Page 1
THE CREATIVITY AND FUN ARE BUILT IN
If you’ve ever wondered whether a digital camera can combine quality and simplicity,
the DS-330 has all the right answers. In a moment, you’ll discover that it couldn’t be
easier to use. And a glance at the image quality will tell you that the performance and
resolution are comparable to those of our most advanced digital SLRs.
FUJIX DIGITAL CAMERA
DS-330
Page 2
Everyone has heard about the promise of digital photography. Reviewing a shot immediately.
Easy image processing. Fast data transfer and transmission.
All the automated functions you’re used to. And a lot more.
It’s time to get serious about the possibilities because the DS-330 delivers all this
performance and raises image quality to another level. It’s everything you’ve been waiting
for (plus some very interesting extras). So see for yourself what the DS-330 can do.
And discover the power of the digital imagination.
The Power
of
the Imagination
FUJIX Digital Camera
DS-330
All pictures on this page were taken with the DS-330. Shooting information is on the back cover.
12
3
654
7
FUJI PHOTO FI LM CO., LTD.
26-30, NISHIAZABU 2-CHOME, MINATO-KU, TOKYO 106, JAPAN
Page 3
Check the resolution of an image taken with the DS-330, and examine the color reproduction. You’ll be pleasantly
surprised to find the image quality is close to the results you get with silver-halide film. Until you see it for yourself,
that might sound impossible, but the DS-330 was created to make you a believer.
EXPECT THE UNEXPECTED
Perfect vision
If you’re wondering how the
DS-330’s images can approach
photographic quality, think of
the 2/3-inch CCD as a “digital
eye.” It’s the same one used
in our top-of-the-line DS560/565 digital SLRs, and it
has 1.4 million pixels (effectively 1.3 million in an array of
1,280
× 1,000 pixels). This
integration is so advanced that
the resolution is almost four
times higher than the 640
×
480 pixels of a VGA.
The number of pixels is a
sign of image quality, but their
proportions are just as important. With square pixels specially for a digital camera, there’s
no need to adjust the horizontal/vertical ratio when data are
input to a PC. That means data
transfer is faster and image
quality isn’t affected.
The DS-330 also has an
RGB filter which reproduces
colors much more accurately
than a conventional complementary-color filter. The difference this primary-color filter
makes is particularly noticeable
with high saturation and gray
tones—areas where other digital
cameras usually fall short.
Normal
3
× Zoom
An exact balance
Whether you’re shooting at
midday or in the soft light at
the end of day, you can optimize the exposure with the
DS-330’s three-step White
Balance system. Fixed at
5500K, the Standard setting is
suited to daylight. Option 1 is
specially for the continuous
light including artificial lighting as well as low light at
sunset and nighttime. And
Option 2 adjusts the white balance for flash photography in
a studio.
Top: STD Mode (640 × 480 pixels),
1/500 sec. F5.6, Hi setting
Middle: Opt. 1 Mode (640 × 480 pixels),
1/60 sec. F3.5, Hi setting
Above: Opt. 2 Mode (1,280 × 1,000 pixels),
1/125 sec. F8, Fine setting
The professional’s choice
Whether you’re using a 35 mm
camera or a digital model, no
image can be better than your
lens. That’s why the DS-330
has a Super EBC Fujinon
Lens—a highly regarded design
that’s even used in professional
broadcast cameras. To eliminate
ghosting and flare, it has an
exclusive EBC multi-coating.
To cover focal lengths
equivalent to the 35–105 mm
range of a 35 mm camera, simply press the electronic Zoom
Button. The Optical 3
× Mode is
always ready for wide-angle and
telephoto shots.
When a subject is unusually
far away, just switch to the
Digital 2
× Mode for a 6× tele-
photo setting comparable to a
conventional camera’s 210 mm
focal length. There’s also a
Macro function for images in
full A5 size (half of letter size)
shot from as close as 20 cm
(7.8 in.).
The mind’s eye
The DS-330 has five exposure
modes. In the Auto Mode,
optimal shooting settings are
determined automatically for
the aperture, shutter speed,
focusing and more. Choose the
Programmed AE Mode, and
the camera will determine the
optimal combination of aperture and shutter speed. For
greater creative control, use
the Aperture-Priority Mode,
Shutter Speed-Priority Mode
or even Manual Mode.
Capable of handling the most
complicated lighting, it also
has a TTL Intelligent AE system that reads the lighting at
nine points in the frame and
calculates the appropriate
exposure automatically.
You’ll find some extras as
well. If you decide to capture a
scene in an expressive grayscale image, use the B/W Mode
to be sure that you record all the
gradations.
When you want to accentuate the contrast and sharpen the
edges, the Clear
Mode will create
a dramatic effect.
6× Zoom
(with Digital Zoom)
Image Memory Card
PC Card
Adapter
SmartMedia
TV Monitor
TTL Viewfinder
Computer
NTSC/PAL
GPS Receiver
Computer
Serial
SCSI
SCSI
SCSI
PC Card
Reader
Digital Color Printer
Pictrography 3000
Digital Color Printer
NC-300D
Extension Unit
Digital Camera
DS-330
Computer
Page 4
Sophisticated functions and the easy operation of a point-and-shoot camera are only some of the DS-330’s handling
advantages. Its digital capabilities open up almost limitless possibilities.
And you’ll quickly discover they’re only the beginning.
A NEW DEPARTURE
Integration means innovation
The DS-330’s high-precision
Super Hybrid Autofocus system
makes focusing incredibly fast
and absolutely accurate. It’s
based on an integration of active
and passive AF as well as CCD
AF. Of course, you can also
control the focus manually just
by turning the Up/Down Dial to
the appropriate setting.
Friendly formats
The DS-330 records images in
Fujifilm’s original Exif (JPEG)
format* on an ATA-compliant
PC Card. The widely used international JPEG standard eliminates any worries about PC
compatibility, while the Exif
format automatically records
information such as thumbnail
images, the date, aperture, shutter speed and other shooting data.
*
In the Hi Mode, the TIFF-YC format is used for
recording. Fujifilm’s optional software is required
to open the images.
Both practical and elegant
The DS-330 is the first digital
camera with a body made from a
corrosion-resistant, high-purity
magnesium compound. Created
with a special Thixomolding
process, it has the unmistakable
look and feel of quality. Even
more important, it offers the
durability, precision and light
weight that are impossible to
achieve with plastic. There’s
also an aluminum lens barrel
that’s exceptionally strong and
finished to exacting tolerances.
The creative edge
For all its sophistication, the
DS-330 simplifies creativity at
every step.
Just add the optional LV-D3
LCD Viewfinder, and you’ll
have a real image of your subject, without any worries about
parallax distortion. During capture, you can see the image
through the lens, then review it
afterwards. Since the viewfinder
can be turned to any angle, it’s
always easy to compose, even
when the camera is held very
low. The LCD Viewfinder also
gives you a display of essential
information including the aperture setting, shutter speed and
exposure compensation.
To use an external flash,
simply attach it to the hot shoe
on top of the camera.
For fast
and simple
data transfer
to a computer, input
image files
directly
from the PC Card or connect the
DS-330 with an RS-232C cable.
You can also speed up transfers
by adding an optional Extension
Unit with a SCSI connection
that will move your image files
almost before you know it.
A free hand
The DS-330 gives you both
freedom and control. Use the
Mode Dial and the Up/Down
Dial to set the combination
you want, from the exposure,
manual focus and autofocus to
the ISO sensitivity and more.
Checking your settings is as
easy as glancing at the large,
easy-to-read LCD Panel. And
Quick Select simplifies handling further by letting you program Custom Ready with the
settings you use most often.
Image Memory Card
PC Card
Adapter
SmartMedia
TV Monitor
TTL Viewfinder
Computer
NTSC/PAL
GPS Receiver
Computer
Serial
SCSI
SCSI
SCSI
PC Card
Reader
Digital Color Printer
Pictrography 3000
Digital Color Printer
NC-300D
Extension Unit
Digital Camera
DS-330
Computer
(1,280 × 1,000 pixels), 1/125 sec. F8, Fine setting
Page 5
T o maximize the DS-330’s performance (and get more out of your photography), add an optional Extension Unit.
Whether you want to expand your creative opportunities or handle data more efficiently,
it will give you all the tools you need. Very , very quickly.
EVERY SECOND COUNTS
Move into action
Unless you have the right
equipment, action photography
takes luck as well as skill.
That’s why you’ll welcome the
ways that the DS-330’s
Extension Units’ Continuous
Mode can open up new subjects and approaches.
Both the EU-D3 and EUD3A Extension Units can
record up to 4.5 frames per
second. The EU-D3 can capture three frames in succession, while the EU-D3A can
shoot a sequence of 12
frames.
Continuous Mode (1,280
× 1,000 pixels), 1/60
sec. F5.6, Fine setting
System configuration
The SCSI connection
The Extension Units have the
answer when you want to
move files faster than a serial
port connection allows. Just
connect a cable to a PC from
the SCSI port for superhighspeed data transfers.
You can also use the
Extension Units to control the
camera from a PC during
shooting, and then record the
data on your PC.
Take the direct approach
When you add an Extension
Unit, you can also use the
SCSI port for direct output to a
digital color printer such as the
Fujifilm Digital Color Printer
NC-300D or Pictrography 3000.
Simple and fast, this solution
avoids the bother of transferring data to your PC before
you can print an image. Not
only for full-frame images, the
Extension Unit can also output
an Index Print with reduced
images of the shots you’ve
recorded on the PC Card.
Image Memory Card
PC Card
Adapter
SmartMedia
TV Monitor
TTL Viewfinder
Computer
NTSC/PAL
GPS Receiver
Computer
Serial
SCSI
SCSI
SCSI
PC Card
Reader
Digital Color Printer
Pictrography 3000
Digital Color Printer
NC-300D
Extension Unit
Digital Camera
DS-330
Computer
Page 6
Ref. No. EB-807E(SK·98·06·DT·MW) Printed in Japan © 1998 Fuji Photo Film Co., Ltd.
Interface Kit
IF-D3*
The interface kit includes an
RS-232C cable and TWAINcompliant driver software for
transferring image data
directly to a Windows
®
or
Macintosh
®
computer.
LCD Viewfinder
LV-D3
The LV-D3 lets you check
the image through the lens
and review it immediately.
With the versatile angleadjustment mechanism,
composition is easy wherever the camera is held.
Dust Cover
CV-D3
DS Camera Plug-in
Module for
Photoshop™
SD-D5
The SD-D5 plug-in module
can check shooting data and
image files; it opens JPEG
and TIFF-YC files. Versions
for Windows ’95/3.1
®
and
Macintosh
®
are included.
Rechargeable Battery NP-510
Remote Release RE-HC**
Slave Adapter SA-D5**
Converter Cable CC-D3
ACCESSORIES
SPECIFICATIONS
Carrying Case
LC-D3
Extension Units
EU-D3/ EU-D3A*
The optional Extension Units offer Continuous Mode
shooting, direct printing and a SCSI connection (D-sub
25-pin) to a PC. In the Continuous Mode, the EU-D3
can record a sequence of three frames, while the EUD3A can capture 12 frames. TWAIN-compliant driver
software for both Windows
®
and Macintosh®comput-
ers is included.
Image Memory Cards
Power Supply Kit
• An image memory card and the power supply kit are required to use the DS-330.
• Performance with other companies’ cards is not guaranteed.
CCD image sensor • 2/3-inch CCD with 1.4 million pixels
(effectively 1.3 million)
• Square pixels with RGB (primary
color) filter
Storage media • ATA Type I or II PC Card (PCMCIA
release 2.1)
• SmartMedia with PC Card Adapter
File format • JPEG standard (Exif)
• TIFF-YC (Exif)
Number of frames • Hi (TIFF-YC): 4 images
(HG-10 memory card) • Fine (JPEG): 16 images
• Normal (JPEG): 33 images
• Basic (JPEG): 64 images
Resolution • 1,280 × 1,000 pixels
• 640
× 480 pixels
• 8-bit/color (24-bit full color)
ISO • Equivalent to 100/400
Focal lengths • 35–105 mm (35 mm camera equivalent)
Macro shooting • Full A5 size at 20 cm/half of letter size
at 7.8 in.
Autofocus system • Super Hybrid AF system (combining
passive, active and CCD AF)
• Focusing range: 20 cm/7.8 in.~
∞
(including Macro shooting)
Viewfinder • Optical
Shutter speeds • 1/4~1/1,000 sec.
Aperture • F3.5, 5.6, 8 and 11
Exposure control • Programmed AE, Aperture-Priority AE,
Shutter Speed-Priority AE and Manual
Modes
Exposure compensation • 0.3 EV steps (–0.9~+1.8 EV)
White balance • 5500K fixed or one-push auto
Flash • Built-in auto flash; hot shoe for external
flash
Output • Video: Live/Playback (NTSC/PAL);
NTSC (U model) with RCA pin
PAL (E model) with RCA pin
• Digital: Mini DIN (9 pin) for high-speed
transfer with RS-232C cable
Power source • NP-510 lithium ion battery, AC power
adapter
Dimensions • 153 (W) × 96 (H) × 78 (D) mm/
6.0 (W)
× 3.8 (H) × 3.1 (D) in.
Weight • Approx. 620 g/21.9 oz.
(excluding battery and PC Card)
FUJIX DIGITAL CAMERA DS-330
Specifications are subject to change without notice.
HG-5 HG-15HG-10 HG-40
PK-D3
* The TWAIN-compliant driver software, included with the EU-D3 and EU-D3A Extension
Units and IF-D3 interface kit, requires application software such as Adobe Photoshop™.
** Requires Converter Cable CC-D3.
Macintosh®is a registered trademark of Apple Computer, Inc.
Windows®is a registered trademark of Microsoft Corporation.
Adobe Photoshop™ is a trademark of Adobe Systems Inc.
All other trademarks are the property of their respective holders.
12
3
654
7
Shooting information for the introduction page
1 (1,280 × 1,000 pixels), 1/125 sec. F11, Hi setting
2 (1,280 × 1,000 pixels), 1/4 sec. F8, Fine setting
3 B/W mode (1,280 × 1,000 pixels), 1/60 sec. F8, Fine
setting
4 (1,280 × 1,000 pixels), 1/30 sec. F5.6, Fine setting
5 (1,280 × 1,000 pixels), 1/125 sec. F8, Hi setting
6 (1,280 × 1,000 pixels), 1/125 sec. F8, Fine setting
7 (1,280 × 1,000 pixels), 1/6 sec. F5.6, Fine setting
with built-in auto flash
All pictures were taken with the DS-330.
FUJI PHOTO FI LM CO., LTD.
26-30, NISHIAZABU 2-CHOME, MINATO-KU, TOKYO 106, JAPAN
Loading...
