56-6XX
CLEAR-Pb Mobile Barriers
January 2008
Manual No. 56-6XX-1 Rev. 2
2004, 2005, 2008 Fluke Corporation, All rights reserved.
All product names are trademarks of their respective companies
User Manual
Fluke Biomedical
6045 Cochran Road
Cleveland, Ohio 44139
440.498.2564
www.flukebiomedical.com
Table of Contents
Section 1: General Information...................................................................................... 1-1
1.1 Introduction.................................................................................................. 1-1
1.2 Components Supplied.................................................................................. 1-2
Section 2: Operation........................................................................................ 2-1
2.1 Assembly Procedure.................................................................................... 2-1
2.2 Service and Repairs .................................................................................... 2-3
i
(Blank page)
1.1 Introduction
General Information
Introduction
1
Section 1
General Information
Nuclear Medicine
56-602
Regular
56-603
Jumbo
56-604
Deluxe
56-616
Deluxe
56-617
Ultra
56-618
Ultra
56-619
Your CLEAR-Pb
shipping damage. Assembly is very simple. However, since the panels are heavy they should be
handled by two people until fully assembled.
Mobile Barrier is shipped to you disassembled, in compact cases designed to minimize
Overall Size
61” H x 36” W
75” H x 30” W
75” H x 30 W
75” H x 48” W
75” H x 48:” W
75” H x 72” W
75: H x 72” W
Window Panel
Lead Equiv.
24” H x 36” W
0.8 mm
24” H x 30” W
0.5 mm
60” H x 30” W
0.5 mm
36” H x 48” W
0.5 mm
36” H x 48” W
1.0 mm
36” H x 72” W
0.5 mm
36” H x 72” W
1.0 mm
CAUTION
Opaque Panel Lead
Equiv.
34” H x 36” W
1/16” (1.5 mm)
48” H x 30” W
min. 1/32” (0.8 mm)
12” H x 30” W
36” H x 48” W
min. 1/32” (0.8 mm)
36” H x 48” W
1/16” (1.5 mm)
36” H x 72” W
min. 1/32 (0.8 mm)
36” H x 72” W
1/16” (1.5 mm)
Do not remove the protective paper from the
viewing panel until after installation. This will help
keep the leaded plastic from being scratched during
assembly.
1-1
56-6XX
User Manual
1.2 Components Supplied
1 ea. CLEAR-Pb lead-plastic viewing panel
1 ea. opaque lower panel
4 ea. caster brackets
2 ea. locking casters and 2 ea. non-locking casters
1 set caster bracket mounting hardware (screws, washers and nuts)
1 set caster mounting hardware (hex bolts, washers and nuts)
2 ea. vertical side channels
1 ea. horizontal coupling channel (no holes)
1-2
Operation
Assembly Procedure
Section 2
Operation
2.1 Assembly Procedure
2.1.1 To facilitate installing the caster brackets, lay the opaque lower panel flat on a table with the
mounting holes extending over the table’s edge (see Figure 2-1).
2
Figure 2-1. Caster Brackets Assembly
2.1.2 If the vertical side channels are not welded to the lower panel, position them over the edges
as shown. The pre-drilled holes in the caster brackets and vertical side channels will line up
with the holes in the lower panel. Using the supplied hardware (screws, washers and nuts),
attach the brackets to the panel (see Figure 2-2).
For maximum safety convenience, the locking
casters should be on the same side of the panel
(see Figure 2-2).
NOTE
2-1
56-6XX
User Manual
2.1.3 If the casters are not already attached to the brackets, attach them by lining up the holes in
the brackets with those in the casters. Using the caster mounting hardware, (hex bolts,
washers and nuts), attach them as shown in Figure 2-2.
Figure 2-2. Brackets to Panel Assembly
2-2
Operation
Assembly Procedure
2.1.4 Carefully lower the assembly to the floor in a vertical position. The barrier can now be moved
about on its casters.
2.1.5 If it is not pre-welded to the panel, lay the horizontal coupling channel over the top edge of
the opaque lower panel.
2.1.6 Now peel back the protective paper about two inches from the sides of the CLEAR-Pb leadplastic viewing panel. Carefully slide the panel into the two upright channels. Once in place,
remove the rest of the protective paper from the CLEAR-Pb panel.
The Mobile Barrier is now ready to use.
2
3.2 Service And Repairs
If your Mobile Barrier needs service or repairs, please contact Fluke Biomedical at 440.248.2564.
2-3
