Gl o s s a r y o f Te r m s
A
Absolute Pressure (abs press) - Gauge pressure plus barometric pressure. Absolute pressure can be zero only in a perfect vacuum.
Absolute Viscosity (abs visc) - The product of uid kinematic viscosity times its density. Absolute viscosity is a measure of uid tendency to
resist ow, without regard to its density. Sometimes the term dynamic viscosity is used in place of absolute viscosity. Refer to Viscosity, Absolute.
Accuracy - A measure of how close a regulator can keep downstream pressure (P2) to the setpoint. Regulator accuracy is expressed as percent
droop or proportional band or offset in percent of setpoint or in units of pressure.
ACFH - Actual Cubic Feet per Hour. The actual volume of uid measured by the meter. This is not SCFH (standard cubic feet per hour).
Active/Working Regulator - A regulator that is in service performing a control function.
Adjusting Screw - A screw used to change the compression setting of a loading spring.
AGA - The American Gas Association or Australian Gas Association.
Airsets - See Filter/Supply Regulators.
ALPGA - Australian Liqueed Petroleum Gas Association, Ltd.
ANSI - American National Standards Institute.
API - American Petroleum Institute.
Appliance (Equipment) - Any device that uses gas as a fuel or raw material to produce light, heat, power, refrigeration, or air conditioning.
ASME - American Society of Mechanical Engineers.
Aspirator - Any device using uid velocity effect to produce a low-pressure zone. Used in regulator control and combustion systems.
Atmospheric Pressure - The pressure exerted by the atmosphere at a given location and time. Sea level pressure is approximately 14.7 pounds
per square inch absolute (1.0 bar absolute).
Automatic Control System - A control system that operates without human intervention.
Automatic Cutoff - A device used on some regulators to close the main valve in the event of pressure deviation outside of a preset range.
Must be reopened manually.
B
Backpressure Regulator - This is a device that controls and responds to changes in its upstream/inlet pressure. Functions the same as a relief
valve in that it opens on increasing upstream pressure.
Barometer - An instrument for measuring atmospheric pressure, usually in inches, centimeters, or millimeters of mercury column.
Barometric Pressure - The atmospheric pressure at a specic place according to the current reading of a barometer.
Bellows - A exible, thin-walled cylinder made up of corrugations one next to the other that can expand or contract under changing pressures.
Bimetallic Thermal System - A device working on the difference in coefcient of expansion between two metals to produce the power to
position a valve plug in response to temperature change.
Bleed - Removal of uid from a higher pressure area to a lower pressure area in a regulator pilot system.
Bode Diagram - A plot of log amplitude ratio and phase values on a log frequency base for a transfer function. (It is a common form of
graphically presenting frequency response data.)
Body - Pressure retaining shell enclosing the restricting element.
Boiler - A closed vessel in which a liquid is heated or vaporized.
Bonnet - The regulator component that connects the valve body to the actuator.
713
714
Gl o s s a r y o f Te r m s
Boost - The increase in control pressure above setpoint as ow is increased from low ow to maximum ow. Some regulators exhibit droop
instead of boost.
British Thermal Unit (BTU) - The quantity of heat required to raise one pound of water from 59° to 60°F.
Build-up - In a relief valve, the pressure increase above setpoint required to produce a given ow rate.
BSPT - British Standard Pipe Thread.
C
C1 - A term used in a sizing equation. It is dened as the ratio of the gas sizing coefcient and the liquid sizing coefcient and provides a
numerical indicator of the valve’s recovery capabilities.
Cage - A hollow, cylindrical trim element that is a guide to align the movement of a valve plug with a seat ring and/or retains the seat ring in
the valve body. The walls of the cage contain openings that usually determine the ow characteristic of the control valve.
Capacity, Flow - The amount of a specied uid that will ow through a valve, specic length and conguration of tubing, a manifold, tting,
or other component at a specied pressure drop in a xed period of time. (SCFH, gpm, Nm³/h, Lpm, bph).
Capacity, Rated - The rate of ow through the regulator specied by the manufacturer for a given inlet pressure, outlet pressure,
offset, and size.
Capacity, Wide-Open - If a wide-open failure occurs, this is the amount a regulator will ow.
Cavitation - A phenomenon whereby liquid owing through a valve under reduced pressure will form gaseous bubbles that will collapse upon
pressure recovery, producing potential trim damage. This is a concern when high-pressure drops exist across the valve.
Centipoise - A unit for measurement of absolute viscosity. One centipoise is equal to one hundredth of a poise, the metric (cgs) unit of absolute
viscosity. The absolute viscosity of water at 20°C is approximately one centipoise.
Centistoke - A unit for measurement of kinematic viscosity. One centistoke is equal to one hundredth of a stoke, the metric (cgs) unit of
kinematic viscosity. The kinematic viscosity in centistokes times the density equals the absolute viscosity in centipoises.
CFH - Cubic Feet per Hour (ft3/h). Volumetric measurement of gas ow per hour, generally at line conditions.
Cg (Flow Coefcient) - A term used in gas and steam valve sizing equations. The value of Cg is proportional to ow rate and is used to predict
ow based on physical size or ow area.
CGA - Canadian Gas Association.
Coal/Coke Oven Gas - A gas with a high sulfur content that is produced from baking coal. It may also contain tar that can cause sticking
in moving parts of a regulator. Regulators with brass or copper parts should not be used with this gas. Often this gas requires the
use of fluoroelastomers.
Compressibility Effect - The change in density of gas or air under conditions of compression.
Compression (Spring) - The action on a spring which decreases its length relative to the force to which it is subjected.
Condensate - The liquid resulting when a vapor is cooled and/or when its pressure is increased.
Control Line - The external piping which connects the regulator actuator or pilot to the point on the main line where control is required.
Control Valve - A mechanically, electrically, or hydraulically operated valve, using an external power source to effect its operation, that
modies the uid ow characteristics in a process. It consists of a valve connected to an actuator mechanism that is capable of changing the
position of the ow controlling element or closure member in the valve in response to a signal from the controlling device.
Controller - A device that operates automatically to regulate a controlled variable.
Critical Flow - The rate at which a uid ows through an orice when the stream velocity at the orice is equal to the velocity of sound in the
uid. Under such conditions, the rate of ow may be increased by an increase in upstream pressure, but it will not be affected by a decrease
in downstream pressure. Critical ow occurs when P2 is approximately 1/2 of P1 absolute.
Critical Velocity - The velocity at critical ow. Also called sonic velocity.
715
Gl o s s a r y o f Te r m s
CSA - Canadian Standards Association.
Cs (Flow Coefcient) - Steam valve sizing coefcient. At pressures below 1000 psig, a constant relationship exists between the gas sizing
coefcient (Cg) and the steam coefcient (Cs). This relationship is expressed: Cs = Cg ÷ 20.
Cv (Flow Coefcient) - Liquid sizing coefcient. It is numerically equal to the number of U.S. Gallons of water at 60°F that will ow through
the valve in one minute when the pressure differential across the valve is one pound per square inch.
D
Dead Band - The range through which an input can be varied without initiating observable response.
Delta P (DP) (∆P) (Pressure Drop) - The difference between the inlet and outlet pressures.
Demand - The rate at which uid is delivered to or required by a system, part of a system, or a piece of equipment, usually expressed in terms
of volume per unit of time.
Density - The weight of a unit volume of a substance. Also called specic weight.
Diaphragm - A exible membrane used in a regulator or relief valve to sense changes in downstream pressure and respond to them, thus
moving the restricting element or closure member to which it is attached.
Diaphragm Actuated Regulator - A regulator utilizing a diaphragm and actuator to position the valve plug.
Diaphragm Case - A housing used for supporting a diaphragm and establishing one or two pressure chambers.
Diaphragm Effect - The change in effective area of the diaphragm as the regulator strokes from low to high ow.
Diaphragm Plate - A plate used to transmit force in conjunction with a diaphragm and uid pressure on a spring to the actuator stem or
pusher post.
Differential Pressure - The difference in pressure between two points in a system.
Differential Pressure Regulator - A device that maintains a constant differential pressure between a reference pressure and the pressure of
the controlled uid.
Digester Gas - A gas produced by sewage treatment plants. This gas is used to power burners and engines. Because of its high methane
content, stainless steel construction might be required.
Disk - A movable part that is positioned in the ow path to modify the rate of ow through the valve. It is often made of an elastomer material
to improve shutoff capability.
Downstream - Any site beyond a reference point (often a valve or regulator) in the direction of uid ow.
Drift - A change in setpoint over an extended period of time.
Droop - The amount a regulator deviates below its setpoint as ow increases. Some regulators exhibit boost instead of droop.
DVGW - Deutscher Verein des Gas - und Wasserfaches e.v. (German approval agency).
Dynamic Unbalance - The force exerted on a valve plug when uid is owing through the valve.
E
Effective Area - In a diaphragm actuator, the part of the diaphragm area that generates operating force. The effective area is less than the
total area. (The effective area of a diaphragm might change as it is stroked, usually being a maximum at the start and a minimum at the end
of the travel range. Molded diaphragms have less change in effective area than at-sheet diaphragms.)
End Connection - The style of joint used to make a pressure tight connection between the valve body and the pipeline.
Entropy - A thermodynamic quantity that measures the fraction of the total energy of a system that is not available for doing work.
716
Gl o s s a r y o f Te r m s
Enthalpy - Total heat content, expressed in BTU per pound, above an arbitrary set of conditions chosen as the base or zero point.
External Pressure Registration - A regulator with a control line. The actuator pressure is isolated from the body outlet pressure within
the regulator.
External Static Line - The same as control line.
F
Face-to-Face Dimension - The dimension from the face of the inlet opening to the face of the outlet opening of the regulator.
Fail-Closed - In the event of a regulator failure, a condition wherein the valve port remains closed. All regulators can fail open or closed.
Fail-Open - In the event of a regulator failure, a condition wherein the valve port remains open. All regulators can fail open or closed.
Filter/Supply Regulators - Pressure reducing regulators used in air service to simultaneously lter and reduce pressure. Used to supply
process control instruments pneumatic power. Also called airsets.
First-Stage Regulator - A regulator used to reduce inlet pressure to a set value being fed to another regulator in series.
Fixed Factor Measurement - The measurement of gas at a controlled elevated pressure without the use of an automatic correcting device to
correct the volume for variation from base or contract pressure. This is accomplished by placing an accurate regulator upstream of the meter.
Also known as PFM (Pressure Factor Measurement).
Fixed Restriction - A small diameter hole in the pilot or piloting system that determines gain.
Flange - End connections of regulator valve bodies used for bolting onto another tting or pipe element.
Flange Facing - The nish on the end connection of valves.
Flashing - A condition when liquid changes to the vapor state caused by pressure reduction inside a valve.
Flow Capacity - The rated ow through a regulator under stated inlet, outlet, and droop pressures.
Flow Characteristic - Relationship between ow through the valve and percent rated travel.
Flow Coefcient - See Cv, Cs, Cg, C1.
Flow Rate - The amount (mass, weight, or volume) of uid owing through a valve body per unit of time.
Fluid - Materials in a liquid, gas, or vapor state, as opposed to a solid.
Fuel Gas - A commonly distributed gas used for fuel, such as natural gas, propane, landll gas, etc.
Full Capacity Relief - A relief valve that has the capability of maintaining downstream pressure to within certain limits in the event of some
type of failure, by venting the excess gas to the atmosphere.
G
Gage Pressure - (Psig or bar g) The difference between atmospheric pressure and the pressure being measured. Also written gauge pressure.
Gas - That state of matter which expands to ll the entire container which holds it. Gas is one of the forms of matter (solid, liquid, and gas).
Gas Utilization Equipment - Any device which utilizes gas as a fuel or raw material, or both.
Gauge Pressure - Pressure reading as shown on a gauge (psig or bar g). The difference between atmospheric pressure and the pressure the
gauge is measuring. Also written gage pressure.
Gauge, Pressure - An instrument that measures the pressure of a uid.
Governor - An attachment to a machine for automatic control or limitation of speed. Also, an archaic term used for a low-pressure, direct-
operated, pressure reducing gas regulator.
717
Gl o s s a r y o f Te r m s
h
Hard Facing - A material harder than the surface to which it is applied. Used to resist galling or uid erosion.
Header - A piping conguration where a number of pipes are combined at one location.
Hunting - A condition in which a regulator’s outlet pressure slowly uctuates on either side of a setpoint.
Hysteresis - A deviation from setpoint caused by friction and parts clearance.
I
Impulse Line - See control line.
Inch of Water - A unit of pressure measurement. The pressure required to support a column of water one inch high. Typically reported as
inches w.c. (water column); 27.68-inches of water is equal to one pound per square inch (psi).
Inlet Pressure - The pressure at the inlet opening of a valve (P1).
Inlet Pressure Sensitivity - The increase or decrease in the outlet pressure caused by changes in the inlet pressure which results in differing
degrees of force being applied to the seat disk and diaphragm.
Internal Relief Valve - A small, spring-loaded pressure relief valve contained within the regulator at the center of the diaphragm to prevent
outlet pressure from exceeding a predetermined pressure.
Isolation Valve - Refer to Valve, Isolation.
I/O - Input/Output -- Electrical inputs and electrical outputs.
J - K - L
Km - Value recovery coefcient - used in liquid sizing equations to determine ∆P allowable for cavitation.
Kinematic Viscosity (kin visc) - The relative tendency of uids to resist ow. The value of the kinematic viscosity includes the effect of the
density of the uid. The kinematic viscosity is equal to the absolute viscosity divided by the density. Refer to Viscosity, Kinematic.
LCD - Liquid crystal display; readout panel which displays alphanumeric sequences in digital format.
Landll Gas - A gas produced by decaying organic matter in a garbage landll. This gas is used to power burners and engines. This gas has
a high methane content and may contain other gases; therefore, stainless steel construction is usually required.
Liquid Expansion Thermal System - A closed system containing liquid whose expansion and contraction in response to temperature changes
provides the power to position a valve member.
Liqueed Petroleum Gas (LPG) - Butane, propane, or a mixture of the two, obtained from oil or gas wells, or as a by-product from the
rening of gasoline. It is sold in metal bottles under pressure as a liquid; hence, sometimes called bottled gas.
Loading Element - In a regulator, the means for placing a measured amount of force against the regulator’s diaphragm. The loading element
is commonly a spring.
Loading Pressure - The pressure employed to position a pneumatic actuator. (This is the pressure that actually works on the actuator diaphragm
or piston to change the position of the valve plug.)
Lockup Pressure - Increase over setpoint when the regulator is at no-ow condition.
718
Gl o s s a r y o f Te r m s
M
Maximum Allowable Operating Pressure (MAOP) - The maximum pressure that the system may be operated at as determined by its
components, taking into account function and a factor of safety based on yield of parts or fracture.
Maximum Operating Pressure - The maximum pressure existing in a piping system during normal operation.
Measuring Element - A diaphragm that senses (measures) changes in downstream pressure and causes the regulator restricting element to
move toward the open or closed position.
Meters Cubed per Hour (Normal or Standard) - Refer to Nm3/h or Sm3/h.
Minimum Controllable Flow - The lowest ow at which a steady regulated condition of the controlled variable can be maintained.
Modbus - Protocol used for communications between electronic devices developed by Gould Modicon.
N - O
NACE - National Association of Corrosion Engineers
Natural Gas - A hydrocarbon gas consisting mainly of methane.
Needle Valve - Refer to Valve, Needle.
Nm3/h - meters cubed per hour (normal); measurement of volume rate of a gas at atmospheric pressure and 0°C. Also refer to Sm3/h.
NPT - National Pipe Thread, a standard for tapered thread used on pipes and pipe ttings.
Offset - The deviation from setpoint for a given ow. Negative offset is equivalent to droop.
Operating Pressure - The actual pressure at which a device operates under normal conditions. This pressure may be positive or negative
with respect to atmospheric pressure.
Orice - A xed opening, normally the inside diameter of a seat ring, through which uid passes. The term can also refer to the inlet or outlet
of a regulator or pilot valve. Also called a port.
Outlet Pressure (Reduced Pressure) - The pressure leaving the outlet opening of a valve (P2).
Over-Pressure Cut-Off Device - A mechanical device incorporated in a gas pipework system to shutoff the supply of gas when the pressure
at the sensing point rises to a predetermined value.
P
P1 - Inlet or upstream pressure.
P2 - Outlet or downstream pressure.
PFM (Pressure Factor Measurement) - The measurement of gas at a controlled elevated pressure without the use of an automatic correcting
device to correct the volume for variation from base or contract pressure. This is accomplished by placing an accurate regulator upstream of
the meter. Also known as Fixed Factor Measurement
PID - Proportional/Intergral/Derivative device. Usually used as a controller.
Pilot (Amplier) - A relatively small controlling regulator that operates the main regulator. They are used to increase accuracy.
Piston Actuated Regulator - A regulator utilizing a piston rather than a diaphragm actuator.
Pitot Tube - A hollow tube that connects the area beneath the regulator diaphragm with the vena contracta area of gas ow. The pitot tube
causes the diaphragm to sense a pressure lower than that which exists downstream of the regulator, and thus allows the regulator to open more
for any given change in downstream pressure. The result is increased regulator accuracy.
719
Gl o s s a r y o f Te r m s
PL - Loading pressure. Pressure of uid on the main diaphragm that is controlled by a pilot regulator.
Plug - Piece that throttles against an orice to increase and decrease ow.
Poise - A metric unit for measuring absolute viscosity. One poise equals one dynesecond per square centimeter, or one gram per centimeter second.
Port - A xed opening, normally the inside diameter of a seat ring, through which uid passes. The term can also refer to the inlet or outlet
of a regulator or pilot valve. Also called an orice.
Powder Paint Coating - A paint process that uses dry powder with no solvents for surface nish. Dry powder can be reused, thereby reducing
waste and pollutants. The powder coating over a clean surface provides better corrosion resistance than liquid coat.
Pressure - Force per unit area.
Pressure Buildup - In a relief valve, the pressure increase above setpoint required to produce a given ow rate.
Pressure Differential - The difference in pressure between two points in a system.
Pressure Drop - The difference between the inlet and outlet pressures.
Pressure Reducing Regulator - A valve that satises downstream demand while maintaining a constant reduced pressure. As the pressure
decreases, the valve opens to increase ow.
Pressure Relief Valve - A valve that opens and closes to ensure that pressure does not rise above a predetermined value.
Propane - An easily liqueable hydrocarbon gas. Propane is one of the components of raw natural gas, and it is also derived from petroleum
rening processes. Its chemical formula is C3H8.
Proportional Band (Amount of Deviation) - The amount a regulator deviates from setpoint as the ow increases from minimum to maximum.
Also referred to as droop or offset.
psia - pounds per square inch, absolute - The pressure above a perfect vacuum, calculated from the sum of the pressure gauge reading and
the (local or ambient) atmospheric pressure (approximately 14.7).
psid - Pounds per square inch, differential.
psig - Pounds per square inch, gauge. The pressure above atmospheric pressure. Near sea level the atmospheric pressure is approximately
14.7 pounds per square inch.
q - R
Range - The region between the limits within which a quantity is measured, received, or transmitted, expressed by stating the lower and upper
range values (Example: 3 to 15 psi; -40° to 212°F (-40° to 100°C)).
Rangeability - The ratio of maximum rated capacity to the minimum controllable ow within the specied accuracy band.
Rate of Flow - The volume of material passing a given point in a system per unit of time.
Rated Working Pressure - The maximum allowable pressure specied by the manufacturer.
Reduced Pressure - The pressure leaving the outlet opening of a valve (P2). More commonly called outlet pressure.
Regulator, Direct-Operated - See Pressure Reducing Regulator.
Regulator, Pilot-Operated - Two regulators connected so that one increases the effect of downstream pressure changes on the other. This
arrangement is used to provide increased accuracy and ow capacity compared to direct-operated regulators.
Relief Valve - See Pressure Relief Valve.
Relief Valve, Pilot-Operated - Two relief valves connected so that one increases the effect of inlet pressure changes on the other. This
arrangement is used to provide increased capacity and reduced buildup compared to other relief valve types.
Relief Valve, Pop Type - A spring-loaded poppet type relief valve.
Repeatability - The closeness of agreement of a regulated value when returned to the same steady-state conditions after upset(s).
720
Gl o s s a r y o f Te r m s
Reseat Point - In a relief/backpressure valve which is opened by an increase in inlet pressure, the point where the valve closes.
Restricting Element - The element that restricts and controls uid ow in a system. In a regulator this element is typically a disk and orice
combination, or plug and cage assembly.
RTD - Resistance Temperature Detector. A resistance device used to measure temperature.
RTU - Remote Terminal Unit or Remote Telemetry Unit.
S
SAE Number Viscosity - Refer to Viscosity, SAE Number.
Saybolt Furol - A scale used for measuring the viscosity of heavy oils. The instrument has a larger orice and is used at a higher temperature
than the Saybolt Universal instrument used for lighter oils.
Saybolt Universal - A scale used for measuring the viscosity of oil, expressed in seconds required for a specied amount of oil to ow through
an orice; hence, the larger the number of seconds, Saybolt Universal (SSU), the more viscous the oil.
SCFH - Standard cubic feet per hour. Volumetric gas measurement of ow per hour at standard or at base conditions.
Seat - The portion of the seat ring or valve body which a closure member contacts for shutoff.
Seat Leakage - Flow of uid past a seat or seal when in the closed position.
Seat Ring - A separate piece inserted in a valve body to form a valve body port. It generally provides a seating surface for a plug or disk.
Self-Contained Regulator - Pressure control device that is powered by the process media pressure and does not require outside energy.
Setpoint - The pressure at which the regulator or relief valve is set to control.
Set Pressure Range - The range of pressures, specied by the manufacturer, within which the device can be adjusted.
Sm3/h - meters cubed per hour (standard); measurement of volume rate of a gas at atmospheric pressure and 60°F. Also refer to Nm3/h.
Soft Seat - An elastomeric, plastic, or other readily deformable material used either in the valve plug or seat ring to provide tight shutoff with
minimal force.
Sonic Velocity - The speed of sound for a particular gas at a given inlet pressure and temperature.
Sour Gas - Gaseous fuel that contains a relatively large proportion of sulfur or sulfur compounds. See the discussion on Sulde Stress
Cracking in the Technical Section.
Specic Gravity - The ratio of weight of a given volume of uid to the weight of an equal volume of liquid/gas at stated temperature.
Speed of Response (Stroking Speed) - The amount of time it takes the valve plug or disk to travel from completely closed to completely
open (0 to 100%).
Spring - Part used as the loading element in a regulator. Length is adjusted to establish setpoint.
Spring Adjustment Screw - A screw used to compress the spring to establish the regulator setpoint.
Spring Rate (K) - Spring rate is dened by the amount of force required to compress a spring a given distance. Spring rate is given in force/
length (for example, lbf/in).
Stability - The ability to hold a steady controlled variable within the limits of stated accuracy of regulation.
Standard Atmosphere - The accepted normal atmospheric pressure at sea level, equal to 14.696 pounds per square inch.
Standard Barometer - The reading of a barometer for standard atmospheric pressure; equal to 29.92 inches of mercury column.
Standard Gravity - Standard accepted value for the force of gravity. It is equal to the force which will produce an acceleration of 32.17 feet
per second per second.
Standard Pressure - The same as standard atmosphere; equal to a pressure of 14.696 pounds per square inch.
721
Gl o s s a r y o f Te r m s
Static Line - See Control Line.
Static Pressure - The pressure in a uid at rest.
Static Unbalance - The force exerted on a valve plug due to uid pressure in the non-owing condition.
Stoke - The cgs unit of kinematic viscosity. One stoke equals one centimeter squared per second.
Supercompressibility - Many gases are more compressible under high pressure at ordinary temperatures than indicated by Boyle’s Law. These
gases, measured at the high pressures, will occupy a greater volume when the pressure is reduced to near atmospheric pressure.
SUS (or SSU) Viscosity - Refer to Viscosity, SUS (or SSU).
T - U
Therm - 100,000 BTU.
Thermostat - A device that automatically maintains a predetermined temperature in an appliance or component.
Travel - The amount of linear movement of the valve closure member from the closed position to the rated full-open position.
Travel Indicator - An external, visible device used to indicate the travel of the valve plug.
Trim - The replaceable internal parts of a regulator, usually made up of a seat ring or orice, valve plug or disk and disk holder, and stem;
other replaceable internal parts may be considered trim.
Under-Pressure Cut-Off Device - A mechanical device incorporated in a gas pipe work system to shutoff the supply of gas when the pressure
at the sensing point falls to a predetermined gure.
V - W
Vacuum Breaker - A valve used to limit an increase in vacuum. An increase in vacuum (decrease in absolute pressure) beyond a certain
value registers on the diaphragm. The valve disk will open permitting atmospheric, positive pressure, or an upstream vacuum that has a higher
absolute pressure than the downstream vacuum, to enter the system and restore to setpoint.
Vacuum Regulator - A device that maintains a vacuum at a setpoint. A decrease in this vacuum (increase in absolute pressure) beyond this
value registers underneath the diaphragm and opens the valve. This permits the downstream vacuum of lower absolute pressure than the
upstream vacuum to restore the upstream vacuum to its original pressure setting.
Valve - A device used for the control of uid. It consists of a uid retaining assembly, one or more parts between end openings, and a movable
closure member which opens, restricts, or closes the port(s).
Valve Body - A pressure retaining housing for internal parts having inlet and outlet ow connections.
Valve Closure Member - The movable part which is positioned in the ow path to modify the rate of ow through the valve, often made of
an elastomer material to improve shutoff.
Valve Linkage - A lever or levers connecting the diaphragm to the valve plug or valve plug stem.
Valve Plug - A movable part which provides a variable restriction in a port.
Valve, Needle - A small, adjustable valve in which the position of a pointed plug or needle relative to an orice or tapered orice permits or
restricts uid ow.
Valve, Isolation - Simple valves located in the piping system used to isolate individual equipment. They are designed to be operable by hand
and installed to be readily accessible to the consumer.
VDC - Volts direct current.
Vena Contracta - The location where cross-sectional area of the ow stream is at its minimum size, where uid velocity is at its highest level, and
uid pressure is at its lowest level. (The vena contracta normally occurs just downstream of the actual physical restriction in a regulator.)
Gl o s s a r y o f Te r m s
Vent - An opening in the regulator spring case to allow atmospheric pressure access to the diaphragm, thus allowing free movement of the
diaphragm during operation.
Viscosity - The tendency of a uid to resist ow.
Viscosity, Absolute - The product of a uid’s kinematic viscosity times its density. Absolute viscosity is a measure of a uid’s tendency to
resist ow, without regard to its density. Sometimes the term dynamic viscosity is used in place of absolute viscosity.
Viscosity, Kinematic - The relative tendency of uids to resist ow. The value of the kinematic viscosity includes the effect of the density of
the uid. The kinematic viscosity is equal to the absolute viscosity divided by the density.
Viscosity, SAE Number - The Society of Automotive Engineers’ arbitrary numbers for classifying uids according to their viscosities. The
numbers in no way indicate the viscosity index of uids.
Viscosity, SUS (or SSU) - Saybolt Universal Seconds (SUS), which is the time in seconds for 60 milliliters of oil to ow through a standard
orice at a given temperature (ASTM Designation D88.56).
Volume Corrected - The volume metered times metering pressure plus atmospheric pressure/base pressure equals volume corrected.
Water Column - A unit of measurement. The pressure required to support a column of water one inch high. Typically reported as inches w.c.
(water column); 27.68-inches of water is equal to one pound per square inch (psi).
Weight, Specic - The weight per unit volume of a substance. The same as density.
X - Y - z
Yoke - A structure by which the diaphragm case or cylinder assembly is supported rigidly on the bonnet assembly.
722
Loading...
