Frigidaire FGB24L2E C User Manual
Drop-In Cooktop
Single Wall Oven
FPEC3085K S
FGB24L2E C
30" Electric
24" Gas
Product Dimensions
Height 38-7/16"
Width 23-7/8"
Depth 25-3/8"
More Easy-To-Use Features
GlideOut™ Broiler
Bright Oven Lighting
Our bright lighting makes it easy to see
what’s inside.
Timer Function
Manual-Clean Oven
Attractive Stainless Steel
Exterior
A.D.A. Compliant
Available in:
1
Signature Features
Ready-Select® Controls
Easily select options or control
cooking temperature with our
easy-to-use controls.
Vari-Broil™ Option
Allows you to choose between two
heat levels.
Large Capacity
Our large capacity oven gives you room
to cook more at once.
Large Window
Our large oven window lets you easily
see what’s inside.
Stainless
(C)
1
When properly installed, meets the appliance
standards in the Americans with Disabilities Act
and the Architectural Barriers Act Accessibility
Guidelines as published by the United States
Access Board on June 23, 2004, as amended
August 5, 2005.
frigidaire.com
E
D
B
C
A
Features
Oven Control / Timing System
Window
Exterior Door Finish
Handle Design
Oven Cleaning System
Drawer Functionality
Ready-Select®
Large
Real Stainless Steel
Black
Manual Clean
GlideOut™ Broiler
Oven Controls
Bake / Broil
Convection Conversion
Convection Bake / Broil / Roast
Quick Bake Convection
PowerPlus® / Quick Preheat
My Favorite
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Bake
Self-Clean
Rapid / Quick Clean Option
Delay Clean
Kitchen Timer
Timed Cook Option
Control Lock
Auto Oven Shut-O
Oven Lock-Out
Yes /
Variable (Hi - Lo)
Yes
Oven Features
Capacity (Cu. Ft.)
Convection System
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake / Broil Element (BTU)
3.2
1
2 Racks
Regular
Vari-Broil™
16,000 / 16,000
Certifications
A.D.A. Compliant
Sabbath Mode (Star-K® Certified)
1
Yes
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Gas Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 120 Volts
Amps @ 120 Volts
Minimum Circuit Required (Amps)
Approved for Under-Counter
Installation
Shipping Weight (Approx.)
1
When properly installed, meets the appliance standards in the
Americans with Disabilities Act and the Architectural Barriers Act
Accessibility Guidelines as published by the United States
Access Board on June 23, 2004, as amended August 5, 2005.
2
For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded for
safe operation.
2
16" x 18-1/2" x 18-1/2"
Right Bottom Rear
Right Bottom Rear
120V / 60Hz
.001
5.0
15
150 Lbs.
Single Wall Oven
NOTE: For planning purposes only. Always consult local and national electric and gas codes. Refer
to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
Product Dimensions
A - Height
B - Width
C - Depth
D - Height (Wrapper)
E - Width (Wrapper)
Depth with Door Open 90˚
38-7/16"
23-7/8"
25-3/8"
37-3/8"
21-11/16"
43"
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Depth (Min.)
FGB24L2E C 24" Gas
37-1/2"
38"
22"
23-1/2"
•
USA
10200 David Taylor Drive
•
CANADA
FGB24L2E 02/12 © 2012 Electrolux Home Products, Inc.
5855 Terry Fox Way
•
Charlotte, NC 28262
•
Mississauga, ON L5V 3E4
•
1-800-FRIGIDAIRE
•
1-800-265-8352
•
frigidaire.com
•
frigidaire.ca
Accessories information available
on the web at frigidaire.com
Specifications
subject to change.
