Wireless
Family Camera
DWB-700
(Additional Camera for
First Alert Family Monitor DWB-740)
USER'S MANUAL
©2011 BRK Brands, Inc.
All rights reser ved. D istri bute d b y BRK Brands , Inc ., 39 01 Li bert y Stre et Roa d, A urora. IL
60504-8 122. D ue to c onti nuing pr oduc t de velopm ent, the produc t ins ide th e pack aging m a y
look slightly dif fer ent tha n the one on the pack age.
BRK Brands, Inc . is a s ub sidiar y of Jarde n Cor porat ion ( NYS E: JAH) . T o obt ain warrant y
service, contact the C ons um er Af f airs Divis io n at 1 -800-323-9005, Monda y through Frida y,
7:30 a.m. - 5 p.m., Centr al Standar d T im e.
Made in China
M08-0310-006
2
Table of Contents
Safety ............................................................................................................................. 4
Safety Precautions .......................................................................................................... 4
FCC Compliance ............................................................................................................. 4
Getting to Know Your DWB-700 Family Camera ......................................................... 4
Check Package Contents ................................................................................................ 5
Digital Wireless Camera .................................................................................................. 6
Setting Up Your DWB-700 Family Camera ................................................................... 7
General Precautions ........................................................................................................ 7
Installing the Camera .................................................................................................... 7-8
Pairing ............................................................................................................................. 8
Troubleshooting ............................................................................................................ 9
Technical Information ................................................................................................. 10
Maintenance ................................................................................................................ 10
Warranty .................................................................................................................. 11-12
Product Limited Warranty .............................................................................................. 11
Warranty Exclusions ................................................................................................. 11-12
Obtaining Service .......................................................................................................... 12
3
Getting to Know Your DWB-700 Family Camera
Model DWB-700 User's Manual
Safety
SAFETY PRECAUTIONS
Please read the following instructions and warnings carefully and keep this User’s
Manual for future reference.
This product is not a substitute for responsible adult supervision.
This product is not a toy. Do not allow children to play with it.
Prevent cord entanglement—do not place camera in crib or within arm’s
reach of the child.
This product contains small parts. Adult assembly is required. Keep small
parts out of children’s reach.
Do not drop, puncture, or disassemble the camera.
Never tug on the power adapter. Use the plug to remove it from the wall.
Use the device with care. Avoid pressing hard on the camera or receiver
body.
Do not expose the camera to high temperatures.
Do not use power cable if it is crushed or damaged.
For your own safety, avoid using the camera when there is a storm or
lightning.
Do not use monitor near water.
FCC COMPLIANCE STATEMENTS
FCC COMPLIANCE CLASS B DIGITAL DEVICE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that of the receiver.
• Consult the dealer or an experienced radio or TV technician for help.
Notice: Only peripherals complying with FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by First Alert / BRK
Brands, Inc. is likely to result in interference to radio and TV reception. Changes or modifications to
the product, not expressly approved by First Alert / BRK Brands, Inc., could void the user’s authority
to operate the equipment.
We, First Alert / BRK Brands, Inc. declare under our sole responsibility that the device to which this
declaration relates: Complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CER TIFICATIO N (IF AP P LICAB LE )
FCC
This device contains a radio transmitter. Accordingly, it has been certified as compliant with 47
CFR Part 15 of the FCC Rules for intentional radiators. Products that contain a radio transmitter
are labeled with an FCC ID.
4
Setting Up Your DWB-700 Family Camera
Model DWB-700 User's Manual
Getting to Know Your
DWB-700 F a mily Camer a
Congratulations on purchasing your First Aler t Family Camera. This Camera is
designed to be used with the First Alert Family Monitor DWB-740. First Alert has been
helping your family stay safe for over 50 years. By having a First Alert Family Monitor,
you are taking the first step in watching your family.
CHECK PACKAGE CONTENTS
After unpacking the carton, check the contents for damage. Contact your supplier
or dealer immediately if any part is missing or damaged.
Digital Wireles s Baby Camer a (1)
5V 1A power adapter (1)
Camera Stand (1)
Mounting Kit (1)
User’s Manual (1)
5
Getting to Know Your DWB-700 Family Camera
Model DWB-700 User's Manual
DIGITAL WIRELESS CAMERA
1 Camera Lens
2 Night Visio n IR L EDs - Allows you to s ee up to 16 ft . in c om plete d ark ness
3 EDS Light Se nsor - Detects the abs enc e of light and turns on night vision
4 Power/Battery Indic ator - Green: Power on, Red: Battery low ( when powere d with
batteries onl y)
5 Link indicator F lashi ng: Pairing is in processi ng, Stead y Blue: Linked with r ecei ver
6 Microphone - Captur es a ll s ound in room
7 Power key/Lullaby play - Turns cam era on and of f
8 Pairing key - Press and hold to pa ir cam era t o rec ei ver
9 Power Input (DC IN 5V 1A ) - Plug the i ncl uded adap ter into this jack
10 Power adapter - Neede d to p ower c am era
11 Camera stand - Provides flexibilit y for ta ble t op us e, or wall or ce iling m ount ing of c am era
12 Camera Antenna - Tr ansm its and r ecei ves si gnals
13 Battery Compar tment ( not sho wn) - Remov e co ver to i nsta ll 3 A AA a lkalin e ba tteries (no t
included)
6
Setting Up Your DWB-700 Family Camera
Model DWB-700 User's Manual
Setting Up Your
DWB-700 F amily C a mer a
GENERAL PRECAUTIONS
Do not place any of the equipment near a radiator, vent, or other place
where it might be exposed to heat, moisture, dust, vibrations, or strong
magnetic fields. If any liquid comes into contact with the monitor, turn off the
power immediately and have a qualified technician inspect the equipment
before using it again.
W hen installing the camera, follow manufacturer’s advice when using power
tools, steps, ladders, etc. and wear suitable protective equipment (e.g.,
safety goggles) when drilling holes. Before drilling holes through a ceiling,
check for hidden electricity cables and water pipes.
INSTALLING THE CAMERA
Before the camera is installed, the camera pairing procedure
should be completed.
DC Power Supply Mode
1 Connect the power cable to the DC IN of the camera.
2 Plug the power supply into the electrical outlet.
3 Press POWER button to turn on the camera.
Battery Power Supply Mode
1 Insert 3 AAA alkaline batteries making sure the
polarity is correct.
2 Press POWER button to turn on the camera.
Table top or wall mounting:
Determine a location for the camera that will provide the best view of your baby in his
crib. Place the camera on a flat surface, such as a dresser, bureau, or shelf. Or
mount the camera on a wall. Be sure to place camera and monitor no less than 3 feet
away from your baby’s crib. Do not place the camera near open windows, direct
sunlight or heat sources.
7
Setting Up Your DWB-700 Family Camera
Model DWB-700 User's Manual
To Wall or Ceiling Mount
Use stand to mark position of screws. Before drilling a hole, it is important to check
the reception and camera/monitor positioning in the place that you intend on hanging
it to the wall or ceiling.
1 Select the position for the camera and secure the camera stand.
a. Pre-drill holes using a 7/32 inch drill bit.
b. Insert wall anchors and gently tap with hammer
until the anchors are flush with the wall.
c. Secure stand with screws.
2 Screw the camera onto the bracket.
3 Adjust camera to the proper view angle. Make sure the lens is upright relative to
your subject. Tighten the nut. Adjust the antenna to an upright position.
PAIRING (USING THE DWB-740 FAMILY MONITOR)
Access the Pairing menu from the Main Menu. Use this menu to pair receiver with camera.
1. Use
to select a channel.
2. Press
3. Within 60-second countdown, press PAIR at the camera side. Image will
display when pairing is complete
to start system countdown from 60 seconds.
8
TROUBLESHOOTING
Problem Possible Cause s Remedies
System messag e
shows “No Signal”
Low or unstable
signal
No power suppl y to
camera
Camera is not pa ired
with receiver
Service out of ra nge Move the camer a closer to th e rec ei ver.
Signal is b loc k ed If possible, rem ove m ajor obstac les in
Antenna direction is
limited
Signal has been
blocked
Strong radio sign al
nearby
Strong
electromagnetic
interference nearb y
Check po wer adapt er a nd po wer c able
connection. If c am era is r unning o n batter y
alone, you ma y need to r e place b att eries .
See pairing operation for detail.
between the cam era a nd t he rec eiver. Or,
relocate the cam era to an other l ocat ion.
Adjust the cam era ant enn a and rec ei ver
position.
If possible, rem ove m ajor obstac les in
between the cam era a nd rec eiver. Or,
relocate the cam era to an other l ocat ion.
Keep WIFI router awa y from the c am era
and/or receiver.
Keep active appli ances s uch as hair dr yers,
heat fans, air co ndit ioners , water p um ps, or
microwave ovens awa y from the c am era
and/or receiver.
Audio feedback Camera and rece iver
are too close
The camera has a high s e nsitiv it y
microphone. Kee p the c a m era at leas t 10
feet away from the rec eiver . If th e cam er a
must be within 10 f eet of the r ec eiver, keep
the volume down .
9
Technical Information
GENERAL
Operating Power 5V
Operating Tem peratur e 14°F - 122°F
Indoor Yes
Outdoor No
Digital Wireless Yes
Dimensions: Cam era & S tand 2.52” x 2.44” x 3.9”
CAMERA
Image Sensor Color CMOS
Vox (Voice) Triggered Yes
Digital Yes
Color Yes
Night Visio n C ap ab ilit y Yes
Number of Infrar ed LE Ds 10
Night Visio n D ist anc e up to 16 ft.
WIRELESS
Wireless Range 750 ft. lin e of sig ht
Frequency 2.4 GHz
MAINTENANCE
Clean the surfaces of the camera and monitor with a soft, lint-free cloth.
If the units become dirty, use a lightly damp cloth to wipe surfaces, taking care not to
allow water into any openings.
Never use cleaning agents or solvents.
10
Warranty
PRODUCT LIMITED WARRANTY
BRK Brands, Inc., (“BRK”) the maker of First Alert® brand products warrants that for a
period of one year from the date of purchase (the “Warranty Period”), this product will be
free from defects in material and workmanship. BRK, at its sole option, will repair or
replace this product or any component of the product found to be defective during the
Warranty Period. Replacement or repair will be made with a new or remanufactured
product or component. If the product is no longer available, replacement may be made
with a similar product of equal or greater value. This is your exclusive warranty.
This warranty is valid for the original retail purchaser only from the date of initial retail
purchase and is not transferable. In order to obtain warranty service, you must keep the
original sales receipt and proof of purchase in the form of the UPC code from the package.
BRK dealers, service centers, or retail stores selling BRK products do not have the right to
alter, modify or any way change the terms and conditions of this warranty.
WARRANTY EXCLUSIONS
Parts and Labor: 1 year limited (warranted parts do not include bulbs, LEDs, and batteries)
This warranty does not apply to bulbs, LEDs, and batteries supplied with or forming part
of the product.
This warranty is invalidated if non- BRK accessories are or have been used in or in
connection with the product or in any modification or repair is made to the product.
This warranty does not apply to defects or damages arising by use of the product in other
than normal (including normal atmospheric, moisture and humidity) conditions or by
installation or use of the product other than in strict accordance with the instructions
contained in the product owner’s manual.
This warranty does not apply to defects in or damages to the product caused by (i)
negligent use of the product, (ii) misuse, abuse, neglect, alteration, repair or improper
installation of the product, (iii) electrical short circuits or transients, (iv) usage not in
accordance with product installation, (v) use of replacement parts not supplied by BRK,
(vi) improper product maintenance, or (vii) accident, fire, flood or other Acts of God.
This warranty does not cover the performance or functionality of any computer software
included in the package with the product. BRK makes no warranty that the software
provided with the product will function without interruption or otherwise be free of
anomalies, errors, or “Bugs.” This warranty does not cover any costs relating to removal or
replacement of any product or software installed on your computer.
BRK reserves the right to make changes in design or to make additions to or improvements
in its products without incurring any obligations to modify any product which has already
been manufactured. BRK will make every effort to provide updates and fixes to its
11
Warranty
Model DWB-740 User's Manual
software via its website. This warranty does not cover any alteration or damage to any
other software that may be or may become resident on the users system as a result of
installing the software provided. This warranty is in lieu of other warranties, expressed or
implied, and BRK neither assumes nor authorizes any person to assume for it any other
obligation or liability in connection with the sale or service of the product. In no event
shall BRK be liable for any special or consequential damages arising from the use of the
product or arising from the malfunctioning or non-functioning of the product, or for any
delay in the performance of this warranty due to any cause beyond its control.
BRK does not make any claims or warranties of any kind whatsoever regarding the
product’s potential, ability, or effectiveness to prevent, minimize, or in any way affect
personal or property damage or injury. BRK is not responsible for any personal damage,
loss, or theft related to the product or to its use for any harm, whether physical or mental
related thereto. Any and all claims or statements, whether written or verbal, by
salespeople, retailers, dealers, or distributors to the contrary are not authorized by BRK,
and do not affect this provision of this warranty.
BRK’s responsibility under this, or any other warranty, implied or expressed, is limited to
repair, replacement or refund, as set forth above. These remedies are the sole and exclusive
remedies for any breach of warranty. BRK is not responsible for direct, special, incidental,
or consequential damages resulting from any breach of warranty or under any other legal
theory including but not limited to, loss profits, downtime, goodwill, damage to or
replacement of equipment and property and any costs of recovering, reprogramming or
reproducing any program or data stored in or used with a system containing the product
accompanying software.
BRK does not warrant the software will operate with any other software except that which
is indicated. BRK cannot be responsible for characteristics of their party hardware or
software which may effect the operation of the software included.
Except to the extent prohibited by applicable law, any implied warranty of merchantability
or fitness for a particular purpose is limited in duration to the duration of the above
Warranty Period. Some states, provinces, or jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages or limitations on how long an implied
warranty lasts, so the above limitations or exclusion may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights that vary from state to
state, or province to province, or jurisdiction to jurisdiction.
OBTAINING SERVICE
If service is required, do not return the product to your retailer. In order to obtain warranty
service, contact the Consumer Affairs Division at 1-800-323-9005, 7:30 a.m. – 5:00 p.m.
Central Standard Time, Monday through Friday. To assist us in serving you, please have
the model number and date of purchase available when calling.
After contacting the Consumer Affairs Division and it is determined that the product
should be returned for Warranty Service, please mail the product to: BRK Brands, Inc.,
3901 Liberty Street Road, Aurora. IL 60504-8122.
12
Loading...
