Page 1
Horizon™ Ice Machine Models with RIDE™ Technology
HCC1000AJS, HCC1400AJS, HCC1000WJS, HCC1400WJS,
HMC1000AJS, HMC1400AJS, HMC1000WJS, HMC1400WJS,
HCE1000AJS, HCE1400AJS, HCE1000WJS, HCE1400WJS
HME1000AJS, HME1400AJS, HME1000WJS, HME1400WJS
(See model number con gurator on page 2 for details.)
Order parts online
www.follettice.com
Installation Instructions for Drop-In
self-contained
a
i
n
va
l
y
s
n
n
e
P
O
n
N
o
t
T
s
R
E
a
L
A
E
P
G
N
I
S
E
AS
H
P
Z
Z
O
H
G
I
S
P
D
E
E
T
G
C
E
S
AR
T
T
L
H
O
C
O
R
V
P
N
I
Y
E
E
L
D
D
L
A
I
A
A
S
M
S
U
M
E
W
R
H
O
E
T
L
H
T
R
SF
O
N
S
S
E
R
M
O
U
L
R
C
U
L
R
S
P
M
A
S
P
AM
208264
Stock Module Identification Plate
Module No.
Product
Service No.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
00159939R07
Page 2
Chewblet® Ice Machine Model Number Configurations
HC 1400CSVA
MC Maestro™
Chewblet
(400 Series)
HC Horizon
Chewblet
(1000, 1400,
1650 Series)
HM Horizon
Micro Chewblet
C 208-230/60/1 (icemaking head)
®
Self-contained only.
D 115/60/1 (icemaking head)
Self-contained and remote. If remote
unit, high side is 208-230/60/1.
E 230/50/1 (icemaking head)
Self-contained only.
F 115/60/1 (icemaking head)
Remote only. High side is
208-230/60/3.
400 up to
454 lbs
(206kg)
1000 up to
1036 lbs
(471kg)
1400 up to
1450 lbs
(658kg)
1650 up to
1580 lbs
(717kg)
CondenserSeriesVoltageIcemaker
A Air-cooled, self-contained
W Water-cooled, self-contained
R Air-cooled, remote condensing unit
N Air-cooled, no condensing unit for
connection to parallel rack system
V Vision™
H Harmony™
B Ice storage bin
J Drop-in
M Ice Manager
diverter valve
system
ConfigurationApplication
S RIDE™
(RIDE remote
ice delivery
equipment)
T Top-mount
2
self-contained DROP-IN • RIDE Technology
Page 3
Read and complete the following 8 installation steps
Unpack
1
Dispenser preparation
3
Ice transport tube
5
Site preparation
2
Louvered docking assembly
4
External connection
6
Internal connection
7
Front cover
8
DROP-IN • RIDE Technology self-contained
3
Page 4
Carefully unpack and inspect the contents of your Follett ice machine.
1/2"
1/2"
➊➋
➌➍
➎➏
Unpack
1
1. 1
Unpack ice machine
4
self-contained DROP-IN • RIDE Technology
Page 5
Site preparation
Prepare the installation site.
Provide drainage, water supply and electrical power to within 6 feet (2m) of ice
machine in accordance with local and national codes. Outdoor installation is
not recommended and will void warranty.
2
2.1
2.1
Installation site requirements
H_E1000A/W
requires 15 amp circuit
1.50 mm2 wire
H_E1400A/W
requires 20 amp circuit
4.00 mm2 wire
‡
H_C1000A/W
‡
NEMA
6-15
➊
➋
➌
ia
n
a
lv
sy
n
n
e
O
P
n
N
o
t
T
E
R
as
L
A
E
G
P
IN
E
S
S
A
H
P
Z
Z
O
H
D
E
G
T
I
S
C
P
E
T
E
G
RO
R
S
P
A
T
L
H
Y
L
C
L
VO
N
I
E
A
E
D
M
I
D
A
A
R
S
S
M
U
E
W
E
H
H
O
T
T
L
R
F
O
S
S
N
S
E
R
M
O
U
L
R
C
U
L
R
S
P
M
A
S
P
M
A
208264
Stock Module Identification Plate
Module No.
Product
Service No.
Electrical
NEMA
6-20
H_C1400A/W
➊
➍
1/4"
1'
• H_C1000(A/W)JS 208-230/60/1-15 amps • H_C1400(A/W)JS 208-230/60/1-20 amps
• H_E1000(A/W)JS 230/50/1-15 amps
(H_E1000A/W Requires 15 amp circuit 1.50 mm2 wire) (H_E1400A/W Requires 20 amp circuit 4.00 mm2 wire)
‡ Plug must be provided by end user & must conform to standard EN 60 335-2-24 of the end destination.
Potable water supply
➋
‡
• H_E1400(A/W)JS 230/50/1-20 amps
• 10-70 psi (69-483kpa)
• 45 to 90 F (7 to 32 C)
• Follett recommends the use of an in-line water ltration system (item# 00130286)
Condenser water supply for water-cooled systems
➌
• 10 psi min.; 150 psi max. (69kpa min.; 1034kpa max.)
• 45 to 90 F (7 to 32 C)
• 1.5 gallons per minute (5.68 liters per minute)
Drain
➍
• The drain line from the ice machine must have at least 1/4" per foot pitch (6,4mm/0,3m)
DROP-IN • RIDE Technology self-contained
‡
5
Page 6
Prepare the dispenser.
Dispenser preparation
3
2.1
3.1
Dispenser preparation
➌
➋
➍
➊
➎
160 F (71 C)
➐
Hot Water
➒
12"
(304,8mm)
min.
4"
(101,6mm)
➏
➐
➓
➑
• Determine best route for ice transport tube run. Note: 12" (304,8mm) clearance is required.
• Drill 1 3/4" (44,5mm) hole through either side of dispenser
• Install gasket ➋ onto bulkhead tting
• Attach bulkhead tting with at up ➍ and tighten bulkhead nut
• Position and secure nut locking plate ➏ with supplied screws
• Verify installation of O-ring on stainless steel ice transport tube coupling
• Insert stainless steel ice transport tube coupling
cap
➑
• Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers ➒
before making connection to ease assembly
• Attach ice transport tube to coupling with supplied hose clamp
➌
into bulkhead tting and secure with coupling
➐
➊
➎
➓
➐
6
self-contained DROP-IN • RIDE Technology
Page 7
DROP-IN • RIDE Technology self-contained
7
Page 8
Louvered docking assembly
Install the louvered docking assembly.
WARNING
• Docking station must be secured in accordance with these instructions to ensure ice machine
stability.
• Ventilation openings in the louvered docking station should be clear of obstruction
Wall bracket accessory Machine stand accessory
4
• Mount louvered docking assembly to wall
bracket accessory
4.1
DOCKING STATION: Horizon 1000 & 1400 water- and air-cooled models
• Position and screw louvered docking assembly to the bottom of counter inside of access panel/
• The mounting surface for the louvered docking assembly must be solid.
• There must be no lip or edge that would hinder the ice machine from sliding in or out of the
INTAKE AND EXHAUST GRILLE PLACEMENT: Horizon 1000 & 1400 air-cooled models only
• Position the intake grille cut out in the access panel/door
• Left edge of cutout should be 1.75" (45mm) from the left side of the ice machine
• Bottom edge of cutout should be 1.875" (48mm) from the bottom of the ice machine
• Position supplied exhaust grille at least 18" (458mm) away from intake grille ➎.
• If not using supplied grille, air circulation requirements below must be met:
Undercounter installation requirements Horizon 1000 & 1400 series
(See detail drawing on page 9)
door 1.75" (45mm) from the front edge of the cross brace
Do not mount directly onto runners or channels.
louvered docking station
(See detail drawing on page 9)
Note: Ice machine must be aligned with cut out and inside of access panel to provide a tight
seal and prevent recirculation of hot exhaust air.
Where possible, install exhaust grille to the rear or side of the base cabinet.
1000 series: 150 sq. in (967 sq cm) intake air, 150 sq. in (967 sq. cm) exhaust air
1400 series: 175 sq. in (1129 sq. cm) intake air, 175 sq. in (1129 sq. cm) exhaust air
➋
• Mount louvered docking assembly to
machine stand accessory
➊
➌
➍
8
self-contained DROP-IN • RIDE Technology
Page 9
Undercounter installation detail – Horizon 1000 & 1400 series
Front View
1.875"
(48mm)
➍
Top View
CROSSBRACE
➊
➌
1.75"
(45mm)
1000 series - 12"x16" cutout (305x407mm)
1400 series - 16"x16" cutout (407x407mm)
bottom of ice machine
side of ice machine
CAUTION
• Keep ventilation openings in the appliance enclosure clear of obstruction.
• To ensure proper ventilation (if not using supplied grille) carefully review air
circulation speci cations on facing page (4.1)
Access panel/
door on counter
1.75" (45mm)
➎
18" min.
(458mm)
3D Counter View
1000 series - 28.6" min. (727mm)
1400 series - 31.6" min. (303mm)
24.5" min.
(623mm)
CROSSBRACE
16"
(407mm)
No Lip
➋
1000 series - 12" (305mm)
1400 series - 16" (407mm)
DROP-IN • RIDE Technology self-contained
9
Page 10
Install the ice transport tube.
Ice transport tube
5
5.1
Ice transport tube installation.
Hot Water
160 F (71 C)
➎
➏
➍
➐
1/4"
➌
➋
➊
1'
a
i
n
a
v
l
y
s
n
n
e
P
O
n
N
o
T
st
E
R
a
L
A
E
G
P
N
I
E
S
AS
H
P
Z
Z
O
H
D
E
G
I
T
S
C
P
E
E
T
G
O
R
R
S
A
P
T
H
Y
L
OL
C
L
V
N
I
E
A
E
D
D
M
I
A
A
S
R
S
M
U
E
E
W
H
H
O
T
T
L
R
F
O
S
S
N
S
E
R
M
O
U
L
R
C
U
L
R
S
P
M
A
S
P
M
A
208264
Stock Module Identification Plate
Module No.
Product
Service No.
Ice transport tube tips
• Insulate entire length of ice transport tube
• Secure ice transport tube ➋ as needed to prevent dips and traps from forming.
For long tube runs see guide on page 16.
• Pitch tube at least 1/4" per foot (6,4mm/.3m)
• Ice transport tube must drain towards ice machine
➊
➌
Ice transport tube to Ice machine
• Be sure tube ends are square
• Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers ➎
before making connection to ease assembly
• Push ice transport tube onto ice machine nipple
• Install hose clamp
➐
10
➍
➏
self-contained DROP-IN • RIDE Technology
Page 11
Connect utilities to louvered docking assembly.
External connections
6
6.1
Air-cooled ice machines only
➋
➊
• Remove access panel if necessary
• Install drain line
The rigid drain line from the ice machine
must have at least 1/4" per foot pitch
(6,4mm/0,3m).
• Install ice machine potable water
supply
• Replace access panel
➋
➊
.
6.2
Water-cooled ice machines only
➌
➋
➍
➊
• Remove access panel if necessary
• Install drain line
The rigid drain line from the ice machine
must have at least 1/4" per foot pitch.
• Connect cooling water supply
return
• Install ice machine potable water
supply
• Replace access panel
➌
➍
➊.
➋
and
DROP-IN • RIDE Technology self-contained
11
Page 12
Connect louvered docking assembly to ice machine.
CAUTION
• Plug must be accessible after nal installation.
• H_E1400A/W 230/50/1) requires a 20 amp circuit (4.00 mm2 wire)
Air-cooled ice machines – follow steps 7.1 through 7.4.
Internal connections
7
7. 1
Ice transport tube
➋
➊
• Slide ice machine into louvered docking
assembly
• Insert ice transport tube all the way into
coupling and tighten nut rmly
➊
➋
7. 2
Potable water and drain lines
➊
• Insert potable water line into valve
• Push drain line over hose barb on
back of evaporator mount
➋
➊
➋
➋
➊
7. 3
• Remove twist tie
• Carefully pass plug thru opening and plug
Power cord
into wall outlet
7. 4
• Position plate into opening and secure
Power cord
with supplied screw
12
self-contained DROP-IN • RIDE Technology
Page 13
➋
➊
Water-cooled ice machines – follow steps 7.5 through 7.10.
7. 5
• Install ice machine cooling water lines to
Cooling lines
Out
In
louvered docking assembly
7. 6
Ice transport tube
➋
• Slide ice machine into louvered docking
assembly
• Insert ice transport tube into coupling and
tighten nut rmly
➊
➋
7. 7
Potable water and drain lines
➊
• Insert potable water line into valve
• Push drain line over hose barb on
back of evaporator mount
➋
➋
➊
➊
➋
7. 8
• Connect cooling water lines to ice
• Water valve is set at the factory. DO NOT
Cooling lines and power
Adjustment will void warranty and may damage equipment.
Do not adjust.
ATTENTION INSTALLER
Valve is preset at factory.
machine
remove seal or adjust water valve
➊
➋
DROP-IN • RIDE Technology self-contained
13
Page 14
7. 9
Power cord
7. 1 0
Power cord
• Remove twist tie
• Carefully pass plug thru opening and plug
into wall outlet
• Position plate into opening and secure
with supplied screw
14
self-contained DROP-IN • RIDE Technology
Page 15
Install front cover to ice machine.
Front cover
8
Front cover installation – undercounter
➊
➋
➌
CAUTION
• Keep ventilation openings in the appliance enclosure
clear of obstruction.
• To ensure proper ventilation (if not using supplied grille)
carefully review air circulation speci cations in section
4.1
• Remove and discard plastic grille
• Apply supplied gasket material around
entire opening on skin to prevent air
recirculation
• Attach supplied metal grille to opening in
counter door (see section 4.1)
➋
➊
➌
Normal front cover installation
➋
➊
• Slide ice machine cover over machine
ensuring that tabs on back of cover
slip under louvers on back of louvered
docking assembly
• Insert and tighten two screws through
cover and into louvered docking assembly
➊
➋
NOTICE
Ice machine MUST be sanitized prior to operation!
Consult Operation and Service Manual provided with ice machine for sanitizing instructions.
DROP-IN • RIDE Technology self-contained
15
Page 16
Long tube run recommendations
max. 2 ft (.6m)
➋
1/4"
• Pitch ice transport tube to allow melt water to drain towards ice machine
➊
➊
1'
• Secure insulated ice transport tube at least every 2 ft (.6m) to prevent dips or traps
➋
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
00159939R07
3/12
Loading...
