Fluke MOLBOX ANALOG CIRCUIT User Manual
molbox™ Analog Circuit
Calibration Software
User’s Manual
© 2002 DH Instruments, Inc.
High pressure liquids and gases are potentially hazardous. Energy stored in these liquids and gases
can be released unexpectedly and with extreme force. High pressure systems should be assembled
and operated only by personnel who have been instructed in proper safety practices.
© 1997-2002 DH Instruments, Inc. All rights reserved.
Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any
form or by any means, electronic or mechanical, for any purpose, without the express written permission of DH Instruments, Inc.
4765 East Beautiful Lane Phoenix AZ 85044-5318 USA.
DH Instruments makes sincere efforts to ensure accuracy and quality of its’ published materials; however, no warranty, expressed
or implied, is provided. DH Instruments disclaims any responsibility or liability for any direct or indirect damages resulting from the
use of the information in this manual or products described in it. Mention of any product or brand does not constitute an
endorsement by DH Instruments of that product or brand. This manual was originally composed in English and was subsequently
translated into other languages. The fidelity of the translation cannot be guaranteed. In case of conflict between the English version
and other language versions, the English version predominates.
Products described in this manual are manufactured under international patents and one or more of the following U.S. patents:
5,142,483, 5,257,640, 5,331,838, 5,445,035. Other U.S. and international patents pending.
DH Instruments, DH, DHI, molbox, molbox1 are trademarks, registered and otherwise, of DH Instruments, Inc.
Document No. 5500093b-04
020604
Printed in the USA.
© 1997-2002 DH Instruments, Inc.
TABLE OF CONTENTS
T
AABBLLEE
T
TABLE OF CONTENTS ...............................................................I
FIGURES.................................................................................II
ABOUT THIS MANUAL .............................................................. 2
1. MOLBOX ANALOG CIRCUIT CALIBRATION SOFTWARE.......... 1
1.1 PRODUCT OVERVIEW ...........................................................................................................................1
1.2 GETTING STARTED................................................................................................................................1
2. RUNNING A CALIBRATION .................................................. 3
2.1 OVERVIEW ..............................................................................................................................................3
2.2 CHECK CALIBRATION ...........................................................................................................................3
2.3 RECALIBRATE........................................................................................................................................4
3. MENU OPTIONS ................................................................. 5
3.1 FILE: SAVE DATA (SHORTCUT: CTRL+S)..........................................................................................5
3.2 FILE: PRINT FILE ...................................................................................................................................5
3.3 FILE: PRINT CURRENT DATA (SHORTCUT: CTRL+P) ...................................................................... 5
3.4 FILE: VIEW FILE (SHORTCUT: CTRL+F) ............................................................................................5
3.5 TEST: CHECK MOLBOX CALIBRATION .............................................................................................. 5
3.6 TEST: RECALIBRATE MOLBOX...........................................................................................................5
3.7 TEST: TEST SET VALUE (SHORTCUT: CTRL+T)............................................................................... 6
3.8 TEST: RESTORE PREVIOUS CALIBRATION....................................................................................... 6
O
O
FF
C
OONNTTEENNTTS
C
S
4. TROUBLESHOOTING .......................................................... 7
4.1 GENERAL PROCEDURES......................................................................................................................7
5. FORMS / DIAGRAMS........................................................... 9
5.1 SERIAL COMMUNICATIONS FORM ......................................................................................................9
5.2 ANALOG CALIBRATION FORM.............................................................................................................9
5.3 SET POINT TEST FORM.........................................................................................................................9
5.4 EXAMPLE .CFG FILE............................................................................................................................10
5.5 CABLES................................................................................................................................................. 11
6. WARRANTY STATEMENT .................................................. 13
Page I © 1997-2002 DH Instruments, Inc.
MFC SWITCHBOX USER’S MANUAL
T
AABBLLEES
T
Table 1. DHI Authorized Service Providers ............................................................................................... 13
F
IIGGUURREES
F
Figure 1 Communications Setup Screen ...................................................................................................... 9
Figure 2 molbox Analog Calibration Software ver 1.2b DH Instruments 1995 Screen ............................... 9
Figure 3 Set Point Test Screen.................................................................................................................... 9
Figure 4 molbox Analog Calibration Cable ................................................................................................ 11
Figure 5 Old Style molbox Analog Calibration Cable................................................................................. 11
A
BBOOUUTT
A
S
S
T
T
HHIISS
M
AANNUUAAL
M
L
Manual Conventions
(CAUTION) is used in throughout the manual to identify user warnings and cautions.
(NOTE) is used throughout the manual to identify operating and applications advice and
additional explanations.
[ ] indicates direct function keys (e.g., [RANGE]).
< > indicates PG7000 screen displays (e.g., <1yes>).
© 1997-2002 DH Instruments, Inc. Page II
1. INTRODUCTION
11..
MMOOLLBBOOXX
C
AALLIIBBRRAATTIIOONN
C
A
NNAALLOOGG
A
C
C
S
OOFFTTWWAARRE
S
IIRRCCUUIITT
E
1.1 PRODUCT OVERVIEW
The purpose of this software is to calibrate the MFC analog control circuit in molbox1™. There are three
separate lines that are individually calibrated by the software. First there is the set line that is used to set
MFC set points. Then there are two input lines, the sense and the measure. The sense line is used
to readjust the set value to match itself and the measure line is used to read the output of the MFC.
The measure line is the most important of the three, even if the set point and sense point are out of
tolerance, the measure line will still allow an accurate calibration if it is within tolerance. In current (mA)
mode there is no sense line so N/A appears in all sense fields while in current mode.
1.2 GETTING STARTED
Make sure that your PC has the following minimum requirements: Windows® 3.0, 4 MB of RAM and 1 MB of
hard disk space. To install the software, insert the moltools installation disk and run the setup utility. This can
be done in Windows by going to the File Menu, selecting Run and typing “A:\SETUP”, or in Windows 95
by pressing Start and choosing Run then typing “A:\SETUP” (where ‘A’ represents the drive that the
installation disk is located). This utility will install the molbox Analog Calibration program and all of its
associated files into the moltools directory and create a program group in Windows named molbox
moltools.
Before attempting to run the Analog Calibration program, be sure that the molbox COM1 port is
connected to one of the communications ports of the host PC with a standard RS232 cable. This allows
the program to auto-detect molbox and the serial communications setup is skipped. To run the program
double click the Analog Calibration Icon. In most cases, if everything is properly attached, the software
will auto-detect molbox and the calibration form will follow. The exceptions are when the current settings
of the molbox COM1 port are not Even parity, 1 Stop bit, 7 Data bits, and Baud rates of 2 400 or above.
In these cases, you will have to manually set up the communications. It is also possible that a general
communications error will occur or some other unexpected problem that has not been mentioned. If so,
choose the Communications menu option and select the proper settings from the Serial Communications
Form shown at the end of this document in the Forms/Diagrams section. If you cannot determine the
current settings of molbox, use the following procedure from the molbox keypad:
Press [ESC] until you return to the main menu if you are NOT already there.
Select <0 Special>, followed by <5 Internal> and <2 Remote>. Old style molbox1 users should
select: <3 Special>, <8 Internal>, <2 Remote>, <1 com1>.
If the molbox has an IEEE 488 option, select COM1 after selecting Remote in the previous step.
Either change the baud rate with the number keys and select [ENTER], or bypass it to view the next
parameter by pressing enter.
Repeat Step for Parity, Word Length and Stop Bits, and terminating characters.
Select the proper configuration on the Serial Communications Form and press [OK].
Page 1 © 1997-2002 DH Instruments, Inc.
MFC SWITCHBOX USER’S MANUAL
N
N
OOTTEES
S
© 1997-2002 DH Instruments, Inc. Page 2
