Page 1
ED930F
1080p Full HD True Day / Night
Indoor IR Dome Camera
Features
• 1080p Full HD with high flexibility and performance for astounding ima ge
• 1/2.9" Sony 2.24MP CMOS sensor, delivering amazing high sensitivity
• Varifocal 2.8-12mm DC iris lens to capture the d esi red field of view
• Extended IR range of up to 30m / 100ft. with 18 LEDs (depending on scene IR reflectivity)
• D-WDR to improve the visibility under high contrast scene
• 3D-Noise Reduction ensures less blurry moving subjects, vivid and high SN ratio images even
under low light environments
• Supports 1080p, 720p & 960H analog signal outputs, which can be easily switched using OSD
Joystick
• The flexible angle viewing with its 3-Axis rotation design allows wall or ceiling mounting
• Ea sy lock inst alla t ion by screwing the b ase p lat e to the surfa ce a nd then locking the c amera t o
the base plate without mounting screws
• eZ Controller function: Control cam era OSD settings and PTZ operation directly from DVR end
Page 2
Dimensions
Accessory
BA-ED05
L-Shaped Plastic bracket
Page 3
Find Out More At:
Specifications
scene IR reflectivity)
Model No. ED930F
English / Simplified Chinese /
Pickup Device 1/2.9" Sony 2.24MP CMOS OSD Languages
Traditional Chinese / German / French /
Italian / Spanish / Polish / Russian /
Portuguese / Netherlands / Turkish
Video Format NTSC / PAL (Can be switched via OSD) DNR 2DNR / 3DNR, Off
Effective Pixels 1920 (H) x 1080 (V) Defog Off / Auto
Scanning System Progressive Scan D-WDR On / Off / Auto
Sensitivity 0 Lux with IR On Sens-up Off / Auto (x2 ~ x30)
Electronic
Auto / Manual (x30 ~ 1/50,000) / FLK Mirror Off / Mirror / V-Flip / Rotate
Shutter
Gamma
0.45 Motion Detection Off / On for 4 selectable zones
Correction
Lens Type DC Iris 2.8-12mm, F1.4 Privacy Mask Off / On for 4 selectable zones
BLC Off / BLC / HS BLC Selectable Environmental Indoor
AGC 0 ~ 15 Levels Power Source 12VDC / 24VAC~
ATW / AWC-SET / Indoor / Outdoor /
Power
12VDC: 3.7W max. /
White Balance
Manual / AWB
Consumption
24VAC~: 3.5W max.
Operating
Sync. Mode Internal
-10°C ~ 50°C / 14°F ~ 122°F
Temperature
Day / Night Ext, Auto, Color, B/W Humidity Less than 80%
UTC Function Supported Dimensions 133 x 96.6mm / 5.24" x 3.8"
IR LEDs 18 Units Weight 360g / 0.79lb
IR Distance
Up to 30m / 100ft. (Depending on
Certificates CE, FCC, RoHS
EverFocus Taiwan HQ:
TEL: +886 2 2698 2334
www.everfocus.com.tw
marketing@everfocus.com.tw
EverFocus USA - California:
TEL: +1 626 844 8888
www.everfocus.com
sales@everfocus.com
International Branch Offices:
Germany, China, Japan
