Focusrite Scarlett Studio User Manual [ru]

User Guide

FA0807-01

www.focusrite.com

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus with water.

6. Clean only with dry cloth.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

8. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

9. Only use attachments/accessories speciﬁed by the manufacturer.

10. Use only with the cart, stand, tripod, bracket, or table speciﬁed by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

11. Unplug this apparatus during lightning storms or when unused for long periods of time.

12. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

13. No naked ﬂames, such as lighted candles, should be placed on the apparatus.

WARNING: Excessive sound pressure levels from earphones and headphones can cause hearing loss.

WARNING: This equipment must only be connected to USB 2.0 type ports.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning ﬂash with arrowhead symbol, within equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufﬁcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

ENVIRONMENTAL DECLARATION

Compliance Information Statement: Declaration of Compliance procedure

Product Identiﬁcation: Focusrite Scarlett 2i2

Responsible party: American Music and Sound

Address: 5304 Derry Avenue #C

Agoura Hills,

CA 91301

Telephone: 800-994-4984

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

For USA

To the User:

1. Do not modify this unit! This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modiﬁcations not expressly approved by Novation may void your authority, granted by the FCC, to use this product.

2. Important: This product satisﬁes FCC regulations when high quality shielded cables are used to connect with other equipment. Failure to use high quality shielded cables or to follow the installation instructions within this manual may cause magnetic interference with appliances such as radios and televisions and void your FCC authorization to use this product in the USA.

3. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

For Canada

To the User:

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

RoHS Notice

Focusrite Audio Engineering Limited has conformed and this product conforms, where applicable, to the European Union’s Directive 2002/95/EC on Restrictions of Hazardous Substances (RoHS) as well as the following sections of California law which refer to RoHS, namely sections 25214.10, 25214.10.2, and 58012, Health and Safety Code; Section 42475.2, Public Resources Code.

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS .............................................. 2

OVERVIEW..................................................................... 5

Introduction .................................................................5

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Box Contents ................................................................6

System requirements .........................................................6

Mac OS .......................................................................6

Windows ......................................................................6

GETTING STARTED .............................................................7

Software Installation ..........................................................7

Mac OS .......................................................................7

Windows Installation ............................................................7

Connecting your Scarlett 2i2 ...................................................8

Audio Setup in Cubase LE (or your other DAW) ....................................8

Example of Usage ...........................................................10

Connecting a microphone or instrument...........................................10

Recording with a microphone ....................................................11

Using Direct Monitoring.........................................................12

Connecting Scarlett 2i2 to headphones ............................................13

Connecting Scarlett 2i2 to loudspeakers ...........................................13

HARDWARE FEATURES.........................................................14

Front Panel.................................................................14

Back Panel .................................................................15

SPECIFICATIONS .............................................................. 16

Performance Speciﬁcations ...................................................16

Physical and Electrical Characteristics ..........................................17

Scarlett Studio CM25 Microphone Speciﬁcations ..................................18

Scarlett HP60 Headphones Speciﬁcations .......................................18

TROUBLESHOOTING ........................................................... 19

OVERVIEW

Introduction

Thank you for purchasing the Scarlett Studio package, part of the range of Focusrite professional computer audio interfaces incorporating high quality, Focusrite analogue pre-ampliﬁers. You now have a simple, compact and complete solution for recording with a microphone or directly from instruments, by routing high quality audio to and from your computer.

This User Guide provides a detailed explanation of the components to help you achieve a thorough understanding of the Scarlett 2i2’s operational features. We recommend that whether you are new to computer recording or a more experienced user, you should take the time to read through the user guide so that you are fully aware of all the possibilities that the Scarlett Studio components and accompanying software has to offer. If the main User Guide sections do not provide the information you need, be sure to consult http://www.focusrite.com/answerbase, which contains a comprehensive collection of answers to common technical support queries.

Features

The Scarlett Studio package comprises a Scarlett 2i2 computer audio interface, a Scarlett Studio CM25 studio quality condenser microphone, a pair of Scarlett Studio HP60 reference quality headphones and all the necessary software – including Steinberg’s Cubase LE - to get you started with recording great audio on your computer as quickly as possible.

The Scarlett 2i2 hardware interface is the key component in the Scarlett Studio system; this provides the means of connecting the CM25 (or other) microphone, musical instruments or line level audio signals to a computer running Mac OS or Windows. The signals applied at the 2i2’s physical inputs can be routed to Cubase LE or other recording software via a USB connection. Similarly, the recording software’s monitor or recorded output will appear at the 2i2’s physical outputs. (Note - computer audio recording software is frequently referred to as a “Digital Audio Workstation”, or “DAW”, and the term “DAW” is used throughout this user guide.)

Audio sources – mics, instruments, etc. - connected to the 2i2’s physical inputs can be recorded in the DAW and then routed from your DAW to the physical outputs. The 2i2’s various physical outputs can be connected to the HP60 headphones, or if you wish, to an ampliﬁer and speakers, powered monitors, analogue mixer or any other analogue audio equipment that you wish to use. Although all inputs and outputs on the Scarlett 2i2 are routed directly to and from your DAW for recording and playback, you can conﬁgure the routing within your DAW in order to meet your needs.

Box Contents

You should ﬁnd that your Scarlett Studio package comprises:

• Scarlett 2i2 computer audio interface

• Scarlett Studio CM25 condenser microphone

• Scarlett Studio HP60 headphones

• Resources DVD containing:

- Cubase LE 6 recording software

- USB Drivers for Mac and Windows

• Red XLR microphone cable (3 m)

• USB cable

• “Getting Started Guide”

• “Download Your Software” online registration card

System requirements

Mac OS

Apple Macintosh with a high-speed USB 2.0-compliant USB port

OS: Mac OS X 10.7 or later DVD drive

Windows

Windows compatible computer with a USB 2.0-compliant USB port

OS: Windows 7 (all versions) or Windows 8 (excluding Windows 8 RT) DVD drive
