Foxit RMS PDF Protection Tool - 2.0 Developers Guide

Content

Prerequisites .................................................................................................................. 3

How to Use the SDK ....................................................................................................... 3

Running Your Application ............................................................................................... 4

How to Build Your Application ....................................................................................... 5

Add Security Dynamic Watermark to the File Encrypted by RMS ............................... 14

How to Debug Applications that Use RMS PDF Protection Tool .................................. 17

How to Understand Common Error Conditions and Solutions .................................... 19

Quick Start for Using Windows Azure AD Right Management .................................... 20

Prerequisites

Step 1: Install the AD RMS Services Client

To run this SDK, you must have the latest version of the AD RMS client installed. If you have an

existing older version of the AD RMS client installed, you will need to uninstall the old version first

and then download and install the latest version of the AD RMS client from below: For X86：

http://us-request.foxitservice.com/products/redirect.php?title=ad_rms_sdk_x86&language=en_

For X64：

http://us-request.foxitservice.com/products/redirect.php?title=ad_rms_sdk_x64&language=en_

As for using Windows Azure AD Right Management (AAD RM), please refer to the Quick Start

for Using Windows Azure AD Right Management.

Step 2: Install and configure RMS Server

About how to install and configure an RMS Server, please see AD RMS Step-by-Step Guide .

How to Use the SDK

i. Unzip the installation package to a directory, for example, D:\ Foxit RMS PDF Protection

Tool(SDK).

ii. Add the file frms.h under the directory "Foxit RMS PDF Protection Tool(SDK)\include" to your

project, so that you can check each interface conveniently.

iii. Add the file FPDFRMS.lib to the project, for example, add #pragma comment(lib,"D:\\ Foxit

RMS PDF Protection Tool(SDK)\\library\\FPDFRMS.lib") to the file stdafx.cpp (pre-compiled

file).

iv. Include the header file frms.h in the file which needs to use SDK interfaces, for example, add

include " D:\\ Foxit RMS PDF Protection Tool(SDK)\\library\\frms.h" to the file stdafx.h

(pre-compiled file).

v. Copy the file FPDFRMS.dll under “Foxit RMS PDF Protection Tool(SDK)\library” to the same

directory where your application program locates.

Running Your Application

In order to run your RMS application you need to generate a signed application manifest. This

guide shows how to generate a manifest

On your development machine:

1. Copy the following files to a single directory:

 “Foxit RMS PDF Protection Tool(SDK)\tools\Genmanifest.exe”  “Foxit RMS PDF Protection Tool(SDK)\tools\ isvtier5appsigningprivkey.dat”  “Foxit RMS PDF Protection Tool(SDK)\tools\ isvtier5appsigningpubkey.dat”  “Foxit RMS PDF Protection Tool(SDK)\tools\ isvtier5appsignsdk_client.xml”  “Foxit RMS PDF Protection Tool(SDK)\tools\< YourAppName >.bat”

 “Foxit RMS PDF Protection Tool(SDK)\tools\< YourAppName >.mcf”  < YourAppName >.exe

Note: If it's the pre-production environment, please copy the files “isvtier5appsigningprivkey.dat”,

“isvtier5appsigningpubkey.dat” and “isvtier5appsignsdk_client.xml” under the directory of

“FoxitPDF_ADRMS_SDK_10\tools\pre-production”.

2. In this same directory, use notepad.exe to open the file < YourAppName >.mcf. Modify

the option REQ HASH "YourAppName.exe", and fill in the name of your application program. The file should have the following contents:

AUTO-GUID

"isvtier5appsigningprivkey.dat"

MODULELIST

REQ HASH "YourAppName.exe"

POLICYLIST

INCLUSION

PUBLICKEY "isvtier5appsigningpubkey.dat"

EXCLUSION

NOTE: Ensure that “YourAppName.exe” is consistent with the actual < YourAppName >.exe.

3. In this same directory, use notepad.exe to open the file < YourAppName >.bat. Modify the

option YourAppName.exe.man, and fill in the name of your application program. The file

should have the following contents:

cd %~dp0

genmanifest.exe -chain isvtier5appsignsdk_client.xml YourAppName.mcf

YourAppName.exe.man

NOTE: Ensure that the file YourAppName.mcf and the file “YourAppName” under

YourAppName.exe.man are consistent with the actual ones.

4. You will get a file “YourAppName.exe.man” by double-clicking the file YourAppName.bat.

Note: If the program YourAppName.exe has been modified, you should regenerate the file <

YourAppName >.exe.man.

5. Copy the following files to your RMS server:

 < YourAppName >.exe  < YourAppName >.exe.man  FPDFRMS.dll

6. Run your application. You can run the application from any directory, but your generated

manifest (<YourAppName >.exe.man and FPDFRMS.dll) must be in the same directory as <

YourAppName >.exe

How to Build Your Application

1. Before you can call any functions, you need to first call FRMS_UnlockLibrary function to

unlock the library. If you are in free 30-day trial, don't pass any parameter to the function

FRMS_UnlockLibrary, for example, FRMSAPI FRMS_HRESULT FRMS_UnlockLibrary().

Example:

// Use the Key information to unlock the library

FRMS_HRESULT hr =

FRMS_UnlockLibrary("XXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXXX");

if (FRMS_HRESULT_OK != hr)

{

DisplayFRMSError(hr);

goto Exit;

}

2. Initialize the SDK with FRMS_Initialize. Before the application exits, destroy the library to

release resources.

Example:

//Initalize the SDK with library

hr = FRMS_Initialize(FRMS_API_MODE_CLIENT);

if (FRMS_HRESULT_OK != hr)

{

DisplayFRMSError(hr);

goto Exit;

}

//Release all resources allocated by the SDK library

if(Null != hProtector)

{

FRMSProtector_Release(hProtector);

}

NOTE: If failing to call the function, 1. ensure you have called the function FRMS_UnlockLibrary

successfully. 2. check whether the AD RMS environment has been set up correctly if the function

FRMS_UnlockLibrary is returned successfully.

3. Sets the source to be protected. It can be a folder containing PDF files or can be a PDF file

path.

Example:

//Set the PDF file path

wchar_t wsSource[20] = L"C:\\test.pdf";

FRMS_HPROTECTOR hProtector = NULL;

Hr = FRMSProtector_Create(&hProtector);

if (NULL != hProtector)

{

hr = FRMSProtector_SetSource(hProtector,wsSource);

if(hr != FRMS_HRESULT_OK)

{

DisplayFRMSError(hr);

goto Exit;

}

4. Get all Issuers.

Example:

int nCount = 0;

// Gets the count of issuers

hr = FRMSProtector_GetIssuerCount(hProtector, this->GetSafeHwnd(), &nCount);

if(hr != FRMS_HRESULT_OK)

{

DisplayFRMSError(hr);

goto Exit;

}

for(int i=0; i<nCount; i++)

{

LPWSTR lpwsIssuer = NULL;

int nLen = 0;

// Gets the length of the issuer name

hr = FRMSProtector_GetIssuer(hProtector, i, this->GetSafeHwnd(), lpwsIssuer, &nLen);

if(hr != FRMS_HRESULT_OK)

{

DisplayFRMSError(hr);

goto Exit;

}

lpwsIssuer = new wchar_t[nLen];

memset(lpwsIssuer, 0, sizeof(wchar_t)*nLen);

//Gets the issuer name by index

hr = FRMSProtector_GetIssuer(hProtector, i, this->GetSafeHwnd(), lpwsIssuer, &nLen);

if(hr != FRMS_HRESULT_OK)

{

DisplayFRMSError(hr);

delete [] lpwsIssuer;

goto Exit;

}

5. Get the number of Rights Poilcy Template.

Example:

int nTemplateCount = 0;

//Gets the count of RMS rights policy templates of the specified issuer.

hr = FRMSProtector_GetTemplateCount(hProtector, lpwsIssuer, TRUE, this->GetSafeHwnd(),

&nTemplateCount);

if (hr != FRMS_HRESULT_OK)

{

DisplayFRMSError(hr);

delete [] lpwsIssuer;

goto Exit;

}

6. Get the names of all templates.

Example:

for(int j=0; j<nTemplateCount; j++)

{

+ 14 hidden pages
