Ford Expedition 2013 Owner's Manual

2013 EXPEDITION Owner’s Manual
2013 EXPEDITION Owner’s Manual
DL1J 19A321 AA | May 2013 | Third Printing | Owner’s Manual | Expedition | Litho in U.S.A.

Table of Contents 1

Introduction 9
Child Safety 17
Child seats...........................................19
Child seat positioning ...................................19
Booster seats .........................................21
Installing child safety seats ...............................23
Child safety locks ......................................34
Safety Belts 35
Fastening the safety belts ................................37
Safety belt height adjustment .............................40
Safetybeltwarninglightandindicatorchime..................41
Safety belt-minder .....................................42
Child restraint and safety belt maintenance ...................44
Supplementary Restraints System 45
Driver and passenger airbags .............................47
Side airbags ..........................................49
Safety canopy curtain airbags .............................51
Crash sensors and airbag indicator .........................53
Airbag disposal........................................54
Keys and Remote Control 55
General information on radio frequencies.....................55
Remote control .......................................55
Keys ...............................................55
Replacing a lost key or remote control.......................58
MyKey 59
Settings, MyKey .......................................59
Creating.............................................60
Clearing.............................................61
System status.........................................61
Remote start, MyKey ...................................61
Troubleshooting, MyKey .................................64
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
2 Table of Contents
Locks 66
Locking and unlocking ..................................66
SecuriCode™ keyless entry keypad .........................74
Security 77
SecuriLock® passive anti-theft system.......................77
Anti-theft alarm .......................................79
Steering Wheel 81
Adjusting the steering wheel ..............................81
Steering wheel controls .................................81
Pedals 83
Adjustable pedals ......................................83
Wipers and Washers 84
Windshield wipers .....................................84
Rain-sensing wipers ....................................84
Windshield washers ....................................85
Rear-window wiper and washer ............................85
Lighting 86
Lighting control .......................................86
Autolamps ...........................................87
Instrument lighting dimmer...............................87
Daytime running lamps ..................................88
Front fog lamps.......................................88
Directionindicators ....................................88
Interior lamps ........................................89
Windows and Mirrors 91
Power windows .......................................91
Exteriormirrors.......................................92
Interiormirrors .......................................94
Sunvisors...........................................96
Moonroof ............................................97
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Table of Contents 3
Instrument Cluster 98
Gauges .............................................98
Warning lamps and indicators .............................99
Audible warnings and indicators ..........................104
Information Displays 105
Controls............................................105
Information messages ..................................116
Audio System 120
AM/FM/CD with SYNC .................................122
Rear seat controls.....................................124
Auxiliary input jack ...................................127
USBport...........................................129
Satellite radio information ...............................129
Rear seat entertainment system...........................132
Climate Control 151
Manual heating and air conditioning........................151
Dual automatic temperature control........................155
Rear window defroster .................................162
Seats 163
Sitting in the correct position ............................163
Head restraints.......................................164
Manual seats ........................................166
Power seats .........................................168
Memory function .....................................169
Rear seats ..........................................173
Universal Garage Door Opener (If Equipped) 184
Car2U® home automation system .........................184
HomeLink® wireless control system .......................189
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
4 Table of Contents
Auxiliary Power Points 194
Storage Compartments 197
Center console .......................................197
Overhead console .....................................197
Starting and Stopping the Engine 199
Ignition switch .......................................199
Engine block heater ...................................202
Fuel and Refueling 204
Fuel quality .........................................205
Refueling...........................................208
Fuel consumption .....................................209
Transmission 214
Four-Wheel Drive (If Equipped) 221
Four wheel drive .....................................221
Brakes 231
Brakes .............................................231
Hints on driving with anti-lock brakes ......................232
Parking brake........................................232
Traction Control 233
TractionControl™....................................233
Stability Control 234
AdvanceTrac® .......................................235
Parking Aids 236
Sensing system.......................................236
Rear-view camera system ...............................238
Cruise Control 242
Usingcruisecontrol...................................242
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Table of Contents 5
Driving Aids 244
Steering ............................................244
Air suspension .......................................245
Load Carrying 246
Roof racks and load carriers .............................246
Vehicle loading .......................................247
Cargo management system ..............................254
Towing 257
Trailertowing........................................257
Trailer brake controller-integrated .........................263
Wrecker towing ......................................269
Recreational towing ...................................270
Driving Hints 271
Economical driving ....................................271
Floormats..........................................273
Roadside Emergencies 275
Getting roadside assistance ..............................275
Hazard warning flashers ................................276
Fuel pump shut-off switch...............................277
Jump-starting the vehicle ...............................278
Customer Assistance 281
Reporting safety defects (U.S. only) .......................288
Reporting safety defects (Canada only) .....................288
Fuses 289
Changing a fuse ......................................289
Fuse specification chart ................................290
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
6 Table of Contents
Maintenance 298
General information ...................................298
Opening and closing the hood ............................299
Under hood overview ..................................300
Engine oil dipstick ....................................301
Engine oil check......................................301
Engine coolant check ..................................302
Automatic transmission fluid check ........................306
Brake fluid check .....................................307
Fuel filter...........................................307
Washer fluid check ....................................308
Battery ............................................308
Checking the wiper blades ..............................310
Changing the wiper blades ..............................310
Air filter(s) .........................................311
Adjusting the headlamps ................................314
Changing a bulb ......................................315
Removing a headlamp ..................................316
Vehicle Care 321
Cleaning products.....................................321
Cleaning the exterior ..................................321
Waxing.............................................323
Repairing minor paint damage ............................323
Cleaning the engine ...................................323
Cleaning the windows and wiper blades .....................324
Cleaning the interior ...................................325
Cleaning the instrument panel and instrument cluster lens .......325
Cleaning the alloy wheels ...............................328
Vehicle storage .......................................329
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Table of Contents 7
Wheels and Tires 332
Tire care ...........................................334
Tire Pressure Monitoring System (TPMS) ...................350
Changing a road wheel .................................355
Technical specifications.................................363
Wheel lug nut torque ..................................363
Capacities and Specifications 364
Engine specifications ..................................364
Part numbers ........................................369
Vehicle identification number ............................370
Vehicle certification label ...............................371
Transmission code designation............................371
Accessories 372
Accessories .........................................372
Ford Extended Service Plan 374
Scheduled Maintenance 377
Normal scheduled maintenance and log .....................382
SYNC® 394
Pairing your phone for the first time .......................399
911 Assist™ .........................................413
Vehicle Health Report ..................................416
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
8 Table of Contents
Navigation System (If Equipped) 441
Statusbars..........................................444
Loading pictures......................................445
Voice recognition .....................................446
Accessing media features ...............................451
Jukebox features .....................................469
Recording (saving) music to your jukebox ...................469
Accessing the music in your jukebox .......................469
Creating a playlist.....................................471
Where am I?.........................................472
Accessing the help screen ...............................475
Navigation features ....................................476
Appendices 495
Navigation end user license agreement......................502
Index 507
The information contained in this publication was correct at the time of going to print. In the interest of continuous development, we reserve the right to change specifications, design or equipment at any time without notice or obligation. No part of this publication may be reproduced, transmitted, stored in a retrieval system or translated into any language in any form by any means without our written permission. Errors and omissions excepted.
© Ford Motor Company 2013
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)

Introduction 9

ABOUT THIS MANUAL

Thank you for choosing Ford. We recommend that you take some time to get to know your vehicle by reading this manual. The more that you know about it, the greater the safety and pleasure you will get from driving it.
WARNING: Always drive with due care and attention when using and operating the controls and features on your vehicle.
Note: This manual describes product features and options available throughout the range of available models, sometimes even before they are generally available. It may describe options not fitted to your vehicle.
Note: Some of the illustrations in this manual may be used for different models, so may appear different to you on your vehicle. However, the essential information in the illustrations is always correct.
Note: Always use and operate your vehicle in line with all applicable laws and regulations.
Note: Pass on this manual when selling your vehicle. It is an integral part of the vehicle.
This manual may qualify the location of a component as left-hand side or right-hand side. The side is determined when facing forward in the seat.
A
A. Right-hand side B. Left-hand side
B

Protecting the Environment

You must play your part in protecting the environment. Correct vehicle usage and the authorized disposal of waste, cleaning and lubrication materials are significant steps toward this aim.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
10 Introduction

SYMBOL GLOSSARY

WARNING: You risk death or serious injury to yourself and others if you do not follow the instruction highlighted by the
warning symbol.
These are some of the symbols you may see on your vehicle.
Symbol Description Symbol Description Symbol Description
Safety alert See Owner’s
Avoid smoking, flames, or sparks
Brake fluid – non petroleum base
Check fuel cap
Child seat tether anchor
Manual
Battery Battery acid
Brake system Cabin air
Child Safety Door Lock and Unlock
Cruise control
Anti-lock braking system
filter
Child seat lower anchor
Do not open when hot
Engine air filter
Engine oil Explosive gas Fan warning
Fasten safety belt
Fuel pump reset
Engine coolant
Front airbag Front fog
Fuse compartment
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Engine coolant temperature
lamps
Hazard warning flasher
Introduction 11
Symbol Description Symbol Description Symbol Description
Heated rear window
Lighting control
Panic alarm Parking aid
Interior luggage compartment release
Low tire pressure warning
system
Jack
Maintain correct fluid level
Parking brake system
Power steering fluid
Service engine soon
Windshield defrost and demist

DATA RECORDING

Service Data Recording

Service data recorders in your vehicle are capable of collecting and storing diagnostic information about your vehicle. This potentially includes information about the performance or status of various systems and modules in the vehicle, such as engine, throttle, steering or brake systems. In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access or share among them vehicle diagnostic information received through a direct connection to your vehicle when diagnosing or servicing your vehicle. Additionally, when your vehicle is in for service or repair, Ford Motor Company, Ford of Canada, and service and repair facilities may access or share among them data for vehicle improvement purposes. For U.S. only (if equipped), if you choose to use the SYNC® Vehicle Health Report, you consent that certain diagnostic information may also be accessed electronically by Ford Motor Company and Ford authorized service facilities, and that the diagnostic information may be used for any purpose. See the SYNC® chapter for more information.
Power windows front and rear
Side airbag Stability
Windshield washer and wiper
Power window lockout
control
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
12 Introduction

Event Data Recording

This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an airbag deployment or hitting a road obstacle; this data will assist in understanding how a vehicle’s systems performed. The EDR is designed to record data related to vehicle dynamics and safety systems for a short period of time, typically 30 seconds or less. The EDR in this vehicle is designed to record such data as:
How various systems in your vehicle were operating;
Whether or not the driver and passenger safety belts were
buckled/fastened;
How far (if at all) the driver was depressing the accelerator and/or the brake pedal;
How fast the vehicle was travelling;
Where the driver was positioning the steering wheel.
This data can help provide a better understanding of the circumstances in which crashes and injuries occur.
Note: EDR data is recorded by your vehicle only if a non-trivial crash situation occurs; no data is recorded by the EDR under normal driving conditions and no personal data or information (e.g., name, gender, age, and crash location) is recorded (see limitations regarding 911 Assist and Traffic, Directions and Information privacy below). However, parties, such as law enforcement, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as law enforcement, that have such special equipment, can read the information if they have access to the vehicle or the EDR. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority. Other parties may seek to access the information independently of Ford Motor Company and Ford of Canada.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Introduction 13
Note: Including to the extent that any law pertaining to Event Data Recorders applies to SYNC® or its features, please note the following: Once 911 Assist (if equipped) is enabled (set ON), 911 Assist may, through any paired and connected cell phone, disclose to emergency services that the vehicle has been in a crash involving the deployment of an airbag or, in certain vehicles, the activation of the fuel pump shut-off. Certain versions or updates to 911 Assist may also be capable of being used to electronically or verbally provide to 911 operators the vehicle location (such as latitude and longitude), and/or other details about the vehicle or crash or personal information about the occupants to assist 911 operators to provide the most appropriate emergency services. If you do not want to disclose this information, do not activate the 911 Assist feature. See your SYNC® chapter for more information.
Additionally, when you connect to Traffic, Directions and Information (if equipped, U.S. only), the service uses GPS technology and advanced vehicle sensors to collect the vehicle’s current location, travel direction, and speed (“vehicle travel information”), only to help provide you with the directions, traffic reports, or business searches that you request. If you do not want Ford or its vendors to receive this information, do not activate the service. Ford Motor Company and the vendors it uses to provide you with this information do not store your vehicle travel information. For more information, see Traffic, Directions and Information, Terms and Conditions. See your SYNC® chapter for more information.

CALIFORNIA PROPOSITION 65

WARNING: Some constituents of engine exhaust, certain vehicle
components, certain fluids contained in vehicles and certain products of component wear contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

PERCHLORATE MATERIAL

Note: Certain components in your vehicle, such as airbag modules, safety belt pretensioners, and remote control batteries, may contain perchlorate material. Special handling may apply for service or vehicle end of life disposal. See www.dtsc.ca.gov/hazardouswaste/perchlorate for more information.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
14 Introduction

FORD CREDIT (U.S. ONLY)

Ford Credit offers a full range of financing and lease plans to help you acquire your vehicle. If you have financed or leased your vehicle through Ford Credit, thank you for your business.
For your convenience, we offer a number of ways to contact us, as well as help manage your account.
Phone: 1-800-727-7000 For more information regarding Ford Credit, as well as access to
Account Manager, please go to www.fordcredit.com.

REPLACEMENT PARTS RECOMMENDATION

Your vehicle has been built to the highest standards using quality parts. We recommend that you demand the use of genuine Ford and Motorcraft parts whenever your vehicle requires scheduled maintenance or repair. You can clearly identify genuine Ford and Motorcraft parts by looking for the Ford, FoMoCo or Motorcraft branding on the parts or their packaging.

Scheduled Maintenance and Mechanical Repairs

One of the best ways for you to make sure that your vehicle provides years of service is to have it maintained in line with our recommendations using parts that conform to the specifications detailed in this owner’s manual. Genuine Ford and Motorcraft parts meet or exceed these specifications.
Collision Repairs
We hope that you never experience a collision, but accidents do happen. Genuine Ford replacement collision parts meet our stringent requirements for fit, finish, structural integrity, corrosion protection and dent resistance. During vehicle development, we validate that these parts deliver the intended level of protection as a whole system. A great way to know for sure you are getting this level of protection is to use genuine Ford replacement collision parts.
Warranty on Replacement Parts
Genuine Ford and Motorcraft replacement parts are the only replacement parts that benefit from a Ford Warranty. Damage caused to your vehicle as a result of the failure of non-Ford parts may not be covered by the Ford Warranty. For additional information, see the terms and conditions of the Ford Warranty.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Introduction 15

SPECIAL NOTICES

New Vehicle Limited Warranty

For a detailed description of what is covered and what is not covered by your vehicle’s New Vehicle Limited Warranty, see the warranty information that is provided to you along with your owner’s manual.

Special Instructions

For your added safety, your vehicle is fitted with sophisticated electronic controls.
WARNING: Please read the Supplementary Restraints System
chapter. Failure to follow the specific warnings and instructions could result in personal injury.
WARNING: Front seat mounted rear-facing child or infant seats
should NEVER be placed in front of an active passenger airbag.

Using your vehicle with a snowplow

Do not use this vehicle for snowplowing.
Your vehicle is not equipped with a snowplowing package.

Using your vehicle as an ambulance

Do not use this vehicle as an ambulance.
Your vehicle is not equipped with the Ford Ambulance Preparation Package.

MOBILE COMMUNICATIONS EQUIPMENT

Using mobile communications equipment is becoming increasingly important in the conduct of business and personal affairs. However, you must not compromise your own or others’ safety when using such equipment. Mobile communications can enhance personal safety and security when appropriately used, particularly in emergency situations. Safety must be paramount when using mobile communications equipment to avoid negating these benefits.
Mobile communication equipment includes, but is not limited to, cellular phones, pagers, portable email devices, text messaging devices and portable two-way radios.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
16 Introduction
WARNING: Driving while distracted can result in loss of vehicle
control, crash and injury. We strongly recommend that you use extreme caution when using any device that may take your focus off the road. Your primary responsibility is the safe operation of your vehicle. We recommend against the use of any handheld device while driving and encourage the use of voice-operated systems when possible. Make sure you are aware of all applicable local laws that may affect the use of electronic devices while driving.

EXPORT UNIQUE (NON–UNITED STATES/CANADA) VEHICLE SPECIFIC INFORMATION

For your particular global region, your vehicle may be equipped with features and options that are different from the features and options that are described in this owner’s manual. A market unique supplement may be supplied that complements this book. By referring to the market unique supplement, if provided, you can properly identify those features, recommendations and specifications that are unique to your vehicle. This owner’s manual is written primarily for the U.S. and Canadian Markets. Features or equipment listed as standard may be different on units built for Export. See this owner’s manual for all other required
information and warnings.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)

Child Safety 17

GENERAL INFORMATION

See the following sections for directions on how to properly use safety restraints for children.
WARNING: Always make sure your child is secured properly in a
device that is appropriate for their height, age and weight. Child safety restraints must be bought separately from your vehicle. Failure to follow these instructions and guidelines may result in an increased risk of serious injury or death to your child.
WARNING: All children are shaped differently. The
recommendations for safety restraints are based on probable child height, age and weight thresholds from NHTSA and other safety organizations, or are the minimum requirements of law. Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) and consulting your pediatrician to make sure your child seat is appropriate for your child, and is compatible with and properly installed in your vehicle. To locate a child seat fitting station and CPST, contact the NHTSA toll free at 1-888-327-4236 or on the internet at http://www.nhtsa.dot.gov. In Canada, check with your local St. John Ambulance office for referral to a CPST or for further information, contact your provincial ministry of transportation, or locate your local St. John Ambulance office by searching for St. John Ambulance on the internet, or Transport Canada at 1–800–333–0371 (http://www.tc.gc.ca). Failure to properly restrain children in safety seats made especially for their height, age, and weight may result in an increased risk of serious injury or death to your child.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
18 Child Safety
Recommendations for Safety Restraints for Children
Child size, height, weight, or age
Infants or toddlers
Small children
Larger children
You are required by law to properly use safety seats for infants and toddlers in the U.S. and Canada.
Many states and provinces require that small children use approved booster seats until they reach age eight, a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms). Check your local and state or provincial laws for specific requirements about the safety of children in your vehicle.
When possible, always properly restrain children twelve (12) years of age and under in a rear seating position of your vehicle. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in a front seating position.
Children weighing 40 lb (18 kg) or less (generally age four or younger).
Children who have outgrown or no longer properly fit in a child safety seat (generally children who are less than 4 ft. 9 in. (1.45 m) tall, are greater than age four (4) and less than age twelve (12), and between 40 lb (18 kg) and 80 lb (36 kg) and upward to 100 lb (45 kg) if recommended by your child restraint manufacturer).
Children who have outgrown or no longer properly fit in a belt-positioning booster seat (generally children who are at least 4 ft. 9 in. (1.45 m) tall or greater than 80 lb (36 kg) or 100 lb (45 kg) if recommended by child restraint manufacturer).
Recommended restraint type
Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat).
Use a belt-positioning booster seat.
Use a vehicle safety belt having the lap belt snug and low across the hips, shoulder belt centered across the shoulder and chest, and seat back upright.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Child Safety 19

CHILD SEATS

Use a child safety seat (sometimes called an infant carrier, convertible seat, or toddler seat) for infants, toddlers or children weighing 40 pounds (18 kilograms) or less (generally age four or younger).

CHILD SEAT POSITIONING

WARNING: Airbags can kill or injure a child in a child seat.
NEVER place a rear-facing child seat in front of an active airbag. If you must use a forward-facing child seat in the front seat, move the vehicle seat upon which the child seat is installed all the way back. When possible, all children age 12 and under should be properly restrained in a rear seating position. If all children cannot be seated and restrained properly in a rear seating position, properly restrain the largest child in the front seat.
WARNING: Always carefully follow the instructions and
warnings provided by the manufacturer of any child restraint to determine if the restraint device is appropriate for your child’s size, height, weight, or age. Follow the child restraint manufacturer’s instructions and warnings provided for installation and use in conjunction with the instructions and warnings provided by your vehicle manufacturer. A safety seat that is improperly installed or utilized, is inappropriate for your child’s height, age, or weight or does not properly fit the child may increase the risk of serious injury or death.
WARNING: Never let a passenger hold a child on his or her lap
while your vehicle is moving. The passenger cannot protect the child from injury in a crash, which may result in serious injury or death.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
20 Child Safety
WARNING: Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or
death in a crash.
WARNING: Always restrain an unoccupied child seat or booster seat. These objects may become projectiles in a crash or sudden
stop, which may increase the risk of serious injury.
WARNING: Never place, or allow a child to place, the shoulder
belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash.
WARNING: Do not leave children or pets unattended in your
vehicle.
Use any attachment method as indicated
below by X.
Restraint Type
Rear-facing child seat
Forward­facing child seat
Forward­facing child seat
Child
Weight
Up to 48 lb (21 kg)
Up to 48 lb (21 kg)
Over 48 lb (21 kg)
LATCH (lower anchors and top tether anchor)
LATCH (lower anchors only)
XX
XXX
Safety belt and top tether anchor
Safety belt and LATCH (lower anchors and top tether anchor)
XX
Safety belt only
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Child Safety 21
Note: The child seat must rest tightly against the vehicle seat upon which it is installed. It may be necessary to lift or remove the head restraint. See the Seats chapter for information on head restraints.

BOOSTER SEATS

WARNING: Never place, or allow a child to place, the shoulder
belt under a child’s arm or behind the back because it reduces the protection for the upper part of the body and may increase the risk of injury or death in a crash.
Use a belt-positioning booster seat for children who have outgrown or no longer properly fit in a child safety seat (generally children who are less than 4 feet 9 inches (1.45 meters) tall, are greater than age four (4) and less than age twelve (12), and between 40 pounds (18 kilograms) and 80 pounds (36 kilograms) and upward to 100 pounds (45 kilograms) if recommended by your child restraint manufacturer). Many state and provincial laws require that children use approved booster seats until they reach age eight (8), a height of 4 feet 9 inches (1.45 meters) tall, or 80 pounds (36 kilograms).
Booster seats should be used until you can answer YES to ALL of these questions when the child is seated without a booster seat.
Can the child sit all the way back against their vehicle seat with knees bent comfortably at the edge of the seat cushion?
Can the child sit without slouching?
Does the lap belt rest low across the hips?
Is the shoulder belt centered on the shoulder and chest?
Can the child stay seated like this for the whole trip?
Always use booster seats in conjunction with your vehicle lap and shoulder belt.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
22 Child Safety

Types of Booster Seats

Backless booster seats
If your backless booster seat has a removable shield, remove the shield. If a vehicle seating position has a low seat back or no head restraint, a backless booster seat may place your child’s head (as measured at the tops of the ears) above the top of the seat. In this case, move the backless booster to another seating position with a higher seat back or head restraint and lap and shoulder belts, or consider using a high back booster seat.
High back booster seats
If, with a backless booster seat, you cannot find a seating position that adequately supports your child’s head, a high back booster seat would be a better choice.
Children and booster seats vary in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder. The following drawings compare the ideal fit (center) to a shoulder belt uncomfortably close to the neck and a shoulder belt that could slip off the shoulder. The drawings also show how the lap belt should be low and snug across the child’s hips.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Child Safety 23
If the booster seat slides on the vehicle seat upon which it is being used, placing a rubberized mesh sold as shelf or carpet liner under the booster seat may improve this condition. Do not introduce any item thicker than this under the booster seat. Check with the booster seat manufacturer’s instructions.

INSTALLING CHILD SEATS

Using Lap and Shoulder Belts

WARNING: Airbags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active airbag.
If you must use a forward-facing child seat in the front seat, move the seat all the way back.
WARNING: Children 12 and under should be properly restrained in the rear seat whenever possible.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
24 Child Safety
WARNING: Depending on where you secure a child restraint,
and depending on the child restraint design, you may block access to certain safety belt buckle assemblies or LATCH lower anchors, rendering those features potentially unusable. To avoid risk of injury, occupants should only use seating positions where they are able to be properly restrained.
When installing a child safety seat with combination lap/shoulder belts:
Use the correct safety belt buckle for that seating position.
Insert the belt tongue into the proper buckle until you hear a snap
and feel it latch. Make sure the tongue is securely fastened in the buckle.
Keep the buckle release button pointing up and away from the safety seat, with the tongue between the child seat and the release button, to prevent accidental unbuckling.
Place your vehicle seat back in the upright position.
Put the safety belt in the automatic locking mode. See Step 5. This
vehicle does not require the use of a locking clip.
Perform the following steps when installing the child seat with combination lap/shoulder belts:
Note: Although the child seat illustrated is a forward facing child seat, the steps are the same for installing a rear facing child seat.
1. Position the child safety seat in a seat with a combination lap and shoulder belt.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Child Safety 25
2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together.
3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted.
4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
26 Child Safety
5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out.
Note: The automatic locking mode is available on the front passenger and rear seats. This vehicle does not require the use of a locking clip.
6. Allow the belt to retract to remove slack. The belt will click as it
retracts to indicate it is in the automatic locking mode.
7. Try to pull the belt out of the retractor to make sure the retractor is
in the automatic locking mode (you should not be able to pull more belt out). If the retractor is not locked, unbuckle the belt and repeat Steps 5 and 6.
8. Remove remaining slack from the belt. Force the seat down with extra weight, e.g., by pressing down or kneeling on the child restraint while pulling up on the shoulder belt in order to force slack from the belt.
This is necessary to remove the remaining slack that will exist once the extra weight of the child is added to the child restraint. It also helps to achieve the proper snugness of the child seat to your vehicle. Sometimes, a slight lean toward the buckle will additionally help to remove remaining slack from the belt.
9. Attach the tether strap (if the child seat is equipped). See Using
Tether Straps in this chapter.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Child Safety 27
10. Before placing the child in the seat, forcibly move the seat forward and back to make sure the seat is securely held in place.
To check this, grab the seat at the belt path and attempt to move it side to side and forward and back. There should be no more than 1 inch (2.5 centimeters) of movement for proper installation.
Ford recommends checking with a NHTSA Certified Child Passenger Safety Technician (CPST) to make certain the child restraint is properly installed. In Canada, check with your local St. John Ambulance office for referral to a CPST.

Using Lower Anchors and Tethers for CHildren (LATCH)

WARNING: Never attach two child safety seats to the same
anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death.
The LATCH system is composed of three vehicle anchor points: two lower anchors located where the vehicle seat back and seat cushion meet (called the seat bight) and one top tether anchor located behind that seating position.
LATCH compatible child safety seats have two rigid or webbing mounted attachments that connect to the two lower anchors at the LATCH equipped seating positions in your vehicle. This type of attachment method eliminates the need to use safety belts to attach the child seat, however the safety belt can still be used to attach the child seat. For forward-facing child seats, the top tether strap must also be attached to the proper top tether anchor, if a top tether strap has been provided with your child seat. Ford Motor Company recommends the use of a child safety seat having a top tether strap. See Using Tether Straps in this chapter.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
28 Child Safety
Your vehicle has LATCH lower anchors for child seat installation at the seating positions marked with the child seat symbol.
The LATCH anchors are located at the rear section of the rear seat between the cushion and seat back, below the locator symbols on the seat back. Follow the child seat manufacturer’s instructions to properly install a child seat with LATCH attachments.
The locator symbols are on round plastic buttons for the center seat and on rectangular tags for the outboard seats.
Follow the instructions on attaching child safety seats with tether straps. See Using Tether Straps in this chapter.
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Child Safety 29
Attach LATCH lower attachments of the child seat only to the anchors shown.
Each time you use the safety seat, check that the seat is properly attached to the lower anchors and tether anchor, if applicable. Tug the child seat from side to side and forward and back where it is secured to the vehicle. The seat should move less than one inch when you do this for a proper installation.
If the safety seat is not anchored properly, the risk of a child being injured in a crash greatly increases.

Combining Safety Belt and LATCH Lower Anchors for Attaching Child Safety Seats

When used in combination, either the safety belt or the LATCH lower anchors may be attached first, provided a proper installation is achieved. Attach the tether strap afterward, if included with the child seat.

Using Tether Straps

Many forward-facing child safety seats include a tether strap which extends from the back of the child safety seat and hooks to an anchoring point called the top tether anchor.
Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap, or to obtain a longer tether strap if the tether strap on your safety seat does not reach the appropriate top tether anchor in the vehicle.
Some of the rear seats of your vehicle are equipped with built-in tether strap anchors located behind the seats as described below.
In the third row center seating position, the tether anchor is a loop at the bottom of the seat back.
The tether strap anchors in your vehicle are in the following positions (shown from top view).
2013 Expedition (exd) Owners Guide gf, 3rd Printing, April 2013 USA (fus)
Loading...
+ 485 hidden pages
