USER'S

N7003-1V2 7/98

GUIDE

FA1220CV

2-Partition Security System

TABLE OF CONTENTS

SYSTEM OVERVIEW .............................................................. 3

General ............................................................................... 3

A Partitioned System .......................................................... 3

Zones .................................................................................. 3

Burglary Protection ............................................................ 4

Fire Protection .................................................................... 4

Alarms ................................................................................. 5

Emergency Alarms (Panic) & Duress Code ........................ 5

Memory of Alarm................................................................. 5

Speed Key (macros) ........................................................... 5

Phone Access & Voice Response Capability...................... 6

Access Door Control ........................................................... 6

Self-Help Feature ................................................................ 6

ABOUT THE KEYPADS .......................................................... 7

FUNCTIONS OF THE KEYPADS .......................................... 10

ENTRY/EXIT DELAYS .......................................................... 12

CHECKING FOR OPEN ZONES ........................................... 13

DISPLAYING ALL ZONE DESCRIPTORS ........................... 14

BYPASSING PROTECTION ZONES .................................... 15

Quick Bypass .................................................................... 16

Displaying Bypassed Protection Zones ............................ 16

ARMING PERIMETER ONLY (STAY)................................... 17

ARMING PERIMETER ONLY (INSTANT)............................. 18

ARMING ALL PROTECTION (AWAY) .................................. 19

ARMING ALL PROTECTION (MAXIMUM) ........................... 20

DISARMING AND SILENCING ALARMS ............................. 21

USING THE KEYSWITCH ..................................................... 22

CHIME MODE ........................................................................ 23

VIEWING CENTRAL STATION MESSAGES ....................... 24

PANIC KEYS ......................................................................... 25

SECURITY CODES & AUTHORITY LEVELS....................... 26

General ............................................................................. 26

Duress Code ..................................................................... 26

Quick Arming .................................................................... 26

Authority Levels ................................................................ 27

To Add A User .................................................................. 29

Limited Use User (#84 Command).................................... 30

To Change A User's Code ................................................ 31

To Delete A User .............................................................. 31

ACCESSING OTHER PARTITIONS (GOTO)........................ 32

GOTO Command .............................................................. 32

Global Arming ................................................................... 32

[D] SPEED KEY (Macros)..................................................... 33

USING #70 RELAY MENU MODE ........................................ 34

EVENT LOGGING PROCEDURES....................................... 35

TESTING THE SYSTEM........................................................ 37

TROUBLE CONDITIONS ...................................................... 39

FIRE ALARM SYSTEM ......................................................... 41

NFPA RECOMMENDATIONS ............................................... 42

EMERGENCY EVACUATION ............................................... 43

MAINTAINING YOUR SYSTEM ............................................ 44

QUICK GUIDE TO SYSTEM FUNCTIONS............................ 46

SUMMARY OF AUDIBLE NOTIFICATIONS......................... 48

GLOSSARY ........................................................................... 49

INSURANCE CREDIT REQUEST FORM.............................. 55

– 2 –

SYSTEM OVERVIEW

General

A Partitioned

System

Zones

Congratulations on your ownership of a First Alert Professional Partitioned Security System.
You've made a wise decision in choosing it, for it represents the latest in security protection
technology today. This system offers you three forms of protection: burglary, fire and
emergency. To realize the system's full potential, it is important that you feel comfortable in
operating it.

Your system consists of at least one Keypad which provides full control and display of system
operation, various sensors which provide perimeter and interior burglary protection, plus
strategically placed smoke or combustion detectors designed to provide early warning in case
of fire.

The system uses microcomputer technology to monitor system status and initiate alarms for all
protection zones. Your system may also have been programmed to automatically transmit
alarm or status messages over the phone lines to a central alarm monitoring station.

A partitioned system shares one physical alarm system among different users, each with their
own requirements. For the most part, you as a user need not know about other users of the
system, but from time to time, you may see display messages which indicate the system is in
use by another user. Do not be concerned, this is normal. Refer to the ACCESSING OTHER
PARTITIONS section for additional information.

Your system's sensing devices have been assigned to various "zones." For example, the
sensing device on your Entry/Exit door may have been assigned to zone 01, sensing devices
on windows in the master bedroom to zone 02, and so on. These numbers will appear on the
display, along with an alpha descriptor for that zone (if programmed and using analpha
keypad), when an alarm or trouble condition occurs.

– 3 –

SYSTEM OVERVIEW

Burglary Protection The burglary protection portion of your system must be turned on or "armed" before it will sense

burglary alarm conditions. When the system is armed, faulting one or more protection zones
causes an alarm to sound and can allow the central station to listen-in to activity at the
premises (if your system is so equipped).

Your system provides four modes of burglary protection: STAY, AWAY, INSTANT and
MAXIMUM, and allows you to BYPASS selected zones of protection while leaving the rest of
the system armed. The system also provides a CHIME mode, for alerting users to the opening
and closing of doors and windows while the system is disarmed. The following table lists the
different arming modes and the results of each.

Arming Features For Each Arming Mode
Mode Exit Delay Entry Delay Perimeter Armed Interior Armed

AWAY Yes Yes Yes Yes
STAY Yes Yes Yes No
INSTANT Yes N o Y es No
MAXIMUM Yes N o Y es Yes

Fire Protection The fire protection portion of your security system (if used) is always on and sounds an alarm if

a fire condition is detected, and allows the central station to listen-in to activity at the premises
(if your system is so equipped). Refer to the FIRE ALARM SYSTEM section for important
information concerning fire protection, smoke detectors and planning emergency exit routes
from your house.

– 4 –

SYSTEM OVERVIEW

Alarms When an alarm occurs, both the keypad and external sounders will sound, and the keypad

displays the zone(s) causing the alarm. If your system is connected to a central monitoring
station, an alarm message is sent. To stop the alarm sounding, simply disarm the system.

Emergency (Panic)

Alarms & Duress

Code

Memory of Alarm

Speed Key

(Macros)

Your system can provide special emergency key functions, programmed by your installer and
referred to as panic keys. These keys allow you to manually send silent or audible alarms, or
sound fire alarms. Your system may also include one or more wireless pushbutton panic
transmitters. Refer to the PANIC KEYS section later in this manual for more information about
panic alarms.

A special duress code may also have been programmed. You can use this code in place of
your usual security code to arm or disarm the system while under threat. The system acts
normally, but sends a silent alarm message to the central station, alerting them to your
situation. Refer to the SECURITY CODES & AUTHORITY LEVELS section for more
information about the duress code.

When an alarm condition occurs, the keypad displays the number(s) of the zone(s) that caused
the alarm, and displays the type of alarm (ex. FIRE, ALARM). It remains displayed until it is
cleared by disarming the system (see DISARMING THE SYSTEM section later in this manual).

The system can store a string of up to 16 keystrokes, which you can activate anytime by
pressing the D key. This feature can make it easy to perform a complicated procedure (such as
going to another partition to bypass a zone), or it can simplify an everyday, repeated procedure.
Refer to the SPEED KEY section for procedures.

– 5 –

SYSTEM OVERVIEW

Phone Access &

Voice Response

Capability

Access Door

Control

Self-Help Feature Abbreviated user's instructions are built into the system and can be easily viewed on the alpha

Your system may include a phone module that permits you to access the system via a
TouchTone phone, either on-premises or by call-in when away. The phone access feature
enables you to hear synthesized voice messages over the telephone regarding the status of the
security system, and allows you to arm and disarm the system and perform most commands via
the telephone just as you would from the keypad, with voice confirmation provided after each
command entry. Complete information regarding the use of this feature is provided separately
with the phone module.

Your system may be set up such that a locked access door (such as in a lobby) can be
unlocked using a keypad command. Ask your installer if you have this feature.

To unlock the door: Enter your security code and press 0 . The door unlocks for 2
seconds.

keypad's display screen. This feature can prove particularly useful if this manual is not
conveniently accessible when you need to perform a system procedure with which you are not
familiar.

To view the abbreviated instructions: Simply press and hold down the function key of
interest until the description starts to appear (about 5 seconds) and then release it. Refer to the
FUNCTIONS OF THE KEYPAD section for descriptions of each key function.

– 6 –

ABOUT THE KEYPADS

General

Your keypads allow you to control all system functions. The keypads feature a telephone style
(digital) keypad and a Liquid Crystal Display (LCD) which shows the nature and location of all

IMPORTANT: If the
keypad beeps rapidly
upon entering the
premises, it indicates
that an alarm has
occurred during your
absence. LEAVE
IMMEDIATELY and
CONTACT THE POLICE
from a nearby safe
location.

occurrences. Keypad display backlighting is programmable to always stay on or to light only
when a key is pressed, then turn off within a minute.

The keypads also feature a built-in sounder which will sound during alarms and troubles. It will
also "beep" during certain system functions, such as during entry/exit delay times, during
CHIME mode, and when pressing keys to arm and disarm the system (to acknowledge the key
press). These sounds can be optionally suppressed in some of your keypads (so as not to
disturb other users of the system). Ask your installer if this has been done.

There are two types of keypads – an alpha keypad, and a fixed-word keypad.

The Alpha Keypad Alpha keypads feature a 2-line, 32 character alphanumeric Liquid Crystal Display (LCD) which

can display system messages in friendly English. Abbreviated user's instructions can also be
displayed (see Self Help paragraph in the SYSTEM OVERVIEW section). These keypads can
also be programmed with custom zone descriptors, and feature a flip-down cover which can be
removed, if desired.

The Fixed-Word

Keypad

Fixed-Word keypads are functionally identical to alpha keypads, but the LCD display uses pre­designated words to identify nature and location of occurrences.

– 7 –

ABOUT THE KEYPADS

00

ALARM
FIRE

AWA Y

BYPASS

STAY

CHECK INSTANT

NO AC

NOT READY

CHIME BAT

Fixed-Word Keypad Displays

AWAY: All burglary zones, interior & perimeter, are armed.

STAY: Perimeter burglary zones, such as windows & doors, are

armed. Interior zones are bypassed.

INSTANT: Perimeter burglary zones are armed and entry delay is

turned off. Interior zones are bypassed.

MAXIMUM: All burglary zones, interior & perimeter, are armed, and entry delay is turned off.

BYPASS: One or more burglary protection zones have been bypassed.

NOT READY: Appears when burglary portion of the system is not ready for arming (due to open protection zones).

READY: The burglary system is ready to be armed.

NO AC: Appears when AC power has been cut off. System is operating on backup battery power.

AC: Appears when AC power is present.

CHIME: Appears when the CHIME feature is activated.

BAT: Low battery condition in a wireless sensor (if ID number displayed) or low system battery (if no ID

number displayed).

ALARM: Appears when an intrusion has been detected and the system is armed (also appears during a fire

alarm or audible emergency alarm). Accompanied by the protection zone ID in alarm.

CHECK: Appears when a malfunction is discovered in the system at any time or if a fault is detected in a FIRE

zone at any time or in a DAY/NIGHT burglary zone during a disarmed period. Accompanied by a
display of zone number in trouble. This also appears if the cover of certain wireless transmitters are
removed.

FIRE: Appears when a fire alarm is present. Accompanied by a display of the zone in alarm.

00

ALARM
FIRE

AWAY

BYPASS

STAY

CHECK INSTANT

NO AC

NOT READY

CHIME BAT

– 8 –

Keypads With Flip-Down Key Covers Are Shown With Cover Removed

ARMED

READY

Professional

OFF AWAY

STAY

MAXIMUM

TEST

BYPASS

INSTANT

CODE

CHIME

READY

1

A

B

C

D

2

3

4

5

6

7

8

9

*

0#

First Alert

First Alert

®

READY

Professional

OFF AWAY STAY

MAXIMUM TEST BYPASS

INSTANT CODE CHIME

READY

PANIC

1

2

3

4

5

6

7

8

9

*

0

#

ARMED

ALARM
CHECK
FIRE

AWAY
STAY
INSTANT
BYPASS

NO AC
CHIME

BAT

NOT READY

ARMED

READY

PPrrooffeessssiioonnaall

OFF AWAY

STAY

MAXIMUM TEST

BYPASS

INSTANT

CODE

CHIME

READY

1

A

B

C

D

2

3

45 6

7

8

9

*

0

#

First Alert

ALARM
FIRE

CHECK

AWAY

NO AC

BYPASS NOT READY

STAY

CHIME BAT

INSTANT

FA550KPALPHA KEYPAD

FA210KP FIXED-WORD KEYPAD

(STYLE A DISPLAY)

FA250KP FIXED-WORD KEYPAD

(STYLE B DISPLAY)

**** DISARMED ****

READY TO ARM

ABOUT THE KEYPADS

FA550KP ALPHA KEYPAD

FA210KP FIXED-WORD KEYPAD
(STYLE A DISPLAY)

– 9 –

FA250KP FIXED-WORD KEYPAD
(STYLE B DISPLAY)

FUNCTIONS OF THE KEYPAD

1. ALPHA DISPLAY WINDOW: A 2-line, 32-character Liquid
Crystal Display (LCD). Displays protection point
identification and system status, messages, and user
instructions.

2. OFF KEY: Disarms the burglary portion of the system,
silences alarms and audible trouble indicators, and clears

visual alarm trouble after the problem has been corrected.

3. AWAY
interior burglary protection for backup protection by

sensing an intruder's movements through protected
interior areas as well as guarding protected doors,
windows, etc. Late arrivals can enter through an entry
delay zone without causing an alarm if the system is
disarmed before the entry delay time expires.

4. STAY
guarding protected doors, windows and other perimeter

protection points, and sounds an alarm if one is opened.
Interior protection is not armed, which allows movement
within your house without causing an alarm. Late arrivals
can enter through an entry delay zone without causing an
alarm if the system is disarmed before the entry delay time
expires.

5. TEST
disarmed.

6. BYPASS
tion zones from being monitored by the system. Displays

previously bypassed protection zones.

KEY: Completely arms both perimeter and

KEY: Arms the perimeter burglary protection,

KEY: Tests the system and alarm sounder if

KEY: Temporarily removes individual protec-

7. CHIME
any entry through a protected delay or perimeter zone

while the system is disarmed will cause a tone to sound at
the Keypad(s).

8.

# KEY: Permits ARMING of the system without use

of a security code ("Quick Arm", if programmed).

9. KEYS 0–9: Used to enter individual security access
code(s).

10. CODE KEY: Allows the entry of additional user codes
that can be given to other users of the system.

11. READY
system, the keypad will display all open protection zones

within the keypad's home partition. This key is also used to
display all zone descriptors that have been programmed
for your system, by holding the key down for at least 5
seconds.

12. INSTANT
but turns off the entry delay period, offering greater

security while inside and not expecting any late arrivals.
An alarm will occur immediately upon opening any
perimeter protection point, including entry delay zones.

13. MAXIMUM
mode, but eliminates the entry delay period, thus providing

maximum protection. An alarm will occur immediately upon
opening any protection point, including entry delay zones.

KEY: Turns CHIME mode on & off. When on,

KEY: When depressed prior to arming the

KEY: Arms in manner similar to STAY mode,

KEY: Arms in manner similar to AWAY

– 10 –

14. POWER/READY INDICATOR: (GREEN) On some

ARMED

READY

Professional

OFF AWAY

STAY

MAXIMUM

TEST

BYPASS

INSTANT

CODE

CHIME

READY

1

A

B

C

D

2

3

4

5

6

7

8

9

*

0#

First Alert

1

15
14

2

13

16

12

8

911

10

7

6

5

4

17

18

SHOWN WITH
FLIP-DOWN
KEY COVER
REMOVED

19

keypads, this lights when primary power is on. If off,
system is operating on its backup battery power. CALL
YOUR INSTALLER IMMEDIATELY. On other types of
keypads, lit indicates system is ready to be armed, while
unlit indicates system not ready.

15. ARMED INDICATOR: (RED) Lit when the system has
been armed (STAY, AWAY, INSTANT or MAXIMUM).

16. INTERNAL SOUNDER: Source of audible internal
warning and confirmation sounds, as well as alarms (see
"Summary of Audible Notifications").

NOTE:

Unless stated otherwise, most procedures in this
manual apply to all keypad types and styles.

IMPORTANT!:

When using the keypad to enter codes and
commands, sequential key depressions must be
made within 3 seconds of one another. If 3
seconds elapses without a key depression, the
entry is aborted and must be repeated from its
beginning.

17. A-B-C PANIC KEYS: Refer to the PANIC KEYS section
for descriptions of these keys.

18. SPEED KEY [D]: The "D" key can be used to activate a
pre-programmed string of up 16 keystrokes, known as a
macro. Refer to the SPEED KEY section for procedures
on using this key.

– 11 –

ENTRY/EXIT DELAYS

General

Information

Your system has preset time delays, known as exit delay and entry delay. Whenever you arm
your system, exit delay gives you time to leave through the designated exit door without setting
off an alarm. Exit delay begins immediately after entering any arming command, and applies to
all modes of arming protection. If programmed, a slow beeping will sound throughout the exit
delay period.

Entry Delay gives you time to disarm the system when you reenter through the designated
entrance door. But the system must be disarmed before the entry delay period ends, or an
alarm will occur. The keypad will beep during the entry delay period, reminding you to disarm
the system. You can also arm the system with no entry delay at all by using either INSTANT or
MAXIMUM arming modes. These modes provide greater security while on the premises or
while away for extended periods of time. See your installer for your delay times.

Partition 1

Exit Delay 1: seconds Entry Delay 1: seconds

Exit Delay 2: seconds Entry Delay 2: seconds

Partition 2

Exit Delay 1: seconds Entry Delay 1: seconds

Exit Delay 2: seconds Entry Delay 2: seconds

– 12 –

CHECKING FOR OPEN ZONES

Using the ✱

READY Key

Before arming your system, all protected doors, windows and other protection zones must be
closed or bypassed (see BYPASSING section). Otherwise the keypad will display a "Not
Ready" message. Pressing the READY key will display all zones that are faulted, making it
easier for you to secure any open zones.

To show faulted zones:

DISARMED - PRESS Note: Some keypads light a green LED when the system
✴ TO SHOW FAULTS is ready. If not lit, the system is not ready to be armed.

READY

1. Do not enter security code, but simply press ✱ .

FAULT 05 FRONT

UPSTAIRS BEDROOM

2.

DISARMED

READY TO ARM

Typical fault display

Secure or bypass the zones displayed before arming the system.
The "Ready" message will be displayed† when all protection zones

have been either closed or bypassed.

†

NOTE: All or part of this message may be replaced by a customized

message programmed by the installer. Bear this in mind whenever the
instructions indicate that the "DISARMED" or "READY" message will be
displayed.

– 13 –

DISPLAYING ALL ZONE DESCRIPTORS

Using the ✱

READY Key

The Alpha and 2-Way Voice/Alpha Keypads can also display all the zone descriptors that are
programmed in your system. The abbreviated instructions for the READY key will appear first,
followed by the zone descriptors. Displaying all descriptors is useful when you need to know the
zone number of a particular zone, as when bypassing zones.

The "Disarmed-Ready to arm" message must be displayed before zone descriptors can
be displayed.

READY

1. Press the ✱ key and hold down for at least 5 seconds.

– 14 –

BYPASSING PROTECTION ZONES

Using the 6

BYPASS Key

This key is used when you want to arm your system with one or more zones intentionally
unprotected. Bypassed zones are unprotected and will not cause an alarm when violated while
your system is armed. All bypasses are removed when an OFF sequence (security code plus
OFF) is performed. Bypasses are also removed if the arming procedure that follows the bypass
command is not successful.

Note: The system will not allow fire or emergency zones (keypad panics A, B, C) to be
bypassed.

To bypass zones, the system must be disarmed first.

(Your system may include special high security zones. If so, these zones can be bypassed
while the system is armed or disarmed. Ask your installer if your system has these zones.)

BYPASS

1. Enter your security code and press 6 .

2. Enter zone number(s) for the zones to be bypassed (e.g., 01, 02, 03, etc.).
Important! All single-digit numbers must be preceded by a zero (for example, enter 01 for

zone 1).

3.

BYPASS 07 FRONT
UPSTAIRS BEDROOM

Typical bypass message

4.

DISARMED BYPASS

READY TO ARM

When finished, the keypad will display the word BYPASS along
with each bypassed zone number. Wait for these zones to be
displayed before arming. Arming the system before bypassed
zones are displayed eliminates all bypasses.

Arm the system as usual when the keypad displays "ready" to arm
message.

– 15 –

BYPASSING PROTECTION ZONES

Quick Bypass Your system may allow you to easily bypass all open (faulted) zones without having to enter

zone numbers individually. Ask your installer if this feature is active for your system.
Note: All bypasses are removed when an OFF sequence (security code plus OFF) is

performed.

To use the Quick Bypass feature:

1. Enter your security code and press 6 then press # .

BYPASS

Displaying

Bypassed Zones

2.

BYPASS 07 FRONT
UPSTAIRS BEDROOM

Typical bypass message

3.

DISARMED BYPASS

READY TO ARM

In a few moments, all open zones will be displayed along with the
word BYPASS. Wait for these zones to be displayed before
arming. Arming the system before bypassed zones are displayed
eliminates all bypasses.

Arm the system as usual when the keypad displays the
"ready" to arm message. Bypassed zones are unprotected
and will not cause an alarm when violated while your system
is armed.

For determining what zones have been previously bypassed.

BYPASS

1. Enter your security code and press 6 .

2. Wait for all bypassed zones to be sequentially displayed.

– 16 –

ARMING PERIMETER ONLY

(With Entry Delay ON)

Using the 3

STAY key

Use this key when you are staying home, but might expect someone to use the entrance door
later.

When armed in STAY mode, the system will sound an alarm if a protected door or window is
opened, but you may otherwise move freely throughout the premises. Late arrivals can enter
through the entrance door without causing an alarm, but they must disarm the system within the
entry delay period or an alarm will occur.

Close all perimeter windows and doors before arming (see CHECKING FOR OPEN
ZONES section)

STAY

1. Enter your security code and press 3 .

2.

ARMED ***STAY***

ZONE BYPASSED

The keypad will beep three times and will display the armed
message.

Note: "ZONE BYPASSED" in this display simply indicates that the
interior zones of protection are not armed when using STAY mode.

– 17 –

ARMING PERIMETER ONLY

(With Entry Delay OFF)

Using the 7

INSTANT Key

Use this key when you are staying home and do not expect anyone to use the entrance door.
When armed in INSTANT mode, the system will sound an alarm if a protected door or window

is opened, but you may otherwise move freely throughout the premises. The alarm will also
sound immediately if anyone opens the entrance door.

Close all perimeter windows and doors before arming (see CHECKING FOR OPEN
ZONES section)

INSTANT

1. Enter your security code and press 7 .

2.

ARMED *INSTANT*

ZONE BYPASSED

The keypad will beep three times and will display the armed
message.

Note: "ZONE BYPASSED" in this display simply indicates that the
interior zones of protection are not armed when using STAY mode.

– 18 –

ARMING ALL PROTECTION

(With Entry Delay ON)

Using the 2

AWAY Key

Use this key when no one will be staying on the premises.
When armed in AWAY mode, the system will sound an alarm if a protected door or window is

opened, or if any movement is detected inside the premises. You may leave through the
entrance door during the exit delay period without causing an alarm. You may also reenter
through the entrance door, but must disarm the system within the entry delay period or an alarm
will occur.

Close all perimeter windows and doors before arming (see CHECKING FOR OPEN
ZONES section)

AWAY

1. Enter your security code and press 2 .

2.

YOU MAY EXIT NOW

ARMED **AWAY**

The keypad will beep twice and will display the armed message.
Note: The "YOU MAY EXIT NOW" portion of the message

disappears when exit delay expires.

– 19 –

ARMING ALL PROTECTION

(With Entry Delay OFF)

Using the 4

MAXIMUM Key

Use this key when the premises will be vacant for extended periods of time such as vacations,
etc., or when no one will be moving through protected interior areas.

When armed in MAXIMUM mode, the system will sound an alarm if a protected door or window
is opened, or if any movement is detected inside the premises. You may leave through the
entrance door during the exit delay period without causing an alarm, but an alarm will be
sounded as soon as someone reenters.

Close all perimeter windows and doors before arming (see CHECKING FOR OPEN
ZONES section)

MAXIMUM

1. Enter your security code and press 4 .

2.

ARMED *MAXIMUM*

YOU MAY EXIT NOW

The keypad will beep twice and will display the armed message.
Note: The "YOU MAY EXIT NOW" portion of the message

disappears when exit delay expires.

– 20 –

DISARMING AND SILENCING ALARMS

Using the 1

OFF Key

Memory of Alarm The keypad displays the zone number and type of alarm for any zone that has had an alarm

The OFF key is used to disarm the system and to silence alarm and trouble sounds. See
"SUMMARY OF AUDIBLE NOTIFICATION" section for information which will help you to
distinguish between FIRE and BURGLARY alarm sounds.

IMPORTANT: If you return and the main burglary sounder is on, DO NOT enter the premises,
but call the police from a nearby safe location. If you return after an alarm has occurred and the
main sounder has shut itself off, the keypad will beep rapidly upon entering, indicating that an
alarm has occurred during your absence. LEAVE IMMEDIATELY and CONTACT THE POLICE
from a nearby safe location.

To disarm the system and silence burglary or fire alarms:

OFF

1. Enter your security code and press 1 .

DISARMED

READY TO ARM

condition. These messages will remain displayed until cleared by a user. If an alarm has
occurred, note the zone number displayed on the keypad and repeat step 1 above to clear the
"Memory of Alarm" and restore the Ready message display. If the Ready message will not
display, go to the displayed zone and remedy the fault (close windows, etc.). If the fault cannot
be remedied, notify the alarm agency.

If the system was armed when the alarm occurred, repeat step 1 twice: once to disarm the
system, a second time to clear the display.

The Ready message will be displayed (if no alarms have occurred
while armed) and the keypad will beep once to confirm that the
system is disarmed.

– 21 –

USING THE KEYSWITCH

GREEN

RED

General

Your system may be equipped with a keyswitch for use when arming and disarming. A red and green
light on the keyswitch plate indicate the status of your system as follows:

Green Light: Lights when the system is disarmed and

ready to be armed (no open zones). If the

system is disarmed and the green light is off,
it indicates the system is not ready (one or
more zones are open).

Red Light: Lights when system is armed or memory of

alarm exists.

Lit Steady: System is armed in AWAY mode.

Slow Flashing: System is armed in STAY mode.

Rapid Flashing: Memory of alarm, indicating an alarm has

occurred .

Arming

To arm in the AWAY mode, turn the key to the right for 1
second and release. Keypads will beep twice and the red light
will stay on steady.

To arm in the STAY mode, turn the key to the right and hold for
longer than 5 seconds, then release. Keypads will beep three
times and the red light will flash slowly.

Disarming

To disarm the system, turn the key to the right and release. If an alarm has occurred, the red
light will be flashing rapidly (memory of alarm).

– 22 –

CHIME MODE

Using the 9

Key

Your system can be set to alert you to the opening of a door or window while it is disarmed by
using CHIME mode. When activated, the Not Ready message is displayed and three tones
sound at the Keypad whenever a protected perimeter door or window is opened. Pressing the
READY key will display the open protection points.

Note that Chime mode can be activated and de-activated only when the system is disarmed.

CHIME

1. To turn Chime Mode on, enter the security code and press 9 .

CHIME MODE ON

2. To turn Chime Mode off, enter the security code and press 9 again.

CHIME MODE OFF

The CHIME MODE ON message will appear for about two seconds
then disappear. To display this message again (to determine
whether chime mode is on or off), simply press and hold down the
CHIME key for 5 seconds.

CHIME

The CHIME MODE OFF message will appear for about two
seconds then disappear. To display this message again (to
determine whether chime mode is on or off), simply press and hold
down the CHIME key for 5 seconds.

– 23 –

VIEWING CENTRAL STATION MESSAGES

General

Information

Users of the system may periodically receive messages on their display screens from their
monitoring agency or installer. When a message is waiting to be viewed, the message shown
below will appear.

MESSAGE. PRESS 0
FOR 5 SECS.

1. Press and hold down 0 key for 5 seconds. The message could take up to four screens
to display all the information available.

– 24 –

PANIC KEYS

(FOR MANUALLY ACTIVATING SILENT AND/OR AUDIBLE ALARMS)

Using

Panic Keys

Your system may have been programmed to use special key combinations to manually activate
panic functions. The functions that might be programmed are Silent Emergency, Audible
Emergency, Personal Emergency, and Fire. See your installer for the function(s) that may have
been programmed for your system.

Active Panic Functions

(your installer should note which

function(s) is active in your system)

Keys Zone Function

1 and ✱ 95
3 and # 96

✱ and # 99

A* 95
B* 99
C* 96

* May not be present on your keypad(s).

To use a paired key panic function,
simply press both keys of the assigned
pair at the same time. If your keypad(s)
have lettered keys for panic functions,
press the designated key and hold
down for at least 2 seconds to activate
the panic function.

A silent emergency will send a silent alarm

signal to the central station, but there will be no
audible alarms or visual displays.

An audible emergency will send an emergency
message to the central station (if connected) and
will sound a loud, steady alarm at your keypad
and at any external sounders that may be
connected ( ALARM plus a zone number would
also be displayed).

A personal emergency alarm will send an
emergency message to the central station (if
connected) and will sound at keypads, but not at
external bells or sirens. (ALARM plus a zone
number would also be displayed)

A fire alarm will send a fire alarm message to
the central station and will uniquely sound
external bells and sirens (FIRE plus a zone
number would also be displayed).

– 25 –

SECURITY CODES & AUTHORITY LEVELS

General

Information

Duress Code This feature is intended for use when you are forced to disarm or arm the system under threat.

Quick Arming

At the time of installation, you were assigned an authority level and a personal four-digit
security code, known only to you and yours. The security code must be entered when arming
and disarming the system. The authority level defines the system functions that you can
perform.

As an additional safety feature, other users that do not have a need to know your code can be
assigned different security codes and each user can be given a different authority level. Users
are identified by "user numbers", which are assigned when assigning a user's security code.

All codes can be used interchangeably when performing system functions within the limits of
each code's authority level (a system armed with one user's code can be disarmed by another
user's code), with the exception of the Operator C code (authority level 5). See AUTHORITY
LEVELS section on the following page for detailed information regarding user authority levels.

When used, the system will act normally, but can silently notify the central station of your
situation, if that service has been provided. The duress code is pre-assigned by the installer
during installation (authority level 6).

Important: This code is useful only when the system is connected to a central station.

Note that if "Quick Arming" was programmed by the installer, the # key can be pressed in
place of the security code when arming the system. The security code must always be used to

disarm the system, however. Note that Operator C cannot disarm the system if the system was
armed by quick arm.

– 26 –

SECURITY CODES & AUTHORITY LEVELS

Authority Levels Authority levels define the system functions a particular user can perform. Depending on your

authority, there are certain system functions you may be prohibited from performing. There are
seven authority levels, each having certain system restrictions.

Level 1 Master: Can perform all system functions in assigned partitions and can add,

delete or change Manager and Operator level users. Master codes are
added by the Installer. Can also change own code.

Level 2 Manager: Can perform system functions in assigned partitions and can add,

delete or change Operator level users. Can also change own code.

Level 3 Operator A: Can perform system functions in assigned partitions but cannot add or

delete other users.

Level 4 Operator B: Same as Operator A, except Operator B cannot bypass zones of

protection.

Level 5 Operator C: Can arm the system in assigned partitions but cannot disarm the

system unless the system was armed with this code. Typically
assigned to someone who has a need to arm/disarm the system only
at certain times (such as a babysitter).

Level 6 Duress: Can arm and disarm the system, but also sends a silent panic alarm to

the central station, if that service is connected.

Level 7 Limited Use: Can arm and disarm the system, but only for a predetermined number

of times, after which, this code automatically expires. The actual usage
count is set by using the #84 command discussed later in this section.

To view your authority level and system capabilities (alpha keypads only):

1. Enter your security code + ✱ + ✱ . The alpha keypad will display the partition(s)
that you are authorized to operate, and your user number and authority level in each

partition.

– 27 –

SECURITY CODES & AUTHORITY LEVELS

General Rules on

Authority Levels

and Changes

To Exit User Edit

Mode

• A user may not delete or change the user code of the SAME or HIGHER authority than which

he is assigned.

• A master/manager may only ADD users to a LOWER authority level.

• A master/manager may assign access codes only to those partitions to which the user adding

the code has access. (ex. a user with access to only partition 1 cannot assign codes in
partition 2.)

• The only way to assign a user's authority level is by using the "Add A User" procedure. To

change a user's authority level, that user must first be deleted, then added again.

• A user can only be DELETED or CHANGED from within the partition he is assigned.

• User numbers must be entered as 2-digit entries. Single digit user numbers must be

preceded by a "0" (example, 03, 04, etc.). Security codes are entered as 4-digit numbers.

• Before assigning a security code, be sure it does not conflict with any DURESS code or other

user code.

Note: When adding, changing or deleting users, all other alpha keypads in that partition will
display "User Edit Mode – Please Stand By", and key depressions (except Panic) at those
keypads will be ignored. Panic key depressions will cause an alarm and terminate user entry.

You can exit any of the user edit modes described on the following pages at any time by doing
the following:

1. Press either ✱ or # , or don't press any key for 10 seconds.

– 28 –

SECURITY CODES & AUTHORITY LEVELS

To Add a User

NOTE: Adding/deleting
security codes can only
be done from an alpha
keypad.

†

Refer to the #84
Command section for
setting usage counter
for limited use users.

IMPORTANT: Temporary users should not be shown how to use any system function they do
not need to know (e.g. bypassing protection zones).

CODE

1. Enter Master or Manager code and press the 8 key.

2. Enter the new user's 2-digit User Number (02–69).

3. Enter 4-digit security code for that user. The following prompts will appear.

ADD NEW USER?

0 = NO , 1 = YES
USER NUMBER =3

ENTER AUTH.LEVEL

RF BUTTON ?

0 = NO , 1 = YES

ENTER BUTTON ZN #

(01-64)

MULTI-ACCESS ?

0 = NO , 1 = YES

Enter 1 to add a new user code. Entering 0 will change the existing
user's code to the code entered in step 3. See

Code

section.

Enter the authority level, 1–6, for this user within this partition.

1=master 3=operator A 5=operator C 7=Limited Use
2=manager 4=operator B 6=duress code

This prompt will appear if a 5800 series button transmitter has
been supplied and has not yet been assigned to a user.

Press 1 if a button transmitter will be assigned to this user.
Otherwise press 0.

If assigning a button transmitter, this prompt will appear. Enter the
button's zone number (see your installer for zone number).

If you as a user have access to other partitions, the keypad will
prompt for ability of this new user to access (GOTO) those
partitions. Press 0 (NO) or 1 (YES). If no, the system activates this
user code and exits “Add a User” mode. If yes, the keypad prompts
for the Global Arm option for this user.

Changing A User's

†

– 29 –

SECURITY CODES & AUTHORITY LEVELS

To Add a User

(continued)

Limited Use User

(#84 Command)

GLOBAL ARM ?

0 = NO , 1 = YES

PART.2 - SHOP?

0 = NO , 1 = YES

PART. 1 * WHSE

USER 03 AUTH =3G

To set the usage count for users with authority level 7, enter #84. The following prompt will
appear.

Press 1 (YES) if this user will be allowed to arm both partitions at the
same time from one keypad. Press 0 if this user will arm only his
assigned partition, or another partition individually.

The keypad now prompts for the user’s access to the next partition
(see GOTO command). Again press 0 or 1. If yes, the system will
automatically assign a user number for use in that partition and will
prompt for the authority level and global arm option for this user
within the partition (see previous steps).

When both partitions have been displayed, the keypad scrolls
through the partition(s) to which access has been assigned, and will
display the user number, authority level and global arm option for
each. Note that the “G” following the authority level indicates that the
global arm feature has been selected for this user in the displayed
partition,. The "✱" indicates the partition from which the user can be
changed or deleted.

CODE USE LIMIT

01-15 00 = QUIT

Enter the number of times these users will have access to the system. These codes
automatically expire (but the codes are not deleted) after this number of uses. To reactivate
the codes, simply enter #84 and set a new usage limit.

– 30 –

SECURITY CODES & AUTHORITY LEVELS

To Change a User's

Code

To Delete a User

CODE

1. Enter Master/Manager code and press the 8 key + user number to be changed.

2. Enter the new code for that user.

ADD NEW USER?

0 = NO , 1 = YES

USER 02 CHANGED
SUCCESSFULLY

1. Enter the Master or Manager code and press the 8 key + User Number to be
deleted.

2. Enter the same Master or Manager code again.

OK TO DELETE

0 = NO , 1 = YES

USER CODE
DELETED

The system will recognize that the user number is already in use
and will prompt whether or not this is a new user. Enter 0 to
change the user's code to the code entered in step 2.

The system confirms that the change is allowed based on
authorization level, and if so, puts the new code into effect.
Note that if changing one’s own code, the system will prompt for
the new code to be reentered. This prevents accidentally changing
a high level code.

CODE

The system will recognize that the user number is already in use
and will prompt to confirm that it should be deleted. Press 0 (NO)
or 1 (YES).

If yes, that user's code is removed from all partitions to which it
was assigned, and all authority levels and other information about
that user is deleted. Note that a user can only be deleted from the
partition in which it was first assigned, and can only be deleted by
a user with a higher authority level. A User's security code cannot
be deleted by oneself.

– 31 –

ACCESSING OTHER PARTITIONS

(GOTO Command and Global Arming)

To Access Another

Partition

Global Arming The Global Arming option may have been programmed for use by some users. If Global Arming

Each keypad is assigned a default partition for display purposes, and will show only that
partition's information. But, if the user is authorized, an alpha keypad in one partition can be
used to perform system functions in the other partition by using the GOTO command. Note that
only those partitions authorized and programmed by the installer can be accessed in this
manner.

To GOTO another partition (using an alpha keypad):

READY

1. Enter your security code, then press ✱ + partition number (0–2).
Entering partition number 0 will return the keypad to its original partition.

2.

LOG-ON TO AAAA

PART. X COMPLETE

was enabled for use with your security code, an alpha keypad prompt (message) will appear
after pressing one of the arming function keys (STAY, INSTANT, AWAY, MAXIMUM, OFF).
Follow the keypad prompts to continue arming the system. See your installer for detailed
instructions on the use of this feature.

If global arming does not apply to your security code, use the procedures described in the
following pages.

The keypad will remain in the new partition until directed to go to
another partition, or until 2 minutes has elapsed with no keypad
activity.

AAAA = alpha descriptor, if programmed by the installer
X = partition number

– 32 –

[D] Speed Key (Macros)

General

Information

Defining

NOTE: Defining and using
speed keys requires an
alpha keypad.

Executing Press and hold down (about 2 seconds) the "D" key until the following prompt appears:

The "D" key can activate a string of up to 16 keystrokes. These keystrokes are known as a
macro and are stored in the system's memory. Typical Speed Key functions include:

• Seldom used but repeatable sequences.

• Arming sequences that involve bypassing certain zones before arming.

• Relay activation sequences.

Enter your user code + # + D and hold the “D” key down until the following appears:
ENTER SPEED KEY "D"

existing sequence displayed

Enter up to 16 keystrokes. A speed key sequence can include
different commands. Press the "D" key to separate different
commands.

For example, you may want to perform the following sequence.

GOTO partition 2 .................. Enter *2

Bypass zones 10 & 11 ......... Press bypass [6], then the zone numbers 10 & 11

Arm in maximum mode ........ Press maximum [4] key

Return to partition 1.............. Enter *1

To program this sequence, type the following : ✱ 2 D 61011 D 4 D ✱ 1 D D
Note that the "D" key is pressed after the "2," the last "1" and the "4," separating the different

commands. Press "D" twice to complete the entry and exit.

ENTER USER CODE

0000

NOTE: When defining speed key sequences, do not use the [#] key to represent Quick Arming. The
system uses the code entered at the prompt to initiate commands in a speed key sequence, so quick arm
is unnecessary. The system interprets the use of the [#] key in a speed key sequence as its designated
function only (usually installer functions).

Enter your user code. The defined speed key sequence will
begin automatically.

– 33 –

USING #70 RELAY MENU MODE

General

Information

NOTE: Using #70 Menu
Mode requires an alpha
keypad.

Your system may be set up so that certain lights or other devices can be turned on or off by
using the #70 command from either a keypad or a telephone keypad (if phone module is used).
Ask your installer if this has been done in your system.

To activate relays from a keypad, enter 4-digit security code + [#] + [7] [0]. Follow the keypad
prompts described below.

To activate relays using the telephone (if phone module is used), first dial the 2-digit phone
access code. When the system acknowledges the access, enter the 4-digit security code + [#] +
[7] [0]. The following prompts/voice responses will begin.

ENTER DEVICE NO.
00=QUIT 01

Voice: "ENTER DEVICE CODE NOW"

Enter the 2-digit number of the device to be activated.
Note that if an invalid number is entered, the system will simply ask
you to reenter the number.

NN DEVICE IS OFF
HIT 0=OFF , 1=ON

Voice: "
ENTER 1, FOR

voice descriptor

voice descriptor

DEVICE nn ON/OFF. FOR

OFF ENTER 0"

voice descriptor

ON

Press 0 or 1 to turn the device off or on respectively.
"nn" represents the 2-digit device number and

voice descriptor

is the

relay voice descriptor programmed by the installer.

NN DEVICE IS OFF
HIT THE "*" KEY

Voice: "

From a keypad, press [ ✽] to continue. The ENTER DEVICE NO.

voice descriptor

DEVICE nn ON/OFF. TO EXIT ENTER 00 NOW"

prompt will appear.
From a telephone keypad, enter 00 to exit, or enter the next relay

number to be programmed. The current on/off state of that relay will
be annunciated as described above. Alternatively, if 6 seconds
elapses with no key depression, the voice module will annunciate the
"ENTER DEVICE CODE NOW" message.

– 34 –

FA1220CV EVENT LOGGING PROCEDURES

General Information

The system has the ability to record various events in a
history log wherein each event is recorded in one of five
categories (listed on other side), with the time and date
of its occurrence. The Event Log holds up to 100 events,
with the oldest event being replaced by the logging of
any new event after the log is full. Using an alpha
keypad, the Event Log can be viewed one category at a
time, or can display all events, regardless of category
(ALL EVENT LOG). The system also allows selection of
displaying the COMPLETE log, or only those events
occurring since the last installer service (RECENT). In
addition, events in the other partition can be viewed by
users authorized to access that partition. Note that
events are displayed in chronological order, from most
recent to oldest.

To Display The Event Log:

1. Enter CODE + [#] + [6] + [0]

2. Select the display mode.
RECENT: Displays only those events occurring since

last installer service.
COMPLETE: Displays complete event log (up to 100

events).
Press the desired key, 0 or 1.

ENTER 0 = RECENT
1 = COMPLETE

3. Select the partition, 0-2.
Enter the partition number for the partition whose

events are to be displayed.
Entering 0 (NO) will display all partitions' events.

SCAN LOG BY PART
0 = NO 1–2 = PART #

– 35 –

FA1220CV EVENT LOGGING PROCEDURES (continued)

4. Use the [3] & [1] keys (for next and previous
categories respectively) to display the categories of
events.

Press [8] to select a category and display the first
event. Press [8] again for each subsequent event.

Shows burglary alarm occurred in zone 3 (C03) of
partition 1 (P1), at 12:02AM on January 1.

P1 01/01 12:02AM
BURGLARY C03

Typical Event

L

og Display

After the last event has been displayed, the END OF
EVENT LOG message appears for a few seconds, then
the system automatically displays the RECENT/
COMPLETE mode select screen again (see step 2).

5. To EXIT the Event Log:
Press [✱] at any time.

ALARM EVENT LOG
TYPE CCC UUU

Typical Category
Select Screen

Any or all of the following categories may be active.
Check with your installer.

ALARM EVENT LOG

Displays time and date for zones that have either caused
an alarm or have been restored in the selected partition.

CHECK EVENT LOG

Displays time and date for zones that have caused a
trouble or supervisory condition in the selected partition.

BYPASS EVENT LOG

Displays time and date for zones that have been bypassed
in the partition.

OPEN EVENT LOG

Displays time, date and user number for each arming and
disarming of the system for the partition selected.

SYSTEM EVENT LOG

Displays time and date for system problems, such as AC
Loss, low battery, etc., regardless of partition.

ALL EVENT LOG

Displays all categories of events in chronological order.

See your Installer for additional

information concerning the event log.

– 36 –

TESTING THE SYSTEM

(TO BE CONDUCTED WEEKLY)

Using the 5

TEST Key

The TEST key puts your system into Test mode, which allows each protection point to be
checked for proper operation.

1. Disarm the system and close all protected windows, doors, etc. READY should be
displayed.

TEST

2. Enter your security code and press the 5 key.

3. The external sounder should sound for 3 seconds and then turn off. If the sounder does
not sound, it may be due to dialer communication activity. Wait a few minutes and try
again. If the sounder still does not sound, CALL FOR SERVICE IMMEDIATELY.

4. The keypad will sound a single beep every 15 seconds as a reminder that the system is in
Test mode. Each time a protection zone is faulted (opened), the keypad should beep three
times. If the keypad does not sound, CALL FOR SERVICE IMMEDIATELY.

Note that no alarm reports will be sent to the central monitoring station while the
system is in the Test mode.

(Continued)

– 37 –

TESTING THE SYSTEM

(Continued)

Testing Your

System

1. Open and close each protected door and window in turn and listen for three beeps. The
identification of each faulted protection point should appear on the display.

2. Walk in front of any interior motion detectors (if used) and listen for three beeps as
movement is detected. The identification of the detector should appear on the display when
it is activated.

NOTE: Wireless motion detectors activate only once in a 3-1/2 minute period to conserve
battery life.

3. Follow the manufacturer's instructions to test all smoke detectors to ensure that all are
functioning properly. The identification of each detector (or the zone number of the zone
assigned to the detector) should appear on the display when each is activated.

4. When all protection points have been checked, there should be no zone identification
numbers displayed. If a problem is experienced with any protection point (no confirming
sounds, no display), CALL FOR SERVICE IMMEDIATELY.

5. Turn off Test mode by entering the security code and pressing the OFF key.

– 38 –

TROUBLE CONDITIONS

Typical "Check"

Displays

* Note that zone

numbers 87, 88-91,
97 and 98 represent
problems with system
components, which
are not user
serviceable. CALL
FOR SERVICE
IMMEDIATELY.

** Not all systems

employ wireless
transmitters.

The word CHECK on the keypad's display, accompanied by a rapid "beeping" at the keypad,
indicates that there is a trouble condition in the system.

To silence the beeping sound for "check" conditions, press any key.

1. "CHECK" accompanied by a display of "CALL SERVICE" indicates that a problem
exists with the system that eliminates some of the protection. CALL FOR SERVICE
IMMEDIATELY.

2. "CHECK" accompanied by a display of one or more zone descriptors indicates that a
problem exists with those zone(s)*. First, determine if the zone(s) displayed are intact and
make them so if they are not. If the problem has been corrected, the display of the zone
descriptor(s) and CHECK should disappear after entering your security code + OFF. If not,
key another OFF sequence (Code plus OFF) to clear the display. If the display persists,
CALL FOR SERVICE IMMEDIATELY.

3. "COMM. FAILURE" at the Keypad indicates that a failure has occurred in the telephone
communication portion of your system. CALL FOR SERVICE IMMEDIATELY.

4. "SYSTEM LO BAT", accompanied by a once per minute "beeping" at the keypad indicates
that a low system battery condition exists. CALL FOR SERVICE IMMEDIATELY.

5. "LO BAT" and a zone descriptor, accompanied by a once per minute "beeping" at the
keypad indicates that a low battery condition exists in the wireless transmitter** displayed.
CALL FOR SERVICE IMMEDIATELY.

6. "MODEM COMM" indicates that the control is on-line with the central station's remote
computer. The control will not operate while on-line. No action is necessary.

– 39 –

TROUBLE CONDITIONS

Power Failure If the POWER indicator is off, operating power for the system has stopped and is inoperative.

CALL FOR SERVICE IMMEDIATELY. If the POWER indicator is on, but the message " AC
LOSS" is displayed, the keypad is operating on battery power only. If only some lights are out
on the premises, check circuit breakers and fuses and reset or replace as necessary. CALL
FOR SERVICE IMMEDIATELY if AC power cannot be restored.

Non-Alpha Keypad

Displays

The following displays will appear on non-alpha keypads when the associated trouble condition
(previously described) is present.

97 = CALL SERVICE
98 = CALL SERVICE
FC = COMM FAILURE
BAT = SYSTEM LO BAT (if no zone number) or LO BAT (if zone number shows)
CC = MODEM COMM
NO AC = AC LOSS

SERVICING INFORMATION

Your local First Alert Professional dealer is the person best qualified to service your alarm
system. Arranging some kind of regular service program with him is advisable.

Your local First Alert Professional dealer is:
Name:

Address:

Phone:

– 40 –

FIRE ALARM SYSTEM (IF INSTALLED)

General Your fire alarm system (if installed) is on 24 hours a day, providing continuous protection. In the

event of an emergency, the installed smoke and/or heat detectors will automatically send
signals to your Control/Communicator, triggering a loud, interrupted sound from the keypad. An
interrupted sound will also be produced by optional exterior sounders. A FIRE message will
appear at your keypad and remain on until you silence the alarm.

In Case Of Fire

Alarm

Silencing A Fire

Alarm

1. Should you become aware of a fire emergency before your detectors sense the problem,
go to your nearest keypad and manually initiate an alarm by pressing the panic key pair
assigned as FIRE emergency (if programmed by the installer) and hold down for at least 2
seconds.

2. Evacuate all occupants from the premises.

3. If flames and/or smoke are present, leave the premises and notify your local Fire
Department immediately.

4. If no flames or smoke are apparent, investigate the cause of the alarm. The zone descriptor
of the zone(s) in an alarm condition will appear at the keypad.

1. Silence the alarm by entering your code and pressing the OFF key. To clear the display,
enter your code and press the OFF key again.

2. If the keypad does not indicate a READY condition after the second OFF sequence, press
the READY key to display the zone(s) that are faulted. Be sure to check that smoke
detectors are not responding to smoke or heat producing objects in their vicinity. If this is
the case, eliminate the source of heat or smoke.

3. If this does not remedy the problem, there may still be smoke in the detector. Clear it by
fanning the detector for about 30 seconds.

4. When the problem has been corrected, clear the display by entering your code and
pressing the OFF key.

– 41 –

DINING

KITCHEN

BEDROOM

BEDROOM

BEDROOM

BEDROOM

LIVING ROOM

✪

✪

✪

✪

✪

▲

▲

BEDROOM

BDRM

BDRM

DINING

LIVING ROOM

TV ROOM

KITCHEN

■

■

■

✪

✪

✪

✪✪

✪

▲

✪

✪

✪

BEDROOM

BEDROOM

TO
BR

■

■

■

■

■

LVNG RM

BASEMENT

KTCHN

▲

▲

.

CLOSED
DOOR

GARAGE

▲

Smoke Detectors for Minimum Protection
Smoke Detectors for Additional Protection
Heat-Activated Detectors

NATIONAL FIRE PROTECTION ASSN.

RECOMMENDATIONS ON SMOKE DETECTORS

With regard to the number and placement of
smoke/heat detectors, we subscribe to the
recommendations contained in the National
Fire Protection Association's Standard #74
noted below.

Early warning fire detection is best achieved
by the installation of fire detection equipment
in all rooms and areas of the household as
follows: A smoke detector installed outside
of each separate sleeping area, in the
immediate vicinity of the bedrooms and on
each additional story of the family living unit,
including basements and excluding crawl
spaces and unfinished attics.

In addition, it is recommended that the
householder consider the use of heat or
smoke detectors in the living room, dining
room, bedroom(s), kitchen, hallway(s), attic,
furnace room, utility and storage rooms,
basements and attached garages.

– 42 –

•

FRONT

•

BACK

•

BEDROOM

BATH

BEDROOM

KITCHEN

BACK DOOR

1 FLOOR

ST

BEDROOM

BEDROOM

2 FLOOR

ND

BATH

BEDROOM

PORCH

CLOSET

EMERGENCY EVACUATION

Steps to Safety

Establish and regularly practice a plan of escape in the event of fire. The following
steps are recommended by the National Fire Protection Association:

1. Plan on your detector or your interior and/or exterior sounders warning all oc ­cupants.

2. Determine two means of escape from each room. One path of escape should lead
to the door that permits normal exit from the building. The other may be a window,
should your path be unpassable. Station an escape ladder at such windows if
there is a long drop to the ground.

3. Sketch a floor plan of the building. Show windows, doors, stairs and rooftops that
can be used to escape. Indicate escape routes for each room. Keep these routes
free from obstruction and post copies of the escape routes in every room.

4. Assure that all bedroom doors are shut while you are asleep. This will prevent
deadly smoke from entering while you escape.

5. Try the door. If the door is hot, check your alternate escape route. If the door is
cool, open it cautiously. Be prepared to slam the door if smoke or heat rushes in.

6. Crawl in the smoke.

7. Escape quickly; don't panic.

8. Establish a common meeting place outdoors, away from your house, where
everyone can meet and then take steps to contact the authorities and account for
those missing. Choose someone to assure that nobody returns to the house —
many die going back.

– 43 –

MAINTAINING YOUR SYSTEM

Taking Care of

Your System

Replacing

Batteries in

Wireless Sensors

Wireless sensors

may not have been

used in your

security system

The components of your security system are designed to be as free of maintenance as
possible. However, there are some things you can do to make sure that your system is in
reliable working condition.

1. Test your system weekly.

2. Test the system after any alarm occurs (see
Each wireless sensor in your system has a 9 volt or 3 volt battery. The system detects a low

battery in any wireless sensor, including smoke detectors, the optional personal emergency
transmitter, and the optional portable wireless keypad. (A low battery in a portable wireless
keypad is detected as soon as one of its keys is pressed, and the keypad will display 64.)

Alkaline batteries provide a minimum of 1 year of operation, and in most units and applications,
provide 2–4 years of service (4-7 years in units using 3 volt lithium batteries). Actual battery life
will depend on the environment in which the sensor is used, the number of signals that the
transmitter in the sensor has had to send, and the specific type of sensor. Factors such as
humidity, high or low temperatures or large swings in temperature, may all lead to the reduction
of actual battery life in an installation.

If you have a low battery in a wireless sensor, a low battery message is displayed on the
keypad.

In addition, a battery-operated smoke detector with a low battery also emits a single "chirp"
sound once approximately every 20-30 seconds, identifying itself as the smoke detector with
the weak battery. If you do not replace a smoke detector's low battery, the smoke detector

TESTING THE SYSTEM

).

may sound continuously, as if there were a fire alarm.

Note:

The low battery message comes on as a warning that battery replacement in indicated
sensor(s) is due within 30 days. In the meantime, the sensor(s) causing the low battery
indication is still fully operational.

Important: Use only batteries recommended by your installer as replacement.

– 44 –

MAINTAINING YOUR SYSTEM

Silencing Low

Battery Warning

Tones at the

Keypad

Routine Care • Treat the components of your security system as you would any other electrical equipment.

The keypad’s warning tones can be silenced by performing an OFF sequence (code plus OFF
key), but the keypad's low battery message display will remain on as a reminder that you have
a low battery condition in one or more of your sensors. When you replace the weak battery
with a fresh one, the sensor will send a "good battery" signal to the control as soon as the
sensor is activated (opening/closing of door, window, etc.), causing the low battery display to
turn off. If the sensor is not activated, the display will automatically clear within approximately 1
hour.

Do not slam sensor-protected doors or windows.

• Keep dust from accumulating on the keypad and all protective sensors, particularly on motion

sensors and smoke detectors.

• The keypad and sensors should be cleaned carefully with a dry soft cloth.

water or any other fluid on the units.

• Do not paint over smoke detectors or wireless transmitters.

Do not spray

– 45 –

QUICK GUIDE TO

FA1220CV SYSTEM FUNCTIONS

FUNCTION PROCEDURE COMMENTS

Check Zones Press [✱]. To view faulted zones when system not ready.
Display All Press and hold [✱] Displays all alpha descriptors programmed by installer.

Descriptors for 5 seconds
Arm System Enter code. Arms system in mode selected.

Press arming key desired.

(AWAY, STAY, INSTANT,

MAXIMUM)

Disarm System Enter code. Disarms system and silences alarms.

Press OFF [1]. Exits Test mode; unbypasses previously bypassed zones.

Bypass zones Enter code. Bypassed zones are unprotected and will not

Press BYPASS [6]. cause an alarm if violated.
Enter zone numbers to be
bypassed (use 2-digit entries).

Quick Bypass Enter code. Bypasses all faulted zones automatically.

Press BYPASS [6] + [#].

Chime Mode Enter code. Keypad will sound if doors

Press CHIME [9]. or windows are violated while system disarmed.

Test Mode Enter code. Sounds alarm sounder and allows sensors to be tested.
Press TEST [5]. No reports are sent to the central station.

View Messages Press and hold [0] for at least Message from central station will appear.
5 seconds.

View User Enter user's code. Displays partitions & authority
Capabilities Press [✱] + [✱]. levels assigned to the user.

Limited Use User Enter your code + [#] + [8][4]. Master or manager level codes only.
(Auth. Level 7) Enter the number of uses 01-15.

– 46 –

QUICK GUIDE TO

FA1220CV SYSTEM FUNCTIONS

FUNCTION PROCEDURE COMMENTS

GOTO Partition Enter security code. Allows a user at one keypad to perform functions in another

Press [✱]. partition, if that user is authorized to do so.
Enter partition number (1-2).
0 returns to default partition.

Add a User Enter master/manager code. Master & Manager level users can add subordinate users to the system,

Press CODE [8]. each with its own code and authority level.
Enter new user's user number. A master code can only be assigned by the installer.
Enter code for that user. 1 = Master 5 = Operator C (babysitter code)
At prompt, enter authority for 2 = Manager 6 = Duress
that user in this partition (2-7) 3 = Operator A 7 = Limited Use
Follow prompts, 1=Yes, 0=No. 4 = Operator B

Change a user's Enter master/manager code. Master & Manager level users can change their own or other
Code Press CODE [8]. users' codes.

Enter user's 2-digit number.
Enter new code for that user.
Press 0 (No) at prompt.

Delete a User Enter master/manager code. Master & Manager level users can delete users.

Press CODE [8]. A user can only be deleted by a user with
Enter user no. to be deleted. higher authority level.
Enter master/manager code.
Press 1 (Yes) at prompt.

Using Speed Key D Press and hold down the [D] key. Defined sequence automatically begins.

Enter your user code at prompt. Refer to SPEED KEY section for details on defining sequences.
Relay Menu Mode Enter code + [#] + [7][0]. Follow the prompts displayed.
Self-Help Press and hold any function Will display abbreviated instructions for the key pressed.

key for at least 5 seconds.

– 47 –

SUMMARY OF AUDIBLE NOTIFICATION

(ALPHA DISPLAY KEYPADS)

SOUND CAUSE DISPLAY

LOUD, INTERRUPTED*
Keypad & External

LOUD, CONTINUOUS*
Keypad & External

ONE SHORT BEEP
(not repeated)
Keypad only

ONE SHORT BEEP
(once every 15 seconds)
Keypad only

ONE BEEP every 60 sec.

Keypad only

TWO SHORT BEEPS
Keypad only

THREE SHORT BEEPS
Keypad only

RAPID BEEPING
Keypad only

SLOW BEEPING
Keypad only

* If bell is used as external sounder, fire alarm is pulsed ring; burglary/audible emergency is steady ring.
** Entry warning may consist of three short beeps or slow continuous beeping, as programmed by your installer.
*** Loss of system battery power is not indicated or annunciated by the keypad (warnings are for loss of AC power only).

FIRE ALARM FIRE is displayed; descriptor of zone in alarm is displayed.
BURGLARY/AUDIBLE

EMERGENCY ALARM
a. SYSTEM DISARM

b. SYSTEM ARMING ATTEMPT
WITH AN OPEN ZONE.
c. BYPASS VERIFY

SYSTEM IS IN TEST MODE Opened Zone identifications will appear.

LOW BATTERY AT A TRANSMITTER LO BAT displayed with description of transmitter.
ARM AWAY OR MAXIMUM ARMED AWAY or ARMED MAXIMUM is displayed. Red ARMED indicator is

a. ARM STAY OR INSTANT
b. ZONE OPENED WHILE SYSTEM

IS IN CHIME MODE.
c. ENTRY WARNING**

a. TROUBLE
b. AC POWER LOSS ALERT***
c. MEMORY OF ALARM

a. ENTRY DELAY WARNING**
b. EXIT DELAY WARNING

(if programmed)

ALARM is displayed; descriptor of zone in alarm is also displayed.
a. DISARMED/READY TO ARM is displayed.

b. The number and descriptor of the open protection zone is displayed.
c. Numbers and descriptors of the bypassed protection zones are displayed

(One beep is heard for each zone displayed). Subsequently, the following is
displayed: DISARMED BYPASS Ready to Arm

lit.
a. ARMED STAY ZONE BYPASSED or ARMED INSTANT ZONE BYPASSED

is displayed. Red ARMED indicator is lit.
b. CHIME displayed, descriptor of open protection zone will be displayed if the
[✱] key is pressed.
c. DISARM SYSTEM OR ALARM WILL OCCUR is displayed.

a. CHECK displayed. Descriptor of troubled protection zone is displayed.
b. AC LOSS displayed (may alternate with other displays that may be present).
c. FIRE or ALARM is displayed; descriptor of zone in alarm is displayed.

a. DISARM SYSTEM OR ALARM WILL OCCUR is displayed. Exceeding the
delay time without disarming causes alarm.
b. ARMED AWAY or ARMED MAXIMUM is displayed along with You May

Exit Now

– 48 –

GLOSSARY

The following glossary of terms are used throughout the manual.

ARM/DISARM: "Armed" simply means that the burglary portion of your system is turned ON and is in a state of

readiness. "Disarmed" means that the burglary system is turned OFF, and must be rearmed to
become operational. However, even in a "disarmed" state, "emergency" and "fire" portions of
your system are still operational.

KEYPAD: This is the area on your Keypad containing numbered pushbuttons similar to those on

telephones or calculators. These keys control the arming or disarming of the system, and
perform other functions which were previously described in this manual.

ZONE: A specific area of protection (may include more than one window or door).

PARTITION: An independent group of zones that can be armed and disarmed without affecting other zones

or users.

BYPASS: To disarm a specific area of burglary protection while leaving other areas operational.

DELAY ZONE: An area of protection containing doors most frequently used to enter or exit (typically, a front

door, back door, or door from the garage into the building). The delay zone allows sufficient
time for authorized entry or exit without causing an alarm. Consult your installer for the entry
and exit delay times that have been set for your system during installation and record them on
the separate sheet provided in this manual.

DAY/NIGHT ZONE: An area of protection whose violation causes a trouble indication during the disarmed (DAY)

mode (keypad beeps rapidly) and an alarm during the armed (NIGHT) mode.

– 49 –

UL NOTICE: This is a "GRADE A" system.

"FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT"

This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following
statement for your information:

This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the
manufacturer's instructions, may cause interference to radio and television reception. It has been type tested and found to comply with
the limits for a Class B computing device in accordance with the specifications in Part 15 of FCC Rules, which are designed to provide
reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• If using an indoor antenna, have a quality outdoor antenna installed.

• Reorient the receiving antenna until interference is reduced or eliminated.

• Move the receiver away from the control/communicator.

• Move the antenna leads away from any wire runs to the control/communicator.

• Plug the control/communicator into a different outlet so that it and the receiver are on different branch circuits.

If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions.
The user or installer may find the following booklet prepared by the Federal Communications Commission helpful: "Interference

Handbook"
This booklet is available from the U.S. Government Printing Office, Washington, DC 20402.

The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's
Manual. Unauthorized changes or modifications could void the user's authority to operate the equipment.

IN THE EVENT OF TELEPHONE OPERATIONAL PROBLEMS

In the event of telephone operational problems, disconnect the control by removing the plug from the RJ31X (CA38A in Canada)
telephone wall jack. We recommend that your certified installer demonstrate disconnecting the phones on installation of the system.
Do not disconnect the phone connection inside the control/communicator. Doing so will result in the loss of your phone lines. If the
regular phone works correctly after the control/communicator has been disconnected from the phone lines, the control/communicator
has a problem and should be returned for repair. If upon disconnection of the control/communicator, there is still a problem on the
line, notify the telephone company that they have a problem and request prompt repair service. The user may not under any
circumstances (in or out of warranty) attempt any service or repairs to the system. It must be returned to the factory or an authorized
service agency for all repairs.

– 50 –

"FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 68 NOTICE

This equipment complies with Part 68 of the FCC rules. On the front cover of this equipment is a label that contains, among other
information, the FCC registration number and ringer equivalence number (REN) for this equipment. If requested, this information
must be provided to the telephone company.

This equipment uses the following jacks:

An RJ31X is used to connect this equipment to the telephone network.

The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive RENs on the
telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs
should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total
RENs, contact the telephone company to determine the maximum REN for the calling area.

If this equipment causes harm to the telephone network, the telephone company will notify you in advance that temporary
discontinuance of service may be required. If advance notice is not practical, the telephone company will notify the customer as soon
as possible. Also, you will be advised of your right to file a complaint with the FCC if you believe necessary.

The telephone company may make changes in its facilities, equipment, operations, or procedures that could affect the operation of
the equipment. If this happens, the telephone company will provide advance notice in order for you to make the necessary
modifications in order to maintain uninterrupted service.

If trouble is experienced with this equipment, please contact the manufacturer for repair and warranty information. If the trouble is
causing harm to the telephone network, the telephone company may request you remove the equipment from the network until the
problem is resolved.

There are no user serviceable components in this product, and all necessary repairs must be made by the manufacturer. Other repair
methods may invalidate the FCC registration on this product.

This equipment cannot be used on telephone company-provided coin service. Connection to Party Line Service is subject to state
tariffs.

This equipment is hearing-aid compatible.
When programming or making test calls to an emergency number, briefly explain to the dispatcher the reason for the call. Perform

such activities in the off-peak hours; such as early morning or late evening.

– 51 –

CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT

The Canadian Department of Communications label identifies certified

NOTICE

equipment. This certification means that the equipment meets certain
telecommunications network protective, operational and safety
requirements. The Department does not guarantee the equipment will
operate to the user's satisfaction.

Before installing this equipment, users should ensure that it is permissible
to be connected to the facilities of the local telecommunications company.
The equipment must also be installed using an acceptable method of
connection. In some cases, the company's inside wiring associated with a
single line individual service may be extended by means of certified
connector assembly (telephone extension cord). The customer should be
aware that compliance with the above conditions may not prevent
degradation of service in some situations.

Repairs to certified equipment should be made by an authorized
Canadian maintenance facility designated by the supplier. Any repairs or
alterations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company cause to
request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines and internal metallic
water pipe system, if present, are connected together. This precaution
may be particularly important in rural areas.

Caution: User should not attempt to make such connections themselves,
but should contact the appropriate electric inspection authority, or
electrician, as appropriate.

The Load Number (LN) assigned to each terminal device denotes the
percentage of the total load to be connected to a telephone loop which is

used by the device, to prevent overloading. The termination on a loop
may consist of any combination of devices subject only to the requirement
that the total of the Load Numbers of all the devices does not exceed 100.

L'étiquette du ministère des Communications du Canada identifie le

AVIS

matériel homologué. Cette étiquette certifie que le matériel est conforme
à certaines normes de protection, d'exploitation et de sécurité des
réseaux de télécommunications. Le ministère n'assure toutefois pas que
le matériel fonctionnera à la satisfaction de l'utilisateur.

Avant d'installer ce matériel, l'utilisateur doit s'assurer qu'il est permis de
le raccorder aux installations de l'entreprise locale de
télécommunications. Le matériel doit également être installé en suivant
une méthode acceptée de raccordement. Dans certains cas, les fils
intérieurs de l'entreprise utilisés pour un service individuel à la ligne
unique peuvent être prolongés au moyen d'un dispositif homologué de
raccordement (cordon prolongateur téléphonique interne). L'abonné ne
doit pas oublier qu'il est possible que la conformité aux conditions
énoncées ci-dessus n'empèchet pas la dégradation du service dans
certaines situations. Actuellement, les entreprises de télécommunications
ne permettent pas que l'on raccorde leur matériel aux prises d'abonnés,
sauf dans les cas precis prévus par les tarifs particuliers de ces
entreprises.

Les réparations du matériel homologué doivent être effectuées pas un
centre d'entretien canadien autorisé désigné par le fournisseur. La
compagnie de télécommunications peut demander à l'utilisateur de
débrancher un appareil à la suite de réparations ou de modifications
effectuées par l'utilisateur ou à cause de mauvais fonctionnement.

Pour sa propre protection, l'utilisateur doit s'assurer que tous les fils de
mise en terre de la source d'énergie électrique, des lignes téléphoniques
de réseau de conduites d'eau s'il y en a, soient raccordés ensemble.
Cette précaution est particulièrement importante dans les régions rurales.

Avertissement: L'utilisateur ne doit pas tenter de faire ces
raccordements lui-même; il doit avoir recours à un service d'inspection
des installations électriques, ou à un électricien, selon le cas.

L'indice de charge (IC) assigné à chaque dispositif terminal pour éviter
toute surcharge indique le pourcentage de la charge totale qui peut être

raccordé à un circuit téléphonique bouclé utilisé par ce dispositif. La
terminaison du circuit bouclé peut être constituée de n'importe quelle
combinaison de dispositifs, pourvu que la somme des indices de charge
de l'ensemble des dispositifs ne dépasse pas 100.

– 52 –

WARNING!

THE LIMITATIONS OF THIS ALARM SYSTEM

While this system is an advanced design security system, it does not offer guaranteed protection against burglary or fire or other
emergency. Any alarm system, whether commercial or residential, is subject to compromise or failure to warn for a variety of reasons.
For example:

• Intruders may gain access through unprotected openings or have the technical sophistication to bypass an alarm sensor or
disconnect an alarm warning device.

• Intrusion detectors (e.g. passive infrared detectors), smoke detectors, and many other sensing devices will not work without p ower.
Battery operated devices will not work without batteries, with dead batteries, or if the batteries are not put in properly. Devices
powered solely by AC will not work if their AC power supply is cut off for any reason, however briefly.

• Signals sent by wireless transmitters may be blocked or reflected by metal before they reach the alarm receiver. Even if the signal
path has been recently checked during a weekly test, blockage can occur if a metal object is moved into the path.

• A user may not be able to reach a panic or emergency button quickly enough.

• While smoke detectors have played a key role in reducing residential fire deaths in the United States, they may not activate or
provide early warning for a variety of reasons in as many as 35% of all fires, according to data published by the Federal Emergency
Management Agency. Some of the reasons smoke detectors used in conjunction with this System may not work are as follows.
Smoke detectors may have been improperly installed and positioned. Smoke detectors may not sense fires that start where smoke
cannot reach the detectors, such as in chimneys, in walls, or roofs, or on the other side of closed doors. Smoke detectors also may
not sense a fire on another level of a residence or building. A second floor detector, for example, may not sense a first floor or
basement fire. Moreover, smoke detectors have sensing limitations. No smoke detector can sense every kind of fire every time. In
general, detectors may not always warn about fires caused by carelessness and safety hazards like smoking in bed, violent
explosions, escaping gas, improper storage of flammable materials, overloaded electrical circuits, children playing with matches, or
arson. Depending upon the nature of the fire and/or the locations of the smoke detectors, the detector, even if it operates as
anticipated, may not provide sufficient warning to allow all occupants to escape in time to prevent injury or death.

• Passive Infrared Motion Detectors can only detect intrusion within the designed ranges as diagrammed in their installation manual.
Passive Infrared Detectors do not provide volumetric area protection. They do create multiple beams of protection, and intrusion
can only be detected in unobstructed areas covered by those beams. They cannot detect motion or intrusion that takes place
behind walls, ceilings, floors, closed doors, glass partitions, glass doors, or windows. Mechanical tampering, masking, painting or
spraying of any material on the mirrors, windows or any part of the optical system can reduce their detection ability. Passive
Infrared Detectors sense changes in temperature; however, as the ambient temperature of protected area approaches the
temperature range of 90° to 105°F, the detection performance can decrease.

(Continued)

– 53 –

WARNING!

THE LIMITATIONS OF THIS ALARM SYSTEM

(continued)

• Alarm warning devices such as sirens, bells or horns may not alert people or wake up sleepers if they are located on the other side
of closed or partly open doors. If warning devices sound on a different level of the residence from the bedrooms, then they are less
likely to waken or alert people inside the bedrooms. Even persons who are awake may not hear the warning if the alarm is muffled
from a stereo, radio, air conditioner or other appliance, or by passing traffic. Finally, alarm warning devices, however loud, may not
warn hearing-impaired people or waken deep sleepers.

• Telephone lines needed to transmit alarm signals from a premises to a central monitoring station may be out of service or
temporarily out of service. Telephone lines are also subject to compromise by sophisticated intruders.

• Even if the system responds to the emergency as intended, however, occupants may have insufficient time to protect themselves
from the emergency situation. In the case of a monitored alarm system, authorities may not respond appropriately.

• This equipment, like other electrical devices, is subject to component failure. Even though this equipment is designed to last as
long as 10 years, the electronic components could fail at any time.

The most common cause of an alarm system not functioning when an intrusion or fire occurs is inadequate maintenance. This alarm
system should be tested weekly to make sure all sensors and transmitters are working properly.

Installing an alarm system may make one eligible for lower insurance rates, but an alarm system is not a substitute for insurance.
Homeowners, property owners and renters should continue to act prudently in protecting themselves and continue to insure their lives
and property.

We continue to develop new and improved protection devices. Users of alarm systems owe it to themselves and their loved ones to
learn about these developments.

– 54 –

OWNER'S INSURANCE PREMIUM CREDIT REQUEST

This form should be completed and forwarded to your homeowner's insurance carrier for possible premium credit.

A. GENERAL INFORMATION:

Insured's Name and Address:

Insurance Company: Policy No.:
FIRST ALERT PROFESSIONAL'S FA1220C ___ FA1220CV ____ Other

Type of Alarm: Burglary Fire Both

Installed by: Serviced by:

Address Address

B. NOTIFIES (Insert B = Burglary, F = Fire)

Local Sounding Device Police Dept. Fire Dept.
Central Station Name:

Address:
Phone:

C. POWERED BY: A.C. With Rechargeable Power Supply
D. TESTING: Quarterly Monthly Weekly Other

Name Name

continued on other side

– 55 –

OWNER'S INSURANCE PREMIUM CREDIT REQUEST (cont.)

E. SMOKE DETECTOR LOCATIONS

Furnace Room Kitchen Bedrooms Attic
Basement Living Room Dining Room Hall

F. BURGLARY DETECTING DEVICE LOCATIONS:

Front Door Basement Door Rear Door All Exterior Doors
1st Floor Windows All windows I nterior locations
All Accessible Openings, Including Skylights, Air Conditioners and Vents

G. ADDITIONAL PERTINENT INFORMATION:

_________________________________________________________________

_________________________________________________________________
_________________________________________________________________
_________________________________________________________________
_________________________________________________________________

Signature: ___________________________________ Date: ___________________

– 56 –

ONE YEAR LIMITED WARRANTY

Pittway Corporation, and its divisions, subsidiaries and affiliates ("Seller"), 165 Eileen Way, Syosset, New York 11791, warrants its
First Alert security equipment (the "product") to be free from defects in materials and workmanship for one year from date of original
purchase, under normal use and service. Seller's obligation is limited to repairing or replacing, at its option, free of charge for parts,
labor, or transportation, any product proven to be defective in materials or workmanship under normal use and service. Seller shall
have no obligation under this warranty or oth erwise if the product is altered or improperly repaired or serviced by anyone other than
the Seller. In case of de fect, contact the security professional who installed and maintains your security equipment or the Seller for
product repair.

This one year Limited Warranty is in lieu of all other express warranties, obligations or liabilities. THERE ARE NO EXPRESS
WARRANTIES, WHICH EXTEND BEYOND THE FACE HEREOF. ANY IMPLIED WARRANTIES, OBLIGATIONS OR LIABILITIES
MADE BY SELLER IN CONNECTION WITH THIS PRODUCT, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY,
OR FITNESS FOR A PARTICULAR PURPOSE OR OTHERWISE, ARE LIMITED IN DURATION TO A PERIOD OF ONE YEAR
FROM THE DATE OF ORIGINAL PURCHASE. ANY ACTION FOR BREACH OF ANY WARRANTY, INCLUDING BUT NOT
LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY, MUST BE BROUGHT WITHIN 12 MONTHS FROM DATE OF
ORIGINAL PURCHASE. IN NO CASE SHALL SELLER BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, OR UPON ANY OTHER BASIS OF
LIABILITY WHATSOEVER, EVEN IF THE LOSS OR DAMAGE IS CAUSED BY THE SELLER'S OWN NEGLIGENCE OR FAULT.
Some states do not allow limitation on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.

Seller does not represent that the product may not be compromised or circumvented; that the product will prevent any personal injury
or property loss by burglary, robbery, fire or oth erwise; or that the product will in all cases provide adequate warning or protection.
Buyer understands that a properly installed and maintained alarm may only reduce the risk of a burglary, robbery, fire or other events
occurring without providing an alarm, but it is not insurance or a guaran tee that such will not occur or that there will be no personal
injury or property loss as a result. CONSEQUENTLY, SELLER SHALL HAVE NO LIABILITY FOR ANY PERSONAL INJURY,
PROPERTY DAMAGE OR OTHER LOSS BASED ON A CLAIM THE PRODUCT FAILED TO GIVE WARN ING . HOWEVER, IF
SELLER IS HELD LIABLE, WHETHER DIRECTLY OR INDIRECTLY, FOR ANY LOSS OR DAMAGE ARISING UNDER THIS
LIMITED WARRANTY OR OTHERWISE, REGARDLESS OF CAUSE OR ORIGIN, SELLER'S MAXIMUM LIABILITY SHALL NOT IN
ANY CASE EXCEED THE PURCHASE PRICE OF THE PRODUCT, WHICH SHALL BE THE COMPLETE AND EXCLUSIVE
REMEDY AGAINST SELLER. This warranty gives you specific legal rights, and you may also have other rights which vary from state
to state. No increase or alteration, written or verbal, to this warranty is authorized.

– 57 –

– 58 –

– 59 –

àN7003-1V2]ä

N7003-1V2 7/98

175 Eileen Way, Syosset, New York 11791

Copyright © 1998 PITTWAY CORPORATION
