30" COLUMN REFRIGERATOR
& FREEZER
SINGLE PRODUCT INSTALL
—
10/10/2018
CONTENTS
30" Integrated Column Refrigerator and Freezer
with Stainless Steel Door panels
Model Nos:
Right Hinge Fridge RS3084SR1 / RS3084SRK1
Right Hinge Freezer RS3084FLJ1 / RS3084FLJK1
Stainless Steel Door Panel RD3084R4D
Handle AHD3-RD84
Stainless Steel Toekick Panel AKRS30041
Left Hinge Fridge RS3084SL1 / RS3084SLK1
Left Hinge Freezer RS3084FLJ1 / RS3084FLJK1
Stainless Steel Door Panel RD3084L4D
Handle AHD3-RD84
Stainless Steel Toekick Panel AKRS30041
in
pagemmpage
Product & Cavity Dimensions 4 17
Door Opening & Clearance Dimensions 5 18
Hinge Range of Movement 10 23
Cavity Preparation 12 25
Max Distance of Hose & Cord 15 28
30" Professional Integrated Column Refrigerator and Freezer with Stainless Steel Door panels
Model Nos:
Right Hinge Fridge RS3084SR1 / RS3084SRK1
Right Hinge Freezer RS3084FRJ1 / RS3084FRJK1
Stainless Steel Door Panel RD3084R4D,
Professional Handle AHC-RD84
Stainless Steel Toekick Panel AKRS30041
Left Hinge Fridge RS3084SL1 / RS3084SLK1
Left Hinge Freezer RS3084FLJ1 / RS3084FLJK1
Stainless Steel Door Panel RD3084L4D,
Professional Handle AHC-RD84
Stainless Steel Toekick Panel AKRS30041
in
pagemmpage
Product & Cavity Dimensions 6 19
Door Opening & Clearance Dimensions 7 20
Hinge Range of Movement 10 23
Cavity Preparation 12 25
Max Distance of Hose & Cord 15 28
30" Integrated Column Refrigerator and Freezer
for Custom Door panels
Model Nos:
Right Hinge Fridge RS3084SR1 / RS3084SRK1
Right Hinge Freezer RS3084FRJ1 / RS3084FRJK1
Left Hinge Fridge RS3084SR1 / RS3084SRK1
Left Hinge Freezer RS3084FLJ1 / RS3084FLJK1
in
pagemmpage
Product & Cavity Dimensions 8 21
Door Opening & Clearance Dimensions 9 22
Hinge Range of Movement 10 23
Custom Panel Dimensions 11 24
Cavity Preparation 12 25
Custom Panel Preparation 14 27
Max Distance of Hose & Cord 15 28
Note: This guide shows specifications for right hinge models.
For left hinge models, door related specifications are mirrored.
IMPERIAL
in
84"
30"
25"
2 11/16"- 4"
B
PRODUCT & CAVITY DIMENSIONS
30" Integrated Column Fridge / Freezer
FRAMED
1/8"
1/8"
FRAMELESS
C
A
F
PLAN VIEW
FLUSH WITH FRONT OF CABINETRY
F i G
F
Dh
A
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
with Stainless Steel Door Panel RD3084R4D, Handle AHD3-RD84
and Stainless Steel Toekick Panel AKRS30041
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
with Stainless Steel Door Panel RD3084L4D, Handle AHD3-RD84
and Stainless Steel Toekick Panel AKRS30041
Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Minimum overall depth of cavity
Product Dimensions in
D Overall height of product
E Overall width of product
F Minimum cabinetry gap clearance from edge of door panel
G Overall depth of product (excl. door front panel)
h Height of door front panel
i Depth of door front panel (excludes handles)
j Height of toekick*
k Depth of toekick (excl. door front and toekick panels)
*Standard toe kick height is 4” with the optional stainless door panel.
84"
29 3/4"
1/8"
24"
79 7/8"
3/4 "
4"
INDICATES CAVITY CLEARANCES
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
E
B
j
k
C
FRONT VIEW PROFILE VIEW
in
32"
16 1/2"
4 5/16"
C
B
DOOR OPENING CLEARANCE DIMENSIONS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
with Stainless Steel Door panel RD3084R4D
and Handle AHD3-RD84
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
with Stainless Steel Door panel RD3084L4D
and Handle AHD3-RD84
Door Opening & Clearance Dimensions
a Depth of door (90° open) measured from front of door
B Minimum door clearance to adjacent wall* (115° – full internal
access)
C Minimum door clearance to adjacent wall* (90° – reduced
internal access)
* Measured from front cabinetry edge.
AA
WALL WALL
90° DOOR OPENING 115° DOOR OPENING
[FULL ROTATION]
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
in
84"
30"
25"
2 11/16"- 4"
B
PRODUCT & CAVITY DIMENSIONS
30" Professional Integrated Column Fridge / Freezer
FRAMED
1/8"
1/8"
FRAMELESS
C
A
F
PLAN VIEW
FLUSH WITH FRONT OF CABINETRY
F i G
F
Dh
A
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
with Stainless Steel Door panel RD3084R4D, Handle AHC-RD84
and Stainless Steel Toekick Panel AKRS30041
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
with Stainless Steel Door panel RD3084L4D, Handle AHC-RD84
and Stainless Steel Toekick Panel AKRS30041
Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Minimum overall depth of cavity
Product Dimensions in
D Overall height of product
E Overall width of product
F Minimum cabinetry gap clearance from edge of door panel
G Overall depth of product (excl. door front panel)
h Height of door front panel
i Depth of door front panel (excludes handles)
j Height of toekick*
k Depth of toekick (excl. door front and toekick panels)
*Standard toe kick height is 4” with the optional stainless door panel.
84"
29 3/4"
1/8"
24"
79 7/8"
3/4 "
4"
INDICATES CAVITY CLEARANCES
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
E
B
j
k
C
FRONT VIEW PROFILE VIEW
in
32"
16 1/2"
4 5/16"
C
B
DOOR OPENING CLEARANCE DIMENSIONS
30" Professional Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
with Stainless Steel Door panel RD3084R4D
and Handle AHC-RD84
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
with Stainless Steel Door panel RD3084L4D
and Handle AHC-RD84
Door Opening & Clearance Dimensions
a Depth of door (90° open) measured from front of door
B Minimum door clearance to adjacent wall* (115° – full internal
access)
C Minimum door clearance to adjacent wall* (90° – reduced
internal access)
* Measured from front cabinetry edge.
AA
WALL WALL
90° DOOR OPENING 115° DOOR OPENING
[FULL ROTATION]
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
in
84"
30"
25"
2 11/16"- 4"
B
PRODUCT & CAVITY DIMENSIONS
30" Integrated Column Fridge / Freezer
FRAMED
1/8"
1/8"
FRAMELESS
C
A
F
PLAN VIEW
e
F
D
G
A
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Minimum overall depth of cavity*
Total front panel width with required gaps at sides = 84"
(Refer custom panel dimensions – panel width + 2 x
* Assumes a door panel thickness of 3/4".
Product Dimensions in
D Overall height of product
E Overall width of product
F Minimum cabinetry gap clearance from edge of custom
panels**
G Overall depth of product (excl. door front panel)
h Height of toekick**
i Width of toekick**
j Depth of toekick** (excl. door front and toekick panels)
** For custom panel dimensions refer to page 11.
Door panel and custom toekick panel to be manufactured and fitted by
cabinetmaker. Door panel thickness min 5/8" – max 1".
F cabinetry gaps).
84"
29 3/4"
1/8"
24"
2" – 6"
29 7/8"
INDICATES CAVITY CLEARANCES
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
i
B
h
g
C
FRONT VIEW PROFILE VIEW
in
32"
16 1/2"
4 5/16"
C
B
DOOR OPENING CLEARANCE DIMENSIONS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
Door Opening & Clearance Dimensions
a Depth of door (90° open) measured from front of door
B Minimum door clearance** to adjacent wall* (115° – full internal
access)
C Minimum door clearance** to adjacent wall* (90° – reduced
internal access)*
* Does not include the custom door panels or handles to be manufactured and
fitted by cabinetmaker.
** Measured from front cabinetry edge.
AA
WALL WALL
90° DOOR OPENING 115° DOOR OPENING
[FULL ROTATION]
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
DOOR CLOSED
FRONT OF CABINETRY
WITH 3/4" PANEL
CUSTOM PANEL PREPARATION - HINGE
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
Dwg & Dxf Files
Dwg and Dxf files of the panel preparation are available within the download
folder for this product and can be found on
http://thekitchentools.fisherpaykel.com
Door Hinge – Hettich K05
1 SQUARE = 1/2"
TOP VIEW
HINGE RANGE OF MOVEMENT
SHOWN WITH STANDARD 3/4" PANEL
DOOR
90° OPEN
DOOR FULLY OPEN 115°
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
in
77 7/8"
- 81 7/8"
29 3/4"
29 13/16"
min 5/8"
max 1"
2" - 6"
29 7/8"
66lb
CUSTOM PANEL DIMENSIONS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
NOTE: Right hand hinge model is a mirrored version of image
shown.
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
Custom Panel Dimensions*
a Height of door panel
B Width of door panel - single install
Width of door panel - dual install
c Maximum depth of custom panel
D Height of toekick panel**
E Width of toekick panel
Maximum weight of door panel***
c
A
E
b
d
ISO VIEW
* Custom door panels, toekick and handles to be manufactured / fitted by
cabinetmaker.
** The bottom grille can be reduced to allow for a higher toekick. Adjust the
height of the door panel accordingly.
*** Includes weight of handle.
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
in
84"
30"
25"
4"
in
9"
1"
1/2"
5"
min 22 psi (150 kPa)
CAVITY SIDES & TOP
4"
D
FRAMELESS
FINISHED RETURN
SUPPLY AREA
F
G
A
C
Electrical
Plumbing
ALTERNATIVE AREA
ABOVE CAVITY FOR
ELEC CONNECTION
Electrical
Plumbing
E
CAVITY PREPARATION - FRAMELESS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
IMPORTANT!
For ease of installation, ensure cavity has consistent dimensions
top to bottom and left to right.
Minimum Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Overall depth of cavity
Minimum required finished return
Electrical / Plumbing Supply Dimensions
d Overall height of supply area
E Overall depth of supply area
F Width of notch in supply area (both sides)
G Height of sides of supply area (both sides)
Specifications
Electrical
Supply
Service
Plumbing
Supply
Pressure
NOTE: Electrical connection can be located an adjacent cabinet to either side
of the fridge or above the fridge cavity.
1/4" (6mm) comp. stainless steel braided hose
max 120 psi (827 kPa) @ 68°F (20°C)
115 VAC, 60 Hz
10 amp circuit
with adaptor
B
B
ISO VIEW OF CAVITY
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
in
84"
30"
25"
4"
in
9"
1"
1/2"
5"
min 22 psi (150 kPa)
CAVITY SIDES & TOP
4"
D
FRAMED
FINISHED RETURN
SUPPLY AREA
F
G
A
C
Electrical
Plumbing
ALTERNATIVE AREA
ABOVE CAVITY FOR
ELEC CONNECTION
Electrical
Plumbing
E
CAVITY PREPARATION - FRAMED
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
IMPORTANT!
For ease of installation, ensure cavity has consistent dimensions
top to bottom and left to right.
Minimum Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Overall depth of cavity
Minimum required finished return
Electrical / Plumbing Supply Dimensions
d Overall height of supply area
E Overall depth of supply area
F Width of notch in supply area (both sides)
G Height of sides of supply area (both sides)
Specifications
Electrical
Supply
Service
Plumbing
Supply
Pressure
NOTE: Electrical connection can be located an adjacent cabinet to either side
of the fridge or above the fridge cavity.
1/4" (6mm) comp. stainless steel braided hose
max 120 psi (827 kPa) @ 68°F (20°C)
115 VAC, 60 Hz
10 amp circuit
with adaptor
B
B
ISO VIEW OF CAVITY
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
30"
COLUMN DOOR PANEL
REAR VIEW
50”
20”
14 7/8"
8”
2”
Model nos:
5”
2”
22 x Ø1/16”
PILOT HOLES ONLY.
DO NOT PENETRATE
FRONT SURFACE
2”
DO NOT PLACE
HANDLE HOLES IN
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
Custom Panel Preparation
Dimensions are shown in inches.
Dimensions apply for the preparation and installation of custom panels
Handles
Ensure handle screw heads are countersunk into back of panel to avoid
interfering with hanging bracket, and clear of side brackets as indicated.
CUSTOM PANEL PREPARATION
30" Integrated Column Fridge / Freezer
THESE LOCATIONS
70”
Dwg & Dxf Files
Dwg and Dxf files of the panel preparation are available within the download
folder for this product and can be found on
http://thekitchentools.fisherpaykel.com
79 7/8"
2”
13/16"
3 9/16"
2 3/8”
2”
FOR 6” TOEKICK, MAKE
DOOR LENGTH 2” SHORTER
FOR 2” TOEKICK, MAKE
DOOR LENGTH 2” LONGER
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
1 1/4”
29 3/4"
10 1/2"
POWER AND WATER CONNECTIONS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
* Water inlets apply to freezers only
RIGHT HAND SIDELEFT HAND SIDE
51 3/4" 27 3/4"
70 1/2" 71 1/2"
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
METRIC
mm
2134
762
635
3
B
PRODUCT & CAVITY DIMENSIONS
30" Integrated Column Fridge / Freezer
FRAMED
3
3
FRAMELESS
C
A
F
PLAN VIEW
FLUSH WITH FRONT OF CABINETRY
F i G
F
Dh
A
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
with Stainless Steel Door panel RD3084R4D, Handle AHD3RD84 and Stainless Steel Toekick Panel AKRS30041
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
with Stainless Steel Door panel RD3084L4D, Handle AHD3-RD84
and Stainless Steel Toekick Panel AKRS30041
Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Minimum overall depth of cavity
Product Dimensions mm
D Overall height of product
E Overall width of product
F Minimum cabinetry gap clearance from edge of door panel
G Overall depth of product (excl. door front panel)
h Height of door front panel
i Depth of door front panel (excludes handles)
j Height of toekick*
k Depth of toekick (excl. door front and toekick panels)
*Standard toe kick height is 102mm with the optional stainless door panel.
2134
756
610
2029
102
68 - 101
19
INDICATES CAVITY CLEARANCES
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
E
B
j
k
C
FRONT VIEW PROFILE VIEW
mm
813
419
110
C
B
DOOR OPENING CLEARANCE DIMENSIONS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
with Stainless Steel Door panel RD3084R4D
and Handle AHD3-RD84
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
with Stainless Steel Door panel RD3084L4D
and Handle AHD3-RD84
Door Opening & Clearance Dimensions
a Depth of door (90° open) measured from front of door
B Minimum door clearance to adjacent wall* (115° – full internal
access)
C Minimum door clearance to adjacent wall* (90° – reduced
internal access)
* Measured from front cabinetry edge.
AA
WALL WALL
90° DOOR OPENING 115° DOOR OPENING
[FULL ROTATION]
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
mm
2134
762
635
3
B
PRODUCT & CAVITY DIMENSIONS
30" Professional Integrated Column Fridge / Freezer
FRAMED
3
3
FRAMELESS
C
A
F
PLAN VIEW
FLUSH WITH FRONT OF CABINETRY
F i G
F
Dh
A
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
with Stainless Steel Door panel RD3084R4D, Handle AHC-RD84
and Stainless Steel Toekick Panel AKRS30041
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
with Stainless Steel Door panel RD3084L4D, Handle AHC-RD84
and Stainless Steel Toekick Panel AKRS30041
Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Minimum overall depth of cavity
Product Dimensions mm
D Overall height of product
E Overall width of product
F Minimum cabinetry gap clearance from edge of door panel
G Overall depth of product (excl. door front panel)
h Height of door front panel
i Depth of door front panel (excludes handles)
j Height of toekick*
k Depth of toekick (excl. door front and toekick panels)
*Standard toe kick height is 102mm with the optional stainless door panel.
2134
756
610
2029
102
68 - 101
19
INDICATES CAVITY CLEARANCES
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
E
B
j
k
C
FRONT VIEW PROFILE VIEW
mm
813
419
110
C
B
DOOR OPENING CLEARANCE DIMENSIONS
30" Professional Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
with Stainless Steel Door panel RD3084R4D
and Handle AHC-RD84
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
with Stainless Steel Door panel RD3084L4D
and Handle AHC-RD84
Door Opening & Clearance Dimensions
a Depth of door (90° open) measured from front of door
B Minimum door clearance to adjacent wall* (115° – full internal
access)
C Minimum door clearance to adjacent wall* (90° – reduced
internal access)
* Measured from front cabinetry edge.
AA
WALL WALL
90° DOOR OPENING 115° DOOR OPENING
[FULL ROTATION]
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
mm
2134
762
635
mm
2134
756
3
610
50 - 152
759
68 - 101
B
PRODUCT & CAVITY DIMENSIONS
30" Integrated Column Fridge / Freezer
FRAMED
3
3
FRAMELESS
C
A
F
PLAN VIEW
e
F
D
G
A
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1/ RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Minimum overall depth of cavity*
Total front panel width with required gaps at sides = 762mm
(Refer custom panel dimensions – panel width + 2 x
* Assumes a door panel thickness of 19mm.
Product Dimensions
D Overall height of product
E Overall width of product
F Minimum cabinetry gap clearance from edge of custom
panels**
G Overall depth of product (excl. door front panel)
h Height of toekick**
i Width of toekick**
j Depth of toekick** (excl. door front and toekick panels)
** For custom panel dimensions refer to page 24.
Door panel and custom toekick panel to be manufactured and fitted by
cabinetmaker. Door panel thickness min 16mm – max 25mm
F cabinetry gaps).
INDICATES CAVITY CLEARANCES
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
i
B
h
j
C
FRONT VIEW PROFILE VIEW
mm
813
419
110
C
B
DOOR OPENING CLEARANCE DIMENSIONS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1/ RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
Door Opening & Clearance Dimensions
a Depth of door (90° open) measured from front of door
B Minimum door clearance** to adjacent wall* (115° – full internal
access)
C Minimum door clearance** to adjacent wall* (90° – reduced
internal access)*
* Does not include the custom door panels or handles to be manufactured and
fitted by cabinetmaker.
** Measured from front cabinetry edge.
AA
WALL WALL
90° DOOR OPENING 115° DOOR OPENING
[FULL ROTATION]
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
CUSTOM PANEL PREPARATION - HINGE
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
Dwg & Dxf Files
Dwg and Dxf files of the panel preparation are available within the download
folder for this product and can be found on
http://thekitchentools.fisherpaykel.com
DOOR CLOSED
1 SQUARE = 1CM
TOP VIEW
HINGE RANGE OF MOVEMENT
SHOWN WITH STANDARD 19MM PANEL
DOOR
90° OPEN
FRONT OF CABINETRY
DOOR FULLY OPEN 115°
WITH 19MM PANEL
Door Hinge – Hettich K05
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
mm
1978
- 2080
756
75 7.5
min 16
max 25
50 - 152
762
30kg
CUSTOM PANEL DIMENSIONS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
NOTE: Right hand hinge model is a mirrored version of image
shown.
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
Custom Panel Dimensions*
a Height of door panel
B Width of door panel - single install
Width of door panel - dual install
c Maximum depth of custom panel
D Height of toekick panel**
E Width of toekick panel
Maximum weight of door panel***
c
A
E
b
d
ISO VIEW
* Custom door panels, toekick and handles to be manufactured / fitted by
cabinetmaker.
** The bottom grille can be reduced to allow for a higher toekick. Adjust the
height of the door panel accordingly.
*** Includes weight of handle.
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
mm
2134
762
635
102
mm
229
25
13
127
min 150 kPa (22 psi)
CAVITY SIDES & TOP
102
D
FRAMELESS
FINISHED RETURN
SUPPLY AREA
F
G
A
C
Electrical
Plumbing
ALTERNATIVE AREA
ABOVE CAVITY FOR
ELEC CONNECTION
Electrical
Plumbing
E
CAVITY PREPARATION - FRAMELESS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
IMPORTANT!
For ease of installation, ensure cavity has consistent dimensions
top to bottom and left to right.
Minimum Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Overall depth of cavity
Minimum required finished return
Electrical / Plumbing Supply Dimensions
d Overall height of supply area
E Overall depth of supply area
F Width of notch in supply area (both sides)
G Height of sides of supply area (both sides)
Specifications
Electrical
Supply
Service
Plumbing
Supply
Pressure
NOTE: Electrical connection can be located an adjacent cabinet to either side
of the fridge or above the fridge cavity
1/4" (6mm) comp. stainless steel braided hose
max 827 kPa (120 psi) @ 20°C (68°F)
115 VAC, 60 Hz
10 amp circuit
with adaptor
B
B
ISO VIEW OF CAVITY
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
mm
2134
762
635
102
mm
229
25
13
127
min 150 kPa (22 psi)
CAVITY SIDES & TOP
102
D
FRAMED
FINISHED RETURN
SUPPLY AREA
F
G
A
C
Electrical
Plumbing
ALTERNATIVE AREA
ABOVE CAVITY FOR
ELEC CONNECTION
Electrical
Plumbing
E
CAVITY PREPARATION - FRAMED
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1/ RS3084FLJK1
IMPORTANT!
For ease of installation, ensure cavity has consistent dimensions
top to bottom and left to right.
Minimum Cavity Dimensions
a Overall height of cavity
B Overall width of cavity
c Overall depth of cavity
Minimum required finished return
Electrical / Plumbing Supply Dimensions
d Overall height of supply area
E Overall depth of supply area
F Width of notch in supply area (both sides)
G Height of sides of supply area (both sides)
Specifications
Electrical
Supply
Service
Plumbing
Supply
Pressure
NOTE: Electrical connection can be located an adjacent cabinet to either side
of the fridge or above the fridge cavity.
1/4" (6mm) comp. stainless steel braided hose
max 827 kPa (120 psi) @ 20°C (68°F)
115 VAC, 60 Hz
10 amp circuit
with adaptor
B
B
ISO VIEW OF CAVITY
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
762MM
COLUMN DOOR PANEL
REAR VIEW
508
378
203
51
Model nos:
127
50
22 x Ø2
PILOT HOLES ONLY.
DO NOT PENETRATE
FRONT SURFACE
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
NOTE: Left hand hinge model is a mirrored version of image
shown.
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
Custom Panel Preparation
Dimensions are shown in millimetres (mm).
Dimensions apply for the preparation and installation of custom panels
CUSTOM PANEL PREPARATION
30" Integrated Column Fridge / Freezer
2029
1778
1270
33
50
50
50
DO NOT PLACE
HANDLE HOLES IN
THESE LOCATIONS
90
20
60
FOR 152MM TOEKICK, MAKE
DOOR LENGTH 50MM SHORTER
FOR 50MM TOEKICK, MAKE
DOOR LENGTH 52MM LONGER
Handles
Ensure handle screw heads are countersunk into back of panel to avoid
interfering with hanging bracket, and clear of side brackets as indicated.
Dwg & Dxf Files
Dwg and Dxf files of the panel preparation are available within the download
folder for this product and can be found on
http://thekitchentools.fisherpaykel.com
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
756
267mm
POWER AND WATER CONNECTIONS
30" Integrated Column Fridge / Freezer
Model nos:
RS3084SR1 / RS3084SRK1 / RS3084FRJ1 / RS3084FRJK1
RS3084SL1 / RS3084SLK1 / RS3084FLJ1 / RS3084FLJK1
* Water inlets apply to freezers only
RIGHT HAND SIDELEFT HAND SIDE
1314mm 705mm
1791mm 1816mm
DATE: 10.10.2018
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm (1/16'').
Please read the installation manual for detailed information on installing the
product. For full installation instructions & specifications visit fisherpaykel.com
Loading...
