FA-5700-2
SEWING MACHINE
INSTRUCTION MANUAL
ШВЕЙНАЯ МАШИНКА
ИНСТРУКЦИЯ ПО
ЭКСПЛУАТАЦИИ
FA-5700-2
ENGLISH .................. PAGE 2
РУССКИЙ .................. СТР. 8
NAME OF PARTS
FRONT VIEW & BACK VIEW
Accessories
Foot controller X1
Bobbin X2
ENGLISH
• Please read the Instruction Manual carefully before operating the sewing machine.
• Please save this manual in a safe place.
• The Machine is for Household Use only.
Please read all instructions before using this appliance and keep the instructions for future
reference
Thread spool X2
Needle threader X1
Needle X1
CONNECTING THE SEWING MACHINE TO THE MAINS POWER SUPPLY
1. Make sure the „powerOFF I L & H speed switch“ is at the „OFF“ position.
2. Connect the jack Position A to the DC input socket on the back of the sewing machine, and
connect the three-pin plug Position B into the Main power supply.
3. Connect the foot pedal Position C to the sewing machine
by inserting the jack into the foot pedal, input socket on the
back of the sewing machine.
4. You can either use the foot pedal (Please keep the power/
speed switch at the off position) or the power/speed switch
(H stand for high sewing speed whilst the L stand for low
sewing speed) to operate the sewing machine.
CAUTION:
Whenever the sewing machine is not in use, make sure it is
switched off and unplugged from the Main power supply.
INSTALLING THE BATTERIES
1. Make sure the „powerOFF I L & H speed switch“ is in the „OFF“ position.
2. Turn the sewing machine over on a at surface and remove the battery compartment cover.
3. Insert 4xAA batteries into the compartment and replace the battery cover.
CAUTION:
To prevent accidental start up of the sewing machine,always
make sure that the „powerOFF I L & H speed switch“ is in the
„OFF „ position when inserting, or changing the batteries.
THREADING THE SEWING MACHINE
Threading upper thread
Caution: When threading the sewing machine make sure that the“power OFF I L & H speed switch, is
in the OFF position and follow the steps 1-6 below.
Turn hand wheel counter clockwise until the needle is in the highest position.
IMPORTANT SAFETY INSTRUCTIONS:
This sewing machine is for domestic use only.
Do not use outdoors.
Powered by an DC/AC Adapter.
The sewing machine must be switched off with the adapter unplugged when:
• Threading the needle
• Changing the needle
• Changing bottom bobbin
• Changing parts
• Cleaning the machine
• After each use
CAUTIONS
• Never leave the sewing machine unattended in the presence of children.
• When operating the sewing machine, keep your hands away from the needle, hand wheel, upper
thread tension dial and pattern selection dial.
• To clean the sewing machine, simply wipe it with a soft cloth and never use any harsh chemical
solutions.
2 3
ENGLISH
NEEDLE REPLACEMENT
CAUTION: Remove the batteries and/or disconnect the AC/DC adapter before starting to
replace the needle.
1. Turn the hand wheel to raise the needle to its
highest position.
2. Hold the old needles and loosen the needle
clamp screw. Remove the old needle and discard
responsibly.
3. Insert the new needle into the clamp with the at
side toward the right. Be sure to push the needle
clamp before tightening the needle clamp screw.
4. Tighten the needle clamp screw.
ENGLISH
REPLACING THE BOBBIN
1. Turn the hand wheel counter clockwise until the
needle is in the highest position. Raise presser foot
lifter.
2. Slide the bobbin cover button to the right and
remove the bobbin cover (Fig. 1 ).
3. Put the new bobbin in the holder, with the thread
going clockwise. Leave 10 cm of thread hanging out
(Fig. 2)
4. Hold the end of the upper thread with one hand,
and turn the hand wheel counterclockwise with the
other hand, the needle thread will pick up the bobbin
thread and pull it up through the hole under the
needle (Fig. 3).
5. Replace the bobbin cover and separate the two
threads and pull them to the back of the machine
under the presser foot, leaving about 15cm hanging there (Fig. 4).
CAUTION:
1. Always switch off the appliance, disconnect from the power supply and remove foot pedal when
replacing bottom bobbin.
2. Please use metal bobbins, otherwise the magnetic holder cannot tense the bobbin thread and
work rightly.
PRESSER FOOT REPLACEMENT
1. Removing the Presser Foot:
Turn the hand wheel counterclockwise to raise the
needle to its highest position (Fig. 1). Raise the presser
foot lifter, and press the presser foot locking lever. The
presser foot will drop off automatically from the locking
device. (Fig. 2).
2. Installing the Presser Foot:
Put the presser foot under the presser foot locking
device, lower the presser foot lifter (Fig.3), press the
presser foot locking device to reset the foot, and lift the
presser foot lifter.( (Fig. 4).
Cautions:
1. Please always switch Power off, disconnecting the
machine from the Power Adaptor and, remove the
foot pedal before replacing the Presser Foot.
2. When replace the presser foot, please place the machine on a stable platform.
3. When you put down the presser, please keep your hand or ngers away from the bottom side of
the Presser Foot to avoid injuring your ngers.
SEWING
1. Turn. the hand wheel on the side of the sewing
machine anticlockwise to raise the needle to its
highest position. Lift the presser foot and place the
fabric you wish to sew under the presser foot
(Fig. 1).
2. Lower the presser foot (Fig. 2).
3. The sewing machine can be operated in two ways:
with the foot controller or with the „power OFF I L
& H speed switch“. To operate the sewing machine
with the foot controller simply press your foot
down on the pedal and to stop sewing at any time
simply by releasing your foot from the controller.
Alternatively, when you are ready to start sewing
slide the „power OFF I L & H speed switch“ left to
the low (L) position and the sewing machine will
automatically start sewing slide switch, right to the
high position (H). In order to stop sewing slide the „power OFF I L & H speed switch“ to the „OFF“
position (Fig. 3).
4. Turn the hand wheel on the side of the sewing machine anticlockwise to raise the needle to the
highest position. Lift the presser foot and pull out the thread tension release bar, then gently
remove the fabric away from the sewing machine (Fig. 4).
5. Cut the thread using the thread cutter.
WARNING: When the sewing machine is in use do not touch the pattern selection dial..
Note: Thickness of cloth sewed by this model: ≥0.3мм.
Best to use the machine to sew double layers of cloth, thus every stitch is available. Best to use
No.6, No.7, No.8 stitch to sew soft cloth (thickness ≥ 0.3mm) or silk instead of other stitch patterns.
12 STITCH PATTERNS
1. The sewing machine has a choice of 12 different stitch PATTERNS. To
select the stitch you require, look at the diagrams numbered 1-12 on the
front of the sewing machine, choose the corresponding number on the
dial which is lined up with the arrow. For example, to select zigzag stitch
(diagram number 6), simply turn the selector dial until the number 6 on the
dial is lined up with the arrow.
2. When you wish to change a stitch pattern turn the hand wheel on the side
of the sewing machine to raise the needle to the highest point and set the
pattern selection dial to the desired stitch type in the same way as above.
REVERSE STITCH BUTTON
Reverse sewing (back stitching) is useful for reinforcing the beginning and end of seams. To use this
function proceed as follows:
1. Sew forwards as normal, and then press and hold down the reverse stitch button on the front of
the sewing machine to sew backwards.
2. To sew forwards again simply release the reverse stitch button.
SETTING THE SEWING SPEED
This sewing machine has two sewing speeds. Push the ‚OFF‘ button,into the
right,to the ‚H‘position and the sewing speed will be increased, while in the ‚L‘
position will reduce the speed.
4 5
