Extron electronic MTPX 1616, MTPX 1632, MTPX 168, MTPX 3216 User Manual

Download

Setup Guide

www.extron.com

Extron Electronics, USA

1230 South Lewis Street Anaheim, CA 92805

800.633.9876 714.491.1500 FAX 714.491.1517

Extron Electronics, Europe

Beeldschermweg 6C 3821 AH Amersfoort, The Netherlands +800.3987.6673 +31.33.453.4040 FAX +31.33.453.4050

Extron Electronics, Asia

135 Joo Seng Rd. #04-01 PM Industrial Bldg., Singapore 368363 +800.7339.8766 +65.6383.4400 FAX +65.6383.4664

Extron Electronics, Japan

Kyodo Building, 16 Ichibancho Chiyoda-ku, Tokyo 102-0082 Japan +81.3.3511.7655 FAX +81.3.3511.7656

MTPX Series

Mini Twisted Pair Matrix Switchers

68-1561-01 Rev. A

06 08

Precautions

Safety Instructions • English

This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment.

This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product’s enclosure that may present a risk of electric shock.

Caution

Read Instructions • Read and understand all safety and operating

instructions before using the equipment.

Retain Instructions • The safety instructions should be kept for future

reference.

Follow Warnings • Follow all warnings and instructions marked on the

equipment or in the user information.

Avoid Attachments • Do not use tools or attachments that are not

recommended by the equipment manufacturer because they may be hazardous.

Consignes de Sécurité • Français

Ce symbole sert à avertir l’utilisateur que la documentation fournie avec le matériel contient des instructions importantes concernant l’exploitation et la maintenance (réparation).

Ce symbole sert à avertir l’utilisateur de la présence dans le boîtier de l’appareil de tensions dangereuses non isolées posant des risques d’électrocution.

Attention

Lire les instructions• Prendre connaissance de toutes les consignes de

sécurité et d’exploitation avant d’utiliser le matériel.

Conserver les instructions• Ranger les consignes de sécurité aﬁ n de pouvoir

les consulter à l’avenir.

Respecter les avertissements • Observer tous les avertissements et consignes

marqués sur le matériel ou présentés dans la documentation utilisateur.

Eviter les pièces de ﬁ xation • Ne pas utiliser de pièces de ﬁ xation ni d’outils

non recommandés par le fabricant du matériel car cela risquerait de poser certains dangers.

Sicherheitsanleitungen • Deutsch

Dieses Symbol soll dem Benutzer in der im Lieferumfang enthaltenen Dokumentation besonders wichtige Hinweise zur Bedienung und Wartung (Instandhaltung) geben.

Dieses Symbol soll den Benutzer darauf aufmerksam machen, daß im Inneren des Gehäuses dieses Produktes gefährliche Spannungen, die nicht isoliert sind und die einen elektrischen Schock verursachen können, herrschen.

Achtung

Lesen der Anleitungen • Bevor Sie das Gerät zum ersten Mal verwenden,

sollten Sie alle Sicherheits-und Bedienungsanleitungen genau durchlesen und verstehen.

Aufbewahren der Anleitungen • Die Hinweise zur elektrischen Sicherheit

des Produktes sollten Sie aufbewahren, damit Sie im Bedarfsfall darauf zurückgreifen können.

Befolgen der Warnhinweise • Befolgen Sie alle Warnhinweise und

Anleitungen auf dem Gerät oder in der Benutzerdokumentation.

Keine Zusatzgeräte • Verwenden Sie keine Werkzeuge oder Zusatzgeräte,

die nicht ausdrücklich vom Hersteller empfohlen wurden, da diese eine Gefahrenquelle darstellen können.

Instrucciones de seguridad • Español

Este símbolo se utiliza para advertir al usuario sobre instrucciones importantes de operación y mantenimiento (o cambio de partes) que se desean destacar en el contenido de la documentación suministrada con los equipos.

Este símbolo se utiliza para advertir al usuario sobre la presencia de elementos con voltaje peligroso sin protección aislante, que puedan encontrarse dentro de la caja o alojamiento del producto, y que puedan representar riesgo de electrocución.

Precaucion

Leer las instrucciones • Leer y analizar todas las instrucciones de operación y

seguridad, antes de usar el equipo.

Conservar las instrucciones • Conservar las instrucciones de seguridad para

futura consulta.

Obedecer las advertencias • Todas las advertencias e instrucciones marcadas

en el equipo o en la documentación del usuario, deben ser obedecidas.

Evitar el uso de accesorios • No usar herramientas o accesorios que no

sean especiﬁ camente recomendados por el fabricante, ya que podrian implicar riesgos.

Warning

Power sources • This equipment should be operated only from the power source

indicated on the product. This equipment is intended to be used with a main power system with a grounded (neutral) conductor. The third (grounding) pin is a safety feature, do not attempt to bypass or disable it.

Power disconnection • To remove power from the equipment safely, remove all power

cords from the rear of the equipment, or the desktop power module (if detachable), or from the power source receptacle (wall plug).

Power cord protection • Power cords should be routed so that they are not likely to be

stepped on or pinched by items placed upon or against them.

Servicing • Refer all servicing to qualiﬁ ed service personnel. There are no user-

serviceable parts inside. To prevent the risk of shock, do not attempt to service this equipment yourself because opening or removing covers may expose you to dangerous voltage or other hazards.

Slots and openings • If the equipment has slots or holes in the enclosure, these are

provided to prevent overheating of sensitive components inside. These openings must never be blocked by other objects.

Lithium battery • There is a danger of explosion if battery is incorrectly

replaced. Replace it only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

Avertissement

Alimentations• Ne faire fonctionner ce matériel qu’avec la source d’alimentation

indiquée sur l’appareil. Ce matériel doit être utilisé avec une alimentation principale comportant un ﬁ l de terre (neutre). Le troisième contact (de mise à la terre) constitue un dispositif de sécurité : n’essayez pas de la contourner ni de la désactiver.

Déconnexion de l’alimentation• Pour mettre le matériel hors tension sans danger,

déconnectez tous les cordons d’alimentation de l’arrière de l’appareil ou du module d’alimentation de bureau (s’il est amovible) ou encore de la prise secteur.

Protection du cordon d’alimentation • Acheminer les cordons d’alimentation de

manière à ce que personne ne risque de marcher dessus et à ce qu’ils ne soient pas écrasés ou pincés par des objets.

Réparation-maintenance • Faire exécuter toutes les interventions de réparation-

maintenance par un technicien qualiﬁ é. Aucun des éléments internes ne peut être réparé par l’utilisateur. Aﬁ n d’éviter tout danger d’électrocution, l’utilisateur ne doit pas essayer de procéder lui-même à ces opérations car l’ouverture ou le retrait des couvercles risquent de l’exposer à de hautes tensions et autres dangers.

Fentes et oriﬁ ces • Si le boîtier de l’appareil comporte des fentes ou des oriﬁ ces, ceux-ci

servent à empêcher les composants internes sensibles de surchauffer. Ces ouvertures ne doivent jamais être bloquées par des objets.

Lithium Batterie • Il a danger d’explosion s’ll y a remplacment incorrect de la batterie.

Remplacer uniquement avec une batterie du meme type ou d’un ype equivalent recommande par le constructeur. Mettre au reut les batteries usagees conformement aux instructions du fabricant.

Vorsicht

Stromquellen • Dieses Gerät sollte nur über die auf dem Produkt angegebene

Stromquelle betrieben werden. Dieses Gerät wurde für eine Verwendung mit einer Hauptstromleitung mit einem geerdeten (neutralen) Leiter konzipiert. Der dritte Kontakt ist für einen Erdanschluß, und stellt eine Sicherheitsfunktion dar. Diese sollte nicht umgangen oder außer Betrieb gesetzt werden.

Stromunterbrechung • Um das Gerät auf sichere Weise vom Netz zu trennen, sollten

Sie alle Netzkabel aus der Rückseite des Gerätes, aus der externen Stomversorgung (falls dies möglich ist) oder aus der Wandsteckdose ziehen.

Schutz des Netzkabels • Netzkabel sollten stets so verlegt werden, daß sie nicht im

Weg liegen und niemand darauf treten kann oder Objekte darauf- oder unmittelbar dagegengestellt werden können.

Wartung • Alle Wartungsmaßnahmen sollten nur von qualiﬁ ziertem Servicepersonal

durchgeführt werden. Die internen Komponenten des Gerätes sind wartungsfrei. Zur Vermeidung eines elektrischen Schocks versuchen Sie in keinem Fall, dieses Gerät selbst öffnen, da beim Entfernen der Abdeckungen die Gefahr eines elektrischen Schlags und/oder andere Gefahren bestehen.

Schlitze und Öffnungen • Wenn das Gerät Schlitze oder Löcher im Gehäuse aufweist,

dienen diese zur Vermeidung einer Überhitzung der empﬁ ndlichen Teile im Inneren. Diese Öffnungen dürfen niemals von anderen Objekten blockiert werden.

Litium-Batterie • Explosionsgefahr, falls die Batterie nicht richtig ersetzt

wird. Ersetzen Sie verbrauchte Batterien nur durch den gleichen oder einen vergleichbaren Batterietyp, der auch vom Hersteller empfohlen wird. Entsorgen Sie verbrauchte Batterien bitte gemäß den Herstelleranweisungen.

Advertencia

Alimentación eléctrica • Este equipo debe conectarse únicamente a la fuente/tipo

de alimentación eléctrica indicada en el mismo. La alimentación eléctrica de este equipo debe provenir de un sistema de distribución general con conductor neutro a tierra. La tercera pata (puesta a tierra) es una medida de seguridad, no puentearia ni eliminaria.

Desconexión de alimentación eléctrica • Para desconectar con seguridad la acometida

de alimentación eléctrica al equipo, desenchufar todos los cables de alimentación en el panel trasero del equipo, o desenchufar el módulo de alimentación (si fuera independiente), o desenchufar el cable del receptáculo de la pared.

Protección del cables de alimentación • Los cables de alimentación eléctrica se deben

instalar en lugares donde no sean pisados ni apretados por objetos que se puedan apoyar sobre ellos.

Reparaciones/mantenimiento • Solicitar siempre los servicios técnicos de personal

caliﬁ cado. En el interior no hay partes a las que el usuario deba acceder. Para evitar riesgo de electrocución, no intentar personalmente la reparación/mantenimiento de este equipo, ya que al abrir o extraer las tapas puede quedar expuesto a voltajes peligrosos u otros riesgos.

Ranuras y aberturas • Si el equipo posee ranuras o oriﬁ cios en su caja/alojamiento,

es para evitar el sobrecalientamiento de componentes internos sensibles. Estas aberturas nunca se deben obstruir con otros objetos.

Batería de litio • Existe riesgo de explosión si esta batería se coloca en la posición

incorrecta. Cambiar esta batería únicamente con el mismo tipo (o su equivalente) recomendado por el fabricante. Desachar las baterías usadas siguiendo las instrucciones del fabricante.

Extron’s Warranty

Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of purchase and description of malfunction to:

USA, Canada, South America, Europe, Africa, and the Middle East: and Central America:

Extron Electronics, Europe Extron Electronics Beeldschermweg 6C

1001 East Ball Road 3821 AH Amersfoort

Anaheim, CA 92805, USA The Netherlands

Asia: Japan:

Extron Electronics, Asia Extron Electronics, Japan 135 Joo Seng Road, #04-01 Kyodo Building PM Industrial Bldg. 16 Ichibancho Singapore 368363 Chiyoda-ku, Tokyo 102-0082 Japan

This Limited Warranty does not apply if the fault has been caused by misuse, improper handling care, electrical or mechanical abuse, abnormal operating conditions or nonExtron authorized modiﬁ cation to the product.

If it has been determined that the product is defective, please call Extron and ask for an Applications Engineer at (714) 491-1500 (USA), 31.33.453.4040 (Europe), 65.6383.4400 (Asia), or 81.3.3511.7655 (Japan) to receive an RA# (Return Authorization number). This will begin the repair process as quickly as possible.

Units must be returned insured, with shipping charges prepaid. If not insured, you assume the risk of loss or damage during shipment. Returned units must include the serial number and a description of the problem, as well as the name of the person to contact in case there are any questions.

Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or ﬁ tness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.

Please note that laws vary from state to state and country to country, and that some provisions of this warranty may not apply to you.

安全须知 • 中文

这个符号提示用户该设备用户手册中有重要的操作和维护说明。

这个符号警告用户该设备机壳内有暴

露的危险电压，有触电危险。

注意

阅读说明书 • 用户使用该设备前必须阅读并理

解所有安全和使用说明。

保存说明书 • 用户应保存安全说明书以备将来使

用。

遵守警告 • 用户应遵守产品和用户指南上的所有安

全和操作说明。

避免追加 • 不要使用该产品厂商没有推荐的工具或

追加设备，以避免危险。

警告

电源 • 该设备只能使用产品上标明的电源。设备

必须使用有地线的供电系统供电。第三条线（地线）是安全设施，不能不用或跳过。

拔掉电源 • 为安全地从设备拔掉电源，请拔掉所有设备后

或桌面电源的电源线，或任何接到市电系统的电源线。

电源线保护 • 妥善布线，避免被踩踏，或重物挤压。维护 • 所有维修必须由认证的维修人员进行。设备内部

没有用户可以更换的零件。为避免出现触电危险不要自己试图打开设备盖子维修该设备。

通风孔 • 有些设备机壳上有通风槽或孔，它们是用来防止

机内敏感元件过热。不要用任何东西挡住通风孔。

锂电池 • 不正确的更换电池会有爆炸的危险。必须使用

与厂家推荐的相同或相近型号的电池。按照生产厂的建议处理废弃电池。

FCC Class A Notice

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. Front Panel Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The Class A limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Front Panel Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.

This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used

with the unit to ensure compliance with FCC emissions limits.

Chapter One • Introduction ................................................... 1-1

About this Manual ....................................................................1-2

About the MTPX Switchers .................................................... 1-2

Twisted Pair (TP) Cable Transmission Distance ................1-4

Chapter Two • Installation ...................................................... 2-1

Rear Panel .................................................................................... 2-2

Inputs ...................................................................................... 2-3

Outputs ................................................................................... 2-4

Remote control ....................................................................... 2-5

Power ...................................................................................... 2-5

Front Panel ................................................................................... 2-5

Chapter Three • Front Panel Operation..........................3-1

Creating a Tie ..............................................................................3-2

Saving or Recalling a Preset ...................................................3-3

Setting the Front Panel Locks (Executive Modes) ........... 3-4

Selecting Lock mode 2 or toggling between

mode 2 and mode 0 ............................................................... 3-4

Selecting Lock mode 2 or toggling between

mode 2 and mode 1 ............................................................... 3-5

Deﬁning the Audio/RS-232 Wire Pair (an

d Conﬁguring the R

Viewing and Adjusting the Audio Level ............................ 3-8

Viewing Ties (and Muting Outputs) .................................... 3-9

emote Port) ......................................3-6

Chapter Four • Remote Control and Optimizing the Video

Selected SIS™ Commands ........................................................ 4-2

Host-to-switcher instructions ................................................ 4-2

Installing and Starting the Control Program ..................4-10

Installing the program ......................................................... 4-10

Starting the program ........................................................... 4-11

Optimizing the video ........................................................... 4-12

Refer also to the MTPX User’s Manual at www.extron.com.

.................................................................. 4-1

MTPX • Table of Contents

Table of Contents, cont’d

MTPX Twisted Pair Matrix Switcher

Chapter One

All trademarks mentioned in this manual are the properties of their respective owners.

68-1561-01 Rev. A

MTPX • Table of Contents

Refer also to the MTPX User’s Manual at www.extron.com.

Introduction

About this Manual

About the MTPX Switchers

Twisted Pair (TP) Cable Transmision Distance

06 08

1-2

Refer also to the MTPX User’s Manual at www.extron.com.

1-3

Refer also to the MTPX User’s Manual at www.extron.com.

ETH

ACT

INP

SELEC

LOC

RJ-

LOCAL

UTS

3 4 5

6 7

9 1

0 11 12

13 1415

1819 2

0 2

222

3 24

25 2

6 27 28

29 3031

3 4 5

6 7

9 1

0 11 12

13 1415

1819 2

222

3 24

25 2

6 27 28

29 30 31

21 3

4 5 6

LOCAL

OUTP

UTS

OUTP

CONTR

MON

O AUDI

TPU

DIO IN

PUT

L R

I.T.E

INPUT

MTP T S

V A

S-VI

DEO

OUTPU

eci

INP

12V

0.5A

MONO

DIO 2

Y/C

-Y

R-Y

S-2

ACE

0.5A M

Y/C

MTP

U R A

AUDIO

PUT

ITO

MTP T 15H

D R

PRE

-PE

OFF

T 15H

PRE

-PEAK

OFF

Extron MTPX 3232

Twisted Pair Matrix Switcher

Control System

Extron MTP T SV A

Transmitter

DVD

Sound System

Extron MTP U R RSA SEQ

Universal Receiver

Extron MTP U R A

Universal Receiver

Plasma / LCD Display

Extron MTP T 15HD RS

Receiver

Extron MTP T 15HD A

Transmitter

Rack Mounted PC

LCD projector

Monitor

MTPX • Introduction

Introduction

MTPX • Introduction

About this Manual

About the MTPX Switchers

This setup guide allows you to easily and quickly set up and congure your Extron MTPX Twisted Pair (TP) Matrix Switcher. Step by step instructions show you how to connect the hardware, and then use the physical controls and the Matrix Switchers Control Program to optimize the video and audio output for the best quality.

The MTPX matrix switcher (gure 1-1) distributes signals that are compatible with the Extron MTP and VTT/VTR product lines. The matrix switcher routes a TP input signal to any combination of TP outputs. Depending on the MTP model, the routed TP signal can include RGB or low resolution video and either mono audio or transmitter-to-receiver RS-232 serial communications. The matrix switcher can route multiple input/output congurations simultaneously.

Figure 1-1 — Typical MTPX Twisted Pair Matrix Switcher application

The receiver-to-transmitter serial communications and

remote power capabilities available with certain MTP models are not supported by this matrix switcher.

The MTPX matrix switcher is available in the following matrix sizes:

MTPX 816 (8 inputs by 16 outputs)•

MTPX 168 (16 inputs by 8 outputs)•

MTPX 1616 (16 inputs by 16 outputs)•

MTPX 1632 (16 inputs by 32 outputs)•

MTPX 3216 (32 inputs by 16 outputs)•

MTPX 3232 (32 inputs by 32 outputs)•

The MTPX switchers input and output TP signals on RJ-45 connectors.

For best results, use a cable length of at least 50' (15 m)

between the TP inputs and outputs and the transmitter and receiver.

Three or six (depending on the matrix size) 15-pin HD and 5-pole 3.5 mm direct insertion input connectors are available for direct RGB (VGA) and stereo audio inputs without an MTP transmitter.

One or two (depending on the matrix size) 15-pin HD output connectors are available for direct RGB (VGA) output to a video device without an MTP receiver.

The direct input and direct output 15-pin HD connectors

can also support HD-YUV video, YUV video, S-video, and composite video.

Four or eight (depending on the matrix size) 5-pole 3.5 mm captive screw ports are available for direct mono audio outputs to an audio device without an MTP transmitter.

For low resolution MTPs (S-video and composite video) on

the TP inputs and outputs, the MTPX audio circuits are compatible only with the newer generation, mono audio models. See the MTP transmitter/ receiver to determine which MTP models you have.

The matrix switcher can be remotely controlled via ieither of two serial ports using either Extron’s Windows

-based Matrix

Switchers Control Program or the Simple Instruction Set (SIS™).

Refer also to the MTPX User’s Manual at www.extron.com.

MTPX • Introduction

Introduction, cont’d

1-4

MTPX • Introduction

1-5

Twisted Pair (TP) Cable Transmission Distance

The maximum distance is determined by the frequency and resolution of the signal that is input to the transmitter or to one of the matrix switcher’s local inputs. The table below species the recommended maximum transmission distances using Extron Enhanced Skew-Free A/V UTP cable or UTP CAT 5, 5e, or 6 cable, terminated with RJ-45 connectors.

Recommended transmission distances at 60 Hz

Video format MTPX Pre-Peak Maximum distance

Component, S-video, composite

640 x 480

800 x 600

1024 x 768*

1280 x 1024*

1600 x 1200*

Do not connect this device to a computer data or

telecommunications network.

On Off High

quality

<350'

(100 m)

<350'

100 m)

<350'

(100 m)

<350'

(100 m)

<350'

(100 m)

<350'

(100 m)

>400'

(120 m)

>400'

(120 m)

>400'

(120 m)

>400'

(120 m)

>400'

(120 m)

>400'

(120 m)

(245 m)

(215 m)

(168 m)

(150 m)

(100 m)

800'

700'

550'

500'

350'

300'

(90 m)

Variable

quality

1,000'

(300 m)

750'

(230 m)

650'

(200 m)

600'

(185 m)

450'

(135 m)

450'

(135 m)

The transmitters, receivers, and matrix switcher are

designed for and perform best with Extron Enhanced Skew-Free A/V cable terminated in accordance with the TIA/EIA T 568 A wiring standard. CAT 5, 5e, and 6 cables are acceptable, but less preferable. We also recommend the use of preterminated and tested cables. Cables terminated on site should be tested before use to ensure that they comply with Category 5 speciﬁcations.

The recommendations shown on the preceeding page

apply equally for a transmission line consisting of a single transmitter, the switcher, and receiver; and for a transmision line that encompass a transmission daisy chain. For example, the maximum suggested range for 1024 x 768 video is 350’ (100 m) with Pre-Peak off and 400’ (120 m) with Pre-Peak on whether the transmission line consists of the transmitter, switcher, and a single receiver or a transmitter, the switcher, and three daisychained receivers.

For daisy-chained units, the ﬁrst receiver in the chain

should be at least 50’ (15 m) from the switcher when the Pre-Peak feature is on.

For daisy-chained units, any receiver in the chain closer

than 350’ (105 m) may experience some form of overpeaking when the Pre-Peak switch is on.

N N

For any transmission distances above 350' (100 m), turn

on the transmitting device's (MTP transmitter or MTPX) prepeak function. See the MTP Transmitter/Receiver User's Manual and/or the Output Pre-Peaking SIS commands on page 4-4.

Resolutions marked with an asterisk (*) in these tables

have the same range speciﬁcations at 75 Hz.

The minimum TP cable length should be 50' (15m).

It is possible to exceed the recommended distance; however,

image quality may be reduced.

The MTPX output can be extended by 50 feet (15 m) for

those outputs that have a Pre-Peak feature that is turned on.

Introduction, cont’d

MTPX Twisted Pair Matrix Switcher

Chapter Two

1-6

Installation

Rear Panel

Front Panel

MTPX • Introduction

Refer also to the MTPX User’s Manual at www.extron.com.

Installation

Rear Panel

LOCAL INPUTS

RGB

9 8

INPUT

SELECT

LISTED

1T23

LOCAL

I.T.E.

RJ-45

9 8

LOCAL OUTPUT

AUDIO

MONO AUDIO OUTPUTS

6 4

RGB

LOCAL

123

RJ - 45

INPUT SELECT

12345678

910111213141516

INPUTS

OUTPUTS

1234 5678

910111213141516

Figure 2-1 — MTPX 1616 rear panel

The MTPX 816 and MTPX 168 are housed in the same

2U enclosureas the MTPX 1616, but have fewer input and/or output connectors to accommodate their smaller matrix sizes.

126

LOCAL INPUTS

213

456

LOCAL OUTPUTS OUTPUTS

LR1LR2LR3LR4LR5LR6LR1LR2LR3LR4LR5LR6LR7LR

1234 5678 910111213141516

17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

1234 5678 910111213141516

17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32

INPUTS

MONO AUDIO OUTPUTSAUDIO INPUTS

Figure 2-2 — MTPX 3232 rear panel

The MTPX 1632 and MTPX 3216 are housed in the same

3U enclosure as the MTPX 3232, but have fewer input and/or output connectors to accommodate their smaller matrix sizes.

CONTROLCONTROL

RESET

CONTROL

REMOTE

RESET

RS-232/RS-422

Inputs

TP inputs — Connect up to 8, 16, or 32 (depending

on the matrix size) compatible TP inputs to the Inputs RJ-45 connectors.

Local RGB (VGA) inputs — Connect analog

computer-video sources to the Local Inputs 15-pin HD female connectors.

Local audio inputs — Connect balanced or unbalanced

stereo audio inputs to the Audio 5-pole captive screw connectors.

Tip

Sleeve

Tip

Unbalanced Input

Figure 2-3 — Audio input connector wiring

Input Select switches — Set the Input Select DIP

switches for each input that can be either local or on TP cable from an MTP transmitter.

RJ-45 (down) for an input from an MTP transmitter (a)

Local (up) for a local (RGB video and audio) input (

Turn off power to the input and output devices, and

disconnect their power cords.

You must conﬁgure the switcher for the appropriate input

(RS-232 or audio) for each TP input. See “Deﬁning the Audio/RS-232 Wire Pair (and Conﬁguring the Remote Port)“ on page 3-6.

These connectors can also accept HD component video,

component video, S-video, or composite video.

Tip

Ring

Sleeve (s)

Tip

Ring

(high impedance) (high impedance)

Balanced Input

L R

INPUT SELECT

b and c

MTPX 1616 and smaller have Input Select DIP switches

for inputs 1 through 3.

LOCAL

123

RJ - 45

)

2-2

MTPX • Installation

Refer also to the MTPX User’s Manual at www.extron.com. Refer also to the MTPX User’s Manual at www.extron.com.

MTPX 1632 and larger have Input Select DIP switches for inputs 1 through 6.

MTPX • Installation

2-3

Refer also to the MTPX User’s Manual at www.extron.com.

CAUTION Connect the sleeve to ground.

Connecting the sleeve to a negative (-) terminal will damage the audio output circuits.

Unbalanced Output

Balanced Output

L R

Ring

Tip

Sleeve(s)

Tip

Ring

Sleeve(s)

Tip

NO GROUND HERE.

RS-232 Function Pin Function

1 2 3 4 5 6 7 8 9

—

Gnd

— — — —

Not used Tr ansmit Receive Not used Ground Not used Not used Not used Not used

—

TX–

RX–

—

Gnd

—

RX+

TX+

—

Not used Tr ansmit (–) Receive (–) Not used Ground Not used Receive (+) Tr ansmit (+) Not used

RS-422

ENTER PRESET VIEW ESC RGBHV AUDIO

CONTROL IO

CONFIG

MTPX SERIES

MTP MATRIX SWITCHER

MTPX • Installation

Installation, cont’d

2-4

MTPX • Installation

2-5

Outputs

TP outputs — Connect up to 8, 16, or 32 (depending

on the matrix size) compatible MTP receivers to the Outputs RJ-45 connectors.

Local RGB (VGA) outputs — Connect one

or two RGBHV video displays to the Local Outputs (VGA) 15-pin HD female connectors.

N N

Local audio outputs — Connect audio devices, such as audio

ampliers or powered speakers to these four or eight 3.5 mm, Mono Audio (local audio) outputs 5-pole captive screw connectors to receive unamplied, mono line level audio.

These outputs are always outputs 1 and 2.

The video that is output on this (these) connector(s) is

converted from the tied proprietary TP input signal or the local (VGA) input.

This connector can also output HD component video,

component video, S-video, or composite video if that is the video format that was input.

If the video output is NTSC component video, S-video, or composite video, set the output to turn off sync stripping. See the Local video output sync polarity SIS commands on page 4-5.

Remote control

Remote port — If desired, connect a control system or computer

to the rear panel Remote RS-232/RS-422 port.

Figure 2-6 — Remote port connector wiring

Power

Power connector — Plug the switcher into a grounded AC

source.

Front Panel

Figure 2-5 — Audio output connector wiring

These outputs are always outputs 1 through 4 (matrix

sizes up to 1616) or outputs 1 through 8 (matrix sizes 1632 and larger), with the same inputs tied to them as to TP outputs 1 through 4 (8).

Each local output has a volume control. See "Viewing and

Adjusting the Audio Level” on page 3-8.

Figure 2-7 — Front panel conﬁguration port

Conﬁguration port — If desired, connect a control system

or computer to the front panel Conguration (RS-232) port. Use an optional 9-pin D to 2.5 mm mini jack TRS RS-232 cable, part #70-335-01.

Installation, cont’d

MTPX Twisted Pair Matrix Switcher

Chapter Three

2-6

Front Panel Operation

Creating a Tie

Saving or Recalling a Preset

Setting the Front Panel Locks (Executive Modes)

Deﬁning the Audio/RS-232 Wire Pair (and Conﬁguring the Remote Port)

Viewing and Adjusting the Audio Level

Viewing Ties (and Muting Outputs)

MTPX • Installation

Refer also to the MTPX User’s Manual at www.extron.com.

3-2

Refer also to the MTPX User’s Manual at www.extron.com.

3-3

Refer also to the MTPX User’s Manual at www.extron.com.

VIDEO AUDIO

Lit when selected

Off when deselected

Lit when selected Off when deselected

The input LED

lights to indicate

the selection.

3 4 8

ENTER

Output LEDs blink to indicate a potential tie.

Enter LED blinks to indicate the need to confirm the change.

PRESET PRESET

Preset LED blinks.

Press and hold.

2 seconds

Save a preset

PRESET PRESET

Recall a

preset

Preset LED lights.

Press and release.

All input and output buttons with assigned presets light.

The configuration data at assigned preset locations will be overwritten.

ENTER

The LED blinks to indicate that this preset is selected.

The Enter LED blinks to indicate the need to save or recall the preset.

= lit, = unlit= blinking,

MTPX • Front Panel Operation

Front Panel Operation

MTPX • Front Panel Operation

Creating a Tie

1. Press and release the Esc button to clear any input LED, output LED, or control LEDs that may be lit.

2. Press and release the Video and/or Audio I/O button(s) to select or deselect video and/or audio as desired.

3. Press and release the desired input button.

4. Press and release the desired output button(s).

Saving or Recalling a Preset

1. Save a preset — Press and hold the Preset button until the Preset LED ashes.

Recall a preset — Press and release the Preset button.

Audio (RS-232) or video can be broken away (tied by itself)

by selecting only the Video button or only the Audio button.

2. Press and release the desired input or output button.

5. Press and release the Enter button. All LEDs turn off.

3. Press and release the Enter button.

VIDEO AUDIO

ENTER

VIDEO AUDIO

ENTER

I/O

Press and hold the Enter, Video, and Audio buttons simultaneously to turn on Lock mode 2 or to toggle between mode 2 and mode 0.

2 seconds

The Enter, Video, and Audio LEDs blink twice to indicate the mode change. Release the buttons.

I/O

Press and hold the Video and Audio buttons simultaneously to turn on Lock mode 2 or to toggle between mode 1 and mode 2.

2 seconds

The Video and Audio LEDs blink twice to indicate the mode change. Release the buttons.

VIDEO AUDIO

I/O

VIDEO AUDIO

I/O

= lit, = unlit= blinking,

Front Panel Operation, cont’d

Setting the Front Panel Locks (Executive Modes)

The matrix switcher has three levels of front panel security lock that limit the operation of the switcher from the front panel. The three levels are:

Lock mode 0 —• The front panel is completely unlocked. Lock mode 1 —• All changes are locked from the front

panel (except for setting Lock mode 2). Some functions can be viewed.

Lock mode 2 —• Basic functions are unlocked. Advanced features are locked and can be viewed only.

Basic features consist of:

m Making ties m Saving and recalling presets m Setting input audio gain and attenuation m Changing Lock modes

Advanced features consist of:

m Setting audio output mutes m Setting audio output volume m Setting audio/RS-232 wire pair (and front panel

conguration)

Selecting Lock mode 2 or toggling between mode 2 and mode 0

The switcher is shipped from the factory in Lock mode 2.

If the switcher is in Lock mode 0 or mode 1, this procedure

selects mode 2.

Selecting Lock mode 2 or toggling between mode 2 and mode 1

Toggle the lock on and off by pressing and holding the Video button and the Audio button simultaneously for approximately 2 seconds.

If the switcher is in Lock mode 0 or mode 1, this procedure

selects mode 2.

If the switcher in in Lock mode 2, this procedure selects mode 1.

If the switcher in in Lock mode 2, this procedure selects mode 0 (unlocks the switcher).

Toggle the lock on and off by pressing and holding the Enter button, the Video button, and the Audio button simultaneously for approximately 2 seconds.

3-4

MTPX • Front Panel Operation

Refer also to the MTPX User’s Manual at www.extron.com.

MTPX • Front Panel Operation

3-5

ENTER

PRESET VIEW ESC

CONTROL

ENTER PRESET VIEW ESC

CONTROL

1 2 3 4 15 16

VIDEO AUDIO

I/O

Press and hold the Control buttons.

Release the Control buttons.

Lit input LEDs indicate RS-232 is selected. Unlit LEDs indicate audio is selected.

Protocol: RS-422RS-232

After 2 seconds

Both I/O buttons light

with one flashing.

Flashing LED indicates

the baud rate.

9600

Baud

rate:

1152001920038400

All Control buttons light with one flashing.

Flashing LED indicates the baud rate.

1 2 3 4 15 16

Press and release the Input 1 button to toggle the RS-232 / audio setting.

The input changes state; in this example, from an RS-232 input to an audio input.

= lit, = unlit= blinking,

Front Panel Operation, cont’d

Deﬁning the Audio/RS-232 Wire Pair (an

d Conﬁguring the R

1. To enter Conﬁguration mode, simultaneously press and

hold the Enter, Preset, View, and Esc buttons.

emote Port)

2. Release the Control buttons.

These settings are protected when front panel Lock mode 2

is selected. You can view the conﬁgurations in Lock mode 2 but you cannot change them from the front panel; the actions are ignored and the Enter, Video, and Audio LEDs ﬂash. See “Selecting Lock mode 2 or toggling between mode 2 and mode 0” on page 3-4 to unlock the front panel.

3. To change an input’s audio/RS-232 wire pair conguration, press and release the input button to toggle that input’s conguration.

You can also change the Remote port baud rate and/

or protocol by pressing the associated Control and/or I/O buttons.

4. Press and release an output button to exit the Serial Port Selection and Conguration mode.

The Control and I/O LEDs indicate the Remote port baud

rate and protocol as shown.

The input LEDs show the audio/RS-232 wire pair conﬁgurations.

3-6

MTPX • Front Panel Operation

Refer also to the MTPX User’s Manual at www.extron.com.

MTPX • Front Panel Operation

3-7

Refer also to the MTPX User’s Manual at www.extron.com.

AUDIO AUDIO

The Audio LED blinks.

Hold 2 seconds

1 2 3

VIEW ESC

For the input level (gain/attenuation), the View and Esc LEDs display the polarity (attenuation [ ] or gain [ ]).

Press an input button to adjust gain/attenuation.

- or -

Press an output button to adjust the output volume.

Output LEDs display gain or attenuation.

- or -

Input LEDs display

output volume level.

VIEW ESC

button decreases the level.

button increases the level.

= lit, = unlit= blinking,

MTPX • Front Panel Operation

Front Panel Operation, cont’d

3-8

MTPX • Front Panel Operation

3-9

Viewing and Adjusting the Audio Level

1. Press and hold the Audio button until the Audio LED ashes.

2. Press an input or output button. Refer to the MTPX User's

Only the twisted pairs' input levels and only the local

outputs' volume can be adjusted.

Manual, chapter 3, “Operation”, to read the displayed

value.

Viewing Ties (and Muting Outputs)

1. Press the View button. Output LEDs light for outputs that have no ties established.

2. Press an input button. The LEDs for all tied outputs light.

3. Press an output button. The LEDs for the tied input and

4. Press the View button. All input and output LEDs return

If the Audio LED blinks, audio is broken away (switched

separately from video).

If an output LED blinks, that output is muted. To toggle

mute on and off, press and hold the output button for 2 seconds.

all tied outputs light.

to an unlit state.

3. Increase/decrease the level or volume by pressing the Esc (

4. Press and release the Audio button to exit.

) and View (<) buttons.

Front Panel Operation, cont’d

MTPX Twisted Pair Matrix Switcher

Chapter Four

3-10

Remote Control and

Optimizing the Video

Selected SIS™ Commands

Installing and Starting the Control Program

Accessing the HTML Pages

MTPX • Front Panel Operation

Refer also to the MTPX User’s Manual at www.extron.com.

Remote Control and Optimizing the Video

Selected SIS™ Commands

The switchers have Simple Instruction Set (SIS™) commands that you can use for operation and conﬁguration. You can run these commands from a PC connected to either of the switcher’s serial ports. See

Host-to-switcher instructions

The switcher accepts SIS (Simple Instruction Set) commands through either serial port. SIS commands consist of one or more characters per command ﬁeld. They do not require any special characters to begin or end the command character sequence. Each switcher response to an SIS command ends with a carriage return and a line feed (CR/LF = ]), which signals the end of the response character string. A string is one or more characters.

and j, on page 2-5, for connection information.

The table that begins on the next page is a partial list

of SIS commands. For a complete listing, refer to the

MTPX User's Manual.

4-2

MTPX • Remote Control and Optimizing the Video

Refer also to the MTPX User’s Manual at www.extron.com.

Command ASCII command

(host to switcher)

Create ties

 •Commandscanbeenteredback-to-backinastring,withnospaces.Forexample:1*1!02*02&003*003%4*24$.

MTPX • Remote Control and Optimizing the Video

Refer also to the MTPX User’s Manual at www.extron.com.

Thematrixswitcherssupport1-,2-,and3-digitnumericentries(1*1!,02*02&,or003*003%).

•

 The& tiecommandforRGBandthe%tiecommandforvideocanbeusedinterchangeably.

 The&read tiecommandforRGBandthe%read tiecommandforvideocanbeusedinterchangeably.

Tie input and audio

Tie input only

Read RGB output tie

Read video output tie

Read audio output tie

X! to output X@, video

Example:

X! to output X@, RGBHV

Example

(see2ndNote,above):

X! to output X@, video

Example

(see2ndNote,above)

X! to output X@, audio

Example:

X!*X@

1*3!

X!*X@

10*4&

X!*X@

7*5%

X!*X@

24*04$

Response

(switcher to host)

! Out

Out03

& Out

Out04

% Out

Out05

$ Out

Out04

X!] X!] X!]

X@•InX!•

•

In01•All

X@•InX!•

•

In10•RGB

X@•InX!•

•

In07•Vid

X@•InX!•

•

In24•Aud

All

]

RGB

Vid

]

Aud

]

Additional description

Tie input X!‘s video and audio to output X@.

Tie input 1 video and audio to output 3.

Audio breakaway.

Tie input 10 RGB to output 4.

Audio breakaway.

Tie input 7 video to output 5.

Audio breakaway.

Tie input 24 audio to output 4.

RGBHV input X! is tied to output X@.

Video input X! is tied to output X@.

Audio input X! is tied to output X@.

4-3

= Input number

= Output number 01 – (maximum number of outputs for your model)

00 – (maximum number of inputs for your model) (00 = untied)

Refer also to the MTPX User’s Manual at www.extron.com.

Command ASCII command

MTPX • Remote Control and Optimizing the Video

Remote Control and Optimizing the Video, cont’d

4-4

MTPX • Remote Control and Optimizing the Video

4-5

(host to switcher)

Response

(switcher to host)

Audio/RS-232 TP input (wire pair 3 and 6) conﬁguration

Congure input as audio

Congure input as RS-232

Read TP input conguration

*0\ TypX!*0

*1\ TypX!*1

X#]

Output pre-peaking

Set output pre-peaking on

Set output pre-peaking off

Read output pre-peaking setting

EX$ EX$ EX$

}

*1Opek

}

*0Opek

} X%]

Opek

OpekX$*1

OpekX$*0

]

] ]

Additional description

Dene the audio/RS-232 input as audio, such as provided by an MTP 15HD A transmitter.

Dene the audio/RS-232 input as bi-directional serial communications, such as provided by an MTP 15HD RS transmitter.

Show the audio/RS-232 wire pair input denition.

Pre-peak the TP output.

Do not pre-peak the TP output.

X! = Input number

= Audio/RS-232 wire pair input type 0 = audio

1 = RS-232

= Pre-peakable output number 01 – half of your matrix switcher's outputs (such as 04 for MTPX 168)

= Pre-peaking 0 = off

Command ASCII command

(host to switcher)

Local video output sync polarity

The command structure differs, depending on the size of the matrix. Matrix sizes 1616 and smaller do not need the local output variable

(X&). Matrix sizes 1632 and larger require the variable.

Set local output polarity (matrix size 1616 and smaller)

Example:

Set local output polarity (matrix size 1632 and larger)

Example:

Read local output sync settings (matrix size 1616 and smaller)

Read local output sync settings (matrix size 1632 and larger)

EX^

EX&*X^

EX&

01 – (maximum number of inputs for your model)

}

Opol

}

0Opol

}

Opol

}

2*0Opol

} X^]

Opol

} X^]

Opol

Response

(switcher to host)

X^]

Opol

]

Opol00

OpolX&*

Opol2*00

X^]

]

Additional description

Set the horizontal and vertical sync polarity for a local output.

Set the local output to output negative horizontal and vertical sync.

Set the horizontal and vertical sync polarity for local output

Set local output 2 to output negative horizontal and vertical sync.

X^ = Local output sync polarity 0 = H- / V- (default)

1 = H+ / V 2 = H- / V+ 3 = H+ / V+ 4 = NTSC (no sync stripping)

= Local video output number 1 (matrix sizes 1616 and smaller)

1 or 2 (matrix sizes 1632 and larger)

Refer also to the MTPX User’s Manual at www.extron.com.

Command ASCII command

MTPX • Remote Control and Optimizing the Video

Remote Control and Optimizing the Video, cont’d

4-6

MTPX • Remote Control and Optimizing the Video

4-7

(host to switcher)

Audio or RS-232 mute commands

Audio or RS-232 mute

Audio or RS-232 unmute

Read audio or RS-232 mute

Global audio or RS-232 mute 1*Z

Global audio or RS-232 unmute 0*Z

View output mutes

Example:

MTPX 3216

The “Mut” portion of the response appears only when the switcher is in Verbose mode 3. See the Verbose mode command on page 4-10.

X@ = Output number 01 – (maximum number of outputs for your model)

= Mute 0 = off (unmuted)

1 = on (muted)

= Audio or RS-232 mute: 0 = no mutes

2 = audio or RS-232 mute

*1Z AmtX@*1

*0Z AmtX@*0

EVM}

Response

(switcher to host)

] ]

X*]

]

Amt1

]

Amt0

X(n]

, ...

Mut0220200002202000

Additional description

Mute output X@ audio (audio off).

Unmute output X@ audio (audio on). 1 = mute on, 0 = mute off.

Mute all audio outputs.

Unmute all audio outputs.

Each X( response is the mute status of an output, starting from output 1. n = the maximum number of outputs for this model.

Output 2, 3, 5, 10, 11, and 13 audio or RS-232

]

are muted. All other outputs are unmuted.

Command ASCII command

(host to switcher)

Audio input gain and attenuation

The set gain (G) and set attenuation (g) commands are case sensitive.

Set input audio level to +dB value

Example:

Set input audio level to -dB value

Increment gain

Example:

Decrement gain

Example:

Read input level

X!*X1)

1*2G

X!*X1@ X!

+G InX!•Aud

5+G

-G InX!•Aud

7-G

Audio output volume

Set the audio volume to a specic value

Example:

Increment volume

Example:

Decrement volume

Read output volume

X@*X1#

1*50v

+V OutX@•Vol

1+V

-V OutX@•Vol

Response

(switcher to host)

G InX!•Aud

In01•Aud+02

g InX!•Aud

In05•Aud+03

In07•Aud-09

X1!]

V OutX@•Vol

Out01•Vol50

Out01•Vol51

X1#]

X1!]

] X1!] X1!]

] X1!]

]

X1#]

]

X1#]

]

X1#]

Additional description

Set input 1 audio gain to +2 dB.

Increase gain by 1 dB.

Increase audio input 5 level from +2 dB to +3 dB.

Decrease gain by 1 dB.

Decrease audio input 7 level from -8 dB to -9 dB.

Set output 1 volume to 79%.

Increase volume by 1 step.

Decrease volume by 1 step.

= Input number

X1)

= Audio gain 0 – 24 (1 dB/step)

X1!

= Numeric dB value –18 to +24 (45 steps of gain or attenuation) (Default = 0 dB)

X1@

= Audio attenuation 1 – 18 (1 dB/step)

= Output number

X1#

= Volume adjustment range 0 – 64 (1 dB/step except for 0-to-1, which is 22 dB) (default = 64 [0 dB])

01 – (maximum number of inputs for your model)

Refer also to the MTPX User’s Manual at www.extron.com.

Command ASCII command

MTPX • Remote Control and Optimizing the Video

Remote Control and Optimizing the Video, cont’d

4-8

MTPX • Remote Control and Optimizing the Video

4-9

(host to switcher)

Save and recall presets

If you try to recall a preset that is not saved, the matrix switcher responds with the error code E11.

Save current conguration as a global preset

Example:

Recall a global preset

Example:

X1$

Lock (executive) modes

See “Setting the front panel locks (Executive modes)” on page 3-4 for more information on the Lock modes.

Lock all front panel functions 1X

Lock advanced front panel functions 2X

Unlock all front panel functions 0X

View lock status X

X1$

= Global or room preset # 0 - 32

X1%

= Lock mode 0, 1, or 2

Response

(switcher to host)

X1$]

Spr

]

Spr09

X1$]

Rpr

]

Rpr05

]

Exe1

]

Exe2

]

Exe0

X1%]

Additional description

Command character is a comma.

Save current ties as preset 9.

Command character is a period.

Recall preset 5, which becomes the current conguration.

Enable Lock mode 1.

Enable Lock mode 2.

Enable Lock mode 0.

Command ASCII command

(host to switcher)

Information requests

Information request I

Example:MTPX 3216

Request part number N Query controller rmware version Q

Example:

X1^

= Inputs Total number of inputs for this switcher

X1&

= Outputs Total number of outputs for this switcher

X1*

= Part number

X1(

= Firmware version number to second decimal place (x.xx)

Response

(switcher to host)

X1^XX1&•AX1^XX1&]

V32X16•A32X16

] X1*] X1(]

]

1.23

Additional description

X1^XX1&

The factory-installed controller rmware version is 1.23 (sample value only).

is the video matrix size.

is the audio matrix size.

Refer also to the MTPX User’s Manual at www.extron.com.

MTPX • Remote Control and Optimizing the Video

Remote Control and Optimizing the Video, cont’d

4-10

MTPX • Remote Control and Optimizing the Video

4-11

Installing and Starting the Control Program

Another way to operate the switcher, to set the skew adjustments, the level and peaking, and the output pre-peaking (see "Optimizing the video", beginning on page 4-12), is via the Windows program is contained on the Extron Software Products CD-ROM (included with the switcher). Run this program on a PC connected to either of the switcher’s serial ports. See h and j, on page 2-5, for connection information. The program must be installed on a Windows-based computer and cannot be run from the CD-ROM.

Installing the program

1. Insert the CD-ROM into the drive. The installation program should start automatically.

The Extron software CD window appears.

-based Matrix Switchers Control Program. This

For details on operating the program, refer to the

MTPX User's Manual, chapter 5, “Matrix Software”.

4. Follow the on-screen instructions. The installation program creates a C:\Program Files\Extron\ Matrix_Switchers directory and an “Extron Electronics\ Matrix Switchers” group folder. It installs the following four programs:

• MATRIX Switcher+ Control Program

• MATRIX Switcher+ Help

• Uninstall MATRIX Switcher

• Check for Matrix Updates

Starting the program

1. Click Start > Programs > Extron Electronics > Matrix Switchers > MATRIX Switcher + Control Pgm.

The Comm Port Selection window appears.

2. Click the Software tab.

3. Scroll to the Matrix Switchers program and click

If the installation program does not self-start, run

Launch.exe from the CD.

Install.

2. Choose the comm (serial) port that is connected to the switcher.

Click OK.

The Matrix Switchers Control Program is ready for

Although IP [LAN] is available for selection, the switcher

does not have an Ethernet port. Do not select IP [LAN].

Check the baud rate displayed in the

comm port selection window. If you need to change the baud rate, click the Baud button and double-click the desired baud rate.

operation.

Refer also to the MTPX User’s Manual at www.extron.com.

Remote Control and Optimizing the Video, cont’d

MTPX • Remote Control and Optimizing the Video

4-13

Optimizing the video

Most MTP transmitters and half of the MTPX TP outpust have a pre-peaking feature. Many MTP receivers have level/peaking and skew adjustments. Set these features as follows for the best image quality:

1. For inputs from MTP T 15HD products only — If the cable between the MTP transmitter and the MTPX Plus is > 300', turn the transmitter’s Pre-Peak switch on. For shorter cables, turn the switch off.

2. For outputs — If the cable between the MTPX and the receiver is > 300', turn the MTPX’s Pre-Peak feature on. For shorter cables, turn the feature off. Set the feature as follows:

a. In the Matrix Switchers Control Program, click Tools >

MTPX Config settings and then check or uncheck the appropriate Pre-Peaking box.

4-12

3. If level/peaking and skew adjustments are available on

MTPX • Remote Control and Optimizing the Video

MTPX Pre-Peak is available on the ﬁrst half of the MTPX

Plus outputs (for example outputs 1 through 4 for an MTPX Plus 168.

Unless the TP cable lengths are changed, these settings

should need to be made only once, during installation.

the connected receiver(s), set them in accordance with the applicable MTP product manual.

Refer also to the MTPX User’s Manual at www.extron.com.

Extron electronic MTPX 1616, MTPX 1632, MTPX 168, MTPX 3216 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

About this Manual

About the MTPX Switchers

Twisted Pair (TP) Cable Transmission Distance

Rear Panel

INPUTS

Outputs

Remote control

Power

Front Panel

Creating a Tie

Saving or Recalling a Preset

Setting the Front Panel Locks (Executive Modes)

Selecting Lock mode 2 or toggling between mode 2 and mode 0

Selecting Lock mode 2 or toggling between mode 2 and mode 1

Viewing and Adjusting the Audio Level

Viewing Ties (and Muting Outputs)

Selected SIS™ Commands

Host-to-switcher instructions

Installing and Starting the Control Program

Installing the program

Starting the program

Optimizing the video
