Ferguson FT-8300 HD User Manual

User manual

FT-8300 HD

English

2

WARNING !!!

On the USB Memory Function for FT-8300 HD model, user can make recording or playing function
using by external USB devices such as USB Flash Memory Disk or external USB HDD(Hard Disk).
However, below condition should be remarked before applying.

REMEMBER:

1. To use the external USB device, the device has to be supported by USB

2.0. In case of the USB flash memory disk for recording, we suggest to
use USB2.0 by SLC type with writing speed over 9.0MB/s for stable
recording and playing.

2. Please make sure the USB device condition is set as FAT32 before using.
To make FAT32 condition, user can make format function on their
personal PC.

3. External hard drives HDD should contain their own power supply unit.

CAUSION

1. Please do not remove the external USB device from the receiver during the recording or playing
in USB mode. Unexpected action could make damaged condition for either the receiver and the
external USB device.

2. Do not touch with wet hand in any cases.

3

SAFETY INSTRUCTIONS ........... ....................... .................................................................4

SOFTWARE FOR DOWNLOADING........... ................................................................ .............4

USER MANUAL ................... ........... ............ ............ ......................................................... 4

SYMBOLS USED ON THE RECEIVER ....................................... .............................................5

GENERAL INFORMATION ................................................................................. .................6

1. Main Features ............... ....................... ............ .....................................................6

2. Unpacking....................................................... .....................................................6

3. General Operation of STB ........ ........... ............ ......................................................... 6

INSTALLATION OF STB..................... ....................... ............ .............................................7

1. Front Panel...................................................... ............ .........................................7

2. Rear Panel....................................................................................... ............ .........7

3. CI Module(CAM) and smart card ...................................... ............ .............................8

REMOTE CONTROLLE .......................................................................... ........................ .....9

Quick Installation............................................................... ............ ............ ................... 10

THE MAINMENU INFORMATION............................................. ........................................... 11

Main menu.............................................................................. ............ ............ ....... 11

1. Installation........................... ....................... ....................................................... 11

1.1 Auto Scan................. ................................... ............................................... 11

1.2 Manual Scan................................................................. ........................ ....... 11

1.3 Delete All Programs............................................................................ ........... 12

1.4 Reset System Setting ............................................................................. ....... 12

1.5 Firmware Update Via USB.................................................... ........................... 12

2. System Setting ............................. ................................... ................................... 12

2.1 Audio Setting............................................................ ................................... 12

2.2 Video Setting............................. ....................... ........................................... 12

2.3 Subtitle Setting......................... ........................ ........................................... 13

2.4 Parental Setting ........................ ............ ....................................................... 13

2.5 Time Setting......................................................................... ....................... 13

2.6 OSD Setting .. .............................................................................................. 14

2.7 PVR Setting............... ....................... ............ ............................................... 14

2.8 Other Setting......... ...................................................................................... 14

3. Program Manage .................................................................. ............ ............ ....... 14

3.1 Program Edit ........................................................................ ....................... 14

3.2 Favorite Edit .. ........................................................................... ................... 15

4. Program Guide.......................... ....................... ............ ....................................... 15

4.1 New reservation .......... ........... ............ ............ ........................................... 15

4.2 Schedule................................................................... ........................ ....... 16

5. My recordings ... ................................... ............................................................... 16

6. System Information .................................................................. ............ ............ ... 17

6.1 SW/HW Information ............... ................................................................ ....... 17

6.2 Common Interface ............................................................................. ........... 17

6.3 HDD information ................................................... ....................................... 17

7. Record ............................................................................... ........................ ....... 17

7.1 Start record................................................................................................. 17

7.2 Recording info.................... ................................... ....................................... 18

7.3 Stop record ...................................................................................... ........... 18

8. Time Shifting .... ................................... ............................................................... 18

8.1 Start Timeshift...................... ............ ........................................................... 18

8.2 Play Timeshift........ ................................... ................................................... 19

8.3 Change Timeshift speed ...................................... ............ ............................... 19

8.4 Stop Timeshift .................................................................. ........................... 19

GLOSSARY ........................................................................................... ....................... 20

Specifications................................................................................ ........................ ....... 21

4

SAFETY INSTRUCTIONS

Please observe all warnings and instructions on the equipment and contained in these operating
instructions. You must install the dish with correct direction and angle.

Please carefully read this user’s manual before
using the receiver.

To avoid electric-shock hazards, do not open
the cabinet, refer servicing to qualified
personnel only. If cabinet is opened warranty
will be invalid.

Please switch off completely the receiver
during thunder, during abnormal phenomenon,
before cleaning it and in case it remains out of
service for a long period.

Do not expose the receiver under the sunlight.
And keep it away from the heat source or
humid environments. Do not block ventilation
holes of the receiver so that air can circulate
freely.

Please place the receiver in horizontal and
stable conditions, keeping it away from
vibrating.

If device is moved from warmer place to a
colder one some problem might occur. Please
switch off the receiver and turn it on after 1 or
2 hours.

Keep the receiver away from flower vases,
tubs, sinks, etc., in order to avoid damaging
the equipment. Do not touch power supply
with wet hands.

Don’t put any objects on the receiver.

Be sure to turn the receiver off and disconnect the AC power cord before cleaning the receiver surface.
If the surface is dirty, wipe clean with a cloth which has been dipped in a weak soap/and/water solution
and wrung out thoroughly, and then wipe again with a dry cloth.

Do not connect cables while power is plugged.
Do not use damaged cables for connections: you could cause fires.
Please switch off completely the receiver while making all connections.
The product purchased is a sophisticated electronic device which is not suitable for children under 18
years.
We do not assume responsibility for damages caused to people or object, deriving from use of the
device made by people under 18 years.

SOFTWARE FOR DOWNLOADING

Ferguson has used all the available means to deliver to its users software updates guaranteeing the
best possible parameters of the satellite television receivers. Ferguson reserves the right to make
corrections, changes or modifications of the software used in the receiver on any basis whatsoever and
without prior notice. The current version of the software is available on the following website

http://www.ferguson-digital.eu

USER MANUAL

Telstar has used all the available means to ensure the latest information regarding its products.
Ferguson does not give a warranty regarding the contents of this User Manual and waives any implied
warranties regarding market value or fitness for specific purposes. The information contained herein
provide guidelines allowing the operation and maintenance of the receiver.

Ferguson reserves the right to make changes, corrections or to translate the User Manual without
giving prior notice of such changes. Therefore, it is recommended that users visit our website regularly
to receive the latest information.

5

SYMBOLS USED ON THE RECEIVER

The Digital Video Broadcasting logo.

This logo tells you that this receiver is compliant with the DVB standards.

technicians are allowed to open the box.

electromagnetic compatibility and the provisions of Council Directive 73/23/EEC and 93/68/EEC on the
approximation of the laws of the Member States relating to low voltage and electrical safety.

The caution risk of electrical shock - do not open symbol
This symbol tells you that you are not allowed to open the receiver. Only authorized (service)

The CE mark.
This mark tells you that the receiver is following the provisions of Council Directive
89/336/EEC on the approximation of the laws of the Member States relating to the

The double insulation symbol.
This symbol tells you that the receiver is electrically safe within the normal use of the
receiver as stated in the safety chapter.

Environment protection first!

 Your appliance contains valuable materials which can be recovered or recycled.
 Leave it at a local civic waste collection point.

6

GENERAL INFORMATION

This digital terrestrial receiver is a highly cost-effective digital terrestrial receiver integrated. It
provides big channels storage with fast searching. The receiver is definitely one of the best choices to
deliver your digital life.

1. Main Features

 Fully conforms to MPEG4, MPEG2 and DVB-T standard.
 Using a CAM, it can decrypt the conditional access service.
 Bandwidth of 7MHz & 8MHz supported.
 Convenient user interface supports Multi-language character-sets.
 Stores up to 1000 programs.
 Separate TV/Radio List & Favourite Group List
 Auto & manually scan all available TV and Radio channels
 Component (YPbPr) output supports 1080i/720p
 HDMI output supports HDCP
 Digital Audio Stream through optical S/PDIF
 PAL-NTSC-SECAM Auto-conversion system
 Supports logical channel number (LCN)
 Supports Teletext (OSD / VBI) and Subtitles (OSD)
 Advanced Electronic Program Guide (EPG)
 USB PVR function – recording on USB memory
 TimeShift - with this feature, stop and rewind movies and programs in the course of watching

2. Unpacking

Unpack the receiver and check to make sure that all of the following items are included in the
packaging.

 1 x Remote Control Unit
 1 x User’s Guide
 1 x Digital Terrestrial Receiver

3. General Operation of STB

Throughout this manual you will notice that the everyday operation of your STB is based on a series of
user friendly on screen display and menus. These menus will help you get the most from your STB,
guiding you through installation, channel organizing, viewing and many other functions.
All functions can be carried out using the buttons on the RCU, and some of the functions can also be
carried out using the buttons on the front panel.
Please be aware that new software may change the functionality of the receiver.
Should you experience any difficulties with the operation of your unit, please consult the relevant
section of this manual, including the Problem Shooting, or alternatively call your dealer or a customer
service adviser.

NOTE:
Please be aware that new software may change the functionality of the receiver. The photo
and the function explanation involved in this specification is for reference only. If there is any
mistake, please refer to the entity.

7

INSTALLATION OF STB

1. Front Panel

【POWER】Press to switch between ON and OFF modes.

【MENU】Display the main menu on TV

【EXIT】Return to the previous menu.

【OK】Confirm user’s selection or display the programs list on TV screen.

【VOL-】Left move key or increases volume

【VOL+】Right move key or decreases volume

【CH-】Move cursor or channel down

【CH+】Move cursor or channel up

【DISPLAY SCREEN】Display the channel number and status. Power indicator. Signal indicator.

【CAM】CAM slot

2. Rear Panel

【ANT IN】Aerial signal input

【RF OUT】Signal loop output

【HDMI】Connects to the HDMI input on your TV set

【S/PDIF】Digital audio output.

【USB】USB for update software

【VIDEO】Connects to the video channel of TV

【R/L】Provides the stereo audio output to TV or other equipments

【YPbPr】Provides a component video output to TV or other equipments.

【TV】Connect to TV using SCART cable

【VCR】Connect to VCR using SCART cable.

【LAN】 Not available
