Fluke 5500A Getting Started

Download

5500A

Multi-Product Calibrator

Getting Started

PN 945159 August 2001

LIMITED WAR RA NTY & LIMITATION OF LIABILITY

Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is one year and begins on the date of shipment. Parts, product repairs and services are warranted for 90 days. This warranty extends only to the original buyer or end-user customer of a Fluke authorized reseller, and does not apply to fuses, disposable batteries or to any product which, in Fluke’s opinion, has been misused, altered, neglected or damaged by accident or abnormal conditions of operation or handling. Fluke warrants that software will operate substantially in accordance with its functional specifications for 90 days and that it has been properly recorded on non-defective media. Fluke does not warrant that software will be error free or operate without interruption. Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price. Fluke reserves the right to invoice Buyer for importation costs of repair/replacement parts when product purchased in one country is submitted for repair in another country. Fluke’s warranty obligation is limited, at Fluke’s option, to refund of the purchase price, free of charge repair, or replacement of a defective product which is returned to a Fluke authorized service center within the warranty period. To obtain warranty service, contact your nearest Fluke authorized service center or send the product, with a description of the difficulty, postage and insurance prepaid (FOB Destination), to the nearest Fluke authorized service center. Fluke assumes no risk for damage in transit. Following warranty repair, the product will be returned to Buyer, transportation prepaid (FOB Destination). If Fluke determines that the failure was caused by misuse, alteration, accident or abnormal condition of operation or handling, Fluke will provide an estimate of repair costs and obtain authorization before commencing the work. Following repair, the product will be returned to the Buyer transportation prepaid and the Buyer will be billed for the repair and return transportation charges (FOB Shipping Point). THIS WARRANTY IS BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. FLUKE SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, WHETHER ARISING FROM BREACH OF WARRANTY OR BASED ON CONTRACT, TORT, RELIANCE OR ANY OTHER THEORY. Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion or limitation of incidental or consequential damages, the limitations and exclusions of this warranty may not apply to every buyer. If any provision of this Warranty is held invalid or unenforceable by a court of compet ent jurisdiction, such hold ing will not affect the val idi ty or enforceability of any other provision.

Fluke Corporation Fluke Europe B.V. P.O. Box 9090 P.O. Box 1186 Everett, WA 98206-9090 5602 BD Eindhoven U.S.A. The Netherlands

5/94

LIMITE DE GARANTIE ET LIMITE DE RESPONSABILITE

La société Fluke garantit l'absence de vices des matériaux et à la fabrication de ce produit dans des conditions normales d'utilisation et d'entretien. La période de garantie est de un an et prend effet à la date d'expédition. Les pièces, les réparations de produit et les services sont garantis pour un période de 90 jours. Cette garantie ne s'applique qu'à l'acheteur d'origine ou à l'utilisateur final s'il est client d'un distributeur agréé par Fluke, et ne s'applique pas aux fusibles, aux batteries/piles interchangeables ni à aucun produit qui, de l'avis de Fluke, a été malmené, modifié, négligé ou endommagé par accident ou soumis à des conditions anormales d'utilisation et de manipulation. Fluke garantit que le logiciel fonctionnera en grande partie conformément à ses spécifications fonctionnelles pour une période de 90 jours et qu'il a été correctement enregistré sur des supports non défectueux. Fluke ne garantit pas que le logiciel ne contient pas d'erreurs ou qu'il fonctionne sans interruption.

Les distributeurs agréés par Fluke appliqueront cette garantie à des produits vendus à leurs clients neufs et qui n'ont pas servi mais ne sont pas autorisés à appliquer une garantie plus étendue ou différente au nom de Fluke. Le support de garantie est offert si le produit a été acquis par l'intermédiaire d'un point de vente agréé par Fluke ou bien si l'acheteur a payé le prix international applicable. Fluke se réserve le droit de facturer à l'acheteur les frais d'importation des pièces de réparation ou de remplacement si le produit acheté dans un pays a été expédié dans un autre pays pour y être réparé.

L'obligation de garantie de Fluke est limitée, au choix de Fluke, au remboursement du prix d'achat, ou à la réparation/remplacement gratuit d'un produit défectueux retourné dans le délai de garantie à un centre de service agréé par Fluke.

Pour avoir recours au service de la garantie, mettez-vous en rapport avec le centre de service Fluke le plus proche ou envoyez le produit, accompagné d'une description du problème, port et assurance payés (franco lieu de destination), au centre de service agréé par Fluke le plus proche. Fluke dégage toute responsabilité en cas de dégradations survenues au cours du transport. Après la réparation sous garantie, le produit sera retourné à l'acheteur, frais de port payés d'avance (franco lieu de destination). Si Fluke estime que le problème a été causé par un traitement abusif, une modification, un accident ou des conditions de foncti on nem ent ou de man ipu lation anormales, Fluke fournira un devis des frais de réparation et ne commencera la réparation qu'après en avoir reçu l'autorisation. Après la réparation, le produit sera retourné à l'acheteur, frais de port payés d'avance, et les frais de réparation et de transport lui seront facturés.

LA PRESENTE GARANTIE EST EXCLUSIVE ET TIENT LIEU DE TOUTES AUTRES GARANTIES, EXPLICITES OU IMPLICITES, Y COMPRIS, MAIS NON EXCLUSIVEMENT, TOUTE GARANTIE IMPLICITE QUANT A L'APTITUDE DU PRODUIT A ETRE COMMERCIALISE OU A ETRE APPLIQUE A UNE FIN OU A UN USAGE DETERMINE. FLUKE NE POURRA ETRE TENU RESPONSABLE D'AUCUN DOMMAGE PARTICULIER, INDIRECT, ACCIDENTEL OU CONSECUTIF, NI D'AUCUNS DEGATS OU PERTES DE DONNEES, QUE CE SOIT A LA SUITE D'UNE INFRACTION AUX OBLIGATIONS DE GARANTIE, SUR UNE BASE CONTRACTUELLE, EXTRA- CONTRACTUELLE OU AUTRE.

Etant donné que certains pays ou états n'admettent pas les limitations d'une condition de garantie implicite, ou l'exclusi on ou la limitation de dégâts accidente ls ou co ns éc utif s, le s li mit ati on s et les exclusions de cette garantie pourraient ne pas s'appliquer à chaque acheteur. Si une disposition quelconque de cette garantie est jugée non valide ou inapplicable par un tribunal compétent, une telle décision n'affectera en rien la validité ou le caractère exécutoire de toute autre disposition.

Fluke Corporation Fluke Europe B.V. P.O. Box 9090 P.O. Box 1186 Everett, WA 98206-9090 5602 B.D. Eindhoven USA Pays-Bas

BEFRISTETE GARANTIEBESTIMMUNGEN & HAFTUNGSBESCHRÄNKUNG

Für jedes Produkt, das Fluke herstellt, leistet Fluke eine Garantie für einwandfreie Materialqualitßt und fehlerfreie Ausführung unter normalen Betriebs- und Wartungsbedingungen. Der Garantiezeitraum gilt für ein Jahr und beginnt mit dem Lieferdatum. Die Garantiebestimmungen für Ersatzteile, Instandsetzungs- und Wartungsarbeiten gelten für einen Zeitraum von 90 Tagen. Diese Garantie wird ausschließlich dem Erst erwerber bzw. dem Endverbraucher, der das betreffende Produkt von einer von Fluke autorisierten Weiterverkaufsstelle erworben hat, geleistet und erstreckt sich nicht auf Sicherungen, Einwegbatterien oder irgendwelche andere Produkte, die nach dem Ermessen von Fluke unsachgemäß verwendet, verändert, vernachlässigt, durch Unfälle beschädigt oder abnormalen Betriebsbedingungen oder einer unsachgemäßen Handhabung ausgesetzt wurden. Fluke garantiert für einen Zeitraum von 90 Tagen, daß die Software im wesentlichen in Übereinstimmung mit den einschlägigen Funktionsbeschreibungen funktioniert und daß diese Software auf fehlerfreien Datenträgern gespeichert wurde. Fluke übernimmt jedoch keine Garantie dafür, daß die Software fehlerfrei ist und störungsfrei arbeitet.

Von Fluke autorisierte Weiterverkaufsstellen werden diese Garantie ausschließlich für neue und nichtbenutzte, an Endverbraucher verkaufte Produkte leisten, sind jedoch nicht dazu berechtigt, diese Garantie im Namen von Fluke zu verlängern, auszudehnen oder in irgendeiner anderen Weise abzuändern. Der Erwerber hat das Recht aus der Garantie abgeleitete Unterstützungsleistungen in Anspruch zu nehmen, wenn er das Produkt bei einer von Fluke autorisierten Vertriebsstelle gekauft oder den jeweils geltenden internationalen Preis gezahlt hat. Fluke behält sich das Recht vor, dem Erwerber Einfuhrgebühren für Ersatzteile in Rechnung zu stellen, wenn dieser das Produkt in einem anderen Land zur Reparatur anbietet, als das Land, in dem er das Produkt ursprünglich erworben hat.

Flukes Garantieverpflichtung beschränkt sich darauf, daß Fluke nach eigenem Ermessen den Kaufpreis ersetzt oder aber das defekte Produkt unentgeltlich repariert oder austauscht, wenn dieses Produkt innerhalb der Garantiefrist einem von Fluke autorisierten Servicezentrum zur Reparatur übergeben wird.

Um die Garantieleistung in Anspruch zu nehmen, wenden Sie sich bitte an das nächstgelegene und von Fluke autorisierte Servicezentrum oder senden Sie das Produkt mit einer Beschreibung des Problems und unter Vorauszahlung von Fracht- und Versicherungskosten (FOB Bestimmungsort) an das nächstgelegene und von Fluke autorisierte Servicezentrum. Fluke übernimmt keinerlei Haftung für eventuelle Transportschäden. Im Anschluß an die Reparatur wird das Produkt unter Vorauszahlung von Frachtkosten (FOB Bestimmungsort) an den Erwerber zurückgesandt. Wenn Fluke jedoch feststellt, daß der Defekt auf unsachgemäße Handhabung, Veränderungen am Gerät, einen Unfall oder auf anormale Betriebsbedingungen oder unsachgemäße Handhabung zurückzuführen ist, wird Fluke dem Erwerber einen Voranschlag der Reparaturkosten zukommen lassen und erst die Zustimmung des Erwerbers einholen, bevor die Arbeiten in Angriff genommen werden. Nach der Reparatur wird das Produkt unter Vorauszahlung der Frachtkosten an den Erwerber zurückgeschickt und werden dem Erwerber die Reparaturkosten und die Versandkosten (FOB Versandort) in Rechnung gestellt.

DIE VORSTEHENDEN GARANTIEBESTIMMUNGEN SIND DAS EINZIGE UND ALLEINIGE RECHT AUF SCHADENERSATZ DES ERWERBERS UND GELTEN AUSSCHLIESSLICH UND AN STELLE VON ALLEN ANDEREN VERTRAGLICHEN ODER GESETZLICHEN GEWÄHRLEISTUNGSPFLICHTEN, EINSCHLIESSLICH JEDOCH NICHT DARAUF BESCHRÄNKT - DER GESETZLICHEN GEWÄHRLEISTUNG DER MARKTFÄHIGKEIT, DER GEBRAUCHSEIGNUNG UND DER ZWECKDIENLICHKEIT FÜR EINEN BESTIMMTEN EINSATZ. FLUKE ÜBERNIMMT KEINE HAFTUNG FÜR SPEZIELLE, UNMITTELBARE, MITTELBARE, BEGLEITODER FOLGESCHÄDEN ODER ABER VERLUSTE, EINSCHLIESSLICH DES VERLUSTS VON DATEN, UNABHÄNGIG DAVON, OB SIE AUF VERLETZUNG DER GEWÄHRLEISTUNGSPFLICHT, RECHTMÄSSIGE, UNRECHTMÄSSIGE ODER ANDERE HANDLUNGEN ZURÜCKZUFÜHREN SIND.

Angesichts der Tatsache, daß in einigen Ländern die Begrenzung einer gesetzlichen Gewährleistung sowie der Ausschluß oder die Begrenzung von Begleit- oder Folgeschäden nicht zulässig ist, könnte es sein, daß die obengenannten Einschränkungen und Ausschlüsse nicht für jeden Erwerber gelten. Sollte irgendeine Klausel dieser Garantiebestimmungen von einem zuständigen Gericht für unwirksam oder nicht durchsetzbar befunden werden, so bleiben die Wirksamkeit oder Erzwingbarkeit irgendeiner anderen Klausel dieser Garantiebestimmungen von einem solchen Spruch unberührt.

Fluke Corporation Fluke Europe B.V. Postfach 9090 Postfach 1186 Everett, WA 98206-9090 5602 B.D. Eindhoven USA Niederlande

GARANTÍA LIMITADA Y LIMITACIÓN DE RESPONSABILIDAD

Se garantiza que cada uno de los productos de Fluke no tiene defectos de material y mano de

obra si es objeto de una utilizac ió n y un mante nim ie nto nor m ale s. El per í odo de garan tía es de un año y comienza a partir de la fecha de envío. Las piezas, reparaciones y mantenimiento del producto están garantizados durante 90 días. Esta garantía se concede exclusivamente al comprador original o al cliente usuario final de un revendedor autorizado por Fluke, y no es de aplicación a fusibles, baterías o pilas desechables o cualquier otro producto que, en opinión de Fluke, haya sido objeto de una mala utilización, alteración, negligencia o daños por accidente o manejo o manipulación anómalos. Fluke garantiza que el software operará sustancialmente de acuerdo con sus espec ificac i on es fun ci ona le s durante 90 días y que ha sido grabado correctamente en medios no defectuosos. Fluke no garantiza que el software carezca de errores ni opere sin interrupc ió n.

Los revendedores autorizados por Fluke concederán esta garantía a productos nuevos y sin utilizar suministrado s a cli ent es u suari os fina le s exclu siv a me nte, per o no tie nen autor idad para conceder una garantía diferente o mayor por cuenta de Fluke. Puede utilizar el servicio de garantía si el producto ha si do comprado en una oficina de ventas Fluke autorizada o si el Comprador ha pagado el importe de aplicación internacional. Fluke se reserva el derecho de facturar al Comprador los costes de importación debidos a la reparación o sustitución de piezas cuando el producto comprado en un país es enviado para su reparación a otro país.

La obligación de Fluke en concepto de garantía se limita, a criterio de Fluke, al reembolso del importe de la compra, a la reparación gratis, o a la sustitución de un producto defectuoso que sea devuelto a un centro de servicio Fluke autorizado dentro del período de garantía.

Para obtener servicio en garantía, póngase en contacto con el Servicio Oficial Fluke autorizado más próximo o envíe el producto, con una descripción del problema surgido, a portes y seguros pagados por anticipado (FOB en Destino), al Servicio Oficial Fluke autorizado más próximo. Fluke no asume ningún riesgo por los daños en tránsito. Tras la reparación en concepto de garantía, el producto será devuelto al Comprador, previo pago del transporte (FOB en Destino). Si Fluke decide que la avería ha sido causada por una mala utilización, alteración, accidente o manejo o manipulación anormales, Fluke hará una estimación de los costes de reparación y solicitará autorización antes de comenzar el trabajo. Tras la reparación, el producto será devuelto al Comprador, prev io pago del tr an sporte, y se facturarán al Comprad or los ga sto s en concepto de reparación y de transporte para su devolución (FOB en el Punto de envío).

ESTA GARANTÍA SE CONCEDE A TÍTULO ÚNICO Y EXCLUSIVO DEL COMPRADOR Y SUSTITUYE A TODAS LAS DEMÁS GARANTÍAS, EXPRESAS O IMPLÍCITAS, INCLUYENDO, PERO SIN LIMITARSE A, NINGUNA GARANTÍA IMPLÍCITA DE COMERCIABILIDAD O IDONEIDAD PARA UN FIN O UN USO DETERMINADOS. FLUKE NO SE RESPONSABILIZARÁ DE PÉRDIDAS O DAÑOS ESPECIALES, INDIRECTOS, IMPREVISTOS O CONTINGENTES, INCLUIDA LA PÉRDIDA DE DATOS, YA SEAN PRODUCTO DE VIOLACIÓN DE LA GARANTÍA O YA SEA EN RELACIÓN CON UN CONTRATO, POR RESPONSABILIDAD CIVIL EXTRACONTRACTUAL, CONFIANZA O EN CUALQUIER OTRA FORMA.

Dado que algunos países o estados no permiten la limitación del plazo de una garantía implícita, ni la exclusión o limitación de daños imprevistos o contingentes, las limitaciones y exclusiones de esta garantía pueden no ser de aplicación a todos los compradores. Si alguna disposición de esta Garantía es considerada nula o no aplicable por un tribunal de justicia competente, dicha consideración no afectará a la validez o aplicación de las demás disposiciones.

Fluke Corporation Fluke Europe B.V. P.O. Box 9090 P.O. Box 1186 Everett, WA 98206-9090 5602 B.D. Eindhoven ESTADOS UNIDOS Holanda

CAUTION

This is an IEC safety Class 1 product. Before using, the ground wire in the line cord or rear panel binding post must be connected to an earth ground for safety.

Interference Information

This equipment generates and uses radio frequency energy and if not installed and used in strict

accordance with the manufacturer’s instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a Class B computing device in accordance with the specifications of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation.

Operation is subject to the following two conditions:

This device may not cause harmful interference.

•

This device must accept any interference received, including interference that may cause

•

undesired operation.

There is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of more of the following measures:

Reorient the receiving antenna

•

Relocate the equipment with respect to the receiver

•

Move the equipment away from the receiver

•

Plug the equipment into a different outlet so th at the com puter and re ceiver are on d ifferent

•

branch circuits If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find the following booklet prepared by the Federal Communications Commission helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet is available from the U.S. Government Printing Office, Washington, D.C.

20402. Stock No. 004-000-00345- 4.

Declaration of the Manufacturer or Importer

We hereby certify that the Fluke Model 5500A is in compliance with BMPT Vfg 243/1991 and is RFI suppressed. The normal operation of some equipment (e.g. signal generators) may be subject to specific restrictions. Please observe the notices in the users manual. The marketing and sales of the equipment was reported to the Central Office for Telecommunication Permits (BZT). The right to retest this equipment to verify compliance with the regulation was given to the BZT.

Bescheinigung des Herstellers/Importeurs

Hiermit wird bescheinigt, daβ die Fluke Model 5500A in Übereinstimmung mit den Bestimmungen der BMPT-AmtsblVfg 243/1991 funk-entstört sind. Der vorschriftsmäßige Betrieb mancher Geräte (z.B. Meßsender) kann allerdings gewissen Einschränkungen unterliegen. Beachten Sie deshalb die Hinweise in der Bedienungsanleitung. Dem Bundesamt für Zulassungen in der Telecommunikation wurde das Inverkehrbringen dieses Gerätes angezeigt und die Berechtigung zur Überprüfung der Serie auf Einhaltung der Bestimmungen eingeräumt.

Fluke Corporation

SAFETY TERMS IN THIS MANUAL

This instrument has been designed and tested in accordance with IEC publication 1010-1 (1992-1), Safety Requirements for Electrical Measuring, Control and Laboratory Equipment, and ANSI/ISA-582.01-1994, and CAN/CSA-C22.2 No. 1010.1-92. This User Manual contains information, warning, and cautions that must be followed to ensure safe operation and to maintain the instrument in a safe condition. Use of this equipment in a manner not specified herein may impair the protection provided by the equipment.

This instrument is designed for IEC 1010-1 Installation Category II use. It is not designed for connection to circuits rated over 4800 VA.

WARNING statements identify conditions or practices that could result in personal injury or loss of life.

CAUTION statements identify conditions or practices that could result in damage to equipment.

SYMBOLS MARKED ON EQUIPMENT

WARNING Risk of electric shock. Refer to the manual (see the Index for

references).

GROUND Ground terminal to chassis (earth).

Attention Refer to the manual (see the Index for references). This

symbol indicates that information about usage of a feature is contained in the manual. This symbol appears on the rear panel ground post and by the fuse compartment.

AC POWER SOURCE

The instrument is intended to operate from an ac power source that will not apply more than 264V ac rms between the supply conductors or between either supply conductor and ground. A protective ground connection by way of the grounding conductor in the power cord is required for safe operation.

USE THE PROPER FUSE

To avoid fire hazard, for fuse replacement use only the specified unit: 110 or 120 V operation, 2.5 ampere/250 volt time delay; 220 or 240 V operation, 1.25 ampere/250 volt time delay.

GROUNDING THE INSTRUMENT

The instrument utilizes controlled overvoltage techniques that require the instrument to be grounded whenever normal mode or common mode ac voltages or transient voltages may occur. The enclosure must be grounded through the grounding conductor of the power cord, or through the rear panel ground binding post.

USE THE PROPER POWER CORD

Use only the power cord and connector appropriate for the voltage and plug configuration in your country.

Use only a power cord that is in good condition. Refer power cord and connector changes to qualified service personnel.

DO NOT OPERATE IN EXPLOSIVE ATMOSPHERES

To avoid explosion, do not operate the instrument in an atmosphere of explosive gas.

DO NOT REMOVE COVER DURING OPERATION

To avoid personal injury or death, do not remove the instrument cover without first removing the power source connected to the rear panel. Do not operate the instrument without the cover properly installed. Normal calibration is accomplished with the cover closed. Access procedures and the warnings for such procedures are contained both in this manual and in the Service Manual. Service procedures are for qualified service personnel only.

DO NOT ATTEMPT TO OPERATE IF PROTECTION MAY BE IMPAIRED

If the instrument appears damaged or operates abnormally, protection may be impaired. Do not attempt to operate the instrument under these conditions. Refer all questions of proper instrument operation to qualified service personnel.

Title Page

Introduction....................................................................................................... 1

Instruction Manuals........................................................................................... 2

5500A Getting Started Manual..................................................................... 3

5500A Operator Manual ............................................................................... 3

5500A Operator Reference Guide................................................................. 3

5500A Programmer Reference Guide........................................................... 3

5500A Service Manual.................................................................................. 3

Where to Go from Here..................................................................................... 3

Operation Overview.......................................................................................... 4

Local Operation............................................................................................. 4

Remote Operation (RS-232).......................................................................... 4

Remote Operation (IEEE-488)...................................................................... 4

Preparing for Operation..................................................................................... 5

Unpacking and Inspection................................................................................. 5

Replacing the Fuse ............................................................................................ 6

Selecting Line Voltage...................................................................................... 6

Connecting to Line Power................................................................................. 7

Service Information........................................................................................... 9

Placement and Rack Mounting.......................................................................... 9

Cooling Considerations..................................................................................... 9

5725A Amplifier ............................................................................................... 10

Connecting the 5725A Amplifier...................................................................... 10

Specifications .................................................................................................... 11

General Specifications .................................................................................. 12

DC Voltage Specifications............................................................................ 13

DC Current Specifications............................................................................ 14

Resistance Specifications.............................................................................. 15

AC Voltage (Sinewave) Specifications......................................................... 16

AC Current (Sinewave) Specifications......................................................... 18

Capacitance Specifications............................................................................ 20

Temperature Calibration (Thermocouple) Specifications............................. 21

Temperature Calibration (RTD) Specifications............................................ 22

DC Power Specification Summary................................................................ 24

AC Power (45 Hz to 65 Hz) Specification Summary, PF=1......................... 25

Power and Dual Output Limit Specifications ............................................... 26

5500A

Getting Started

5500A Phase Specifications.......................................................................... 27

Calculating Power Uncertainty..................................................................... 28

Additional Specifications.................................................................................. 29

Frequency Specifications.............................................................................. 29

Harmonics (2nd to 50th) Specifications........................................................ 30

AC Voltage (Sinewave) Extended Bandwidth Specifications...................... 31

AC Voltage (Non-Sinewave) Specifications................................................. 32

AC Voltage, DC Offset Specifications......................................................... 33

AC Voltage, Squarewave Characteristics..................................................... 33

AC Voltage, Triangle wave Characteristics (typical)................................... 34

AC Current (Sinewave) Extended Bandwidth Specifications....................... 34

AC Current (Non-Sinewave) Specifications................................................. 34

AC Current (Non-Sinewave) Specifications ..................................................... 35

AC Current, Squarewave Characteristics (typical)....................................... 35

AC Current, Trianglewave Characteristics (typical)..................................... 35

Introduction

The Fluke Model 5500A Multi-Product Calibrator (Figure 1) is a precise instrument that calibrates a wide variety of electrical measuring instruments. With the 5500A Calibrator, you can calibrate precision multimeters that measure ac or dc voltage, ac or dc current, ac or dc power, resistance, capacitance, and temperature. With the Oscilloscope Calibration option, you can use the 5500A Calibrator to calibrate analog and digital oscilloscopes. Specifications are provided in this manual. Complete operating information is provided in the Operator Manual and complete service information is provided in the Service Manual. Both manuals are provided on the CD-ROM you received with your Calibrator.

If the 5500A Calibrator is operated in any way not specified by this manual or other documentation provided by Fluke, the protection provided by the Calibrator may be impaired.

Getting Started

Warning

NORMAL AUX

V, ,

RTD

1000V

RMS MAX

20V PK

MAX

1V PK

MAX

5500A

A, -SENSE,

AUX V

20V RMS MAX

20V PK

MAX

CALIBRATOR

SCOPE

60V PK

MAX

TRIG OUT

SHIFT

dBm sec

VHz

¡F

¡C

ENTER

SETUP

RESET

NEW

REF

MEAS

TRIG

OUT

MULT

DIV

EDIT FIELD

OPRSTBY EARTH SCOPE BOOST MENU

789

456

123

0•

Figure 1. 5500A Multi-Product Calibrator

POWER

F1-01.eps

5500A

Getting Started

The 5500A Calibrator is a fully programmable precision source of the following:

• DC voltage from 0 V to +1020 V.

• AC voltage from 1 mV to 1020 V, with output from 10 Hz to 500 kHz.

• AC current from 0.01 µA to 11.0 A, with output from 10 Hz to 10 kHz.

• DC current from 0 to +11.0 A.

• Resistance values from a short circuit to 330 MΩ.

• Capacitance values from 330 pF to 1100 µF.

• Simulated output for three types of Resistance Temperature Detectors (RTDs).

• Simulated output for nine types of thermocouples.

Features of the 5500A Calibrator include the following:

• Automatic meter error calculation.

• X and D keys that change the output value to pre-determined cardinal values

for various functions.

• Programmable entry limits that prevent invalid amounts from being entered.

• Simultaneous output of voltage and current, up to 11 kW.

• Simultaneous output of two voltages.

• Extended bandwidth mode outputs multiple waveforms down to 0.01 Hz, and sine

waves to 2 MHz.

• Variable phase signal output.

• Standard IEEE-488 (GPIB) interface, complying with ANSI/IEEE Standards

488.1-1987 and 488.2-1987.

• EIA Standard RS-232-C serial data interface for printing, displaying, or transferring

internally stored calibration constants, and for remote control of the 5500A.

• Pass-through RS-232-C serial data interface for communicating with the Unit Under

Test (UUT).

• Extensive automatic internal self testing and diagnostics of analog and digital

functions.

Instruction Manuals

The 5500A Manual Set provides complete information for operators and service or maintenance technicians. The set includes:

• 5500A Getting Started Manual (PN 945159)

• 5500A Operator Reference Guide (PN 945097)

• 5500A Remote Programming Reference Guide (PN 105783)

• 5500A Operator Manual (Provided on CD-ROM or printed copy available for

purchase (PN 1628802) through the Fluke Service Department.)

• 5500A Service Manual (PN 105798)

5500A Getting Started Manual

This 5500A Getting Started Manual contains a brief introduction to the 5500A Manual Set, instructions on how to get your calibrator prepared for operation and a complete set of specifications.

5500A Operator Manual

The 5500A Operator Manual provides complete information for installing the 5500A Calibrator and operating it from the front panel keys and in remote configurations. This manual also provides a glossary of calibration, specifications, and error code information. The Operator Manual includes the following topics:

• Installation

• Operating controls and features, including front panel operation

• Remote operation (IEEE-488 bus or serial port remote control)

• Serial port operation (printing, displaying, or transferring data, and setting up for

serial port remote control)

• Operator maintenance, including verification procedures and calibration approach

for the 5500A

• Oscilloscope Calibration Option

• Accessories

5500A Operator Reference Guide

The 5500A Operator Reference Guide contains a summary of operating instructions, and a front panel and rear panel feature reference. This guide is included with this manual.

Multi-Product Calibrator

Where to Go from Here

5500A Programmer Reference Guide

The 5500A Programmer Reference Guide contains a summary of remote commands and reference information useful in determining system status using the status byte and related registers. This guide is included with this manual.

5500A Service Manual

The 5500A Service Manual is available in PDF format on the CD-ROM provided with your instrument. It can also be ordered through your local Fluke Sales or Service representative. The 5500A Service Manual includes: theory of operation, performance testing, maintenance, calibration, troubleshooting, parts lists, and schematic diagrams.

Where to Go from Here

To locate specific information concerning the operation of the 5500A calibrator, refer to the following list:

• Controls, indicators, and displays: Operator Manual - Chapter 3, “Features”

• Front panel operation: Operator Manual - Chapter 4, “Front Panel Operation”

• Cabling to a UUT (Unit Under Test): Operator Manual - Chapter 4, “Front Panel

Operation”

• Using the auxiliary amplifier: Operator Manual - Chapter 4, “Front Panel

Operation”

• Remote operation (IEEE-488 or serial): Operator Manual - Chapter 5, “Remote

Operation”

• Calibrating an Oscilloscope: Operator Manual - Chapter 8, “Oscilloscope

Calibration Option”

• Accessories to the 5500A Calibrator: Operator Manual - Chapter 9, “Accessories”

5500A

Getting Started

Operation Overview

Local Operation

Remote Operation (RS-232)

The 5500A Calibrator may be operated at the front panel in the local mode, or remotely using RS-232 or IEEE-488 ports. For remote operations, several software options are available to integrate 5500A operation into a wide variety of calibration requirements.

Typical local operations include front panel connections to the Unit Under Test (UUT), and then manual keystroke entries at the front panel to place the calibrator in the desired output mode. The front panel layout facilitates hand movements from left to right, and multiply and divide keys make it easy to step up or down at the press of a single key. You can also review 5500A Calibrator specifications at the push of a button [available, July, 1995]. The backlit liquid crystal display is easy to read from many different viewing angles and lighting conditions, and the large, easy-to-read keys are color-coded and provide tactile feedback when they are pressed.

There are two rear-panel serial data RS-232 ports: SERIAL 1 FROM HOST, and SERIAL 2 TO UUT (Figure 2). Each port is dedicated to serial data communications for operating and controlling the 5500A during calibration procedures. For complete information on remote operations, see Chapter 5.

The SERIAL 1 FROM HOST serial data port connects a host terminal or personal computer to the 5500A. You have several choices for sending commands to the 5500A: you can enter commands from a terminal (for example, using the Terminal accessory from Windows using a PC), you can write your own programs using BASIC, or you can run optional Windows-based software such as 5500/CAL or MET/CAL. The 5500/CAL software includes more than 200 example procedures covering a wide range of test tools the 5500A can calibrate. (See Chapter 6 for a discussion of the RS-232 commands.)

The SERIAL 2 TO UUT serial data port connects a UUT to a PC or terminal via the 5500A (see Figure 2). This “pass-through” configuration eliminates the requirement for

two COM ports at the PC or Terminal. A set of four commands control the operation of the SERIAL 2 TO UUT serial port. See Chapter 6 for a discussion of the UUT_* commands.

Remote Operation (IEEE-488)

The 5500A rear panel IEEE-488 port is a fully programmable parallel interface bus meeting standard IEEE-488.1 and supplemental standard IEEE-488.2. Under the remote control of an instrument controller, the 5500A Calibrator operates exclusively as a “talker/listener.” You can write your own programs using the IEEE-488 command set or run the optional Windows-based MET/CAL software. (See Chapter 6 in the Operator Manual for a discussion of the commands available for IEEE-488 operation.)

The 5500A Calibrator can supply lethal voltages. Read this section before operating the calibrator.

Warning

Multi-Product Calibrator

Preparing for Operation

5500A

SERIAL 2

TO UUT port

SERIAL 1 FROM HOST port

RS-232 Remote Operation using the

SERIAL 1 FROM HOST port

5500A

RS-232 Remote Operation using the

SERIAL 1 FROM HOST and

SERIAL 2 TO UUT ports

COM port

PC or Terminal

COM port

PC or Terminal

Unit Under Test

Figure 2. RS-232 Remote Connections

Preparing for Operation

The following paragraphs provide instructions for unpacking and installing the 5500A, selecting the line voltage, replacing the fuse, and connecting to line power. Instructions for cable connections other than line power can be found in the following chapters of the Operator Manual:

• UUT (Unit Under Test) connections: Chapter 4, “Front Panel Operation”

• IEEE-488 parallel interface connection: Chapter 5, “Remote Operation”

• RS-232C serial interface connection: Chapter 5, “Remote Operation”

• Auxiliary amplifier connections: Chapter 4, “Front Panel Operation”

Unpacking and Inspection

The calibrator is shipped in a container designed to prevent damage during shipping. Inspect the calibrator carefully for damage and immediately report any damage to the shipper. Instructions for inspection and claims are included in the shipping container.

When you unpack the calibrator, check for all the standard equipment listed in Table 1 and check the shipping order for any additional items ordered. Refer to the 5500A Operator Manual Chapter 9, “Accessories” for more information. Report any shortage to the place of purchase or to the nearest Fluke Technical Service Center. A performance test is provided in the 5500A Operator Manual Chapter 7, “Maintenance.”

F1-02.eps

If reshipping the calibrator, use the original container. If it is not available, you can order a new container from Fluke by indicating the calibrator's model and serial number.

5500A

Getting Started

Table 1. Standard Equipment

Item Model or Part Number

Calibrator Line Power Cord 5500A CD-ROM (contains Operator and Service Manual)

5500A Getting Started Manual 5500A Operator Reference Guide 5500A Remote Programming Reference Guide

Certificate of Calibration

Replacing the Fuse

CAUTION

To prevent possible damage to the instrument, veri fy the correct fuse is installed for the sel ected line voltage setting (100 V and 120 V, use 2.5 A/250 V time delay; 200 V and 240 V, use 1.25 A/250 V time delay).

The line power fuse is accessible on the rear panel. The fuse rating is 2.5 A/250 V time delay fuse for the 100 V/120 V line voltage setting; 1.25 A/250 V time delay fuse for the 220 V/240 V line voltage setting. Fuses that are not user replaceable are discussed in

Chapter 7, “Maintenance.” To check or replace the fuse, refer to Figure 4 and proceed as follows:

1. Disconnect line power.

2. Open the fuse compartment by inserting a screwdriver blade in the tab located at the

left side of the compartment and gently pry until it can be removed with the fingers.

5500A See Table 2 1627768 945159 945097 105783 Form G749

3. Remove the fuse from the compartment for replacement or verification. Be sure the

correct fuse is installed.

4. Reinstall the fuse compartment by pushing it back into place until the tab locks.

Selecting Line Voltage

The calibrator arrives from the factory configured for the line voltage normally appropriate for the country of purchase, or as specified at the time of your purchase order. You can operate the 5500A Calibrator from one of four line voltage settings: 100 V, 120 V, 200 V, and 240 V (47 to 63 Hz). To check the line voltage setting, note the voltage setting visible through the window in the power line fuse compartment cover (Figure 4). The allowed line voltage variation is 10% above or below the line voltage setting.

To change the line voltage setting, complete the following procedure:

1. Remove the fuse compartment by following the first two steps in “Replacing the

Fuse” earlier in this manual.

2. Remove the line voltage selector assembly by gripping the line voltage indicator tab

with pliers and pulling it straight out of its connector.

3. Rotate the line voltage selector assembly to the desired voltage and reinsert.

4. Verify the appropriate fuse for the selected line voltage (100 V/120 V, use

2.5 A/250 V time delay; 220 V/240 V, use 1.25 A/250 V time delay) and reinstall the fuse compartment by pushing it back into place until the tab locks.

Connecting to Line Power

To avoid shock hazard, connect the factory supplied threeconductor line power cord to a properly grounded power outlet. Do not use a two-conductor adapter or extension cord; this will break the protective ground connection.

Use the rear-panel ground terminal for a protective grounding wire if there is any question as t o i nstrument earth grounding.

The calibrator is shipped with the appropriate line power plug for the country of purchase. If you need a different type, refer to Table 2 and Figure 3 for a list and illustration of the line power plug types available from Fluke.

After you verify that the line voltage selection is set correctly and that the correct fuse for that line voltage is installed, connect the calibrator to a properly grounded threeprong outlet.

Table 2. Line Power Cord Types Available from Fluke

Type Voltage/Current Fluke Option Number

Multi-Product Calibrator

Connecting to Line Power

Warning

North America North America Universal Euro United Kingdom Switzerland Australia South Africa

LC-1 LC-2 LC-3 LC-4

120 V/15 A 240 V/15 A 220 V/16 A 240 V/13 A 220 V/10 A 240 V/10 A 240 V/5 A

LC-1 LC-2 LC-3 LC-4 LC-5 LC-6 LC-7

LC-5 LC-6 LC-7

Figure 3. Line Power Cord Types Available from Fluke

F2-02.eps

5500A

Getting Started

MAINS SUPPLY

100V 220V

/120V /240V

FUSE

T2.5A 250V

T1.25A 250V

CAUTION

(SB)

REPLACE ONLY WITH A 250V FUSE OF INDICATED RATING

(SB)

FOR FIRE PROTECTION

47Hz 300VA MAX

/ 63Hz

CHANGING LINE FUSE

(SB)

240

120

LINE VOLTAGE INDICATOR

120

CHANGING LINE VOLTAGE

F2-01.eps

Figure 4. Accessing the Fuse and Selecting Line Voltage

Service Information

Each Model 5500A Calibrator is warranted to the original purchaser for a period of 1 year beginning on the date received. The warranty is located at the front of this manual.

To locate an authorized service center, call Fluke using any of the phone numbers listed below, or visit us on the World Wide Web: www.fluke.com

USA: 1-888-99-FLUKE (1-888-993-5853) Canada: 1-800-36-FLUKE (1-800-363-5853) Europe: +31 402-675-200 Japan: +81-3-3434-0181 Singapore: +65-738-5655 Anywhere in the world: +1-425-446-5500

Or, visit Fluke’s Web site at www.fluke.com. To register your product, visit register.fluke.com.

After-warranty service is available, but you may choose to repair the calibrator using the information in the Troubleshooting Chapter of the 5500A Service Manual and the Module Exchange Program. Refer to the Fluke catalog or contact a Technical Service Center representative for the module exchange procedure.

Multi-Product Calibrator

Service Information

Placement and Rack Mounting

You may place the calibrator on a bench top or mount it in a standard-width, 24-inch (61-cm) deep equipment rack. For bench-top use, the calibrator is equipped with nonslipping, non-marring feet. To mount the calibrator in an equipment rack, use the 5500A Rack Mount Kit, Model Y5537. Instructions for rack mounting the calibrator are packed with the rack mount kit.

Cooling Considerations

Warning

To avoid risk of injury, never operate or power the 5500A Calibrator without the fan fil t er i n pl ace.

CAUTION

Damage caused by overheating may occur if the area around the air intake is restricted, the int ake ai r i s t oo w arm, or t he air filter becomes clogged.

Baffles direct cooling air from the fan throughout the chassis to internally dissipate heat during operation. The accuracy and dependability of all internal parts of the calibrator are enhanced by maintaining the coolest possible internal temperature. You can lengthen the life of the calibrator and enhance its performance by observing the following rules:

• The area around the air filter must be at least 3 inches from nearby walls or rack

enclosures.

• The exhaust perforations on the sides of the calibrator must be clear of obstructions.

• The air entering the instrument must be at room temperature: make sure the exhaust

air from another instrument is not directed into the fan inlet.

• Clean the air filter every 30 days or more frequently if the calibrator is operated in a

dusty environment. (See the 5500A Operator Manual Chapter 7, “Maintenance” for

instructions on cleaning the air filter.)

5500A

Getting Started

5725A Amplifier

The Fluke 5725A Amplifier (Figure 5) is an external unit operating under 5500A control to extend the Volts x Hertz and voltage compliance of the calibrator. The amplifier adds the following capabilities with no compromise in accuracy:

Frequency Increase to 100 kHz at 750 V, 30 kHz at 1020 V. AC Voltage Load limit extended to 70 mA for frequencies above 5 kHz, and to 50 mA

for frequencies less than 5 kHz. Capacitive drive increases to 1020 pF, subject to the maximum output current, for volts ac.

AC Current 11 A load limit extended to 10 kHz, with a 3-volt drive compliance. A separate set of binding posts on the front panel of the 5725A supplies extended

capability. Since most meters have a separate input terminal for the high current ranges, this eliminates the need to change cables during a procedure.

Figure 5. 5725A Amplifier

F1-03.eps

Connecting the 5725A Amplifier

The 5500A provides an interface connection for the Fluke 5725A Amplifier. You designate whether the 5500A or 5725A is the preferred source of current and voltage in a calibrator setup menu (see 5500A Operator Manual Chapter 4, “Front Panel Operation”).

A single connection cable provides the complete link for analog and digital control signals. Refer to the 5725A Instruction Manual for installation instructions (a copy is provided on the CD-ROM you received with your 5500A).

Specifications

The following paragraphs describe the details for the 5500A specifications. All specifications are valid after allowing a warm-up period of 30 minutes, or twice the time the 5500A has been turned off. (For example, if the 5500A has been turned off for 5 minutes, the warm-up period is 10 minutes.)

All specifications apply for the temperature and time period indicated. For temperatures outside of tcal + 5°C (tcal is the ambient temperature when the 5500A was calibrated), the temperature coefficient is less than 0.1 times the 90-day specifications per °C (limited to 0°C - 50°C). These specifications also assume the 5500A Calibrator is zeroed every seven days or when the ambient temperature changes more than 5°C. (See

“Zeroing the Calibrator” in Chapter 4 of the Operator Manual.) Also see additional specifications later in this chapter for information on extended

specifications for ac voltage and current. The dimensional outline for the 5500A Calibrator is shown in Figure 6.

Multi-Product Calibrator

Specifications

43.2 cm (17 in)

NORMAL AUX

V, ,

RTD

1000V

RMS MAX

20V PK

MAX

5500A

1V PK

MAX

CALIBRATOR

A, -SENSE,

AUX V

SCOPE

200V PK

MAX

STBY

OPR EARTH SCOPE BOOST MENU

20V RMS MAX

TRIG OUT

20V PK

MAX

789

456

123

0•

npW

SHIFT

dBm sec

VHz

¡F

¡CA

ENTER

SETUP

NEW REF

MEAS

MULTxDIV

RESET

EDIT

FIELD

TRIG

OUT

POWER

(7 in)

17.8 cm

47.0 cm (18.5 in) 6.4 cm (2.5 in)

For Cable

Access

Figure 6. 5500A Calibrator Dimensional Outline

F1-04.eps

5500A

Getting Started

General Specifications

Warmup Time Twice the time since last warmed up, to a maximum of 30 minutes Settling Time 5 seconds typical for all functions and ranges Internal Diagnostics Comprehensive analog and digital self-tests on demand. Self-tests are

valid after warm-up time.

Standard Interfaces IEEE-488 (GPIB), RS-232, 5725A Amplifier Temperature Performance Operating: 0°C to 50°C

Calibration (tcal): 15°C to 35°C Storage: -20°C to 70°C

Electromagnetic Compatibility

Temperature Coefficient Temperature Coefficient for temperatures outside tcal +5°C is 0.1X/°C of

Relative Humidity Operating: <80% to 30°C, <70% to 40°C,<40% to 50°C

Altitude Operating: 3,050 m (10,000 ft) maximum

Safety Designed to comply with IEC 1010-1 (1992-1); ANSI/ISA-S82.01-1994;

Analog Low Isolation 20V EMI/RFI Designed to comply with FCC Rules Part 15; VFG 243/1991 Line Power Line Voltage (selectable): 100 V, 120 V, 220 V, 240 V

Designed to operate in Standard Laboratory environments where the Electromagnetic environment is highly controlled. If used in areas with Electromagnetic fields of 1 to 3 V/m, resistance outputs have a floor adder of 0.508 Ω. Performance not specified above 3 V/m.

the 90-day specification (or 1-year, as applicable).

Storage: <95%, noncondensing

Nonoperating: 12,200 m (40,000 ft) maximum

CAN/CSA-C22.2 No. 1010.1-92

Line Frequency: 47 to 63 Hz Line Voltage Variation: +10% about line voltage setting

Power Consumption 5500A Calibrator, 300 VA; 5725A Amplifier, 750 VA Dimensions

Weight 5500A Calibrator:

5500A Calibrator:

Height, 17.8 cm (7 inches), standard rack increment, plus 1.5 cm (0.6 inch) for feet on bottom of unit; Width, 43.2 cm (17 inches), standard rack width Depth, 47.3 cm (18.6 inches) overall.

5725A Amplifier:

Height, 13.3 cm (5.25 inches) Width, 43.2 cm (17 inches), standard rack width Depth, 63.0 cm (24.8 inches) overall.

20 kg (44 pounds)

5725A Amplifier:

32 kg (70 pounds)

DC Voltage Specifications

Multi-Product Calibrator

Specifications

Absolute Uncertainty, tcal + 5°C Stability

Ranges

0 to 329.9999 mV 0.005% 3 µV 0.006% 3 µV 5 ppm + 1 µV0.1 µV 50 Ω 0 to 3.299999 V 0.004% 5 µV 0.005% 5 µV 4 ppm + 3 µV1 µV 10 mA 0 to 32.99999 V 0.004% 50 µV 0.005% 50 µV 4 ppm + 30 µV 10 µV 10 m A 30 to 329.9999 V 0.0045% 500 µV 0.0055% 500 µV 4.5 ppm + 300 µV 100 µV5 mA 100 to 1020.000 V 0.0045% 1500 µV 0.0055% 1500 µV 4.5 ppm + 900 µV 1000 µV5 mA

+ (% of output + µV)

90 days 1 year

24 hours, + 1°C

+ (ppm output + µV)

Resolution

Maximum

Burden

[1]

Auxiliary Output (dual output mode only) [2]

0 to 329.999 mV

0.33 to 3.3 V 0.03% 350

[1] Remote sensing is not provided. Out put resistance is < 5 mΩ for outputs > 0.33 V. The AUX output has an output

resistance of < 1Ω.

[2] Two channels of dc voltage output are provided.

0.03% 350

µV

0.04% 350 µV

30 ppm + 100 µV1 µV5 mA

30 ppm + 100 µV 10 µV5 mA

Noise

Ranges Bandwidth

0.1 to 10 Hz

Bandwidth

10 to 10 kHz

p-p rms

+ (ppm output + µV) µV

0 to 329.9999 mV 1 µV4 µV 0 to 3.299999 V 10 µV 50 µV 0 to 32.99999 V 100 µV 600 µV 30 to 329.9999 V 10 ppm + 1 mV 20 mV 100 to 1020.000 V 10 ppm + 5 mV 20 mV

Auxiliary Output (dual output mode only) [1]

0 to 329.999 mV 5 µV 20 µV

0.33 to 3.3 V 20 µV 200 µV [1] Two channels of dc voltage output are provided.

5500A

Getting Started

DC Current Specifications

Ranges

Absolute Uncertainty, tcal + 5°C

+ (% of output + µA)

90 days 1 year

Resolution Voltage Inductive

Compliance Maximum

Load

0 to 3.29999 mA 0.010% 0.05 µA 0.013% 0.05 µA 0.01 µA 4.5 V 1 µH 0 to 32.9999 mA 0.008% 0.25 µA 0.01% 0.25 µA0.1 µA 4.5 V 200 µH 0 to 329.999 mA 0.008% 3.3 µA 0.01% 3.3 µA1 µA 4.5 to 3.0 V [1] 200 µH 0 to 2.19999 A 0.023% 44 µA 0.03% 44 µA 10 µA 4.5 to 3.4 V [2] 200 µH 0 to 11 A 0.038% 330 µA 0.06% 330 µA 100 µA 4.3 to 2.5 V [3] 200 µH

5725A Amplifier

0 to 11 A 0.03% 330 µA 0.04% 330 µA 100 µA 4 V 400 µH

[1]The actual voltage compliance (Vc) is a function of current output (lo), and is given by the formula

= -5.05*lo+4.67. The highest compliance voltage is limited to 4.5 V.

[2] The actual voltage compliance (V

= -0.588*lo+4.69. The highest compliance voltage is limited to 4.5 V.

[3] The actual voltage compliance (V

= -0.204*lo+4.75. The highest compliance voltage is limited to 4.3 V.

) is a function of current output (lo), and is given by the formula

Noise

Ranges

Bandwidth

0.1 to 10 Hz

Bandwidth

10 to 10 kHz

p-p rms

0 to 3.29999 mA 20 nA 200 nA 0 to 32.9999 mA 200 nA 2.0 µA 0 to 329.999 mA 2000 nA 20 µA 0 to 2.19999 A 20 µA1 mA 0 to 11 A 200 µA 10 mA

5725A Amplifier

0 to 11 A + 25 ppm of output + 200 nA 2 mA

Multi-Product Calibrator

Specifications

Resistance Specifications

Absolute Uncertainty, tcal + 5°C

Ranges

[1]

+ (% of output + Ω) [2]

Resolution

90 days 1 year [4]

0 to 10.99 Ω 0.009% 0.008 Ω [3] 0.012% 0.008Ω [3] 0.001 Ω 1 to 125 mA 11 to 32.999 Ω 0.009% 0.015 Ω [3] 0.012% 0.015 Ω [3] 0.001 Ω 1 to 125 mA 33 to 109.999 Ω 0.007% 0.015 Ω [3] 0.009% 0.015 Ω [3] 0.001 Ω 1 to 70 mA 110 to 329.999 Ω 0.007% 0.015 Ω [3] 0.009% 0.015 Ω [3] 0.001 Ω 1 to 40 mA 330Ω to 1.09999 kΩ 0.007% 0.06 Ω 0.009% 0.06Ω 0.01 Ω 250 µA to 18 mA

1.1 to 3.29999 kΩ 0.007% 0.06 Ω 0.009% 0.06 Ω 0.01 Ω 250 µA to 5 mA

3.3 to 10.9999 kΩ 0.007% 0.6 Ω 0.009% 0.6 Ω 0.1 Ω 25 µA to 1.8 mA 11 to 32.9999 kΩ 0.007% 0.6 Ω 0.009% 0.6 Ω 0.1 Ω 25 µA to 0.5 mA 33 to 109.999 kΩ 0.008% 6 Ω 0.011% 6 Ω 1 Ω 2.5 µA to 0.18 mA 110 to 329.999 kΩ 0.009% 6 Ω 0.012% 6 Ω 1 Ω 2.5 µA to 0.05 mA 330 k to 1.09999 MΩ 0.011% 55 Ω 0.015% 55 Ω 10 Ω 250 nA to 0.018 mA

1.1 to 3.29999 MΩ 0.011% 55 Ω 0.015% 55 Ω 10 Ω 250 nA to 5 µA

3.3 to 10.9999 MΩ 0.045% 550 Ω 0.06% 550 Ω 100 Ω 25 nA to 1.8 µA 11 to 32.9999 MΩ 0.075% 550 Ω 0.1% 550 Ω 100 Ω 25 nA to 0.5 µA 33 to 109.999 MΩ 0.4% 5.5 kΩ 0.5% 5.5 kΩ 1000 Ω 2.5 nA to 0.18 µA 110 to 330 MΩ 0.4% 16.5 kΩ 0.5% 16.5 kΩ 1000 Ω 2.5 nA to 0.06 µA [1] Continuously variable from 0 to 330 MΩ. [2] Applies for COMP OFF (to the 5500A Calibrator front panel NORMAL terminals) and 2-wire and 4-wire

compensation.

[3] The floor adder is improved to 0.006 Ω (0 to 10.99 Ω range) and 0.010 Ω (11 to 329.999 Ω) if the 5500A

Calibrator is zeroed (ohms zero or instrument zero) within 8 hours and temperature is +1°C of zeroing ambient temperature.

[4] Do not exceed the largest current for each range. For currents lower than shown, the floor adder increases

by Floor

(new)

= Floor

(old)

x I

min/Iactual

. For example, a 100 µA stimulus measuring 100 Ω has a floor uncertainty

of 0.01 Ω x 1 mA/100 µA = 0.1 Ω.

Allowable Current

Ranges Maximum Voltage [1] Maximum Lead Resistance [2]

0 to 10.99 Ω 1.37 V <3.2 Ω 11 to 32.999 Ω 4.1 V <3.2 Ω 33 to 109.999 Ω 7.7 V <3.2 Ω 110 to 329.999 Ω 13.2 V <3.2 Ω 330Ω to 1.09999 kΩ 19.8 V <6 Ω

1.1 to 3.29999 kΩ 16.5 V <6 Ω

3.3 to 10.9999 kΩ 19.8 V <6 Ω 11 to 32.9999 kΩ 16.5 V <6 Ω 33 to 109.999 kΩ 19.8 V <6 Ω 110 to 329.999 kΩ 16.5 V (n/a 110 kΩ and above) 330 kΩ to 1.09999 MΩ 19.8 V (n/a 110 kΩ and above)

1.1 to 3.29999 MΩ 16.5 V (n/a 110 kΩ and above)

3.3 to 10.9999 MΩ 19.8 V (n/a 110 kΩ and above) 11 to 32.9999 MΩ 16.5 V (n/a 110 kΩ and above) 33 to 109.999 MΩ 19.8 V (n/a 110 kΩ and above) 110 to 330 MΩ 19.8 V (n/a 110 kΩ and above) [1] This is for the largest resistance for each range. The maximum voltage for other values is Imax (highest

value of Allowable Current above) multiplied by Rout.

[2] Maximum lead resistance for no additional error in 2-wire COMP.

5500A

Getting Started

AC Voltage (Sinewave) Specificat ions

1.0 to 32.999 mV 10 to 45 Hz 0.26% 20 µV 0.35% 20 µV1 µV 50 Ω

33 to 329.999 mV 10 to 45 Hz 0.19% 50 µV 0.25% 50 µV1 µV 50 Ω

0.33 to 3.29999 V 10 to 45 Hz 0.11% 250 µV 0.15% 250 µV 10 µV 10 mA

3.3 to 32.9999 V 10 to 45 Hz 0.11% 2500 µV 0.15% 2500 µV 100 µV 10 mA

33 to 329.999 V 45 Hz to 1 kHz 0.04% 6.6 mV 0.05% 6.6 mV 1 mV 5 mA, except

330 to 1020 V 45 Hz to 1 kHz 0.04% 80 mV 0.05% 80 mV 10 mV 2 mA, except

10 to 329.999 mV 10 to 20 Hz 0.15 370 µV 0.2 370 µV1 µV5 mA

0.33 to 3.29999 V 10 to 20 Hz 0.15 450 µV 0.2 450 µV 10 µV5 mA

[1] Remote sensing is not provided. Output resistance is < 5 mΩ for outputs > 0.33 V. The AUX output

[2] There are two channels of voltage output. The maximum frequency of the dual output is 10 kHz.

Ranges Frequency

Absolute Uncertainty, tcal + 5°C

+ (% of output + µV) Resolution

Maximum

Burden

90 days 1 year [1]

45 Hz to 10 kHz 0.11% 20 µV 0.15% 20 µV 10 to 20 kHz 0.15% 20 µV 0.2% 20 µV 20 to 50 kHz 0.19% 20 µV 0.25% 20 µV 50 to 100 kHz 0.26% 33 µV 0.35% 33 µV 100 to 500 kHz 0.75% 60 µV 1% 60 µV

45 Hz to 10 kHz 0.04% 20 µV 0.05% 20 µV 10 to 20 kHz 0.08% 20 µV 0.1% 20 µV 20 to 50 kHz 0.12% 40 µV 0.16% 40 µV 50 to 100 kHz 0.17% 170 µV 0.24% 170 µV 100 to 500 kHz 0.53% 330 µV 0.7% 330 µV

45 Hz to 10 kHz 0.02% 60 µV 0.03% 60 µV 10 to 20 kHz 0.06% 60 µV 0.08% 60 µV 20 to 50 kHz 0.10% 300 µV 0.14% 300 µV 50 to 100 kHz 0.17% 1700 µV 0.24% 1700 µV 100 to 500 kHz 0.38% 3300 µV 0.5% 3300 µV

45 Hz to 10 kHz 0.03% 600 µV 0.04% 600 µV 10 to 20 kHz 0.06% 2600 µV 0.08% 2600 µV 20 to 50 kHz 0.14% 5000 µV 0.19% 5000 µV 50 to 100 kHz 0.17% 17000 µV 0.24% 17000 µV

1 to 10 kHz 0.06% 15 mV 0.08% 15 mV 20 mA for 10 to 20 kHz 0.07% 33 mV 0.09% 33 mV 45 to 65 Hz

1 to 5 kHz 0.15% 100 mV 0.20% 100 mV 6 mA for 5 to 10 kHz 0.15% 500 mV 0.20% 500 mV 45 t o 65 Hz

5725A Amplifier

100 to 1020 V 45 Hz to 1 kHz 0.04 80 mV 0.05 80 mV 10 m V 50 mA

1 to 20 kHz 0.06 100 mV 0.08 100 mV 10 mV 70 mA 20 to 30 kHz 0.08 100 mV 0. 10 100 mV 10 mV 70 mA

100 to 750 V 30 to 100 kHz 0.38 500 mV 0.5 500 mV 10 mV 70 mA

Auxiliary Output [dual output mode only] [2]

20 to 45 Hz 0.08 370 µV 0.1 370 µV 45 Hz to 1 kHz 0.08 370 µV 0.1 370 µV 1 to 5 kHz 0.15 450 µV 0.2 450 µV 5 to 10 kHz 0.3 450 µV 0.4 450 µV

20 to 45 Hz 0.08 450 µV 0.1 450 µV 45 Hz to 1 kHz 0.07 450 µV 0.09 450 µV 1 to 5 kHz 0.15 1400 µV 0.2 1400 µV 5 to 10 kHz 0.3 1400 µV 0.4 1400 µV

resistance is < 1 Ω. The maximum load capacitance is 500 pF, subject to the maximum burden current limits.

AC Voltage (Sinewave) Specificat ions (cont)

Maximum Distortion and Noise

Ranges Frequency

1.0 to 32.999 mV 10 to 45 Hz 0.15% + 90 µV 45 Hz to 10 kHz 0.035% + 90 µV 10 to 20 kHz 0.06% + 90 µV 20 to 50 kHz 0.15% + 90 µV 50 to 100 kHz 0.25% + 90 µV 100 to 500 kHz 0.3% + 90 µV

33 to 329.999 mV 10 to 45 Hz 0.15% + 90 µV

45 Hz to 10 kHz 0.035% + 90 µV 10 to 20 kHz 0.06% + 90 µV 20 to 50 kHz 0.15% + 90 µV 50 to 100 kHz 0.20% + 90 µV 100 to 500 kHz 0.20% + 90 µV

0.33 to 3.29999 V 10 to 45 Hz 0.15% + 200 µV 45 Hz to 10 kHz 0.035% + 200 µV 10 to 20 kHz 0.06% + 200 µV 20 to 50 kHz 0.15% + 200 µV 50 to 100 kHz 0.20% + 200 µV 100 to 500 kHz 0.20% + 200 µV

3.3 to 32.9999 V 10 to 45 Hz 0.15% + 2 mV 45 Hz to 10 kHz 0.035% + 2 mV 10 to 20 kHz 0.08% + 2 mV 20 to 50 kHz 0.2% + 2 mV 50 to 100 kHz 0.5% + 2 mV

33 to 329.999 V 45 Hz to 1 kHz 0.15% + 10 mV

1 to 10 kHz 0.05% + 10 mV 10 to 20 kHz 0.6% + 10 mV

330 to 1020 V 45 Hz to 1 kHz 0.15% + 30 mV

1 to 10 kHz 0.07% + 30 mV

10 Hz to 5 MHz Bandwidth

+ (% output + µV)

Multi-Product Calibrator

Specifications

5725A Amplifier

100 to 1020 V 45 Hz to 1 kHz 0.07%

1 to 20 kHz 0.15% 20 to 30 kHz 0.3%

100 to 750 V 30 to 100 kHz 0.4%

Auxiliary Output [dual output mode only] 10 Hz to 100 kHz Bandwidth

10 to 329.999 mV 10 to 20 Hz 0.2% + 200 µV

20 to 45 Hz 0.06% + 200 µV 45 Hz to 1 kHz 0.08% + 200 µV 1 to 5 kHz 0.3% + 200 µV 5 to 10 kHz 0.6% + 200 µV

0.33 to 3.29999 V 10 to 20 Hz 0.2% + 200 µV 20 to 45 Hz 0.06% + 200 µV 45 Hz to 1 kHz 0.08% + 200 µV 1 to 5 kHz 0.3% + 200 µV 5 to 10 kHz 0.6% + 200 µV

5500A

Getting Started

AC Current (Sinewave) Specificati ons

0.029 to 10 to 20 Hz 0.19% 0.15 µA 0.25% 0.15 µA 0.01 µA 3.0 V rms 1 µH

0.32999 mA 20 to 45 Hz 0.09% 0.15 µA 0.125% 0.15 µA

0.33 to 10 to 20 Hz 0.15% 0.3 µA 0.2% 0.3 µA 0.01 µA 3.0 V rms 1 µH

3.2999 mA 20 to 45 Hz 0.08% 0.3 µA 0.1% 0.3 µA

3.3 to 10 to 20 Hz 0.15% 3 µA0.2% 3 µA0.1 µA 3.0 V rms 200 µH,

32.999 mA 20 to 45 Hz 0.08% 3 µA0.1% 3 µA 10 to 500 Hz

Ranges Frequency

45 Hz to 1 kHz 0.09% 0.25 µA 0.125% 0.25 µA 1 to 5 kHz 0.30% 0.15 µA 0.4% 0.15 µA 5 to 10 kHz 0.94% 0.15 µA 1.25% 0.15 µA

45 Hz to 1 kHz 0.08% 0.3 µA 0.1% 0.3 µA 1 to 5 kHz 0.15% 0.3 µA 0.2% 0.3 µA 5 to 10 kHz 0.45% 0.3 µA 0.6% 0.3 µA

45 Hz to 1 kHz 0.07% 3 µA 0.09% 3 µA 1 to 5 kHz 0.15% 3 µA0.2% 3 µA1 µH, 5 to 10 kHz 0.45% 3 µA0.6% 3 µA 500 Hz t o 10 kHz

Absolute Uncertainty, tcal + 5°C

+ (% of output + µA) Resolution Compliance

Maximum

Inductive

90 days 1 year Voltage Load

33 to 10 to 20 Hz 0.15% 30 µA 0.2% 30 µA1 µA 3.0 to 2.0 V rms 200 µH,

329.99 mA 20 to 45 Hz 0.08% 30 µA 0.1% 30 µA [ 1] 10 to 500 Hz 45 Hz to 1 kHz 0.07% 30 µA 0.09% 30 µA 1 to 5 kHz 0.15% 30 µA 0.2% 30 µA5 µH, 5 to 10 kHz 0.45% 30 µA 0.6% 30 µA 500 Hz to 10 kHz

0.33 to

2.19999 A

2.2 to 11 A 45 to 65 Hz 0.05% 2000 µA 0.06% 2000 µA 100 µA 2.8 to 1.25 V rms 200 µH,

1.5 to 11 A 45 to 1 kHz 0.08% 100 µA 0.1% 100 µA 100 µA 3.0 V rms 400 µH

10 to 45 Hz 45 Hz to 1 kHz 1 to 5 kHz 0.7% 300 µA 0.75% 300 µA5 µH,

65 to 500 Hz 0.08% 2000 µA 0.10% 2000 µA [3] 45 to 65 Hz 500 Hz to 1 kHz 0.25% 2000 µA 0.33% 2000 µA1 µH,

1 to 5 kHz 0.19% 5000 µA 0.25% 5000 µA 5 to 10 kHz 0.75% 10000 µA 1% 10000 µA

0.15% 300 µA 0.2% 300 µA 10 µA 3.0 to 2.0 V rms 200 µH,

0.08% 300 µA 0.1% 300 µA[2]

5725A Amplifier

45 to 500 Hz

500 Hz to 5 kHz

65 Hz to 1 kHz

[1] The actual voltage compliance (Vc) is a function of current output (lo), and is given by the formula

= -3.37*lo+3.11. The highest compliance voltage is limited to 3.0 V.

[2] The actual voltage compliance (V

= -0.535*lo+3.18. The highest compliance voltage is limited to 3.0 V.

[3] The actual voltage compliance (V

= -0.176*lo+3.19. The highest compliance voltage is limited to 2.8 V.

) is a function of current output (lo), and is given by the formula

Note

1. 0.30 mA - 2.19999 A can be sent from the 5500A Calibrator to the 5725A Amplifier front panel terminals. 0.30 mA - 32.999 mA is simultaneously available at the 5500A AUX terminals when sent from the 5500A Calibrator to the 5725A Amplifier front panel terminals

AC Current (Sinewave) Specificati ons (cont)

Maximum Distortion and Noise

10 Hz to 100 kHz

Ranges Frequency

0.02 to 0.32999 mA 10 to 20 Hz 0.15% + 1.0 µA 20 to 45 Hz 0.1% + 1.0 µA 45 Hz to 1 kHz 0.05% + 1.0 µA 1 to 5 kHz 0.5% + 1.0 µA 5 to 10 kHz 1.0% + 1.0 µA

0.33 to 3.2999 mA 10 to 20 Hz 0.15% + 1.5 µA 20 to 45 Hz 0.06% + 1.5 µA 45 Hz to 1 kHz 0.02% + 1.5 µA 1 to 5 kHz 0.5% + 1.5 µA 5 to 10 kHz 1.2% + 1.5 µA

3.3 to 32.999 mA 10 to 20 Hz 0.15% + 5 µA 20 to 45 Hz 0.05% + 5 µA 45 Hz to 1 kHz 0.07% + 5 µA 1 to 5 kHz 0.3% + 5 µA 5 to 10 kHz 0.7% + 5 µA

Bandwidth

+ (% output + µA)

Multi-Product Calibrator

Specifications

33 to 329.99 mA 10 to 20 Hz 0.15% + 50 µA

20 to 45 Hz 0.05% + 50 µA 45 Hz to 1 kHz 0.07% + 50 µA 1 to 5 kHz 0.2% + 50 µA 5 to 10 kHz 0.7% + 50 µA

0.33 to 2.19999 A

2.2 to 11 A 45 to 65 Hz 0.2% + 5 mA

1.5 to 11 A 45 Hz to 1 kHz 0.05% + 1 m A

10 to 45 Hz 0.2% + 500 µA 45 Hz to 1 kHz 0.1% + 500 µA 1 to 5 kHz 1.4% + 500 µA

65 to 500 Hz 0.1% + 5 mA 500 Hz to 1 kHz 0.4% + 5 mA

5725A Amplifier

1 to 5 kHz 0.12% + 1 mA 5 to 10 kHz 0.5% + 1 mA

5500A

Getting Started

Capacitance Specifications

Absolute Uncertainty, tcal + 5°C

Ranges

0.33 to 0.4999 ηF 0.38% 0.01 ηF 0.5% 0.01 ηF 0.1 pF 50 to 1000 Hz 10 kHz

0.5 to 1.0999 ηF 0.38% 0.01 ηF 0.5% 0.01 ηF 0.1 pF 50 to 1000 Hz 10 kHz

1.1 to 3.2999 ηF 0.38% 0.01 ηF 0.5% 0.01 ηF 0.1 pF 50 to 1000 Hz 10 kHz

3.3 to 10.999 ηF 0.38% 0.01 ηF 0.5% 0.01 ηF 1 pF 50 to 1000 Hz 10 kHz 11 to 32.999 ηF 0.19% 0.1 ηF 0.25% 0.1 ηF 1 pF 50 to 1000 Hz 10 kHz 33 to 109.99 ηF 0.19% 0.1 ηF 0. 25% 0.1 ηF 10 pF 50 to 1000 Hz 10 kHz 110 to 329.99 ηF 0.19% 0.3 ηF 0.25% 0.3 ηF 10 pF 50 to 1000 Hz 10 kHz

0.33 to 1.0999 µF 0.19% 1 ηF 0.25% 1 ηF 100 pF 50 to 1000 Hz 5 kHz

1.1 to 3.2999 µF 0.26% 3 ηF 0.35% 3 ηF 100 pF 50 to 1000 Hz 2 kHz

3.3 to 10.999 µF 0.26% 10 ηF 0.35% 10 ηF1 ηF 50 to 400 Hz 1.5 kHz 11 to 32.999 µF 0.30% 30 ηF 0.40% 30 ηF1 ηF 50 to 400 Hz 800 Hz 33 to 109.99 µF 0.38% 100 ηF 0.50% 100 ηF 10 ηF 50 to 200 Hz 400 Hz 110 to 329.99 µF 0.50% 300 ηF 0.70% 300 ηF 10 ηF 50 to 100 Hz 200 Hz

+ (% of output + ηF) Resolution Allowed

90 days 1 year

Frequency

Typical

Frequency

for <1%

Error

330 to 1.1 mF 1% 300 ηF 1% 300 ηF 100 ηF 50 to 100 Hz 150 Hz

Notes

1. Specifications apply to both dc charge/discharge capacitance meters and ac RCL

meters.

2. The output is continuously variable from 330 pF to 1.1 mF.

3. For all ranges, the maximum charge and discharge current is 150 mA peak or 30 mA rms. The peak voltage is 4 V, except the 330 µF - 1.1 mF range is limited to 1 V. The maximum lead resistance for no additional error in 2-wire COMP mode is 10 ohms.

Temperature Calibration (Thermocouple) Specifications

)

Absolute Uncertainty,

]

90 days

Range (°C

TC Type Minimum Maximum Source/Measure

B 600°C 800°C0.42°C0.44°C

800°C 1000°C0.34°C0.34°C 1000°C 1550°C0.30°C0.30°C 1550°C 1820°C0.26°C0.33°C

C0°C 150°C0.23°C0.30°C

150°C 650°C0.19°C0.26°C 650°C 1000°C0.23°C0.31°C 1000°C 1800°C0.38°C0.50°C 1800°C 2316°C0.63°C0.84°C

E -250°C -100°C0.38°C0.50°C

-100°C-25°C0.12°C0.16°C

-25°C 350°C0.10°C0.14°C 350°C 650°C0.12°C0.16°C 650°C 1000°C0.16°C0.21°C

J -210°C -100°C0.20°C0.27°C

-100°C-30°C0.12°C0.16°C

-30°C 150°C0.10°C0.14°C 150°C 760°C0.13°C0.17°C 760°C 1200°C0.18°C0.23°C

K -200°C -100°C0.25°C0.33°C

-100°C-25°C0.14°C0.18°C

-25°C 120°C0.12°C0.16°C 120°C 1000°C0.19°C0.26°C 1000°C 1372°C0.30°C0.40°C

L -200°C -100°C0.37°C0.37°C

-100°C 800°C0.26°C0.26°C 800°C 900°C0.17°C0.17°C

N -200°C -100°C0.30°C0.40°C

-100°C-25°C0.17°C0.22°C

-25°C 120°C0.15°C0.19°C 120°C 410°C0.14°C0.18°C 410°C 1300°C0.21°C0.27°C

R0°C 250°C0.48°C0.57°C

250°C 400°C0.28°C0.35°C 400°C 1000°C0.26°C0.33°C 1000°C 1767°C0.30°C0.40°C

S0°C 250°C0.47°C0.47°C

250°C 1000°C0.30°C0.36°C 1000°C 1400°C0.28°C0.37°C 1400°C 1767°C0.34°C0.46°C

T -250°C -150°C0.48°C0.63°C

-150°C0°C0.18°C0.24°C 0°C 120°C0.12°C0.16°C 120°C 400°C0.10°C0.14°C

U -200°C0°C0.56°C0.56°C

0°C 600°C0.27°C0.27°C

[1] Does not include thermocouple error.

Notes

1. Resolution i s 0.01°C.

2. The 10 µV/°C linear output mode has t he same uncer tainty as the 300 mV dc range.

3. Applies to both simulated thermocouple output and thermocouple measur ement.

4. Temperature standard I TS-90 or IPTS-68 is selectable.

Multi-Product Calibrator

Specifications

tcal + 5°C, + (°C) [1

1 year

5500A

Getting Started

Temperature Calibration (RTD) Specifi cat ions

RTD Type

Minimum Maximum 90 days 1 year

Pt 385, 100 Ω -200°C-80°C0.04°C0.05°C

-80°C0°C0.05°C0.05°C 0°C 100°C0.07°C0.07°C 100°C 300°C0.08°C0.09°C 300°C 400°C0.09°C0.10°C 400°C 630°C0.10°C0.12°C 630°C 800°C0.21°C0.23°C

Pt 3926, 100 Ω -200°C-80°C0.04°C0.05°C

-80°C0°C0.05°C0.05°C 0°C 100°C0.07°C0.07°C 100°C 300°C0.08°C0.09°C 300°C 400°C0.09°C0.10°C 400°C 630°C0.10°C0.12°C

Pt 3916, 100 Ω -200°C -190°C0.25°C0.25°C

-190°C-80°C0.04°C0.04°C

-80°C0°C0.05°C0.05°C 0°C 100°C0.06°C0.06°C 100°C 260°C0.06°C0.07°C 260°C 300°C0.07°C0.08°C 300°C 400°C0.08°C0.09°C 400°C 600°C0.08°C0.10°C 600°C 630°C0.21°C0.23°C

Pt 385, 200 Ω -200°C-80°C0.03°C0.04°C

-80°C0°C0.03°C0.04°C 0°C 100°C0.04°C0.04°C 100°C 260°C0.04°C0.05°C 260°C 300°C0.11°C0.12°C 300°C 400°C0.12°C0.13°C 400°C 600°C0.12°C0.14°C 600°C 630°C0.14°C0.16°C

Pt 385, 500 Ω -200°C-80°C0.03°C0.04°C

-80°C0°C0.04°C0.05°C 0°C 100°C0.05°C0.05°C 100°C 260°C0.06°C0.06°C 260°C 300°C0.07°C0.08°C 300°C 400°C0.07°C0.08°C 400°C 600°C0.08°C0.09°C 600°C 630°C0.09°C0.11°C

Range (°C) Absolute Uncertainty, tcal + 5°C, + (°C) [1]

Temperature Calibration (RTD) Specifi cations (cont.)

Multi-Product Calibrator

Specifications

RTD Type

Minimum Maximum 90 days 1 year

Pt 385, 1000 Ω -200°C-80°C0.03°C0.03°C

-80°C0°C0.03°C0.03°C 0°C 100°C0.03°C0.04°C 100°C 260°C0.04°C0.05°C 260°C 300°C0.05°C0.06°C 300°C 400°C0.05°C0.07°C 400°C 600°C0.06°C0.07°C 600°C 630°C0.22°C0.23°C

PtNi 385, 120 Ω -80°C0°C0.06°C0.08°C (Ni120) 0°C 100°C0.07°C0.08°C

100°C 260°C0.13°C0.14°C

Cu 427, 10 Ω [2] -100°C 260°C0.3°C0.3°C

[1] Applies for COMP OFF (to the 5500A Calibrator front panel NORMAL terminals) and 2-wire and 4-

wire compensation.

[2] Based on MINCO Application Aid No. 18.

Range (°C) Absolute Uncertainty, tcal + 5°C, +

(°C) [1]

Note

1. Resolution is 0.003°C.

5500A

Getting Started

DC Power Specification Summary

90 days 33 mV to 1020 V 0.03% 0.02% 0.03% 0.02% 1 year 33 mV to 1020 V 0.04% 0.03% 0.04% 0.03%

90 days 33 mV to 1020 V 0.07% 0.05% 0.08% 0.06% 1 year 33 mV to 1020 V 0.08% 0.06% 0.12% 0.09%

5500A Calibrator Current Range

Voltage Range 3.3 to 8.999 mA 9 to 32.999 mA 33 to 89.99 mA 90 to 329.99 mA

Absolute Uncertainty, tcal + 5°C, + (% of watts output)

5500A Calibrator Current Range

Voltage Range 0.33 to 0.8999 A 0.9 to 2.1999 A 2.2 to 4.4999 A 4 .5 to 11 A

Absolute Uncertainty, tcal + 5°C, + (% of watts output)

5725A Amplifier Current Range

Voltage Range 1.5 to 4.4999 A 4.5 to 11 A

Absolute Uncertainty, tcal + 5°C, + (% of watts output) 90 days 33 mV to 1020 V 0.09% 0.07% 1 year 33 mV to 1020 V 0.10% 0.08%

Note

1. To determine dc power uncertainty with more precision, see the individual “DC

Voltage Specifications” and “DC Current Specifications” and “Calculating Power Uncertainty.”

Multi-Product Calibrator

AC Power (45 Hz to 65 Hz) Specification Summary, PF=1

5500A Calibrator Current Range

Voltage Range 3.3 to 8.999 mA 9 to32.999 mA 33 to 89.99 mA 90 to 329.99 mA

Absolute Uncertainty, tcal + 5°C, + (% of watts output)

5500A Calibrator

90 days 33 to 329.999 mV 0.30% 0.20% 0.25% 0.20%

330 mV to 1020 V 0.20% 0.12% 0.20% 0.12%

1 year 33 to 329.999 mV 0.40% 0.25% 0.35% 0.25%

330 mV to 1020 V 0.25% 0.15% 0.25% 0.15%

5725A Amplifier

90 days 100 to 1020 V 0.20% 0.12% 0.20% 0.12%

1 year 100 to 1020 V 0.25% 0.15% 0.25% 0.15%

5500A Calibrator Current Range

Specifications

Voltage Range 0.33 to 0.8999 A 0.9 to 2.1999 A 2.2 to 4.4999 A 4.5 to 11 A

Absolute Uncertainty, tcal + 5°C, + (% of watts output)

5500A Calibrator

90 days 33 to 329.999 mV 0.25% 0.20% 0.25% 0.20%

330 mV to 1020 V 0.20% 0.12% 0.18% 0.12%

1 year 33 to 329.999 mV 0.35% 0.25% 0.35% 0.25%

330 mV to 1020 V 0.25% 0.15% 0.20% 0.15%

5725A Amplifier

90 days 100 to 1020 V 0.20% 0.12% 0.18% 0.12%

1 year 100 to 1020 V 0.25% 0.15% 0.20% 0.15%

5725A Amplifier Current Range

Voltage Range 1.5 to 4.4999 A 4.5 to 11 A

Absolute Uncertainty, tcal + 5°C, + (% of watts output)

5500A Calibrator

90 days 33 to 329.999 mV 0.25% 0.20%

330 mV to 1020 V 0.15% 0.12%

1 year 33 mV to 1020 V 0.35% 0.25%

330 mV to 1020 V 0.20% 0.15%

Note

1. To determine uncertainty with more precision, see “Calculating Power Uncertainty.”

5500A

Getting Started

Power and Dual Output Limit Speci f i cat ions

Frequency

DC 0 to +1020 V 0 to + 11 A 0 to + 3.3 V  10 to 45 Hz 33 mV to 32.9999 V 3.3 mA to 2.19999 A 10 mV to 3.3 V 0 to 1 45 to 65 Hz 33 mV to 1020 V 3.3 mA to 11 A 10 mV to 3.3 V 0 to 1 65 to 500 Hz 330 mV to 1020 V 33 mA to 2.19999 A 100 mV to 3.3 V 0 to 1 65 to 500 Hz 3.3V to 1020 V 33 mA to 11 A 100 mV to 3.3 V 0 to 1 500 to 1 kHz 330 mV to 1020 V 33 mA to 11 A 100 mV to 3.3 V 1 1 to 5 kHz 3.3V to 1020 V [1] 33 mA to 2.19999 A 100 mV to 3.3 V [1] 1 5 to 10 kHz 3.3V to 1020 V [2] 33 to 329.99 mA 1 to 3.3 V [2] 1 [1] In dual volts, voltage is limited to 3.3 to 500 V in the NORMAL output. [2] In dual volts, voltage is limited to 3.3 to 250 V in the NORMAL output.

Voltages

(NORMAL)

Currents

Voltages

(AUX)

Power Factor

(PF)

Notes

1. The range of voltages and currents shown in “DC Voltage Specifications,” “DC

Current Specifications,” “AC Voltage (Sinewaves) Specifications,” and “AC Current (Sinewave) Specifications” are available in the power and dual output modes (except minimum current for ac power is 0.33 mA). However, only those limits shown in this table are specified. See “Calculating Power Uncertainty” to determine the uncertainty at these points.

2. The phase adjustment range for dual ac outputs is 0 to +179.99 degrees.

3. The phase resolution for dual ac outputs is 0.02 degree.

5500A Phase Specifications

1-Year Absolute Uncertainty, tcal + 5 °C, (∆Φdegrees)

Multi-Product Calibrator

Specifications

10 to 65 Hz

0.15° [1]

65 to 500 Hz

0.9° [2]

500 to 1 kHz

2.0° [3]

1k to 5 kHz

6°

5k to 10 kHz

10°

Notes

1. For 33 to 1000 V output, burden current <6 mA. For 6 to 20 mA burden current (33 to 330 V), the phase uncertainty is 0.4°.

2. For 33 to 1000 V output, burden current <2 mA. For 2 to 5 mA burden current (33 to 330 V), the phase uncertainty is 1.5°.

3. For 33 to 1000 V output, burden current <2 mA. For 2 to 5 mA burden current (33 to 330 V), the phase uncertainty is 5°.

Phase

(Φ)

Watts VARs

0° 90° 1.000 0.00% 0.01% 0.06% 0.55% 1.52%

5° 85° 0.996 0.02% 0.15%  10° 80° 0.985 0.05% 0.29%  15° 75° 0.966 0.07% 0.43%  20° 70° 0.940 0.10% 0.58%  25° 65° 0.906 0.12% 0.74%  30° 60° 0.866 0.15% 0.92%  35° 55° 0.819 0.18% 1.11%  40° 50° 0.766 0.22% 1.33%  45° 45° 0.707 0.26% 1.58%  50° 40° 0.643 0.31% 1.88%  55° 35° 0.574 0.37% 2.26%  60° 30° 0.500 0.45% 2.73%  65° 25° 0.423 0.56% 3.38%  70° 20° 0.342 0.72% 4.33%  75° 15° 0.259 0.98% 5.87%  80° 10° 0.174 1.49% 8.92%  85° 5° 0.087 2.99% 17.97%  90° 0° 0.000  

Phase

(Φ)

10 to 65

Power Uncertainty Adder due to Phase Error

65 to 500

500 to 1

kHz

1 to 5

kHz

5 to 10

kHz

Note

1. To calculate exact ac watts power adders due to phase uncertainty for values not

Cos

()

Adder

=−

shown, use the following formula:

100 1

()

for a PF of .9205 (Φ = 23) and a phase uncertainty of

Cos

(23 )

adder is:

Adder

()

=−

Cos

()

=100 1

011%

Φ∆Φ

Cos

= 0.15, the ac watts power

∆Φ

) . For example:

()

5500A

Getting Started

Calculating Power Uncertainty

Overall uncertainty for power output in watts (or VARs) is based on the root sum square (rss) of the individual uncertainties in percent for the selected voltage, current, and power factor parameters:

UUUU

Watts uncertainty VARs uncertainty UUUU

power voltage current PFadder

VARs voltage current VARsadder

=++

Because there are an infinite number of combinations, you should calculate the actual ac power uncertainty for your selected parameters. The method of calculation is best shown in the following examples (using 90-day specifications):

Example

1 Output: 100 V, 1 A, 60 Hz, Power Factor = 1.0 (Φ=0)

Voltage Uncertainty Uncertainty for 100 V at 60 Hz is 0.04% + 6.6 mV, totaling:

100V x .0004 = 40 mV added to 6.6 mV = 46.6 mV. Expressed in percent:

46.6 mV/100 V x 100 = 0.047% (see “AC Voltage (Sinewave) Specifications”).

Current Uncertainty Uncertainty for 1 A is 0.08% + 300 µA, totaling: 1 A x .0008 = 800 µA added to 300 µA = 1.1 mA. Expressed in percent:

1.1 mA/1A x 100 = 0.11% (see “AC Current (Sinewaves) Specifications”). PF Adder Watts Adder for PF = 1 (Φ=0) at 60 Hz is 0% (see “Phase Specifications”).

Total Watts Output Uncertainty = U

power

=++=0 047 011 0 012%

.. .

Example 2 Output: 100 V, 1 A, 400 Hz, Power Factor = 0.5 (Φ=60) Voltage Uncertainty Uncertainty for 100 V at 400 Hz is 0.04% + 6.6 mV, totaling:

100 V x .0004 = 40 mV added to 6.6 mV = 46.6 mV. Expressed in percent:

46.6 mV/100 V x 100 = 0.047% (see “AC Voltage (Sinewave) Specifications”). Current Uncertainty Uncertainty for 1 A is 0.08% + 300 µA, totaling:

1 A x .0008 = 800 µA added to 300 µA = 1.1 mA. Expressed in percent:

1.1 mA/1 A x 100 = 0.11% (see “AC Current (Sinewave) Specifications”). PF Adder Watts Adder for PF = 0.5 (Φ=60) at 400 Hz is 2.73% (see “Phase Specifications”).

Total Watts Output Uncertainty = U

power

=++=0047 011 273 273%

....

VARs When the Power Factor approaches 0.0, the watts output uncertainty becomes unrealistic because the dominant characteristic is the VARs (volts-amps-reactive) output. In these cases, calculate the Total VARs Output Uncertainty, as shown in example 3:

Example 3 Output: 100 V, 1 A, 60 Hz, Power Factor = 0.0872 (Φ=85) Voltage Uncertainty Uncertainty for 100 V at 60 Hz is 0.04% + 6.6 mV, totaling:

100 V x .0004 = 40 mV added to 6.6 mV = 46.6 mV. Expressed in percent:

46.6 mV/100 V x 100 = 0.047% (see “AC Voltage (Sinewave) Specifications”). Current Uncertainty Uncertainty for 1 A is 0.08% + 300 µA, totaling:

1 A x .0008 = 800 µA added to 300 µA = 1.1 mA. Expressed in percent:

1.1 mA/1 A x 100 = 0.11% (see “AC Current (Sinewave) Specifications”). VARs Adder VARs Adder for Φ=85 at 60 Hz is 0.02% (see “Phase Specifications”).

Total VARS Output Uncertainty = U

= 0 047 011 0 02 012%

VARs

....++ =

Multi-Product Calibrator

Additional Specifications

The following paragraphs provide additional specifications for the 5500A Calibrator ac voltage and ac current functions. These specifications are valid after allowing a warm-up period of 30 minutes, or twice the time the 5500A has been turned off. All extended range specifications are based on performing the internal zero-cal function at weekly intervals, or when the ambient temperature changes by more than 5°C. (See Chapter 4,

“Front Panel Operations.”)

Frequency Specifications

Frequency Resolution 1-Year Absolute Uncertainty, Jitter

Range tcal + 5°C

.01 to 119.99 Hz .01 Hz 25 ppm, + 1 mHz 2 µs

120.0 to 1199.9 Hz 0.1 Hz 25 ppm, + 1 mHz 2 µs

1.200 to 11.999 kHz 1.0 Hz 25 ppm, + 1 mHz [1] 2 µs

12.00 to 119.99 kHz 10 Hz 25 ppm, + 15 mHz 140 ns

120.0 to 1199.9 kHz 100 Hz 25 ppm, + 15 mHz 140 ns

1.200 to 2.000 MHz 1 kHz 25 ppm, + 15 mHz 140 ns [1] ± (25 ppm + 15 mHz) above 10 kHz

5500A

Getting Started

Harmonics (2nd to 50th) Specificati ons

Fundamental

Frequency [1]

10 to 45 Hz 33 mV to 32.9999 V 3.3 mA to 2.19999 A 10 mV to 3.3 V Same % of

45 to 65 Hz 33 mV to 1020 V 3.3 mA to 11 A 10 mV to 3.3 V as the

65 to 500 Hz 33 mV to 1020 V 33 mA to 11 A 100 mV to 3.3 V single output,

500 to 1 kHz 330 mV to 1020 V 33 mA to 11 A 100 mV to 3.3 V twice the floor 1 to 5 kHz 3.3 to 1020 V 33 mA to 2.19999 A 100 mV to 3.3 V adder.

[1] The maximum frequency of the harmonic output is 10 kHz. For example, if the fundamental output is

5 kHz, the maximum selection is the 2nd harmonic (10 kHz). All harmonic frequencies (2nd to 50th) are available for fundamental outputs between 10 and 200 Hz.

Voltages

NORMAL

Terminals

Currents

Voltages

AUX Terminals

Amplitude

Uncertainty

output

equivalent

but

Note

1. Phase uncertainty for harmonic outputs is 1 degree, or the phase uncertainty shown

in “Phase Specifications” for the particular output, whichever is greater. For example, the phase uncertainty of a 400 Hz fundamental output and 10 kHz harmonic output is 10 degrees (from “Phase Specifications”). Another example, the phase uncertainty of a 60 Hz fundamental output and a 400 Hz harmonic output is 1 degree.

Example of determining Amplitude Uncertainty in a Dual Output Harmonic Mode

What are the amplitude uncertainties for the following dual outputs?

NORMAL (Fundamental) Output: 100 V, 100 Hz From “AC Voltage (Sinewave) Specifications” the single output specification for

100 V, 100 Hz, is 0.04% + 6.6 mV. For the dual output in this example, the specification is 0.04% + 13.2 mV as the 0.04% is the same and the floor is twice the value (2 x 6.6 mV).

AUX (50th Harmonic) Output: 100 mV, 5 kHz From “AC Voltage (Sinewave) Specifications” the auxiliary output specification for

100 mV, 5 kHz, is 0.15% + 450 mV. For the dual output in this example, the specification is 0.15% + 900 mV as the 0.15% is the same and the floor is twice the value (2 x 450 mV).

AC Voltage (Sinewave) Extended Bandwidt h Specifications

1-Year Absolute

Uncertainty,

Ranges Frequency

+ (% of output + % of range)

%Output %Range

Normal Channel (Single Output Mode)

1.0 to 33 mV 0.01 to 10 Hz 5.0% 0.5% Two digits, e.g., 25 mV 34 to 330 mV Three digits

0.4 to 3.3 V Two digits 4 to 33 V Two digits

10 to 500 kHz See “AC Voltage (Sinewaves) Specifications”

tcal + 5°C,

Maximum Voltage Resolution

Multi-Product Calibrator

Additional Specifications

0.3 to 3.3 V 500 to 1 MHz -8 dB at 1 MHz, typical 1 to 2 MHz -32 dB at 2 MHz, typical

Auxiliary Output (Dual Output Mode)

10 to 330 mV 0.01 to 10 Hz 5.0% 0.5% Three digits

0.4 to 3.3 V Two digits 10 to 10 kHz See “AC Voltage (Sinewaves) Specifications”

Two digits

5500A

Getting Started

AC Voltage (Non-Sinewave) Specif ications

Trianglewave & Truncated Sine

Ranges

Peak-to-Peak [1]

2.9 to 92.999 mV 0.01 to 10 Hz 5.0% 0.5% Two digits on each range 93 to 929.999 mV 10 to 45 Hz 0.25% 0.5%

0.93 to 9.29999 V 45 to 1 kHz 0.25% 0.25% Six digits on each range

9.3 to 92.9999 V 1 to 20 kHz 0.5% 0.25%

93 to 929.999 mV 10 to 45 Hz 0.25% 0.5%

0.93 to 9.29999 V 45 to 1 kHz 0.25% 0.25% Six digits on each range

[1] To convert peak-to-peak to rms for trianglewave, multiply the peak-to-peak value by 0.2886751. To

convert peak-to-peak to rms for truncated sinewave, multiply the peak-to-peak value by 0.2165063.

[2] Uncertainty is stated in peak-to-peak. Amplitude is verified using an rms-responding DMM.

Frequency

Normal Channel (Single Output Mode)

20 to 100 kHz 5.0% 0.5%

Auxiliary Output (Dual Output Mode)

0.01 to 10 Hz 5.0% 0.5% Two digits on each range

1 to 10 kHz 5.0% 0.5%

1-Year Absolute Uncertainty,

tcal + 5°C,

+ (% of output + % of range) [2]

%Output %Range

Maximum

Voltage

Resolution

1-Year Absolute Uncertainty,

Squarewave

Ranges (p-p) [1]

2.9 to 65.999 mV 0.01 to 10 Hz 5.0% 0.5% Two digits on each range 66 to 659.999 mV 10 to 45 Hz 0.25% 0.5%

0.66 to 6.59999 V 45 to 1 kHz 0.25% 0.25% Six digits on each range

6.6 to 65.9999 V 1 to 20 kHz 0.5% 0.25%

66 to 659.999 mV 10 to 45 Hz 0.25% 0.5%

0.66 to 6.59999 V 45 to 1 kHz 0.25% 0.25% Six digits on each range

[1] To convert peak-to-peak to rms for squarewave, multiply the peak-to-peak value by 0.5000000. [2] Uncertainty is stated in peak-to-peak. Amplitude is verified using an rms-responding DMM.

Frequency

Normal Channel (Single Output Mode)

20 to 100 kHz 5.0% 0.5%

Auxiliary Output (Dual Output Mode)

0.01 to 10 Hz 5.0% 0.5% Two digits on each range

1 to 10 kHz 5.0% 0.5%

+ (% of output + % of range) [2]

%Output %Range

tcal + 5°C

Maximum Voltage

Resolution

AC Voltage, DC Offset Speci f ications

Multi-Product Calibrator

Additional Specifications

Range [1]

(Normal Channel) Offset Range [2]

3.3m to 32.999 mV 0 to 50 mV 80 mV 0.1% + 33 µV

33m to 329.999 mV 0 to 500 mV 800 mV 0.1% + 330

0.33 to 3.29999 V 0 to 5 V 8 V 0.1% + 3300

3.3 to 32.9999 V 0 to 50 V 55 V 0 .1% + 33 mV

Trianglewaves and Truncated Sinewaves

9.3 to 92.999 mV p-p 0 to 50 mV 80 mV 0.1% + 93 µV

93 to 929.999 mV p -p 0 to 500 mV 800 mV 0.1% + 930

0.93 to 9.29999 V p-p 0 to 5 V 8 V 0.1% + 9300

9.3 to 92.9999 V p-p 0 to 50 V 55 V 0.1% + 93 mV

Squarewaves

6.6 to 65.999 mV p-p 0 to 50 mV 80 mV 0.1% + 66 µV

66 to 659.999 mV p-p 0 to 500 mV 800 mV 0.1% + 660

Maximum

Peak Signal

Sinewaves

1-Year Absolute Offset

Uncertainty, tcal + 5°C [3]

+ (% Output (dc) + µV)

0.66 to 6.59999 V p-p 0 to 5 V 8 V 0.1% + 6600

6.6 to 65.9999 V p-p 0 to 50 V 55 V 0.1% + 66 mV

[1] Offsets are not allowed on ranges above the highest range shown above. [2] The maximum offset value is determined by the difference between the peak value of the selected

voltage output and the allowable maximum peak signal. For example, a 10 V peak-to-peak square wave output has a peak value of 5 V, allowing a maximum offset up to +50 V to not exceed the 55 V maximum peak signal. The maximum offset values shown above are for the minimum outputs in each range.

[3] For frequencies 0.01 to 10 Hz, and 500 kHz to 2 MHz, the offset uncertainty is 5% of output, + 1% of

the offset range.

AC Voltage, Squarewave Characteristics

Risetime

@ 1 kHz

Typical

<1 µs <10 µs to 1%

Settling

Time

@ 1 kHz

Typical

of final value

Overshoot

@ 1 kHz

Typical

<2% 1% to 99%, <3.3 V p-p,

Duty Cycle Range Duty Cycle Uncertainty [1]

0.01 Hz to 100 kHz

+ (0.8% of period +140 ns) for frequencies >10 kHz; + (0.8% of period + 2 µs) for frequencies <10 kHz.

[1] For duty cycles of 10.00% to 90.00%.

5500A

Getting Started

AC Voltage, Triangle wave Characterist i cs ( t ypical)

AC Current (Sinewave) Extended Bandwidth Speci f ications

Linearity to 1 kHz Aberrations

0.3% of p-p value, from 10% to 90% point <1% of pk-to-pk value, with amplitude >50% of range

1-Year Absolute Uncertainty,

tcal + 5°C,

Ranges Frequency

All current ranges, <330 mA 0.01 - 10 Hz 5.0% 0.5% 2 digits each

10 - 10 kHz See “AC Current (Sinewave) Specifications”

+ (% of output + % of range) [2]

%Output %Range

Maximum

Current

Resolution

range

AC Current (Non-Sinewave) Specificat i ons

1-Year Absolute Uncertainty,

Trianglewave &

Truncated Sinewave

Ranges [1]

2.9 to 92.999 mA 0.01 to 10 Hz 5.0% 0.5% Two digits, e.g., 75 mA

93 to 929.999 mA 0.01 to 10 Hz 5.0% 0.5% Two digits

Frequency

10 to 45 Hz 0.25% 0.5% 45 to 1 kHz 0.25% 0.25% Six digits on each

1 to 10 kHz 5.0% 0.5%

+ (% of output + % of range) [2]

%Output %Range

tcal + 5°C,

Maximum

Current

Resolution

range

10 to 45 Hz 0.25% 0.5% 45 to 1 kHz 0.25% 0.5% Six digits on each

range

1 to 10kHz 5.0% 1.0%

0.93 to 6.19999 A 10 to 45 Hz 5.0% 1.0% Two digits 45 to 1kHz 0.5% 0.5% Six digits on each

range

1 to 5 kHz 5.0% 1.0%

6.2 to 31 A 45 to 500 Hz 2.0% 0.5% Two digits on each

range

500 to 1 kHz 5.0% 1.0% Six digits on each

range [1] All waveforms are peak-to-peak output ranges. [2] Uncertainty is stated in peak-to-peak. Amplitude is verified using an rms-responding DMM.

Multi-Product Calibrator

Additional Specifications

AC Current (Non-Sinewave) Specificat ions

1-Year Absolute Uncertainty,

Squarewave

Ranges [1]

2.9 to 65.999 mA 0.01 to 10 Hz 5.0% 0.5% Two digits, e.g., 50 mA

66 to 659.999 mA 0.01 to 10 Hz 5.0% 0.5% Two digits

Frequency

10 to 45 Hz 0.25% 0.5% 45 to 1 kHz 0.25% 0.25% Six digits on each

1 to 10 kHz 5.0% 0.5%

10 to 45 Hz 0.25% 0.5% 45 to 1 kHz 0.25% 0.5% Six digits on each

1 to 10 kHz 5.0% 1.0%

+ (% of output + % of range) [2]

%Output %Range

tcal + 5°C,

Maximum

Current

Resolution

range

0.66 to 4.39999 A 10 to 45 Hz 5.0% 1.0% Two digits 45 to 1 kHz 0.5% 0.5% Six digits on each

range

1 to 5 kHz 5.0% 1.0%

4.4 to 22 A 45 to 500 Hz 2.0% 0.5% Two digits on each

range

500 to 1 kHz 5.0% 1.0% Six digits on each

range [1] All waveforms are peak-to-peak output ranges. [2] Uncertainty is stated in peak-to-peak. Amplitude is verified using an rms-responding DMM.

AC Current, Squarewave Characteristics (typical)

Range Risetime Settling Time Overshoot

I<4.4 A @ 400 Hz 25 µs 40 µs to 1% of final value <10% for loads <100 Ω

AC Current, Trianglewave Characteristi cs ( t ypi cal)

Linearity to 400 Hz Aberrations

0.3% of p-p value, from 10% to 90% point <1% of p-p value, with amplitude >50% of range

5500A

Getting Started

Fluke 5500A Getting Started

Specifications and Main Features

Frequently Asked Questions

User Manual

LIMITED WAR RA NTY & LIMITATION OF LIABILITY

LIMITE DE GARANTIE ET LIMITE DE RESPONSABILITE

BEFRISTETE GARANTIEBESTIMMUNGEN & HAFTUNGSBESCHRÄNKUNG

GARANTÍA LIMITADA Y LIMITACIÓN DE RESPONSABILIDAD

SAFETY TERMS IN THIS MANUAL

Table of Contents

Introduction

Instruction Manuals

5500A Getting Started Manual

5500A Operator Manual

5500A Operator Reference Guide

Where to Go from Here

5500A Programmer Reference Guide

5500A Service Manual

Operation Overview

Local Operation

Remote Operation (RS-232)

Remote Operation (IEEE-488)

Preparing for Operation

Unpacking and Inspection

Replacing the Fuse

Selecting Line Voltage

Connecting to Line Power

Service Information

Placement and Rack Mounting

Cooling Considerations

5725A Amplifier

Connecting the 5725A Amplifier

Specifications

General Specifications

DC Voltage Specifications

DC Current Specifications

Resistance Specifications

AC Voltage (Sinewave) Specificat ions

AC Current (Sinewave) Specificati ons

Capacitance Specifications

Temperature Calibration (Thermocouple) Specifications

Temperature Calibration (RTD) Specifi cat ions

DC Power Specification Summary

AC Power (45 Hz to 65 Hz) Specification Summary, PF=1

Power and Dual Output Limit Speci f i cat ions

5500A Phase Specifications

Calculating Power Uncertainty

Additional Specifications

Frequency Specifications

Harmonics (2nd to 50th) Specificati ons

AC Voltage (Sinewave) Extended Bandwidt h Specifications

AC Voltage (Non-Sinewave) Specif ications

AC Voltage, DC Offset Speci f ications

AC Voltage, Squarewave Characteristics

AC Voltage, Triangle wave Characterist i cs ( t ypical)

AC Current (Sinewave) Extended Bandwidth Speci f ications

AC Current (Non-Sinewave) Specificat i ons

AC Current (Non-Sinewave) Specificat ions

AC Current, Squarewave Characteristics (typical)

AC Current, Trianglewave Characteristi cs ( t ypi cal)
