Limited Warranty
This probe is warranted against defects in material and workmanship for one year from date of purchase from an authorized Fieldpiece
dealer. Fieldpiece will replace or repair the defective unit, at its option,
subject to verification of the defect.
This warranty does not apply to defects resulting from abuse,
neglect, accident, unauthorized repair, alteration, or unreasonable
use of the instrument.
Any implied warranties arising from the sale of a Fieldpiece
product, including but not limited to implied warranties of merchantability and fitness for a particular purpose, are limited to the above.
Fieldpiece shall not be liable for loss of use of the instrument or other
incidental or consequential damages, expenses, or economic loss, or
for any claim of such damage, expenses, or economic loss.
State laws vary. The above limitations or exclusions may not apply
to you.
Obtaining Service
Visit www.fieldpiece.com/rma for the latest information on
how to obtain service.
www.fieldpiece.com
© Fieldpiece Instruments, Inc 2017; v04
Quick Start
1 Install the Fieldpiece Job LinkTM app on your
mobile device and sign up for an account if
you're a new user.
2 Remove the single screw from the top rubber-
ized battery cover and install 2 x AAA batteries.
3 Press for 1 second to power on.
4 Open Measurements in the Job Link™ app and
favorite the probe to the tool manager.
5 View live measurements on your mobile device
up to 350 feet away.
Certifications
EN 300 328
FCC ID: 2ALHR003
RCM
WEEE
RoHS Compliant
Description
The JL3PC Job Link™ Premium Pipe Clamp
Probe sends long range wireless pipe temperature measurements directly to the Fieldpiece
Job Link™ mobile app. Take advantage of the
Rapid Rail™ sensor for extremely fast and accurate measurements that surpasses California's
Title 24 requirements.
The Rapid Rail™ sensor is specifically
designed to work on HVACR electrically (and
thermally) conductive piping. It uses the pipe
itself to complete the circuit so ambient air
does not affect testing, resulting in the highest
temperature accuracy!
Navigate cramped spaces using the narrow
jaw. Rubberized grips and ergonomic design
supply comfort and control. Work on a wide
range of pipes from ¼’’ to 1-3/8’’. Pipe diameters are etched into sides of the clamp for quick
reference.
What's Included
Job Link™ Premium Pipe Clamp Probe
2 x AAA Batteries
Emery Cloth for Cleaning Pipes
Operator's Manual
1 Year Limited Warranty
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or
modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
(Example - use only shielded interface cables when connecting to computer or peripheral devices).
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Fieldpiece Instruments
1636 West Collins Avenue
Orange, CA 92867
Fieldpiece
Job Link™ Premium
Pipe Clamp Probe
(1/4" to 1 3/8")
OPERATOR'S
MANUAL
Model JL3PC
www.fieldpiecejoblink.com
06 07 08 09 10
Operation
Press for 1 second to power ON/OFF.
LED Color Indications
Green slow blink: normal operation
Yellow blink: open thermocouple circuit
JL3PC requires electrical continuity with the
pipe. Clean pipe surface if necessary.
Red slow blink: batteries need to be replaced
High or Low Side Switch
The Job Link™ app knows which side you
have selected for each probe. Select Suction
line or Liquid line and place it on the system
appropriately.
Rapid Rail™ Sensor Advantage
Traditional pipe clamps sit on top of the pipe
surface. Some sensors touch the pipe, some
have a material between the pipe and the
sensor. Those sensors can be affected by wind,
heat, corrosion, insulation, paint, dirt, etc.
The Rapid Rail™ sensor uses the pipe itself to
complete the thermocouple circuit. The pipe is
part of the sensor! If you get a measurement,
you know it's accurate.
Because the pipe is the thermocouple
junction, all you need is enough contact for
conductivity. This means the clamp can sit on an
angle or on a bend without loss in performance.
There is a beeper and an LED to indicate
whether or not the circuit is closed and a temperature is being measured:
Double beep and yellow LED = Open Circuit
Single beep and green LED = Closed Circuit
If you don't get a measurement, there's
something on the pipe that's blocking the electrical circuit (and accuracy). Sometimes you can
slightly rotate the clamp back and forth around
the pipe to cut through contaminants. Sometimes you need to clean the pipe a bit with
emery cloth.
Remote Data Logging
(Data logging will be available shortly after
time of printing. Look for Job Link™ app updates.)
Use the Job Link™ app to program the JL3PC
to log measurements starting at a specific time
of day for up to 7 days. Auto power off disables.
1 Make sure JL3PC is powered OFF.
2 Open the Job Link™ app.
3 Press on JL3PC for 5 seconds to enter data
logging mode. The LED will shine solid green.
4 Set up the probe's data logging parameters
within the app. The LED will blink green while
the app is sending setup instructions. The
LED will slow blink blue when waiting for
programmed start time to occur.
5 Place the JL3PC on the system.
6 When the programmed start time is reached,
the LED will very slowly blink green to indicate
data logging has begun.
7 When the programmed span has finished, the
LED blinks and powers OFF.
8 Repeat steps 1-3 and use the Job Link™ app
to extract your data log from the JL3PC.
Auto Power Off (APO)
If the clamp hasn't been opened/closed or
the button pressed, it will automatically power
off after 2 hours. To disable APO until powered
off, while power is on tap twice. The LED will
briefly blink red. To enable APO, while power
is on tap
twice. The LED will briefly shine red.
Maintenance
CLEANING: Clean the exterior with a damp
cloth. Do not use detergents or solvents.
BATTERIES: When the LED slow blinks Red,
the batteries must be replaced. Ensure the
power is OFF. Remove the single screw from
the top rubberized battery cover. Install 2 x AAA
batteries. You can also monitor batter y life in
the Job Link™ app tool manager.
CALIBRATION: The JL3PC is wireless so it
doesn't need to be calibrated as often as wired
thermocouples. To verify accuracy, submerge
just the sensor into ice water. Depending on
atmospheric pressure and water purity, the
measurement will be 32°F ± 1°F. If calibration is
required, use the tool manager in the Job Link™
app to adjust the offset for that particular tool.
Specifications
Minimum Device Requirement:
BLE 4.0 devices running iOS® 7.0 or AndroidTM 5.0
(Latest compatibility at www.fieldpiece.com)
Pipe Contact Surface Compatibility: Electrically conductive
Pipe Size Compatibility: 1/4" to 1 3/8" (6.4mm to 34.9mm) OD
Sensor Type: Rapid Rail™ thermocouple
(nickel chromium / nickel aluminum)
Measurement Feedback: Beeper and LED
Measurement Range: -50°F to 257°F (-46°C to 125°C)
Plastic body and wire insulation are designed to withstand a
maximum continuous temperature of 257°F (125°C).
Stabilization Time: 3 seconds typical
Accuracy: ±1.0°F (±0.6°C) *
*Meets California's Title 24 requirements
Battery Type: 2 x AAA, NEDA 24A, IEC LR03
Battery Life: 150 hours typical alkaline. LED blinks red when bat-
tery replacement is needed.
Auto Power Off: 2 hours (APO can be disabled)
Wireless Range: 350 feet (107 meters) line of sight.
Obstructions affect distance.
Radio Frequency: 2.4 GHz
Operating Environment: 32°F to 122°F (0°C to 50°C) at <75% RH
Storage Temperature: -4°F to 140°F (-20°C to 60°C), 0 to 80% RH
(with batteries removed)
Temperature Coefficient: 0.1 x (specified accuracy) per 0.6°F
(32°F to 64°F, 82°F to 122°F), per 1°C (0°C to 18°C, 28°C to 50°C)
Weight: 0.33 lbs (150 g)
Water Resistant: Designed to IP55
Patent: Pending
WARNING
The entire JL3PC may become hot when testing hot pipes
or cylinders. Use caution handling.
Liquid Line
(High Side)
(Red)
Suction Line
(Low Side)
(Blue)
