BHF-XR Pro
Operator's Manual
38 pgs1.68 Mb0

FLIR BHS-X Pro, BHF-XR Pro, BHS-Series Bi-Ocular Operator's Manual

BHS-Series Bi-Ocular
1.877.766.5412
www.ShopFLIR.ca
Thermal Night Vision Camera
Operator’s Manual
Document Number: 431-BHS0-00-10
Revision: 110
March 2012
BHS-Series Bi-Ocular Operator’s Manual
1.877.766.5412
www.ShopFLIR.ca
© 2012 FLIR Commercial Systems, Inc. All rights reserved worldwide. No parts of this manual, in whole or in part, may be copied, photocopied, translated, or transmitted to any electronic medium or machine readable form without the prior written permission of FLIR Commercial Systems, Inc.
Names and marks appearing on the products herein are either registered trademarks or trademarks of FLIR Commercial Systems, Inc. and/or its subsidiaries. All other trademarks, trade names, or company names referenced herein are used for identification only and are the property of their respective owners.
This product is protected by patents, design patents, patents pending, or design patents pending.
If you have questions that are not covered in this manual, or need service, contact FLIR Commercial Vision Systems, Inc. customer support at 805.964.9797 for additional information prior to returning a camera.
The contents of this document are subject to change. For additional information visit www.flir.com or write to FLIR Commercial Systems, Inc., 70 Castilian Drive, Goleta CA
93117.
Proper Disposal of Electrical and Electronic Equipment (EEE)
The European Union (EU) has enacted Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE), which aims to prevent EEE waste from arising; to encourage reuse, recycling, and recovery of EEE waste; and to promote environmental responsibility.
In accordance with these regulations, all EEE products labeled with the “crossed out wheeled bin” either on the product itself or in the
product literature must not be disposed of in regular rubbish bins, mixed with regular household or other commercial waste, or by other regular municipal waste collection means. Instead, and in order to prevent possible harm to the environment or human health, all EEE products (including any cables that came with the product) should be responsibly discarded or recycled.
To identify a responsible disposal method where you live, please contact your local waste collection or recycling service, your original place of purchase or product supplier, or the responsible government authority in your area. Business users should contact their supplier or refer to their purchase contract.
This document is controlled to FLIR Technology Level 1. The information contained in this document pertains to a defense article controlled for export by the International Traffic in Arms Regulations (ITAR). FLIR trade secrets contained herein are subject to disclosure restrictions as a matter of law. Diversion contrary to US law is prohibited. [US Government authorization for public release has been obtained from the Office of Security Review, authorization no. 11-S-3545.] Additional US Department of State authorization is not required prior to export or transfer to foreign persons or parties, unless otherwise prohibited.
BHS-Series Bi-Ocular Operator’s Manual
1.877.766.5412
www.ShopFLIR.ca
Important Instructions and Notices to the User:
Modification of this device without the express authorization of FLIR Commercial Systems, Inc. may void the user’s authority under FCC rules to operate this device.
Note 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna;
•Increase the separation between the equipment and receiver;
•Connect the equipment into an outlet on a circuit different from that of the receiver; and/or
•Consult the dealer or an experienced radio/television technician for help.
Note 2: This equipment was tested for compliance with the FCC limits for a Class B digital device using a shielded cable for connecting the equipment to an analog video output to a monitor and using a shielded USB cable for connecting the equipment to a personal computer. When making such connections, shielded cables must be used with this equipment.
Industry Canada Notice:
This Class B digital apparatus complies with Canadian ICES-003.
Avis d’Industrie Canada:
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FLIR Commercial Systems, Inc.
70 Castilian Drive
Goleta, CA 93117
Phone: 888.747.FLIR (888.747.3547)
International: +1.805.964.9797
www.flir.com
431-BHS0-00-10, Revision 110 iii
BHS-Series Bi-Ocular Operator’s Manual
1.877.766.5412
www.ShopFLIR.ca
iv March 2012
Table of Contents
1.877.766.5412
www.ShopFLIR.ca
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BHS-Series Bi-Ocular Camera Features . . . . . . . . . . . . . . . . . . . . . . 2
Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
BHS-Series Bi-Ocular Camera Accessories . . . . . . . . . . . . . . . . . . .6
Lens Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operating Your Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Camera Features and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Installing the SD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Charging the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
BHS-Series Bi-Ocular Power Management . . . . . . . . . . . . . . . . . 13
Buttons and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
SD Card Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Auto-Standby Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
The Hot Shoe. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Bayonet Lens Mounting System . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Installing Software Upgrades. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
BHS-Series Bi-Ocular Camera Model Features. . . . . . . . . . . . . . 27
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Physical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Additional Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Field of View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Range Detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
431-BHS0-00-10, Revision 110 v
BHS-Series Bi-Ocular Operator’s Manual
1.877.766.5412
www.ShopFLIR.ca
vi March 2012
1Introduction
BHS-Series Bi-Ocular Camera
Image Intensified Camera
1.877.766.5412
www.ShopFLIR.ca
The BHS-Series Bi-Ocular handheld thermal imaging camera lets law enforcement officers see clearly in total darkness, giving them the information they need while making quick decisions, enhancing mission effectiveness, maximizing operational capabilities, and improving officer safety.
The Vanadium Oxide (VOx) microbolometer employed in the BHS­Series Bi-Ocular camera provides high-fidelity thermal imagery with the detail necessary for cutting edge performance. You will see improved detection and recognition ranges in total darkness, as well as through smoke, dust, and light fog.
You can see better through camouflage and foliage in any lighting conditions. You can see more—and see farther—than with other night vision technologies because BHS-Series Bi-Ocular cameras see clearly without any light whatsoever. You can see farther at night than with technologies that need ambient light to work and you can see heat sources that these other cameras could never find.
With a variety of lens options, on-board image, and video capture capability all built in to the camera, BHS-Series Bi-Ocular cameras are the most potent imaging package available today.
431-BHS0-00-10, Revision 110 1
1—Introduction BHS-Series Bi-Ocular Operator’s Manual
1.877.766.5412
www.ShopFLIR.ca
1–1 BHS-Series Bi-Ocular Camera Features
•Micro bolometer sensor for excellent image quality and clarity
•Quick Connect Hot Shoe—Provides convenient power input and video output.
•Choose from interchangeable 35 mm, 65 mm, or 100 mm quick-disconnect lenses (purchased separately).
•Two-sided Hand Strap—Accommodates both left-handed and right-handed users.
•SD Card Slot—Allows for storing captured still images and video on the removable SD card.
•Software upgrades using SD card in the field.
•USB 2.0 Connection—Rapid transfer of still images and video files from the camera to a PC.
• Four rechargeable AA NiMH batteries—Provides up to 5 hours of camera operation on a single charge.
•Battery charging AC adapter is included.
•Rugged design—Built to withstand the demands of day-in, day-out law enforcement operations.
•Hard Carrying Case—Provides protected storage for your BHS­Series Bi-Ocular camera, lenses, and all accessories.
2March 2012
BHS-Series Bi-Ocular Operator’s Manual 1—Introduction
1.877.766.5412
www.ShopFLIR.ca
1–2 Cautions
Do not disassemble the camera enclosure. Disassembly can cause permanent damage and will void the warranty. Keep the compartment covers closed to avoid exposing the cameras electronics to water or debris.
Do not point the camera directly at extremely high-intensity radiation sources, such as the sun, lasers, arc welders, etc.
Use only the supplied adapters to power or recharge the camera.
Be careful not to leave fingerprints on the camera’s optics.
Always keep the camera window covered. A lens or the lens cover should always be installed on the camera to protect the window.
Caution!
Always keep the camera window covered. A lens or the lens cover should always be installed on the camera to protect the window.
431-BHS0-00-10, Revision 110 3
1—Introduction BHS-Series Bi-Ocular Operator’s Manual
1.877.766.5412
www.ShopFLIR.ca
4March 2012
2Getting Started
QD100
QD65
QD35
1.877.766.5412
www.ShopFLIR.ca
The BHS-Series Bi-Ocular camera with accessories is shown packed in its Hard Carrying Case. The available lenses are shown in “Lens Options” on page 7. Refer to the packing list enclosed with your camera shipment to determine the actual contents of your camera package and lens or lenses you have purchased.
431-BHS0-00-10, Revision 110 5
2—Getting Started BHS-Series Bi-Ocular Operator’s Manual
Neck Lanyard
Hot Shoe
Video Output Cable
SD Card
AC Power Adaptor
USB Cable
Rechargeable
AA Batteries
Video Jack
1.877.766.5412
www.ShopFLIR.ca
2–1 BHS-Series Bi-Ocular Camera Accessories
In addition to the camera and Hard Carrying Case, Quick Start card, Operator’s manual, and Documentation/Training CD or DVD; the following items are included in the camera package:
6March 2012
