Features and Design

◆ Compact Design

This projector is designed compact in size and weight. It is
easy to carry and work anywhere you wish to use.

◆ Compatibility

The projector widely accepts various video and computer
input signals including; Computers, 6 Color systems,
Component video, S-video and RGB scart.

◆ Simple Computer System Setting

The projector has the Multi-scan system to conform to
almost all computer output signals quickly. (See page 24,
28, and 42.)

◆ Digital Zoom (for Computer)

The digital zoom function expands (to approx. 16 times of
screen size) or compress the image size, allowing you to
focus on crucial information at a presentation.
(See page 34.)

◆

Power Management

The Power management function reduces power
consumption and maintain the lamp life. (See page 45.)

◆ User’s Logo

A projected image can be captured and used for the
starting display of the projector with the Capture function.
You can also display the captured image in an interval
during your presentation instead of blackout image with the
No show function. (See page 25 and 44.)

◆ Selectable Lamp Mode

Brightness of the projection lamp can be selected in the
Setting menu. (See page 45.)

◆ Blackboard Function

Blackboard✳ can be used as a projection screen.

✳ The board color is limited to Green.

(See page 32 and 38.)

◆ Film Function

The Film function reproduces pictures faithful to the original
film quality from 3:2 pull-down video contents.
(See page 40.)

◆ PIN Code Lock Function

The PIN code lock function prevents others except users
from using the projector. (See page 20 and 47.)

◆ Multilanguage Menu Display

Operation menu is available in 12 languages; English,
German, French, Italian, Spanish, Portuguese, Dutch,
Swedish, Russian, Chinese, Korean, or Japanese.
(See page 42.)

◆

Switcheable Interface Terminal

The projector provides a switcheable interface terminal.
You can use the terminal as computer input or monitor
output conveniently. (See page 44.)

◆

Auto Setup Function

For quick and easy setup of the projector, Auto Setup
function is provided. Vertical auto keystone correction and
Auto PC adjustment is performed with just pressing one
button. (See page 24 and 42.)

This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector
utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology.

3

Table of Contents

Features and Design . . . . . . . . . . . . . . . . . . .2

Table of Contents . . . . . . . . . . . . . . . . . . . . . .3

To the Owner . . . . . . . . . . . . . . . . . . . . . . . . .4

Safety Instructions . . . . . . . . . . . . . . . . . . . .5

Air Circulation 6
Installing the Projector in Proper Position 6
Moving the Projector 6

Compliance . . . . . . . . . . . . . . . . . . . . . . . . . .7

Part Names and Functions . . . . . . . . . . . . . .8

Front 8
Back 8
Bottom 8
Rear Terminal 9
Top Control 10
Remote Control 11
Laser Pointer Function 12
Pointer Function 12
Wireless Mouse Operation 13
Operating Range 13
Remote Control Code 14
Remote Control Battery Installation 14

Installation . . . . . . . . . . . . . . . . . . . . . . . . . .15

Positioning the Projector 15
Adjustable Feet 15
Connecting the AC Power Cord 16
Connecting to a Computer 17
Connecting to Video Equipment 18
Connecting to Component Video Equipment 19

Basic Operation . . . . . . . . . . . . . . . . . . . . . .20

Turning On the Projector 20
Turning Off the Projector 21
How to Operate the On-Screen Menu 22
Menu Bar 23
Zoom and Focus Adjustment 24
Auto Setup Function 24
Keystone Adjustment 25
Picture Freeze Function 25
No Show Function 25
P-Timer Function 26
Sound Adjustment 26

Computer Input . . . . . . . . . . . . . . . . . . . . .27

Input Source Selection 27
Computer System Selection 28
Auto PC Adjustment 29
Manual PC Adjustment 30
Image Level Selection 32
Image Level Adjustment 33
Screen Size Adjustment 34

Video Input . . . . . . . . . . . . . . . . . . . . . . . . . .35

Input Source Selection (Video, S-Video) 35
Input Source Selection

(Component, RGB Scart 21-Pin)

36
Video System Selection 37
Image Level Selection 38
Image Level Adjustment 39
Screen Size Adjustment 41

Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Setting 42

Maintenance and Cleaning . . . . . . . . . . . . .49

Warning Indicator 49
Cleaning the Air Filters 50
Attaching the Lens Cover 50
Cleaning the Projection Lens 51
Cleaning the Projector Cabinet 51
Lamp Replacement 52
Lamp Replace Counter 53

Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Troubleshooting 54
Menu Tree 56
Indicators and Projector Condition 58
Compatible Computer Specifications 59
Technical Specifications 60
Optional Parts 61
Configurations of Terminals 62
PIN Code Number Memo 63

Trademarks

Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.

4

To the Owner

CAUTION : TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE EXCEPT LAMP REPLACEMENT.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

THIS SYMBOL INDICATES THAT DANGEROUS
VOLTAGE CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE
IMPORTANT OPERATING AND MAINTENANCE
INSTRUCTIONS IN THE OWNER'S MANUAL WITH
THIS UNIT.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Before operating this projector, read this manual thoroughly
and operate the projector properly.
This projector provides many convenient features and
functions. Operating the projector properly enables you to
manage those features and maintains it in better condition for
a considerable time.
Improper operation may result in not only shortening the
product-life, but also malfunctions, fire hazard, or other
accidents.
If your projector seems to operate improperly, read this
manual again, check operations and cable connections and try
the solutions in the “Troubleshooting” section in the end of
this booklet. If the problem still persists, contact the dealer
where you purchased the projector or the service center.

Safety Precaution

WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.

– This projector produces intense light from the projection

lens. Do not stare directly into the lens as possible. Eye
damage could result. Be especially careful that children do
not stare directly into the beam.

–Install the projector in a proper position. If not, it may

result in a fire hazard.

– Provide appropriate space on the top, sides and rear of the

projector cabinet for allowing air circulation and cooling the
projector. Minimum clearance must be maintained. If the
projector is to be built into a compartment or similarly
enclosed, the minimum distances must be maintained. Do
not cover the ventilation slot on the projector. Heat build­up can reduce the service life of your projector, and can
also be dangerous.

– Do not put any flammable object or spray can near the

projector, hot air is exhausted from the ventilation holes.

– If the projector is not to be used for an extended time,

unplug the projector from the power outlet.

READ AND KEEP THIS OWNER'S MANUAL FOR LATER
USE.

SIDE and TOP REAR

CAUTION

Not for use in a computer room as defined in the Standard for
the Protection of Electronic Computer/Data Processing
Equipment, ANSI/NFPA 75.

Ne puet être utillisé dans une salle d’ordinateurs telle que
définie dans la norme ANSI/NFPA 75 Standard for Protection
of Electronic Computer/Data Processing Equipment

20cm

50cm 50cm

50cm

5

Safety Instructions

All the safety and operating instructions should be read before
the product is operated.

Read all of the instructions given here and retain them for later
use. Unplug this projector from AC power supply before
cleaning. Do not use liquid or aerosol cleaners. Use a damp
cloth for cleaning.

Follow all warnings and instructions marked on the projector.
For added protection to the projector during a lightning storm,

or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet. This will prevent damage
due to lightning and power line surges.

Do not expose this unit to rain or use near water... for
example, in a wet basement, near a swimming pool, etc...

Do not use attachments not recommended by the
manufacturer as they may cause hazards.

Do not place this projector on an unstable cart, stand, or table.
The projector may fall, causing serious injury to a child or
adult, and serious damage to the projector. Use only with a
cart or stand recommended by the manufacturer, or sold with
the projector. Wall or shelf mounting should follow the
manufacturer's instructions, and should use a mounting kit
approved by the manufacturers.

An appliance and cart combination should
be moved with care. Quick stops,
excessive force, and uneven surfaces
may cause the appliance and cart
combination to overturn.

Slots and openings in the back and bottom of the cabinet are
provided for ventilation, to ensure reliable operation of the
equipment and to protect it from overheating.

The openings should never be covered with cloth or other
materials, and the bottom opening should not be blocked by
placing the projector on a bed, sofa, rug, or other similar
surface. This projector should never be placed near or over a
radiator or heat register.

This projector should not be placed in a built-in installation
such as a book case unless proper ventilation is provided.

Never push objects of any kind into this projector through
cabinet slots as they may touch dangerous voltage points or
short out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the projector.

Do not install the projector near the ventilation duct of air­conditioning equipment.

This projector should be operated only from the type of power
source indicated on the marking label. If you are not sure of
the type of power supplied, consult your authorized dealer or
local power company.

Do not overload wall outlets and extension cords as this can
result in fire or electric shock. Do not allow anything to rest
on the power cord. Do not locate this projector where the
cord may be damaged by persons walking on it.

Do not attempt to service this projector yourself as opening or
removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service
personnel.

Unplug this projector from wall outlet and refer servicing to
qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the projector.
c. If the projector has been exposed to rain or water.
d. If the projector does not operate normally by following the

operating instructions. Adjust only those controls that are
covered by the operating instructions as improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the projector to normal operation.

e. If the projector has been dropped or the cabinet has been

damaged.

f. When the projector exhibits a distinct change in

performance-this indicates a need for service.

When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer that have the same characteristics as the
original part. Unauthorized substitutions may result in fire,
electric shock, or injury to persons.

Upon completion of any service or repairs to this projector,
ask the service technician to perform routine safety checks to
determine that the projector is in safe operating condition.

Voor de klanten in Nederland

Bij dit product zijn batterijen
geleverd.
Wanneer deze leeg zijn, moet u

ze niet weggooien maar inleveren
als KCA.

NL

6

Safety Instructions

USE CAUTION IN CARRYING OR
TRANSPORTING THE PROJECTOR

–Do not drop or bump a projector, otherwise damages or

malfunctions may result.
– When carrying a projector, use a suitable carrying case.
– Do not transport a projector by using a courier or transport

service in an unsuitable transport case. This may cause

damage to a projector. To transport a projector through a

courier or transport service, consult your dealer for their

information.

Moving the Projector

CAUTION

Carrying Bag (supplied) is intended for protection from dust
and scratches on the surface of a cabinet, and it is not
designed to protect an appliance from external forces. Do not
transport a projector through a courier or transport services
with this bag, otherwise the projector can be damaged. When
handling a projector, do not drop, bump, subject it to strong
forces or put other things on the cabinet.

When moving the projector, replace the Lens Cover and
retract Adjustable Feet to prevent damage to the lens and
cabinet.
When the projector is not in use for an extended period, put
it into the case (carrying bag) supplied with the projector.

7

AC Power Cord for the United Kingdom :

This cord is already fitted with a moulded plug incorporating a fuse, the value of which is indicated on the pin face of the plug. Should the
fuse need to be replaced, an ASTA approved BS 1362 fuse must be used of the same rating, marked thus . If the fuse cover is
detachable, never use the plug with the cover omitted. If a replacement fuse cover is required, ensure it is of the same colour as that visible
on the pin face of the plug (i.e. red or orange). Fuse covers are available from the Parts Department indicated in your User Instructions.
If the plug supplied is not suitable for your socket outlet, it should be cut off and destroyed.
The end of the flexible cord should be suitably prepared and the correct plug fitted. (See Over)

WARNING : A PLUG WITH BARED FLEXIBLE CORD IS HAZARDOUS IF ENGAGED IN A LIVE SOCKET
OUTLET.

The Wires in this mains lead are coloured in accordance with the following code:

Green-and-yellow ············ Earth
Blue ································· Neutral

Brown ······························ Live
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in
your plug proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked by the letter E or by the safety
earth symbol or coloured green or green-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

WARNING : THIS APPARATUS MUST BE EARTHED.

The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it.

AC Power Cord for the United States and Canada :

AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and
certified by the Canadian Standard Association (CSA).
AC Power Cord has a grounding-type AC line plug. This is a safety feature to be sure that the plug will fit into
the power outlet. Do not try to defeat this safety feature. Should you be unable to insert the plug into the
outlet, contact your electrician.

THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILY ACCESSIBLE.

AC Power Cord Requirement

Federal Communication Commission Notice

Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures :

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.

Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in the instructions. If such changes or

modifications should be made, you could be required to stop operation of the equipme
Model Numbers : PLC-XU56, PLC-XU51, PLC-SU51

Trade Name : Sanyo
Responsible party : SANYO FISHER COMPANY
Address : 21605 Plummer Street, Chatsworth, California 91311

Telephone No. : [phone]

Compliance

ASA

GROUND

8

9

Part Names and Functions

A built-in micro processor which controls this unit may occasionally
malfunction and need to be reset. This can be done by pressing the RESET
button with a pen, which will shut down and restart the unit. Do not use the
RESET function excessively.

Rear Terminal

q

w e

r

t y

o i u

i S-VIDEO

Connect the S-VIDEO output from video equipment to
this jack. (p18)

e AUDIO IN

Connect the audio output from video equipment
connected to r or i to this jack. (When the audio
output is monaural, connect it to L (MONO) jack.) (p18)

y AUDIO IN COMPUTER/ COMPONENT

Connect the audio output (stereo) from a computer or
video equipment connected to q or o to this jack.
(p 17, 19)

r

VIDEO

Connect the composite video output from video
equipment to VIDEO jack. (p18)

o COMPUTER IN 2/ COMPONENT IN/ MONITOR OUT

This terminal is switcheable and can be used for input
from a computer, video equipment (Component or RGB
Scart) or output to the other monitor. Optional cables
are required when using this terminal as component
input or RGB Scart 21-Pin Video input. (p61)
Set the terminal up as either Computer input or Monitor
output properly. (Used for Monitor out, this terminal
outputs only incoming signal from COMPUTER IN 1 DVI­I terminal.) (p17, 19, 44)

u AUDIO OUT(VARIABLE)

Connect an external audio amplifier to this jack.
(p17- 19)
This terminal outputs sound from AUDIO IN terminal (e
or y).

t USB (Series B)

When operating the connected computer with the
remote control, connect USB port of your computer to
this connector with a USB cable. (p17)

w SERVICE PORT

This jack is used to service this projector.

✽

Part Names and Functions

✽

Do not press this button. This button is used for optional
accessories.

q COMPUTER IN 1 DVI-I

Connect output signal from a computer (Digital/Analog
DVI-I type) or Multi Card Imager (optional) to this
terminal. (p17)

COMPUTER IN 1

DVI - I

RESET

COMPUTER IN 2 /

MCI

COMPONENT IN /

MONITOR OUT

AUDIO IN

R VIDEOL

SERVICE PORT

(MONO)

S-VIDEO

USB

COMPUTER /
COMPONENT

AUDIO IN

AUDIO OUT

(VARIABLE)

10

Part Names and Functions

ON - OFF

POWER

AUTO SET UP

INPUT

WARNING

LAMP

REPLACE

SELECT

MENU

V

O

L

U

M

E

–

V

O

L

U

M

E

+

q w e

r

t y

o i u

u LAMP REPLACE indicator

Turns yellow when the life of the projection lamp draws
to an end. (p52)

y WARNING indicator

Lights red when the projector detects abnormal
condition. This also blinks red when the internal
temperature of the projector exceeds the operating
range. (p49)

e POWER ON–OFF button

Turns the projector on or off. (p20, 21)

t

POWER indicator

Blinks red until the projector gets ready to be turned on.
It turns red when the projector is in the stand-by mode.
It remains green while the projector is under operation.

w INPUT button

Selects input source. (p27, 36 )

o MENU button

Opens or closes the On-Screen Menu. (p22)

i POINT (

eedd

7 8 ) button

Selects an item or adjusts value in the On-Screen Menu.
These are also used to pan the image in the Digital zoom
+/– mode. (p34)
Point

7 8 button are used as VOLUME +/– button.

(p26)

r SELECT button

Executes the item selected. It is also used to expand/
compress the image in Digital zoom +/– mode. (p34)

q AUTO SETUP button

Corrects vertical keystone distortion and adjusts
computer display parameters including Fine sync., Total
dots and Picture position. (p24, 42)

Top Control

11

Part Names and Functions

Part Names and Functions

Remote Control

q

w
e
r

t
y

u

i

o

!0
!1

!4

!5

!6
!7

!9

@0

@1

!2
!3

@2

@2 RESET/ON/ALL-OFF switch

When using the remote control, set this switch to “ON.” Set it to “ALL OFF” for
power saving when it is not used. Slide this switch to "RESET" to initialize the
remote control code or switch Spotlight and Pointer back to Laser pointer. (p12, 14)

w SIGNAL EMISSION indicator

This indicator lights red while the laser beam is being emitted from the laser light
window or a signal is being sent from the remote control to the projector.

e AUTO PC button

Operates the Auto PC adjustment function. (p29)

r D.ZOOM button

Selects the Digital zoom +/– mode and resize the image. (p34)

!7

MUTE button

Mutes sound. (p26)

i POINT (

eedd

7 8) button

Selects an item or adjusts value in the On-Screen Menu. These are also used to pan
the image in the Digital zoom +/- mode. (p34)
Point 7 8 button are also used as VOLUME +/- buttons. (p26)

!0 MENU button

Opens or closes the On-Screen Menu. (p22)

!3 LASER button

Operates the Laser pointer function. Laser beam is emitted while pressing this
button within 1 minute. When using this laser pointer for more than 1 minute,
release the LASER button and press it again. This button is also used as a
switching button to activate the Pointer function of the projector. (p12)

!4 POWER ON-OFF button

Turns the projector on or off. (p20, 21)

!5 NO SHOW button

Turns the picture into black image. (p25)

t FREEZE button

Freezes the projected picture. (p25)

y IMAGE button

Selects image levels.(p32, 38)

!2 SELECT button

Executes the item selected, or to expand or compress image in the Digital zoom +/­mode. (p34)

!6

P-TIMER button

Operates P-Timer function. (p26)

u PAGE UP/DOWN button

Turns pages; the Up button to the previous page and the Down button to the next
page for an image from a computer. Connect the projector and your computer with
a USB cable before use. (See page 17.)

!9 R-CLICK button

Acts as right click for wireless mouse operation. (p13)

q L-CLICK button

Acts as left click for wireless mouse operation. (p13)

@1 VIDEO button

Selects input source (VIDEO). (p35)

!1 KEYSTONE button

Corrects keystone distortion. (p25, 42)

o PRESENTATION POINTER button

Move a pointer of the projector or a pointer for wireless mouse operation. (p12)

!8

!8

AUTO SET button

Corrects vertical keystone distortion and adjusts PC display parameters. (p24, 42)

@0 COMPUTER button

Selects input source (COMPUTER 1 or COMPUTER 2). (p27, 36)

12

Part Names and Functions

Spotlight

Pointer Function

Pointer

✔Note:

You can choose the size of Spotlight (Large, Middle, and Small) and the pattern of
Pointer (Arrow, Finger, and Dot) in the Setting Menu. See “Pointer” on page 46.

This remote control emits a laser beam from the laser light window. With the LASER button pressed, laser light goes on.
The signal emission indicator lights red and laser is emitted with red light. With the LASER button pressed for more than 1
minute or released, the light goes off.
The laser emitted is a class II laser. Do not look into the laser light window or shine the laser beam on yourself or other
people. Below are the caution labels for laser beam.

CAUTION

13

Part Names and Functions

Part Names and Functions

The remote control can be used as a wireless mouse for your computer. Before operating the wireless mouse, connect
your computer and the projector with the supplied USB cable. (See page 17 for connection.)
When the Pointer function is used, the wireless mouse is not available.

Move the pointer on the screen
with this button.

PRESENTATION POINTER button

R-CLICK button

L-CLICK button

Acts as right click while the
projector and a computer are
connected with a USB cable.

Acts as left click while the
projector and a computer are
connected with a USB cable.

Point the remote control toward the projector (Infrared
Remote Receiver) whenever pressing any button. Maximum
operating range for the remote control is about 16.4’ (5m)
and 60° in front of the projector.

16.4’
(5 m)

60°

Operating Range

Wireless Mouse Operation

Remote control

14

Part Names and Functions

To insure safe operation, please observe the following precautions :

● Use (2) AA, UM3 or LR6 type alkaline batteries.

● Replace two batteries at the same time.

● Do not use a new battery with a used battery.

● Avoid contact with water or liquid.

● Do not expose the remote control to moisture, or heat.

● Do not drop the remote control.

● If a battery has leaked on remote control, carefully wipe case clean and install new batteries.

● Risk of explosion if battery is replaced by an incorrect type.

● Dispose of used batteries according to the instructions.

15

Installation

Projection angle can be adjusted up to 11.8 degrees with the
adjustable feet.

Lift the front of the projector and pull upward the feet lock
latches on both sides of the projector.

1

Adjustable Feet

Feet Lock Latches

Release the feet lock latches to lock the adjustable feet and
rotate the adjustable feet to adjust the position and tilt.

2

To retract the adjustable feet, lift the front of the projector
and pull and undo the feet lock latches.
Keystone distortion of the projected image can be adjusted
automatically with Auto Setup function or manually with the
remote control or the menu operation. (p24, 25, and 42)

3

Adjustable Feet

✔Note:

• The brightness in a room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image.

• The values shown above are approximate and may vary from the actual size.

Positioning the Projector

Installation

25.3' (7.7m)

16.4' (5.0m)

12.5' (3.8m)

8.2' (2.5m)

Max. Zoom

Min. Zoom

A : B = 9 : 1

Screen Size

(W x H) mm

4 : 3 aspect ratio

Zoom (min)

40”

Zoom (max)

813 x 610

4.9' (1.5m)

3.3' (1.0m)

100”

2032 x 1524

12.8' (3.9m)

8.2' (2.5m)

150”

3048 x 2286

19.3' (5.9m)

12.5' (3.8m)

195”

3962 x 2972

25.3' (7.7m)

16.4' (5.0m)

300”

6096 x 4572

––-––

25.3' (7.7m)

(Inch Diagonal)

3.3' (1.0m)

This projector is designed to project on a flat projection surface and can be focused from 3.3’(1.0m) - 25.3’(7.7m). Refer to
the figure and the table below for the screen size and the distance between the projector and the screen.

(Center)

A

150”

195”

127”

300”

195”

100”

97”

40”

64”

B

16

NOTE ON THE POWER CORD

AC power cord must meet requirement of the country where you use a projector.
Confirm an AC plug type with the chart below and proper AC power cord must be used.
If supplied AC power cord does not match your AC outlet, contact your sales dealer.

Installation

To power cord
connector on your
projector.

Projector side AC outlet side

Ground

To the AC outlet.

(120 V AC)

For Continental Europe

For the U.S.A. and Canada

This projector uses nominal input voltages of 100-120 V or 200-240
V AC. This projector automatically selects the correct input
voltage. It is designed to work with single-phase power systems
having a grounded neutral conductor. To reduce risk of electrical
shock, do not plug into any other type of power system.
Consult your authorized dealer or service station if you are not sure
of the type of power being supplied.
Connect the projector with all peripheral equipment before turning
the projector on. (See page 17-19 for connection.)

CAUTION

For safety, unplug AC power cord when the projector is not in
use. When this projector is connected to an outlet with AC
power cord, it is in Stand-by mode and consumes a little electric
power.

Connecting the AC Power Cord

Connect AC power cord (supplied) to the
projector.
The AC outlet must be near this equipment and
must be easily accessible.

For the U.K.

To the AC outlet.

(200 - 240 V AC)

To the AC outlet.

(200 - 240 V AC)

17

Installation

Installation

Connecting to a Computer

DVI - I

RESET

COMPUTER IN 2 /
COMPONENT IN /

MONITOR OUT

AUDIO IN

R VIDEOL

SERVICE PORT

(MONO)

S-VIDEO

USB

COMPUTER /
COMPONENT

AUDIO IN

AUDIO OUT

(VARIABLE)

COMPUTER IN 1

MCI

ONON

18

COMPUTER IN 1

DVI - I

COMPUTER IN 2 /
COMPONENT IN /

MONITOR OUT

RESET

AUDIO IN

R VIDEOL

SERVICE PORT

(MONO)

S-VIDEO

USB

COMPUTER /
COMPONENT

AUDIO IN

AUDIO OUT

(VARIABLE)

19

Installation

Installation

Connecting to Component Video Equipment

COMPUTER IN 1

DVI - I

MONITOR OUT

S-VIDEO

COMPUTER IN 2 /
COMPONENT IN /

COMPUTER /
COMPONENT

AUDIO IN

AUDIO IN

R VIDEOL

USB

SERVICE PORT

RESET

(MONO)

(VARIABLE)

AUDIO OUT

S-VIDEO

COMPUTER

/ COMPONENT

AUDIO IN

AUDIO IN

R VIDEOL

USB

SERVICE PORT

(MONO)

AUDIO OUT

(VARIABLE)

COMPUTER IN 1

DVI - I

MONITOR OUT

COMPUTER IN 2 /
COMPONENT IN /

RESET

MCI

Cables used for connection

• Audio Cables (Mini Plug (stereo) x 2 or RCA x 2) ✽

• Scart-VGA Cable ✽

• Component-VGA Cable ✽
(✽ = Not supplied with this projector.)

Note:

When connecting the cable, the power cords of both the projector and
the external equipment should be disconnected from AC outlet.

✔Note:

• Input sound to the COMPUTER/COMPONENT AUDIO IN terminal when using the
COMPUTER IN 2/COMPONENT IN/MONITOR OUT terminal as input.

• When connecting AUDIO OUT to external audio equipment, the projector's built-in
speaker is disconnected.

External Audio Equipment

COMPUTER IN 2/
COMPONENT IN/
MONITOR OUT

COMPUTER IN 2/
COMPONENT IN/
MONITOR OUT

COMPUTER/ COMPONENT
AUDIO IN

Audio cable ✽
(stereo)

Audio cable ✽
(stereo)

Audio Input

Component Video Output

(Y, Pb/Cb, Pr/Cr)

RGB Scart 21-pin Output Audio Output

Scart-VGA cable ✽ Component-VGA

cable✽

AUDIO OUT
(stereo)

20

Connect the projector's AC power cord into an AC outlet.
The POWER indicator blinks red in a moment and lights red.

Press the POWER ON-OFF button on the top control or on
the remote control. The POWER indicator turns green
lighting and the cooling fans start to operate. The
preparation display appears on the screen and the count
down starts.

2
3

1

16

The preparation display disappears after 20 seconds.

4

After the count-down, the input source that was selected
last and the Lamp mode status icon (see page 45) appear on
the screen.

If the projector is locked with a PIN code, PIN code Input
Dialog Box will appear. Enter the PIN code as instructed
below.

(See page 45 for Lamp mode.)

Selected Input Source and Lamp Mode

Complete peripheral connections (with a computer, VCR,
etc.) before turning on the projector.

Lamp mode

What is PIN code?

PIN code is a security code using Personal Identification Number that
allows the person who knows it to operate the projector. Setting PIN code
prevents others except the specific users from operating the projector.

A PIN code consists of a four-digit number. Refer to PIN Code Lock
function in Setting on page 47 for locking operation of the projector with
your PIN code.

Pointer

After the OK icon
disappears, you can
operate the projector.

PIN code Input Dialog Box

Turning On the Projector

Basic Operation

Enter a PIN code

Select a number by pressing the Point 7 8 button and fix the number with
the SELECT button. The number will change to "✳". If you fixed a wrong
number, move the pointer to "Set" or "Clear" once by pressing the Point

dd

button, then return to "PIN code". Enter the correct number again.
Repeat this step to complete entering a four-digit number.

When the four-digit number is fixed, the pointer will automatically move to
"Set". Press the SELECT button so that you can start to operate the
projector.

If you entered a wrong PIN code, "PIN code" and the number (✳✳✳✳) will
turn red and disappear. Enter a correct PIN code all over again.

CAUTION ON HANDLING PIN CODE

If you forget your PIN code, the projector can no
longer be started. Set a new PIN code with special
care, write it down in column on page 63 of this
manual, and keep it at hand. Should the PIN code be
missing or forgotten, consult your dealer or service
center.
