Fiat Connect 7.0 User Manual

7.0 CONNECT

FIAT124S PIDE R

CONTENTS

INTRODUCTION ............. 3

TIPS, CONTROLS, AND GENERAL

INFORMATION ............... 3

Tips ....................... 3

Road Safety ................. 3

Reception Condition ........... 3

CareAndMaintenance ......... 3

Important Information .......... 4

Aerial ...................... 4

Cybersecurity ................ 5

General Information ............ 5

OPERATING TIPS FOR THE

AUDIO SYSTEM .............. 5

RADIO RECEPTION ........... 6

AM Characteristics ............ 6

FM Characteristics ............ 6

OPERATING TIPS FOR MP3 . . . 7

OPERATING TIPS FOR WMA . . 7

OPERATING TIPS FOR AAC . . . 8

OPERATING TIPS FOR OGG . . . 8

OPERATING TIPS FOR USB

DEVICES — IF EQUIPPED ..... 8

OPERATING TIPS FOR IPOD . . . 9

Audio System ................ 9

Audio Set .................. 10

Basic Operation Method ....... 11

Home Screen ............... 12

Volume/Display/Sound Controls . 13

OPERATING THE RADIO ..... 15

RadioOn .................. 15

Radio Favorites .............. 16

Radio Broadcast Data System

(RBDS) — If Equipped ........ 17

HD RADIO .................. 18

OPERATING THE SATELLITE

RADIO — IF EQUIPPED ...... 19

SiriusXM Operation ........... 21

ParentalLock ............... 21

HOW TO USE AUXILIARY JACK/
USB PORT — IF EQUIPPED . . . 21

Settings ................... 23

Applications ................ 23

AUDIO CONTROL SWITCH

OPERATION ................ 24

Adjust The Volume . .......... 24

Seek Switch ................ 24

USB Audio/Bluetooth/Audio —

If Equipped ................ 24

Aha/Stitcher Radio . .......... 24

Mute Switch ................ 24

AUX/USB/IPOD MODE —

IF EQUIPPED ............... 25

How To Connect The USB Port/

Auxiliary Jack ............... 26

How To Use AUX Mode . . . .... 26

How To Use USB Mode —

If Equipped ................. 28

BLUETOOTH ............... 30

Bluetooth Hands Free Outline . . . 30

Bluetooth Audio Outline . . . . . . . 30

Component Parts ............ 31

BluetoothPreparations ........ 31

Available Language ........... 33

Voice Recognition ............ 34

Audio Operation Using Voice

Recognition . . . ............. 34

Making A Call ............... 36

Receiving An Incoming Call ..... 39

Call Interrupt . ............... 40

Receiving And Replying To
Messages (Available Only With

SMS Compatible Phones) ...... 40

Communication Settings . ...... 43

Bluetooth Audio . . ........... 44

How To Use The Bluetooth Audio

System .................... 46

Bluetooth Audio Device Information

Display .................... 48

How To Use Pandora . . ....... 49

HowToUseAha ............. 50

How To Use Stitcher Radio —

If Equipped ................. 53

TROUBLESHOOTING ........ 55

Bluetooth Hands-Free Customer

Service . . . . . . .............. 55

Bluetooth Device Pairing

(Connection Problems) ........ 55

Voice Recognition Related

Problems .................. 56

Regarding Problems With Calls . . 58

OtherProblems .............. 58

FIAT Connect 7.0

1

NAVIGATION ............... 59

Before Using The Navigation

System .................... 59

Navigation Menu ............. 59

Buttons And Other Controls

OnTheScreen .............. 60

PressAndHold .............. 61

MapScreen ................ 62

Position Markers ............. 62

Objects On The Map .......... 62

ManipulatingTheMap ......... 67

On-Road Navigation .......... 68

Selecting The Destination

Of A Route ................. 68

Entering An Address Or A Part Of

An Address . ................ 69

Selecting The Destination From

The POI (Point Of Interest) ...... 74

Searching For A Place Using
Local Search (Only Some Countries

AndRegion) ................ 80

Reference Guide ............. 97

GLOSSARY ................. 98

END-USER TERMS .......... 99

FIAT Connect 7.0

2

INTRODUCTION

The vehicle is equipped with an audio
system designed according to the
specific characteristics of the
passenger compartment, with a
customized design that matches the
style of the dashboard.

The system is installed in an ergonomic
position for the driver and passenger,
and controls can be quickly located
from the graphical display on the front,
making the device easy to use.

The instructions for use are given below
and we recommend you read them
carefully and always keep them on
hand (for example, in the glove
compartment).

Enjoy reading. Happy motoring!

Note: The information in this publica­tion is provided by way of example.
FCA can modify the content of this
publication at any time, for technical or
commercial purposes. For further infor­mation, contact an authorized dealer.

TIPS, CONTROLS,
AND GENERAL
INFORMATION

Tips

Warning!

Follow the safety rules below. Otherwise
serious injuries may occur to the
occupants or the system may be
damaged.

If the volume is too loud, this can be
dangerous. Adjust the volume so that you
can still hear background noises (e.g.
horns, ambulances, police vehicles, etc).

Road Safety

Learn how to use the various system
functions before setting off.

Read the instructions for the system
carefully before setting off.

Reception Condition

Note: The volume may be increased
when receiving traffic alerts and news.

Care And Maintenance

Caution!

Only clean the front panel and the
display with a soft, clean, dry, anti-static
cloth. Cleaning and polishing products may
damage the surface. Do not use alcohol
or similar products to clean the panel or the
display.

Do not use the display as a base for
supports with suction pads or adhesives for
external navigators or smartphones or
similar devices.

The display lens should not come into
contact with pointed or rigid objects, which
could damage its surface. Use a soft, dry
anti-static cloth to clean and do not press.

Never use alcohol, petrols and
derivatives to clean the display lens.

Prevent any liquid from entering the
system: this could damage it beyond repair.

FIAT Connect 7.0

Reception conditions change
constantly while driving. Reception may
be disrupted by the presence of
mountains, buildings or bridges,
especially when you are far away from
the broadcaster.

3

Important Information

In the event of a fault, the system must
only be checked and repaired by an
authorized dealer.

If the temperature is particularly low, the
display may take a while to reach
optimum brightness.

Aerial

AM/FM Radio Antenna

The AM/FM radio antenna receives
both AM and FM signals. To remove the
antenna, turn it counterclockwise.

To install the antenna, turn it clockwise.
Make sure the antenna is securely
installed.

FIAT Connect 7.0

06020105121001

Note:

To prevent damage to the antenna,
remove it before passing beneath a
low overhead clearance.

When leaving your vehicle
unattended, we recommend that you
remove the antenna and store it inside
the vehicle.

Satellite Radio Antenna —
If Equipped

The satellite radio antenna receives
SiriusXM signals.

06020105123003

Cybersecurity

Your vehicle may be a connected
vehicle and may be equipped with both
wired and wireless networks. These
networks allow your vehicle to send and
receive information. This information
allows systems and features in your
vehicle to function properly.

Your vehicle may be equipped with
certain security features to reduce the
risk of unauthorized and unlawful
access to vehicle systems and wireless
communications. Vehicle software
technology continues to evolve over
time and FCA US LLC, working with its
suppliers, evaluates and takes
appropriate steps as needed. Similar to
a computer or other devices, your
vehicle may require software updates to
improve the usability and performance
of your systems or to reduce the
potential risk of unauthorized and
unlawful access to your vehicle
systems.

The risk of unauthorized and unlawful
access to your vehicle systems may still
exist, even if the most recent version
of vehicle software (such as Connect
software) is installed.

4

Warning!

It is not possible to know or to predict
all of the possible outcomes if your
vehicle’s systems are breached. It may be
possible that vehicle systems, including
safety related systems, could be impaired
or a loss of vehicle control could occur that
may result in an accident involving serious
injury or death.

ONLY insert media (e.g., USB or SD
card) into your vehicle if it came from
a trusted source. Media of unknown origin
could possibly contain malicious software,
and if installed in your vehicle, it may
increase the possibility for vehicle systems
to be breached.

As always, if you experience unusual
vehicle behavior, take your vehicle to your
nearest authorized dealer immediately.

Note:

FCA US LLC or your dealer may
contact you directly regarding software
updates.

To help further improve vehicle
security and minimize the potential risk
of a security breach, vehicle owners
should:

– Routinely check

www.driveuconnect.com/

software-update

(U.S. Residents) or

http://www.driveuconnect.ca/

support/system_updates

(Canadian
Residents) to learn about available
Uconnect software updates.

– Only connect and use trusted

media devices (e.g. personal mobile
phones or USBs).

Privacy of any wireless and wired
communications cannot be assured.
Third parties may unlawfully intercept
information and private communications
without your consent.

General Information

The following regulatory statement
applies to all Radio Frequency (RF)
devices equipped in this vehicle:

This device complies with Part 15 of the
FCC Rules and with Industry Canada
license-exempt RSS standard(s).
Operation is subject to the following two
conditions

A This device may not cause harmful

interference, and

B This device must accept any

interference received, including
interference that may cause
undesired operation.

Note: Changes or modifications not
expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment.

OPERATING TIPS
FOR THE AUDIO
SYSTEM

Warning!

ALWAYS drive safely with your hands on
the wheel. You have full responsibility
and assume all risks related to the use of
the features and applications in this vehicle.
Only use these features and applications
when it is safe to do so. Failure to do
so may result in an accident involving
serious injury or death.

Note: For the purposes of safe driving,
adjust the audio volume to a level that
allows you to hear sounds outside of
the vehicle including car horns and par­ticularly emergency vehicle sirens.

To prevent the battery from being
discharged, do not leave the audio
system on for a long period of time
when the engine is not running.

If a cellular phone or CB radio is
used in or near the vehicle, it could
cause noise to occur from the audio
system, however, this does not
indicate that the system has been
damaged.

Do not spill any liquid on the audio
system.

FIAT Connect 7.0

5

RADIO RECEPTION

AM Characteristics

AM signals bend around such things as
buildings or mountains and bounce
off the ionosphere.

Therefore, they can reach longer
distances than FM signals.

Because of this, two stations may
sometimes be picked up on the same
frequency at the same time.

FM Characteristics

An FM broadcast range is usually about
25– 30 mi (40—50 km) from the source.
Because of extra coding needed to
break the sound into two channels,
stereo FM has even less range
than monaural (non-stereo) FM.

Signals from an FM transmitter are
similar to beams of light because they

FIAT Connect 7.0

do not bend around corners, but they
do reflect.

Unlike AM signals, FM signals cannot
travel beyond the horizon. Therefore, FM
stations cannot be received at the great
distances possible with AM reception.

Atmospheric conditions can also affect
FM reception. High humidity will cause
poor reception. However, cloudy days
may provide better reception than clear
days.

Multipath Noise

Since FM signals can be reflected by
obstructions, it is possible to receive
both direct signal and reflected signal at
the same time. This causes a slight
delay in reception and may be heard as
a broken sound or a distortion. This
problem may also be encountered
when in close proximity to the
transmitter.

Flutter/Skip Noise

Signals from an FM transmitter move in
straight lines and become weak in
valleys, between tall buildings,
mountains, and other obstacles. When
a vehicle passes through such an
area, the reception conditions may
change suddenly, resulting in annoying
noise.

Weak Signal Noise

In suburban areas, broadcast signals
become weak because of distance
from the transmitter. Reception in such
fringe areas is characterized by sound
breakup.

Strong Signal Noise

This occurs very close to a transmitter
tower. The broadcast signals are
extremely strong, so the result is noise
and sound breakup at the radio
receiver.

Station Drift Noise

When a vehicle reaches the area of two
strong stations broadcasting at similar
frequencies, the original station may
be temporarily lost and the second
station picked up. At this time, there will
be some noise from this disturbance.

6

OPERATING TIPS
FOR MP3

MP3 stands for MPEG Audio Layer 3,
which is standardized voice
compression established by the ISO (*)
working group (MPEG).

Use of MP3 allows for audio data to be
compressed to approximately a tenth
of the source data size.

This unit plays files with the extension
(.mp3) as MP3 files.

(*) International Organization for
Standardization

Note:

Do not use an audio file extension
on files other than audio files. In
addition, do not change the audio file
extension. Otherwise, the unit will
not recognise the file correctly resulting
in noise or a malfunction.

Supply of this product only conveys
a license for private, non-commercial
use and does not convey a license
or imply any right to use this product in
any commercial (i.e. revenue-generating)
real time broadcasting (terrestrial,
satellite, lead and/or any other media),
broadcasting/streaming via the Internet,
intranets and/or other networks or in
other electronic content distribution
systems, such as pay-audio or audio-on
demand applications. An independent
license for such use is required. For
details, please visit http://www.
mp3licensing.com.

When naming an MP3 file, be sure to
add an MP3 file extension (.mp3) after
the file name.

The number of characters which can
be displayed is restricted.

OPERATING TIPS
FOR WMA

WMA is short for Windows Media Audio
and is the audio compression format
used by Microsoft.

Audio data can be created and stored
at a higher compression ratio than
MP3. This unit plays files with the
extension (.wma) as WMA files.

* Microsoft and Windows Media are
registered trademarks of Microsoft
Corporation U.S. in the United States
and other countries.

Note: Do not use an audio file exten­sion on files other than audio files. In
addition, do not change the audio file
extension. Otherwise, the unit will not
recognize the file correctly resulting in
noise or a malfunction.

WMA files written under
specifications other than the indicated
specification may not play normally
or files or folder names may not display
correctly.

The file extension may not be
provided depending on the system,
version, software, or settings. In this
case, add the file extension “.wma” to
the end of the file name, and then write
it to the disc.

FIAT Connect 7.0

7

OPERATING TIPS
FOR AAC

AAC stands for Advanced Audio Coding,
which is standardized voice compression
established by the ISO (*) working group
(MPEG).

Audio data can be created and stored at
a higher compression ratio than MP3.

This unit plays files with the extensions
.aac/.m4a/.wav (**) as the AAC files.

(*) International Organization for
Standardization

Note:

Do not use an audio file extension
on files other than audio files. In
addition, do not change the audio file
extension. Otherwise, the unit will
not recognise the file correctly resulting
in noise or a malfunction.

AAC files written under specifications
other than the indicated specification

FIAT Connect 7.0

may not play normally or files or folder
names may not display correctly.

The file extension may not
be provided depending on the
computer operating system, version,
software, or settings. In this case, add
the file extension “.aac ”, “.m4a”, or
“.wav” to the end of the file name, and
then write it to the memory.

OPERATING TIPS
FOR OGG

OGG is the audio compression format
for Xiph. Org Foundation.

Audio data can be created and stored
at a higher compression ratio than
MP3.

This unit plays files with the extension
(.ogg) as OGG files.

Note:

Do not use an audio file extension
on files other than audio files. In
addition, do not change the audio file
extension. Otherwise, the unit will
not recognise the file correctly resulting
in noise or a malfunction.

OGG files written under
specifications other than the indicated
specification may not play normally
or files or folder names may not display
correctly.

The file extension may not be
provided depending on the computer
operating system, version, software, or
settings. In this case, add the file
extension “.ogg” to the end of the file
name, and then write it to the disc.

OPERATING TIPS
FOR USB DEVICES —
IF EQUIPPED

This unit plays audio files as follows:

Extension

.mp3 MP3

,wma WMA

.aac, .m4a, .wav AAC

.ogg OGG

Note: Do not use an audio file exten­sion on files other than audio files. In
addition, do not change the audio file
extension. Otherwise, the unit will not
recognize the file correctly resulting in
noise or a malfunction.

Playback With
This Unit

8

OPERATING TIPS
FOR IPOD

This unit supports playback of music
files recorded to an iPod.

iPod is a trademark of Apple Inc.,
registered in the U.S. and other
countries.

The iPod may not be compatible
depending on the model or OS version.
In this case, an error message is
displayed.

Note:

Remove the iPod when it is not in
use. Because the iPod is not designed
to withstand excessive changes in
temperature inside the cabin, it could
be damaged or the battery may
deteriorate due to the excessive
temperature or humidity inside the
cabin if it is left in the vehicle.

If data in the iPod are lost while it is
connected to the unit, FCA cannot
guarantee recovery of any lost data.

If the iPod battery is deteriorated,
the iPod may not recharge and
playback may not be possible when it
is connected to the unit.

For details on using the iPod, refer
to the iPod instruction manual.

When connecting the iPod to a
USB port, all commands are made
from the audio unit. iPod control is not
possible.

The audio unit cannot display
images or videos stored in an iPod.

Audio System

Six audio speakers.

Available “Bose Premium Audio
System” with Nine Bose audio speakers
including dual headrest speakers for
driver and passenger seats and woofer
installed in passenger floor.

Bose Audio System (Premium
Sound System) — If Equipped

In addition to the six speakers used by the
standard-equipment system, the
“Premium sound system” includes a
subwoofer positioned behind the
dashboard at the foot of the passenger
side and a pair of headrest speakers
on both the driver’s and passenger seats.

The nine speakers with differing
frequency ranges that comprise this
high performance system are paired
with a high-efficiency seven-channel
hybrid amplifier to deliver clear sound
with a wide reproduction range.

Audio Set

Note: The explanation of functions
described in this publication may differ
from the actual operation, and the
shapes of screens, buttons, letters, and
characters displayed may also differ
from the actual appearance.

Additionally, depending on future
software updates, the content may
successively change without notice.

Audio set has three interfaces:

Multimedia Control Knob;

Touchscreen;

Voice recognition with steering

switch and microphone.

Multimedia Control Knob
Operation

Note: For safety reasons, some opera­tions are disabled while the vehicle is
being driven.

Volume Dial Operation

Press the volume dial to switch the
audio MUTE on and off.

FIAT Connect 7.0

9

Turn the volume dial to adjust the
volume. The volume increases by turning
the dial clockwise, and decreases by
turning it counterclockwise.

Switches Around Multimedia
Control Knob

The following operations can be done
by pressing the switches around the
multimedia control knob:

: displays the home screen.

FIAT Connect 7.0

: displays the Entertainment screen.

NAV: displays the Navigation screen
(only navigation-equipped vehicles).
If the SD card for the navigation system
is not inserted, the compass indicating
the direction in which the vehicle is
moving is displayed.

06020400122002

: displays the Favorites screen.
Long-press to store particular items in
Favorites (radio, phonebook and
destination of the navigation system
can be programmed)

: returns to previous screen.

Multimedia Control Knob
Operation

Selection Of Icons On Screen

Tilt or turn the multimedia control
knob and move the cursor to the
desired icon.

Press the multimedia control knob
and select the icon.

Note: Long-press operation of the mul­timedia control knob is also possible for
some functions.

Touchscreen Operation

Note:

Do not press the screen strongly or
press it with a sharp pointed object.
Otherwise, the screen could be
damaged.

For safety reasons, touchscreen
operation is disabled while the vehicle
is moving.

Basic Operation Method

Touch & Tap

Proceed as follows:

Touch or tap on the item indicated on

the screen.

The operation is launched and the

next item is displayed.

06020400033001

10

Slide

Touch the setting item displaying a

slider bar.

Touch the slider with your finger and

move to the desired level.

06020409364002

Swipe

Proceed as follows:

Touch the screen with your finger

and move up or down.

Items which were not displayed can

be displayed.

06020409365002

Return To Previous Screen

Touch the Back button.

Displaying The Home Screen

Touch the Home button.

FIAT Connect 7.0

11

Home Screen

Icon Functions

FIAT Connect 7.0

Applications

Information such as average fuel economy, maintenance, and warnings can be verified depending on
the grade and specification, the screen display may differ.

Entertainment

Operates audio such as the radio and CDs. The audio source most recently used is displayed. An
audio source which cannot be used at that time is skipped and the previous audio source is
displayed. To change the audio source, select the icon displayed at the bottom of the screen.

Communication

Bluetooth related functions are available.

Navigation

Navigation screen is displayed (vehicles with navigation system). If the SD card for the navigation
system is not inserted, the compass indicating the direction in which the vehicle is moving is
displayed. The compass may not indicate the correct bearing when the vehicle is stopped or travelling
at a slow speed.

Settings

Overall setting menu (such as display, sound, Bluetooth and Language).
Depending on the grade and specification, the screen display may differ.

12

Volume/Display/Sound
Controls

Volume Adjustment

Turn the multimedia control knob VOL
dial. The volume switch on the steering
wheel can also be pressed.

Display Settings

Select the icon on the home screen
to display the Settings screen.

Select the Display tab to select the item
you would like to change.

Display OFF/Clock

The center display can be turned off.
Select Turn Display Off to turn the
display off.

When Turn Display Off and Show Clock is
selected, the center display turns off
and the clock is displayed.

The center display can be turned back
on as follows:

1.

Touch the center display;

2.

Operate the multimedia control knob.

Daytime/Nighttime (Mode)
Screen Setting

The daytime or nighttime screen can be
selected.

Auto: switches screen automatically
according to headlight illumination
condition (*)

Day: daytime screen setting

Night: nighttime screen setting

(*) The display is constantly on daytime
screen when the illumination dimmer
is canceled.

Brightness Adjustment

Adjust the center display brightness
using the slider.

Contrast Adjustment

Adjust the center display contrast using
the slider.

Display Setting Reset

All of the screen setting values can be
reset to their initial settings.

Proceed as follows:

1.

Select Reset.

2.

Select Yes.

Audio Sound Adjustment

Select the icon on the home screen
to display the Settings screen.

Select the Sound tab to select the item
you would like to change.

Indication Setting Value

Bass
(Low Pitch Sound)

Treble
(Treble Sound)

Fade (Front/Rear
Volume Balance)

Balance (Left/Right
Volume Balance)

ALC (*) (Automatic
Volume Adjustment)

Bose AudioPilot (**)
(Automatic Volume
Adjustment)

Beep (Audio
Operation Sound)

+ Side: Low Pitch
Enhancement
– Side: Low Pitch
Reduction

+ Side: Treble
Enhancement
– Side: Treble
Reduction

Front: Front
Speaker Volume
Enhancement
Rear: Rear Speaker
Volume
Enhancement

Right: Right
Speaker Volume
Enhancement
Left: Left Speaker
Volume
Enhancement

Off—Adjustment At
Seven Levels

On/Off

On/Off

(*) Standard audio

(**) Bose Sound System

FIAT Connect 7.0

13

Automatic Volume Adjustment

The automatic level control (ALC) is a
feature that automatically adjusts audio
volume and sound quality according
to the vehicle speed. The volume
increases in accordance with
the increase in vehicle speed, and
decreases as vehicle speed decreases.

FIAT Connect 7.0

Bose AudioPilot (Automatic
Volume Adjustment)

When driving, background noise can
interfere with enjoying music.

AudioPilot (*) noise compensation
technology continuously adjusts the
music to compensate for background
noise and vehicle speed.

It reacts only to sustained noise
sources and not intermittent ones, such
as speed bumps.

An enhanced DSP algorithm allows
faster and more effective compensation
for unusual situations, such as driving
on a very rough road or at high speeds.

(*) AudioPilot is a registered trademark
of Bose Corporation.

14

OPERATING THE RADIO

Radio On

Select the icon on the home screen to display the Entertainment screen. When selecting the desired radio, the following
icons are indicated in the lower part of the center display.

AM/FM Radio

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

Displays the station list (AM only). Select Update Station List to display the
frequencies of up to ten radio stations on the auto memory preset list. Select the
desired frequency.

Displays the Favorites list. Long-press to store radio station currently being aired

Switches the HD Radio on and off. Displays the multi-cast channel list of the HD
Radio

You can search for receivable radio stations. Scanning stops at each station for
about five seconds. Select again to continue receiving the radio station

You can change the radio frequency manually. Rotate the multimedia control knob,
slide the screen, or touch the radio frequency. Press left arrow or right arrow
buttons to change the radio frequency one step at a time. When left arrow or right
arrow buttons is long-pressed, the radio frequency changes continually. It stops
when you remove your hand from the icon or the multimedia control knob.

FIAT Connect 7.0

Launches the iTunes Tagging function (for Apple devices with USB use only). Can
be used when the HD Radio is on.

15

Icon Function

Automatic radio station selection. When long-pressed, the radio frequency
changes continually. It stops when you remove your hand from the icon or the
multimedia control knob.

Displays the FM settings screen (FM only). On/Off of Alternative frequency and
Region lock can be set.

Displays sound settings to adjust audio quality level. Refer to “Volume/Display/
Sound controls” paragraph.

Note: While in FM Mode, pressing the / icon, will select each program.

16

Radio Favorites

Selected stations can be registered for
convenient operation. Up to 50 stations
can be registered. The Favorites list is
common to AM, and FM.

Registering To Favorites

Long-press the icon to register the
current radio station.

The registration can also be performed

FIAT Connect 7.0

using the following procedure:

1.

Select the icon to display the

Favorites list.

2.

Select Add/Edit Radio Favorites.

3.

Select Add <active station>

4.

The station is added to the bottom of

the Favorites list.

Note: If the battery is disconnected,
your Favorites list will be not deleted.

Selecting Radio Station From
Favorites

Proceed as follows:

1.

Select the icon to display the

Favorites list.

2.

Select the radio station name or radio

frequency to tune in the radio station.

Deleting From Favorites

Proceed as follows:

1.

Select the icon to display the

Favorites list.

2.

Select Add/Edit Radio Favorites.

3.

Select Delete.

4.

Select the radio station or radio

frequency you want to delete.

5.

Select Delete.

Changing Favorites List Order

Proceed as follows:

1.

Select the icon to display the

Favorites list.

2.

Select Add/Edit Radio Favorites.

3.

Select Move.

4.

Select a radio station or radio
frequency. The selected radio station
can be moved.

5.

Slide the radio station or move it
using the multimedia control knob, then
select OK.

Radio Broadcast Data
System (RBDS) —
If Equipped

Radio Text Information Display

Radio text information sent from a
broadcasting station is displayed in the
center display.

Note:

Radio text information is a function
of FM radio. Text information is not
displayed in the following:

During reception

Not an RBDS broadcast

RBDS broadcast, but radio text is
not transmitted from the radio station

Genre Seek

Some FM stations transmit Genre
codes (Program type like a Rock,
News, and so on). This code enables
alternative stations transmitting the
same Genre code to be found quickly.

To Scan For Genre Seek

Proceed as follows:

1.

Select the

mode.

2.

Select Genre Seek to open the genre

list.

3.

Select the genre type you want to

select.

4.

Select the icon.

Note: To change the desired genre,
select the icon.

Example: 89.3 is currently being
received. With Rock selected as the
Genre, the radio stations broadcasting
Rock are at the following frequencies.

98.3 (*) , 98.7, 104.3 (*) , 107.1

(*) Radio stations with good reception

The frequency changes as follows each
time Genre Seek is pressed.

89.3→98.3→104.3→98.3

icon while in the FM

Note:

Only one Genre can be selected.

It may not be possible to receive
any station even if the Genre Seek
function is used.

If a program in the selected genre is
not broadcast to a region, reception
is not possible even if the Genre Seek
function is used.

The Genre Seek function searches
for genre code (program type) which
FM analog broadcasts transmit. HD
Radio specialty programs (HD2-HD8)
cannot be searched because they
are not FM analog broadcasts.

If radio stations, which are selected
by scanning, using the Genre Seek
function are HD Radio broadcasting
stations, they are changed from analog
broadcasts to HD Radio broadcasts
after a few seconds if the reception
conditions are good. The genre is
displayed after the switch, however,
the genre for FM analog broadcasts
may differ.

FIAT Connect 7.0

17

HD RADIO

What is HD Radio Technology
And How Does It Work?

HD Radio Technology is the digital
evolution of analog AM/FM radio.

Your radio product has a special receiver
which allows it to receive digital
broadcasts (where available) in addition
to the analog broadcasts it already
receives. Digital broadcasts have better
sound quality than analog broadcasts as
digital broadcasts provide free, crystal
clear audio.

For more information, and a guide to
available radio stations and programming,
please visit www.hdradio.com.

Benefits of HD Radio
Technology

Information

The song title, artist name, album name
and genre will appear on the screen

FIAT Connect 7.0

when available by the radio station.

Multicast

On the FM radio frequency most digital
stations have “multiple” or supplemental
programs on each FM station.

Listening To HD Radio
Technology

If HD Radio icon turns on by selecting a
radio station which is an HD Radio
broadcasting station, the analog
broadcast is switched to an HD Radio
broadcast automatically after a few
seconds and then received.

If the broadcast is stopped and
changed to an analog broadcast, press
down the HD Radio icon to turn off
the HD Radio.

Multicast channel selection (FM)

If multi-cast channels are available for
an HD Radio broadcast currently being
received, the multi-cast channel list is
displayed. Select the desired radio
station.

Note:

If an analog broadcast is received
once and is received while HD1 is
selected, the audio unit switches to the
station automatically.

When the HD Radio icon is
illuminated, there could be a noticeable
difference in sound quality and volume
when a change from digital to analog
signals occurs. If the sound quality and

volume become noticeably diminished
or cut off, select the HD Radio icon
to turnoff HD Radio. The Icon will not
illuminate.

Once an analog broadcast is
received when HD1 is selected from
the Favorite channels, it is switched to
HD Radio automatically. If the radio
reception conditions are poor, or HD is
off, switching to HD Radio broadcasts
is not possible.

When an HD specialty channel
(HD2 to HD8) is selected from the
Favorite channels, “Signal Lost” is
displayed and no audio is output until
HD Radio is received. If the radio
reception conditions are poor, “Signal
Lost” continues to be displayed.

If the HD Radio icon is not
illuminated, information such as song
titles of the station are received,
however, the audio output is analog.

18

iTunes Tagging (For Apple
Devices With USB Use Only)

By tagging a song currently being aired,
the song can be easily purchased
from the iTunes Store. Up to 100 tags
can be stored.

Proceed as follows:

1.

Select the icon. The tag is stored

in the audio unit.

2.

Connect the device via USB. The tag
is sent to the connected device
automatically.

3.

Synchronize the device with iTunes.
The tagged song can now be
purchased from the iTunes Store.

Note:

Both AM and FM HD Radio can be

used.

Because iTunes Tagging only
supports purchasing from the iTunes
Store, direct downloading from the
equipped vehicle audio is not possible.

If the available memory for the
connected device is insufficient, the
tag is not sent.

If an error occurs while the tag is
being sent, reconnect the device.

OPERATING THE
SATELLITE RADIO —
IF EQUIPPED

What Is Satellite Radio?

With over 130 channels, Sirius XM
Satellite Radio brings you more of what
you love. Get channels and channels
of commercial-free music, plus sports,
news, talk, entertainment and more.

Commercial-free music from nearly
every genre — rock to pop, hip-hop to
country, jazz, classical and more. Plus
live performances and artist-dedicated
channels.

Live sports Play-by-Play & Expert Talk
— every NFL game, every NASCAR
race, 24/7 sports talk, college sports
and more.

Exclusive entertainment, comedy and
talk — The biggest names, compelling
talk, hilarious comedy.

World-class news plus local traffic and
weather. Sign up for Sirius XM Satellite
Radio today!

Note:

To listen to Sirius XM, a prior

subscription (fee-based) is required.

The channels which you can
receive depend on the package you
subscribe to.

Satellite radio is broadcast as
Sirius, XM, and Sirius XM in the U.S.A.,
and Sirius and XM in Canada. In this
owner’s manual, only the name Sirius
XM is used.

For traffic and weather channels,
map information is not displayed and
only audio broadcasts can be received.

Call 888-539-7474 to activate. For
more information, visit
www.siriusxm.com (U.S. Residents) or
www.siriusxm.ca (Canadian
Residents). Satellite radio is only
available in regions providing satellite
radio service (some areas of the United
States and Canada). Contact a Fiat
Dealership.

FIAT Connect 7.0

19

How To Activate Satellite Radio

You must call Sirius XM to re-activate
your service. Activation is free and
takes only a few minutes.

Sirius XM service uses an ID code to
identify your radio. This code is needed
to activate Sirius XM service, and report
any problems.

Please have the following information
ready:

Radio ID (8-digit electronic serial no -

See below for how to find your ESN)

Valid credit card information (may not

be required at initial sign-up)

Be sure you are parked outside with a
clear view of open sky, you will be
instructed to turn on your radio.
In Sirius XM mode and tuned
to channel 184 (Sirius)/1 (XM and Sirius
XM). Activation typically takes only
2—5 minutes.

FIAT Connect 7.0

Displaying The Radio ID (ESN)

When channel 0 is selected, the radio
ID is displayed. Use the PREVIOUS
or NEXT channel buttons to select
channel 0.

SiriusXM Operation

Select the icon on the home screen
to display the Entertainment screen.
When XM is selected, the following
icons are indicated in the bottom part of
the center display.

Icon Function

Displays the Entertainment
menu. Use to switch to a
different audio source.

Displays the channel list of
the current category.

Displays the favorites list.
Long-press to store the
channel currently being
aired. Refer to “Operating
The Radio” paragraph.

Indicates that the parental
lock function is in use.
Switching of Lock/Unlock
and PIN code setting
changes can be performed.

Icon Function

Plays each channel in the
current channel list for
5 seconds. Select again to
continue receiving the
channel.

Plays the previous channel.

Plays the next channel.

Displays sound settings to
adjust audio quality level.
Refer to “Volume/Display/
Sound Controls” paragraph.

Selection From Channel List

Receivable channels can be displayed
on the channel list screen. You can
easily select the channel you want to
listen from the list. Each category can
be also displayed.

Proceed as follows:

Select the icon to display the

channel list.

Select a desired channel.

20

Select From Category List

Proceed as follows:

Select the icon to display the

channel list.

Select Category: to display the

category list.

Select a desired category.

Parental Lock

If a channel is locked, the channel is
muted.

To use the parental lock function, the
PIN code must be initialized first.

By using the session lock, the parental
lock can be enabled or disabled during
the current drive cycle (from when the
ignition is switched on to switched
off). When the session lock is on, the
parental lock is available. When the
session lock is off, the parental lock is
temporarily cancelled.

When canceling the parental lock or
session lock, or when changing the PIN
code, PIN code input is required.

PIN Code Reset

If the registered code has been
forgotten, reset the code to the default
[0000] code.

Proceed as follows:

1.

Select the “Lock” icon.

2.

If the selected channel is locked,
input the PIN code to cancel the
parental lock temporarily.

3.

Select Reset PIN Code.

4.

Input the default code [0000] using
the number buttons.

5.

Select OK.

6.

Input the new PIN code using the
number buttons.

7.

Select OK.

HOW TO USE
AUXILIARY
JACK/USB PORT —
IF EQUIPPED

Audio can be heard from the vehicle's
speakers by connecting a commercially
available portable audio unit to the
auxiliary jack.

Use a commercially-available, non
impedance (3.5 Ø) stereo mini plug
lead.

In addition, audio can be played from
the vehicle audio device by connecting
a USB device or an iPod to the USB
port. Refer to “AUX/USB/iPod Mode”.

FIAT Connect 7.0

21

Settings

Note: Depending on the grade and specification, the screen display may differ. Select the icon on the home screen to dis-
play the Settings screen.

Switch the tab and select the setting item you want to change.

You can customize settings in the setup display as follows:

Tab Item Function

Display

Safety

Sound

Clock

FIAT Connect 7.0

Vehicle

Devices

Refer To “Volume/Display/Sound
Controls” Paragraph

Blind Spot Monitoring Volume
Other

Refer To “Volume/Display/Sound
Controls” Paragraph

Adjust Time

GPS Sync When On Is Selected, “Adjust Time” Is Disabled.

Time Format Changes The Display Between 12 And 24-Hour Clock Time.

Time Zone Select Selects The Time Zone.

Daylight Savings Time

Rain Sensing Wiper, Door Lock,
Other

Bluetooth Refer To “Bluetooth Hands Free Outline”

Network Management

–

–

–

Displays The Currently Set Time Is Displayed. Press + To Advance
The Hour/Minute, And Select – To Move The Hour/Minute Back.
AM/PM Can Only Be Selected With The 12-Hour Clock Display.

Turns The Daylight Saving Time Setting On/Off. When On, The Time
Advances 1 Hour. When Off, It Returns To Normal Time.

–

Wi-Fi Is Used To Obtain Navi Poi/Real Time Traffic Function (Such As
Fuel Prices, Weather, Nearest Restaurant)

22

Tab Item Function

Tool Tips Turns Button Explanations On/Off

Language Changes The Language

Temperature Changes The Setting Between Fahrenheit And Celsius

Distance Changes The Setting Between Miles And Kilometers

Supplementary Music Information (Such As Song Name, Artist

Name)

Voice Recognition Assistance For Play Artist

Memory And Settings Are Initialized To The Factory Settings. The
Initialization Launches By Selecting The Yes Button

Agreements And Disclaimers Verify The Disclaimer And Agree

Version Information

Can Verify The Current Audio
Unit OS Version

System

Music Database Update

Factory Reset

About

Applications

Note: Depending on the grade and specification, the screen display may differ. Select the applications icon on the home screen
to display the Applications screen.

The following information can be verified:

Top System Item

Fuel, Economy, Monitor, Settings Fuel, Consumption Control Status, Effectiveness, Display, Settings

Maintenance Scheduled, Maintenance, Tire Rotation, Oil Change

Warning Guidance Warnings Currently Active Can Be Verified.

FIAT Connect 7.0

23

AUDIO CONTROL
SWITCH OPERATION

Adjust The Volume

To increase the volume: press up the
volume switch (+).

To decrease the volume: press down
the volume switch (–).

Seek Switch

AM/FM Radio

Push the seek switch
switches to the next/previous stored
station in the order that it was stored.

Push and hold the seek switch

to seek all usable stations at a
higher or lower frequency whether
programmed or not.

Radio stations which have been
previously stored in the favorite radio
can be called up by pushing the seek

FIAT Connect 7.0

switch
stored in the favorite radio is being
received.

Radio stations can be called up in the
order they were stored with each press
of the switch

while any radio station

.

. The radio

USB Audio/Bluetooth/
Audio — If Equipped

Push the seek switch to skip
forward to the beginning of the next
track.

Push the seek switch
seconds after playback begins to track
down to the beginning of the previous
track.

Push the seek switch
seconds have elapsed to start playback
from the beginning of the current
track.

Push and hold the seek switch

to continuously switch the tracks

up or down.

Aha/Stitcher Radio

Push the seek switch to skip
forward to the beginning of the next
track.

Push and hold the seek switch
evaluate the playback of the current
song as “Like”.

Push and hold the seek switch
evaluate the playback of the current
song as “Dislike”.

within a few

after a few

to

to

Mute Switch

Push the mute switch once to mute
audio, press it again to resume audio
output.

Note: If the ignition is switched off with
the audio muted, the mute will be can­celled. Therefore, when the engine is
restarted, the audio is not muted. To
mute the audio again, push the mute
switch.

24

AUX/USB/IPOD
MODE — IF
EQUIPPED

Warning!

Do not adjust the portable audio unit or a
similar product while driving the vehicle:
Adjusting the portable audio unit or a
similar product while driving the vehicle is
dangerous as it could distract your
attention from the vehicle operation which
could lead to a serious accident. Always
adjust the portable audio unit or a similar
product while the vehicle is stopped.

Audio can be heard from the vehicle's
speakers by connecting a
commercially-available portable audio
unit to the auxiliary jack.

A commercially-available, non­impedance (3.5 Ø) stereo mini plug lead
is required. Contact a authorized dealer
for details.

In addition, audio can be played from
the vehicle audio device by connecting
a USB device or an iPod to the USB
port.

Note: The SD card slot is for the naviga­tion system. For vehicles with the navi­gation system, the SD card (FCA genu­ine) with stored map data is inserted
into the SD card slot and used.

06020700122001

1 - USB port (vehicle is fitted with 2 USB
ports)

2 - Auxiliary Jack

Note:

Always close the auxiliary jack/USB
port lid when it is not in use. If foreign
matter or liquid penetrates the auxiliary
jack/USB port, it may cause a
malfunction.

Depending on the portable audio
device, noise may occur when the
device is connected to the vehicle
accessory socket (if noise occurs, do
not use the accessory socket).

This mode may not be usable
depending on the portable audio
device to be connected.

Before using the auxiliary jack/USB
port, refer to the instruction manual
for the portable audio device.

Use a commercially-available,
non-impedance (3.5 Ø) stereo mini
plug for connecting the portable audio
unit to the auxiliary jack. Before using
the auxiliary jack, read the
manufacturer's instructions for
connecting a portable audio unit to the
auxiliary jack.

To prevent battery discharge, do
not use the auxiliary input for long
periods with the engine off or idling.

When connecting a device to
the auxiliary jack or USB port, noise
may occur depending on the
connected device. If the device is
connected to the vehicle's accessory
socket, the noise can be reduced
by unplugging it from the accessory
socket.

FIAT Connect 7.0

25

How To Connect The
USB Port/Auxiliary Jack

Warning!

Do not allow the connection plug cord to get
tangled with the parking brake or the shift
lever (manual transmission/gear selector
(automatic transmission). Allowing the plug
cord to become tangled with the parking
brake or the gear selector manual
transmission/gear selector (automatic
transmission) is dangerous as it could
interfere with driving, resulting in an accident.

Connecting A Device

Proceed as follows:

1.

If there is a cover on the AUX jack or

USB port, remove the cover.

2.

Connect the connector on the device

to the USB port.

FIAT Connect 7.0

Connecting With A Connector
Lead

Proceed as follows:

1.

If there is a cover on the AUX jack or

USB port, remove the cover.

2.

Connect the device plug/connector

lead to the auxiliary jack/USB port.

Note:

Do not place objects or apply force
to the auxiliary jack/USB port with
the plug connected.

Insert the plug into the auxiliary
jack/USB port securely.

Insert or pull out the plug with the
plug perpendicular to the auxiliary
jack/USB port hole.

Insert or remove the plug by
holding its base.

How To Use AUX Mode

Select the icon on the home screen
to display the Entertainment screen and
then select “Audio Source”.

Select AUX to switch to the AUX mode.
The following icons are displayed in
the lower part of the center display.

Icon Function

Displays the Entertainment
menu. Use to switch to a
different audio source.

Displays sound settings to
adjust audio quality level.
Refer to “Volume/Display/
Sound controls” paragraph.

Note:

If a device is not connected to the
auxiliary jack, the mode will not switch
to the AUX mode.

Adjust the audio volume using the
portable audio device, commander
switch, or audio control switch.

Audio adjustments can also be
made using the portable audio
device's volume setting.

If the connection plug is pulled out
from the auxiliary jack while in AUX
mode, noise may occur.

26

How To Use USB Mode — If Equipped

Type Playable Data

USB mode MP3/WMA/AAC/OGG file

Note: This unit does not support a USB 3.0 device. In addition, other devices may not be supported depending on the model
or OS version. USB devices formatted to FAT32 are supported (USB devices formatted to other formats such as NTFS are not
supported).

Playback

Select the icon on the home screen to display the Entertainment screen and the select “Audio Source”.
Select USB 1 or USB 2 to switch the USB mode. The following icons are displayed in the lower part of the center display.

Icon Function

Displays the entertainment menu. Use to switch to a different audio source.

Category list is displayed.

Current track list is displayed. Select a desired track to play it.

Plays the current track repeatedly. Select it again to play the tracks in the current track list repeatedly.
When selected again, the function is cancelled.

Tracks in the current track list are played randomly. Select it again to cancel.

FIAT Connect 7.0

Select the desired song from the category list to cancel more like this.

27

Icon Function

If selected within a few seconds from the beginning of a song which has started to play, the previous
song is selected. If more than a few seconds have elapsed, the song currently being played is
replayed from the beginning. Long-press to fast reverse. It stops when you remove your hand from
the icon or the multimedia control knob.

Track is played. When selected again, playback is temporarily stopped.

Advances to the beginning of the next song. Long-press to fast forward.

Displays sound settings to adjust audio quality level. Refer to “Volume/Display/Sound Controls”
paragraph.

To move to the desired location on the track, move the slider indicating the playback time.
The appearance of the repeat and shuffle icons changes depending on the type of operation in which the function is used.

FIAT Connect 7.0

28

Category List

Select the icon to display the following category list.

Select a desired category and item.

Category Function

Playlist Displays Playlists on the device.

Artist

Album Displays the album name list.

Song All the tracks in the device are displayed.

Genre

Audiobook Displays the Audiobook list. Chapters can be selected and played.

Podcast

Folder Displays the folder/file list.

Displays the artist name list. All the tracks or tracks for each album of
the selected artist can be played.

Displays the genre list. All the tracks or tracks per album or artist in
the selected genre can be played.

Displays the Podcast list. Episode can be selected and played
(special service for some apple devices).

FIAT Connect 7.0

29

30

Example Of Use (To Play All
Tracks In USB Device)

Method 1

Proceed as follows:

1.

Select to display the category list.

2.

Select Song. All the tracks in the

USB device are displayed.

3.

Select a desired track. The selected
track is played. All the tracks in the USB
device can be played by continuing
playback.

Note: Only the tracks in the desired
category selected in Step Two are
played.

Method 2 (*)

Proceed as follows:

1.

Select to display the category list.

2.

Select Folder. All the folders in the
USB device are displayed.

3.

Select All Songs. All the tracks in the
USB device are displayed.

FIAT Connect 7.0

4.

Select a desired track. The selected
track is played. All the tracks in the USB
device can be played by continuing
playback.

(*) Can be operated using an Android
device or USB flash memory.

Note: Only the tracks in the desired
folder selected in Step Three are
played.

BLUETOOTH

Bluetooth Hands Free
Outline

When a Bluetooth device (mobile
phone) is connected to the vehicle's
Bluetooth unit via radio wave
transmission, a call can be made or
received by pressing the talk button,
pickup button, or hang-up button
on the multimedia control knob, or by
operating the center display.

For example, even if a device (mobile
phone) is in your coat pocket, a call can
be made without taking the device
(mobile phone) out and operating it
directly.

Warning!

ALWAYS drive safely with your hands on
the wheel. You have full responsibility
and assume all risks related to the use of
the features and applications in this vehicle.
Only use these features and applications
when it is safe to do so. Failure to do
so may result in an accident involving
serious injury or death.

Bluetooth Audio Outline

When a portable audio unit equipped
with the Bluetooth communication
function is paired to the vehicle, you
can listen to music stored on the paired
portable audio device from the vehicle's
speakers.

It is not necessary to connect the
portable audio device to the vehicle's
external input terminal.

After programming, operate the vehicle
audio control panel to play/stop the
audio.

Note:

For your safety, a device can be
paired only when the vehicle is parked.
If the vehicle starts to move, the pairing
procedure will end. Park the vehicle in
a safe place before pairing.

The communication range of a
Bluetooth equipped device is about
10 meters or less.

Basic audio operation is available
using voice commands even if
Bluetooth is not connected.

Some Bluetooth mobile devices are
not compatible with the vehicle.
Contact an authorized dealer for
information regarding Bluetooth mobile
device compatibility.

Component Parts

Microphone (Hands-Free)

The microphone is used for speaking
voice commands or when making a
Hands-free call.

06010904135005

Talk button / Pick-Up Button
And Hang-Up Button (Hands­free)

The basic functions of Bluetooth
Hands-Free can be used for such
things as making calls or hanging up
using the talk pick-up

buttons on the steering wheel.

and hang-up

Volume Control Knob —
If Equipped

The Volume Control Knob, near the
Multimedia Control Knob, is used for
volume adjustment and display
operation. Tilt or turn the Multimedia
Control Knob to move the cursor. Press
the Multimedia Control Knob to select
the icon.

Volume Adjustment

The volume dial of the multimedia
control knob is used to adjust
the volume. Turn the dial to the right to
increase volume, to the left to decrease
it. The volume can also be adjusted
using the volume button on the steering
wheel.

Note: If the volume is lower compared
to other audio modes, increase the vol­ume from the device side.

Conversation volume and the volume of
the voice guidance and ringtone can
each be set in advance.

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Setting.

3.

Adjust the Phone Volume and the VR
and Ringtone using the slider.

Bluetooth Preparations

Device Pairing

To use Bluetooth audio and Hands­Free, the device equipped with
Bluetooth has to be paired to the unit
using the following procedure.

A maximum of seven devices including
Bluetooth audio devices and hands-free
mobile phones can be paired.

Note: The Bluetooth system may not
operate for 1 or 2 minutes after the igni­tion is switched to ACC or ON. How­ever, this does not indicate a problem. If
the Bluetooth system does not connect
automatically after 1 or 2 minutes have
elapsed, make sure that the Bluetooth
setting on the device is normal and
attempt to reconnect the Bluetooth
device from the vehicle side.

Pairing Procedure

Proceed as follows:

1.

Select the icon on the home

screen to display the Settings screen.

2.

Select the Devices tab.

3.

Select Bluetooth.

4.

Turn the Bluetooth setting on.

5.

Select “Add New Device” to display
the message and switch to the device
operation.

FIAT Connect 7.0

31

6.

Using your device, perform a search
for the Bluetooth device (Peripheral
device).

7.

Select “124 Spider” from the device
list searched by the device.

8.

Device with Bluetooth version 2.0

Input the displayed 4-digit pairing code
into the device. Device with Bluetooth
version 2.1 or higher: Make sure the
displayed 6-digit code on the audio is
also displayed on the device, and touch
the Yes. Connection permission and
phonebook access permission for your
mobile device may be required
depending on the mobile device.

9.

If pairing is successful, the functions
of the device connected to Bluetooth
are displayed.

Note: When Call history and messages
are downloaded automatically, each
automatic download setting must be
on. Refer to “Communication Settings”
paragraph.

FIAT Connect 7.0

After a device is registered, the system
automatically identifies the device.

By activating Bluetooth Hands-Free
again, or by activating Bluetooth
Hands-Free first after switching the
ignition from OFF to ACC, the device
connection condition is indicated in the
center display.

Note: About pairing and automatic
reconnecting:

If pairing is redone on the same
mobile phone device, first clear
“124 Spider” displayed on the
Bluetooth setting screen of the mobile
device.

When the OS of the device is
updated, the pairing information may be
deleted. If this happens, reprogram the
pairing information to the Bluetooth unit.

Before you pair your device, make
sure that Bluetooth is “ON”, both
on your phone and on the vehicle.

Device Selection

If several devices have been paired, the
Bluetooth unit links the device last
paired.

If you would like to link a different paired
device, it is necessary to change the link.

The order of device priority after the
link has been changed is maintained
even when the ignition is switched off.

Connecting Other Devices

Proceed as follows:

1.

Select the

screen to display the Settings screen.

2.

Select the Devices tab.

3.

Select Bluetooth.

4.

Turn the Bluetooth setting on.

5.

Select the name of the device you

would like to connect.

6.

Phone And Audio selection Connects
both devices as hands-free and
Bluetooth audio. Phone Only selection
Connects as a hands-free device.
Audio Only selection Connects
as Bluetooth audio.

Note: The following functions can be
used for the Hands-free or audio.

Hands-free: phone calls and

E-mail/SMS

Audio: Bluetooth audio, Pandora,

Aha, Stitcher radio

icon on the home

32

Disconnecting A Device

Proceed as follows:

1.

Select the icon on the home

screen to display the Settings screen.

2.

Select the Devices tab.

3.

Select Bluetooth.

4.

Turn the Bluetooth setting on.

5.

Select the device name which is

currently connected.

6.

Select Disconnect.

Deleting A Device

Proceed as follows:

1.

Select the icon on the home

screen to display the Settings screen.

2.

Select the Devices tab.

3.

Select Bluetooth.

4.

Turn the Bluetooth setting on.

5.

Select the device name which you

would like to delete.

6.

Select Unpair This Device.

7.

Select Yes.

Deleting All Devices

Proceed as follows:

1.

Select the icon on the home

screen to display the Settings screen.

2.

Select the Devices tab.

3.

Select Bluetooth.

4.

Select Custom Settings.

5.

Select Unpair All/Paired Devices.

6.

Select Yes.

Changing PIN Code

PIN code (4 digits) can be changed.

Proceed as follows:

1.

Select the icon on the home

screen to display the Settings screen.

2.

Select the Devices tab.

3.

Select Bluetooth.

4.

Select Custom Settings.

5.

Select Change Pairing Code.

6.

Input the new PIN code to be set.

Available Language

The Bluetooth Hands-Free System
applies to the following languages:

English

Spanish

French

Refer to “Settings” paragraph.

Voice Recognition

Warning!

ALWAYS drive safely with your hands on
the wheel. You have full responsibility
and assume all risks related to the use of
the features and applications in this vehicle.
Only use these features and applications
when it is safe to do so. Failure to do
so may result in an accident involving
serious injury or death.

In this section, the basic operation of
the voice recognition is explained.

Activating Voice Recognition

Push the talk button.

Ending Voice Recognition

Use one of the following methods:

Push the hang-up button.

Say, “Cancel”.

Operate the commander switch or
the center display (only when vehicle is
stopped).

Skipping Voice Guidance
(For Faster Operation)

Push and release the talk button.

FIAT Connect 7.0

33

Troubleshooting For Voice
Recognition

If you do not understand an operation
method while in the voice recognition
mode, say “Tutorial” or “Help”.

Commands Usable Anytime
During Voice Recognition

“Go Back” and “Cancel” are commands
which can be used at anytime during
voice recognition.

Returning to previous operation

To return to the previous operation, say,
“Go Back” while in voice recognition
mode.

Cancel

To put the Bluetooth Hands-Free
system in standby mode, say, “Cancel”
while in voice recognition mode.

Deterioration In Rate And Quality
of Voice Recognition

FIAT Connect 7.0

To Prevent A Deterioration In The Voice
Recognition Rate And Voice Quality,
The Following Points Should Be
Observed:

The voice recognition cannot be
performed while voice guidance or the
beep sound is operating. Wait until
the voice guidance or the beep sound
is finished before saying your
commands.

Phone related commands are
available only when your phone is
connected via Bluetooth. Make sure
your phone is connected via Bluetooth
before you operate phone related
voice commands.

Music play commands, such as Play
Artist and Play Album can be used
only in USB audio mode.

Do not speak too slowly or loudly (do
not yell).

Speak clearly, without pausing
between words or numbers.

Dialects or different wording other
than hands-free prompts cannot be
recognized by voice recognition. Speak
in the wording specified by the voice
commands.

It is not necessary to face the
microphone or approach it. Speak the
voice commands while maintaining a
safe driving position.

Close the windows and/or the
convertible top to reduce loud noises from
outside the vehicle, or turn down the
airflow of the air-conditioning system while
Bluetooth Hands-Free is being used.

Make sure the vents are not directing
air up towards the microphone.

Note: If the voice recognition perfor­mance is not satisfactory. Refer to “
Voice Recognition Related Problems”
paragraph.

Audio Operation Using
Voice Recognition

Main Audio Operation

The below commands are examples of
the available commands.

When the talk button is pressed and the
following command is spoken aloud,
the audio can be operated.

The commands in the()canbe
omitted. The specified name and
number are put into the { }.

34

Voice Command Function Corresponding Audio Source

(Go To/Play) AM (Radio) Switches the audio source to AM radio All

(Go To/Play) FM (Radio) Switches the audio source to FM radio All

(Go To/Play) Satellite (Radio) Switches the audio source to satellite radio All

(Go To/Play) Bluetooth (Audio) Switches the audio source to BT audio All

(Go To/Play) Aha (Radio) Switches the audio source to Aha radio All

(Go To/Play) Stitcher Switches the audio source to Stitcher radio All

(Go To/Play) USB 1 Switches the audio source to USB 1 All

(Go To/Play) USB 2 Switches the audio source to USB 2 All

Play Playlist {Playlist name} Plays the selected Playlist USB

Play Artist {Artist name} Plays the selected artist USB

Play Album {Album name} Plays the selected album USB

Play Genre {Genre name} Plays the selected genre USB

Play Folder {Folder name} Plays the selected folder USB

Note:

Some commands cannot be used depending on devices and use conditions.

If the Bluetooth device, USB, or AUX is not connected, the related commands cannot be used.

FIAT Connect 7.0

35

36

Making A Call

Phonebook Usage

Telephone calls can be made by saying
the contact name in the downloaded
phonebook or the name of a person
whose phone number has been
registered in the Bluetooth Hands-Free.
Refer to Import Contact (download
Phonebook).

Proceed as follows:

1.

Press the talk button.

2.

Wait for the beep sound.

3.

Say: “Call XXXXX... (Ex. “John”) Mobile”.

4.

Follow the voice guidance to place

the call.

Screen Operation

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Contacts to display the

FIAT Connect 7.0

contact list.

3.

Select the contact you would like to
call to display the details for the
contact.

4.

Select the desired phone number to
make the call.

Import Contact (Download
Phonebook)

Phonebook data from your device
(Mobile phone) can be sent and
registered to your Bluetooth Hands­Free phonebook using Bluetooth.

Automatic Downloading

The “Auto Download Contacts” setting
must be on. When hands-free is
connected to the device, the
phonebook is downloaded
automatically.

Manually Downloading

If the “Auto Download Contacts” setting
is off, download the phonebook using
the following procedure.

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Contacts to display the
contact list.

3.

Select Edit Contacts.

4.

Select Import All Contacts or Import
Selected Contact to switch to the
device operation.

5.

If Import All Contacts is selected,
select Download.

6.

Download will be started from the
mobile phone.

Note:

If “Import All Contacts” is
performed after saving the phonebook
to the Bluetooth unit, the phonebook
will be overwritten.

A maximum of 1000 contacts can
be registered to the phonebook.

Phonebook, incoming/outgoing call
record, and favorite memories are
exclusive to each mobile phone to
protect privacy.

Favorites Contacts

A maximum of 50 contacts can be
registered. It will take less time to make
a call after registering the telephone
number.

In addition, you do not have to look for
the person you want to call in the
phonebook.

Registering to your favorites

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Favorites to display the
favorites list.

3.

Select Add/Edit Communication
Favorites.

4.

Select Add New Contact or Add New

Contact Details.

5.

Select from the displayed list.

Note: When “Add New Contact” is
selected, information such as the
selected person’s name is also regis­tered. In addition, when “Add New
Contact Details” is selected, only the
telephone number of the selected per­son is registered.

Making a call from your favorites

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Favorites to display the
favorites list.

3.

Only one phone number is registered to
contact. Select the contact information
you would like to call. Select Yes. Multiple
phone numbers are registered to contact
Select the contact you would like to call to
display the screen indicating the details
for the contact. Go to next step.

4.

Select the phone number you would
like to call.

5.

Select Yes.

Deleting from your favorites

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Favorites to display the
favorites list.

3.

Select Add/Edit Communication
Favorites.

4.

Select Delete.

5.

Select the contact information which
you would like to delete.

6.

Select Delete.

Changing the display order of
your favorites list

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Favorites to display the
favorites list.

3.

Select Add/Edit Communication
Favorites.

4.

Select Move.

5.

The contact can be moved after it is
selected.

6.

Slide the contact or move it using the
multimedia control knob, then select OK.

Changing contact name of your
favorites

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Favorites to display the
favorites list.

3.

Select Add/Edit Communication
Favorites.

4.

Select Rename.

5.

Select the contact to display the
keyboard screen.

6.

If a new name is input and OK is
selected, the contact name is stored.

Note: If the contact is long-pressed
when the favorites list is displayed, the
contact information can be edited
(deleted, moved).

Telephone Number Input

Note: Practice this while parked until
you are confident you can do it while
driving in a non-taxing road situation. If
you are not completely comfortable,
make all calls from a safe parking posi­tion, and only start driving when you
can devote your full attention to driving.

FIAT Connect 7.0

37

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

When Dial Phone is pressed, the dial
pad is displayed.

3.

Input the telephone number using the
dial pad.

4.

Select to make the call.

Call Back Function

Makes a call to the last person who
called your mobile phone/vehicle (latest
person on incoming call record).

Proceed as follows:

1.

Press the talk button.

2.

Wait for the beep sound.

3.

Say: “Call back”.

38

Numeral or symbol entry

Use the dial pad.

Long-press to input +.

Select the back button to delete the
currently input value. Long-press to
delete all input values.

Radial Function

Makes a call to the last person called
(latest person on outgoing call record)
from the mobile phone/vehicle.

Proceed as follows:

FIAT Connect 7.0

1.

Press the talk button.

2.

Wait for the beep sound.

3.

Say: “Redial”.

Receiving An Incoming
Call

When an incoming call is received, the
incoming call notification screen is
displayed. The “Incoming Call
Notifications” setting must be on. Refer
to “Communication Settings”
paragraph.

To accept the call, press the pick-up
button on the audio control switch
or select Answer on the screen.

To reject the call, press the hang-up
button on the audio control switch
or select Ignore on the screen.

The following icons are displayed on the screen during a call. Icons which can be used differ depending on use condition.

Icon Function

Displays the Communication menu.

Ends the call.

Transferring A Call From Hands-Free To A Mobile Phone

Communication between the Bluetooth unit and a device (mobile phone) is cancelled, and an incoming
call will be received by the device (mobile phone) like a standard call

Transferring A Call From A Device (Mobile Phone) To Hands-Free

Communication between devices (mobile phone) can be switched to Bluetooth Hands-Free

Mute

The microphone can be muted during a call. When selected again, the mute is cancelled.

A call is made to other person during a call and a 3-way call can be made. Select the contact from the
following to make a call:

Call History: Call History is displayed.

Contacts: the phonebook is displayed.

Dial: the dial pad is displayed. Input the phone number

The device may be unusable depending on the contractual content.

The call on hold is made to make a 3-way call. The device may be unusable depending on the contractual
content.

FIAT Connect 7.0

Switches the call on hold.

DTMF (Dual Tone Multi-Frequency Signal) Transmission

This function is used when transmitting DTMF via the dial pad. The receiver of a DTMF transmission is
generally a home telephone answering machine or a company's automated guidance call centre. Input the
number using a dial pad.

39

Note:

If the ignition is switched off during
a hands-free call, the line is transferred
to the device (Mobile phone)
automatically.

If the DTMF code has two or more
digits or symbols, each one must
be transmitted individually.

Call Interrupt

A call can be interrupted to receive an
incoming call from a third party.

When “Hold + Answer” is selected or
the pickup button on the steering wheel
is pressed, the current call is held and
the system switches to the new
incoming call.

When “End + Answer” is selected, the
current call is ended and the system
switches to the new incoming call (GSM
network only).

FIAT Connect 7.0

When Ignore is selected or the hang-up
button on the steering wheel is
pressed, an incoming call is refused.

Note:

The function may not be available
depending on the contractual content
of the mobile device.

The function may not be operable
depending on the type of the
telephone network and the mobile
device.

Receiving And Replying
To Messages (Available
Only With SMS
Compatible Phones)

SMS (Short Message Service)
messages received by connected
devices can be downloaded, displayed,
and played (read by the system).

Additionally, replies can also be made
to calls and messages in the received
messages.

Downloading Messages

Up to 20 new messages can be
downloaded and displayed from a
connected device.

Automatic Downloading

The “Auto Download SMS” (SMS)
setting must be on.

A message is downloaded
automatically when the Bluetooth unit is
connected to the device. Refer to
“Communication settings” Paragraph.

Manually Downloading

When the “Auto Download SMS” (SMS)
setting is off, the message is
downloaded using the following
procedure.

1.

Select the icon on the home screen

to display the Communication screen.

2.

Select SMS to display the Inbox.

3.

Select Update Inbox.

4.

Download will be started from the

mobile phone.

Note:

Attached data are not downloaded.

Messages up to 1 kilobyte
(e-mail)/140-bytes (SMS) can be
downloaded.

A message list is created for each
device.

If the connected device does not
correspond to MAP 1.0, the AT
command is used to download. The
downloaded message indicates that it
is already read.

Downloading using the AT
command may not function depending
on the connected device.

40

Receiving Messages

Method 1

When a device receives a message, a
message received notification is
displayed.

The “SMS Notifications” (SMS) setting
must be on.

Refer to “Communication settings”
paragraph.

Select Read and display the message.

Method 2

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Notifications and display the
new message list for e-mail and SMS.

3.

Select the message you would like to
display.

The following icons are displayed in the
lower part of the details on the
message. Icons which can be used
differ depending on use conditions.

Icon Function

Displays the
Communication
menu.

Displays the inbox.

Plays back a
message. When
selected again,
playback is
temporarily
stopped.

Displays the
previous message.

Displays the next
message.

Only replies to the
sender of the
currently displayed
message. Select
the sentence on the
displayed reply
screen and select
the sentence for
sending from the
preset message.
Select Send.

Icon Function

Makesacalltoa
person who sent a
message. For
E-mail, this function
may not work
depending on the
device.

Deletes a message.
The messages
stored in a device is
also deleted.

Note: Up to three preset messages can
be selected.

Example of use (verify unread
E-mail)

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Email to display the inbox.

3.

Select the unread message displayed
in bold.

4.

The details of the message are
displayed and replying to the message,
making a call, or playback can be
performed.

FIAT Connect 7.0

41

Editing preset messages

Proceed as follows:

1.

Select the phone icon on the home
screen to display the Communication
screen.

2.

Select Settings.

3.

Select Preset Messages.

4.

Select the preset message which you
would like to edit. The keyboard
screen is displayed.

5.

When the message is input and the
check mark is selected, the message is
stored as a preset message.

Note:

Select the icon to change the

language.

Select the icon to switch
between capitalized and lowercase
characters.

Select the icon to return to the
previous screen without storing the

FIAT Connect 7.0

edit.

42

Communication Settings

Select the phone icon on the home screen to display the Communication screen. Select Settings to change the setting.

Item Setting Function

Bluetooth —

Incoming Call Notifications On/Off Notifies when an incoming call is received.

Auto Download SMS On/Off

SMS Notifications On/Off Notifies when a new SMS is received.

Auto Download Call History On/Off

Auto Download Contacts (*) On/Off

Ringtone Fixed/In-Band/Off Changes the ringtone setting.

Phone Volume Adjusts Using The Slider Adjusts the conversation volume

VR And Ringtone Adjusts Using The Slider

First Name / Last Name

Contacts Sort Order

Last Name / First Name

Preset Messages —

Reset — Initializes all communication settings

Go to Bluetooth setting menu. Refer to
“Bluetooth Preparation” paragraph.

Downloads SMS automatically when the
Bluetooth unit is connected to the device.

Downloads call history automatically when
the Bluetooth unit is connected to the
device.

Downloads the Phonebook automatically
when the Bluetooth unit is connected to the
device.

Adjusts the voice guidance and ringtone
volume

Displays the contact information in
alphabetical order of the first name

Displays the contact information in
alphabetical order of the last name

Edits the preset message refer to “receiving
and replying to messages (available only with
SMS compatible phones)” paragraph

(*) Depending on the device, it may be necessary to acquire download permission on the device side.

FIAT Connect 7.0

43

Bluetooth Audio

Response Profile

A2DP (Advanced Audio Distribution Profile) Ver. 1.0/1.2

AVRCP (Audio/Video Remote Control Profile) Ver. 1.0/1.3/1.4

A2DP is a profile which transmits only audio to the Bluetooth unit. If your Bluetooth audio device corresponds only to A2DP, but
not AVRCP, you cannot operate it using the control panel of the vehicle's audio system.

In this case, only the operations on the mobile device are available the same as when a portable audio device for a non­compliant Bluetooth device is connected to the AUX terminal.

44

Function A2DP

Playback XXXX

Pause XXXX

File (Track) up/down — X X X

Reverse — — X X

Fast-Forward — — X X

Text Display — — X X

Repeat — — Depends On Device Depends On Device

FIAT Connect 7.0

Shuffle — — Depends On Device Depends On Device

Scan — — Depends On Device Depends On Device

Folder up/down ———Depends On Device

AVRCP

Ver. 1.0 Ver. 1.3 Ver. 1.4

X Available

— Not available

Note:

The battery consumption of Bluetooth audio devices increases while Bluetooth is connected.

If a general mobile phone device is USB connected during music playback over the Bluetooth connection, the Bluetooth
connection is disconnected. For this reason, you cannot have music playback over a Bluetooth connection and music
playback using a USB connection at the same time.

The system may not operate normally depending on the Bluetooth audio device.

FIAT Connect 7.0

45

How To Use The
Bluetooth Audio System

Switching To Bluetooth Audio
Mode

To listen to music or voice audio
recorded to a Bluetooth audio device,
switch to the Bluetooth audio mode
to operate the audio device using the
audio system control panel.

Any Bluetooth audio device must be
paired to the vehicle's Bluetooth unit
before it can be used.

Refer to “Bluetooth Preparation”
paragraph.

Proceed as follows:

1.

Turn on the Bluetooth audio device's

power.

2.

Switch the ignition to ACC or ON.

3.

Select the
screen to display the Entertainment
screen.

4.

When Bluetooth is selected, switches

FIAT Connect 7.0

to the Bluetooth audio mode to begin
playback.

icon on the home

Note:

If Bluetooth audio is used after
using Pandora, Aha or Stitcher radio,
the application on the mobile device
has to be closed first.

If the Bluetooth audio device does
not begin playback, select the

If the mode is switched from
Bluetooth audio mode to another
mode (radio mode), audio playback
from the Bluetooth audio device stops.

icon.

Playback

To listen to a Bluetooth audio device
over the vehicle's speaker system,
switch the mode to Bluetooth audio
mode (refer to “Switching to Bluetooth
Audio Mode” paragraph). After
switching to the Bluetooth audio mode,
the following icons are displayed in
the lower part of the display.

Icons which can be used differ
depending on the version of the
Bluetooth audio device which you are
currently using.

46

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

AVRCP Ver. 1.4 only

Displays the top level folder/file list. Select the folder which you want to select. The files in the selected
folder are displayed. Select the file you want to play.

AVRCP Ver. 1.3 or higher

Replays the song currently being played repeatedly. When selected again, the songs in the folder are
played repeatedly. Select it again to cancel. Icons change when the song is repeated or the folder is
repeated.

AVRCP Ver. 1.3 or higher

Plays songs in the folder in random order. When selected again, the songs on the device are played in
random order. Select it again to cancel. Icons change during folder shuffle or device shuffle.

Scans the titles in a folder and plays the beginning of each song to aid in finding a desired song. When
selected again, the beginning of each song on the device is played. When selected again, the operation is
cancelled and the song currently being played continues.

Returns to the beginning of the previous song. Long-press to fast reverse. It stops when you remove your
hand from the icon or the multimedia control knob.

Plays the Bluetooth audio. When selected again, playback is temporarily stopped.

Advances to the beginning of the next song. Long-press to fast forward. It stops when you remove your
hand from the icon or the multimedia control knob.

Displays sound settings to adjust audio quality level (refer to “Volume/Display/Sound Controls” paragraph).

Example of use (when searching for a song from the top level of a device)

Proceed as follows:

1.

Select the icon to display the folder/file list at the top level.

2.

When the folder is selected, folders/file lists in the folder are displayed. When the playlist is selected, the file list is displayed.

3.

Select the desired song.

4.

Select to move to a folder one level higher.

FIAT Connect 7.0

47

Bluetooth Audio Device Information Display

If a Bluetooth audio device is connected, the following information is displayed in the center display.

AVRCP Ver. Lower Than 1.3 AVRCP Ver. 1.3 AVRCP Ver. 1.3 Or Higher

Device name X X X

Remaining Battery Charge
Of Device

Song Name — X X

Artist Name — X X

Album Name — X X

Playback Time — X X

Genre Name — X X

Album Art Image — — —

X Available

— Not available

Note: Some information may not display depending on the device, and if the information cannot be displayed, “Unknown---”
is indicated.

XXX

FIAT Connect 7.0

48

How To Use Pandora

What is Pandora

Pandora is free personalized Internet
radio. Simply enter a favorite artist,
track, genre, and Pandora will create a
personalized station that plays their
music and more like it.

Rate songs by giving thumbs-up and
thumbs-down feedback to further refine
your station, discover new music and
help Pandora play only music you like.

Note: Pandora, the Pandora logo,
and the Pandora trade dress are
trademarks or registered trademarks of
Pandora Media, Inc., used with
permission.

To operate Pandora from your
Bluetooth device, perform the following
in advance:

Create Pandora account on the

Web.

Create Pandora station using

Pandora application.

Install Pandora application on your

device.

Playback

Launch the Pandora app on the device
and select the
screen to display the Entertainment
screen. When is Pandora selected, the
following icons are indicated in the
bottom part of the center display.

Icon Function

icon on the home

Displays the entertainment
menu. Use to switch to a
different audio source.

Displays the station list. Use
to switch to other stations.

Thumbs-down

Press the icon to tell Pandora
nottoplaythistrack.

Thumbs-up

Press the icon to tell Pandora
“you like this track” and it
helps to bring in more tracks
like it to your station.

Bookmarking

Bookmarks the song or artist
currently being played.

Bookmarks the song or artist
currently being played.

Goes to the next song.

Displays sound settings to
adjust audio quality level.
Refer to “Volume/Display/
Sound Controls” paragraph.

Note:

The skip function may not be

available depending on the device.

The number of skips is limited

by Pandora.

If the icon is selected when the
skip song function is running, the next
song is skipped.

Selection From Station List

Selection can be made from a
programmed radio station list.

1.

Select the icon.

2.

Select the desired radio station.

Note: When Shuffle is selected, songs
randomly selected from the radio sta­tion list are played.

Selecting the sort method

The displayed order of the station list
can be changed.

1.

Select the icon.

2.

Select Sort By.

3.

Select Date to display in the order

starting from the newly created station.

4.

Select A-Z to display in alphabetical

order.

Note: The displayed order of Shuffle
cannot be changed.

FIAT Connect 7.0

49

Bookmarking

You can bookmark song or artist to
check out later on the Web.

1.

Select the flag icon.

2.

Select Bookmark Song to bookmark

the song.

3.

Select Bookmark Artist to bookmark

the artist.

How To Use Aha

Aha is an application which can be
used to enjoy various Internet content
such as Internet radio and podcasts.

Stay connected to your friends activities
by getting updates from Facebook
and Twitter.

Using the location-based service,
nearby services and destinations can
be searched or real time local
information can be obtained.

For details on Aha, refer to “http://

FIAT Connect 7.0

www.aharadio.com/”.

Aha, the Aha logo, and the Aha

Note:

trade dress are trademarks or registered
trademarks of Harman Inter national
Industries, Inc., used with permission.

The service content provided by
Aha varies depending on the country in
which the user resides. In addition,
the service is not available in some
countries.

To operate Aha from your Bluetooth
device, perform the following in
advance:

– Install the Aha application to your

device.

– Create an Aha account for your

device.

– Log onto Aha using your device.
– Select the preset station on your

device.

Playback

Select the
to display the Entertainment screen.
When Aha is selected, the following
icons are displayed at the bottom of the
center display. The displayed icon
differs depending on the selected
station. In addition, icons other than the
following icons may be displayed.

icon on the home screen

50

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

Displays the main menu. Use to switch to other stations.

Displays the content list. Use to switch to other desired content on the station.

Shout

Records voice. Records voice and posts it as playable audio to Facebook and other social stations.

Like (*)

Evaluates the current content as “Like”.

Dislike (*)

Evaluates the current content as “Dislike”.

Reverses for 15 seconds.

Map (vehicles with navigation system)

Displays the destination searched by the location based services on the navigation system.

Call

A call can be made to the telephone number of a shop searched using the Location Based Services. Available
when a device is connected as a Hands-Free.

FIAT Connect 7.0

Returns to the previous content.

Pauses playback of the content. When selected again, playback resumes.

51

Icon Function

Goes to the next content.

Fast-forwards for 30 seconds.

Displays sound settings to adjust audio quality level (refer to “Volume/Display/Sound controls” paragraph).

(*) Some stations may use alternate variations of Like and Dislike, based on station type or provider.

52

Main Menu

FIAT Connect 7.0

Select the icon.

Switch the tab and select the station
category.

12000000002002

Tab Function

Displays the preset
station list set on

Presets

Nearby

the device. Select
the preset station
name to play the
station content.

Select the desired
station. Guidance is
provided to the
searched
destination near the
vehicle's position.
You can designate
desired categories
previously set using
the filter setting on
your device.

Note: The available Location Based
Services may differ because the ser­vices depend on the content provided
by Aha.

Example Of Use (Location
Based Services)

Proceed as follows:

1.

Select the desired station from the
Nearby tab on the main menu. The
destination name or address playback
starts in the order of the destination
name list.

12000000003003

2.

When the icon is selected, the
currently displayed destination
is displayed on the navigation system
(vehicles with navigation system).

3.

When the icon is selected, a
phone call is placed to the currently
displayed destination.

4.

Select the icon to display the
content list. Selection of other
destinations from the list can be made.

12000000004004

Shout

Some social stations, such as
Facebook or Caraoke, support the
ability to record and share voice
messages using the “Shout” function.

1.

Select the
countdown (3, 2, 1, 0). Recording starts
when the countdown reaches zero.

2.

Records voice.

icon and start the

3.

Select Save and store/post the

recording.

Note:

Recordable time varies depending

on the station (max. 30 seconds).

Recording stops automatically
when the recordable time has elapsed.
You can then post or delete the
recording.

How To Use Stitcher
Radio — If Equipped

What Is Stitcher Radio

Stitcher radio is an application which
can be used to listen to Internet radio or
stream podcasts. Recommended
content is automatically selected by
registering content which you put into
your favorites or by pressing the Like or
Dislike button.

For details on Stitcher Radio, refer to
“http://stitcher.com/”.

(*) Stitcher, the Stitcher logo, and the
Stitcher trade dress are trademarks or
registered trademarks of Stitcher, Inc.,
used with permission.

Note: To operate Stitcher Radio from
your Bluetooth device, perform the
following in advance:

Install the Stitcher Radio application

to your device;

Create a Stitcher Radio account for

your device;

Log onto Stitcher Radio using your

device.

Playback

Select the icon on the home screen
to display the Entertainment screen.

When Stitcher is selected, the following
icons are indicated in the bottom part
of the center display.

Icon Function

Displays the entertainment
menu. Use to switch to a
different audio source.

Displays the main menu. Use to
switch to other stations.

Dislike

Evaluates the current content as
“Dislike”.

Like

Evaluates the current content as
“Like”.

FIAT Connect 7.0

53

Icon Function

Adds the current station to your
favorites or deletes the current
station from your favorites.

Reverses for 30 seconds.

Plays the station. Select it again
to pause playback.

Goes to the next station.

Displays sound settings to adjust
audio quality level (refer to
“Volume/Display/Sound
Controls” paragraph).

Station List

Proceed as follows:

1.

Select the icon to display the

station list.

2.

Favorite (1) station name: select to

display the program registered to your

FIAT Connect 7.0

favorites.

3.

Category (2) name: a recommended
category selected from your favorites by
Stitcher is displayed.

Select it to display the category
program.

12000000005005

Select the program name to play it.

Add to your favorites

If the current program has not been
registered to your favorites, it can
be registered to your favorites.

Proceed as follows:

1.

Select the
favorite station of which the registration
can be added.

2.

Select the station name which you
want to register.

3.

Select OK to add the program to the
selected favorites station.

icon to display the

Note:

Multiple favorites stations can be

selected and registered.

Favorites stations registered by
oneself as well those set by default are
displayed.

Delete from your favorites

If the current program has already been
registered to your favorites, the
program can be deleted from your
favorites.

Proceed as follows:

1.

Select the icon.

2.

The program is automatically deleted

from the favorites stations.

54

TROUBLESHOOTING

Bluetooth Hands-Free Customer Service

If you have any problems with Bluetooth, contact an authorized dealer.

Bluetooth Device Pairing (Connection Problems)

Note: For more information and device compatibility, please refer to www.FiatConnect.com

Symptom Cause Solution Method

First make sure the device is compatible
with the Bluetooth unit, and then check

Unable To Perform Pairing. —

Pairing Cannot Be Performed Again.

Unable To Perform Pairing.

Does Not Connect Automatically When
Starting The Engine.

Automatically Connects, But Then
Disconnects Suddenly.

The pairing information paired to the
Bluetooth unit or device is not recognized
correctly.

The Bluetooth function and the Find Mode/
Visible setting (*) on the device may turn off
automatically after a period of time has
elapsed depending on the device.

whether the Bluetooth function and the Find
Mode/Visible setting (*) on the device are
turned on. If pairing is still not possible after
this, contact a authorized dealer.

Perform pairing using the following
procedure:

Clear “124 Spider” stored in the device

Perform pairing again

Check whether the Bluetooth function and
the Find Mode/Visible setting (*) on the device
are turned on and pairing or reconnect.

FIAT Connect 7.0

55

Symptom Cause Solution Method

The device is in a location in which radio

Disconnects Intermittently.

Does Not Connect Automatically When
Starting The Engine.

wave interference can occur easily, such as
in a bag or in a rear pocket of a pair of
pants.

The pairing information is updated when the
device OS is updated.

Move the device to a location in which radio
wave interference is less likely to occur.

Perform pairing again.

(*) Setting which detects the existence of a device external to the Bluetooth unit

Note:

When the OS of the device is updated, the pairing information may be deleted. If this happens, reprogram the pairing

information to the Bluetooth unit.

If you pair your phone which has already been paired to your vehicle more than once in the past, you need to delete
“124 Spider” on your mobile device. Then, execute the Bluetooth search on your mobile device once again, and pair to a
newly detected “124 Spider”.

Before you pair your device, make sure that Bluetooth is “ON”, both on your phone and on the vehicle.

Voice Recognition Related Problems

Symptom Cause Solution Method

56

FIAT Connect 7.0

Poor Voice Recognition

False Recognition Of Numbers

Excessive, slow speech

Excessive, forceful speech (shouting)

Speaking before the beep sound has ended

Loud noise (speaking or noise from outside/

inside vehicle)

Airflow from A/C is blowing against the

microphone

Speaking in off-standard expressions (dialect)

Regarding the causes indicated on the
left, be careful with how you speak. In
addition, when numbers are spoken in a
sequence, recognition ability will
improve if no stop is placed between the
numbers.

Symptom Cause Solution Method

Poor Voice Recognition There is a malfunction in the microphone.

Phone-Related Voice Recognition Is
Disabled.

Names In The Phonebook Are Not Easily
Recognized.

When Operating The Audio, A Song Name Is
Not Recognized.

You Want To Skip Guidance. —

There is a problem with the connection between
the Bluetooth unit and the device.

The Bluetooth system is under a condition in
which recognition is difficult.

Song names cannot be recognized by voice. —

A poor connection or malfunction with
the microphone may have occurred.
Contact an authorized dealer.

If there is any malfunction after
checking the pairing situation, check
for device pairing or connection
problems.

By carrying out the following measures,
the rate of recognition will improve.

Clear memory from the phonebook

which is not used very often.

Avoid shortened names, use full
names (recognition improves the longer
the name is. By not using names such
as “Mom”, “Dad”, recognition will
improve).

Guidance can be skipped by quickly
pressing and releasing the Talk button.

FIAT Connect 7.0

57

Regarding Problems With Calls

Symptoms Cause Solution Method

When starting a call, vehicle noise from the
other party can be heard.

The other party cannot be heard or the
speaker's voice is quiet.

For about three seconds after starting a call,
the Bluetooth unit's Noise Suppression
function requires time to adapt to the call
environment.

The volume is set at zero or low. Increase the volume.

This does not indicate a problem with the
device.

Other Problems

Symptoms Cause Solution Method

The indication for the remaining battery is
different between the vehicle and the device.

When a call is made from the vehicle, the
telephone number is updated in the
incoming/outgoing call record but the name
does not appear.

The cell phone does not synchronize with
the vehicle regarding the incoming/outgoing
call record.

It takes a long time to complete the function

FIAT Connect 7.0

for changing the language.

The indication method is different between
the vehicle and the device.

The number has not been registered into the
phonebook.

Some types of cell phones do not
synchronize automatically.

A maximum of 60 seconds is required. —

—

If the number has been registered into the
phonebook, the incoming/outgoing call
record is updated by the name in the
phonebook when the engine is restarted.

Operate the cell phone for synchronization.

58

NAVIGATION

Before Using The
Navigation System

To use the navigation system, the SD
card containing the map information
needs to be inserted in the SD card
slot.

When inserting the SD card, never
move the slider on the side of the SD
card to the LOCK position. If the slider
is set to LOCK, the SD card cannot
be read and the navigation system will
not operate.

This SD card is valid for use in only one
vehicle. Never use it in another vehicle.
If the SD card is used first in one vehicle
and then in another, the navigation
system for either one of the vehicles
may become inoperable.

12000000001001

Navigation Menu

You can reach all parts of the navigation
system from the Navigation menu.

Select and open the navigation menu.

IL001

You have the following options:

: Opens and closes the UMP
(menu bar). The UMP (menu bar) is
displayed on the lower part of the
screen.

:

Adds a destination. Select your
destination by entering an address or
selecting a POI (point of interest), a
location on the map or one of your
Favorite destinations. You can also look
up your recent destinations from the
Smart History by entering the coordinates.
If an Internet connection is available, Local
Search can be of further help to find your
destination.

:

Displays the screen where traffic
information and the GPS reception
conditions can be set and verified.

: Cancels waypoint/route.

:

Finds Places nearby You can
search for points of interest (POI) near
the vehicle position.

:

Displays the route parameters and
the route in its full length on the map. You
can also perform route-related actions
such as editing or cancelling your route,
picking route alternatives, avoiding parts of
the route, simulating navigation or adding
the destination to your Favorites.

: Changes View mode.
The map view mode can be changed
(2D north up/2D heading up/3D).

: Switches to the Settings screen

where you change navigation settings.

Note: Some functions are not available
depending on some countries and
regions.

FIAT Connect 7.0

59

Buttons And Other Controls On The Screen

Using Keyboards

You only need to enter letters or numbers when you cannot avoid it. You can type with your fingertips on the full-screen
keyboards and you can switch between various keyboard layouts, for example English, Greek or numerical.

Task Instruction

Correcting Your Entry On The Keyboard

Entering A Space, For Example Between A First Name And A Family
Name Or In Multi-Word Street Names

Entering Upper And Lower Case Letters

Finalizing The Keyboard Entry

Cancelling The Keyboard Entry (Returning To The Previous Screen)

FIAT Connect 7.0

Select
button to delete several characters or the entire input string

Select

When entering a text, the first character appears in upper case while

the rest of the text is in lower case. Select
letter or select twice to turn on Caps Lock. Select again and lower
case letters return.

Select The Check Mark

Accepting the suggested search result.

Saving your input. Select .

Opening the list of search results.

Select

to remove the unneeded character(s). Select and hold the

(the button at the bottom center of the screen)

to enter an upper case

.

60

Press And Hold

You usually need to select the screen only once, however, some useful features can be accessed with combined touch screen
selecting.

Those are as follows:

Action Button(s) Detail

Touching the button on the map screen
once changes the scale in one step.
Continuously touching the button changes
the scale sequentially.

Touching the button on the map screen
once changes the point of view in one step.
Continuously touching the button changes

Continue pressing the button

the point of view sequentially.

Touching the button on the map screen
once rotates the map. Continuously
touching the button rotates the map
sequentially.

Touching the button on the keyboard screen
once erases one character. Continuously
touching the button erases several
characters rapidly.

FIAT Connect 7.0

61

62

Map Screen

Navigation On The Map

The data fields are different when you
are navigating an active route and when
you have no specified destination (the
burgundy line is not displayed).

GUID-230001-high.tif

FIAT Connect 7.0

Field Description

Speed
Limiter
Symbol

Distance
Traveled

Shows the speed limit of
the current road if the map
contains it.

Shows the distance you
need to travel on the route
before reaching your final
destination. Shows the
estimated arrival time at
the final destination of the
route. If the navigation
system is capable of
receiving live traffic
information, the calculation
takes into account traffic
delays affecting your
route. This estimation can
be inaccurate at times.

Note: Some functions are not available
depending on some countries and
regions.

Position Markers

Selected Map Location (Cursor)
And Selected Map Object

You can mark a map location in the
following ways:

1.

Select the map during route

guidance.

2.

Select the map when asked so that
the destination can be confirmed after
the search is completed.

3.

Select the destination from the map
(see “Selecting A Map Location As
The Destination”).

When a map location is selected, the
Cursor appears at the selected point on
the map. A symbol

with a
combined crosshair and red circle is
displayed for easy visibility of any map
scale size.

The location of the Cursor can be used
as the destination of the route.

You can search for a POI (point of
interest), or you can save it as one of
your Favorites destinations.

You can also select some of the objects
on the map. If you select the map at
the icon of a POI (point of interest) or a
traffic event, the object will be selected.
You can then get information about
this object or use it as a route point.

Note: Some functions are not available
depending on some countries and
regions.

Objects On The Map

Streets And Roads

The navigation system shows the roads
in different widths and colors so that
they can be easily identified. A
expressway will be thicker and a
different color than a small street.

Turn Preview And Next Street

When navigating a route, the top
section of the Map screen shows
information about the next maneuver,
street or town.

There is an area at the top left part of
screen which indicates the next
operation.

Displays both the event type (such as
turning, detouring, exiting
expressways), and the distance from
the current position.

When the next event approaches, the
second event is displayed using a small
icon. If there is no second event, only
the next event is displayed.

GUID-230002-high.tif

Icon Description

Turn Left

Turn Right

Turn Back

Bear Right

Turn Sharp Left

Keep Left

Continue Straight In The
Intersection

Go Left/Right On The
Roundabout, 3rd Exit (Next
Maneuver)

Enter Expressway

Exit Expressway

Board Ferry

Leave Ferry

Lane Information and Signposts

When navigating on multilane roads, it
is important to take the appropriate lane
in order to follow the recommended
route.

If lane information is available in the
map data, the navigation system
displays the lanes and their directions
using small arrows at the bottom of the
map.

Highlighted arrows represent the lanes
and direction you need to take.

Lane guidance is provided constantly if
there is map information. Signposts
are displayed at the top of the map.

The color and style of the signposts are
similar to the real ones you see above
road or by the roadside.

They show the available destinations
and the number of the road the lane
leads to.

FIAT Connect 7.0

Most of these icons are very intuitive.
The same symbols are used in both
fields:

Approaching A Waypoint

Approaching The Destination

GUID-230007-high.tif

63

When navigating a route, only the
signpost that points to the lane(s) to be
taken is displayed in bright colors; all
others are darker. All signposts and lane
guidance arrows are displayed in vivid
colors while driving (when there is
no recommended route).

If you want to hide the currently
displayed signposts, touch anywhere
and the normal Map screen returns until
new signpost information is received.

GUID-230008-high.tif

Junction View

FIAT Connect 7.0

If you are approaching a highway exit or
a complex intersection and the needed
information exists, the map is replaced
with a 3D view of the junction.

The optimum driving lane is indicated
by an arrow, and road signs are
displayed as additional information at
the top of the screen.

GUID-230008-high.tif

Highway Exit Services

You may need to stop at a gas station
or a restaurant during your journey. This
feature displays a new button on the
map when you are driving on highways.

Select this Open button to open a
panel with the details of the next few
exits or service stations.

GUID-230009-high.tif

Applicable only when the setting is
“Only When Menu Is Open”.

GUID-230010-high.tif

Select any of them to display the exit
area on the map. You can now easily
add this exit as a waypoint to your route
if needed.

There are two types of settings for
displaying the next expressway exit:
one which constantly displays the next
expressway exit while travelling on an
expressway, or the other which displays
the next expressway exit only when
the menu panel is open.

You can change the settings in Visual
Guidance settings.

64

Elements Of The Active Route

The navigation system shows the route in the following way:

Symbol Name Description

If there is a road close by, a blue-colored
arrow symbol moves to the road which is

Current Car Position Marker

Waypoint (Intermediate Destination)

Destination (End Point) The final destination of the route.

the closest. The red mark present around a
blue-colored arrow symbol indicates the
correct GPS information. It may be indicated
away from the road because there is no
existing road information.

An intermediate destination of the route
before reaching the final destination.

Route Color

Streets And Roads That Are Excluded From
The Navigation

Streets And Roads That Are Affected By
Traffic Events

Note: Some functions are not available depending on some countries and regions.

The route always stands out with its color on
the map, both in daytime and in nighttime
mode.

You can choose whether you want to use or
avoid certain road types (see “Route
Settings”). However, when the navigation
system cannot avoid such roads, the route
will include them and it will show them in a
color that is different from the route color.

Road segments may be affected by traffic
events received. These streets and roads are
displayed in an alternate color, and small
symbols displayed along the route show the
type of traffic event

FIAT Connect 7.0

65

Manipulating The Map

By touching and dragging any part of
the map screen, it can be moved to
a location close to the currently
displayed map.

Action Button(s) Description

Map Movement Using Touch And Drag No Button

Zooming In And Out

In addition, the map operation button is
displayed, and by touching each of
the buttons, you can zoom in and out
of maps, change the map perspective
and select a destination.

FIAT Connect 7.0

Tilting Up And Down

GUID-230016-high.tif

You can move the map in any direction:
select and hold the map, and move your
finger towards the direction you want to
move the map.

Changes how much of the map is displayed
on the screen. The navigation system uses
high-quality vector maps that let you
examine the map at various zoom levels,
always with optimized content. Map scaling
has a limit in 3D map view mode. If you
zoom out further, the map switches to 2D
view mode. Select the button once to
modify the view in large steps, or select and
hold the button to modify it continuously and
smoothly.

Changes the vertical view angle of the map
in 3D mode. Select the button once to
modify the view in large steps, or select and
hold the button to modify it continuously and
smoothly.

66

Action Button(s) Description

Changes the horizontal view angle of the

Rotating Left And Right

Compass

Open/Close

Select Destination

Return To Normal Navigation

2D Or 3D View

map. Select the button once to modify the
view in large steps, or select and hold the
button to modify it continuously and
smoothly.

The direction of the compass shows North.
Select the button to switch to North-up view,
and then select again to rotate the map in
the previous direction.

The UMP (menu bar) is displayed on the
lower part of the screen. Hides the displayed
UMP if the UMP has been displayed.

Select this button to select the Cursor as a
new destination. The route is automatically
calculated.

Select this button to move the map back to
follow the current GPS position. Automatic
map rotation is also re-enabled. The map
manipulation buttons disappear and
navigation continues.

When this button is selected, the map view
mode can be changed:

The map is displayed so that north is up

regardless of the direction of travel.

The map is rotated so that the direction of

travel is displayed in the upward direction.

Displays things such as actual
construction sites three dimensionally on the
map.

FIAT Connect 7.0

Zoom-In/Zoom- Out Mode

You can zoom-in/zoom-out of maps.

67

Action Button(s) Description

Rotate Mode

Perspective Angle Mode

Check The Details Of The Current
Position (Where Am I?)

This screen contains information about
the current position (or about the last
known position if GPS reception is not
available).

FIAT Connect 7.0

GUID-230017-high.tif

You can access this screen from the
map in one of the following ways:

1.

Select

MAP screen.

2.

Select the Where Am I? screen.

after selecting on the

On-Road Navigation

You can set up your route in different
ways.

If you need a route for immediate
navigation, you can select the
destination and start navigating to it
right away (normal navigation).

You can plan routes with multiple
destinations. Select the first destination.
Then select a second destination and
add it to your route to create a
multi-point route.

You can add as many destinations to
your route as you like.

Rotates maps.

You can change the angle of perspective on
a map.

Selecting The
Destination Of A Route

The navigation system offers you
several ways of choosing your
destination:

Enter a full address or a part of an

address.

Select a POI (point of interest) from a

database as your destination.

Search the destination from the map.

Use a previously saved Favorite

destination.

Select a location from the History of

previously used destinations.

Enter the coordinates of the

destination.

Note: There are other convenient func­tions.

68

Entering An Address Or
A Part Of An Address

If you know at least a part of the
address, it is the quickest way to select
the destination of the route.

Using the same screen, you can find an
address by entering:

Destination address

The center of a town

An intersection

The midpoint of a street

Note: If an address or part of a facility
name is input, a search candidate list
including the input characters is dis­played. The greater the number of char­acters input the more the list is refined.

Entering An Address

To enter an address as the destination,
do as follows:

1. Select
screen.

2. Select Find Address.

3. By default, the navigation system
proposes the country and town where
you are. If needed, select Country, enter
the first few letters of the country name
on the keyboard, and select one
country from the list of results.

after selecting on the MAP

GUID-310001-high.tif

4. If needed, select a new town:

A Select Town.

B Start entering the name of the town

on the keyboard.

C Find the town you need:

D The most likely town name is always

shown in the input field. To accept
it, select

E If the desired name does not show

up, the names that match the string
appear in a list after entering a
couple of characters (to open the list
of results before it appears
automatically, select
town from the list.

.

). Select the

5. Enter the street name:

A Select <street name>

B Start entering the street name on

the keyboard.

C Find the street you need:

D The most likely street name is

always shown in the input field. To
accept it, select

.

IL002

FIAT Connect 7.0

69

E If the desired name does not show

up, the names that match the string
appear in a list after entering a
couple of characters (to open the list
of results before it appears

automatically, select
street from the list.

FIAT Connect 7.0

). Select the

IL003

6. Enter the house number:

A Select House Number.

B Enter the house number on the

keyboard. (To enter letters, select
QWE).

C Select to finish entering the

address. (If the entered house
number cannot be found, the
midpoint of the street is selected as
the destination).

GUID-310006-high.tif

7. The selected location is shown on
the map. The system transitions to the
next screen by selecting, or it returns
to the previous screen by selecting
NavigateTooritreturnstotheprevious

screen by selecting the button

.By
touching the location displayed on
the screen, you can change the
destination to anywhere on the map.

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

GUID-310007-high.tif

8.

Navigation Start if is selected, or after

ten seconds of no user interaction. By
touching the location displayed on the
screen, you can verify the route.
Additionally, the route can be revised by
selecting other options.

70

GUID-310008-high.tif

Entering The Midpoint Of A
Street As The Destination

You can navigate to the midpoint of a
street if the house number is not
available:

1. Select
screen.

2. Select Find Address.

3. If necessary, modify the country and
town as described earlier (see “Entering
An Address”).

4. Enter the street name:

A Select <street name>

B Start entering the street name on

the keyboard.

C Find the street you need:

D The most likely street name is

always shown in the input field. To
accept it, select

E If the desired name does not show

up, the names that match the string
appear in a list after entering a
couple of characters (to open the list
of results before it appears

automatically, select
street from the list.

after selecting on the MAP

.

). Select the

IL003

5. Instead of entering the house
number, select “Select Street”. The
midpoint of the street is selected as the
destination.

GUID-310001A-high.tif

6. The selected location is shown on
the map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by
selecting the button
the location displayed on the screen,
you can change the destination to
anywhere on the map.

. By touching

GUID-310007-high.tif

FIAT Connect 7.0

71

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites

7. Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

GUID-310008-high.tif

FIAT Connect 7.0

Selecting An Intersection As
The Destination

To enter an address as the destination,
do as follows:

1. Select
screen.

2. Select Find Address.

3. If necessary, modify the country and
town as described earlier.

4. Enter the street name:

A Select <street name>

B Start entering the street name on

the keyboard.

C Find the street you need:

D The most likely street name is

always shown in the input field. To
accept it, select

E If the desired name does not show

up, the names that match the string
appear in a list after entering a
couple of characters (to open the list
of results before it appears

automatically, select
street from the list.

after selecting on the MAP

.

). Select the

IL003

5. Enter the intersecting street name:

A Select <Intersecting Street>

B If only a few intersecting streets

exist, their list appears immediately.

72

C In case of a longer street, the

keyboard screen appears. Start
entering the name of the intersecting
street on the keyboard. As soon as
the street names that match the
entered string can be shown on one
screen, their list appears
automatically. Select the street from
the list.

6. The selected location is shown on
the map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by
selecting the button. By touching the
location displayed on the screen, you
can change the destination to anywhere
on the map.

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

7. Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location

IL004

displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

GUID-340001-high.tif

GUID-310008-high.tif

Selecting A Town Center As The
Destination

The town center is not the geometric
center of the town but an arbitrary point
on the map the creators have chosen.
In towns and villages, it is usually the
most important intersection; in larger
cities, it is one of the important
intersections.

1. Select
screen.

2. Select Find Address.

3. If necessary, modify the country and
town as described earlier (see “Entering
An Address”).

4. Instead of entering the street name,
select “Select Town Center”. This way
the center of the displayed town
becomes the destination of the route.

after selecting on the MAP

FIAT Connect 7.0

73

GUID-310001B-high.tif

5. The selected location is shown on
the map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by

selecting the
the location displayed on the screen,
you can change the destination to
anywhere on the map.

button. By touching

FIAT Connect 7.0

GUID-310007-high.tif

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

6. Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

GUID-310008-high.tif

Selecting The
Destination From The
POI (Point Of Interest)

You can select your destination from
the POI (point of interest) included with
the navigation system.

Using the same screen, you can find a
POI (point of interest) in different ways:

You can quickly find a nearby POI
(point of interest) by its name using the
Quick search feature;

You can find frequently searched
types of POI (point of interest) with only
a few screen selects using the Preset
search feature;

You can search for a POI (point of
interest) by its category;

You can search for a POI (point of
interest) by its name.

Quick Search For A POI (Point
Of Interest)

If the name for a POI (point of interest)
is input, a search candidate list is
displayed.

One destination among the candidates
can be selected.

Along the recommended route if it
exists

Around your current location if there
is no destination given.

Start the Quick search function:

1.

Select

screen.

2.

Select Find Places.

after selecting on the MAP

74

3.

Select Filter by Name.

GUID-310011-high.tif

GUID-310012-high.tif

GUID-310013-high.tif

5.

After entering a few letters, select

to open the list of POI (point of
interest) with names containing the
entered character sequence.

the location displayed on the screen,
you can change the destination to
anywhere on the map.

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

7.

Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

4.

Using the keyboard, enter the name

of the POI (point of interest).

Note: If an address or part of a facility
name is input, a search candidate list
including the input characters is dis­played. The greater the number of char­acters input the more the list is refined.

GUID-310014-high.tif

6.

The selected location is shown on the
map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by
selecting

the button. By touching

FIAT Connect 7.0

GUID-310008-high.tif

75

Searching For Help Nearby

The Preset search feature lets you
quickly find the most frequently
selected types of Places.

1.

Select after selecting
screen, or select Find Places after
selecting

2.

In the Navigation menu, select Help
Nearby.

3.

Preset search categories appear, all
for searching around the current

FIAT Connect 7.0

position (or around the last known
position if the current position is not
available).

4.

Select any of the quick search
buttons to get an instant list of Places.

as an alternative method.

on the MAP

GUID-310015-high.tif

GUID-310014-high.tif

5.

The selected location is shown on the
map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by

selecting the

button. By touching
the location displayed on the screen,
you can change the destination to
anywhere on the map.

GUID-310007-high.tif

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

6.

Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

GUID-310008-high.tif

Searching For A POI (Point Of
Interest) By Category

You can search for Places of Interest by
their categories and subcategories.

A Select after selecting on the MAP

screen.

B Select Find Places.

76

C Select Area.

D Select the area around which the

Place should be searched for:

Select Find Places to search around
the current position or if it is not
available, around the last know position
(the result list will be ordered by the
distance from this position).

Select to search along the active
route, and not around a given point.
This is useful when you search for
a later stopover that results in a minimal
detour only, such as searching for
upcoming gas stations or restaurants
(the result list will be ordered by the
length of the necessary detour).

Select to search for a place around
the destination of the active route
(the result list will be ordered by the
distance from the destination).

Select to search for a place within a
selected town (the result list will be
ordered by the distance from the center
of the selected town).

GUID-310200-high.tif

E (Optional) If you have selected In a

Town, select the town to search in.

GUID-310201-high.tif

F Select one of the main Place

categories (e.g. Accommodation) or
select “Search In All Categories”
to list all Places around the selected
location or along the route.

GUID-310202-high.tif

G Select one of the Place

subcategories (e.g. Hotel or Motel)
or select “Search In All Categories”
to list all Places in the selected main
category around the selected
location or along the route.

FIAT Connect 7.0

GUID-310203-high.tif

77

H Sometimes the list of brands in the

selected Place subcategory
appears. Select one brand or select
“Search In All Categories” to list all
Places in the selected subcategory
around the selected location or
along the route.

J The selected location is shown on

the map. The system transitions
to the next screen by selecting
Navigate To, or it returns to
the previous screen by selecting the

button. By touching the location
displayed on the screen, you can
change the destination to anywhere
on the map.

K Navigation starts if Start is selected,

or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can
verify the route. Additionally, the
route can be revised by selecting
other options.

78

I Select Search.

FIAT Connect 7.0

GUID-310014-high.tif

GUID-310012A-high.tif

GUID-310007-high.tif

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

GUID-310008-high.tif

Searching For A POI (Point Of
Interest) By Name

You can search for Places of Interest by
their names. You can search around
different locations or along your route in
the whole Place database or in one
Place category or subcategory only.

1.

Select

after selecting on the MAP

screen.

2.

Select Find Places.

3.

Select Area.

4.

Select the area around which the

Place should be searched for:

Select Around Here to search around
the current position or if it is not
available, around the last know position
(the result list will be ordered by the
distance from this position).

Select Along Route to search along
the active route, and not around a given
point. This is useful when you search
for a later stopover that results in a
minimal detour only, such as searching
for upcoming gas stations or
restaurants (the result list will be
ordered by the length of the necessary
detour).

Select Around Destination to search
for a place around the destination of the
active route (the result list will be
ordered by the distance from the
destination).

Select In a Town to search for a
place within a selected town (the result
list will be ordered by the distance
from the center of the selected town).

GUID-310200-high.tif

5.

(Optional) If you have selected In a

Town, select the town to search in.

GUID-310201A-high.tif

6.

Select one of the main Place
categories (e.g. Accommodation) to
search in or select Filter by Name
to search among all Places.

GUID-310202-high.tif

7.

Select one of the Place
subcategories (e.g. Hotel or Motel) to
search in or select Filter by Name to
search in the selected Place category.

GUID-310203-high.tif

8.

Select Filter by Name if you have
not done it before.

FIAT Connect 7.0

79

GUID-310204-high.tif

9.

Using the keyboard, start entering the

name of the Place.

GUID-310013-high.tif

FIAT Connect 7.0

10.

After entering a few letters, select

to open the list of Places with
names containing the entered character
sequence.

GUID-310016-high.tif GUID-310008-high.tif

11.

The selected location is shown on
the map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by

selecting the

button. By touching
the location displayed on the screen,
you can change the destination to
anywhere on the map.

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

12.

Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

Searching For A Place
Using Local Search
(Only Some Countries
And Region)

If you have an Internet connection, you
can search for places using the Local
Search service.

1.

Select after selecting on the MAP

screen.

2.

Select Local Search.

3.

Using the keyboard, start entering the
text to search for. This text can be a
type of Place (like “Hotel”), a type of
goods you are looking for (like “Pizza”
or “Vacuum cleaner”) or even a street
name followed by the town. (Optional)
The local search is carried out around
your current location. To search around
a different location, enter the name of
the town after the word you are looking
for. You can enter up to 25 characters.

80

GUID-310025-high.tif

4.

After entering the text, select the

check mark to open the list of results:

GUID-310025-high.tif

5.

The selected location is shown on the
map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by

selecting the

button. By touching
the location displayed on the screen,
you can change the destination to
anywhere on the map.

GUID-310007-high.tif GUID-310008-high.tif

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

6.

Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

Selecting A Map Location As
The Destination

1.

Touch anywhere on the map.

GUID-310027-high.tif

2.

Drag the cursor and release it at the

desired point.

FIAT Connect 7.0

81

GUID-310028-high.tif

3.

Select .

4.

The selected location is shown on the
map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by

selecting the

button. By touching
the location displayed on the screen,
you can change the destination to
anywhere on the map.

FIAT Connect 7.0

GUID-310007-high.tif

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

5.

Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

GUID-310008-high.tif

Selecting The Destination From
Your Favorites

1.

Select after selecting on the MAP
screen.

2.

In the Navigation menu, select
Favorites. When Favorites is selected,
the screen transfers to the Favorites
screen. Select your registered favorite.

GUID-310029-high.tif

3.

The selected location is shown on the
map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by
selecting the button. By touching the
location displayed on the screen, you
can change the destination to anywhere
on the map.

GUID-310007-high.tif

82

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

4.

Navigation starts if “Start” is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

GUID-310008-high.tif

Entering The Coordinates Of
The Destination

You can also select a destination by
entering its coordinates as follows:

1.

Select after selecting on the MAP

screen.

2.

In the Navigation menu, select

Coordinate.

GUID-310029B-high.tif

3.

Input the map coordinates value of

Latitude and Longitude.

GUID-310032-high.tif

4.

When finished, select .

GUID-310032A-high.tif

GUID-310032B-high.tif

5.

Select “Select”.

6.

The selected location is shown on the
map. The system transitions to the
next screen by selecting Navigate To, or
it returns to the previous screen by

selecting the

button. By touching
the location displayed on the screen,
you can change the destination to
anywhere on the map.

FIAT Connect 7.0

83

GUID-310007-high.tif GUID-310008-high.tif

84

Note:

Places Nearby: you can search for
POI (point of interest) around the
selected location.

Add to Favorites: the selected
location can be registered to Favorites.

7.

Navigation starts if Start is selected,
or after ten seconds of no user
interaction. By touching the location
displayed on the screen, you can verify
the route. Additionally, the route can
be revised by selecting other options.

FIAT Connect 7.0

Check Route Parameters And
Accessing Route Related Func­tions

You can check different parameters of
the route recommended by the
navigation system.

1.

Select after selecting on the MAP

screen.

2.

The following pieces of information

are displayed:

The name and/or address of the

destination.

The total time of the route.

The total length of the route.

The route planning method (e.g.

Fast).

IL006

3.

You have the following options on this
screen (for detailed instructions on
how to use them, see the next chapter):

Select Edit Route to edit the

route.

Select to display the entire route on

the map.

GUID-OVERVIEW-high.tif

Editing the list of destinations (Edit
Route)

You can edit the route by modifying the
list of destinations.

1.

Select after selecting on the MAP

screen.

2.

Select Edit Route.

Select Avoid to bypass a part of

the route.

Select Cancel Route to delete the

active route.

Note: There are other convenient func-

tions.

Modifying The Route

When navigation is already started,
there are several ways to modify the
active route. The following sections
show some of those options.

Selecting a new destination when
already having a route: New Route,
Waypoint or Final Destination

If you already have a recommended
route and you select a new destination
as described in the above sections,
the application will ask you whether to
start a new route, add a new waypoint
(intermediate destination) to the route or
append the newly selected destination
at the end of the current route.

GUID-330001-high.tif

Select New Route to plan a new
route to the newly selected location.
The previous destination and
waypoint(s) are deleted.

Select Waypoint to add the newly
selected location as an intermediate
destination to your route. The other
destinations of the route remain intact.
Note: the new waypoint is placed
among destinations to keep the route
optimal. To decide where a waypoint to
appear, use the Edit Route feature.

Select Final Destination to append
the newly selected destination at the
end of the route. The other destinations
of the route remain intact. The previous
final destination is now the last
waypoint.

GUID-330002-high.tif

3.

Edit the destination or waypoint.

+: add the new destination or waypoint.

: start the route plan in
consideration of the selected
destination or waypoint.

4.

Select the destination or waypoint to

display the menu.

: close the menu.

: delete the selected destination or

waypoint from the list.

: move the selected destination or

waypoint forward one by one.

FIAT Connect 7.0

85

: move the selected destination or

waypoint rearward one by one.

Checking Route Alternatives
When Planning The Route

You can select from different route
alternatives or change the route
planning method after you have
selected a new destination.

1.

Select after selecting on the MAP

screen.

2.

Select Route Alternative.

FIAT Connect 7.0

GUID-330003-high.tif

GUID-330005-high.tif

3.

The four route alternatives are
displayed next to the selected route
planning method. Select one to view it
on the map.

GUID-310033A-high.tif

4.

Details of a route can be checked by
selecting Browse Map.

GUID-330007-high.tif

5.

Select one of the route alternatives or

select

to return to the previous
screen. The navigation system
recalculates the route. The orange line
now shows the new recommended
route.

Changing The Road Types Used
In Route Planning

To recalculate the active route with
different road type preferences, do as
follows.

These changes can also be made in
Settings.

1.

Select after selecting on the MAP

screen.

2.

Select Route Settings.

86

GUID-330008A-high.tif

3.

Select any of the listed road types to
modify the route. If needed, scroll the
list for all road types. You have the
following options (their order depends
on the selected vehicle type):

You might need to avoid
expressway if you are towing another
vehicle.

Charge roads are pay
roads where you can purchase a pass
or vignette to use the road for a longer
period of time. They can be enabled
or disabled separately from toll roads.

The navigation system
includes toll roads (pay roads where
there is a peruse charge) in the routes
by default. If you disable toll roads,
the navigation system plans the best
toll-free route.

The navigation system
includes ferries in a planned route
by default. However, a map does not
necessarily contain information about
the accessibility of temporary ferries.
You might also need to pay a fare
on ferries.

Setting in which
routes with carpool lanes can be
created or not created.

The navigation
system excludes unpaved roads by
default: unpaved roads can be in a bad
condition and usually you cannot reach
the speed limit on them.

A border crossing
may be a shorter route depending on
the route. For this function, you can
select whether or not to cross a border
when planning the route.

4.

The route has already been

recalculated. Select
Map screen.

Note: Some functions are not available
depending on some countries and
regions.

to return to the

Saving A Location As A Favorite
Destination

You can add any location to Favorites,
the list of frequently used destinations.

Planning a route to one of the Favorite
destinations is described on “Selecting
the destination from your Favorites”.

1.

Select a destination as described
before. It can be an address, a Place,
any location on the map, a previously
used destination from History, etc.

2.

A searched destination can be
registered to Favorites by selecting Add
to favorites on the verification screen
of the destination search results.

GUID-340001-high.tif

FIAT Connect 7.0

87

Editing The Details Of A Favorite
Destination

You can select a location that you have
already saved as a Favorite and edit
its details.

1.

Press the Favorites button on the

multimedia control knob.

2.

Select the Navigation tab.

3.

The list of Favorite destinations is

displayed.

GUID-340002-high.tif

The following functions can be used by

FIAT Connect 7.0

selecting Add/Edit Navigation Favorites.

Add Current Location: set the

current location to Favorites.

Add Current Destination: register the

current destination to Favorites.

Add from Contact: register an

address registered to the contacts list.

Move: switch the Favorites order.

Delete: delete the registered

Favorites.

Your home address can be

registered/changed by selecting Home.

The following functions can be used

by selecting the registered Favorites:

Replace with Current Location:

set the current location to Favorites.

Replace with Current Destination:
register the current destination to
Favorites.

Replace with Address from Contacts:
register an address registered to the
contacts list.

Move: switch the Favorites order.

Rename: edit the registered Favorites
name.

Delete: delete the selected Favorites.

Reference Guide

Smart Zone

Smart Zoom provides much more than
just a usual automatic zoom feature:

While following a route: when
approaching a turn, it will zoom in and
raise the view angle to let you easily
recognize your maneuver at the next
junction. If the next turn is at a distance,
it will zoom out and lower the view
angle to be flat so you can see the road
in front of you.

While driving without an active route:
smart Zoom will zoom in if you drive
slowly and zoom out when you drive at
high speed.

Off: turns the Smart Zoom setting off.

Route Calculation And Recalcu­lation

The navigation system calculates the
route based on your preferences:

Route planning methods:

– Fast: gives a quick route if you can

travel at or near the speed limit on
all roads.

– Short: gives a route that has the

smallest total distance of all
possible routes.

88

– Economical: this method combines

the merits of the Fast and Short
routes. The navigation system
makes a calculation for the Fast
route, but it also includes other
roads in the calculation in
consideration of fuel economy.

– Easy: results in a route with fewer

turns and no difficult maneuver.
With this option, you can make the
navigation system take, for
example, the expressway instead of
a series of smaller roads or streets.

Road type used for route plan:

–

–

–

–

–

–

–

Whenever data exists, route calculation
takes into account historical traffic
data for the given day of week and time
of day (see “Historical traffic”). If the
setting for Traffic Settings is valid,
Real-time Traffic events are taken into
account and the route is largely
modified. The navigation system

automatically recalculates the route if
you deviate from the proposed itinerary
or if a newly received Traffic event
concerns a part of the recommended
route.

Note: Some functions are not available
depending on some countries and
regions.

Road Safety Cameras And
Other Proximity Alert Points
(Only Some Countries And
Regions)

There is a special proximity warning for
road safety cameras (like speed or
red light cameras) and other proximity
alert points (like schools or railroad
crossings).

The application can war n you when you
approach road safety cameras like
speed cameras or dangerous areas like
school zones or railroad crossings.
You can set up the different alert types
individually in Warning Settings.

The following alert types are available:

Audio warning: when approaching
one of these points, a beep sound
(regular sound) can be used or the type
of warning can be announced (TTS),
and an extra alert can warn you if you
exceed the given speed limit while
approaching the point.

Always: the type of the alert point, its
distance, and the related speed limit
appear on the Map screen while you
are approaching one of these points.

For some of the alert points, the
enforced or expected speed limit is
available. For these points, the audio
alert can be different if you are below or
above the given speed limit.

Setting can be selected using Warning
Settings:

Only when speeding: the audio alert
is only played when you exceed the
given speed limit.

When approaching: the audio alert is
always played when approaching one
of these alert points. To draw your
attention, the alert may differ if
you exceed the speed limit.

Note: The warning for road safety cam­eras is disabled when you are in a
country where road safety camera
warnings are prohibited. However, you
must ensure on your own liability that
using this feature is legal in the country
where you intend to use it.

FIAT Connect 7.0

89

90

Traffic Information In Route
Planning — If Equipped

The recommended route is not always
the same between two points. Offline
historical traffic information (historical
speed information or traffic patterns)
can be taken into account in the route
calculation based on the time of day
and the day of week whenever suitable
data exists. In addition, real-time traffic
information can help you avoid current
traffic events like temporary road
closures or a traffic jam caused by an
accident. Both functions are subject to
data availability.

Select Traffic after selecting
MAP screen to display the historical
traffic information on the map.

A 2D map is displayed with road
segments colored by the density of the
traffic in the given period. The current
information is shown when you open
the screen. Modify the day of week and

FIAT Connect 7.0

the time of day to see the desired
period.

on the

GUID-410003-high.tif

Historical Traffic

If historical traffic information is available
with the map data, the navigation
system can use it when planning a
route. In normal cases, these statistics
help you avoid usual traffic jams on
the given day of week in the given hour
but in some cases, like on public
holidays that fall on normal weekdays,
they can be misleading. You can
disable this feature in Traffic Settings.

Select Traffic after selecting
the MAP screen to display the historical
traffic information on the map.

on

Traffic Message Channel (TMC)

TMC (Traffic Message Channel) can
provide your navigation system with the
real-time status of the traffic. Route
calculation can avoid road blocks
or unexpected traffic jams caused by
an accident.

Note: This feature is available only if
your hardware supports TMC.

Note: TMC is not a global service. It
may not be available in your country or
region. Ask your local dealer for cover­age details.

The navigation system may contain the
TMC receiver that is needed to receive
Traffic events.

Ask your local dealer if public Traffic data
is broadcast at your location. If so, the
navigation system automatically takes
into account the traffic events received.
You do not need to set anything in the
program.

The receiver will automatically search for
TMC data, and the decoded information
will immediately be used in route
planning. When the navigation system
receives traffic information that may
affect your route, the program will warn
you that it is recalculating the route,
and navigation will continue with a new
route that is optimal considering the
most up-to-date traffic conditions. To

fine-tune this recalculation, you can set
the minimum delay that can trigger a
route recalculation, or you can instruct
the navigation system to have you
confirm the new recommended route
before it takes effect. You can do these in
Traffic Settings.

A special icon ( ) is displayed on the
Map screen to show you whether
traffic events are received. The icon
shows the status of the traffic receiver
when there are no traffic events on your
route, otherwise it shows the type of
the next traffic event on your route.

Road segments affected by traffic
events are displayed with an alternate
color on the map, and small symbols
above the road show the nature of the
event:

1.

Select ( ) to open the Traffic

Summary screen:

2.

Select to see the list of all events:

GUID-ICON044-high.tif

3.

Select the category.

GUID-410301-high.tif

4.

Select the traffic event.

GUID-410302-high.tif

5.

Select to avoid or ignore the traffic

event.

GUID-410303-high.tif

Online Traffic Information

Unlike historical traffic information,
online traffic can provide you with the
real time status of the traffic. Route
calculation can avoid road blocks
or unexpected traffic jams caused by
an accident.

Note: This feature needs an active Inter­net connection.

The application automatically takes into
account the traffic events received.
You do not need to set anything in the
program. When the navigation system
receives traffic information that may
affect your route, the program will warn
you that it is recalculating the route,
and navigation will continue with a new
route that is optimal considering the
most up-to-date traffic conditions.

FIAT Connect 7.0

91

To fine-tune this recalculation, you can
set the minimum delay that can trigger a
route recalculation, or you can instruct
the navigation system to have you
confirm the new recommended route
before it takes effect. You can do these in

3.

Select the traffic category you are
interested in, or select to see the list of
all events.

Setting Menu

You can configure the program settings,
and modify the behavior of the
navigation system. Select
selecting on the MAP screen.

Traffic Settings.

Road segments affected by traffic events
are displayed with an alternate color on
the map, and small symbols above
the road show the nature of the event:

1.

Select after selecting on the MAP

screen.

2.

Select Traffic.

4.

Now select any of the list items to

GUID-410301-high.tif

see its details, and to display the
affected road segment in its full length
on the map.

Button Descriptions

Map Settings

FIAT Connect 7.0

Guidance Settings A guidance-related setting is available during route guidance.

Warning Settings A setting related to warnings is available.

Route Settings Refer to “Changing The Road Types Used In Route Planning”.

Traffic Settings A setting for traffic information is available.

Connected Settings A setting for online service is available.

You can fine-tune the appearance of the Map screen. Adjust the map
view to your needs, show or hide 3D buildings, and manage POI
(point of interest) display settings (which POI to show on map).

after

GUID-330008-high.tif

Note: Some functions are not available depending on some countries and regions.

92

Guidance Setting

Button Descriptions

Guidance Vol. The guidance audio volume can be changed during route guidance.

Warning Settings

Button Descriptions

The following alert types are available:
Off: No display and sound

Speeding

Speed Limit

Alert Points

Speed Cameras

Visual Only: Only display
Audio and Visual: Both sound and display
If the guidance volume is set to 0, the speed limit notification is also
0 because it is part of the guidance

The speed limit warning display can be changed.
Always: Constantly displayed
When Speeding: Displays only when vehicle speed exceeds speed
limit

A setting is available which sounds a beep at alert points, and it can
be set to on or off. In addition, detailed settings concerning the
warning can be made.
Off: No display and sound
Visual Only: Only display
Audio and Visual: Both sound and display

The speed camera warning setting can be changed.
Off: No display and sound
Visual Only: Only display
Audio and Visual: Both sound and display

FIAT Connect 7.0

Note: Some functions are not available depending on some countries and regions.

93

Traffic Settings

Button Description

Use this switch to enable or disable historical traffic data and traffic

Use Historical Traffic Data

Online Traffic

Offer Detour Alternative routes are offered for detours.

Auto Accept Detour

Detour Sensitivity

patterns. This locally stored information can be very useful in normal
circumstances but for example on public holidays it may be better to
turn off in order not to take into account normal weekday traffic jams.

Use this switch to enable or disable receiving real-time traffic
information online. The rest of the buttons below are all related to this
real-time information and are available only if receiving is enabled.
You can also define whether to receive online traffic only when
connected to a Wi-Fi network.

An appropriate alternative route is determined and provided by the
navigation system in consideration of traffic conditions.

You can select how much time delay on the alternative route you are
willing to accept. The alternative route is offered based on the set
time.

Note: Some functions are not available depending on some countries and regions.

FIAT Connect 7.0

94

Route Settings

Button Description

Route Calculation Method

Expressway

Period Charge

Per-use Toll

Ferries

Carpool Lanes

Unpaved Roads

Border Crossing

The route calculation can be optimized for different situations. See
below for details.

You might need to avoid expressway if you are towing another
vehicle.

Charge roads are pay roads where you can purchase a pass or
vignette to use the road for a longer period of time. They can be
enabled or disabled separately from toll roads.

The navigation system includes toll roads (pay roads where there is a
per-use charge) in the routes by default. If you disable toll roads, the
navigation system plans the best toll-free route.

The navigation system includes ferries in a planned route by default.
However, a map does not necessarily contain information about the
accessibility of temporary ferries. You might also need to pay a fare
on ferries.

Setting in which routes with carpool lanes can be created or not
created.

The navigation system excludes unpaved roads by default: unpaved
roads can be in a bad condition and usually you cannot reach the
speed limit on them.

A border crossing may be a shorter route depending on the route.
For this function, you can select whether or not to cross a border
when planning the route.

FIAT Connect 7.0

Note: Some functions are not available depending on some countries and regions.

95

Map Settings

You can fine-tune the appearance of
the Map screen, adjust the map view to
your needs, show or suppress 3D
buildings, and manage Place visibility
settings (which Places to show on

The map is always shown on the
screen so that you can see the effect
when you change a setting. Scroll
the screen downward to display the
setting behind the lower part of the
screen.

the map).

Button Descriptions

dimensionally on the map

View Mode

the upward direction

direction of travel

Viewpoint

Automatic Zoom

FIAT Connect 7.0

Buildings

Expressway Overview

Adjust the basic zoom and tilt levels to your needs. Three levels are
available.

During route guidance in any map view mode, the function for
zooming in on approaching intersections turns on/off automatically.

Show or hide 3D town models, 3D artistic or block representation of
all town building data containing actual building sizes and positions on
the map.

When enabled, the map zooms out to show an overview of the
surrounding area if the next route event (maneuver) is far away. The
system goes back to the normal map view when you approach the
next event.

GUID-420002-high.tif

When this button is selected, the map view mode can be changed:

3D: Displays things such as actual construction sites three

2D: The map is rotated so that the direction of travel is displayed in

2D N: The map is displayed so that north is up regardless of the

96

Button Descriptions

Select which Places to show on the map while navigating. Too many
Places make the map crowded, so it is a good idea to show as few

Place Markers

as possible. You have the following possibilities:

Select the check box to show or hide the Place category.

Select the name of the Place category to open the list of its

subcategories.

Visual Guidance Settings

Button Description

Show Signposts

Show Junction View

Show Tunnel View

Whenever adequate information is available, lane information similar
to the real ones on road signs above the road is displayed at the top
of the map. You can turn this feature on or off.

If you are approaching a expressway exit or a complex intersection
and the needed information exists, the map is replaced with a 3D
view of the junction. You can turn this feature on or let the map be
displayed for the whole route.

When entering tunnels, the surface roads and buildings can cause
problems visually. This feature shows a generic picture of a tunnel
instead of the map. A top down overview of the tunnel and remaining
distance are also displayed.

Connected Settings — If Equipped

Button Descriptions

Auto Download Weather Set the weather forecast automatic download on/off.

Online Traffic Set the traffic information automatic download on/off.

FIAT Connect 7.0

97

GLOSSARY

Active Route

The currently navigated route.
Whenever a destination is set, the route
is active until you delete it or reach
your destination.

Town Center

The town center is not the geometric
center of the town but an arbitrary point
the map creators have chosen. In
towns and villages, it is usually the most
important intersection; in larger cities,
it is one of the important intersections.

Color Scheme

The navigation system has different
color schemes for daytime and
nighttime which can be selected as
desired.

One daytime scheme and one nighttime
scheme is always selected for the map
and for the menus.

FIAT Connect 7.0

The navigation system uses them when
it switches from day to night and
back.

GPS Accuracy

Several factors have impact on the
deviation between your real position
and the one given by the GPS device.

For example, signal delay in the
ionosphere or reflecting objects near
the GPS device have a different and
varying impact on how accurately the
GPS device can calculate your position.

Map

The navigation system works with
digital maps which are not simply the
computerized versions of traditional
paper maps. Similarly to paper road
maps, the 2D mode of digital maps
show you streets, roads, and elevation
by colors.

In 3D mode, you can see the altitude
differences, for example valleys and
mountains, elevated roads, and in
selected cities 3D landmarks and 3D
buildings are also displayed.

You can use digital maps interactively:
you can zoom in and out (increase
or decrease the scale), you can tilt them
up and down, and rotate them left and
right.

In GPS-supported navigation, digital
maps facilitate route planning.

North-Up Map Orientation

In North-up mode the map is rotated so
its top always faces North. This is the
orientation for example in Find on Map.

Road Safety Camera

This function is not available in some
countries and regions.

Special alert points for speed, red light
or bus lane cameras. Different data
sources are available. You can
configure the navigation system to warn
you when you approach one of these
cameras.

Detecting the location of Road Safety
Cameras is prohibited in certain
countries.

It is the sole responsibility of the driver
to check whether this feature can be
used during the trip.

The software is capable of showing and
warning for more than just cameras.
Various other types of proximity alert
points like school zones and railway
crossings are also available.

98

Route

A sequence of maneuver (for example,
turns and roundabouts) to reach the
destination. The route contains one
starting point and one or more
destinations.

Track-Up Map Orientation

In Track-up mode the map is rotated so
its top always points in the current
driving direction. This is the default
orientation in 3D map view mode.

Vehicle Marker

The current position is indicated by a
blue arrow on the map. The direction
the blue arrow is pointed indicates the
current heading.

END-USER TERMS

The data is provided for your personal,
internal use only and not for resale. It
is protected by copyright, and is
subject to the following terms and
conditions which are agreed to by you,
on the one hand, and VISTEON and
its licensors (including their licensors
and suppliers) on the other hand.

© 2017 HERE. All rights reserved.

The Data for areas of Canada includes
information taken with permission
from Canadian authorities, including: ©
Her Majesty the Queen in Right of
Canada, © Queen’s Printer for Ontario,
© Canada Post Corporation,
GeoBase®, © Department of Natural
Resources Canada.

HERE holds a non-exclusive license
from the United States Postal Service®
to publish and sell ZIP+4® information.

© United States Postal Service® 2013.
Prices are not established, controlled
or approved by the United States
Postal Service®. The following
trademarks and registrations are owned
by the USPS: United States Postal
Service, USPS, and ZIP+4.

The Data for Mexico includes certain
data from Instituto Nacional de
Estadística y Geografía.

Terms and Conditions

Personal Use Only: You agree to use
this Data together with VISTEON’s CMU
for the solely personal, noncommercial
purposes for which you were licensed,
and not for service bureau, time-sharing
or other similar purposes. Accordingly,
but subject to the restrictions set forth
in the following paragraphs, you agree
not to otherwise reproduce, copy,
modify, decompile, disassemble, create
any derivative works of, or reverse
engineer any portion of this Data, and
may not transfer or distribute it in any
form, for any purpose, except to the
extent permitted by mandatory laws.

Restrictions

Except where you have been
specifically licensed to do so by
VISTEON, and without limiting the
preceding paragraph, you may not (a)
use this Data with any products,
systems, or applications installed or
otherwise connected to or in
communication with vehicles, capable
of vehicle navigation, positioning,
dispatch, real time route guidance, fleet
management or similar applications;
or (b) with or in communication with any
positioning devices or any mobile or
wireless-connected electronic or
computer devices, including without

FIAT Connect 7.0

99
