Ford Mountaineer 2005 User Manual

Introduction 4 Instrument Cluster 10

Warning and control lights 10 Gauges 14

Entertainment Systems 18

AM/FM stereo with CD 18 AM/FM stereo with in-dash six CD 21

Climate Controls 37

Manual heating and air conditioning 37 Automatic temperature control 39 Auxiliary passenger climate control 42 Rear window defroster 43

Lights 44 Driver Controls 55

Windshield wiper/washer control 55 Steering wheel adjustment 56 Power windows 61 Mirrors 62 Speed control 64 Message center 75

Locks and Security 92

Keys 92 Locks 92 Anti-theft system 94

Seating and Safety Restraints 105

Seating 105 Safety restraints 117 Airbags 130 Child restraints 138

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Table of Contents

Tires, Wheels and Loading 151

Tire Information 153 Tire Inflation 155 Changing tires 159 Lug Nut Torque 167 Tire Pressure Monitoring System (TPMS) 177 Vehicle loading 182 Trailer towing 189 Recreational towing 194

Driving 195

Starting 195 Brakes 198 Traction control/AdvanceTrac 201 Transmission operation 205

Roadside Emergencies 219

Getting roadside assistance 219 Hazard flasher switch 220 Fuel pump shut-off switch 220 Fuses and relays 221 Jump starting 231 Wrecker towing 237

Customer Assistance 238

Reporting safety defects (U.S. only) 246

Cleaning 247

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Table of Contents

Maintenance and Specifications 253

Engine compartment 255 Engine oil 258 Battery 263 Engine Coolant 265 Fuel information 271 Air filter(s) 285 Part numbers 286 Refill capacities 287 Lubricant specifications 290

Accessories 296 Index 298

All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Introduction

CALIFORNIA Proposition 65 Warning

WARNING: Engine exhaust, some of its constituents, and

certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. In addition, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CONGRATULATIONS

Congratulations on acquiring your new Mercury. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.

For more information on Ford Motor Company and its products visit the following website:

• In the United States: www.ford.com

• In Canada: www.ford.ca

• In Mexico: www.ford.com.mx

• In Australia: www.ford.com.au

Additional owner information is given in separate publications. This Owner’s Guide describes every option and model variant available

and therefore some of the items covered may not apply to your particular vehicle. Furthermore, due to printing cycles it may describe options before they are generally available.

Remember to pass on the Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle.

Fuel pump shut-off switch: In the event of an accident the

safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside Emergencies chapter.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Introduction

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.

Warning symbols on your vehicle

When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind.

Protecting the environment

We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.

BREAKING-IN YOUR VEHICLE

Your vehicle does not need an extensive break-in. Try not to drive continuously at the same speed for the first 1,000 miles (1,600 km) of new vehicle operation. Vary your speed frequently in order to give the moving parts a chance to break in.

Drive your new vehicle at least 500 miles (800 km) before towing a trailer.

Do not add friction modifier compounds or special break-in oils during the first few thousand miles (kilometers) of operation, since these additives may prevent piston ring seating. See Engine oil in the Maintenance and Specifications chapter for more information on oil usage.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Introduction

SPECIAL NOTICES Emission warranty

The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 6.0L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.

Special instructions

For your added safety, your vehicle is fitted with sophisticated electronic controls.

Please read the section Supplemental restraint system (SRS)

in the Seating and Safety Restraints chapter. Failure to follow the specific warnings and instructions could result in personal injury.

Front seat mounted rear-facing child or infant seats should

NEVER be placed in front of an active passenger air bag.

Service Data Recording

Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.

Event Data Recording

Other modules in your vehicle — event data recorders — are capable of collecting and storing data during a crash or near crash event. The recorded information may assist in the investigation of such an event. The modules may record information about both the vehicle and the occupants, potentially including information such as:

• how various systems in your vehicle were operating;

• whether or not the driver and passenger seatbelts were buckled;

• how far (if at all) the driver was depressing the accelerator and/or the

brake pedal;

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Introduction

• how fast the vehicle was traveling; and

• where the driver was positioning the steering wheel.

To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.

Notice to owners of pickup trucks and utility type vehicles

Utility vehicles have a significantly higher rollover rate than

other types of vehicles.

Before you drive your vehicle, please read this Owner’s Guide carefully. Your vehicle is not a passenger car. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of vehicle control, vehicle rollover, personal injury or death.

Be sure to read Driving off road in the Driving chapter.

Using your vehicle with a snowplow

Do not use this vehicle for snowplowing.

Your vehicle is not equipped with a snowplowing package.

Using your vehicle as an ambulance

Do not use this vehicle as an ambulance.

Your vehicle is not equipped with the Ford Ambulance Preparation Package.

MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION

For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner’s Guide; therefore, a supplement has been supplied that complements this book. By referring to the pages in the provided supplement, you can properly identify those features, recommendations and specifications that are unique to your vehicle. Refer to this

Owner’s Guide for all other required information and warnings.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Introduction

These are some of the symbols you may see on your vehicle.

Vehicle Symbol Glossary

Safety Alert

Fasten Safety Belt Air Bag-Front

Air Bag-Side Child Seat

Child Seat Installation Warning

Child Seat Tether Anchor

Anti-Lock Brake System

Powertrain Malfunction Speed Control

Master Lighting Switch Hazard Warning Flasher

Fog Lamps-Front Fuse Compartment

See Owner’s Guide

Child Seat Lower Anchor

Brake System

Brake Fluid Non-Petroleum Based

Fuel Pump Reset Windshield Wash/Wipe

Windshield Defrost/Demist

Rear Window Defrost/Demist

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Vehicle Symbol Glossary

Introduction

Power Windows Front/Rear

Child Safety Door Lock/Unlock

Power Window Lockout Interior Luggage

Compartment Release Symbol

Panic Alarm Engine Oil

Engine Coolant

Engine Coolant Temperature

Do Not Open When Hot Battery

Avoid Smoking, Flames, or Sparks

Battery Acid

Explosive Gas Fan Warning

Power Steering Fluid

Maintain Correct Fluid Level

Emission System Engine Air Filter

MAX

MIN

Passenger Compartment Air Filter

Jack

Check fuel cap Low tire warning

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

WARNING LIGHTS AND CHIMES

Standard instrument cluster

Optional instrument cluster

Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works. If any light remains on after starting the vehicle, have the respective system inspected immediately.

Service engine soon: The Service engine soon indicator light

illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to

SER VICE

ENGINE

SOON

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

On board diagnostics (OBD-II) in the Maintenance and Specifications chapter. If the light is blinking, engine misfire is occurring which could damage your catalytic converter. Drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced immediately.

Under engine misfire conditions, excessive exhaust temperatures

could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.

Check fuel cap (if equipped):

Illuminates when the fuel cap may not be properly installed. Continued driving with this light on may cause the Service engine soon light to come on, refer to Fuel filler cap in the Maintenance and Specifications chapter.

Brake system warning light: To confirm the brake system warning light is functional, it will momentarily illuminate when the ignition is turned to the ON position when the engine is not running, or in a position between ON and START, or by applying the parking brake when the ignition is turned to the ON position. If the brake system warning light does not illuminate at this time, seek service immediately from your dealership. Illumination after releasing the parking brake indicates low brake fluid level and the brake system should be inspected immediately by your servicing dealership.

Driving a vehicle with the brake system warning light on is

dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately.

Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately. Normal braking is still functional unless the brake warning light also is illuminated.

CHECK

FUEL

CAP

BRAKE

ABS

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Air bag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains on, have the system serviced immediately. A chime will also sound when a malfunction in the supplemental restraint system has been detected.

Safety belt: Reminds you to fasten your safety belt. A chime will also sound to remind you to fasten your safety belt.

Charging system: Illuminates when the battery is not charging properly.

Check gage: Illuminates when any of the following conditions has occurred:

• The engine coolant temperature is high.

• The engine oil pressure is low.

• The fuel gauge is at or near empty.

Low tire warning (if equipped with the Tire Pressure Monitoring System): Illuminates

when your tire pressure is low. If the light remains on at start up or while driving, the tire pressure should be checked. Refer to Inspecting and Inflating Your Tires in the Tires, Wheels and Loading chapter. When the ignition is first turned to ON, the light will illuminate for 3 seconds to ensure the bulb is working. If the light does not turn ON, have the system inspected by your servicing dealership. For more information on this system, refer to Understanding Your Tire Pressure Monitoring System in the Tires, Wheels and Loading chapter.

Electronic throttle control:

Illuminates when the engine has defaulted to a ’limp-home’ operation. Report the fault to a dealer at the earliest opportunity.

CHECK

GAGE

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Overdrive off: Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light flashes steadily or does not illuminate, have the transmission serviced soon, or damage may occur.

AdvanceTrac威 (if equipped):

Illuminates when the AdvanceTrac威 with RSC system is active. If the light remains on, have the system serviced immediately.

AWD lock (if equipped):

Illuminates when all wheel drive (AWD) is locked. If the light continues to flash, have the system serviced.

Speed control: Illuminates when the speed control is activated. Turns off when the speed control system is deactivated.

Door ajar (if equipped):

Illuminates when the ignition is in the ON position and any door is open.

O/D

OFF

AWD

LOCK

DOOR

AJAR

Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb.

High beams: Illuminates when the high beam headlamps are turned on.

Key-in-ignition warning chime: Sounds when the key is left in the ignition in the OFF/LOCK or ACCESSORY position and the driver’s door is opened.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Headlamps on warning chime: Sounds when the headlamps or parking lamps are on, the ignition is off (the key is not in the ignition) and the driver’s door is opened.

Turn signal warning chime: Sounds when the turn signal lever has been activated to signal a turn and not turned off after the vehicle is driven more than 1/2 mile (0.8 km).

GAUGES

Standard instrument cluster gauges

Optional instrument cluster gauges

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Speedometer: Indicates the current vehicle speed.

Engine coolant temperature gauge: Indicates engine coolant

temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.

Never remove the coolant reservoir cap while the engine is running or hot.

Odometer: Registers the total miles (kilometers) of the vehicle.

• Standard instrument cluster

TRIP

• Optional instrument cluster

Refer to Message Center in the Drivers Controls chapter on how to switch the display from Metric to English.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Trip odometer: Registers the miles (kilometers) of individual journeys.

• Standard instrument cluster

Press and release the SELECT/RESET button to toggle between odometer and trip odometer display.

• Optional instrument cluster

Press and release the TRIP/RESET button to toggle between odometer and trip odometer display.

Tachometer: Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.

Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated by arrows), have the vehicle’s electrical system checked as soon as possible.

TRIP

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Instrument Cluster

Engine oil pressure gauge:

Indicates engine oil pressure. The needle should stay in the normal operating range (between “L” and “H”). If the needle falls below the normal range, stop the vehicle, turn off the engine and check the engine oil level. Add oil if needed. If the oil level is correct, have your vehicle checked at your dealership or by a qualified technician.

Fuel gauge: Indicates approximately how much fuel is left in the fuel tank (when the ignition is in the ON position). The fuel gauge may vary slightly when the vehicle is in motion or on a grade.

The arrow next to the fuel pump icon indicates which side of the vehicle the fuel filler door is located.

Refer to Filling the tank in the Maintenance and Specifications chapter for more information.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

AM/FM STEREO / SINGLE CD RADIO (IF EQUIPPED)

VOL - PUSH ON

SEEK TUNE

16 17

AM FM

BASSCDTREB BAL FADE

CDCD

123456

1. BAL (Balance): Press

to shift sound to the left/right speakers.

2. FADE: Press

/ to shift

sound to the front/rear speakers.

FM1

DISC

1 234

COMP

SHUFFLE

7910

SCN

CLK

3. SCN (Scan): Press to hear a

brief sampling of all listenable stations or CD tracks. Press again to stop.

4. CLK (Clock): To set the hour,

press and hold CLK and press SEEK to decrease

or increase the

hours.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

CLK

Entertainment Systems

To set the minute, press and hold CLK and press TUNE to decrease or increase the minutes.

5. EJ (Eject): Press to eject a CD.

6. COMP (Compression): In CD

mode, press to bring louder and softer levels into more comfortable listening level. The compression icon (c) will appear in the display.

7. SHUFFLE: Press to listen to the

tracks on the CD in random order. Press again to turn off.

8. Memory presets: To set a

station: Select frequency band

CDCD

123456

AM/FM; tune to a station. Press and hold a preset button until sound returns. This radio is equipped with six station memory preset controls which allow you to set up to six AM stations and 12 FM stations (six in FM1 and six in FM2).

9. CD

: Press and hold until desired point of a selection is reached.

10.

CD: Press and hold until desired point of a selection is reached.

11. TUNE: In radio mode, press to move up or down the frequency band in individual increments.

12. SEEK: Press and release SEEK

/ for previous/next

strong station, selection or track.

13. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

SHUFFLE

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

14. CD: Press to enter CD mode or to play a CD already loaded into the system.

15. AM/FM: Press to choose a frequency band in radio mode.

16. BASS: Press increase/decrease the bass output.

17. TREB (Treble): Press to increase/decrease the treble

output.

18. CD slot: Insert a CD printed side up.

CD units are designed to play commercially pressed 4.75 in (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player. The label may peel and cause the CD to become jammed. It is recommended that homemade CDs be identified with permanent felt tip marker rather than adhesive labels. Ballpoint pens may damage CDs. Please contact your dealer for further information.

/ to

DISC

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

AUDIOPHILE SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SIX CD RADIO (IF EQUIPPED)

1. Seek: Press and release SEEK strong station or track.

2. Rewind: In CD mode, press until desired point within the current selection is reached.

Fast forward: In CD mode, press until desired point within the current selection is reached.

TEXT: TEXT is only available when equipped with Satellite radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Mercury dealer. Detailed Satellite instructions are included with the dealer installed kit.

Dealer installed satellite kit only available in the continental United States.

3. DSP (Digital Signal Processing): Press DSP to access

the Ambiance menu. Ambiance gives the feeling of “being there” to your music, creating increased clarity as well as an open and spacious feel to the music. Press SEL to engage/disengage. Turn the volume control to increase/decrease the level of ambiance.

/ for previous/next

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Occupancy: Press DSP again to change the occupancy mode to optimize sound for ALL SEATS, DRIVERS SEAT or REAR SEATS. Press SEL to scroll through settings.

4. Mute: Press to MUTE playing media; press again to return to playing media.

5. Eject: Press to eject a CD. Press EJ and a memory preset to eject a specific disk. Press and hold to eject all loaded discs.

6. Bass: Press BASS; then press SEL the bass output.

Treble: Press TREB; then press SEL the treble output.

7. Select: Use with Bass, Treble, Balance, Fade and other menu selections.

8. Balance: Press BAL; then press SEL left/right speakers.

Fade: Press FADE; then press SEL rear/front speakers.

9. Menu: Press MENU to access clock mode, RDS on/off, Traffic announcement mode, Program type mode, Shuffle and Compression mode.

The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC) recommend that FM radio broadcasters use RDS technology to transmit information. FM radio stations are independently operated and individually elect to use RDS technology to transmit station ID and program type as desired.

/ to decrease/increase

/ to shift sound to the

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Traffic: Allows you to hear traffic broadcasts. With the feature ON, press SEEK or SCAN to find a station broadcasting a traffic report (if it is broadcasting RDS data).Traffic information is not available in most

U.S. markets.

FIND Program type: Allows you to search RDS-equipped stations for a certain category of music format: Classic, Country, Info, Jazz, Oldies, R&B, Religious, Rock, Soft, Top 40. Press MENU until FIND appears in the display. Use SEL to scroll through music types. Press SEEK or SCAN to search for station playing requested music category.

Show TYPE: Displays the station’s call letters or music format. Press MENU until SHOW appears in the display. Use SEL to select NONE, NAME or TYPE.

Shuffle: Press to play tracks in a random order. Press MENU until SHUFFLE appears in the display. Use SEL to select SHUFFLE DISC, SHUFFLE TRK or SHUFFLE OFF.

Compression: Brings soft and loud CD passages together for a more consistent listening level. Press MENU until COMPRESS is displayed. Press the SEL control to enable the compression feature when COMPRESS OFF is displayed. Press the SEL control again to disable the feature when COMPRESS ON is displayed.

Setting the clock: Press MENU until SELECT HOUR or SELECT MINS is displayed. Use SEL to manually increase ( hours/minutes. Press MENU again to disengage clock mode.

10. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns.

11. SAT (if equipped): Your Audiophile radio comes equipped with Satellite Ready capability. The kit to enable the Satellite reception is available through your Mercury dealer. Detailed satellite instructions are included with the dealer installed kit. Dealer installed satellite kit only available in the

continental United States.

) or decrease ( )the

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

12. AM/FM: Press to select AM/FM frequency band.

Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press and momentarily hold AM/FM. AUTOSET will be shown. When the six strongest stations are filled, the station stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Press and hold again to disengage.

13. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

Speed sensitive volume: Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3. Level 0 turns the feature off and level 7 is the maximum setting. Press and hold the volume control for five seconds. Then press SEL to

increase ( appear in the display.

14. Load: Press to load a CD. Press LOAD and a specific memory preset to load a specific disc. Press and hold to load up to six discs.

15. CD AUX: Press to access CD or AUX mode.

) or decrease ( ) the volume setting. The level will

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

16. Scan: Press SCAN to hear a brief sampling of radio stations or CD tracks. Press again to stop.

17. Disc/Tune: Press manually tune down/up the radio

frequency band, or change to the previous/next CD.

CAT: CAT is only available when equipped with Satellite Radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your Mercury dealer. Detailed Satellite instructions are included with the dealer installed kit.

Dealer installed satellite kit only available in the continental United States.

For information regarding SIRIUS Satellite Radio, please call toll-free 888-539-SIRIUS (888-539-7474) or visit the SIRIUS website at www.siriusradio.com

SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SINGLE CD/MP3 RADIO — LATE AVAILABILITY (IF EQUIPPED)

or to

1. SEEK: Press and release SEEK strong station or track.

/ for previous/next

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection. When MP3 selection text is shown on the message display its corresponding text indicator (Fi, So, Ar, or AL) is shown in the elapsed time display. Press TEXT to scroll through the text fields. The display will scroll through all of the text in the current field before changing to the next field. (TEXT must be pressed within 3 seconds of the previous press to proceed to the next/last text display. The last text field shown on the display will become the new display message default. TEXT is also available when equipped with Satellite radio. Your radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your dealer. Detailed Satellite instructions are included with the dealer installed kit. Dealer installed satellite kit

only available in the continental United States.

3. AUX: This function is not operational.

4. MUTE: Press to MUTE playing media; press again to return to playing media

5. EJ: Press to eject a CD.

6. Bass: Press BASS; then press SEL the bass output.

Treble: Press TREB; then press SEL the treble output.

7. Select: Use with Bass, Treble, Balance, Fade and other menu selections.

8. Balance: Press BAL; then press SEL left/right speakers.

/ to decrease/increase

/ to shift sound to the

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Fade: Press FADE; then press SEL rear/front speakers.

9. Menu: Press MENU and SEL to access AUTOSET, Speed sensitive volume and Setting the clock.

Autoset: Press MENU until AUTOSET appears in the display. Press SEL to toggle ON/OFF. Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . When the six strongest stations are filled, the station stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets.

Speed sensitive volume: Press MENU until SPEED VOL X appears in the display. Then press SEL to increase ( volume setting. The level will appear in the display.

Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3. Level 0 turns the feature off and level 7 is the maximum setting.

Setting the clock: Press MENU until SELECT HOUR or SELECT MINS is displayed. Use SEL to manually increase ( hours/minutes. Press MENU again to disengage clock mode.

Folder/Track mode: In MP3 mode, press MENU until MODE appears in the display. Use SEL to toggle between FOLDER (only tracks within selected folder are accessible) or TRACK (all tracks on disc are accessible) MODE.

10. REPEAT: Repeats current CD/MP3 track when active (ON). Press to shown repeat status. Press again to toggle status.

11. SHUFFLE: Plays CD/MP3 tracks in random order when active (ON). Press to show shuffle status. Press again to toggle status.

12. FOLDER the next MP3 directory.

/ to shift sound to the

) or decrease ( )the

: Press to access

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

13. FOLDER : Press to access the previous MP3 directory.

14. FF(Fast forward): In CD/MP3 mode, press until desired selection is reached.

15. REW(Rewind): In CD/MP3 mode, press until desired selection is reached.

16. SAT (if equipped): Your radio comes equipped with Satellite Ready capability. The kit to enable the Satellite reception is available through your dealer. Detailed satellite instructions are included with the dealer installed kit. Dealer installed

satellite kit only available in the continental United States.

17. BAND: Press to toggle between AM/FM1/FM2 frequency band.

18. Memory presets: To set a station: Select frequency band; tune to a station, press and hold a preset button until sound returns.

19. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

20. CD: Press to enter CD mode.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

21. COMP(Compression): Brings soft and loud CD passages together for a more consistent listening level when in CD mode. Press COMP to turn the feature ON/OFF.

22. Scan: Press SCAN to hear a brief sampling of radio stations or CD/MP3 tracks. Press again to stop.

23. CAT/Tune: Press

manually tune down/up the radio frequency band. CAT: CAT is only available when equipped with Satellite Radio. Your

radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your dealer. Detailed Satellite instructions are included with the dealer installed kit. Dealer installed

satellite kit only available in the continental United States.

For information regarding SIRIUS Satellite Radio, please call toll-free 888-539-SIRIUS (888-539-7474) or visit the SIRIUS website at www.siriusradio.com

24. CD slot: Insert a CD with the label side up.

or to

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

AUDIOPHILE SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SIX CD/MP3 RADIO — LATE AVAILABILITY (IF EQUIPPED)

1. SEEK: Press and release SEEK strong station or track.

TEXT is also available when equipped with Satellite radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your dealer. Detailed Satellite instructions are included with the dealer installed kit. Dealer

installed satellite kit only available in the continental United States.

/ for previous/next

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

3. AUX: This function is not operational.

4. MUTE: Press to MUTE playing media; press again to return to playing media

5. EJ: Press to eject a CD. Press EJ and a memory preset to eject a specific disc. Press and hold to eject all loaded discs.

6. Bass: Press BASS; then press SEL the bass output.

Treble: Press TREB; then press SEL the treble output.

7. Select: Use with Bass, Treble, Balance, Fade and other menu functions.

8. Balance: Press BAL; then press SEL left/right speakers.

Fade: Press FADE; then press SEL rear/front speakers.

9. Menu: Press and hold MENU to access RDS on/off. Use SEL to toggle RDS on/off. Press MENU again to access Traffic mode, Program Type mode or Show Type mode. (MENU must be pressed within 10 seconds to proceed to the next RDS mode).

/ to decrease/increase

/ to shift sound to the

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

U.S. markets.

FIND Program type: Allows you to search RDS-equipped stations for a certain category of music format: Classic, Country, Info, Jazz, Oldies, R&B, Religious, Rock, Soft, Top 40. Press and hold MENU until RDS XX is shown in the display. Press MENU until FIND appears in the display. Use SEL to scroll through music types. Press SEEK or SCAN to search for a station playing the requested music category.

Show TYPE: Displays the station’s call letters or music format. Press and hold MENU until RDS XX is shown in the display Press MENU until SHOW appears in the display. Use SEL to select NAME or TYPE.

Compression: Brings soft and loud CD passages together for a more consistent listening level when in CD mode. Press MENU until compression status is displayed. Press the SEL control to enable the compression feature when COMPRESS OFF is displayed. Press the SEL control again to disable the feature when COMPRESS ON is displayed.

Occupancy mode: Press MENU until occupancy mode appears in the display. Press SEL to select ALL SEATS, DRIVER SEAT or REAR SEATS occupancy mode.

Autoset: Allows you to set the strongest local radio stations without losing your original manually set preset stations for AM/FM1/FM2 . Press MENU until AUTOSET appears in the display. Press SEL to toggle ON/OFF. When the six strongest stations are filled, the station stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets.

Speed sensitive volume: Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3. Level 0 turns the feature off and level 7 is the maximum setting. Press MENU until SPEED VOL X appears in the display. Then press SEL

to increase ( appear in the display.

Setting the clock: Press MENU until SELECT HOUR or SELECT MINS is displayed. Use SEL to manually increase ( hours/minutes. Press MENU again to disengage clock mode.

) or decrease ( ) the volume setting. The level will

) or decrease ( )the

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

Folder/Track Mode: In MP3 mode, press MENU until MODE appears in the display. Use SEL to toggle between FOLDER (only tracks within selected folder are accessible) or TRACK (all tracks on disc are accessible) MODE.

10. REPEAT: Repeats current CD/MP3 track when active (ON). Press to show repeat status. Press again to toggle status.

11. SHUFFLE: Plays CD/MP3 tracks in random order when active (ON). Press to show shuffle status. Press again to toggle status.

12. FOLDER the next MP3 directory.

: Press to access

13. FOLDER the previous MP3 directory.

14. FF(Fast forward): In CD mode, press until desired selection is reached.

15. REW(Rewind): In CD mode, press until desired selection is reached.

satellite kit only available in the continental United States.

17. BAND: Press to toggle between AM/FM1/FM2 frequency band.

18. Memory presets: To set a station: Select frequency band, tune to a station, press and hold a preset button until sound returns.

: Press to access

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

19. Power/volume: Press to turn ON/OFF; turn to increase or decrease volume levels.

20. Load: Press to load a CD. Press LOAD and a memory preset to load to a specific disc slot. Press and hold to load up to six discs.

21. CD: Press to enter CD mode.

22. Scan: Press SCAN to hear a brief sampling of radio stations or CD/MP3 tracks. Press again to stop.

23. Disc/Tune: Press

or to

manually tune down/up the radio frequency band, or to listen to the previous/next CD.

CAT: CAT is only available when equipped with Satellite Radio. Your Audiophile radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your dealer. Detailed Satellite instructions are included with the dealer installed kit. Dealer

installed satellite kit only available in the continental United States.

For information regarding SIRIUS Satellite Radio, please call toll-free 888-539-SIRIUS (888-539-7474) or visit the SIRIUS website at www.siriusradio.com

24. CD slot: Insert a CD, label side up. 34

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

FAMILY ENTERTAINMENT SYSTEM (IF EQUIPPED)

Your vehicle may be equipped with a Family Entertainment System (FES). Refer to the DVD Supplement Guide for further information on your system.

RADIO FREQUENCIES

AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC). Those frequencies are:

AM: 530, 540–1700, 1710 kHz FM: 87.7, 87.9–107.7, 107.9 MHz

RADIO RECEPTION FACTORS

There are three factors that can affect radio reception:

• Distance/strength: The further you travel from an FM station, the

weaker the signal and the weaker the reception.

• Terrain: Hills, mountains, tall buildings, power lines, electric fences,

traffic lights and thunderstorms can interfere with your reception.

• Station overload: When you pass a broadcast tower, a stronger signal

may overtake a weaker one and play while the weak station frequency is displayed.

CD/CD PLAYER CARE

Do:

• Handle discs by their edges only. Never touch the playing surface.

• Inspect discs before playing. Clean only with an approved CD cleaner

and wipe from the center out.

Don’t:

• Expose discs to direct sunlight or heat sources for extended periods

of time.

• Insert more than one disc into each slot of the CD changer magazine.

• Clean using a circular motion.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Entertainment Systems

AUDIO SYSTEM WARRANTY AND SERVICE

Refer to the Warranty Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Climate Controls

MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED)

1. Temperature selection: Controls the temperature of the airflow in the vehicle.

2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control.

MAX A/C: Uses recirculated air through the instrument panel registers to cool the vehicle. This mode is noisier than other modes, but is more economical and efficient and may help prevent undesirable odors from entering the vehicle.

: Distributes outside air through the instrument panel vents.

: Distributes outside air through the instrument panel vents and the

floor vents.

O (OFF): Outside air is shut out and the fan will not operate.

: Distributes outside air through the floor vents.

: Distributes outside air through the windshield defroster vents and

floor vents.

: Distributes outside air through the windshield defroster vents.

3. A/C: Uses outside air to cool the vehicle. Air flows from the instrument panel register vents only.

4. Rear defroster: Clears ice and fog from the rear window.

5. Fan speed adjustment: Controls the volume of air circulated in the vehicle.

Operating tips

• To reduce fog build up on the windshield during humid weather, place

the air flow selector in the

• To reduce humidity build up inside the vehicle, do not drive with the

air flow selector in the O (OFF) position.

• Do not put objects under the front seats that will interfere with the

airflow to the rear seats.

• Remove any snow, ice or leaves from the air intake area at the base of

the windshield.

position.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Climate Controls

• To improve the A/C cool down, drive with the windows slightly open

for 2–3 minutes after start up or until the vehicle has been “aired out.”

For maximum cooling performance in panel (

• Select MAX A/C mode. MAX A/C uses recirculated air with A/C to

provide a cooler airflow.

• Move the temperature control to the coolest setting.

• Set the fan to the highest speed initially, then adjust in order to

maintain comfort.

To allow side window defogging and demisting while warming up the vehicle cabin:

1. Select

2. Select A/C.

3. Set the temperature control to maintain comfort.

4. Set the fan speed to highest setting.

5. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

) mode:

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Climate Controls

Dual Automatic Temperature Control (DATC) system (if equipped)

14 15 16 17 2 31

AUTO

EXT

F F

F C

OFF

A/C

DUAL

10 9 8 7 613 5 412 11

1. A/C control: Uses outside air to cool the vehicle. Press to turn on/off

in all modes except

or .

2. Recirculation control: Cools the vehicle more quickly by recirculating the cabin air instead of using outside air and helps prevent unpleasant outside odors or fumes from entering the vehicle. Press to turn on/off.

3. Passenger side temperature control: Controls the temperature on the passenger side of the vehicle when in dual zone mode. To enter dual zone, press the passenger temperature control or DUAL. The passenger temperature will appear in the display.

4. Rear defroster control: Removes ice and fog from the rear window. Press to turn on/off.

5. DUAL (Single/dual electric temperature control): Allows the driver to have full control of the cabin temperature settings (single zone) or allows the passenger to have control of their individual temperature settings (dual zone control). Press to enable turn on dual zone mode, press again to return to single zone.

A/C

DUAL

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Climate Controls

6. : Distributes outside air through the windshield defroster vents.

: Distributes outside air through the windshield defroster vents

and floor vents.

: Distributes outside air through the floor vents.

: Distributes outside air through the instrument panel vents and

the floor vents.

10.

11. OFF: Outside air is shut out and

: Distributes outside air through the instrument panel vents.

OFF

the fan will not operate.

12. AUTO: Press to select the

AUTO

desired temperature shown in the display window. The system will automatically determine the fan speed, airflow location, outside or recirculated air to heat or cool the vehicle to the selected temperature.

13. Manual override controls:

OFF

Allows you to manually determine where airflow is directed. To return to fully automatic control, press AUTO.

14. Driver’s side temperature control: Controls the temperature on the driver side of the vehicle.

15. Fan Speed: Used to manually enable or disable the fan speed.

16. EXT: Displays the outside air

EXT

temperature. It will remain displayed until the EXT control is pressed again. The external temperature will be most accurate when the vehicle has been moving for a period of time.

17. Temperature conversion:

F C

Press to toggle between Fahrenheit and Celsius temperature on the DATC display only. The set point temperatures in Celsius will be displayed in half-degree increments.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Climate Controls

Operating tips

• To reduce fog build up on the windshield during humid weather, place

the air flow selector in the

• To reduce humidity build up inside the vehicle, do not drive with the

air flow selector in the OFF or with recirculated air engaged.

• Do not put objects under the front seats that will interfere with the

airflow to the rear seats.

• Remove any snow, ice or leaves from the air intake area at the base of

the windshield.

• To improve the A/C cool down, drive with the windows slightly open

for 2–3 minutes after start up or until the vehicle has been “aired out.”

For maximum cooling performance:

• Select and A/C and recirculated air. Use recirculated air with A/C to

provide a cooler airflow.

• Move the temperature control to the coolest setting. To allow side window defogging and demisting while warming up the

vehicle cabin:

1. Select

2. Select A/C.

3. Set the temperature control to maintain comfort.

4. Set the fan speed to highest setting.

5. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.

position.

Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Climate Controls

Auxiliary system (if equipped)

Your vehicle may be equipped with auxiliary climate controls. These allow the front or rear seat passengers to control airflow direction, temperature and fan level of the rear compartment to quickly heat or cool the entire vehicle.

Front auxiliary controls:

1. Temperature control: Determines temperature level. If the main climate control system is cooling in MAX A/C or auxiliary controls will not function as the entire vehicle will operate at a full cool temperature.

2. Mode selector: Press to select air flow direction to or

seating. The selected mode will illuminate on the temperature control.

3. Fan control: Determines fan speed levels. Turn to REAR (if equipped) to give rear seat passengers control of the rear auxiliary controls. Otherwise, the front controls will determine the settings for the entire vehicle cabin. If set to O (OFF), the front and rear auxiliary controls will not function.

Rear auxiliary controls (if equipped):

Once the front auxiliary control is set to REAR, the rear seat passengers may use the rear auxiliary controls in the overhead console to make the desired adjustments.

(Panel).

Directs air to the floor of the third row seating.

directs air to the overhead registers of the second and third row

mode, the

(Floor)

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Climate Controls

1. Temperature control: Determines temperature levels. If the main climate control system is cooling in MAX A/C or

mode,

the auxiliary controls will not

3 1

function as the entire vehicle will operate at a full cool temperature.

2. Mode selector: Press to select between air flow to

(Floor)

or (Panel).

Directs air to the floor of the third row seating.

directs air to the overhead registers of the second and third row

seating. The selected mode will illuminate on the temperature control.

3. Fan control: Determines fan speed levels.

Floor console climate controls (if equipped)

Controls the direction of the airflow to the rear of the vehicle.

selects air flow from the console

panel registers.

selects air flow

from the floor console registers.

REAR WINDOW DEFROSTER

The rear defroster control is located on the instrument panel.

Press the rear defroster control to clear the rear window of thin ice and fog.

• A small LED will illuminate when

the rear defroster is activated.

The ignition must be in the 3 (ON) position to operate the rear window defroster.

The defroster turns off automatically after 10 minutes or when the ignition is turned to the 1 (OFF/LOCK) position. To manually turn off the defroster before 10 minutes have passed, push the control again.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

HEADLAMP CONTROL

Turns the lamps off.

Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps.

Turns the headlamps on.

Autolamp system

The autolamp system sets the headlamps to turn on and off automatically. The autolamp control, located on the headlamp control, may be set to:

• turn on the lamps automatically at night

• turn off the lamps automatically during the daylight

• keep the lamps on for up to three minutes after the key is turned to

OFF.

To turn the autolamps on, rotate the control counterclockwise to

Foglamp control

The foglamps can be turned on only when the headlamp control is in

the

, and position and the high beams are not turned on. Pull headlamp control towards you

to turn foglamps on. The foglamp indicator light

will illuminate

when foglamp is activated. Push the headlamp control towards the instrument panel to deactivate

the foglamps.

Daytime running lamps (DRL) (if equipped)

To activate DRL:

• the ignition must be in the ON position and

• the headlamp control is in the

or position

• the parking brake must be disengaged. 44

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

Always remember to turn on your headlamps at dusk or during

inclement weather. The Daytime Running Light (DRL) System does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.

High beams

Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate.

Flash to pass

Pull the lever toward you to activate. Release the lever to deactivate.

INT2

INT1

OFF

INT2

INT1

OFF

PANEL DIMMER CONTROL

Move the control up and down to adjust the intensity of the panel

lighting. Operates only when the exterior lights are switched on.

Move the control to the full upright position (past detent) to turn on the interior lamps.

Move the control to the full down position (past detent) to prevent interior lamps from illuminating when the doors are opened.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

AIMING THE HEADLAMPS

The headlamps on your vehicle are properly aimed before leaving the assembly plant. If your vehicle is involved in an accident or if you have problems fixing the alignment of your headlamps, have them checked by a qualified service technician.

Headlamp aim adjustment

The headlamps on your vehicle can only be vertically adjusted. Your vehicle does not require horizontal aim adjustments.

To adjust the headlamps:

1. Park your vehicle on a level surface about 25 feet (7.6 meters) away from a vertical plain surface (3). Check your headlamp alignment at night or in a dark area so that you can see the headlamp beam pattern.

• (1) Eight feet

• (2) Center height of lamp to

ground

• (3) Twenty-five feet

• (4) Horizontal reference line

2. The center of the headlamp has a

3.0 mm circle on the lens. Measure the height from the center of your headlamp to the ground (2) and mark an 8 foot (2.4 meter) long horizontal line on the plain surface (1) at this height (masking tape works well).

3. Turn on the low beam headlamps. The brightest part of the light should be below the horizontal line (4). If it is above the line the headlamp will need to be adjusted.

4. Open the hood.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

5. Locate the vertical adjuster for each headlamp. Adjust the aim by turning the adjuster control either clockwise (to adjust down) or counterclockwise (to adjust up).

Note: Usea4mmsocket or box wrench to turn the vertical adjuster control.

6. Horizontal aiming is not required for this vehicle and is non-adjustable.

TURN SIGNAL CONTROL

• Push down to activate the left turn signal.

• Push up to activate the right turn signal.

Lights

INT2

INT1

OFF

INTERIOR LAMPS Dome/reading lamps

The dome lamp lights when:

• any door is opened.

• the instrument panel dimmer

switch is rotated up until the courtesy lamps come on.

• any of the remote entry controls are pressed and the ignition is OFF.

The reading portion, the two outer lights, can only be toggled on and off at the lamp.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

Cargo/reading lamps

The dome portion of the lamp or the center light can be turned on when the headlamp control is rotated fully up or when a door is opened.

With the ignition in the ACC or ON position, the rear dome lamp can be turned ON or OFF by sliding the control.

BULBS Headlamp Condensation

The headlamps are vented to equalize pressure. When moist air enters the headlamp(s) through the vents, there is a possibility that condensation can occur. This condensation is normal and will clear within 45 minutes of headlamp operation.

Replacing exterior bulbs

Check the operation of all the bulbs frequently.

Replacing the interior bulbs

Check the operation of the bulbs frequently. To replace any of the interior bulbs, see a dealer or qualified technician.

Using the right bulbs

Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility. Using incorrect bulbs may damage the lamp assembly or void the lamp assembly warranty or may not provide quality bulb burn time.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

Function Number of bulbs Trade number

Park/turn lamps (front)

Headlamps 2 9007 Rear stop/turn/tail

lamps Rear license plate

lamps Backup lamp 2 3156K High-mount brake

lamps Side mounted turn

signal Front sidemarker 2 194 Rear sidemarker 2 194 Fog lamp 2 9145 Cargo lamp 1 211-2 Interior overhead lamp 1 912 (906) Front door courtesy

lamp Map lamps 2 168 (T10) Ashtray lamp 1 161 All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your dealer.

3157 AK (amber)

3057

168

W5W

WY5W (amber)

168

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

Replacing headlamp bulbs

Do not touch the glass of a halogen bulb.

1. Turn off the headlamps and open

the hood.

2. Remove the two retainer pins,

then pull headlamp forward.

3. Disconnect the electrical

connector.

4. Remove the bulb retaining ring.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

5. Carefully pull the old bulb out of

the lamp assembly.

Handle a halogen headlamp bulb carefully and keep out of

children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.

Reverse steps to reinstall bulb(s).

Replacing front parking/turn signal bulbs

1. Turn OFF the headlamps and open the hood.

2. Remove the two headlamp retainer pins, then pull the headlamp forward.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

3. Remove the bulb socket from the lamp assembly.

4. Carefully pull the old bulb out of the lamp assembly.

Reverse steps to reinstall bulb(s).

Replacing side-mounted turn signal bulbs

1. Turn the headlamp switch to off.

2. Carefully pry the lamp assembly away from the fender.

3. Rotate the bulb socket counterclockwise to remove it from the lamp assembly.

4. Pull the bulb straight out.

Reverse steps to reinstall bulb(s).

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Replacing front/rear side marker bulbs

1. Turn the headlamp switch to off.

2. Reach under the bumper and rotate the bulb socket counterclockwise to remove it.

3. Pull the bulb straight out.

Reverse steps to reinstall bulb(s).

Replacing tail/brake/turn/backup lamp bulbs

1. Turn the headlamp switch to OFF and open the liftgate.

2. Remove the two screws from the lamp assembly.

3. Remove the lamp assembly.

4. Rotate the bulb socket counterclockwise and remove it from the lamp assembly.

5. Pull the bulb straight out of the socket.

Reverse steps to reinstall bulb(s).

Lights

Replacing foglamp bulbs

1. Make sure the headlamp switch is in the OFF position.

2. Remove the plastic splash shield by removing the two screws on the front of the fenderwell.

3. Remove the bulb socket from the foglamp by turning it counterclockwise.

4. Disconnect the electrical connector. Reverse steps to reinstall bulb(s).

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Lights

Replacing license plate lamp bulbs

1. Make sure the headlamp switch is in the OFF position and then remove two screws and the license plate lamp assembly.

2. Remove the bulb socket from the lamp assembly by turning counterclockwise and pull the bulb straight out.

Reverse steps to reinstall bulb(s).

Replacing high-mount brakelamp bulb

1. Remove the two screws and lamp assembly from vehicle.

2. Remove the bulb socket from the lamp assembly by depressing the snaps and pull the bulb straight out.

Reverse steps to reinstall bulb(s).

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

MULTI-FUNCTION LEVER

Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers.

Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed. The faster your vehicle is travelling the faster the wipers will go.

Windshield washer: Push the end of the stalk:

• briefly: causes a single swipe of the wipers without washer fluid.

• a quick push and hold: the wipers will swipe three times with washer fluid.

• a long push and hold: the wipers and washer fluid will be activated for up to ten seconds.

Rear window wiper/washer controls

For rear wiper operation, rotate the rear window wiper and washer control to the desired position. Select:

INT 1 — 3–4 second interval rear

wiper. INT 2 — 8–10 second interval rear

wiper. OFF — Rear wiper and washer off. For rear wash cycle, rotate (and hold as desired) the rear wiper/washer

control to either

position.

From either position, the control will automatically return to the INT 2 or OFF position.

INT2

INT1

OFF

INT1

INT2

INT1

OFF

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Changing the wiper blades

1. Pull the wiper arm away from the

vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.

2. Attach the new wiper to the

wiper arm and press it into place until a click is heard.

Replace wiper blades at least once per year for optimum performance.

Poor wiper quality can sometimes be improved by cleaning the wiper blades, refer to Windows and wiper blades in the Cleaning chapter.

To prolong the life of the wiper blades, it is highly recommended to scrape off the ice on the windshield before turning on the wipers. The layer of ice has many sharp edges and can damage the micro edge of the wiper rubber element.

TILT STEERING COLUMN

Pull the lever down to unlock the steering column. While the lever is in the down position, tilt the steering column to its desired orientation.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Lift the lever back to its original position to lock the steering column.

Never adjust the steering column when the vehicle is

moving.

CENTER CONSOLE

Your vehicle may be equipped with a variety of console features. These include:

• Utility compartment with cassette/compact disc storage

• Auxiliary power point

• Cupholders

• Tissue box holder (located on underside of console lid)

• Ash tray (if equipped)

The rear side of the console may incorporate the following features:

• Air vents

• Cupholders (will pull up with break away feature)

• Rear power point

Use only soft cups in the cupholder. Hard objects can injure you in a collision.

Cell phone use

The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits.

Mobile Communication Equipment includes, but is not limited to cellular phones, pagers, portable email devices, in-vehicle communications systems, telematics devices and portable two-way radios.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

A driver’s first responsibility is the safe operation of the vehicle.

The most important thing you can do to prevent a crash is to avoid distractions and pay attention to the road. Wait until it is safe to operate Mobile Communications Equipment.

Rear center console features (if equipped)

The rear center console incorporates the following features:

• Utility compartment

• Cupholders

• Flip forward armrest to provide a

flat load floor

OVERHEAD CONSOLE (IF EQUIPPED)

The appearance of your vehicle’s overhead console will vary according to your option package.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Storage compartment

Press the latch to open the storage compartment.

Installing a garage door opener (if equipped)

The storage compartment can be converted to accommodate a variety of aftermarket garage door openers:

• Place the VELCRO威 hook onto the side of the aftermarket transmitter opposite of the button.

• Place the transmitter into storage compartment, button down.

• Place the provided height adaptors onto the back of the door as needed.

• Close the door.

• Press the depression in the door

to activate the transmitter.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Illuminated visor mirror

Lift the mirror cover to turn on the visor mirror lamps.

Slide on rod feature

Rotate the visor towards the side window and extend it rearward for additional sunlight coverage.

Note: To stow the visor back into the headliner, visor must be retracted before moving it back towards the windshield.

AUXILIARY POWER POINT (12VDC)

Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty.

The auxiliary power point is located in the floor console.

Do not use the power point for operating the cigarette lighter element (if equipped).

To prevent the fuse from being blown, do not use the power point(s) over the vehicle capacity of 12 VDC/180W.

To prevent the battery from being discharged, do not use the power point longer than necessary when the engine is not running.

Always keep the power point caps closed when not being used.

Cigar/Cigarette lighter (if equipped)

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Do not plug optional electrical accessories into the cigarette lighter socket.

Do not hold the lighter in with your hand while it is heating, this will damage the lighter element and socket. The lighter will be released from its heating position when it is ready to be used.

Improper use of the lighter can cause damage not covered by your warranty.

Rear auxiliary power point (if equipped)

A second auxiliary power point is located on the rear side of the console. It is accessible from the rear seats.

POWER WINDOWS

Do not leave children unattended in the vehicle and do not let children play with the power windows. They may seriously injure

themselves.

When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in

the proximity of the window openings.

Press and hold the bottom part of the rocker switch to open the window. Press and hold the top part of the rocker switch to close the window.

One touch down

Allows the driver’s window to open fully without holding the control down. Press completely down on AUTO and release quickly. Press again to stop.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Window lock

The window lock feature allows only the driver to operate the power windows.

To lock out all the window controls except for the driver’s press the left side of the control. Press the right side to restore the window controls.

Accessory delay

With accessory delay, the window switches, audio system and moon roof may be used for up to ten minutes after the ignition switch is turned to the OFF position or until any door is opened.

POWER SIDE VIEW MIRRORS

The ignition must be in the ACC or ON position to adjust the power side view mirrors.

To adjust your mirrors:

1. Rotate the control clockwise to

adjust the right mirror and rotate the control counterclockwise to adjust the left mirror.

2. Move the control in the direction

you wish to tilt the mirror.

3. Return to the center position to

lock mirrors in place.

Heated outside mirrors

Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.

Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place. These actions could cause damage to the glass and mirrors.

(if equipped)

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Fold-away mirrors

Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash.

Automatic dimming rear view mirror

Your vehicle may be equipped with an inside rear view mirror with an auto-dimming feature. When the auto-dimming mirror is turned on, as indicated by an illuminated green LED to the left of the button on mirror, it will detect bright lights(glare) from behind the vehicle, and will change from the normal, high reflective state, to the darkened state to minimize glare.

When the auto-dimming mirror is turned on, it will automatically return to the normal, high reflective, state whenever the vehicle is placed in R (Reverse) to ensure a clear view while backing up.

Do not block the sensor located to the right of the mirror button or the sensor located on the back side of the mirror as this may impair mirror performance.

POWER ADJUSTABLE FOOT PEDALS (IF EQUIPPED)

The accelerator and brake pedal should only be adjusted when the vehicle is stopped and the gearshift lever is in the P (Park) position.

Press and hold the rocker control to adjust accelerator and brake pedal toward you or away from you.

The adjustment allows for approximately 3 inches (71–76 mm) of maximum travel.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Never adjust the accelerator and brake pedal with feet on the pedals while the vehicle is moving.

SPEED CONTROL

With speed control set, you can maintain a speed of 30 mph (48 km/h) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 30 mph (48 km/h).

Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved.

Setting speed control

The controls for using your speed control are located on the steering wheel for your convenience.

1. Press the ON control and release

it.

2. Accelerate to the desired speed.

3. Press the SET + control and

release it.

4. Take your foot off the accelerator

pedal.

5. The indicator light

on the

instrument cluster will turn on.

SET

COAST

RES

Note:

• Vehicle speed may vary momentarily when driving up and down a steep hill.

• If the vehicle speed increases above the set speed on a downhill, you may want to apply the brakes to reduce the speed.

• If the vehicle speed decreases more than 10 mph (16 km/h) below your set speed on an uphill, your speed control will disengage.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Resuming a set speed

Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 30 mph (48 km/h).

Increasing speed while using speed control

There are two ways to set a higher speed:

• Press and hold the SET + control until you get to the desired speed, then release the control. You can also use the SET + control to operate the Tap-Up function. Press and release this control to increase the vehicle set speed in small amounts by 1 mph (1.6 km/h).

• Use the accelerator pedal to get to the desired speed. When the vehicle reaches that speed press and release the SET + control.

SET

COAST

RES

COAST

SET

RES

Reducing speed while using speed control

There are two ways to reduce a set speed:

• Press and hold the COAST/CST control until you get to the desired speed, then release the control. You can also use the COAST/CST control to operate the Tap-Down function. Press and release this control to decrease the vehicle set speed in small amounts by 1 mph (1.6 km/h).

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

SET

COAST

RES

Driver Controls

• Depress the brake pedal until the desired vehicle speed is reached, press the SET + control.

Turning off speed control

There are two ways to turn off the speed control:

• Depress the brake pedal. This will not erase your vehicle’s previously set speed.

• Press the speed control OFF control.

Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased.

SET

COAST

RES

STEERING WHEEL CONTROLS (IF EQUIPPED)

These controls allow you to operate some radio and climate control features.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Audio control features

Press

• AM, FM1, FM2,

• CD (if equipped), or

• DVD (if equipped).

In AM, FM1, or FM2 mode:

• Press MEM to select preset

In CD mode:

• Press MEM to select the next

In any mode:

• Press VOL + or − to adjust

to select:

stations within the selected radio band.

selection on the CD.

volume.

Driver Controls

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Climate control features

Press TMP + or - to adjust temperature.

Press

MOON ROOF (IF EQUIPPED)

You can move the glass panel of the moon roof back to open or tilt up to ventilate the vehicle.

+ or - to adjust fan speed.

Do not let children play with the moon roof or leave children unattended in the vehicle. They may seriously hurt themselves.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

To open the moon roof:

The moon roof is equipped with an automatic, one-touch, express opening feature. Press and release the rear portion of the control. To stop motion at any time during the one-touch opening, press the control again.

To close the moon roof:

Press and hold the front portion of the control until the glass panel stops moving. Once fully closed, the rear of the glass panel will appear higher than the front edge.

To vent:

To tilt the moon roof into the vent position (when the glass panel is closed), press and hold the front portion of the control. To close the moon roof from the vent position, press and hold the rear portion of the control until the glass panel stops moving.

If the battery is disconnected, discharged, or a new battery is installed, the moon roof needs to be opened to the vent position to reset the moon roof positions.

The moon roof has a sliding shade that can be opened or closed when the glass panel is shut. To close the shade, pull it toward the front of the vehicle.

When closing the moon roof, you should verify that it is free of obstructions and ensure that children and/or pets are not in the

proximity of the moon roof opening.

HOMELINK姞 WIRELESS CONTROL SYSTEM (IF EQUIPPED)

The HomeLink威 Wireless Control System, located on the overhead console, provides a convenient way to replace up to three hand-held transmitters with a single built-in device. This feature will learn the radio frequency codes of most transmitters to operate garage doors, entry gate operators, security systems, entry door locks, and home or office lighting.

When programming your HomeLink威 Wireless Control System to a garage door or gate, be sure that people and objects are out of

the way to prevent potential harm or damage.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Do not use the HomeLink威 Wireless Control System with any garage door opener that lacks safety stop and reverse features as required by U.S. federal safety standards (this includes any garage door opener model manufactured before April 1, 1982). A garage door which cannot detect an object, signaling the door to stop and reverse, does not meet current U.S. federal safety standards. For more information, contact HomeLink威 at: www.homelink.com or 1–800–355–3515.

Retain the original transmitter for use in other vehicles as well as for future programming procedures (i.e. new HomeLink威 equipped vehicle purchase). It is also suggested that upon the sale of the vehicle, the programmed Homelink威 buttons be erased for security purposes, refer to Programming in this section.

Programming

Do not program HomeLink威 with the vehicle parked in the garage. Note: Some vehicles may require the ignition switch to be turned to the

second (or “ACC”) position for programming and/or operation of the HomeLink威. It is also recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink威 for quicker training and accurate transmission of the radio-frequency signal.

1. Press and hold the two outside

buttons releasing only when the indicator light begins to flash after 20 seconds. Do not repeat Step 1 to program additional hand-held transmitters to the remaining two HomeLink威 buttons. This will erase previously programmed hand-held transmitter signals into HomeLink威.

2. Position the end of your

hand-held transmitter 1–3 inches (2–8 cm) away from the HomeLink威 button you wish to program (located on your overhead console) while keeping the indicator light in view.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

3. Simultaneously press and hold

both the HomeLink威 and hand-held transmitter button. Do not release

the buttons until Step 4 has been completed.

Some entry gates and garage door openers may require you to replace Step 3 with procedures noted in the “Gate Operator and Canadian Programming” section for Canadian residents.

4. The indicator light will flash slowly and then rapidly. Release both

buttons when the indicator light flashes rapidly. (The rapid flashing light indicates acceptance of the hand-held transmitters’ radio frequency signals.)

5. Press and hold the just-trained HomeLink威 button and observe the

indicator light. If the light is constant, programming is complete and your device should activate when the HomeLink威 button is pressed and released. Note: To program the remaining two HomeLink威 buttons, begin with Step 2 in the “Programming” section — do not repeat Step 1.

Note: If the indicator light blinks rapidly for two seconds and then turns to a continuous light, proceed with Steps 6 through 8 to complete programming of a rolling code equipped device.

6. At the garage door opener receiver (motor-head unit) in the garage,

locate the “learn” or “smart” button (usually near where the hanging antenna wire is attached to the unit).

7. Press and release the “learn” or “smart” button. (The name and color

of the button may vary by manufacturer.) Note: There are 30 seconds in which to initiate Step 8.

8. Return to the vehicle and firmly press, hold for two seconds and

release the HomeLink威 button. Repeat the press/hold/release sequence again, and, depending on the brand of the garage door opener (or other rolling code equipped device), repeat this sequence a third time to complete the programming.

HomeLink威 should now activate your rolling code equipped device. To program additional HomeLink威 buttons begin with Step 2 in the “Programming” section. For questions or comments, please contact HomeLink at www.homelink.com or 1–800–355–3515.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Gate Operator & Canadian Programming

During programming, your hand-held transmitter may automatically stop transmitting — not allowing enough time for HomeLink威 to accept the signal from the hand-held transmitter.

After completing Steps 1 and 2 outlined in the “Programming” section, replace Step 3 with the following:

Note: If programming a garage door opener or gate operator, it is advised to unplug the device during the “cycling” process to prevent overheating.

• Continue to press and hold the HomeLink威 button (note Step 3 in the “Programming” section) while you press and release — every two seconds (“cycle”) your hand-held transmitter until the frequency signal has been accepted by the HomeLink威. The indicator light will flash slowly and then rapidly after HomeLink威 accepts the radio frequency signal.

• Proceed with Step 4 in the “Programming” section.

Operating the HomeLink姞 Wireless Control System

To operate, simply press and release the appropriate HomeLink威 button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.). For convenience, the hand-held transmitter of the device may also be used at any time. In the event that there are still programming difficulties, contact HomeLink威 at www.homelink.com or 1–800–355–3515.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Erasing HomeLink姞 buttons

To erase the three programmed buttons (individual buttons cannot be erased):

• Press and hold the two outer HomeLink威 buttons until the indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds.

HomeLink威 is now in the train (or learning) mode and can be programmed at any time beginning with Step 2inthe“Programming” section.

Reprogramming a single HomeLink姞 button

To program a device to HomeLink威 using a HomeLink威 button previously trained, follow these steps:

1. Press and hold the desired HomeLink威 button. Do NOT release the

button.

2. The indicator light will begin to flash after 20 seconds. Without

releasing the HomeLink威 button, follow Step 2 in the “Programming” section.

For questions or comments, contact HomeLink威 at www.homelink.com or 1–800–355–3515.

ELECTRONIC COMPASS/TEMPERATURE DISPLAY (IF EQUIPPED)

Outside air temperature

The outside temperature display is contained in the instrument cluster and displays all the time. If equipped with the DATC climate control system, the outside temperature will be displayed there. For more information, refer to Dual automatic temperature control (DATC) in the Climate Controls chapter

To turn the display off or change the display from English to metric see your dealer.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Compass

The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antennas. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy.

Usually, when something affects the compass readings, the compass will correct itself after a few days of operating your vehicle in normal conditions. If the compass still appears to be inaccurate, a manual calibration may be necessary. Refer to Compass calibration adjustment in this section.

Most geographic areas (zones) have a magnetic north compass point that varies slightly from the northerly direction on maps. This variation is four degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error. Refer to Compass zone adjustment in this section.

Compass zone adjustment

1. Determine which magnetic zone

you are in for your geographic location by referring to the zone map.

2. Turn ignition to the ON position.

123

15 14

13 12

6 7 8 91011

3. Locate compass sensor mounted

at base of mirror.

4. Press the button on the top of

the compass module until ZONE appears in the instrument cluster display.

5. Release pressure on the button and then slowly press it down again.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

6. Continue to press until ZONE

appears in the instrument cluster display, then release. The display should show the current zone number.

7. Press until the desired zone

number appears. The display will flash and then return to normal operation. The zone is now updated.

Compass calibration adjustment

Perform this adjustment in an open area free from steel structures and high voltage lines:

For optimum calibration, turn off all electrical accessories (heater/air conditioning, wipers, etc.) and make sure all vehicle doors are shut.

1. Start the vehicle.

2. Locate compass sensor mounted at base of mirror.

3. Press the button on the top of

the compass module until ZONE appears in the instrument cluster display. Continue to hold down until ZONE disappears and CAL is displayed (approximately eight seconds) and release.

4. Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until

CAL indicator turns off (4–5 complete circles).

5. The compass is now calibrated.

MESSAGE CENTER (IF EQUIPPED)

With the ignition in the ON position, the message center, located on your instrument cluster, displays important vehicle information

through a constant monitor of vehicle systems. You may select

display features on the message center for a display of status preceded by a brief indicator chime. The system will also notify you of potential vehicle problems with a display of system warnings followed by a long indicator chime.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Selectable features

Reset

Press this control to select and reset functions shown in the INFO menu and SETUP menu.

Info menu

This control displays the following control displays:

• Odometer/Compass

• Trip odometer/Odometer/Compass

• Average Fuel Economy

• Trip Elapsed Drive Time

• Distance to Empty

Odometer/Trip odometer

Refer to Gauges in the Instrument Cluster chapter.

Compass display

The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antenna. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy.

Most geographic areas (zones) have a magnetic north compass point that varies slightly from the northerly direction on maps. This variation is four

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error. Refer to Compass zone/calibration adjustment in this section.

Compass zone/calibration adjustment

Perform this adjustment in an open area free from steel structures and high voltage lines.

For optimum calibration, turn off all electrical accessories (heater/air conditioning, wipers, etc.) and make sure all vehicle doors are shut.

1. Turn ignition to the ON position.

2. Start the engine.

3. Determine your magnetic zone by

referring to the zone map.

4. From Info menu, select the

Compass/Odometer function. (Do not select Trip, DTE, or AFE. The top of the message center must be blank).

5. Press and hold the RESET and

SETUP control until the message center display changes to show the current zone setting.

123

6 7 8 91011

15 14

13 12

6. Release the RESET AND SETUP

control, then slowly press RESET down again.

7. Press the SETUP control

repeatedly until the correct zone setting for your geographic location is displayed on the message center. To exit the zone setting mode press and release the RESET control.

8. Press the RESET control to start

the compass calibration function.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

9. Slowly drive the vehicle in a

circle (less than 3 mph [5 km/h]) until the CIRCLE SLOWLY TO CALIBRATE indicator changes to CALIBRATION COMPLETED. This will take up to three circles to complete calibration.

10. The compass is now calibrated.

Average fuel economy (AFE)

Select this function from the INFO menu to display your average fuel economy in miles/U.S. gallon or liters/100 km.

If you calculate your average fuel economy by dividing gallons of fuel used by 100 miles traveled (kilometers traveled by liters used), your figure may be different than displayed for the following reasons:

• Your vehicle was not perfectly level during fill-up

• Differences in the automatic shut-off points on the fuel pumps at

service stations

• Variations in top-off procedure from one fill-up to another

• Rounding of the displayed values to the nearest 0.1 gallon (liter)

1. Drive the vehicle at least 5 miles (8 km) with the speed control

system engaged to display a stabilized average.

2. Record the highway fuel economy for future reference.

It is important to press the RESET control after setting the speed control to get accurate highway fuel economy readings.

Average fuel economy for FFV-equipped vehicles

Upon refueling, your vehicle needs to determine the percentage of Ethanol in the fuel. For the first several minutes, or few miles of driving, the message “COMPUTING FUEL” may appear in the message center. The correct fuel economy will appear in the message center following calculation.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Trip elapsed drive time

Select this function from the INFO menu to display a timer.

To operate the Trip Elapsed Drive Time perform the following:

1. Press and release RESET in order

to start the timer.

2. Press and release RESET to pause the timer.

3. Press and hold RESET for 2 seconds in order to reset the timer.

Distance to empty (DTE)

Selecting this function from the INFO menu estimates approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition OFF when refueling to allow this feature to correctly detect the added fuel.

The DTE function will display LOW FUEL LEVEL and sound a tone for one second when you have approximately 50 miles (80 km) to empty. If you RESET this warning message, this display and tone will return within 10 minutes.

DTE is calculated using a running average fuel economy, which is based on your recent driving history of 500 miles (800 km). This value is not the same as the average fuel economy display. The running average fuel economy is reinitialized to a factory default value if the battery is disconnected.

Distance to empty for FFV-equipped vehicles

Upon refueling, your vehicle needs to determine the percentage of Ethanol in the fuel. For the first several minutes, or few miles of driving, the message “COMPUTING FUEL” may appear in the message center. The correct distance to empty will appear in the message center following calculation.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Setup menu

Press this control for the following displays:

• System Check

• Units (English/Metric)

• Autolock

• Easy Entry/Exit

• Autolamp Delay

• Oil Change

• Language

• AWD Lock (vehicles equipped with AdvanceTrac娂 with RSC only)

System check

Selecting this function from the SETUP menu causes the message center to cycle through each of the systems being monitored. For each of the monitored systems, the message center will indicate either an OK message or a warning message for three seconds.

Pressing the RESET control cycles the message center through each of the systems being monitored.

The sequence of the system check report and how it appears in the message center is as follows:

1. FUEL LEVEL

2. WASHER FLUID LEVEL

3. OIL LIFE IN XX%

4. ADVTRAC

5. ENGINE TEMP

6. OIL PRESSURE

7. TIRE PRESSURE SYSTEM (if equipped)

8. BRAKE FLUID LEVEL

9. CHARGING SYSTEM

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Units (English/Metric)

1. Select this function from the

SETUP menu for the current units to be displayed.

2. Press the RESET control to

change from English to Metric.

Autolocks

1. Select this function from the

SETUP control for the current display mode.

2. Press the RESET control to turn

the autolocks ON or OFF.

Easy entry/exit (if equipped)

1. Select this function from the

SETUP control for the current display mode.

2. Press the RESET control to turn

the easy entry/exit feature ON or OFF. For more information refer to Memory Seat/Adjustable Pedals/Easy entry/exit feature in the Seating and Safety Restraints chapter.

Autolamp delay

1. Select this function from the

SETUP control for the current display mode.

2. Press the RESET control to select

the autolamp delay time.

Oil Change

1. Select this function from the

SETUP control for the current display mode.

2. Press the RESET control to reset

oil change.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Language

1. Select this function from the

SETUP menu for the current language to be displayed.

2. Pressing the RESET control

cycles the message center through each of the language choices.

3. Press and hold the RESET

control to set the language choice.

AWD lock (vehicles equipped with AdvanceTrac姟 with RSC only)

Select this function from the SETUP menu to display the AWD locked function.

1. Press the SETUP control for the

current display mode.

2. Press the RESET control within 4

seconds to turn the AWD system to the LOCKED mode.

System warnings

System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems.

In the event of a multiple warning situation, the message center will cycle the display to show all warnings by displaying each one for several seconds.

The message center will display the last selected feature if there are no more warning messages. This allows you to use the full functionality of the message center after you acknowledge the warning by pressing the RESET control and clearing the warning message.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Warning messages that have been reset are divided into three categories:

• They will reappear on the display every minute from the reset.

• They will reappear on the display ten minutes from the reset.

• They will not reappear until an ignition OFF-ON cycle has been

completed.

This acts as a reminder that these warning conditions still exist within the vehicle.

Warning display Status

Temporary AWD lock (vehicles equipped with AdvanceTrac威 only)

AWD lock OFF AWD auto ON (vehicles equipped with AdvanceTrac威 only)

Check engine temperature Warning returns after 10 minutes Transmission overheated Check transmission Low fuel level Check fuel cap Check charging system Low brake fluid level Low oil pressure Warning-tire very low (if

equipped) ETC-engine failsafe mode AWD disabled lock (vehicles

equipped with AdvanceTrac威 with RSC only)

Displays for 4 seconds

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

Warning display Status

Check tire pressure (if equipped)

Tire pressure monitor fault (if equipped)

Tire pressure sensor fault (if equipped)

Check AdvanceTrac威 (if equipped)

Check AWD (vehicles equipped with AdvanceTrac威 with RSC only)

AWD Disabled (vehicles equipped with AdvanceTrac威 with RSC only)

Low washer fluid level Door ajar Change oil soon Oil change required

TEMPORARY AWD LOCK (vehicles equipped with AdvanceTrac威 with RSC only). Displayed when the AWD system automatically locks

to prevent damage from overheating.

AWD LOCK OFF and AWD AUTO ON (vehicles equipped with AdvanceTrac威 with RSC only). Displayed when the AWD system is

completely cooled down from being overheated. CHECK ENGINE TEMPERATURE. Displayed when the engine

coolant is overheating. Stop the vehicle as soon as safely possible, turn off the engine and let it cool. Check the coolant and coolant level. Refer to Engine coolant in the Maintenance and Specifications chapter. If the warning stays on or continues to come on, contact your dealer as soon as possible.

TRANSMISSION OVERHEATED. Indicates the transmission is overheating. This warning may appear when towing heavy loads or when driving in a low gear at a high speed for an extended period of time. Stop the vehicle as soon as safely possible, turn off the engine and let it cool. Refer to Transmission fluid in the Maintenance and Specifications chapter. If the warning stays on or continues to come on, contact your dealer for transmission service as soon as possible.

Warning returns after the ignition key is turned from OFF to ON.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

CHECK TRANSMISSION. Indicates the transmission is not operating properly. If this warning stays on, contact your dealer as soon as possible.

AWD DISABLED LOCK (vehicles equipped with AdvanceTrac威 with RSC only). Displayed when the AWD system begins to overheat

placing itself in the autolock mode. If the warning stays on or continues to come on, contact your dealer as soon as safely possible.

LOW FUEL LEVEL. Displayed as an early reminder of a low fuel condition.

CHECK FUEL CAP. Displayed when the fuel filler cap is not properly installed. Check the fuel filler cap for proper installation. Refer to Fuel filler cap in the Maintenance and Specifications chapter.

ETC-ENGINE FAILSAFE MODE. Displayed when the engine has defaulted to a “limp-home” operation. If the warning stays on or continues to come on, contact your dealer as soon as possible.

CHECK CHARGING SYSTEM. Displayed when the electrical system is not maintaining proper voltage. If you are operating electrical accessories when the engine is idling at a low speed, turn off as many of the electrical loads as possible. If the warning stays on or comes on when the engine is operating at normal speeds, have the electrical system checked as soon as possible.

LOW BRAKE FLUID LEVEL. Indicates the brake fluid level is low and the brake system should be inspected immediately. Refer to Brake fluid reservoir in the Maintenance and Specifications chapter.

LOW OIL PRESSURE. Displayed when the engine oil level is low. If this warning message is displayed, check the level of the engine oil. Refer to Engine oil in the Maintenance and Specifications chapter for information about adding engine oil.

WARNING-TIRE VERY LOW (if equipped). Displayed when one or more road tires on your vehicle have very low pressure. When this warning message is displayed, a warning chime will sound reminding you to stop the vehicle as soon as safely possible to check your tires for proper air pressure, leaks and damage. Refer to Inspecting and Inflating Your Tires in the Tires, Wheels and Loading chapter.

CHECK TIRE PRESSURE (if equipped).Displayed when one or more tires on your vehicle have low tire pressure. Refer to Inspecting and Inflating Your Tires in the Tires, Wheels and Loading chapter.

TIRE PRESSURE MONITOR FAULT (if equipped). Displayed when the Tire Pressure Monitoring System is malfunctioning. If the warning stays on or continues to come on, have the system inspected by your servicing dealership.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

TIRE PRESSURE SENSOR FAULT (if equipped). Displayed when a tire pressure sensor is malfunctioning, or your spare tire is in use. For more information on how the system operates under these conditions, refer to Understanding Your Tire Pressure Monitoring System in the Tires, Wheels and Loading chapter. If the warning stays on or continues to come on, have the system inspected by your servicing dealership.

LOW WASHER FLUID LEVEL. Indicates the washer fluid reservoir is less than one quarter full. Check the washer fluid level. Refer to Windshield washer fluid in the Maintenance and Specifications chapter.

CHECK ADVANCETRAC威 (if equipped). Displayed when the AdvanceTrac威 with RSC system is not operating properly. If this message is displayed on the message center the AdvanceTrac威 with RSC system will be partially operable. If this warning stays on while the engine is running, contact your dealer for service as soon as possible. For further information, refer to AdvanceTrac威 stability enhancement system in the Driving chapter.

AWD DISABLED (vehicles equipped with AdvanceTrac威 with RSC only). Displayed for 4 seconds then SEE OWNER’S MANUAL will

display indicating that the AWD system is not operating properly. For further information, refer to Disabling AWD in the Driving chapter. See your dealer as soon as possible

CHECK AWD (vehicles equipped with AdvanceTrac威 with RSC only). Displayed when the AWD system is not operating properly. If the

warning stays on or continues to come on, contact your dealer immediately.

DOOR AJAR. Displayed when a door or liftgate is not completely closed.

CHANGE OIL SOON/OIL CHANGE REQUIRED. Displayed when the engine oil life remaining is 5 percent or less. When oil life left is between 5% and 0%, the CHANGE OIL SOON message will be displayed. When oil life left reaches 0%, the OIL CHANGE REQUIRED message will be displayed.

An oil change is required whenever indicated by the message center and according to the recommended maintenance schedule. USE ONLY RECOMMENDED ENGINE OILS.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

To reset the oil monitoring system to 100% after each oil change [approximately 5,000 miles (8,000 km) or 180 days] perform the following:

1. Press and release the SETUP

control to display “PRESS RESET AT OIL CHANGE”.

2. Press and release the RESET

control to display “HOLD RESET TO CONFIRM”.

3. Press and hold the RESET

control for 2 seconds and release. Oil life is set to 100% and “OIL LIFE SET TO 100%” is displayed.

After you have done steps 1 through 3, you can reset the oil monitoring system to your personalized oil life %:

4. Press RESET and SETUP

controls at the same time for 2 seconds, to activate a service mode which will display “OIL LIFE XX% RESET TO ALTER”.

5. Press RESET to decrement oil life by 10% down to 30% and back to

100%.

6. With your personalized OIL LIFE XX% displayed, press SETUP to

continue the system check. DATA ERR. These messages indicate improper operation of the vehicle

network communication between electronic modules.

• Fuel computer

• Oil life

• Charging system

• Door sensor

• Washer fluid

• Brake fluid

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

• Compass

• Outside temperature

• Engine sensor

Contact your dealer as soon as possible if these messages occur on a regular basis.

POSITIVE RETENTION FLOOR MAT

Position the driver floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. To remove the floor mat, reverse the installation procedure.

REAR LIFTGATE

The liftgate area is only intended for cargo, not passengers. You can open and close the liftgate from outside the vehicle. It cannot be opened from inside the cargo area.

• To open the liftgate window, press the control on the remote entry transmitter or, with the liftgate unlocked, push the control button on the right side under the license plate lamp shield.

• To open the liftgate, unlock the liftgate (with the power door locks, the remote entry or the keyless entry pad) and pull the middle lever under the license plate lamp shield.

To lock the liftgate and the liftgate window, use the power door locks or press the door lock switch on the left side of the cargo area. To manually lock or unlock the liftgate, move the button located below the window down or up.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

The liftgate door and window should be closed before driving. If not, possible damage may occur to your vehicle.

Always close liftgate window before opening liftgate. Liftgate

glass and liftgate should never be open at the same time. Failure to observe this warning may result in personal injury or damage to your vehicle.

Make sure the liftgate door and/or window are closed to prevent

exhaust fumes from being drawn into the vehicle. This will also reduce the risk of passengers and cargo falling out.

CARGO COVER (IF EQUIPPED)

Your vehicle may be equipped with a cargo area cover that covers the luggage compartment of your vehicle.

To install the cover: Push both ends of the cover into the

depressions (right side first) in the trim panels behind the second row seat.

To reduce the risk of

injuries, the cargo area cover must be properly installed on the rear trim panels.

Do not place any objects on the cargo area cover. They may

obstruct your vision or strike occupants of the vehicle in the case of a sudden stop or collision.

Cargo management system

The cargo management system consists of storage compartments located in the floor of the rear cargo area.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

7 passenger stowage:

1. To open, lift the release handle and the lid.

2. To close, lower the lid, lift the release handle and press down on the lid.

5 passenger stowage:

When the lid is open, it will stand up on its own.

1. To open, lift the release handle and the lid.

2. To close, lower the lid, lift the release handle and press down on the lid.

LUGGAGE RACK

The maximum recommended load is 200 lbs (90 kg), evenly distributed. If it is not possible to distribute the load, position it as far rearward as possible. Use the tie down loops (on the thumbwheels) to secure the load.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Driver Controls

To adjust cross-bar position (if equipped):

1. Loosen the thumbwheel at both ends of the cross-bar (both cross-bars are adjustable).

2. Slide the cross-bar to the desired location.

3. Tighten the thumbwheel at both ends of the cross-bar.

Vehicles with a higher center of gravity such as utility and

four-wheel drive vehicles handle differently than vehicles with a lower center of gravity. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sport cars are designed to perform satisfactorily under off-road conditions. Avoid sharp turns, excessive speed and abrupt maneuvers in these vehicles. Failure to drive cautiously could result in an increase risk of loss of vehicle control, vehicle rollover, personal injury and death.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

KEYS

One key operates all the locks and starts the vehicle. Always carry a spare key with you in case of an emergency.

Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start. If you lose your dealer supplied keys, replacement keys are available through your authorized dealer. Refer to the SecuriLock娂 passive anti-theft system section later in this chapter for more information.

POWER DOOR LOCKS

Press control to unlock all vehicle doors.

Press control to lock all vehicle doors.

Liftgate

An additional power door lock can be accessed by opening the liftgate. The button is located either on the top of the left-hand quarter trim panel underneath the rear window, or on the bottom of the left-hand quarter trim panel. Press this button to lock or unlock all the doors.

Smart unlocking feature

The smart unlocking feature helps prevent you from locking yourself out of the vehicle. With the key in any ignition position, the driver’s door will automatically unlock if it is locked using the power lock control on the driver’s door panel while the driver’s door is open.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

Childproof door locks

• When these locks are set, the rear doors cannot be opened from the inside.

• The rear doors can be opened from the outside when the doors are unlocked.

The childproof locks are located on rear edge of each rear door and must be set separately for each door. Setting the lock for one door will not automatically set the lock for both doors.

• Move lock control up to engage the childproof lock.

• Move control down to disengage childproof locks.

REMOTE ENTRY SYSTEM

This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

The typical operating range for your remote entry transmitter is approximately 33 feet (10 meters). A decrease in operating range could be caused by:

• weather conditions,

• nearby radio towers,

• structures around the vehicle, or

• other vehicles parked next to your vehicle.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

The remote entry system allows you to lock or unlock all vehicle doors and liftgate and open the liftgate window without a key.

The remote entry lock/unlock feature operates in any ignition position. The liftgate glass feature operates as long as the vehicle’s speed is less than 3 mph (5 km/h). The panic feature operates with the key in the 1 (OFF/LOCK) or 2 (ACC) position.

If there is any potential remote keyless entry problem with your vehicle, ensure ALL remote entry transmitters are brought to the dealership, to aid in troubleshooting.

Unlocking the doors

1. Press and release to unlock the driver’s door. Note: The interior

lamps will illuminate.

2. Press

doors. The remote entry system activates the illuminated entry feature. This

feature turns on the interior lamps for 25 seconds or until the ignition is turned to the 3 (ON) position. If the dome lamp control is in the off position the illuminated entry feature will not work.

The inside lights will not turn off if:

• they have been turned on using the dimmer control or

• any door is open.

The battery saver feature will turn off the interior lamps 30 minutes after the ignition is turned to the 1 (OFF/LOCK) position.

and release again within three seconds to unlock all the

Locking the doors/liftgate

1. Press and release to lock all the doors and liftgate. The lamps will

flash. Note: If any door, the liftgate or the liftgate glass are not closed properly, the lamps will not flash.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

2. Press and release again within three seconds to confirm that all the

doors are closed and locked. Note: The doors will lock again, the horn will chirp and the lamps flash once.

Note: If any door, the liftgate or the liftgate glass are not closed properly, the horn will make two quick chirps.

Opening the liftgate window

Press

Sounding a panic alarm

Press will flash for a maximum of 3 minutes. Press again or turn the ignition to the 3 (ON) position to deactivate, or wait for the alarm to timeout in 3 minutes.

Note: The panic alarm will only operate when the ignition is in the 1 (OFF/LOCK) or 2 (ACC) position.

Memory seats/adjustable pedals/easy entry-exit feature (if equipped)

The remote entry system can also control the memory seat /adjustable pedals/easy entry-exit feature.

Press desired memory position (the seat position corresponds to the transmitter being used).

Activating the memory seat feature

To activate this feature:

1. Position the seat and adjustable pedals to the position desired.

2. Press the SET control on the

driver’s door panel.

3. Within 5 five seconds, press one

control on the remote transmitter and then press the 1 or 2 control on the driver’s door panel to which you would like to associate with the seat and Driver 1 or Driver 2 positions.

4. Repeat this procedure for another

remote transmitter if desired.

to unlatch the liftgate window.

to activate the alarm. The horn will sound and the parklamps

to automatically move the seat and adjustable pedals to the

SET

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

Deactivating the memory seat feature

To deactivate this feature:

1. Press the SET control on the driver’s door panel.

2. Within 5 five seconds, press any control on the remote transmitter

which you would like to deactivate and then press the SET control on the driver’s door panel.

3. Repeat this procedure for another remote transmitter if desired.

Replacing the battery

The remote entry transmitter uses one coin type three-volt lithium battery CR2032 or equivalent.

To replace the battery:

1. Twist a thin coin between the two

halves of the remote entry transmitter near the key ring. DO NOT TAKE THE RUBBER COVER AND CIRCUIT BOARD OFF THE FRONT HOUSING OF THE REMOTE ENTRY TRANSMITTER.

2. Do not wipe off any grease on the

battery terminals on the back surface of the circuit board.

3. Remove the old battery. Note: Please refer to local regulations when

disposing of transmitter batteries.

4. Insert the new battery. Refer to the diagram inside the remote entry

transmitter for the correct orientation of the battery. Press the battery down to ensure that the battery is fully seated in the battery housing cavity.

5. Snap the two halves back together.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

Note: Replacement of the battery will not cause the remote transmitter to become deprogrammed from your vehicle. The remote transmitter should operate normally after battery replacement.

Replacing lost remote entry transmitters

If you would like to have your remote entry transmitter reprogrammed because you lost one, or would like to buy additional remote entry transmitters, you can either reprogram them yourself, or take all remote entry transmitters to your authorized dealer for reprogramming.

How to reprogram your remote entry transmitters

You must have all remote entry transmitters (maximum of four) available before beginning this procedure. If all remote entry transmitters are not present during the programming procedure, the transmitters that are not present during programming will no longer operate the vehicle.

To reprogram the remote entry transmitters:

1. Ensure the vehicle is electronically unlocked.

2. Put the key in the ignition.

3. Turn the key from the 1 (OFF/LOCK) position to 3 (ON).

4. Cycle eight times rapidly (within 10 seconds) between the 1

(OFF/LOCK) position and 3 (ON). Note: The eighth turn must end in the 3 (ON) position.

5. The doors will lock, then unlock, to confirm that the programming

mode has been activated.

6. Within 20 seconds press any button on the remote entry transmitter.

Note: If more than 20 seconds have passed you will need to start the procedure over again.

7. The doors will lock, then unlock, to confirm that this remote entry

transmitter has been programmed.

8. Repeat Step 6 to program each additional remote entry transmitter.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

9. Turn the ignition to the 1 (OFF/LOCK) position after you have

finished programming all of the remote entry transmitters.

10. The doors will lock, then unlock, to confirm that the programming

mode has been exited.

Illuminated entry

The interior lamps illuminate when the remote entry system is used to unlock the door(s) or sound the personal alarm.

The illuminated entry system will turn off the interior lights if:

• the ignition is turned to the 3 (ON) position, or

• the remote transmitter lock control is pressed, or

• after 25 seconds of illumination.

The dome lamp control (if equipped) must not be set to the off position for the illuminated entry system to operate.

The inside lights will not turn off if:

• they have been turned on with the dimmer control, or

• any door is open.

The battery saver will shut off the interior lamps 10 minutes after the ignition has been turned to the 1 (OFF/LOCK) position.

KEYLESS ENTRY SYSTEM (IF EQUIPPED)

You can use the keyless entry keypad to:

• lock or unlock the doors without using a key.

• open the liftgate window.

• activate or deactivate the

autolock feature.

The keypad can be operated with the factory set 5–digit entry code; this code is located on the owner’s wallet card in the glove box, is marked on the computer module, and is available from your authorized dealer. You can also create your own 5–digit personal entry code. In the event the wallet card is lost, the factory set code cannot be reprogrammed.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

When pressing the controls on the keypad, press the middle of the controls to ensure a good activation.

Programming a personal entry code

To create your own personal entry code:

1. Enter the factory set code.

2. Within five seconds press the 1 • 2 on the keypad.

3. Enter your personal 5-digit code. Each number must be entered

within five seconds of each other.

4. The doors will again lock then unlock to confirm that your personal

keycode has been programmed to the module.

Tips:

• Do not set a code that uses five of the same number.

• Do not use five numbers in sequential order.

• The factory set code will work even if you have set your own personal

code.

• If you set a second personal code it will erase your first personal code.

Erasing personal code

1. Enter the factory set 5–digit code.

2. Within five seconds, press the 1 • 2 on the keypad and release.

3. Press and hold the 1 • 2 for two seconds. This must be done within

five seconds of completing Step 2. Your personal code is now erased and only the factory set 5–digit code

will work.

Anti-scan feature

If the wrong code has been entered 7 times (35 consecutive button presses), the keypad will go into an anti-scan mode. This mode disables the keypad for one minute and the keypad lamp will flash.

The anti-scan feature will turn off after:

• one minute of keypad inactivity.

• pressing the UNLOCK

• the ignition is turned to the 3 (ON) position.

control on the remote entry transmitter.

Unlocking and locking the doors, liftgate and liftgate window using keyless entry

To unlock the driver’s door, enter the factory set 5-digit code or your personal code. Each number must be pressed within five seconds of each other. The interior lamps will illuminate.

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Locks and Security

To unlock all doors and liftgate, press the 3 • 4 control within five seconds.

To open the liftgate window, press the 5 • 6 control within five seconds.

To lock all doors, liftgate and liftgate window, press the 7 • 8 and the 9 • 0 at the same time. Note: The driver’s door must be closed. You do not need to enter the keypad code first.

Autolock

The autolock feature will lock all the doors, liftgate and liftgate window when:

• all the doors, the liftgate and liftgate window are closed,

• the ignition is in the 3 (ON) position,

• you shift into any gear putting the vehicle in motion, and

• the brake pedal is released and the vehicle attains a speed greater

than 5 mph (8 km/h).

The autolock feature repeats when:

• any door, liftgate or liftgate window is opened then closed while the ignition is in the 3 (ON) position, and

• you put the vehicle in motion by releasing the brake pedal and the vehicle attains a speed greater than 5 mph (8 km/h).

Deactivating/activating autolock

Your vehicle comes with the autolock feature activated. There are four methods to enable/disable this feature: One is through your dealer, the second with a power door unlock/lock sequence, the third with the keypad, and the fourth by using the message center (if equipped).

Before following the activation or deactivation procedures, make sure that the anti-theft system is not armed, ignition is off, and all vehicle doors, liftgate and liftgate window are closed.

100

2005 Mountaineer (mnt) Owners Guide (post-2002-fmt) USA (fus)

Ford Mountaineer 2005 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Introduction

CONGRATULATIONS

SAFETY AND ENVIRONMENT PROTECTION

Warning symbols in this guide

Warning symbols on your vehicle

Protecting the environment

BREAKING-IN YOUR VEHICLE

Special instructions

Service Data Recording

Event Data Recording

Notice to owners of pickup trucks and utility type vehicles

Using your vehicle with a snowplow

Using your vehicle as an ambulance

MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION

Instrument Cluster

WARNING LIGHTS AND CHIMES

GAUGES

Entertainment Systems

AM/FM STEREO / SINGLE CD RADIO (IF EQUIPPED)

AUDIOPHILE SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SIX CD RADIO (IF EQUIPPED)

SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SINGLE CD/MP3 RADIO — LATE AVAILABILITY (IF EQUIPPED)

AUDIOPHILE SATELLITE COMPATIBLE AM/FM STEREO IN-DASH SIX CD/MP3 RADIO — LATE AVAILABILITY (IF EQUIPPED)

FAMILY ENTERTAINMENT SYSTEM (IF EQUIPPED)

RADIO FREQUENCIES

RADIO RECEPTION FACTORS

CD/CD PLAYER CARE

AUDIO SYSTEM WARRANTY AND SERVICE

Climate Controls

MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED)

Operating tips

Dual Automatic Temperature Control (DATC) system (if equipped)

Operating tips

Auxiliary system (if equipped)

Floor console climate controls (if equipped)

REAR WINDOW DEFROSTER

Lights

HEADLAMP CONTROL

Autolamp system

Foglamp control

Daytime running lamps (DRL) (if equipped)

High beams

Flash to pass

PANEL DIMMER CONTROL

AIMING THE HEADLAMPS

Headlamp aim adjustment

TURN SIGNAL CONTROL

Cargo/reading lamps

Replacing exterior bulbs

Replacing the interior bulbs

Using the right bulbs

Replacing headlamp bulbs

Replacing front parking/turn signal bulbs

Replacing side-mounted turn signal bulbs

Replacing front/rear side marker bulbs

Replacing tail/brake/turn/backup lamp bulbs

Replacing foglamp bulbs

Replacing license plate lamp bulbs

Replacing high-mount brakelamp bulb

Driver Controls

MULTI-FUNCTION LEVER

Rear window wiper/washer controls

Changing the wiper blades

TILT STEERING COLUMN

CENTER CONSOLE

Cell phone use

Rear center console features (if equipped)

OVERHEAD CONSOLE (IF EQUIPPED)

Storage compartment

Installing a garage door opener (if equipped)

Illuminated visor mirror

AUXILIARY POWER POINT (12VDC)

Rear auxiliary power point (if equipped)

POWER WINDOWS

One touch down

Window lock
