Nuclear Associates
56-515 & 56-516
Moti X-Ray Mask
March 2005
Manual No. 56-515-1 Rev. 2
©2004, 2005 Fluke Corporation, All rights reserved. Printed in U.S.A.
All product names are trademarks of their respective companies
Users Manual
Fluke Biomedical
Radiation Management Services
6045 Cochran Road
Cleveland, Ohio 44139
440.498.2564
www.flukebiomedical.com/rms
Table of Contents
Section 1: Introduction................................................................................................ 1-1
1.1 Product Description ..................................................................................... 1-1
1.2 Donning the Mask........................................................................................ 1-1
1.3 Maintenance ................................................................................................ 1-1
i
(Blank Page)
Introduction
Product Description
1
Section 1
Introduction
1.1 Product Description
This new radiation shield provides complete protection to the eyes, thyroid and neck of x-ray personnel
while allowing full visibility and freedom of movement, especially during special procedures. It forms a
stationary window in front of the wearer's face. The head is free to move in any direction while the mask
remains fixed to the shoulders. Eyeglasses can be worn without any interference. When used with a lead
apron, the combination shields the entire body from scattered radiation.
The mask consists of a curved, optically clear, leaded-acrylic window mounted in a rugged plastic frame.
The windows 0.35 mm lead equivalence provides significant absorption (81.9 to 96.6%) of heavily filtered,
3-phase, diagnostic x-ray beams. A Velcro connection-closure makes the mask easy to put on and take
off.
Table 1-1. Exposures (In mR) at Fixed 72" Distance
KV
Setting
60 170 0.00 1.64 99.0 5.86 96.6
80 319 0.00 6.7 97.9 24.4 92.4
100 495 0.00 20.6 95.8 54.9 88.9
126 800 0.00 44.7 94.4 113. 85.9
150 970 0.00 70.5 92.7 176. 81.9
No Filtration
mR %abs. mR %abs. mR % abs.
0.50 mm
Lead Apron X-Ray Mask
1.2 Donning the Mask
The mask is held in place by attaching its soft Velcro-surfaced base to mating Velcro applied to the
shoulders of a lead apron.
The 56-515 X-Ray Mask (without apron) includes a kit for affixing the mating to your own lead apron.
In the 56-516 X-Ray Mask/Apron combination, the Velcro has been pre-sewn to the apron's shoulder
supports.
1.3 Maintenance
To remove smudges from the mask, wipe with a damp cloth. To remove stains, use a professional nonabrasive plastic cleaner. If the lens fogs up, clear with any eyeglass defogger.
Avoid excessive exposure to heat or sunlight. To protect against scratches, store the mask so that the
lens does not touch any surface or object.
1-1
