Frymaster YUM Installation Manual

YUM! Wingstreet Computer

Operation Manual

Price $4.00

www.frymaster.com

Frymaster, a member of the Commercial Food Equipment Service Association, recommends
using CFESA Certified Technicians.

24-Hour Service Hotline 1-800-

551-8633

*8196133*

OCT 07

YUM Computer

112354

1-1

1-1

Programming Set Back

1. Computer displays OFF. (Computer must be off to enter programming mode.)

2. Press

3. CODE appears in left display

4. Press

2

1

5. SB TEMP appears in left display with setback point (default is 250F) in right

display.

6. Press

7. SB TIME appears in left display with setback time (default is 15:00) in right

display. Time can be set from 01:00 (one minute) to 60:00 (one hour) using the
product keys.

1

(1212) with product keys.

To disable the setback timer press

one time.

8. Press

9. Computer displays OFF.

10. Press to turn computer on. Right display will read - - - -.

When not cooking, the computer will start the setback timer. When setback time has
passed, the oil temperature will drop to setback point and display will read Not

ready. To resume cooking, press .

Programming New Menu Items

1. Computer displays OFF. (Computer must be off to enter programming mode.)

2. Press .

3. CODE appears in left display

1

4. Press

to advance through menu items. (Use the yellow button to move back). In succession
the following preprogrammed items appear:

5. BIN(a preprogrammed item) appears in the left display; 1 and YES appears in the right

windows.

6. Press the blue button again and BOUT (a preprogrammed item) appears in the left

6

5

(1650) with product keys. Press the blue lane button

2-1
