBACK VOLUME ................................................80

J LCD BRIGHTNESS ....................................................80

E LCD MODE .............................................................81

M AUTO POWER OFF ...................................................81

L DUAL IS MODE .......................................................81

B RED E

YE REMOVAL .................................................81

D DIGITAL ZOOM .......................................................82

n SAVE ORG IMAGE ....................................................82

c GUIDANCE DISPLAY ................................................82

Q VIDEO SYSTEM .......................................................83

Table of Contents

Technical Notes

Troubleshooting

Appendix

Technical Notes

Optional Accessories .......................................................84

Accessories from FUJIFILM..............................................85

Caring for the Camera .....................................................86

Storage and Use .............................................................86

Cleaning .........................................................................87

Traveling ........................................................................87

Troubleshooting

Problems and Solutions ..................................................88

Warning Messages and Displays ....................................94

Appendix

Tips and Tricks..................................................................98

Internal Memory/Memory Card Capacity ....................101

Speci cations ................................................................102

xvi

Before You Begin

Symbols and Conventions

Supplied Accessories

Attaching the Strap

Before You Begin

Symbols and Conventions

The following symbols are used in this manual: Q : This information should be read before use to ensure correct operation. R : Additional information that may be helpful when using the camera. P : Other pages in this manual on which related information may be found.

Menus and other text in the LCD monitor are shown in bold. In the illustra- tions in this manual, displays may be simpli ed for explanatory purposes.

Supplied Accessories

The following items are included with the camera:

NP-45A rechargeable

battery

• Strap

• User Guide

BC-45B battery charger USB cable CD-ROM (contains

Attaching the Strap

Attach the strap as shown.

this manual)

Parts of the Camera

For more information, refer to the page listed to the right of each item.

Selector button

Move cursor up

d (exposure compensation) button (P 32)

b (delete) button (P x)

MENU/OK button

Move cursor left

F (macro) button (P 33)

Move cursor down

h (self-timer) button (P 36)

2 Before You Begin

Move cursor right

N ( ash) button (P 34)

Parts of the Camera

The Indicator Lamp

Indicator lamp

Camera status

Glows green

Blinks green

Blinks green and orange

Glows orange

Blinks orange

Blinks red

1 Zoom control ...........................................................20, 38

2 Shutter button .............................................................. 21

3 ON/OFF button ............................................................. 16

4 Flash ............................................................................. 34

5 Self-timer lamp ............................................................ 36

LED illuminator ............................................................. 66

6 Lens/protective glass

7 Speaker ......................................................................... 47

8 Microphone .................................................................. 45

9 LCD monitor .................................................................... 4

10 t (movie recording) button ........................................ 45

11 Indicator lamp (see below)

* Press and hold the DISP/BACK button until o is displayed.

The Indicator Lamp

12 Strap eyelet ....................................................................1

13 Battery-chamber cover latch .....................................9, 12

14 Connector cover latch ........................................ 48, 49, 57

15 DISP (display)/BACK button .....................................6, 18

o (silent mode) button* ................................................x

16 a (playback) button................................................... 23

17 Tripod mount

18 USB multi-connector ...............................................49, 57

19 Memory card slot .......................................................... 11

20 Battery latch ............................................................10, 13

21 Battery chamber .............................................................9

The indicator lamp shows camera status as follows:

Indicator lamp

Glows green Focus locked.

Blinks green Blur, focus, or exposure warning. Picture can be taken.

Blinks green and orange Recording pictures. Additional pictures can be taken.

Glows orange Recording pictures. No additional pictures can be taken at this time.

Blinks orange Flash charging;  ash will not  re when picture is taken.

Blinks red Lens or memory error.

Camera status

3Before You Begin

Parts of the Camera

Camera Displays

10:00

250

4.5

12 / 31/ 2050

Camera Displays

The following types of indicator may be displayed during shooting and playback. Indicators vary with camera settings.

■ Shooting

7 Movie quality ................................................................ 45

12/31/2050

250

10:00

4.5

800

1 Shooting mode ............................................................. 24

2 Intelligent Face Detection indicator .............................. 29

3 Continuous shooting mode ........................................... 65

4 Silent mode indicator ................................................3, 77

5 Focus frame .................................................................. 30

6 Internal memory indicator

* a: indicates that no memory card is inserted and that pictures will be stored in the camera’s internal memory (P 11).

8 Number of available frames ........................................ 101

9 Sensitivity ..................................................................... 61

10 Image size and quality .............................................62, 63

11 FINEPIX color ................................................................ 63

12 White balance ............................................................... 64

13 Battery level ................................................................... 5

14 Dual IS mode ................................................................ 81

15 Exposure compensation ................................................ 32

16 Date and time ............................................................... 18

17 Blur warning ............................................................35, 94

18 Focus warning .........................................................21, 94

19 Self-timer indicator ...................................................... 36

20 Macro (close-up) mode ................................................. 33

21 Flash mode ................................................................... 34

4 Before You Begin

■ Playback

100-0001

400

10:00 AM

1 / 250

4.5

4:3

12 / 31/ 2050

Battery Level

Indicator

Description

100-0001

YouTube

12/31/2050 1/250

Battery Level

Battery level is shown as follows:

Indicator

D (white) C (white) B (red) A (blinks red)

10:00 AM

4.5

Battery partially discharged. Battery more than half discharged. Low battery. Charge as soon as possible. Battery exhausted. Turn camera o and charge battery.

4:3

400

Parts of the Camera

1 Playback mode indicator..........................................23, 37

2 Intelligent Face Detection indicator .........................29, 71

3 Red-eye removal indicator ............................................ 71

4 Portrait enhancer .......................................................... 25

5 Silent mode indicator ................................................3, 77

6 Gift image ..................................................................... 37

7 Frame number .............................................................. 79

8 Mark for upload to ........................................................ 69

9 Photobook assist........................................................... 42

10 Favorites ....................................................................... 37

11 DPOF print indicator ..................................................... 51

12 Protected image ........................................................... 71

Description

5Before You Begin

Parts of the Camera

Hiding and Viewing Indicators

Press DISP/BACK to cycle through shooting and playback indicators as follows:

• Shooting: Indicators displayed/indicators hidden/best framing

• Playback: Indicators displayed/indicators hidden/I favorites

6 Before You Begin

First Steps

Charging the Battery

The Charging Indicator

Charging indicator

Battery status

Action

O

Battery not inserted.

Insert the battery.

On (green)

Battery fully charged.

Remove the battery.

On (yellow)

Battery charging.

—

Blinks (yellow)

Battery fault.

Unplug the charger and remove the battery.

First Steps

Charging the Battery

The battery is not charged at shipment. Charge the battery before use.

Place the battery in the supplied battery charger.

Insert the battery in the orientation indicated by the CBD labels.

The camera uses an NP-45A rechargeable battery.

Plug the charger in.

Battery

CBD

label

Battery charger

CBD label

Plug the charger into a power outlet. The charging indicator will light.

The Charging Indicator

The charging indicator shows battery charge status as follows:

Charging indicator

O

On (green)

On (yellow)

Blinks (yellow)

Battery status

Battery not inserted.

Battery fully charged.

Battery charging.

Battery fault.

Action

Insert the battery.

Remove the battery.

—

Unplug the charger and remove the battery.

Arrow

Charging the Battery

Charge the battery.

Remove the battery when charging is complete. See the speci cations (P 106) for charging times (note that charging times increase at low temperatures).

Q Unplug the charger when it is not in use.

8 First Steps

Inserting the Battery and a Memory Card

Although the camera can store pictures in internal memory, optional SD, SDHC, and SDXC memory cards (sold separately) can be used to store additional pictures. After charging the battery, insert the battery and memory card as described below.

Open the battery-chamber cover.

Press the latch as shown.

R Be sure the camera is o before opening the

battery-chamber cover.

Q Do not open the battery-chamber cover

when the camera is on. Failure to observe this precaution could result in damage to image  les or memory cards.

Q Do not use excessive force when handling the battery-chamber cover. Q Remove water droplets and other foreign matter with a dry cloth before open-

ing the battery-chamber cover.

9 First Steps

Inserting the Battery and a Memory Card

Insert the battery.

Insert the battery with the terminal  rst and in the orientation shown by the label inside the battery chamber, keeping the battery latch pressed to one side. Con rm that the battery is securely latched.

Q Insert the battery in the correct orientation.

Do NOT use force or attempt to insert the battery upside down or backwards. The battery

will slide in easily in the correct orientation.

Battery latch

Label

10 First Steps

Insert the memory card.

Holding the memory card in the orientation shown at right, slide it in until it clicks into place at the back of the slot.

Q Be sure card is in the correct orientation; do

not insert at an angle or use force. If the memory card is not correctly inserted or no memory card is inserted, a will appear in the LCD monitor and internal memory will be used for recording and playback.

Q SD/SDHC/SDXC memory cards can be locked,

making it impossible to format the card or to record or delete images. Before inserting an SD/SDHC/SDXC memory card, slide the writeprotect switch to the unlocked position.

Inserting the Battery and a Memory Card

Click

Write-protect switch

11 First Steps

Inserting the Battery and a Memory Card

Con rming That the Cover Is Latched

Close the battery-chamber cover.

Before closing the cover, check to con rm that there is no dust, sand, or other foreign matter on the water-resistant seal or adjacent surfaces.

Con rming That the Cover Is Latched

• Con rm that the battery-chamber or connector cover does not protrude from the camera body.

• The covers are latched when the latches are in the positions shown below at left.

Latch indicator

Con rm that there

are no gaps.

Unlatched

Latched

12 First Steps

Inserting the Battery and a Memory Card

Removing the Battery and Memory Card

Before removing the battery or memory card, turn the camera o and press the latch to open the battery-chamber cover.

To remove the battery, press the battery latch to the side, and

Battery latch

slide the battery out of the camera as shown.

To remove the memory card, press it in and release it slowly. The card can then be removed by hand. When a memory card is removed, the card could come out of the slot too quickly. Use your  nger to hold it and gently release the card.

13 First Steps

Inserting the Battery and a Memory Card

QQMemory Cards

■ Compatible Memory Cards

FUJIFILM and SanDisk SD, SDHC, and SDXC memory cards have been approved for use in the camera. A complete list of approved memory cards is available at http://www.fujifilm.com/support/digital_cameras/compatibility/. Operation is not guaranteed with other cards. The camera can not be used with xD-Picture Cards or MultiMediaCard (MMC) devices.

Memory Cards

• Do not turn the camera o or remove the memory card while the memory card is being formatted or data are being recorded to or deleted from the card. Failure to observe this precaution

could damage the card.

• Format SD/SDHC/SDXC memory cards before  rst use, and be sure to reformat all memory cards after using them in a computer or other device. For more information on formatting memory cards, see “K FORMAT” (P 78).

• Memory cards are small and can be swallowed; keep out of reach of children. If a child swallows a memory card, seek medical assistance immediately.

• miniSD or microSD adapters that are larger or smaller than the standard dimensions of an SD/SDHC/SDXC card may not eject normally; if the card does not eject, take the camera to an authorized service representative. Do not forcibly remove the card.

• Do not a x labels to memory cards. Peeling labels can cause camera malfunction.

• Movie recording may be interrupted with some types of SD/SDHC/SDXC memory card. Use a G card or better when shooting HD movies.

14 First Steps

Inserting the Battery and a Memory Card

QQBatteries

• The data in internal memory may be erased or corrupted when the camera is re-

paired. Please note that the repairer will be able to view pictures in internal memory.

• Formatting a memory card or internal memory in the camera creates a folder in

which pictures are stored. Do not rename or delete this folder or use a computer or other device to edit, delete, or rename image  les. Always use the camera to delete pictures from memory cards and internal memory; before editing or renaming  les, copy them to a computer and edit or rename the copies, not the originals.

Batteries

• Remove dirt from the battery terminals with a clean, dry cloth. Failure to observe this

precaution could prevent the battery from charging.

• Do not a x stickers or other objects to the battery. Failure to observe this precaution

could make it impossible to remove the battery from the camera.

• Do not short the battery terminals. The battery could overheat.

• Read the cautions in “The Battery and Power Supply” (P vi).

• Use only battery chargers designated for use with the battery. Failure to observe this

precaution could result in product malfunction.

• Do not remove the labels from the battery or attempt to split or peel the outer casing.

• The battery gradually loses its charge when not in use. Charge the battery one or

two days before use.

15 First Steps

Turning the Camera on and O

Shooting Mode

RRSwitching to Playback Mode

Playback Mode

RRSwitching to Shooting Mode

Turning the Camera on and O

Shooting Mode

Press the ON/OFF button to turn the camera on.

Press ON/OFF again to turn the camera o .

Switching to Playback Mode

Press the a button to start playback. Press the shutter button halfway to return to shooting mode.

Playback Mode

To turn the camera on and begin playback, press the a button for about a second.

Press the a button again or press the ON/OFF button to turn the camera o .

Switching to Shooting Mode

To exit to shooting mode, press the shutter button halfway. Press the a button to return to playback.

16 First Steps

Turning the Camera on and O

RRAuto Power O

Q Fingerprints and other marks on the protective glass covering the lens can a ect

pictures. Keep the glass clean.

Q The ON/OFF button does not completely end the supply of power to the camera.

Auto Power O

The camera will turn o automatically if no operations are performed for the length of time selected for M AUTO POWER OFF (P 81). To turn the camera on, use the ON/OFF button or press the a button for about a second.

17 First Steps

Basic Setup

RRThe Camera Clock

Basic Setup

A language-selection dialog is displayed the  rst time the camera is turned on. Set up the camera as described below (you can reset the clock or change languages at any time using the F DATE/TIME or L a options in the setup menu; for information on displaying the setup menu, see page 77).

Highlight a language and press MENU/OK.

R Press DISP/BACK to skip the current step. Any steps you skip

will be displayed the next time the camera is turned on.

START MENU

ENGLISH

FRANCAIS DEUTSCH ESPAÑOL PORTUGUÊS

NOSET

The date and time will be displayed. Press the selector

left or right to highlight the year, month, day, hour, or minute and press up or down to change. To change the order in which the year, month, and day are displayed,

DATE/TIME NOT SET

2013 2012

2011

YY. MM. DD

2010 2009

NOSET

1. 1 12

00 AM

highlight the date format and press the selector up or down. Press MENU/OK when settings are complete.

The Camera Clock

If the battery is removed for an extended period, the camera clock will be reset and the language-selection dialog will be displayed when the camera is turned on.

18 First Steps

Basic Photography and Playback

Taking Pictures in

(Scene Recognition) Mode

scene recognition

The

Icon

The Scene Icon

Basic Photography and Playback

Taking Pictures in QQ

This section describes how to take pictures in QQ (

(Scene Recognition) Mode

scene recognition) mode. The camera automatically analyzes the composition and adjusts settings appropriately.

Turn the camera on.

Press the ON/OFF button to turn the camera on.

Q shooting indicators will be displayed.

The

Icon

This icon indicates that the camera continuously searches for faces to select the appropriate scene, increasing the drain on the battery.

The Scene Icon

The camera selects the scene according to shooting conditions and the type of subject: b PORTRAIT (portraits), c LANDSCAPE (landscapes), d NIGHT (poorly-lit land- scapes), e MACRO (close ups), f NIGHT PORTRAIT (poorly-lit portraits), g BACKLIT PORTRAIT (backlit portraits), a AUTO (all other scenes)

Taking Pictures in Q (Scene Recognition) Mode

Holding the Camera

Frame the picture.

Use the zoom control to frame the picture in the display.

Zoom out Zoom in

Zoom indicator

Holding the Camera

Hold the camera steady with both hands and brace your elbows against your sides. Shaking or unsteady hands can blur your shots.

To prevent pictures that are out of focus or too dark (underexposed), keep your  ngers and other objects away from the  ash and from the protective glass covering the lens.

20 Basic Photography and Playback

Taking Pictures in Q (Scene Recognition) Mode

Focus.

Press the shutter button halfway to focus.

R The lens may make a noise when the camera focuses; this

is normal.

Double

If the camera is able to focus, it will beep twice and the indicator lamp will glow green.

If the camera is unable to focus, the focus frame will turn red, s will be dis- played, and the indicator lamp will blink green. Change the composition or use focus lock (P 30).

beep

21Basic Photography and Playback

Taking Pictures in Q (Scene Recognition) Mode

The Shutter Button

Shoot.

Smoothly press the shutter button the rest of the way down to take the picture.

R If the subject is poorly lit, the  ash may  re when the pic-

ture is taken. For information on using the  ash when lighting is poor, see “N Using the Flash (Intelligent Flash)” (P 34).

The Shutter Button

The shutter button has two positions. Pressing the shutter button halfway sets focus and exposure; to shoot, press the shutter button the rest of the way down.

Click

22 Basic Photography and Playback

Viewing Pictures

Pictures can be viewed in the LCD monitor. When taking important photographs, take a test shot and check the results.

Press the a button.

The most recent picture will be displayed.

View additional pictures.

Press the selector right to view pictures in the order recorded, left to view pictures in reverse order.

Press the shutter button halfway to exit to shooting mode.

23Basic Photography and Playback

More on Photography

Shooting Mode

Choosing a Shooting Mode

More on Photography

Shooting Mode

Choose a shooting mode according to the scene or type of subject.

Choosing a Shooting Mode

Press MENU/OK to display the shooting menu.

Highlight A SHOOTING MODE and press the

selector right to display shooting mode options.

Highlight the desired mode and press MENU/OK.

Press DISP/BACK to exit to shooting mode.

SHOOTING MENU

SHOOTING MODE

SET

EXIT

SCENE RECOGNITION

Selects optimum camera settings for certain modes.

CANCELSET

Shooting Mode Options

Mode

Description

QQ SCENE RECOGNITION

BB AUTO

PP PROGRAM AE CC NATURAL & DD NATURAL LIGHT LL PORTRAIT ZZ PORTRAIT ENHANCER MM LANDSCAPE rr MOTION PANORAMA NN SPORT OO NIGHT HH NIGHT (TRIPOD) QQ SUNSET

RR SNOW

SS BEACH

Shooting Mode Options

Mode

SCENE RECOGNITION

AUTO

PROGRAM AE The camera sets exposure automatically.

NATURAL & NN

NATURAL LIGHT

PORTRAIT

PORTRAIT ENHANCER LANDSCAPE

MOTION PANORAMA SPORT NIGHT

NIGHT (TRIPOD) SUNSET

SNOW

BEACH

The camera automatically analyzes the composition and selects a scene according to shooting conditions and the type of subject.

Choose for crisp, clear snapshots. This mode is recommended in most situations.

The camera takes two shots: one without the  ash and one with. Capture natural lighting under low-light conditions. Choose for portraits. Choose for a smooth skin e ect when shooting portraits. Choose for daylight shots of buildings and landscapes. Take up to three pictures and join them together to form a panorama. Choose when photographing moving subjects. Choose this mode for poorly lit twilight or night scenes. Choose this mode for slow shutter speeds when shooting at night. Choose this mode to record the vivid colors in sunrises and sunsets. Choose for crisp, clear shots that capture the brightness of scenes domi-

nated by shining white snow.

Choose for crisp, clear shots that capture the brightness of sunlit beaches.

Description

Shooting Mode

25More on Photography

Shooting Mode

Mode

Description FF UNDERWATER tt UNDER WATER

(WIDE)

ss UNDER WATER

(MACRO) UU PARTY VV FLOWER WW TEXT

Mode UNDERWATER UNDER WATER

(WIDE)

UNDER WATER

(MACRO) PART Y FLOWER

TEXT

Description

For underwater shooting (e ective in movies). Choose for wide-angle underwater shots that include more of the back-

ground behind the main subject.

Choose for underwater close-ups of small objects.

Capture indoor background lighting under low-light conditions. Choose for vivid close-ups of  owers. Take clear pictures of text or drawings in print.

26 More on Photography

Shooting Mode

■ r MOTION PANORAMA

In this mode, you can take up to three pictures and join them together to form a panorama. Use of a tripod is recommended to assist in composing overlapping shots.

Press the selector up to select a frame. Press the selector left or right to

highlight a pan direction and press MENU/OK.

Take a photograph. Exposure and white balance for the panorama are set

with the  rst shot.

Frame the next shot to overlap with the previous picture by superimpos-

ing y on + so that they form a solid circle (z). The camera will release the shutter automatically.

Pan direction

END CANCEL

Display after 1st shot Shutter released

END CANCEL

27More on Photography

Shooting Mode

For Best Results

Printing Panoramas

Take the last shot as described in Step 3.

R To end shooting and create a panorama after the  rst or second shot, press the

multi selector up after completing Step 2 or Step 3 and proceed to Step 5.

Press MENU/OK to save the picture.

Q Panoramas are created from multiple frames. The camera may in some cases be

unable to stitch the frames together perfectly.

Q The desired results may not be achieved with moving subjects, subjects close to

the camera, unvarying subjects such as the sky or a  eld of grass, subjects that are in constant motion, such as waves and waterfalls, or subjects that undergo marked changes in brightness. Panoramas may be blurred if the subject is poorly lit.

For Best Results

For best results, be careful not to tilt the camera backward or forward or to either side and try not to move the camera while y and + are aligned to form a solid circle.

Printing Panoramas

Depending on the page size and the size of the panorama, panoramas may print with their edges cropped out or with wide margins at the top and bottom or at both sides.

28 More on Photography

b b Intelligent Face Detection

Intelligent Face Detection

Intelligent Face Detection sets focus and exposure for human faces anywhere in the frame, preventing the camera from focusing on the background in group portraits. Choose for shots that emphasize portrait subjects.

To use Intelligent Face Detection, press MENU/OK to display the shooting menu and select ON for b FACE DETECTION ( P 65). Faces can be detected with the camera in vertical or horizontal orientation; if a face is detected, it will be indicated by a green border. If there is more than one face in the frame, the camera will select the face closest to the center; other faces are indicated by white borders.

Q In some modes, the camera may set exposure for the frame as a whole rather than

the portrait subject.

Q If the subject moves as the shutter button is pressed, their face may not be in the

area indicated by the green border when the picture is taken.

29More on Photography

Focus Lock

To compose photographs with o -center subjects:

Fo cus:

Position the subject in the focus frame (U) and press the shutter button halfway to lock focus and exposure. Focus and exposure will remain locked while the shutter button is pressed halfway (AF/AE lock).

Recompose: Keep the button pressed halfway.

Shoot: Press the button all the way down.

30 More on Photography

Focus Lock

Autofocus

Although the camera boasts a high-precision autofocus system, it may be unable to focus on the subjects listed below. If the camera is unable to focus, focus on another subject at the same distance and use focus lock to recompose the photograph.

• Very shiny subjects such as mirrors or car bodies.

• Fast-moving subjects.

• Subjects photographed through a window or other re-

 ective object.

• Dark subjects and subjec ts that absorb rather than re ect

light, such as hair or fur.

• Insubstantial subjects, such as smoke or  ame.

• Subjects that show little contrast with the background

(for example, subjects in clothing that is the same color as the background).

• Subjects positioned in front of or behind a high-contrast

object that is also in the focus frame (for example, a subject photographed against a backdrop of highly contrasting elements).

31More on Photography

d d Exposure Compensation

Exposure Compensation

To adjust exposure compensation when photographing very bright, very dark, or high-contrast subjects, press the selector up (d). Press the selector up or down to choose an exposure compensation value and then press MENU/OK.

Choose positive (+) values to increase exposure

Choose negative (–) values to reduce exposure

R A d icon and exposure indicator are displayed at settings other than ±0. Exposure

compensation is not reset when the camera is turned o ; to restore normal exposure control, choose a value of ±0.

R Turn the  ash o when using exposure compensation. R Exposure compensation is available only when P (PROGRAM AE) is selected for

shooting mode.

32 More on Photography

F F Macro Mode (Close-ups)

Macro Mode (Close-ups)

For close-ups, press the selector left (F) and select F. When macro mode is in e ect, the camera fo-

cuses on subjects near the center of the frame. Use the zoom control to compose pictures (P 20).

To exit macro mode, press the selector left (F) and select H.

R Use of a tripod is recommended to prevent blur caused

by camera shake.

OFF

33More on Photography

N N Using the Flash (Intelligent Flash)

Option

Description

AUTO

((AUTO FLASH

((FORCED FLASH

((SUPPRESSED FLASH

((SLOW SYNCHRO

Using the Flash (Intelligent Flash)

When the  ash is used, the camera’s Intelligent Flash system instantly analyzes the scene based on such factors as the brightness of the subject, its position in the frame, and its distance from the camera. Flash output and sensitivity are adjusted to ensure that the main subject is correctly exposed while preserving the e ects of ambient background lighting, even in dimly-lit indoor scenes. Use the  ash when lighting is poor, for example when shooting at night or indoors under low light.

Press the selector right (N) and choose from the following  ash modes:

AUTO FLASH

According to shooting conditions

Option

AUTO

AUTO FLASH))

FORCED FLASH))

SUPPRESSED FLASH))

SLOW SYNCHRO))

The  ash  res when required. Recommended in most situations.

The  ash  res whenever a picture is taken. Use for backlit subjects or for natural coloration when shooting in bright light.

The  ash does not  re even when the subject is poorly lit. Use of a tripod is recommended.

Capture both the main subject and the background under low light (note that brightly lit scenes may be overexposed).

Description

34 More on Photography

N Using the Flash (Intelligent Flash)

Red-Eye Removal

R If the  ash will  re, p will be displayed when the shutter button is pressed halfway.

At slow shutter speeds, k will appear in the display to warn that pictures may be blurred; use of a tripod is recommended.

R The  ash may  re several times with each shot. Do not move the camera until

shooting is complete.

R The  ash may cause vignetting.

Red-Eye Removal

When Intelligent Face Detection (P 29) and red-eye removal (P 71) are on, red-eye removal is available in auto (K; RED EYE REDUCTION),  ash on (L; FORCED FLASH), and slow sync (M; RED EYE & SLOW) modes. Red-eye removal minimizes “red-eye” caused when light from the  ash is re ected from the subject’s retinas as shown in the illustration at right.

35More on Photography

h h Using the Self-Timer

Option

Description

RRTo stop the timer before the picture is taken, press

DISP/BACK

RRTo stop the timer before the picture is taken, press

DISP/BACK

Using the Self-Timer

To use the self-timer, press the selector down (h) and choose from the following options:

OFF

Option

T (OFF) Self-timer o .

The camera starts the timer when it detects two portrait subjects close together.

a ( COUPLE TIMER)

g ( GROUP TIMER)

S (10 SEC)

R (2 SEC)

Press the selector up to choose how close the subjects must be together before the timer starts (the more hearts, the closer the subjects must be together).

To stop the timer before the picture is taken, press

The camera will start the timer when it detects the selected number of portrait subjects. Press the selector up to choose the number of subjects.

To stop the timer before the picture is taken, press

The shutter is released ten seconds after the shutter button is pressed. Use for self-portraits. The self-timer lamp on the front of the camera blinks while the timer counts down.

The shutter is released two seconds after the shutter button is pressed. Use to reduce blur caused by the camera moving when the shutter-release button is pressed. The self-timer lamp will blink as the timer counts down.

Description

DISP/BACK..

36 More on Photography

More on Playback

Playback Options

100-0001

I I Favorites: Rating Pictures

More on Playback

Playback Options

To view the most recent picture in the LCD monitor, press the a button.

100-0001

Press the selector right to view pictures in the order recorded, left to view pictures in reverse order. Keep the selector pressed to scroll rapidly to the desired frame.

R Pictures taken using other cameras are indicated by a m (“gift image”) icon during

playback.

Favorites: Rating Pictures

To rate the picture currently displayed in full-frame playback, press DISP/BACK and press the selector up and down to select from zero to  ve stars.

Playback Options

Playback Zoom

Select T to zoom in on pictures displayed in single-frame playback; select W to zoom out. When the picture is zoomed in, the selector can be used to view areas of the image not currently visible in the display.

Zoom indicator

Navigation window shows portion of image currently displayed in LCD monitor

Press DISP/BACK to exit zoom.

R The maximum zoom ratio varies with image size. Playback zoom is not available

with cropped or resized copies saved at a size of a or smaller.

38 More on Playback

Playback Options

Multi-Frame Playback

100-0001

Multi-Frame Playback

Selecting W when a picture is shown full-frame in the LCD monitor displays the current image with previous and following images in the background. Select W to increase the number of images displayed to two, nine, or one hundred, T to view fewer images.

100-0001

When two or more images are displayed, use the selector to highlight images and press MENU/OK to view the highlighted image full frame. In the nine- and hundred-frame displays, use the selector to view more pictures.

39More on Playback

A A Deleting Pictures

Option

Description

FRAME

SELECTED FRAMES

ALL FRAMES

Deleting Pictures

SET

PLAYBACK MENU

ERASE

BACK

FRAME SELECTED FRAMES ALL FRAMES

To delete individual pictures, multiple selected pictures, or all pictures, press MENU/OK, select A ERASE ( P 67), and choose from the options be- low. Note that deleted pictures can not be recov-

ered. Copy important pictures to a computer or other storage device before proceeding.

Option

FRAME

Press the selector left or right to scroll through pictures and press MENU/OK to delete the current picture (a con rmation dialog is not displayed).

Highlight pictures and press MENU/OK to select or deselect (pictures that

SELECTED FRAMES

are protected or in a print order are shown by u). When the operation is complete, press DISP/BACK to display a con rmation dialog, then highlight OK and press MENU/OK to delete the selected pictures.

A con rmation dialog will be displayed; highlight OK and press MENU/OK to delete all unprotected pictures (if a memory card is inserted, only the pic-

ALL FRAMES

tures on the memory card will be a ected; the pictures in internal memory are only deleted if no memory card is inserted). Pressing DISP/BACK cancels deletion; note that any pictures deleted before the button was pressed can not be recovered.

R Protected pictures can not be deleted. Remove protection from any pictures you

wish to delete (P 71).

R If a message appears stating that the selected images are part of a DPOF print order,

press MENU/OK to delete the pictures.

Description

40 More on Playback

b b Image Search

Image Search

Search for pictures.

Select b IMAGE SEARCH in the playback menu (P 67), highlight one of

the following search criteria, and press MENU/OK:

• BY DATE: Search by date.

• BY FACE: Search for faces from the face recognition database.

I FAVORITES: Search by rating.

• BY

• BY SCENE: Search by scene.

• BY TYPE OF DATA: Find all still pictures, all movies, or edited pictures.

• BY UPLOAD MARK: Find all pictures selected for upload to a speci ed destination.

Select a search condition. Only pictures that match the search condition

will be displayed. To delete or protect selected pictures or to view the search results in a slide show, press MENU/OK and choose A ERASE (P 40), D PROTECT (P 71), or I SLIDE SHOW (P 70).

41More on Playback

k k PhotoBook Assist

Creating a PhotoBook

PhotoBook Assist

Create books from your favorite photos.

Creating a PhotoBook

Select NEW BOOK for k PHOTOBOOK ASSIST in the playback menu

(P 67) and choose from the following options:

• SELECT FROM ALL: Choose from all available pictures.

• SELECT BY IMAGE SEARCH: Choose from pictures matching selected search

conditions (P

R Neither photographs a or smaller nor movies can be selected for photobooks.

Scroll through the images and press the selector up to select or deselect.

To display the current image on the cover, press the selector down. Press MENU/OK to exit when the book is complete.

R The  rst picture selected becomes the cover image. Press the selector down to

select a di erent image for the cover.

Select COMPLETE PHOTOBOOK (to select all photos or all photos match-

ing the speci ed search conditions for the book, choose SELECT ALL). The new book will be added to the list in the photobook assist menu.

Q Books can contain up to 300 pictures. Q Books that contain no photos are automatically deleted.

41).

42 More on Playback

k PhotoBook Assist

Viewing Photobooks

Editing and Deleting Photobooks

Photobooks

Viewing Photobooks

Highlight a book in the photobook assist menu and press MENU/OK to display the book, then press the selector left or right to scroll through the pictures.

Editing and Deleting Photobooks

Display the photobook and press MENU/OK. The following options will be displayed; select the desired option and follow the on-screen instructions.

• EDIT: Edit the book as described in “Creating a PhotoBook” (P 42).

• ERASE: Delete the book.

Photobooks

Photobooks can be copied to a computer using the supplied MyFinePix Studio software.

43More on Playback

Viewing Panoramas

If you press the selector down when a panorama is displayed full frame, the camera will play back the picture from left to right. To pause playback, press the selector down; press the selector down again to resume. To exit to fullframe playback, press the selector up while panorama playback is in progress.

PLAY

STOP PAUSE

44 More on Playback

Movies

Recording Movies

Movies

Recording Movies

Press t to shoot a movie. During recording, y REC and the time remaining will be displayed in the LCD monitor and sound will be recorded via the built-in microphone (be careful not to cover the microphone during recording).

Time available is displayed

sREC

in monitor

To end recording, press the t button again. Recording ends automatically when the movie reaches maximum length or memory is full.

R Zoom can be adjusted while recording is in progress. R Before recording, select a frame size using the V MOVIE QUALITY option in the

shooting menu. Select h 1280 (1280 × 720) for an aspect ratio of 16 : 9 (High De ni- tion) or f (640 × 480) to record longer standard de nition movies.

R Focus is  xed when t is pressed. Exposure and white balance are adjusted auto-

matically throughout recording. The color and brightness of the image may vary from that displayed before recording begins.

R Sounds made by the camera may be recorded.

Recording Movies

Q The indicator lamp lights while movies are being recorded. Do not open the bat-

tery chamber during shooting or while the indicator lamp is lit. Failure to observe this precaution could prevent the movie from being played back.

Q Vertical or horizontal streaks may appear in movies containing very bright subjects.

This is normal and does not indicate a malfunction.

Q The temperature of the camera may rise if it is used to record movies for an ex-

tended period or if the ambient temperature is high. This is normal and does not indicate a malfunction.

46 Movies

Viewing Movies

Option

Description

Start/pause

playback

End playback/

delete

Advance/

rewind

Adjust volume

100-006

Viewing Movies

During playback, movies are displayed in the LCD monitor as shown at right. The following operations can be performed while a movie is displayed:

Option

Start/pause

playback

End playback/

delete

Advance/

rewind

Adjust volume

Press the selector down to start playback. Press again to pause.

Press the selector up to end playback. If playback is not in progress, pressing the selector up will delete the movie.

Press the selector right to advance, left to rewind. If playback is paused, the movie will advance or rewind one frame each time the selector is pressed.

Press MENU/OK to pause playback and display volume controls. Press the selector up or down to adjust the volume and press MENU/OK to exit. Volume can also be adjusted from the setup menu.

Q Do not cover the speaker during playback.

Description

100-006

PLAY

47Movies

Connections

Viewing Pictures on TV

Connections

Viewing Pictures on TV

Connect the camera to a TV to show pictures to a group.

Turn the camera o and connect an optional A/V cable as shown below.

Insert into USB multi-connector

Q When connecting cables, be sure the connectors are fully inserted. Q Be sure the battery-chamber cover is open before attempting to open or close

the connector cover.

R Image quality may drop during movie playback. R To view high de nition movies on a high de nition TV, the optional accessory

is required (P 84, 85).

Tune the television to the video input channel. See the documentation

Connect yellow plug to video-in jack

Connect white plug to audio-in jackConnector cover Battery-chamber cover

supplied with the television for details.

Press the a button for about a second to turn the camera on. The camera

monitor turns o and pictures and movies are played back on the TV. Note that the camera volume controls have no e ect on sounds played on the TV; use the television volume controls to adjust the volume.

Printing Pictures via USB

If the printer supports PictBridge, the camera can be connected directly to the printer as shown below and pictures can be printed without  rst being copied to a computer. Note that depending on the printer, not all the functions described below may be supported.

Connect the supplied USB cable as shown and turn the printer on.

Q Be sure the battery-chamber cover is open before attempting to open or close

the connector cover.

Connector cover Battery-chamber cover

Press the a button for about a second to turn the camera on.

Press the selector left or right to display a picture you wish to print.

Press the selector up or down to choose the number of copies (up to 99).

Repeat steps 3–4 to select additional pictures. Press MENU/OK to display a

con rmation dialog when settings are complete.

49Connections

Printing Pictures via USB

Printing the Date of Recording

Press MENU/OK to start printing. Printing can be interrupted by pressing

DISP/BACK, but note that some printers may not respond immediately. If

the printer stops before printing is complete, turn the camera o and then on again.

After con rming that PRINTING has cleared from the camera display, turn

the camera o and disconnect the USB csable.

R Pictures can be printed from internal memory or a memory card that has been

formatted in the camera.

R If no pictures are selected, the camera will print one copy of the current picture. R Page size, print quality, and border selections are made using the printer.

Printing the Date of Recording

To print the date of recording on pictures, press DISP/BACK in the PictBridge display and select PRINT WITH DATE s in the PictBridge menu (to print pictures without the date of recording, select PRINT WITHOUT DATE).

50 Connections

Printing Pictures via USB

Printing the DPOF Print Order

DPOF

Printing the DPOF Print Order

The K PRINT ORDER (DPOF) option in the playback menu can be used to create a digital “print order” for PictBridge-compatible printers (P 84) or devices that support DPOF.

DPOF

DPOF (Digital Print Order Format) is a standard that allows pictures to be printed from “print orders” stored in internal memory or on a memory card. The information in the order includes the pictures to be printed and the number of copies of each picture.

Select playback mode and press MENU/OK to display the playback menu.

Highlight K PRINT ORDER (DPOF) and press MENU/OK.

Highlight one of the following options and press MENU/OK:

• WITH DATE s: Print the date of recording on pictures.

• WITHOUT DATE: Do not print the date of recording on pictures.

R Some printers do not support date printing. See the printer manual for details.

Press the selector left or right to display a picture you wish to add to or

remove from the print order.

51Connections

Printing Pictures via USB

Press the selector up or down to choose the number of copies (up to 99).

To remove a picture from the print order, press the selector down until the number of copies is zero.

Repeat Steps 4–5 to complete the print order and press MENU/OK when

settings are complete.

A con rmation dialog will be displayed. Press MENU/OK to save the print

order.

R Remove the memory card to create or modify a print order for the pictures in

internal memory.

R Print orders can contain a maximum of 999 pictures. R If a memory card is inserted containing a print order created by another camera,

a message will be displayed. Create a new print order as described above.

52 Connections

Viewing Pictures on a Computer

Windows: Installing MyFinePix Studio

Windows 7

Windows Vista

Windows XP

CPU

3 GHz Pentium 4 or better

2 GHz Pentium 4 or

better

RAM

1 GB or more

512 MB or more

Free disk space

15 GB or more

2 GB or more

Video

Other

Viewing Pictures on a Computer

The supplied software can be used to copy pictures to a computer, where they can be stored, viewed, organized, and printed. Before proceeding, install the software as described below. Do NOT connect the camera to the computer until installation is complete.

Windows: Installing MyFinePix Studio

Con rm that the computer meets the following system requirements:

Windows 7

CPU

RAM

Free disk space

Video

Other

* Other versions of Windows are not supported. Only pre-installed operating systems are

supported; operation is not guaranteed on home-built computers or computers that have been upgraded from earlier versions of Windows.

Start the computer. Log in to an account with administrator privileges

• 1024 × 768 pixels or more with 24-bit color or better

• A graphics processing unit (GPU) that supports DirectX 7 or later

• Built-in USB port recommended. Operation is not guaranteed with other USB ports.

• Internet connection (broadband recommended) required to install .NET Framework (if necessary), to use auto update feature, and when performing such tasks as sharing pictures on-line or via e-mail.

3 GHz Pentium 4 or better

1 GB or more

15 GB or more

Windows Vista

Windows XP

2 GHz Pentium 4 or

512 MB or more

2 GB or more

better

before proceeding.

53Connections

Viewing Pictures on a Computer

Windows 7/Windows Vista

If the Installer Does Not Start Automatically

Exit any applications that may be running and insert the installer CD in a

CD-ROM drive.

Windows 7/Windows Vista

If an AutoPlay dialog is displayed, click SETUP.EXE. A “User Account Control” dialog will then be displayed; click Ye s ( Windows 7) or Allow (Windows Vista).

The installer will start automatically; click Install MyFinePix Studio and follow the on-screen instructions to install MyFinePix Studio.

If the Installer Does Not Start Automatically

If the installer does not start automatically, select Computer or My Computer from the Start menu, then double-click the FINEPIX CD icon to open the FINEPIX CD window and double-click setup or SETUP.EXE.

If prompted to install Windows Media Player, DirectX, or .NET Framework,

follow the on-screen instructions to complete installation.

Remove the installer CD from the CD-ROM drive when installation is com-

plete. Store the installer CD in a dry location out of direct sunlight in case you need to re-install the software.

Installation is now complete. Proceed to “Connecting the Camera” (P 57).

54 Connections

Viewing Pictures on a Computer

Macintosh: Installing FinePixViewer

CPU

RAM

Free disk space

Video

Other

Macintosh: Installing FinePixViewer

Con rm that the computer meets the following system requirements:

CPU PowerPC or Intel

Pre-installed copies of Mac OS X version 10.3.9–10.6 (visit http://www.fujifilm.

com/support/digital_cameras/compatibility/ for more information)

RAM 256 MB or more

Free disk space

Video 800 × 600 pixels or more with thousands of colors or better

Other

After starting the computer and quitting any applications that may be run-

A minimum of 200 MB required for installation with 400 MB available when FinePixViewer is running

Built-in USB port recommended. Operation is not guaranteed with other USB ports.

ning, insert the installer CD in a CD-ROM drive and double-click Installer for Mac OS X.

An installer dialog will be displayed; click Installing FinePixViewer to start

installation. Enter an administrator name and password when prompted and click OK, then follow the on-screen instructions to install FinePixViewer. Click Exit to quit the installer when installation is complete.

55Connections

Viewing Pictures on a Computer

Remove the installer CD from the CD-ROM drive. Note that you may be

unable to remove the CD if Safari is running; if necessary, quit Safari before removing the CD. Store the installer CD in a dry location out of direct sunlight in case you need to re-install the software.

Mac OS X 10.5 or earlier: Open the “Applications” folder, start Image Capture,

and select Preferences… from the Image Capture application menu. The Image Capture preferences dialog will be displayed; choose Other… in the When a camera is connected, open menu, then select FPVBridge in the “Applications/FinePixViewer” folder and click Open. Quit Image Capture.

Mac OS X 10.6: Connect the camera and turn it on. Open the “Applications” folder and start Image Capture. The camera will be listed under DEVICES; select the camera and choose FPVBridge from the Connecting this cam- era opens menu and click Choose. Quit Image Capture.

Installation is now complete. Proceed to “Connecting the Camera” (P 57).

56 Connections

Viewing Pictures on a Computer

Connecting the Camera

If the pictures you wish to copy are stored on a memory card, insert the

card into the camera.

R Windows users may require the Windows CD when starting the software for

the  rst time.

Q Loss of power during transfer could result in loss of data or damage to internal

memory or the memory card. Charge the battery before connecting the camera.

Turn the camera o and connect the

supplied USB cable as shown, making sure the connectors are fully inserted. Connect the camera directly to the computer; do not use a USB hub or keyboard.

Q Be sure the battery-chamber cover is open

before attempting to open or close the connector cover.

Press the a button for about a second to turn the camera on. MyFinePix

Connector cover

Battery-chamber cover

Studio or FinePixViewer will start automatically; follow the on-screen instructions to copy pictures to the computer. To exit without copying pictures, click Cancel.

R If the software does not start automatically, it may not be correctly installed.

Disconnect the camera and reinstall the software.

57Connections

Viewing Pictures on a Computer

For more information on using the supplied software, start the application and select the appropriate option from the Help menu.

Q If a memory card containing a large number of images is inserted, there may be a

delay before the software starts and you may be unable to import or save images. Use a memory card reader to transfer pictures.

Q Make sure that the computer does not display a message stating that copying is in

progress and that the indicator lamp is out before turning the camera o or disconnecting the USB cable (if the number of images copied is very large, the indicator lamp may remain lit after the message has cleared from the computer display). Failure to observe this precaution could result in loss of data or damage to internal memory or the memory card.

Q Disconnect the camera before inserting or removing memory cards. Q In some cases, it may not be possible to access pictures saved to a network server

using the supplied software in the same way as on a standalone computer.

Q The user bears all applicable fees charged by the phone company or Internet ser-

vice provider when using services that require an Internet connection.

58 Connections

Viewing Pictures on a Computer

Disconnecting the Camera

Uninstalling the Supplied Software

Disconnecting the Camera

After con rming that the indicator lamp is out, follow the on-screen instructions to turn the camera o and disconnect the USB cable.

Uninstalling the Supplied Software

Only uninstall the supplied software when it is no longer required or before beginning reinstallation. After quitting the software and disconnecting the camera, drag the “FinePixViewer” folder from “Applications” into the Trash and select Empty Trash in the Finder menu (Macintosh), or open the control panel and use “Programs and Features” (Windows7/Windows Vista) or “Add or Remove Programs” (WindowsXP) to uninstall MyFinePix Studio. Under Windows, one or more con rmation dialogs may be displayed; read the contents carefully before clicking OK.

59Connections

Menus

Using the Menus: Shooting Mode

Using the Shooting Menu

Shooting Menu Options

AA SHOOTING MODE

((defaults to

Menus

Using the Menus: Shooting Mode

Using the Shooting Menu

To display the shooting menu, press MENU/OK in shooting mode. Highlight items and press the selector right to view options, then highlight an option and press MENU/OK. Press DISP/BACK to exit when settings are complete. The options available vary with the shooting mode selected.

Shooting Menu Options

SHOOTING MODE

Choose a shooting mode according to the type of subject (P 24).

defaults to QQ))

Using the Menus: Shooting Mode

N N ISO

((defaults to

AUTO)

100

ISO

3200

Bright

Scene

Dark

Less noticeable

Noise (mottling)

More noticeable

Option

Description

AUTO

3200 / 1600 / 800 / 400 /

200 / 100

defaults to

ISO

Control the camera’s sensitivity to light. Higher values can reduce blur; note, however, that mottling may appear in pictures taken at high sensitivities.

100

Bright

Less noticeable

Option

AUTO Sensitivity is adjusted automatically in response to shooting conditions.

3200 / 1600 / 800 / 400 /

200 / 100

Sensitivity is set to the speci ed value, which is shown in the display.

ISO

Scene

Noise (mottling)

Description

3200 Dark

More noticeable

AUTO)

61Menus

Using the Menus: Shooting Mode

O O IMAGE SIZE

((defaults to

4:3)

OO 4 : 3

Size Versus Aspect Ratio

Size

Option

Prints at sizes up to

O P Q

Aspect ratio

IMAGE SIZE

Choose the image size and aspect ratio at which pictures are recorded. Large pictures can be printed at large sizes with no drop in quality, while small pictures require less memory, allowing more pictures to be recorded.

Size Versus Aspect Ratio

Size

Option

34 × 25 cm (13.5 × 10 in.)

24 × 18 cm (9.5 × 7 in.)

P Q

17 × 13 cm (7 × 5 in.)

4 : 3: Pictures have the same proportions as the camera display.

Prints at sizes up to

Aspect ratio

16 : 9: Suited for display on High De nition

(HD) devices.

defaults to OO

Size Aspect ratio

4 : 3

4:3)

62 Menus

Using the Menus: Shooting Mode

T T IMAGE QUALITY

((defaults to

Option

Description

FINE

NORMAL

P P FINEPIX COLOR

((defaults to

Option

Description

cc STANDARD

CHROME

bb B&W ff SEPIA

RRSettings other than

STANDARD

are shown by an icon in the LCD monitor.

RRDepending on the subject, the e ects of

CHROME

may not be visible in the LCD monitor.

IMAGE QUALITY

Choose how much image  les are compressed.

Option

FINE Low compression. Select for higher image quality.

NORMAL High compression. Select this option to store more pictures.

FINEPIX COLOR

Description

Enhance contrast and color saturation or take pictures in black and white.

Option

STANDARD

CHROME

B&W SEPIA

Settings other than cc Depending on the subject, the e ects of aa

Standard contrast and saturation. Recommended in most situations. Vivid contrast and color. Choose for vivid shots of  owers or enhanced greens

and blues in landscapes. Take pictures in black and white. Take pictures in sepia.

STANDARD

are shown by an icon in the LCD monitor.

Description

CHROME

may not be visible in the LCD monitor.

defaults to N)N)

defaults to <<))

63Menus

Using the Menus: Shooting Mode

D D WHITE BALANCE

((defaults to

AUTO)

Option

Description

AUTO

i j k l m n

RRResults vary with shooting conditions. Play pictures back after shooting to check colors in

the LCD monitor.

WHITE BALANCE

For natural colors, choose a setting that matches the light source.

Option

AUTO White balance adjusted automatically.

For subjects in direct sunlight.

For subjects in the shade.

Use under “daylight”  uorescent lights.

Use under “warm white”  uorescent lights.

Use under “cool white”  uorescent lights.

Use under incandescent lighting.

Results vary with shooting conditions. Play pictures back after shooting to check colors in the LCD monitor.

Description

defaults to

AUTO)

64 Menus

Using the Menus: Shooting Mode

R R CONTINUOUS

((defaults to

OFF)

Option

Description

OFF

RRFocus and exposure are determined by the  rst frame in each series. RRThe  ash turns o automatically. The previously selected  ash mode is restored when

OFF

selected for

CONTINUOUS

RRFrame rate varies with shutter speed. RRThe number of pictures that can be recorded depends on the memory available.

b b FACE DETECTION

defaults to

OFF

OFF)

CONTINUOUS

Capture motion in a series of pictures.

Option

ON The camera takes up to 3 pictures while the shutter button is pressed.

OFF One photograph is taken each time the shutter button is pressed.

Focus and exposure are determined by the  rst frame in each series. The  ash turns o automatically. The previously selected  ash mode is restored when selected for RR Frame rate varies with shutter speed. The number of pictures that can be recorded depends on the memory available.

FACE DETECTION

Choose whether the camera automatically detects and sets focus and exposure for human portrait subjects (P 29).

CONTINUOUS..

Description

65Menus

Using the Menus: Shooting Mode

F F AF MODE

Option

Description

RRNote that in

mode, the camera focuses continuously, increasing the drain on the battery,

and that the sound of the camera focusing may be audible.

VV MOVIE QUALITY

((defaults to

qq LED ILLUMINATOR

((defaults to

OFF)

Option

Description

OFF

RRThe LED will not light when

is selected for

SILENT MODE

in the setup menu (

RRSelecting

increases the drain on the battery. Select

OFF

when the LED is not in use.

AF MODE

This option controls how the camera selects the focus area. Regardless of the option selected, the camera will focus on the subject in the center of the LCD monitor when macro mode is on.

Option

r CENTER

x TRACKING

Note that in xx and that the sound of the camera focusing may be audible.

MOVIE QUALITY

Choose a frame size for movies (P 45).

LED ILLUMINATOR

Choose whether the LED (P 2) lights to illuminate nearby subjects when lighting is poor.

Option

The LED will not light when ONON Selecting ONON

The camera focuses on the subject in the center of the frame. Position the subject in the center focus area and press the selector left. Focus will

track the subject as it moves through the frame.

mode, the camera focuses continuously, increasing the drain on the battery,

ON The LED lights during shooting.

OFF LED o .

increases the drain on the battery. Select

is selected for oo

Description

SILENT MODE

OFF

in the setup menu (PP 77).).

when the LED is not in use.

defaults to ff))

defaults to

OFF)

66 Menus

Using the Menus: Playback Mode

Using the Playback Menu

Playback Menu Options

k k PHOTOBOOK ASSIST

b b IMAGE SEARCH

A A ERASE

Using the Menus: Playback Mode

Using the Playback Menu

To display the playback menu, press MENU/OK in playback mode. Highlight items and press the selector right to view options, then highlight an option and press MENU/OK. Press DISP/BACK to exit when settings are complete.

Playback Menu Options

PHOTOBOOK ASSIST

Create books from your favorite photos (P 42).

IMAGE SEARCH

Search for pictures (P 41).

ERASE

Delete all or selected pictures (P 40).

67Menus

Using the Menus: Playback Mode

c c EDIT

Option

Description

CROP

ASPECT RATIO

BRIGHTNESS

CONTRAST

COLOR

SEPIA

FACE MOSAIC

RRRetouched copies can not be further retouched, cropped, or rotated. RRRetouched copies are 640 × 480 pixels in size.

EDIT

Create a retouched copy of the current picture.

Display the desired picture.

Select c EDIT in the playback menu and choose from the following options:

Option

CROP Crop the copy.

ASPECT RATIO Choose the aspect ratio.

BRIGHTNESS Adjust brightness.

CONTRAST Adjust contrast.

COLOR Choose positive values for “warmer” colors, negative values for “cooler” colors.

SEPIA Convert the copy to sepia or black and white.

If the original was taken with Intelligent Face Detection, a mosaic e ect can

FACE MOSAIC

Press MENU/OK to create a retouched copy (in some cases, additional options will be displayed;

adjust settings as desired and press MENU/OK to save the copy).

Retouched copies can not be further retouched, cropped, or rotated. Retouched copies are 640 × 480 pixels in size.

be applied to up to four faces. If Intelligent Face Detection was o or no faces were detected, the mosaic e ect will be applied to the center of the image.

Description

68 Menus

Using the Menus: Playback Mode

j j MARK FOR UPLOAD TO

RROnly movies can be selected for upload to YouTube. RRDuring playback, selected pictures are indicated by

YouTube

FACEBOOK

icons.

MARK FOR UPLOAD TO

Select pictures for upload to YouTube or Facebook using MyFinePix Studio (Windows only).

■ Selecting Pictures for Upload Select YouTube to choose movies for upload to YouTube, FACEBOOK to choose photos and

movies for upload to Facebook.

Press the selector left or right to display pictures and press MENU/OK to select or deselect. Press

DISP/BACK to exit when all the desired pictures are selected.

Only movies can be selected for upload to YouTube. During playback, selected pictures are indicated by jj

■ RESET ALL: Deselecting All Pic tures

Choose RESET ALL to deselect all pictures. If the number of pictures a ected is very large, a message will be displayed while the operation is in progress. Press DISP/BACK to exit before the operation is complete.

■ Uploading Pictures ( Windows Only)

Selected pictures can be uploaded using the YouTube/Facebook Upload option in MyFinePix Studio.

Select with camera

For information on installing MyFinePix Studio and connecting the camera to a computer, see “Viewing Pictures on a Computer” (P 53).

YouTube

or jj

FACEBOOK

Upload from computer

icons.

69Menus

Using the Menus: Playback Mode

I I SLIDE SHOW

Option

Description NORMAL FADE-IN

NORMAL

FADE-IN

MULTIPLE

SCRAP BOOK VIEW

SELECT BGM

RRThe camera will not turn o automatically while a slide show is in progress.

SLIDE SHOW

View pictures in an automated slide show. Choose the type of show and press MENU/OK to start. Press DISP/BACK at any time during the show to view on-screen help. The show can be ended at any time by pressing MENU/OK.

Option NORMAL FADE-IN

NORMAL gg

FADE-IN gg

MULTIPLE Display several pictures at once.

SCRAP BOOK VIEW Display multiple pictures in random positions and sizes.

SELECT BGM Choose background music.

The camera will not turn o automatically while a slide show is in progress.

Press selector left or right to go back or skip ahead one frame. Select FADE-IN for fade transitions between frames.

As above, except that camera automatically zooms in on faces selected with Intelligent Face detection.

Description

70 Menus

Using the Menus: Playback Mode

B B RED EYE REMOVAL

RRRed eye may not be removed if the camera is unable to detect a face or the face is in pro le.

Results may di er depending on the scene. Red eye can not be removed from pictures that

have already been processed using red-eye removal or pictures created with other devices. RRThe amount of time needed to process the image varies with the number of faces detected. RRCopies created with

RED EYE REMOVAL

are indicated by a

icon during playback.

D D PROTECT

QQProtected pictures will be deleted when the memory card or internal memory is formatted

(

51).

RED EYE REMOVAL

If the current picture is marked with a g icon to indicate that it was taken with Intelligent Face Detection, this option can be used to remove red-eye. The camera will analyze the image; if redeye is detected, the image will be processed to create a copy with reduced red-eye.

Display the desired picture.

Select B RED EYE REMOVAL in the playback menu.

Press MENU/OK.

Red eye may not be removed if the camera is unable to detect a face or the face is in pro le. Results may di er depending on the scene. Red eye can not be removed from pictures that have already been processed using red-eye removal or pictures created with other devices. The amount of time needed to process the image varies with the number of faces detected. Copies created with

PROTECT

Protect pictures from accidental deletion.

Select D PROTECT in the playback menu.

Highlight one of the following options and press MENU/OK:

• FRAME: Protect selected pictures. Press the selector left or right to view pictures and press MENU/OK to select or deselect. Press DISP/BACK when the operation is complete.

• SET ALL: Protect all pictures.

• RESET ALL: Remove protection from all pictures.

Protected pictures will be deleted when the memory card or internal memory is formatted (P

51).

RED EYE REMOVAL

are indicated by a

icon during playback.

71Menus

Using the Menus: Playback Mode

G G CROP

RRLarger crops produce larger copies; all copies have an aspect ratio of 4 : 3. If the size of the  nal

copy will be

, , YES

will be displayed in yellow.

OO RESIZE

RRThe sizes available vary with the size of the original image.

CROP

Create a cropped copy of the current picture.

Display the desired picture.

Select G CROP in the playback menu.

Use the zoom control to zoom in and out and use the selector to scroll the picture until the

desired portion is displayed.

Press MENU/OK to display a con rmation dialog.

Press MENU/OK again to save the cropped copy to a separate  le.

Larger crops produce larger copies; all copies have an aspect ratio of 4 : 3. If the size of the  nal copy will be

RESIZE

Create a small copy of the current picture.

Display the desired picture.

Select O RESIZE in the playback menu.

Highlight a size and press MENU/OK to display a con rmation dialog.

Press MENU/OK to save the resized copy to a separate  le.

The sizes available vary with the size of the original image.

YES

will be displayed in yellow.

72 Menus

Using the Menus: Playback Mode

CC IMAGE ROTATE

RRProtected pictures can not be rotated. Remove protection before rotating pictures ( RRThe camera may not be able to rotate pictures created with other devices.

EE COPY

RRCopying ends when the destination is full. RRDPOF print information is not copied (

IMAGE ROTATE

Rotate pictures taken in tall orientation so that they are displayed in tall orientation in the LCD monitor.

Display the desired picture.

Select C IMAGE ROTATE in the playback menu.

Press the selector down to rotate the picture 90 ° clockwise, up to rotate it 90 ° counterclock-

wise.

Press MENU/OK. The picture automatically be displayed in the selected orientation whenever

it is played back on the camera.

Protected pictures can not be rotated. Remove protection before rotating pictures (P 71).). The camera may not be able to rotate pictures created with other devices.

COPY

Copy pictures from internal memory to a memory card.

Select E COPY in the playback menu.

Highlight one of the following options and press the selector right:

• a INTERNAL MEMORY y b CARD: Copy pictures from internal memory to a memory card.

• b CARD y a INTERNAL MEMORY: Copy pictures from a memory card to internal memory.

Highlight one of the following options and press MENU/OK:

• FRAME: Copy selected pictures. Press the selector left or right to view pictures and press MENU/OK to copy the current picture.

• ALL FRAMES: Copy all pictures.

Copying ends when the destination is full. DPOF print information is not copied (P 51).).

73Menus

Using the Menus: Playback Mode

SS TRANSITION

((defaults to

OFF)

Option

Description

WIPE SLIDE-IN FADE-IN

OFF

LL MOVIE TRIMMING

TRANSITION

Choose the transition between images during playback.

Option

WIPE Choose for a wipe transition between images.

SLIDE-IN Images slide into the display.

FADE-IN The next image fades in as the previous image fades out.

OFF No transition between frames.

MOVIE TRIMMING

Remove opening or ending footage to create an edited copy of the current movie.

Display the desired movie.

Select L MOVIE TRIMMING in the playback menu. To remove footage from the start of the

copy, proceed to Step 3; otherwise, proceed to Step 4.

Press the selector down to begin playback and press it down again when the new opening

frame is reached.

Press MENU/OK. To remove footage from the end of the copy, proceed to Step 5; otherwise,

proceed to Step 6 (to exit without creating an edited copy, press DISP/BACK).

Press the selector down to begin playback and press it down again when the new closing

frame is reached.

Press MENU/OK to save the copy.

Description

defaults to

OFF)

74 Menus

Using the Menus: Playback Mode

PP MOVIE JOIN

RRBoth movies must have been recorded at the same frame size and frame rate and have a

combined  le size of no more than 2GB.

KK PRINT ORDER (DPOF)

MOVIE JOIN

Add existing footage to the end of the current movie to create an edited copy.

Display the desired movie.

Select P MOVIE JOIN in the playback menu.

Press the selector left or right to highlight a movie.

Press MENU/OK to add the highlighted footage to the end of the current movie and save the

resulting copy, or press DISP/BACK to exit without creating a copy.

Both movies must have been recorded at the same frame size and frame rate and have a combined  le size of no more than 2GB.

PRINT ORDER (DPOF)

Select pictures for printing on DPOF- and PictBridge-compatible devices (P 49).

75Menus

The Setup Menu

Using the Setup Menu

The Setup Menu

Using the Setup Menu

Display the setup menu.

1.1 Press MENU/OK to display the menu for the cur-

rent mode.

1.2 Press the selector left to highlight the tab for the current menu.

SET

tab

SET-UP

SET

EXIT

1.3 Press the selector down to highlight X.

1.4 Press the selector right to place the cursor in the setup menu.

Adjust settings.

Highlight items and press the selector right to view options, then highlight an option and press MENU/OK. Press DISP/BACK to exit when settings are complete.

76 Menus

The Setup Menu

Setup Menu Options

F F DATE/TIME

NN TIME DIFFERENCE

((defaults to

Option

Description

hh HOME

gg LOCAL

L L a

((defaults to

ENGLISH)

o o SILENT MODE

((defaults to

OFF)

Setup Menu Options

DATE/TIME

Set the camera clock (P 18).

TIME DIFFERENCE

Switch the camera clock instantly from your home time zone to the local time at your destination when traveling. To specify the di erence between local time and your home time zone:

Highlight g LOCA L and press the selector right.

Use the selector to choose the time di erence between local time and your home time zone

in increments of 15 minutes.

Press MENU/OK.

To switch between local time and your home time zone, highlight g LOC AL or h HOME and press MENU/OK.

Option

HOME Switch to the time currently selected for F DATE/TIME (P 18).

Choose a language (P 104).

SILENT MODE

Select ON to disable the speaker,  ash, and LED illuminator in situations in which camera sounds or lights may be unwelcome (note that the  ash will still  re in C mode).

Switch to local time. If this option is selected, g and the time and date will be

LOCA L

displayed in yellow for three seconds each time the camera is turned on.

Description

defaults to hh))

defaults to

ENGLISH)

OFF)

77Menus

The Setup Menu

R R RESET

K K FORMAT

QQAll data—including protected pictures—will be deleted from the memory card or internal

memory. Be sure important  les have been copied to a computer or other storage device.

QQDo not open the battery cover during formatting.

A A IMAGE DISP.

((defaults to

1.5 SEC)

Option

Description

3 SEC

1.5 SEC

ZOOM (CONTINUOUS)

OFF

RROFF

has no e ect in continuous shooting mode.

RESET

Reset all settings except F DATE/TIME, N TIME DIFFERENCE, and Q VIDEO SYSTEM to de- fault values.

Highlight R RESET and press the selector right to display a con rmation dialog.

Highlight OK and press MENU/OK.

FORMAT

If a memory card is inserted in the camera, this option will format the memory card. If no memory card is inserted, this option will format internal memory. Select OK to begin formatting.

All data—including protected pictures—will be deleted from the memory card or internal memory. Be sure important  les have been copied to a computer or other storage device. Do not open the battery cover during formatting.

defaults to

IMAGE DISP.

Choose how long pictures are displayed in the LCD monitor after shooting.

Option

3 SEC

1.5 SEC

ZOOM (CONTINUOUS) Pictures are displayed until the MENU/OK button is pressed.

OFF Pictures are not displayed after shooting.

OFF

has no e ect in continuous shooting mode.

Pictures are displayed for three seconds (3 SEC) or 1.5 seconds (1.5 SEC). Colors may di er slightly from those in the  nal image.

Description

1.5 SEC)

78 Menus

B B FRAME NO.

((defaults to

CONT.)

100-0001

Option

Description

CONTINUOUS

RENEW

RRIf the frame number reaches 999-9999, the shutter release will be disabled (

96).

RRSelecting

RESET

78) sets

FRAME NO.

CONTINUOUS

but does not reset the  le

number.

RRFrame numbers for pictures taken with other cameras may di er.

FRAME NO.

New pictures are stored in image  les named using a four-digit  le number assigned by adding one to the last  le number used. The  le number is displayed during playback as shown at right. B FRAME NO. controls whether  le numbering is reset to 0001 when a new memory card is inserted or the current memory card or internal memory is formatted.

Option

Description

Numbering continues from the last  le number used or the  rst available  le num-

CONTINUOUS

ber, whichever is higher. Choose this option to reduce the number of pictures with duplicate  le names.

RENEW

If the frame number reaches 999-9999, the shutter release will be disabled (P Selecting number. Frame numbers for pictures taken with other cameras may di er.

Numbering is reset to 0001 after formatting or when a new memory card is inserted.

RESET ( (P

78) sets

FRAME NO.

CONTINUOUS

but does not reset the  le

The Setup Menu

defaults to

Frame number

Directory number

96).

CONT.)

100-0001

File

number

79Menus

The Setup Menu

GG OPERATION VOL.

((defaults to

HH SHUTTER VOLUME

((defaults to

ee SOUND

((defaults to

I I PLAYBACK VOLUME

((defaults to

JJ LCD BRIGHTNESS

((defaults to

AUTO)

Option

Description

AUTO

MANUAL

OPERATION VOL.

Adjust the volume of the sounds produced when camera controls are operated. Choose f (mute) to disable control sounds.

SHUTTER VOLUME

Adjust the volume of the sounds produced when the shutter is released. Choose f (mute) to disable the shutter sound.

SOUND

Choose the sounds used for the shutter, at startup, and for camera controls.

PLAYBACK VOLUME

Adjust the volume for movie playback.

LCD BRIGHTNESS

Control the brightness of the display.

Option

AUTO

MANUAL

Display brightness is automatically adjusted during shooting in response to ambient lighting conditions. Brightness is not adjusted during playback.

Press the selector up or down to adjust brightness and then press MENU/OK. Choose from values between –5 and +5.

Description

defaults to cc))

defaults to ii))

defaults to 7)7)

defaults to

AUTO)

80 Menus

The Setup Menu

E E LCD MODE

((defaults to

ON)

Option

Description

U U POWER SAVE ON

U U POWER SAVE OFF

M M AUTO POWER OFF

((defaults to

2 MIN)

L L DUAL IS MODE

((defaults to

B B RED EYE REMOVAL

((defaults to

ON)

RRRed-eye reduction is performed only when a face is detected.

LCD MODE

Choose whether the display automatically dims to save power in shooting mode. This option does not take e ect during playback.

Option

The display dims to save power if no operations are performed for a few

POWER SAVE ON

POWER SAVE OFF

AUTO POWER OFF

Choose the length of time before the camera turns o automatically when no operations are performed. Shorter times increase battery life; if OFF is selected, the camera must be turned o manually. Note that in some situations the camera turns o automatically even when OFF is selected.

DUAL IS MODE

Choose whether image stabilization is performed at all times when the camera is in shooting mode (l CONTINUOUS), or only when the shutter button is pressed halfway (m SHOOT-

ING ONLY). Choose OFF to turn image stabilization o when using a tripod.

RED EYE REMOVAL

Choose ON to remove red-eye e ects caused by the  ash when shooting with Intelligent Face Detection.

Red-eye reduction is performed only when a face is detected.

seconds. Normal brightness can be restored by pressing the shutter button halfway.

Automatic dimming o .

Description

defaults to UU

defaults to

defaults to ll))

defaults to

ON)

2 MIN)

ON)

81Menus

The Setup Menu

DD DIGITAL ZOOM

((defaults to

OFF)

The Zoom Indicator

DIGITAL ZOOM

o

QQDigital zoom produces lower quality images than optical zoom.

nn SAVE ORG IMAGE

((defaults to

OFF)

cc GUIDANCE DISPLAY

((defaults to

ON)

defaults to

DIGITAL ZOOM

If ON is selected, selecting T at the maximum optical zoom position will trigger digital zoom, further magnifying the image.

The Zoom Indicator

OFF)

DIGITAL ZOOM

Optical zoom Digital zoom

DIGITAL ZOOM

Digital zoom produces lower quality images than optical zoom.

SAVE ORG IMAGE

Select ON to save unprocessed copies of pictures taken with red-eye removal.

GUIDANCE DISPLAY

Choose whether to display tool tips.

o

Optical zoom

defaults to

OFF)

ON)

82 Menus

Q Q VIDEO SYSTEM

((defaults to

NTSC)

Option

Description

NTSC

PAL

VIDEO SYSTEM

Choose a video mode for connection to a TV. SECAM is not supported.

Option

NTSC

PAL

Select this mode for connection to video devices in North America, the Caribbean, parts of Latin America, and some East Asian countries.

Select this mode for connection to video devices in the United Kingdom and much of Europe, Australia, New Zealand, and parts of Asia and Africa.

Description

The Setup Menu

defaults to

NTSC)

83Menus

Technical Notes

Optional Accessories

■■Computer Related

■■Printing

■■Audio/Visual

Technical Notes

Optional Accessories

The camera supports a wide range of accessories from FUJIFILM and other manufacturers.

Printing

USB cable

(supplied)

DIGITAL CAMERA

FINEPIX XP20 Series

Audio/Visual

A/V cable (optional)

PictBridge-compatible

printer

Computer Related

Computer

* Available separately.

SD/SDHC/SDXC

memory card

Printer

USB cable (supplied)

SD card slot or card reader

HDMI cable

(sold separately)

HDP-L1

HD player

† SDXC cards not supported.

†

HDTV

FUJIFILM XP20 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
