Fisher & Paykel DD24DI7 Quick Start manual

DD60DI7
DD24D(H)(T)I7

DD60S(T)I7
DD24S(H)(T)I7

DD90STI2
DD36STI2

QUICK START GUIDE

DishDrawer

TM

dishwasher (Integrated)

Selecting a wash program

NZ AU US CA

Keep this document handy for easy reference.

For detailed information on the features of your dishwasher, see your ‘User guide’.
Before using your dishwasher, make sure you read the full ‘User guide’, with special attention to the ‘Safety and warnings’ section.
For contact information or if you require service, assistance or replacement parts, see the end of this document or your ‘Service & warranty’ booklet.

Wash
program

Your model

Note: each drawer in
double models has its own
controls and can run
independently of the
other drawer.

Your remote control

Doubles remote shown

21

selector

Press to
scroll
through the
wash
programs.

Important!

To prevent unauthorized use, keep the remote control out of reach of children.

Signal indicator

A single flash
indicates a
successful
signal to the
dishwasher.
Multiple flashes
indicate that
the dishwasher
cannot read
the signal. The
remote control
may be out of
range.

Double models only

(operates lower drawer)

‘Battery low’ indicator

When this
flashes, the
battery needs to
be replaced. Use
a CR2032 battery,
ensuring the
+ symbol faces up.

Control button(s)

See section ‘Operating instructions’
for information.

Mounting your
remote

Your remote control
comes supplied with a
detachable mounting
bracket and self
adhesive strip. You can
choose to affix this
bracket on a nearby
surface, which should be
out of direct sunlight
and away from excessive
heat and steam. Do not
apply on wallpaper.

Peel red liner off,
press adhesive to bracket

3

10 seconds

Press remote & bracket
to clean, dry surface
for 10 seconds

Peel black
liner off

4

1H

30 seconds

Slide off remote, then
press bracket firmly to
surface for 30 seconds.
Wait 1 hour before
refitting remote.

Operating instructions

Start/resume wash

Loading and detergent

Pause wash

14

2

3

Discard scraps

Scrape large food particles off
(e.g. bones, fruit stones) and
remove any foreign objects
(e.g. toothpicks, strings, paper).

Load dishes carefully

To help with wash performance,
arrange dishes so they are
evenly spaced and not nesting.

Check spray arm(s)

Ensure there are no items
blocking the spray arm(s) from
rotating.

Add detergent and check rinse
aid

Fill the detergent dispenser (a) with

Cancel wash

powdered detergent and close the

a

dispenser door.

Important!

Do not place liquid detergent or tablets in

b

c

d

the detergent dispenser.

If the indicator on its plug (c) glows
bright red, refill the rinse aid
dispenser (b) with liquid rinse aid.
Make sure you then refit the rinse
aid plug back into its original
position.

If using a tablet, place it in the
cutlery basket (d) or at the bottom
of the drawer.

Set Delay start

Cancel Delay start

Wash program indicators

These show which program is selected.

STANDARD PROGRAMS - designed to clean and dry your dishes

HEAVY

Heavily soiled
pots, pans and
dishes.

NORMAL

Dishes with
normal
soils for

FAST

Lightly soiled
dishes.

optimum
performance.

ECO PROGRAMS - designed to clean your dishes energy-efficiently

HEAVY ECO

Heavily soiled
everyday
dishes.

NORMAL
ECO

Normal soiled
dishes for
optimum

FAST ECO

Lightly soiled,
non-greasy

dishes.
water and
energy use.

You can operate your dishwasher in two ways:

EITHER
by using the

button

on the drawer control panel

1

Press .

2

Close the drawer. The wash will start.

You can only pause the wash with the
remote. See opposite.

1

Pause the wash with the remote.

2

Open the drawer, then press and

hold until you hear a
quick double beep.

Any water in the drawer will automatically
drain when you close it.

To delay the start of a wash by 1 to 12
hours:

Press and hold . Count the beeps
as the dishwasher emits them (each
represents 1 more hour of delay) and
release the button when you have
reached the desired delay time.

The indicator of the selected wash
program will flash to show that Delay
start has been set.

The wash will start once the delay
time is over, provided the drawer is
closed.

Press and hold

until you hear a quick
double beep and the indicator of the
selected wash program goes out.

DELICATE

Lightly soiled
and heat
sensitive
crockery.

DELICATE
ECO

Lightly soiled,
non-greasy
and heat
sensitive
crockery.

Start/resume wash

Pause wash

Cancel wash

Set Delay start

Cancel Delay start

RINSE

Prevents
odors
and soils
drying on
dishes.

ECO indicator

The indicator will
glow red when an
Eco program has
been selected.
If you require
enhanced
drying, we do
not recommend
selecting an Eco
program.

OR
by using the remote
control button

1

Close the drawer.

2

Press . The wash will start.

Press

.

After pausing a wash, wait for 3 beeps
before opening the drawer. Forcing it open
in mid-cycle may cause damage or injury.

Press and hold

until you hear a quick

double beep.

Any water in the drawer will automatically
drain.

You can only set Delay start on the drawer
control panel. See opposite.

Press and hold

until you hear a quick

double beep.

continued over

After the wash

Preference options

The dishwasher will beep six times to indicate the end of the wash program.

You may notice the following noises at the end of the wash. These are all part of normal operation:

In double models, both drawers may be draining simultaneously.
The drying fan may continue to run after a wash program has finished for a set time. The fan assists with drying and uses

negligible amounts of energy.

For best drying results, we recommend unloading the dishes once they have cooled.

Dos and don’ts of loading

Sharp or pointed items must be placed
horizontally or with sharp edges/points
facing down to avoid risk of injury.

Protruding items will stop the
internal lid of the drawer from
sealing properly, which could result
in a service call.

You can change the setting of these options to suit your preferences or circumstances. We recommend selecting the most suitable
settings before you start using your dishwasher.

Option Rinse aid Water softener* Beeps at end of wash

Regulates the amount of rinse aid
dispensed. Reduce this setting if there is

What does it do?

How to change the setting of an option

1

CHECK & OPEN

Check that there is no wash underway, then open the drawer.

2

ENTER MENU & SCROLL TO OPTION

To enter the menu: press first with one finger, then with another finger, hold both until one long beep sounds, then
release.

To scroll to the next option: press . To know which option you’re in, keep track of the sequence of options using the table below.

You are now in the Rinse aid option of the preference options menu.
If you want to change the Rinse aid setting, go to step 3 now.
If you want to change the setting of another option, you will need to scroll to that option first.

When you have scrolled to the end of the sequence, it will start again with Rinse aid (after the lower tone).

excess foam after a wash. Increase this
setting if dishes are wet or streaky after
a wash.

Refer to the ‘Water softener’
section of the ‘User guide’ for
details.

Your dishwasher is factory-set to beep
six times at the end of a wash. You can
turn this setting off.

A neatly arranged load with evenly
spaced dishes helps wash performance.

Ensure there is enough space between
plates. Mix spoons, knives and forks
within the cutlery basket to prevent
them from nesting.

Overcrowding reduces wash
performance.

If plates and cutlery are nesting,
they are less likely to be cleaned
well.

Option Rinse aid Water softener* Beeps at end of wash

Possible settings

Example

4 indicators lit = setting is 4

3

CHANGE SETTING

Press to change the setting within an option. For example, to change the Rinse aid setting from 4 (factory default) to 2, you need
to press 3 times.

4

SAVE SETTING & QUIT MENU

Press and hold until a beep sounds and the control panel reverts to showing the wash program currently selected.

*This option is disabled on models without water softener. It appears in the sequence of options but cannot be adjusted.

1 to 5 0 to 5 On/Off

On

3 indicators lit = setting is 3

Off

For more info

For detailed information on the
features of your dishwasher

see your ‘User guide’

Ensure that water reaches all items on
the adjustable racks.

Dishware is blocking water from
reaching items on the adjustable
racks.

For warranty information

If you…

have any questions or comments
need a Fisher & Paykel authorized

technician to service your product
need replacement parts or accessories
want to register your product

see your ‘Service and warranty’ booklet

see your ‘Service and warranty’ booklet or contact us

NZ
AU
USA toll-free, 24/7 1 888 936 7872 www.fisherpaykel.com
CA

toll-free, 24/7 0800 372 273 www.fisherpaykel.co.nz
toll-free, 24/7 1300 650 590 www.fisherpaykel.com.au

toll-free, 24/7 1 888 936 7872 www.fisherpaykel.ca

590194A 10.11
