FSP - Power Never Ends
Raider II (450/550/650/750W)
fsp-europe.com /raider2-450550650750w/
All All All > 650W
Best choice in performance – RAIDER II Series
The RAIDER II series are 80 PLUS Silver certified, and stand for the needs of gamers. Custom
DC-DC module offers supreme efficiency and high system compatibility. With all Japan-made ecap., they’re providing extremely stability and reliability. FSP RAIDER II series, will be your best
choice of power supply.
Features:
+12V Single Rail Design
SATA Array Cable Design
120mm Quite Fan
PCI-E 6+2 Pin Connectors
FSP MIA IC™ Inside
80PLUS® Silver Certified, efficiency > 88%
Complies with ATX 12V 2.31 & EPS 12V 2.92 Version
Active PFC
Complete Protections: OCP, OVP, OPP, SCP, UVP
Full Safety Approved
MIA IC™ (Multiple Intelligence Ability) Chip Set
FSP’s own patented designs to provide Ultimate Performance & Highest
Protection to your system!
SATA Array Cable
50mm intervals for 4 SATA device installation
Optimized the airflow in case
No-hassle with case side panel
1/5
Page 2
+12V Single Rail Design
Designed for power-intensive VGA cards.
Provides strong power to any overloading condition
Quiet and durable Cooling
Powered by Sleeve-fan with low noise and long-lasting life span
DC – DC Module Design
Custom DC-DC module offers supreme efficiency and,
high system compatibility. FSP RAIDER II series, be your best choice of power
supply
Active PFC
Power Factor ≥ 99%
Meet ErP/EuP 2013 Standard
Intel® Skylake™ Platform Ready
Connector Table:
2/5
Page 3
Specifications:
Model RA II450 RA II550 RA II650 RA II750
Effeciency 88%
Input Voltage 100 ~ 240Vac
Frequency 50 ~ 60Hz
PFC Active PFC (0.99)
Power Provided 450W 550W 650W 750W
Over-Current Protection
Over-Voltage Protection
Short-Circuit Protection
Case Color Black
Chassis Fan 120mm
Noise < 21 dBA at 50% loading
Form Factor ATX 12V V2.3 & EPS 12V V2.92
Safety Approval OCP, OVP, SCP, OPP, OTP
Dimensions (LxWxH) mm 150 x 140 x 86
Power Output Table:
450W RA II450
AC Input 100-240Vac ~ 8-4A 50-60Hz
DC Output +3.3V +5V +12 -12V +5Vsb
Max Output Current 20A 20A 37.5A 0.3A 2.5A
3/5
Page 4
Max Combined Power 100W 450W 3.6W 12.5W
Total Power 450W
550W RA II550
AC Input 100-240Vac ~ 8-4A 50-60Hz
DC Output +3.3V +5V +12 -12V +5Vsb
Max Output Current 20A 20A 45.84A 0.3A 3.5A
Max Combined Power 100W 550W 3.6W 17.5W
Total Power 550W
650W RA II650
AC Input 100-240Vac ~ 10-5A 50-60Hz
DC Output +3.3V +5V +12 -12V +5Vsb
Max Output Current 20A 20A 54.17A 0.3A 2.5A
Max Combined Power 130W 650W 3.6W 12.5W
Total Power 650W
750W RA II750
AC Input 100-240Vac ~ 10-5A 50-60Hz
DC Output +3.3V +5V +12 -12V +5Vsb
Max Output Current 20A 20A 62,5A 0.5A 2.5A
Max Combined Power 130W 750W 3.6W 12.5W
Total Power 750W
EAN Code:
Raider II 450 Raider II 550
4711140480053 4711140480060
Raider II 650 Raider II 750
4711140480077 4711140480084
Award / Reviewed by:
