Table of contents
Introduction 2
SVT Contour specific features 4
Engine/Transmission 7
Drivetrain 9
Chassis 10
Performance 11
Options, color and trim 12
Maintenance 13
Jacking points 14
Towing 15
A word about warranty coverage 16
All rights reserved. Reproduction by any means, electronic or mechanical
including photocopying, recording or by any information storage and retrieval
system or translation in whole or part is not permitted without written
authorization from Ford Motor Company.
Copyrightr1999 Ford Motor Company
1
Introduction
INTRODUCTION
Welcome to the Ford Special Vehicle Team family and thank you for
purchasing the Ford SVT Contour. We trust that our tremendous
dedication to the automotive enthusiast’s total ownership experience will
provide you with many miles of exhilarating, safe, and comfortable
driving in your new SVT Contour.
SVT strives for balance between
powertrain and chassis, cornering
prowess and long-distance comfort,
always working to build cars in
which no one system overwhelms or
overshadows any other. In the SVT
Contour, that philosophy is carried
forward through a sophisticated
powertrain as well as significant
interior, exterior, suspension, and
braking system components.
This supplement complements your Contour Owner’s Guide and provides
information specific to SVT and the SVT Contour. By referring to the
pages listed in this supplement, you can identify those features,
recommendations, and specifications unique to your new SVT Contour.
If you have any questions, please call us at the Ford Special Vehicle
Team hotline from 8:30 a.m. to 6:00 p.m. EST at 1–800–FORD-SVT
(1–800–367–3788).
SVT HISTORY
The Ford Special Vehicle Team (SVT) was established in 1991. SVT was
commissioned to create factory-produced driver’s cars and trucks;
vehicles that possess a balance between engine and chassis, roadholding
and a supple ride, refinement and performance capability. These qualities
are the core of the SVT product development philosophy.
To support SVT, Ford Motor Company created a dedicated product
development group, Ford Special Vehicle Engineering (SVE). The
nucleus of the Ford SVT and SVE is a small, cross-functional group of
engineers, product planners, and marketing people who meet on a
weekly basis to ensure SVT vehicles and their mission remain focused. In
addition to Ford SVE, SVT draws heavily on the talents and knowledge
of other driving enthusiasts at Ford who work in the key disciplines of
design, product development, manufacturing, and marketing. The heart
2
Introduction
of the SVT philosophy is a deep commitment to skillful and enthusiastic
driving. The ultimate goal of everyone at SVT and SVE is to create
vehicles that speak to the needs and desires of the knowledgeable
driving enthusiast.
Every SVT vehicle produced has been designed and developed with four
key virtues in mind: Performance, Substance, Exclusivity, and Value.
These hallmarks have driven the SVT Mustang Cobra since 1993, the
original SVT Lightning from 1993 to 1995, the SVT Contour introduced
in early 1997 as a 1998 model, and the 1999 SVT F-150 Lightning.
SVT OWNERSHIP BENEFITS
• Dealer body of approximately 600 specially trained and certified SVT
dealers who are dedicated to a culture within their dealerships that is
friendly to the knowledgeable driving enthusiast.
• On-going commitment from SVT to provide its dealers with constant
support from the SVT Information Center at 1–800–FORD-SVT,
in-depth technical seminars, and training in SVT Owner/Enthusiast
care techniques to assure outstanding quality throughout the entire
SVT ownership experience.
• A Certificate of Authenticity is provided to the owner or lessee of
every SVT vehicle. It includes the Vehicle Identification Number,
production sequence number out of the total number of vehicles built,
and the date of manufacture. These certificates are printed at the end
of the vehicle’s model-year production run.
• SVT-specific line of apparel and accessories available through your
SVT dealer. Contact the SVT team leader at the dealership for details
and ordering information or call 1–800–FORD-SVT. To order direct,
call 1–888–490–6837.
• The SVT Enthusiast, written and published by SVT Headquarters.
The SVT Enthusiast contains information of interest to SVT owners
and prospective buyers, with the latest technical information available
from SVT, interviews with members of SVT and SVE, and suggested
drive routes across the United States and Canada designed to
maximize your enjoyment of your SVT vehicle.
• SVT, in conjunction with The Bob Bondurant School of High
Performance Driving in Phoenix, AZ, gives the owner the opportunity
to attend the school at a 20% discount. The school can be contacted
directly at 1–800–842–7223.
3
SVT Contour specific features
SVT CONTOUR SPECIFIC FEATURES
• 2.5L DOHC 24V V-6 Engine — 200 horsepower/167 lb/ft torque
• 10.94” vented front brake rotors
• Bosch 4–channel, 4–sensor anti-lock braking system
• Heavy duty radiator core
• Extrude Honey polished upper intake manifold and cylinder heads
• Enhanced suspension tuning
• Unique front fascia with ducting to improve cooling system
performance
• Round fog lamps
• Unique upper and lower mesh grilles
• Unique rear valance panel, rocker sill extensions, mesh grille, stainless
steel exhaust tips
• Unique wheels and tires
4
SVT Contour specific features
• SVT-signature white-faced gauges
80
4
x 1000
5
6
7
8
40
30
50
20
10
3
2
M
R
A
O
N
1
L
0
TRACTION
CONTROL
O/D
OFF
• Standard power 10–way driver’s seat with unique perforated leather
• Accentuated seat back and bottom lateral bolstering
• Additional rear seat bottom bolstering
• Standard leather: seating surfaces, steering wheel, shifter knob, shifter
boot, parking brake boot
• Unique texture door trim inserts
• SVT logo floormats, color-keyed
60
60
40
80
20
70
120
100
000123
0 0 0 0
MPH
90
10 0
140
160
180
240
260
CHECK
ENGINE
200
220
160
110
120
130
140
150
BRAKE
EF
PREMIUM FUEL ONLY
5
SVT Contour specific features
ADJUSTING THE POWER DRIVER’S SEAT
Move the relevant control in the
respective direction to adjust the
seat, seatback and lumbar as
follows:
Seat
1. Forward and backward
2. Height of the entire seat
3. Height of the front of the seat
4. Height of the rear of the seat
Seatback
5. Seatback inclination
Lumbar support
6. Lumbar support
1
2
3
4 6
5
6
Engine/Transmission
ENGINE/TRANSMISSION
• Horsepower — 200 hp @ 6 600 rpm
• Torque — 167 lb/ft at 5 500 rpm
• Redline — 6 750 rpm (fuel shut-off 7 000 rpm)
• Compression ratio — 10.0:1
• Throttle body — 60 mm
• Mass air sensor — 70 mm
• Air filter assembly — large capacity, conical
• Upper intake manifold and cylinder heads — Extrude Honey polished
• Lower intake manifold — 32 mm
• Pistons — Unique design, aluminum-alloy
• Camshafts — special design intake and exhaust cams
• Flywheel weight — 18 lbs
• Fuel injectors — 19 lbs/hour
• Oil cooler — block mounted, water-to-oil cooler
• Engine cooling — heavy duty radiator core
• Exhaust — Quasi-dual exhaust
• Transaxle — MTX-75 5–speed with high performance clutch
7
Engine/Transmission
Item Description
Configuration Transversely mounted, 60-degree
V6, cast aluminum block and
heads, iron cylinder liners, fully
counterweighted forged
crankshaft, crankshaft windage
tray, lightened flywheel, structural
aluminum-alloy oil pan
Bore x Stroke 82.4 x 79.0 mm (3.24 x 3.11 in)
Displacement 2 544 cc/155 cid
Compression ratio 10.0:1
Horsepower (SAE net) 149 kW (200 hp) @ 6 600 rpm
Torque 226 Nm (167 lb/ft @ 5 500 rpm)
Redline 6 750 rpm (fuel shut-off at
7 000 rpm)
Specific output 78.6 hp per liter
Valvetrain Dual overhead chain-driven cams,
roller finger followers with
hydraulic lash adjustment,
ovate-wire valve springs, four
valves per cylinder. The Extrude
Honey process is used on the
primary and secondary ports
Fuel system Sequential electronic fuel injection,
19 lb/hr injectors, 379 kPa (55 psi)
Mass air sensor 70 mm (2.76 in) diameter
Throttle body 60 mm (2.36 in) diameter bore
Port throttles Electronically actuated 32 mm
(1.26 in) diameter bore-open at
3 250 rpm
Exhaust manifolds Steel tube clamshell design
Exhaust system 57 mm (2.25 in) diameter with
63.5 mm (2.50 in) polished
stainless steel tips
8
Drivetrain
DRIVETRAIN
The SVT Contour uses the MTX-75 5–speed manual transaxle with a
short-throw shifter. This includes a shift-link design that offers smooth
and accurate shifting. The clutch is a high performance special design.
All transaxle gears and shafts run in needle bearings to reduce drivetrain
friction.
Item Description
Transaxle 5-speed manual (MTX-75)
Final drive
ratio
Gear ratios Gear Ratio Speed
4.06:1
1st 3.42 56 km/h
(35 mph)
2nd 2.14 90 km/h
(56 mph)
3rd 1.45 132 km/h
(82 mph)
4th 1.03 188 km/h
(117 mph)
5th 0.77 230 km/h
(143 mph)
Reverse 3.42 -
9
Chassis
SUSPENSION
• Front suspension: modified MacPherson strut design, lower A-arms,
coil springs, tube shock dampers, special 19 mm front stabilizer bar
• Rear suspension: independent, one lower trailing arm, two transverse
links, strut, coil spring, 18 mm rear stabilizer bar
• Passive rear-wheel steer: small amount designed into rear suspension
STEERING
Type Power assist, rack and pinion
Gear ratio 14.5:1
Turns, lock to lock 2.7
Turning diameter 12.2 m (40 ft)
BRAKES
• The braking system on the SVT Contour is upgraded from the Contour
SE, providing improved performance and fade resistance to meet the
demands of the driving enthusiast.
• Swept area is 18% larger on front rotors.
Front 27.79 cm (10.94 in) vented discs, single-piston calipers
Rear 25.10 cm (9.88 in) vented discs, single-piston calipers
ABS Bosch 4-channel, 4-sensor system
WHEELS AND TIRES
The SVT Contour uses a unique
5–spoke wheel that is now the
SVT-signature design for our family
of vehicles.
Tires 215/50ZR16 BFG
G-Force T/A KDW
Wheels
10
SVT-Signature style, 16 in x 6.5 in cast aluminum 5-spoke wheels
Performance
PERFORMANCE
Item Description
0-100 km/h (0-60 mph) 7.9 seconds
400 meters (quarter mile) 15.7 seconds @ 141.6 km/h
(88 mph)
Top speed 230 km/h (143 mph)
Braking, 100-0 km/h (60-0 mph) 40.8 meters (134 ft.)
Slalom, 30.5 meter (100 ft.)
gates
Skid pad, 61 meter (200 ft.) 0.92 g
105.9 km/h (65.8 mph)
11
Options, color and trim
OPTIONS, COLOR AND TRIM
• Power moon roof
• CD player
• Smoker’s package
• Engine block heater
Exterior:
• Black Clearcoat
• Silver Frost Clearcoat Metallic
• Toreador Red Clearcoat Metallic
• Amazon Green Clearcoat Metallic
Interior:
• Midnight Blue Leather
• Medium Prairie Tan Leather
12
Maintenance
FLUID RECOMMENDATIONS
Fluid capacities:
Please refer to your Contour Owner’s Guide.
Fuel recommendation:
91 Octane or higher
91
(R+M)/2 METHOD
Regular fuel can be used in the SVT Contour without damaging
engine components. The knock sensor will adjust the engine
calibration to accomodate regular unleaded fuel. This may result in
a degradation of engine performance.
SYNTHETIC FLUIDS
There are no synthetic fluids or break-in fluids in your SVT Contour
when it leaves the factory. Note that SVT does not make
recommendations about the use of synthetic oils in your vehicle. Should
you decide to use synthetic engine oil, we recommend you allow 4 000 to
6 000 miles (6 500 km to 9 600 km) in order to assure complete break-in
before switching to synthetic oil.
MAINTENANCE AND BREAK-IN
For complete maintenance and break-in procedure information, please
refer to your Contour Owner’s Guide.
13
Jacking points
JACKING POINTS (FOR USING SPARE TIRE)
The SVT Contour has two jacking points on each side of the car to be
utilized if it is necessary to change to your spare tire.
To access the jacking points:
1. Squeeze inside and outside of the highlighted covers.
2. Pull the cover down to remove.
14
Towing
WRECKER TOWING
If you need to have your vehicle towed, contact a professional towing
service or, if you are a member, your roadside assistance center.
It is recommended that your vehicle be towed with a wheel lift or flatbed
equipment. Do not tow with a slingbelt. Ford Motor Company has not
approved a slingbelt towing procedure.
If the vehicle is towed by other means or incorrectly, vehicle
damage may occur.
When towing your SVT Contour with a wheel lift, follow the procedure
described in your Owner’s Guide.
When towing your SVT Contour with flatbed equipment, you must place
a block under the tongue of the inclined flatbed to decrease the angle of
ascent and descent.
Failure to follow these instructions may result in damage to the vehicle’s
front fascia and tailpipes.
15
A word about warranty coverage
A WORD ABOUT WARRANTY COVERAGE
The SVT Contour carries the same warranty coverage as other Ford
Contour models. This information is covered in its entirety in the Ford
Motor Company Warranty Guide.
The SVT Contour or any SVT can be serviced under warranty at any
Ford-Lincoln-Mercury dealer nationwide.
SVT does not recommend modifying or racing our vehicles, as they are
designed and built to be driven as delivered from the factory. The Ford
Motor Company Warranty Guide discusses the installation of aftermarket
parts and their effect on warranty coverage as follows:
Repairs are not reimbursable under warranty when:
• “The repairs are required because of abuse, misuse, racing, fire,
negligence, accident, modification or a natural disaster.”
• “The repairs are required due to installation of a non-Ford part.”
16
Loading...
