Nuclear Associates
76-810, 76-814
76-815 & 76-818
Bar Phantoms and Test Patterns
March 2005
Manual No. 76-810-1 Rev. 2
©2004, 2005 Fluke Corporation, All rights reserved. Printed in U.S.A.
All product names are trademarks of their respective companies
Operators Manual
Fluke Biomedical
Radiation Management Services
6045 Cochran Road
Cleveland, Ohio 44139
440.498.2564
www.flukebiomedical.com/rms
Table of Contents
Section 1: Introduction................................................................................................ 1-1
1.1 Definition...................................................................................................... 1-1
1.2 Equipment Required .................................................................................... 1-1
Section 2: Test Procedures......................................................................................... 2-1
2.1 Intrinsic Resolution ...................................................................................... 2-1
2.2 System Resolution....................................................................................... 2-2
2.3 Evaluating of Results ................................................................................... 2-2
2.4 Additional Tests ........................................................................................... 2-2
i
(Blank Page)
Introduction
Definition
1
Section 1
Introduction
1.1 Definition
Transmission test patterns provide an indication of both the intrinsic and system resolution capabilities of
a gamma camera. They can also provide a measure of field size and linearity. It is important to obtain
images of these patterns at the time the camera is tuned. These should be repeated periodically and
compared with the original. The images provide a prompt and sensitive indication of any loss in image
quality and alert the user to the need for service.
The image quality and resolution capabilities depend on many factors such as:
a. Gamma ray energy
b. Window width
c. Collimator
d. Information density
e. Count rate
f. Distance from collimator
g. Amount of scattering material
h. Type of data processing
i. Type of photographic system and film
Transmission test patterns provide a convenient means of studying how these different parameters affect
image quality and can be helpful in optimizing their choice.
1.2 Equipment Required
• A transmission test pattern suitable for the resolution capabilities and size of the camera being
tested such as one of the following:
1. Quadrant Bar Test Pattern
a. Standard Field Camera, up to 14 in (D)
Model No. Bar Widths (inches)
76-818 3/8, 1/4, 3/16, 1/10
b. Large-Field Camera, up to 16 in (D)
Model No. Bar Widths (inches)
76-814 3/8, 1/4, 3/16, 1/8
76-815 3/8, 1/4, 3/16, 1/10
2. Hine-Duley Test Pattern
Model No. Bar Spacing
76-810 1/4, 3/16, 5/32
1-1
Nuclear Associates 76-810,76-814,76-815, &76-818
Operators Manual
• Flood Phantom
Three flood phantoms are available, Rectangle, Jumbo and Gigantic. Filler and vent ports are
located on the face. Shipped empty; radioactivity is not included.
76-801 Rectangle phantoms is 18 x 23 x 1 in thick with a 16 x 23 x ½ in (D) cavity, weight 10 lbs
76-804 Jumbo phantom is 18 x 18 x 1 in thick with a cavity 17 x ½ in (D), weight 9 lbs
76-807 Gigantic phantom is 23 x 23 x 1 in thick with a cavity 22 x ½ in (D), weight 13 lb
or
Flood Sources (Co-57)
Model 67-296 for standard-field cameras
Model 67-297 for large-field cameras
Model 67-298 for large-field cameras
• Suitable sources of radioactive material and lead shielding.
• Masonite or Lucite sheets, 45 x 45 x 10 cm
1-2
Test Procedures
Intrinsic Resolution
Section 2
Test Procedures
2.1 Intrinsic Resolution
1. Adjust the window position and width for the radionuclide for which the resolution is to be
measured. A good starting point is 1.5 FWHM. The count rate should not exceed 10,000 cps to
avoid any spectral shifts due to pulse pile-up.
2. With the collimator removed, install the appropriate test pattern against the face of the crystal, using
the adapter plate.
3. Raise the detector to its maximum height, at least 5 feet from the floor (see Figure 2-1).
4. Place a point source or vial of activity of the desired nuclide on the floor, and center it under the
detector. Select the activity of the source to produce a count rate of less than 10,000 cps. Use
appropriate shielding, making sure the source is able to see all of the crystal.
5. Accumulate an image consisting of 1 million counts for standard field cameras and 2 million counts
for large-field cameras.
6. Process the data or develop the film, and inspect the final image.
Figure 2-1. Intrinsic
Figure 2-1. System Resolution
Figure 2-3. System Resolution with
Scattering Material
2
2-1
Nuclear Associates 76-810,76-814,76-815, &76-818
Operators Manual
2.2 System Resolution
1. Put on the desired collimator and invert the detector.
2. Place the test pattern on top of the collimator.
3. Place the filled Flood Phantom or Co-57 Flood Source on top of the bar phantom (Figure 2-2). The
Flood Phantom is filled with the desired isotope, using an activity that will produce less than 10,000
cps.
4. Accumulate an image consisting of 1 million counts for standard-field cameras, and 2 million counts
for large-field cameras.
5. Process the data or develop the film, and inspect the final image.
6. Place 10 cm of the suitable attenuating and scattering material, such as Masonite or Lucite,
between the bar test pattern and collimator (Figure 2-3),
7. Repeat steps 4 and 5.
2.2 Evaluating Of Results
Inspect each of the films to determine the smallest bar spacing that can be visualized. This is an
indication of the resolution under the conditions of measurement. Note that the intrinsic resolution is better
than the system resolution, due to the addition of the collimator. The addition of 10 cm of scattering
material further reduces the resolution.
Inspect the images for linearity by observing how straight the images of the bars are. Check for barrel or
pincushion distortion near the edges of the image.
The evaluation is somewhat subjective. However, if the images are kept in a logbook and compared with
images taken when the camera is properly adjusted, it will be possible to detect any changes or
deterioration of the images. Service can then be initiated immediately.
2.3 Additional Tests
Since each quadrant of the detector face sees a different size pattern when using the Quadrant Bar Test
Pattern, it is desirable to make 3 additional images at 90-degree rotational increments. For the Hine-Duley
Test Patterns, make an additional image at 90-degree rotation.
The resolution obtainable, as well as the overall quality of the image, will be a function of all of the
parameters listed. It is desirable to repeat the procedure and vary each of these parameters in order to
study how the image is affected by changes in window width, very high count rates, distance from the
collimator, or information density.
2-2
