Friedrich WS16, WS13, WE13, WE10, WS08 User Manual

...

Thru-the-wall

Air Conditioners and Heat Pumps

115-Volt: WS08, WS10, WS14 230-Volt: WS10, WS13, WS16, WE10, WE13, WE16, WY10, WY13

Installation and Operation Manual

M P

o o C

o M

Mode

Speed

Timer

Hour

On/Off

920-007-13 (8-07)

r e w

o P

Fan

e v a S

y e n

y l n

O n a

c o l C

Set

i T t r

a t S

T p o t

Temp/Hour

920-007-13

Table of Contents

Introduction

Economizing Tips ............................................................................................................................................................................................................................3

WS models

How to operate your Friedrich room air conditioner .......................................................................................................................................................................4

To start unit ....................................................................................................................................................................................................................................... 4

To set mode of operation ..................................................................................................................................................................................................................4

To adjust temperature ...................................................................................................................................................................................................................... 5

To adjust fan speed...........................................................................................................................................................................................................................5

To activate smart fan ........................................................................................................................................................................................................................5

To set hour clock ............................................................................................................................................................................................................................... 5

To set the timer .................................................................................................................................................................................................................................5

Automatic component protection ..................................................................................................................................................................................................... 5

How to use the remote control ......................................................................................................................................................................................................... 6

All models

How to clean the air ﬁ lter ................................................................................................................................................................................................................. 8

How to change airﬂ ow direction .......................................................................................................................................................................................................8

How to cover inner weather panel holes .........................................................................................................................................................................................8

Electrical requirements ....................................................................................................................................................................................................................8

Never use an extension cord ...........................................................................................................................................................................................................8

Power cord information .................................................................................................................................................................................................................... 9

Troubleshooting tips and home maintenance ................................................................................................................................................................................10

Installation instructions for WSC sleeve

Mounting hardware .........................................................................................................................................................................................................................11

Wall preparation ..............................................................................................................................................................................................................................11

Installation requirements ................................................................................................................................................................................................................ 12

Sleeve installation ........................................................................................................................................................................................................................... 12

WallMaster chassis installation instructions: WS, WE and WY models

Installation ....................................................................................................................................................................................................................................... 13

Condensate removal ......................................................................................................................................................................................................................16

Alternate drain kits ..........................................................................................................................................................................................................................16

Warranty ..........................................................................................................................................................................................................................................17

Warranty registration record ..........................................................................................................................................................................................................18

920-007-13

WELCOME to years of economical comfort

Your new Friedrich Room Air Conditioner has been carefully engineered and man u fac tured to give you many years of de pend able, efﬁ cient operation, keeping your room at a comfortable temperature and hu mid i ty level. Many extra fea tures have been built into your Friedrich Room Air Conditioner to assure quiet operation, greatest circulation of cool, dry air, most ﬂ exible selection of function controls, and high economy of operation.

There are many things you can do in and around your home to save more money - and even increase the efﬁ ciency and long life of your Friedrich unit. Here are a few examples:

1. How to Set Thermostat: When you ﬁ rst turn on your air

conditioner, select the highest fan speed and set the ther mo stat to its coldest position to cool the room. When the desired tem per a ture is reached, turn the ther mo stat control toward "warmer" until the compressor goes off. The thermostat will then cause the compressor to go on and off to maintain this selected temperature. You can adjust the fan speed for optimum air circulation.

2. Do not block the ﬂ ow of air to and from the unit - make sure the

louvers are directed to give even dis tri bu tion of air throughout the room. Caution: If air is obstructed and/or deﬂ ected back into the air conditioner, this may cause the unit to cycle on and off rapidly, which could damage your unit.

3. Adequate insulation - walls, ceilings, and below ﬂ oors - can save

up to 50% of the cost of cooling in most areas of the country.

4. Caulking: in well insulated homes, air leaks around doors,

windows, lighting and plumbing ﬁ x tures can account for as much as 30% of the load on heating and cooling systems. See that all these areas are well caulked.

6. Have a ﬁ replace? Be sure the damper is closed during air

conditioner operation.

7. When it’s time to reroof or repaint the outside of your home,

choose light colors. They reﬂ ect heat instead of absorbing it.

8. Shade your outside walls (especially on the west) from the direct sun; most importantly, shade the unit itself Trees and shrubs provide natural shading, but make sure they don’t block the air ﬂ ow around the unit. If natural shade isn’t present, awnings are the best solution for shading the unit and the windows. Also, avoid areas where too much dust or pollen would be drawn into the air conditioner.

9. Inside the house, use blinds, screens, or drapes on windows exposed to the sun. They will reduce your cooling needs. (Lined or insulated draperies will also help cut heating costs in winter).

10. Make sure your attic area is properly vented. In addition, consider installing turbine or power ven ti la tors to help remove hot air from your attic.

11. Keep your Friedrich unit clean. Use a vacuum cleaner attachment for accessible parts, but take care not to damage them. Clean the reusable ﬁ lter at least twice a month.

12. Set the thermostat at a higher temperature - save 5% in energy usage for each degree of temperature over 72°F.

These are the most important suggestions for saving money on cooling costs. Some, however, may not be ap pli ca ble to your house or area. Check with your local utility company for more specialized information.

5. Install weather stripping (metal is preferable to felt) around exterior doors and windows.

Electrical Data

Model Plug Type

WS08, WS10, WS14 NEMA No. 5-15P 125V-15 AMP

WS10, WS13, WS16 NEMA No. 6-15P 250V-15 AMP

WE10, WE13, WE16, WY10, WY13

NEMA No. 6-20P 250V-20 AMP

Circuit Rating, Breaker

or Time Delay Fuse

920-007-13

How to operate your Friedrich room air con di tion er

To start unit

If your air conditioner is installed and plugged into a proper re cep ta cle,

it is ready to go. The ﬁ rst time the unit is started, the compressor will

delay for three minutes. See Automatic Component Protection on the

following page.

Touch the Power button once. The unit will automatically be in Cool mode with the temperature set at 75

speed at F1, the sleep setting.

F (24°C) and the fan

To set mode of operation

When you ﬁ rst turn the unit on, it will be in the Cool mode with con-

stant fan.

On WS cool-only models, touch the Mode buton once to activate the MoneySaver

instructions on WY/WE models).

MoneySaver

pres sor so that the fan does not run all the time. This saves

energy and improves de hu mid i ﬁ ca tion. MoneySaver® will also

run to test the temperature if the off cycle is too long. Or you may prefer con stant fan for more air move ment. (To return to

constant fan, touch the Mode button two more times).

In order to run the fan by itself, do the following:

(WS models only. See item 14 for Money Saver

is a feature that cycles the fan with the com-

To activate Smart Fan (WY/WE heat-cool models)

Press the Smart Fan button to activate the Smart Fan. The light

will indicate that this feature is in use.

Smart Fan will adjust the fan speed automatically to maintain the desired comfort level. For example, if the outside doors in your home are opened for an extended period of time, or more people enter a room, Smart Fan may adjust to a higher fan speed to compensate for the increased heat load. This keeps you from having to adjust the fan speed on your own.

To set the hour clock

Touch the Set Hour button to see the current setting. The

number that is displayed is the approximate time (hour only). Use the and buttons to change the settings. BE SURE TO SET A.M. AND P.M. ACCORDINGLY. (P.M. is indicated by a red light in the upper left corner of the display).

To set the timer

NOTE: Set the HOUR CLOCK (Set Hour) before attempting to set

timer functions.

You can set the Start Time and Stop Time a minimum of one hour

apart, and a maximum of 23 hours apart.

On WY/WS heat-cool models, touch the Mode button once to

activate the Fan Only feature. The Fan Only setting will circulate

air in the room without the compressor coming on.

Continuing from MoneySaver

once to activate the Fan Only feature (WS cool-only models.

mode, touch the Mode button

To adjus t temperature

Use the Mode button to select either the Cool or MoneySaver

function (or Heat for WY/WE heat-cool models)

COOLER – Touch the button to lower the room air temperature.

WARMER – Touch the button to raise the ro om air temperature.

Press both the and buttons at the same time to switch

the temperature from Fahrenheit (°F) to Celsius (°C). Repeat Step 7 to switch from °C back to °F.

To adjust fan speed

Touch the Fan Speed button to see the current setting. Touch

it again to change speed. F1 is the lowest setting (SLEEP

SETTING / LOW), F2 is MEDIUM, and F3 is HIGH.

To activate Smart Fan (WS cool-only models)

There is a four th option, SF, when selecting the fan speed. This is

the SMART FAN function. SMART FAN DOES NOT OPERATE IN CONJUNCTION WITH THE FAN ONLY MODE.

After setting the time, press the Set Hour button once (Start

light on). Use the and buttons to select the time that the

unit will START.

After selecting the Start Time, press the Set Hour button once.

(Stop Light on). Use the and

that the unit will STOP. After selecting the stopping time, press the Set Hour button once.

Press the Timer On/Off button (light turns on) to activate the

timer function. To deactivate this function, press the Timer On/Off button once again (light turns off). Once the on and

off times have been selected, they will remain in memory and cycle daily until changed.

NOTE: If the unit is unplugged or the power is interrupted, the HOUR must be reset or the Timer On/Off will not function when desired.

buttons to select the time

To Activate Money Saver (WY/WE models)

Press the M oney Saver button to activate the Money Saver

feature. The light will indicate the Money Saver is in use.

MoneySaver

pres sor so that the fan does not run all the time. This saves energy and improves de hu mid i ﬁ ca tion. MoneySaver® will also

run to test the temperature if the off cycle is too long. Or you

may prefer con stant fan for more air move ment. (To return to

constant fan, touch the Mode button two more times).

is a feature that cycles the fan with the com-

920-007-13

2 3

10 11 12

Set

Cool

Fan On ly

Heat

Clock

Start Time

Stop Time

Smart Fan

Money

Saver

Fan

Speed

Timer

On/Off

Mode

Hour

Power

Temp/Hour

2 3 4

10 11 12

Speed

Timer

On/Off

Fan

Mode

Hour

Set

Cool

Money Saver

Fan On ly

Clock

Start Time

Stop Time

Power

Temp/Hour

Figure 1 : WS Model cool-only control panel Figure 2: WY/WE Model heat-cool control panel

Automatic component protection

Your unit is equipped with Automatic Component Protection.

To protect the compressor of the unit, there is a three minute delay if you turn the unit off or if power is interrupted. The fan will not be

affected. Also, if you switch from Cool mode to Fan Only mode, and switch back to Cool mode, there is a three-minute delay before the

compressor comes back on.

Using the remote control

To start unit

POWER - Press the Power button once. The unit will automatically

start in the mode and fan speed it was last left on.

To set mode of operation

COOL - Press the Cool button to automatically switch the operat-

ing mode to COOL.

FAN ONLY - Press the Fan O nly button if you want to run the

fan only.

HEAT (WY/WE models only) - Press the Heat button to

automatically switch the operating mode to HEAT.

MoneySaver

- Press the Money Saver

the MoneySaver® feature. This feature cycles the fan with the compressor so that the fan does not run all the time.

button to activate

To adjus t temperature

WARMER - Press the Warmer button to raise the temperature setting.

COOLER - Press the

Cooler button to lower the temperature setting.

To adjust fan speed

FAN S P E ED - Press the Fan Sp eed button to see the current

setting. Press again to change the fan speed. F1 is the lowest setting (SLEEP / LOW), F2 is MEDIUM, F3 is HIGH, and SF is the SMART FAN setting.

To set the hour clock

SET HOUR CLOCK - Press the Set Hr. button once to see the

current clock setting. Continue pressing the button until you arrive at the current time (Hour only). Minutes are not shown on the display. Make sure that the A.M. / P.M. setting is correct.

920-007-13

To set the timer

NOTE: You can set the START and STOP times a minimum of one hour apart, and a maximum of 23 hours apart.

TIMER START - Press Start to view the current start time for cool-

ing. Continue pressing the START button until you arrive at the start time you desire. The start time for cooling will then be set.

TIMER STOP - Press the Stop button. Continue pressing the

STOP button until you arrive at the stop time you desire. The stop time for cooling will then be set.

TIMER ON / OFF - Press the On/Off button (under Timer Operation) to activate (light on) or deactivate (light off) the timer.

Once the on and off times have been selected, they will remain in memory and cycle daily until changed.

NOTE: If the unit is unplugged or the power is interrupted, the Set Hr. function must be reset or the Timer On/Off function will not work.

Temperature

Cooler

Warmer

Power

Cool

Fan

Only Speed Saver

Timer Operation

On/Off

Heat

Money

Fan

Set Hr.

Start

Stop

Figure 3: WY/WE heat-cool model remote control

Additional RC1 wireless remote controls can be purchased from your Friedrich dealer.

How to clean the air filter

Your Friedrich room air conditioner is equipped with a Permafoam reusable air ﬁ lter which is not affected by washing. The ﬁ lter serves to remove dust, pollen, and other impurities from the air.

KEEP THE FILTER CLEAN - A clogged, dirty ﬁ lter will reduce the

operating efﬁ ciency of your unit and contribute to frosting of the indoor coil. Be sure to check the ﬁ lter every 7 to 10 days. The ﬁ lter check procedure is easy, due to the unique design of the Friedrich DECORATIVE FRONT.

FILTER ACCESS - Remove the INTAKE GRILLE from the

DECORATIVE FRONT frame by grasping it at the upper right and left side corners. Pull out until the GRILLE is released from the upper retaining snaps. Tilt down toward you, lift up and out of the bottom retaining snaps. This will expose the ﬁ lter. Remove the ﬁ lter by pulling it toward you. Wash the ﬁ lter in hot, soapy water, rinse, squeeze lightly to remove excess water, shake dry - do not twist - and replace in the unit on the two support hangers. Replace the INTAKE GRILLE by positioning the bottom of the GRILLE into the bottom retaining snaps. Tilt the front up and away from you. Press in lightly on top and the GRILLE will position itself into the upper retaining snaps.

Figure 4

P M

Speed

Mode

C o

Timer

e y

Fan

a v

Hour

ly C lo

c k

Set

S t a

r t T

m S to

p T i

m e

Tem

p/Hour

Intake Grille

Filter
