INSTALLATION MANUAL
SIENA +
CONGRATULATIONS
Congratulations and thank you for choosing
a Falmec rangehood.
To avoid the risks that are always present
when you use an electrical appliance it is
important that the rangehood is installed
correctly and that you read the safety instructions carefully to avoid misuse and hazards.
We recommend that you keep this instruction
booklet for future reference and pass it on to
any future owners.
IMPORTANT INFORMATION
AFTER UNPACKING THE RANGEHOOD PLEASE REVIEW YOUR NEW ITEM TO ENSURE
THAT IT HASN’T BEEN DAMAGED IN TRANSIT OR IS MISSING ANY COMPONENTS.
FAILURE TO REPORT ANY ISSUE WITHIN 72 HOURS OF RECEIPT OF YOUR ITEM MAY
RESULT IN ADDITIONAL CHARGES.
ENVIRONMENTAL TIP
Information on disposal for users Most of the packing materials are recyclable.
Please dispose of those materials through your local recycling depot or by placing
them in a appropriate collection bin.
If you wish to discard this product, please contact your local authorities and ask for
the correct method of disposal.
TO AVOID THE RISK OF INJURY OR DAMAGE TO THE PRODUCT IT IS ESSENTIAL TO
READ THESE INSTRUCTIONS PRIOR TO INSTALLATION AND USE.
2
PRODUCT DESCRIPTION & CARTON CONTENTS
CARTON 1 - HOOD UNIT
INTEGRATED HOOD - ON BOARD HOOD
Models include:
SIENA + F3SN60S2,
SIENA + F3SN90S2,
SIENA + F3SND90S2
Included in the carton:
1. Main hood housing including control module and lighting
2. Bae lters
3. Grease trap
4. Fixing screws
5. Operating & installation guide
ENGINE TECHNOLOGY
The Siena + hoods
are equipped with
a low consumption
electronic motor
3
SIENA + 56 / 87
F3SN60S2
F3SN90S2
389
88
379 / 665
505 / 815
541 / 851
150
541 / 851
247
332
184
12
280
280
512 / 822
250
EN - HOLE MEASUREMENTS FOR INSTALLATION
IT - MISURE FORO PER INCASSO
4
SIENA + 87 DEEP
F3SND90S2
584
326
248
382
88
815
851
150
851
824
12
326
98
360
360
EN - HOLE MEASUREMENTS FOR INSTALLATION
IT - MISURE FORO PER INCASSO
330
5
STEP 1:
Minimum distance by cooktop.
STEP 2:
Wall unit hole.
STEP 3:
You push the hood in wall unit hole.
1
2
600 - 650 mm
3
6
STEP 4:
You screw the blocking devices.
STEP 6:
Attach the male plug of the rangehood unit to the main
power supply.
STEP5:
Connect the hood outlet (in the top or back ducted position)
to 150mm ducting leading to an external output.
STEP 7:
Assembling the metal lters.
54
x4
CAUTION
6 7
1
2
3
7
SEQUENCE FOR REMOVING THE HOOD
STEP 8:
Remove the metal lters.
STEP 9:
Remove the cover caps.
STEP 10:
With your nger enter the hole and pull the lever to unlock
the stop.
98
10
1
2
8
SAFETY INSTRUCTIONS
AND WARNINGS
Installation operations are to be carried out by skilled and qualied installers in accordance with the instructions in this booklet and in compliance with the regulations in force.
DO NOT use the hood if the power supply cable or other components are damaged:
disconnect the hood from the electrical power supply and contact the Dealer or an authorised Servicing Dealer for repairs.
Do not modify the electrical, mechanical or functional structure of the equipment.
Do not personally try to carry out repairs or replacements. Interventions carried out
by incompetent and unauthorised persons can cause serious damage to the unit or
physical and personal harm, not covered by the Manufacturer's warranty.
WARNINGS FOR THE INSTALLER
TECHNICAL SAFETY
Before installing the hood, check the integrity and function of each part.
Should anomalies be noted, do not proceed with installation and contact
the Dealer.
Do NOT install the hood if an aesthetic (or cosmetic) defect has been detected. Put it
back into its original package and contact the dealer.
No claim can be made for aesthetic (or cosmetic) defects once it has been installed.
During installation, always use personal protective equipment (e.g.: Safety shoes) and adopt
prudent and proper conduct.
The installation kit (screws and plugs) supplied with the hood is only to be used on masonry
walls: in case of installation on walls of a dierent material, assess other installation options
keeping in mind the type of wall surface and the weight of the hood (indicated on page 2).
Keep in mind that installations with dierent types of fastening systems from those supplied, or which are not compliant, can cause electrical and mechanical seal danger.
Do not install the hood outdoors and do not expose it to atmospheric elements (rain, wind,
etc.).
ELECTRICAL SAFETY
The electrical system to which the hood is to be connected must be in accordance with local standards and supplied with earthed connection in
compliance with safety regulations in the country of use. It must also comply with European standards regarding radio antistatic properties.
Before installing the hood, check that the electrical mains power supply corresponds with
what is reported on the identication plate located inside the hood.
The socket used to connect the installed equipment to the electrical power supply must
be within reach: otherwise, install a mains switch to disconnect the hood when required.
Any changes to the electrical system must be carried out by a qualied electrician.
The maximum length of the ue fastening screws (supplied by the manufacturer) must be
13 mm. Use of non-compliant screws with these instructions can lead to danger of an electrical nature.
Do not try to solve the problem yourself in the event of equipment malfunction, but contact
the Dealer or an authorised Servicing Department for repairs.
When installing the hood, disconnect the equipment by removing the
plug or switching o the main switch.
If the equipment is sold or transferred to another person, make sure that the booklet is
also supplied so that the new user can be made aware of the hood's operation and relative
warnings.
After the stainless steel hood has been installed, it will need to be cleaned to remove any
residues remaining from the protection adhesive as well as any grease and oil stains which, if
not removed, can cause irreversible damage to the hood surface. To properly clean the unit,
the manufacturer recommends using the supplied moist wipes, which are also available
sold separately.
Insist on original spare parts.
INTENDED USE
ENGLISH
The equipment is solely intended to be used to extract fumes generated from cooking food in non-professional domestic kitchens: any other use is improper. Improper
use can cause damage to persons, things, pets and exempts the Manufacturer from
any liability.
The equipment can be used by children over the age of 8 and by persons with reduced
physical, sensory and mental abilities, or with no experience or knowledge, as long as they
do so under supervision or after having received relative instructions regarding safe use of
the equipment and understanding of the dangers connected to it.
Children are not to play with the equipment. Cleaning and maintenance by the user must
not be carried out by children without supervision.
USE AND CLEANING WARNINGS
Before cleaning or carrying out maintenance operations, disconnect the
equipment by removing the plug or switching o the main switch.
Do not use the hood with wet hands or bare feet.
Always check that all electrical parts (lights, extractor fan) are o when the equipment is
not being used.
The maximum overall weight of any objects placed or hung (if applicable) on the hood must
not exceed 1.5 Kg.
Always supervise the cooking process during the use of deep-fryers: Overheated oil can
catch re.
Do not leave open, unattended ames under the hood.
Do not prepare food over an open ame under the hood.
Never use the hood without the metal anti-grease lters: in this case, grease and dirt will
deposit in the equipment and compromise its operation.
Accessible parts of the hood can be hot when used at the same time as the cooking appliances.
Do not carry out any cleaning operations when parts of the hood are still hot.
There can be a risk of re if cleaning is not carried out according to the instructions and
products indicated in this booklet.
Disconnect the main switch when the equipment is not used for long periods of time.
If other appliances that use gas or other fuels are being used at the same
time (boiler, stove, replaces, etc.), make sure the room where the fumes
are discharged is well-ventilated, in compliance with the local regulations.
INSTALLATION
only intended for qualied personnel
Before installing the hood, carefully read the chapter "SAFETY INSTRUC-
TIONS AND WARNINGS".
FUMES DISCHARGE SAFETY
Do no connect the equipment to discharge pipes of fumes produced from
combustion (for example boilers, replaces, etc.).
Before installing the hood, ensure that all standards in force regarding discharge of air out of
the room have been complied with.
USER WARNINGS
These warnings have been drawn up for your personal safety and those of
others. You are therefore kindly asked to read the booklet carefully in its
entirety before using the or cleaning the equipment.
The Manufacturer declines all responsibility for any damage caused directly, or indirectly, to persons, things and pets as a consequence of failing to comply with the
safety warnings indicated in this booklet.
It is imperative that this instructions booklet is kept together with the equipment for
any future consultation.
TECHNICAL FEATURES
The technical specications are exhibited on the labels located inside the hood.
POSITIONING
The minimum distance between the highest part of the cooking equipment and the
lowest part of the hood is indicated in the installation instructions.
Generally, when the hood is placed over gas cookers, the distance must be at least 65 cm
(25.6''). However, according to an interpretation of standard EN60335-2-31 dated 11-072002 of TC61 (sub-clause 7.12.1 meeting 15 agenda item 10.11), the minimum distance
between the cooker and lower part of the hood can be reduced to the quota reported in
the installation instructions.
Should the instructions for the gas cooker specify a greater distance, this must be taken
into consideration.
Do not install the hood outdoors and do not expose it to outdoor environment (rain, wind,
etc.).
9
OPERATION
OPERATING YOUR CONTROL PANEL WITH THE 6 BUTTON TOUCH CONTROL
Turning the extraction function ON or OFF:
• In standby mode, press button 2 to turn on operating mode, then press buttons 3 through
to 5 to change the speed.
• The hood has three speed options and a boost speed plus the 24 recirculating mode.
• To turn hood o, press button 2 repeatedly until hood returns to standby mode.
Turning the light function ON or OFF:
Press button 6 to turn on or turn o the light in either standby mode or when the hood is in
use. Light will remain on indenitely until switched o using button 6 again, otherwise will
switch o when time elapses in timer mode (when in use).
Turning the timer function ON or OFF:
In operating mode, press button 1 to engage the timer function.
The default time set is 15 minutes and cannot be increased or decreased.
TOUCH PUSHBUTTON PANEL
1 2 3 4 5 6
TIMER (red LED ashing)
Auto switch-o after 15 min.
The function deactivates (red LED o ) if:
- The motor turns o (key
- The speed is changed.
FILTER ALARM (red LED steady on with (
Anti-grease lter maintenance after approximately 30 hours of operation.
Press the meter for 3 seconds to reset.
MOTOR ON/OFF
Motor on/o and Speed 1.
If pressed for more than 3 seconds, it activates the 24h cycle (1h ON -> 3h
OFF -> 1h ON)
the function deactivates if:
- The motor turns o (key
- After 24h
Speed 2 activation
).
) o )
)
USING THE RADIO CONTROL
WARNINGS!
Place the hood away from sources of electromagnetic waves (e.g. microwave ovens),
which could interfere with the radio control and with the hood electronics.
The maximum operating distance is 5 metres, that may vary according to the presence of electromagnetic interferences.
Radio control operated at 433.92MHz.
The radio control consists of two parts:
- the receiver built into the hood;
- the transmitter shown here in the gure.
REMOTE CONTROL
DESCRIPTION OF TRANSMITTING
COMMANDS
UP
Motor switch-on and speed increase from 1
to 4. Speed 4 is only active for 10 minutes.
DOWN
speed decrease and motor switch-OFF.
Light ON-OFF
Short impulse: turn light on and o
Long impulse:
change light tone from 2700K to 5600K
TIMER ON: The motor automatically switches o after 15 min.
The function is automatically disabled if the
motor is switched o (
ACTIVATION PROCEDURE
Before using the radio control, follow the procedure below on the hood pushbutton panel:
• Press LIGHT and TIMER simultaneously until all LEDs start ashing.
• Release the two keys and press LIGHT again until all LEDs are lit up.
• Release LIGHT : now the receiver is active.
This procedure is also used to deactivate the receiver.
Command transmission active
key)
Speed 3 activation
Speed 4 activation for 10 minutes only
Light on/o
Short impulse: turn light on and o.
Long impulse: change light tone from 2700K to 5600K.
RADIO CONTROL CODE CHANGE
With only one radio control, go directly to point 2.
With several radio controls in the same room, a new code can be created by following the
procedure below.
Disconnect the power to the hood before starting the procedure.
1 CREATE A NEW CODE
The procedure is to be carried out on the radio control.
Press LIGHT and TIMER simultaneously until the display starts ashing.
•
• Press DOWN on the radio control: saving is conrmed by three brief ashes of the
display. The new code cancels and replaces the previous default code.
Reconnect the hood to the electrical power supply, making sure that the
lights and motor are o.
2 PAIRING THE RADIO CONTROL WITH THE HOOD
USING THE ELECTRONIC PUSHBUTTON PANEL
press TIMER
the red LED lights up.
press any key on the radio control within 10 seconds.
RESTORING DEFAULT CODE
the procedure is to be carried out if the hood is disposed of, sold or transferred.
on the hood pushbutton panel for 2 seconds:
Disconnect the power to the hood before starting the procedure.
• Press UP and DOWN simultaneously on the radio control for more than 5 sec-
onds: reset is conrmed by three brief ashes of the display.
• Reconnect the hood to the electrical power supply.
• Proceed with associating the hood and the radio control, as described in point 2.
10
MAINTENANCE
DISPOSAL AFTER END OF USEFUL LIFE
Before cleaning or carrying out maintenance operations, disconnect the
equipment by removing the plug or switching o the main switch.
Do not use detergents containing abrasive, acidic or corrosive substances
Regular maintenance guarantees proper operation and performance over time.
Special attention is to be paid to the metal anti-grease lters: frequent cleaning of the
lters and their supports ensures that no ammable grease is accumulated.
or abrasive cloths.
CLEANING OF EXTERNAL SURFACES
You are advised to clean the external surfaces of the hood at least once every 15 days to
prevent oily substances and grease from sticking to them. To clean the brushed stainless
steel hood, the Manufacturer recommends using "Magic Steel" wipes.
Alternatively and for all the other types of surfaces, it can be cleaned using a damp cloth,
slightly moistened with mild, liquid detergent or denatured alcohol.
Finish o cleaning by rinsing well and drying with soft cloths.
Do not use too much water next to the push button control panel and
lighting devices in order to prevent humidity from reaching electronic
parts.
The glass panels can only be cleaned with specic, non-corrosive or non-abrasive detergents using a soft cloth.
The Manufacturer declines all responsibility for failure to comply with these instructions.
CLEANING OF INTERNAL SURFACES
Do not clean electrical parts, or parts related to the motor inside the hood,
with liquids or solvents.
For the internal metal parts, see the previous paragraph.
The crossed-out trash or refuse bin symbol on the appliance means that the
product is WEEE, i.e. “Waste electrical and electronic equipment'', accordingly it
must not be disposed of with regular unsorted waste (i.e. with ''mixed house-
hold waste''), but it must be disposed of separately so that it can undergo specific processing for its re-use, or a specic treatment, to remove and safely dispose of any
substances that may be harmful to the environment and remove the raw materials that can
be recycled. Proper disposal of these products contributes to saving valuable resources and
avoid potential negative eects on personal health and the environment, which may be
caused by inappropriate disposal of waste.
You are kindly asked to contact your local authorities for further information regarding the
designated waste collection points nearest to you. Penalties for improper disposal of such
waste can be applied in compliance with national regulations.
INFORMATION ON DISPOSAL IN EUROPEAN UNION COUNTRIES
The EU WEEE Directive was implemented dierently in each country, accordingly, if you wish
to dispose of this appliance we suggest contacting your local authorities or dealer to nd
out what the correct method of disposal is.
INFORMATION ON DISPOSAL IN NONEUROPEAN UNION COUNTRIES
The crossed-out trash or refuse bin symbol is only valid in the European Union: if you wish
to dispose of this appliance in other countries, we suggest contacting your local authorities
or dealer to nd out what the correct method of disposal is.
WARNING!
The Manufacturer reserves the right to make changes to the equipment at any time and
without prior notice. Printing, translation and reproduction, even partial, of this manual are
bound by the Manufacturer's authorisation.
Technical information, graphic representations and specications in this manual are for information purposes and cannot be divulged.
This manual is written in Italian. The Manufacturer is not responsible for any transcription
or translation errors.
ENGLISH
LIGHTING
The range hood is equipped with high eciency, low consumption LED light.
GREASE DRIP TRAY
It is advisable to clean the tray every 15 days.
Do not use corrosive, acid or alkaline detergents.
For more thorough cleaning, remove the oil collection tray (see gure) and wash it with
hot water and washing up liquid. Rinse it well and wait for it to be completely dry before
reassembling it. They are dishwasher safe.
2
3
1
FUMES DISCHARGE
In this version the fumes and vapours are discharged outside through the exhaust pipe.
To this end, the hood outlet tting must be connected via a pipe, to an external output.
The outlet pipe must have:
- A diameter not less than that of the hood tting.
- A slight slope downwards (drop) in the horizontal sections to prevent condensation from
owing back into the motor.
- The minimum required number of bends.
- The minimum required length to avoid vibrations and reduce the suction performance
of the hood.
11
PROFESSIONAL WARRANTY
All FALMEC Professional range hoods come with a 3 year parts and labour warranty. PRKS
will correct, free of charge, any defects in material or workmanship for the period of 3 years,
subject to the terms of our warranty stated below.
This warranty will be void if a model from the professional series is used for commercial
purposes. Some examples of commercial purposes but not limited to, include restaurants,
cafés, schools and clubs.
Rangehoods in the Professional range (exlduing BBQ models) are designed and warranted
“strictly” for indoor use only (household kitchen).
Please note: The benets provided by this warranty are in addition to all other rights and
remedies in respect to the product which the consumer has under the Australian competition and Consumer Act 2010.
1. This warranty only applies for products installed by a qualied person and when provided
with a certicate of compliance in accordance with State/Territory laws.
2. This product must be used in accordance with the manufacturer’s instructions. This warranty does not apply should the defect in or failure of the product be attributable to misuse,
abuse, accident or non-observation of the manufactures instructions on the part of the user.
FALMEC appliances does not accept liability for any direct or consequential loss, damage or
other expense caused by or arising out of any failure to install or use the product in accordance with the manufacturer’s instructions.
3. The warranty does not cover failures due to normal wear and tear with reasonable use or
consumable components such as globes, lters, etc.
4. PRKS appliances, at its own discretion may replace or repair any defective component(s)
to aect a repair due to any faulty workmanship and material. The warranty does not cover
breakage of outer glass panels attributed to external damage.
5. The warranty provided is a “Repair Warranty” and in an extreme event if a repair cannot
take place, a replacement will be provided of an equivalent current model where the balance of the warranty period from the original date of purchase will take eect.
6. This warranty is immediately void if the serial or model number label is removed, defaced,
serviced or repaired by a unauthorised/unqualied personal or used for industrial/commercial purposes.
7. Warranty will be only provided when a proof of the original purchase is presented to an
authorised dealer or reseller before or at the time of service.
8. This warranty does not cover any corrosion or defect as a result of the product being
installed in an environment in which the appliance is not protected from the weather.
9. It is the responsibility of the customer to ensure the appliance is easily accessible for a
service technician to carry out required repairs. Any obstruction prohibiting access to the
product by building materials of any kind will be required to be removed and reinstalled
by the customer.
10. This warranty covers the rst 50 km travelled by a repair technician to the appliance location and return. Any travel in excess of 50 km each way is not covered by the warranty. PRKS
has a service network in all metropolitan areas and most regional areas. Where the warranty
claim has been made outside a radius of 50 km from any store where the product can be
purchased, the customer is responsible for the cost of delivery to the nearest service agent
or the travel cost for a technician to travel to a location outside the 50 km radius.
YOUR STATUTORY RIGHTS
FALMEC products fully assures all customers that our goods come with guarantees that
cannot be excluded under the Australian Consumer Law. You are entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not
amount to a major failure. You are also entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage.
The benets under FALMEC’s warranty are in addition to other rights you have at law in
relation to the appliances or services to which the warranty relates.
OUTDOOR USE OF PROFESSIONAL RANGEHOODS
Outdoor BBQ models from the Falmec Professional series are warranted for use above barbecues and in alfresco areas with one open wall and a solid roof such as that they are not
exposed to the elements.
Professional BBQ models MUST only have the specied 2010 m3/hr motor installed in
conjunction with the hood.
In a the scenario where the hood is located near the ocean or exposed to salty air, regular
care and cleaning of the hood is recommended to prevent any corrosion.
This warranty will be void if the outdoor models from the Falmec Professional series are
used for commercial purposes. Some examples of commercial purposes but not limited to,
include restaurants, cafés, schools, clubs.
PROFESSIONAL REMOTE MOTORS
In addition to the standard 3 years parts and labour warranty stated above the remote motors from the Professional series are covered for an additional 7 years as a parts only warranty
therefore giving a total coverage of 10 years. This warranty is conditional by the following
items.
• If installed in coastal applications the external housing must have a anti-corrosive coating
applied. The internal fan may also require additional cleaning/washdown as a result of exposure to salt in the air.
• Fan must be installed in a position that it will not be subjected to excessive duct temperatures (40˚ covers all models).
• Filters must be in place within the rangehood and regularly maintained/cleaned/replaced
as needed.
SUPPORT
At PRKS we place great importance on customer satisfaction and that is why we have
established a dedicated and experienced customer support team that you can rely on.
Should you ever need to make a warranty related enquiry about your FALMEC product simply call 03 9700 9100 (Australia) or 09 9640 400 (New Zealand) to speak with our friendly
customer service consultants. We suggest you have the following information close at hand
to make the process as easy as possible:
1. Model number of your appliance
2. Serial number of your appliance
3. A copy of your original purchase receipt
4. Address details of where the appliance is installed
12
NOTE NOTES
13
NOTE NOTES
14
NOTE NOTES
15
Code 110033078 Ed. 01/2019
Loading...
