Fluke 30/32 Clamp Meters
Product Home | Features | Specifications |
Models, Options & Accessories | Manuals
Rugged, reliable
general purpose
clamp meters
The Fluke Model 30 and 32 Clamp
Meters are rugged, self-contained,
general purpose clamp meters that
measure up to your toughest
standards. Use them for
troubleshooting industrial,
commercial, hospital and residential
electrical and HVAC systems.
Measure not just ac current, but ac
volts, ohms and continuity as well.
Tapered jaws allow easy access in
crowded junction boxes.
Designed for durability, the Fluke 30
and 32 can stand up to tough job
site abuse. Drop them from a 6 foot
(2 meter) ladder, and they'll still deliver reliable measurements. Built-in
overload protection is provided to 600A continuous/600V, meeting UL and
TUV certification standards, and both meters have been tested to meet the
IEC 61010-1 Cat III 600V safety standard.
If you test circuits with non-linear loads such as computers or adjustable
speed drives, you need a True-rms meter. The Model 32 measures true-rms
ac current to 400A with a crest factor of 3, and 600A with a crest factor of 2.
© 1995 - 2000 Fluke Corporation
Privacy Statement
Fluke 30/32 Clamp Meters
Features
Product Home | Features | Specifications |
Models, Options & Accessories | Manuals
The Fluke 30 and 32 combine
the right features at an
affordable price
AC current measurement●
AC Voltage measurement●
True-rms measurement of ac Volts (32
only)
●
Resistance●
Continuity beeper●
Jaws accept one 750 MCM cable or two
350 MCM cables, up to 38 mm (1.5") in
diameter
●
Easy single-handed operation●
Display Hold captures readings in difficult
to reach areas for later viewing
●
Easy-view 2000 count digital display●
Protective soft carrying case and Fluke
Hard PointT TL75 test leads included
●
CAT III 600V●
Independently tested and approved for UL
3111, CSA 22.2 1010.1 1992 and TUV to
EN61010-1:1993
●
© 1995 - 2000 Fluke Corporation
Privacy Statement
Fluke 30/32 Clamp Meters
Specifications
Product Home | Features | Specifications | Models, Options & Accessories |
Manuals
● 30 Clamp Meter
● 32 Clamp Meter
● General Specifications
30 Clamp Meter
AC Current
Range: 400A, 200A
Resolution: 1A, 1A, 0.1A
Accuracy: N/A, ±(1.3%+3), 0-100A: ±(1.8%+8), 100-200A:
±(1.4%+0)
AC Volts 50/60 Hz
Range: 200V, 600V
Resolution: 0.1V, 1.0V
Accuracy: ±(1.2%+3)
Resistance
Range: 200 Ω
Resolution: 0.1 Ω
Accuracy: ±(1.5%+2)
Crest Factor
Range: 400A, 200
Resolution:
Accuracy: N/A
32 Clamp Meter
AC Current
Range: 600A, 400A, 200A
Resolution: 1A, 1A, 0.1A
Accuracy: ±(2.5%+3), ±(1.3%+3), 0-100A: ±(1.8%+8),
100-200A: ±(1.4%+0)
AC Volts 50/60 Hz
Range: 200V, 600V
Resolution: 0.1V, 1.0V
Accuracy: ±(1.2%+3)
Resistance
Range: 200 Ω
Resolution: 0.1 Ω
Accuracy: ±(1.5%+2)
Crest Factor
Range: 400A, 200
Resolution:
Accuracy: N/A
General Specifications
Operating
Temperature
10°C to +50°C (14°F to 122°F)
Battery Life
200 hours typical (Alkaline for Model 32, Carbon-zinc for Model
30). Automatic Low-battery indicator
Size
213 mm L x 93 mm W x 45 mm D (8.4" L x 3.75" W x 1.77"
D)
Weight:
0.45 kg (1 lb.)
Warranty
One Year
© 1995 - 2000 Fluke Corporation
Privacy Statement
Fluke 30/32 Clamp Meters
Models, Options & Accessories
Product Home | Features | Specifications | Models, Options & Accessories |
Manuals
Model Name Product Description
Fluke 30
The Model 30 comes with C-31 Soft Case, TL75 Hard Point Test
Leads, 9V battery and operator's manual.
Fluke 32
The Model 30 and 32 come with C-31 Soft Case, TL75 Hard
Point Test Leads, 9V battery and operator's manual.
Available Accessories and Options
Model Name Accessory or Option Description
AC70A Alligator Clips
AC85A Large Jaw Alligator Clips
C31 Soft Case
C789 Toolcase
TL20 63" Test Lead Set
TL22 63" Right Angle Silicone Test Lead Set
TL23F Electrical Test Lead Set
TL23R Electrical Test Lead Set
TL24 63" Right Angle/Straight Silicone Test Leads
TL26A 60" 5-Way Test Lead Set
TL28A 63" Alligator Clip Test Lead Set
TL71 Premium DMM Test Lead Assembly
TL74 4 mm Diameter Test Leads
TL75 48" Hardpoint Test Lead Set
TL80 Basic Electronic Test Lead Set
TL81 Deluxe Electronic Test Lead Set
TP1 Slim Reach™ Test Probe
TP2 Slim Reach™ Test Probe
TP4 Slim Reach™ Test Probe
Y8140A 48" Slim Flex Test Lead Set
