Fisher & Paykel CG905D, CG903D, CG752D, CG302D, CG451D User Manual
...
Gas-on-glass cooktop
CG302D, CG451D, CG603D, CG604D,
CG752D, CG903D & CG905D, models
User guide
NZ AU GB IE IN
Contents
1
Safety and warnings
Introduction
Using your cooktop
Cooking guidelines and cookware
Care and cleaning
Troubleshooting
Warranty and service
2
4
8
10
11
15
18
Important!
SAVE THESE INSTRUCTIONS
The models shown in this document may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local Fisher & Paykel dealer.
2
Safety and warningsSafety and warnings
Operation
Poisoning Hazard
Never use this appliance as a space
heater to heat or warm the room. Doing
so may result in carbon monoxide
poisoning and overheating of the
appliance.
Failure to follow this advice may result
in poisoning or death.
Hot Surface Hazard
WARNING!
WARNING!
This appliance becomes hot during use.
Do not touch the cooktop components,
burners, pan supports or the ceramic
glass when hot.
Before cleaning, turn the burners o
and make sure the whole cooktop is
cool.
Failure to follow this advice may result
in serious injury.
Safety and warningsSafety and warnings
WARNING!
Fire Hazard
Never leave the appliance unattended
when in use. Boilover causes smoking
and greasy spillovers that may ignite.
Failure to follow this advice may result
in serious injury.
WARNING!
Explosion Hazard
Do not use or store ammable
3
materials such as gasoline near this
appliance.
Do not spray aerosols in the vicinity of
this appliance while it is in operation.
Failure to follow this advice may result
in death or serious injury.
4
Safety and warningsSafety and warnings
Operation
Electrical Shock Hazard
Switch the power to the cooktop
o at the wall before cleaning or
maintenance.
Do not cook on a broken or cracked
cooktop. If the glass should break
or crack, turn o the gas supply and
switch the appliance o immediately
at the mains power supply (wall
switch) and contact a quali ed
technician.
WARNING!
Failure to follow this advice may result
in death or electrical shock.
Safety and warningsSafety and warnings
Important safety instructions!
Operation
Keep children away from the cooktop when it
is in use.
Household appliances are not intended to be
played with by children.
Children of less than 8 years old must be kept
away from the appliance unless continuously
supervised. This appliance can be used by
children aged from 8 years and above, and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge, if they have been given
5
supervision or instruction concerning the
use of the appliance in a safe way and they
understand the hazards involved. Cleaning
and user maintenance shall not be done by
children without supervision.
If the electrical supply cord is damaged,
it must only be replaced by an authorised
person.
If the appliance is connected to the gas supply
with a flexible hose, make sure that the hose
cannot come in contact with the bottom of
the appliance or any sharp edges.
Ensure that the electrical connection plug is
accessible after installation.
6
Safety and warningsSafety and warnings
Important safety instructions!
This appliance should be connected to a
circuit that incorporates an isolating switch
providing full disconnection from the
electricity supply.
Do not use an asbestos mat or decorative
covers between the flame and the saucepan
as this may cause serious damage to your
cooktop.
Do not place aluminium foil or plastic dishes
on the cooktop burners.
Do not let large saucepans, frying pans or
woks push any other pans aside. This could
make them unstable or deflect heat onto your
benchtop and damage the surface.
Do not use a steam cleaner for cleaning this
cooktop.
Saucepan handles may be hot to touch.
Ensure saucepan handles do not overhang
other gas burners that are on. Keep handles
out of reach of children.
Do not stand or place heavy objects on this
appliance.
Take care not to drop any heavy or sharp
objects on the cooktop. The ceramic glass is
tough, but sharp or heavy objects falling on
it (e.g. pepper mill, heavy-based frying pan)
may crack or chip it.
Safety and warningsSafety and warnings
Important safety instructions!
7
After use, ensure that the control dials are in
(o)
the ‘OFF’
position.
Where this appliance is installed in marine
craft or in caravans, it shall not be used as a
space heater.
The use of a gas cooking appliance results
in the production of heat and moisture in
the room in which it is installed. Ensure
the kitchen is well ventilated. Keep natural
ventilation holes open or install a mechanical
ventilation device (mechanical extractor
hood). Prolonged intensive use of the
appliance may call for additional ventilation,
for example opening of a window, or more
effective ventilation, for example increasing
the level of mechanical ventilation where
present.
After having unpacked the appliance, check to
ensure that it is not damaged.
In case of doubt, do not use it and consult your
supplier or a professionally qualified technician.
Packing elements (eg plastic bags, polystyrene
foam, nails, packing straps, etc.) should not be
left around within easy reach of children, as
these may cause serious injuries.
Do not modify this appliance.
This appliance is to be serviced only by an
authorised person.
