Fisher & Paykel CG603, CG903 User Manual
User guide
Gas cooktops
CG603 and CG903 models
NZ AU
Contents
1
Introduction
Safety and warnings
Using your cooktop
Care and cleaning
Troubleshooting
Warranty and service
Gas rate summary
2
3
4
8
10
11
12
Important!
SAVE THESE INSTRUCTIONS
2
Introduction
About your new cooktop
Thank you for buying a Fisher & Paykel gas cooktop. Now that it is installed and ready to use, you
will want to know everything about it to make sure you get excellent results right from the start.
This guide introduces you to all its special features. We recommend you read the whole guide
before using your new cooktop, for both safety and cooking success.
For more information, go to www.fisherpaykel.com
Before using your new cooktop
Before using your new cooktop, please:
Read this user guide, taking special note of the ‘Safety and warnings’ section following.
Plug the cooktop into the electricity supply and turn it on so the electronic ignition will work.
1
1
6
Fig.1 CG603 with rapid burner
1
2
Fig.2 CG603 with wok burner
1
Semi-rapid burner
2
Wok burner
3
Auxiliary burner
4
Cooktop controls
5
Fish burner
6
Rapid burner
3
4
5
1
1
4
3
2
Fig.3 CG903
1
4
3
Safety and warnings
WARNING!
Hot Surface Hazard
This appliance becomes hot during use.
Do not touch the cooktop components, burners, trivets/pan supports or the
stainless steel base when hot.
Before cleaning, turn the burners off and make sure the whole cooktop is cool.
Failure to do so could result in burns and scalds.
Explosion Hazard
Do not store flammable materials such as gasoline near the cooktop.
Do not spray aerosols near the cooktop during use.
Failure to do so may result in death or electrical shock.
Important safety precautions
Household appliances are not intended to be played with by children.
Children, or persons with a disability which limits their ability to use the appliance, should have a
responsible person to instruct them in its use. The instructor should be satisfied that they can use
the appliance without danger to themselves or their surroundings.
This appliance should be connected to a circuit that incorporates an isolating switch providing
full disconnection from the electricity supply.
Do not stand or place heavy objects on this appliance.
Do not use an asbestos mat or decorative covers between the flame and the saucepan as this may
cause serious damage to your cooktop.
Do not place aluminium foil or plastic dishes on the cooktop burners.
Do not let large saucepans or frying pans overlap the bench as this can deflect heat onto your
benchtop and damage the surface.
Do not let large saucepans, frying pans or woks push any other pans aside. This could make them
unstable or deflect heat onto your benchtop and damage the surface.
Do not use a steam cleaner for cleaning this cooktop.
Saucepan handles may be hot to touch. Ensure saucepan handles do not overhang other gas
burners that are on. Keep handles out of reach of children.
If the electrical supply cord is damaged, it must only be replaced by an authorised person. Ensure
that the electrical connection plug is accessible after installation.
Where this gas cooktop is installed in marine craft or in a caravan, it shall not be used as a space
heater.
The use of a gas cooking appliance results in the production of heat and moisture in the room in
which it is installed. Ensure the kitchen is well ventilated. Keep natural ventilation holes open or
install a mechanical ventilation device (mechanical extractor hood).
Prolonged intensive use of the appliance may call for additional ventilation, for example opening of
a window, or more effective ventilation, for example increasing the level of mechanical ventilation
where present.
WARNING!
3
4
Using your cooktop
Lighting the cooktop
1
Choose the control knob for the burner you want to use.
2
Press the knob down gently and turn it anticlockwise to
the High position. The electrodes on all the burners will
High
Off
spark.
Flame failure models only: Hold down the knob for
approximately five seconds after the burner has lit.
Releasing the knob too soon will extinguish the flame.
3
Adjust the flame anywhere between the High and Low
positions. Do not adjust the flame between High and
Off
O
.
Low
Fig.4 Non-jet cooktop controls
(knobs may vary from those illustrated)
Off
Note:
If the burner does not light within 15 seconds, turn the
control knob off and wait at least one minute before
High
trying again.
If the cooktop does not light
If the cooktop does not light, check that:
The cooktop is plugged in and the electricity is switched on.
Low
Fig.5 Jet cooktop controls
(knobs may vary from those illustrated)
The gas is turned on.
The electrodes are sparking.
If the electrodes are not sparking, they may be dirty or wet. Clean them with a toothbrush and
methylated spirits, as shown in Fig. 6.
Electrode
Flame failure probe
(some models only)
Fig.6 How to clean an electrode
