Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
Contents
2
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

About this manual

This manual is valid for all field evaluation units CES-FD-AP-M-01-… (Multicode) and CES-FD-AP-U-01-… (Unicode).

Correct use

The field evaluation units series CES are safety devices for monitoring movable safety guards.
The complete safety system consists of three components:
coded actuator (transponder), read head and field evaluation unit.
- In combination with a separating safety guard and the machine control, this safety system prevents dangerous machine movements from occurring while the safety guard is open. A stop command is triggered if the safety guard is opened during the dangerous machine function.
Before safety components are used, a risk assessment must be performed on the machine, e. g., in accordance with:
Ì EN ISO 13849-1, Safety of machinery. Safety related parts of control systems.
General principles for design
Ì EN ISO 12100, Safety of machinery – General principles for design – Risk as-
sessment and risk reduction
Ì IEC 62061, Safety of machinery. Functional safety of safety-related electrical,
electronic and programmable electronic control systems.
Correct use includes compliance with the relevant requirements for installation and operation, for example
Ì EN ISO 13849-1, Safety of machinery. Safety related parts of control systems.
General principles for design
Ì EN 1088, Safety of machinery. Interlocking devices associated with guards.
Principles for design and selection
Ì EN 60204-1, Safety of machinery. Electrical equipment of machines. General
requirements
Ì EN 60947-5-3, Specification for low-voltage switchgear and controlgear. Con-
trol circuit devices and switching elements. Requirements for proximity devices with defined behavior under fault conditions
The unit must be used only in conjunction with the CES read heads and CES ac­tuators from EUCHNER. On the use of different actuators, EUCHNER provides no warranty for safe function.
3
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
Important!
Ì The user is responsible for the integration of the device into a safe overall
system. For this purpose, the overall system must be validated, e.g. in ac­cordance with EN ISO 13849-2.
Ì In the estimation of the PL for the overall system, a maximum value of 100
years can be assumed for the MTTFd according to the limit value in EN ISO 13849-1:2008, section 4.5.2. This corresponds to a minimum value for the PFHd of 2.47x10-8/h.
Ì Correct use requires observing the permissible operating parameters (see
Technical data).
Ì If a product data sheet is included with the product, the information on the
data sheet applies in case of discrepancies with the operating instructions.
Ì It is only allowed to use components that are permissible in accordance with
the table below.

Possible combinations for CES components

Field evaluation unit Read head
CES-A-LMN-SC
CES-FD-AP-M-…
CES-FD-AP-U-…
Key to symbols
CKS-A-L1B-SC-SC
CES-A-LMN-SC
CKS-A-L1B-SC-SC
077790
113130
077790
113130
CES-A-BMB
077791
Combination possible
Actuator
CKS-A-BK1-RD
113461
Important: Key adapter CKS must not be used as a lockout mechanism in combination with multi­code evaluation.
4
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Exclusion of liability and warranty

In case of failure to comply with the conditions for correct use stated above, or if the safety instructions are not followed, or if any servicing is not performed as required, liability will be excluded and the warranty void.

General safety instructions

Safety switches fulfill personal protection functions. Incorrect installation or tamper­ing can lead to fatal injuries to personnel.
Check the safe function of the safety guard particularly
Ì after any setup work
Ì after the replacement of a CES component
Ì after an extended period without use
Ì after every fault
Independent of these checks, the safe function of the safety guard should be checked at suitable intervals as part of the maintenance schedule.
Warning!
Important!
Danger of fatal injury in the event of incorrect connection or incorrect use.
Ì Safety switches must not be bypassed (bridging of contacts), turned away,
removed or otherwise rendered ineffective. On this topic pay attention in particular to the measures for reducing the pos­sibility of bypassing from EN 1088:1995+A2:2008, section 5.7.
The device is only allowed to be installed and placed in operation by authorized personnel
Ì who are familiar with the correct handling of safety components Ì who are familiar with the applicable EMC regulations Ì who are familiar with the applicable regulations on health and safety and ac-
cident prevention
Ì who have read and understood the operating instructions
Prior to use, read the operating instructions and keep these in a safe place. Ensure that the operating instructions are always available during mounting, setup and servicing work. EUCHNER cannot provide any warranty in relation to the readability of the CD for the storage period required. For this reason you should archive a printed copy of the operating instructions. If you should lose the operating instructions, you can download this document from www.EUCHNER.de.
5
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Function

Field evaluation units series CES-FD-AP make it possible to evaluate CES read heads in the field. The safety outputs on the field evaluation units are connected to the machine control.
The system meets the following safety requirements:
Ì Safety category 4, PLe according to EN ISO 13849-1 Ì Redundant design of the circuit in the unit with self-monitoring Ì This means that the safety system still functions even if an internal component
fails
Ì The switch state of the semiconductor outputs is continuously monitored inter-
nally
Ì Short circuit detection at the safety outputs by pulsed signals
The following switch-on condition applies for the safety outputs FO1A and FO1B (see also System state table and section Typical system times):
Ì Safety guard closed
The system consists of three components: coded actuator (transponder), field evaluation unit and read head.
The read head is connected to the field evaluation unit and reads the actuator code.
Every EUCHNER actuator supplied has an electronic coding (unique coding) that is read by the read head. Only if a correct coding is detected does the system accept the actuator. The code in an actuator cannot be reprogrammed.
Unlike systems with unique code detection, on multicode systems a specific code is not requested but instead it is only checked whether the actuator is of a type that can be detected by the system (multicode detection). There is no exact com­parison of the actuator code with the code defined in the safety switch (unique code detection).
The read head is fastened to the fixed part of the safety guard.
The actuator attached to the movable part of the safety guard is moved towards the read head by closing the door. The read head is connected to the field evaluation unit. When the switch-on distance is reached, power is supplied to the actuator by the read head by induction and data can be transferred.
If a permissible code is detected, the safety outputs are released.
Due to the combination of dynamic polling of the actuator and the redundant, diverse design of the safety electronics with the two feedback safety outputs, the safety switch will enter the safe state with every detectable fault.
When the safety guard is opened, the safety outputs switch off the safety circuit and the monitoring output OD (optional) is switched off. The state of the safety outputs is monitored internally by two microprocessors.
If faults are detected, the safety circuit is switched off and the DIA LED illuminates. In case of devices with a monitoring output OI, the output is switched on.
The field evaluation unit has a redundant switching design with self-monitoring. This means that the safety system is still effective even if a component fails.
The system is designed so that failures will not result in the loss of the safety func­tion. The occurrence of failures is detected by cyclic self-monitoring at the latest on the next demand to switch on the safety outputs (e.g. on starting).
If the safety door with the actuator should settle over time, the actuator can drift out of the read head operating distance. The device recognizes this situation and indicates that the actuator is in the limit range. This allows the safety door to be readjusted in time.
6
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Mounting

Caution!
Risk of damage to equipment as a result of incorrect installation. The read head must not be used as a mechanical end stop.
Ì Fit an additional end stop for the movable part of the safety guard.
Important!
Ì From the assured switch-off distance S
down.
, the safety outputs are safely shut
ar
Ì When mounting several read heads, observe the stipulated minimum dis-
tance to avoid mutual interference.
- For CES-A-LMN s
Note the following points:
= 20 mm
min
min. 20 mm
Ì Actuator, read head and field evaluation unit must be easily accessible for in-
spection and replacement.
Ì The switching operation must only be triggered by the specific actuator desig-
nated for this purpose. For permissible combinations please see the table of possible combinations on page 4.
Ì Actuator and read head must be fitted so that
Ì the front faces are at the minimum switch-on distance 0.8 x S
when the safety guard is closed (see section Operating distances). A mini­mum distance dependent on the actuator must be maintained for a side ap­proach direction: - For CES-A-LMN 1.2 mm
Ì when the safety guard is open up to the distance S
tance), a hazard is excluded.
(assured switch-off dis-
ar
or closer
ao
Ì the actuator is positively mounted on the safety guard. Ì pay attention to the maximum tightening torque for the field evaluation unit
mountings of 1 Nm.
7
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Electrical connection

Warning!
In case of an error, loss of the safety function through incorrect connection.
Ì To ensure safety, both safety outputs (FO1A and FO1B) must always be
evaluated.
Ì Monitoring outputs must not be used as a safety output. Ì Lay the connection cables with protection to prevent the risk of short cir-
cuits.
Caution!
Risk of damage to equipment or malfunctions as a result of incorrect connection.
Ì The device generates its own clock signal on the output lines FO1A/FO1B. A
downstream control system must tolerate these test pulses, which may have a duration of up to 0.4 ms. No pulses are output when the safety outputs are switched off.
Ì The inputs on an evaluation unit connected must be positive-switching, as the
two outputs on the safety switch deliver a level of +24 V in the switched-on state.
Ì All the electrical connections must either be isolated from the mains supply by
a safety transformer according to IEC 61558-2-6 with limited output voltage in the event of a fault, or by other equivalent isolation measures (PELV).
Ì The device tolerates voltage interruptions in the operating voltage U
to 5 ms. Voltage interruptions at UB are also output on the safety and moni­toring outputs.
Ì For use and operation as per the requirements, a power supply with the
feature "for use in class 2 circuits" must be used. The same requirement ap­plies to the safety outputs. Alternative solutions must comply with the following requirements: a) Electrically isolated power supply unit with a max. open-circuit voltage of 30
V/DC and a limited current of max. 8 A.
b) Electrically isolated power supply unit in combination with fuse as per UL248.
This fuse should be designed for max. 3.3 A and should be integrated into the 30 V/DC voltage section.
Ì All electrical outputs must have an adequate protective circuit for inductive
loads. The outputs must be protected with a free-wheeling diode for this pur­pose. RC interference suppression units must not be used.
Ì Power devices which are a powerful source of interference must be installed
in a separate location away from the input and output circuits for signal pro­cessing. The cable routing for safety circuits should be as far away as pos­sible from the cables of the power circuits.
Ì In order to avoid EMC interference, the physical environmental and operating
conditions at the installation site of the device must comply with the require­ments according to the standard EN 60204-1:2006, section 4.4.2 (EMC).
of up
B
Important!
If the device does not appear to function when operating voltage is applied (e.g. green STATE LED does not flash), the safety switch must be returned unopened to the manufacturer.
8
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
Particularities for operation on decentralized pe­ripheral systems
The version CES-FD-AP-…-.SI-… (M12, 5-pin; pin 5 not assigned) is optimized for connection to decentralized peripheral systems, such as the ET200 series from Siemens. The devices are connected like an OSSD (e.g. like light curtains).
The 5-pin M12 plug connector can be connected directly to the socket of an IP65 field module (e.g. ET200pro) with aid of the connection cables on page 25. If flying leads are used, connection to IP20 input and output modules (e.g. ET200s) is naturally also possible.
Important!
Observe the following notes prior to connection:
Ì Parameter assignment might be required for the input/output modules (see
application example at www.EUCHNER.de, in the area Download Applica­tionen CES).
Ì Additionally observe notes from the control system manufacturer where nec-
essary.

Safety in case of faults

Ì The operating voltage U
Ì The contacts FO1A/FO1B are short circuit-proof.
Ì A short circuit between FO1A and FO1B is detected by the device.
Ì A short circuit in the cable can be excluded by laying the cable with protection.
is reverse polarity protected.
B
9
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Fuse protection for power supply

The power supply must be provided with fuse protection depending on the current required for the outputs. The following rules apply:
Caution!
Max. current consumption of a switch I
I
= IUB + IOD + I
max
= Switch operating current (45 mA)
I
UB
= Monitoring output load current (max. 50 mA)
I
OD
I
FO1A+FO1B
= Load current safety outputs FO1A + FO1B (2 x max. 150 mA)
FO1A+FO1B
max

Requirements for connection cables

Risk of damage to equipment or malfunctions as a result of incorrect connec­tion cables.
Ì Use connection components and connection cables from EUCHNER Ì On the usage of other connection components, the requirements in the fol-
lowing table apply. EUCHNER provides no warranty for safe function in case of failure to comply with these requirements.
Ì The connection cable for the field evaluation unit must not be longer than
180 m in total.
Ì The connection cable from the field evaluation unit to the read head is only
allowed to be extended with the aid of the extension (order no. 115464).
Ì The read head cable must not be longer than 0.7 m in total.
Observe the following requirements with respect to the connection cables for the connection of the device:
Parameter Value Unit
Conductor cross-section min. 0.14 mm²
R max. 150 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIYY 8x or 5x0.14 mm²
10
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
M8x1 Stecker X2 / plug connector X2
1
4
3
Connector assignment and wire color for field evalu­ation unit CES-FD-AP-.-01…
Connection for the read head (M8, 3-pin)
M8x1 Stecker X2 / plug connector X2
1
4
3
Pin Designation Description Wire color
1 H1 Data wire BN
3 H2 Data wire WH
4 SH Screen -
The switch has a permanently connected piece of cable approx. 200 mm long. With the aid of an extension piece (order. no. 115464) the read head connection can be extended to max. 700 mm.
M12x1 Stecker X1 / plug connector X1
Kodiernase / coding
Device connection for the field evaluation unit with M12 plug con­nector, 5-pin
5-pin (optional) 5-pin,
+UB
0V
FO1A
FO1B
OD
1
5
4
32
Figure 2: Pin assignment, connection cable for the field evaluation unit with M12
S1.1
S1.3
S1.2
S1.4
S1.5
View of connection side on the field evaluation unit
plug connector
Pin
5-pin
5-pin pin 5
not used
1 1 UB Power supply, DC 24 V BN
2 2 FO1A Safety output, channel 1 WH
3 3 0V Ground, DC 0 V BU
4 4 FO1B Safety output, channel 2 BK
5 - OD Monitoring output (optional) GY
Designation Description Wire color
pin 5 not used
+UB
0V
FO1A
FO1B
n.c.
S1.1
S1.3
S1.2
S1.4
S1.5
4
1
5
Coding lug
3
2
11
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Connection

Connect the device as shown in Figure 3.
Important!
The subsystem CES-FD-AP complies with PL e in accordance with EN 13849-1. To integrate the subsystem in a category 3 or 4 structure, it is necessary to monitor the downstream load (the feedback loop must be monitored). These examples show only an excerpt that is relevant for connection of the CES system. The example illustrated here does not show complete system planning. The user is responsible for safe integration in the overall system.
DC 24 V
-F1
-V1
-K1
UB1
0V3
FO1A2
OD5
FO1B4
M12 plug-connector
(5-pin)
CES-FD-AP-...
GND
Figure 3: Connection example CES-FD-AP…
-V2
-K2
-M1
L2 L3
L1
M
~
3
12
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
Warning!
In case of an error, loss of the safety function through incorrect connection.
Ì To ensure safety, both safety outputs (FO1A and FO1B) must always be
evaluated. Single-channel use of the safety outputs leads to a loss of the category in accordance with EN ISO 13849-1.
DC 24 V
A1
0V3
UB1
FO1A2
OD5
FO1B4
-K1
A2
M12 plug-connector
(5-pin)
CES-FD-AP-...
GND
Figure 4: Example of incorrect connection.
-K2
13
14
A1
A2
M M
-M1 -M2
13
14
13
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
Connecting a CES-FD-AP-…-.SI-… to a decentral­ized peripheral system (e.g. ET200 series from Siemens)
Please observe the notes in section “Particularities for operation on decentralized peripheral systems” on page 9 before connecting the device.
PLC
decentralized periphery e.g. ET 200pro
DI
2
1
5
4
UB1
FO1A2
S1: M12 plug-connector
(5-pin)
CES-FD-AP-...-.SI-...
3
0V3
FO1B4
1
n.c.5
DO
2 5
3
4
Figure 4: Connection example for version for connection to decentralized peripheral systems (here: ET200pro)
14
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Setup

LED indicators

LED Color State Significance
Important:
illumi­nated
STATE
DIA
green
red
flashing
illumi­nated

Teach-in function for actuator (only version Unicode)

The actuator must be allocated to the safety switch using a teach-in function before the system forms a functional unit.
During a teach-in operation, the safety outputs and the monitoring output OD (op­tional) are in a high-resistance state, i.e. the system is in the safe state.
Normal operation: Door closed
- Door open
- Actuator in the limit range (further signal functions see status table)
- Internal electronics fault
- Fault at the inputs/outputs
Ì The safety switch disables the code of the previous actuator if teach-in is
carried out for a new actuator. Teach-in is not possible again immediately for this actuator if a new teach-in operation is carried out. The disabled code is deleted again in the safety switch only after a third code has been taught.
Ì The safety switch can only be operated with the last actuator taught. Ì If the switch detects an actuator which has already been taught when in
teach-in standby state, this state is ended immediately and the switch chang­es to normal state.
Ì The actuator being taught is not activated if it is within the operating dis-
tance for less than 60 s.
Actuator teach-in
1. Apply operating voltage to the safety switch.
¨ A self-test is performed for approx. 0.5 s. After this, the LED flashes cycli-
cally three times and signals that it is in standby state for teach-in. Standby state for teach-in remains active for approx. 3 minutes.
2. Move new actuator to the read head.
¨ Teach-in operation starts, green LED flashes (approx. 1 Hz). During teach-in, the
safety switch checks whether the actuator is a disabled actuator. Provided this is not the case, the teach-in operation is completed after approx. 60 seconds, and the green LED goes out. The new code has now been stored, and the old code is disabled.
3. To activate the new actuator code from the teach-in operation in the safety switch, the operating voltage to the safety switch must then be switched off for min. 3 seconds.
15
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Setup (only version Multicode)

1. Apply operating voltage to the device.
¨ The green LED flashes briefly and a self-test is performed.
After this, the LED flashes cyclically one time and signals that it is in standby state.
Warning!
2. Move actuator to the read head (observe distance < S
¨ The green LED illuminates continuously and indicates the detection of the
actuator.
If the green LED is flashing in fast flashing sequences, the actuator is in the limit range. In this case the safety guard must be re-adjusted such that the actuator is completely in the read area.
).
ao

Functional check

After installation and any fault, the safety function must be fully checked. Proceed as follows:
Danger of fatal injury as a result of faults in installation and functional check.
Ì Before carrying out the functional check, make sure that there are no per-
sons in the danger area.
Ì Observe the valid accident prevention regulations.
1. Switch on operating voltage.
Ì The STATE LED then flashes at regular intervals.
2. Close all safety guards.
Ì The machine must not start automatically.
Ì The green STATE LED illuminates continuously.
3. Enable operation in the control system.
4. Open the safety guard.
Ì The machine must switch off and it must not be possible to start it as long as
the safety guard is open.
Ì The green LED STATE flashes at regular intervals.
Repeat steps 2-4 for each safety guard.
16
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

System status table for version Multicode

LED indicator
output
Operating mode
Normal operation
Fault display
Key to symbols
Actuator/
guard position
closed on
closed on
open off
X off
closed off
X off
X off
Safety outputs FO1A
and FO1B
10 Hz (8 s)
STATE (green)
flashes quickly
2 Hz
1 x Normal operation, door open
3 x Defective actuator (e.g. fault in code or code not readable)
4 x Output error (e. g. short circuits, loss of switching ability)
5 x Internal fault (e.g. component faulty, data error)
State
DIA (red)
Normal operation, door closed
Normal operation, door closed, actuator in limit range ¨ Re-adjust door
Fault on the power supply (e.g. Switch-off pulse duration of clocked power supply too long)
LED not illuminated
LED illuminated
LED flashes for 8 seconds at 10 Hz
Important!
3 x
X Any state
LED flashes three times, and this is then repeated
After the cause has been remedied, faults can generally be reset by opening and closing the door. If the fault is still displayed afterward, use the reset function or briefly interrupt the power supply. Please contact the manufacturer if the fault could not be reset after restarting.
If you do not find the displayed device status in the System status table, this indi­cates an internal device fault. In this case, you should contact the manufacturer.
17
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

System status table for version Unicode

LED indicator
output
Operating mode
Normal operation
Teach-in standby
Setup
Fault display
Actuator/
door position
closed on
closed on
open off
open off
closed off
X off
X off
closed off
X off
X off
Safety outputs
FO1A and FO1B
State
STATE (green)
flashes quickly
2 Hz
1 x Normal operation, door open, no actuator taught
3 x Door open, unit is ready for teach-in for another actuator (only short time after power-up)
1 Hz Teach-in operation
3 x Defective actuator (e.g. fault in code or code not readable)
4 x Output error (e.g. short circuits, loss of switching ability)
5 x Internal fault (e.g. component faulty, data error)
DIA (red)
Normal operation, door closed
Normal operation, door closed, actuator in the boundary area ¨ Re-adjust door
Positive acknowledgment after completion of teach-in operation
Fault on the power supply (e.g. Switch-off pulse duration of clocked power supply too long)
LED not illuminated
Key to symbols
Important:
LED illuminated
10 Hz (8 s)
3 x
X Any state
LED flashes for 8 seconds at 10 Hz
LED flashes three times, and this is then repeated
After the cause has been remedied, faults can generally be reset by opening and closing the door. If the fault is still displayed afterward, briefly interrupt the power supply. Please contact the manufacturer if the fault could not be reset after restarting.
If you do not find the displayed device status in the System status table, this indi­cates an internal device fault. In this case, you should contact the manufacturer.
18
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Dimension drawings and technical data

Field evaluation CES-FD-AP-.-01…

Note!
If a product data sheet is included with the product, the information on the data sheet applies in case of discrepancies with the operating instructions.
Dimension drawing CES-FD-AP-.-01…
Ansicht in Richtung X / view in X-direction
Connection cable
for read head
with M8 plug connector
Length of cable piece:
200 mm
Active face
95
4,5
19,5
11
X
30
6
M8x1
Fastening lug with
reinforcement plate
0
0,5 +
75
85
Connection cable
with M12 plug connector
Length of cable piece:
1000 mm
12
LED-Statusanzeige
LED-status indicator
0
-
0,2
3
6,5
Z
5,5
Ansicht in Richtung Z / view in Z-direction
M 12x1
19
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
Technical data CES-FD-AP-.-01…
Parameter Value Unit
min. typ. max. Housing material Plastic PBT Dimensions 95 x 30 x 12 mm Weight 0.04 kg Ambient temperature at U
- With connection cable with plug connector M12
- Connection cable laid rigidly - 20 - + 65
- Connection cable movable - 5 - + 65 Degree of protection IP 67 Safety class III Degree of contamination 3 Installation position Any Connection
- Evaluation
- Read head Operating voltage U
regulated, residual ripple < 5%) For the approval according to
applies Current consumption 45 mA External fuse (operating voltage) 0.25 - 8 A Safety outputs FO1A/FO1B Semiconductor outputs, p-switching, short circuit-proof
- Output voltage U(FO1A)/U(FO1B)
HIGH
HIGH
LOW
Switching current per safety output 1 - 150 mA Utilization category according to EN IEC 60947-5-2 DC-13 24 V 150 mA
Off-state current I Monitoring output OD Semiconductor output p-switching, short circuit-proof
- Output voltage 0.8 x U
- Max. load - - 50 mA Rated insulation voltage U Rated impulse withstand voltage U Resilience to vibration
Switching frequency - - 1 Hz Repeat accuracy R ≤ 10 % EMC protection requirements In acc. with EN IEC 60947-5-3
Reliability values acc. to EN ISO 13849-1
Category 4 Performance Level PL e PFH
d
Mission time 20 years
1) The device tolerates voltage interruptions of up to 5 ms.
2) Values at a switching current of 50 mA without taking into account the cable length.
= DC 24 V
B
Connection cable with plug connector M12x1, 5-pin
Connection cable with plug connector M8x1, 3-pin
(reverse polarity protected,
B
U(FO1A)
U(FO1B)
1)
the following
1)
Operation only with UL Class 2 power supply, or equivalent measure
U
-1.5 - U
B
24 ± 15% (PELV) V DC
U(FO1A)/U(FO1B) 0 1
Caution: outputs must be protected with a free-wheeling diode in case of inductive loads.
r
B
i
imp
- - 75 V
- - 1.5 kV
≤ 0.25 mA
- U
In acc. with EN IEC 60947-5-2
-9
4.5 x 10
/ h
°C
B
B
V DC
V DC
20
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
Typical system times
Ready delay: After switching on, the unit carries out a self-test. The system is
ready for operation only after this time (0.5 s).
Switch-on time of safety outputs: The max. reaction time from the moment when the actuator is at the operating distance (safety door closed) to the moment when the safety outputs switch on T
Risk time according to EN 60947-5-3: If an actuator moves outside the operating distance, the safety outputs FO1A and FO1B are deactivated after a maximum of 260 ms.
Difference time: The safety outputs FO1A and FO1B switch with a slight delay in relation to each other. They have the same signal state at the latest after a dif­ference time of 10 ms.
Test pulses at the safety outputs: The device generates its own clock signal on the output lines FO1A/FO1B. A downstream control system must tolerate these test pulses, which may have a duration of up to 0.4 ms.
This can usually be set up in the control systems by parameter assignment. If parameter assignment is not possible for your control system or if shorter test pulses are required, please contact our support organization.
is 400 ms.
on

Read head CES-A-LMN-SC

Ì Cylindrical design M12 Ì M8 plug connector (snap-action and screw terminals)
Dimension drawing
R eading distance s
4
1)
19,7
32
M12x1
Centre offset m
1)
5
8
1) Clear zone (area of the active face without metal housing)
M8x1
30
37
35
connected
Active face
17
21
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
Technical data
Parameter Value Unit
min. typ. max.
Housing material Nickel-plated CuZn housing sleeve
Dimensions M12 x 1, length 38 mm
Weight 0.2 kg
Ambient temperature -20 - +70 °C
Ambient pressure (only of active face in installed condition) - - 10 bar
Degree of protection IP67
Installation position Any
Method of operation Inductive
Power supply Via evaluation unit
In combination with actuator CES-A-BMB on field evaluation unit CES-FD-AP-.-01-…
Assured switch-off distance S
Operating distance for center offset m = 0
- Switch-on distance - 5 -
- Assured switch-on distance S
- Switching hysteresis 0.05 0.2 -
Connection M8 plug connector (snap-action and screw terminals), 3-pin
Connection cable - - 0.7 m
1) These values apply for surface installation of the read head in steel.
ar
ao
1)
- - 10
3.4 - -
Plastic PBT GF20 cap
mm
Note
Typical operating distance
(Only in combination with field evaluation unit CES-FD-AP-.-01-… and actuator CES-A-BMB)
Y
8
8
6
6
8
X
Figure 5: Typical operating distance
A minimum distance of s = 1.2 mm must be maintained.
The read distance may vary depending on the installation situation
6
4
2
2
2
4
4
6
8
6
8
Z
22
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Actuator CES-A-BMB

Ì Cylindrical design M12 x 75 Ì In combination with read head CES-A-LMN-SC
(with read head CES-A-LNA…/LCA… operating distance on request)
Dimension drawing
0,80
11
M12x0,75
6
Active face
Notes
Ì The actuator can be screwed into the M12 x 0.75 thread provided with the aid
of an insertion tool (order no. 037 662).
Ì Flush installation of the actuator in steel is allowed.
Technical data
Parameter
Housing material Stainless steel
Dimensions M12 x 0.75, depth 6 mm
Weight 0.002 kg
Ambient temperature -25 - +70 °C
Degree of protection IP67
Installation position Active face opposite read head
Power supply Inductive via read head
min. typ. max.
Value
Unit
23
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
40
83
40
∅

Key adapter CKS

Ì Integrated CES read head Ì M8 plug connector
Dimension drawing
Key adapter Key
70,5
LED
75
8
76
67
max. 4 mm
4 M
(Rubber seal) Screw clamp element
1,5
Plug connector M8
113461
CKS
FR
∅
25,4
31
Aktive face (front and rear)
5
50 10
84
Important!
Ì Key adapter CKS must not be used as a lockout
32
mechanism in combination with multicode evalua­tion.
Ì The key is not included with the key adapter and
Cable outlet angled plug connector
must be ordered separately.
Technical Data
Parameter Value Unit
min. typ. max
Key adapter
Housing material Plastic (PA 6 GF30)
Weight 0.13 kg
Ambient temperature -20 - +70 °C
Degree of protection IP67
Installation position On the front
Mounting cut-out according to DIN 43700 33 x 68 mm
Operating distance
Assured switch-off distance s
Assured switch-on distance s
Switching hysteresis - 1 -
Connection to evaluation unit Plug connector M8
Cable length - - 0.7 m
LED indicator white: valid key detected
Key
Housing material Plastic (PC)
Weight 0.004 kg
Ambient temperature -20 - +70 °C
Degree of protection acc. to IEC 60529 IP67
Power supply Inductive via read head
1) Referred to the stop of the inserted key.
1)
ar
ao
- - 35
2 - -
(in installed state)
mm
(male socket, 3-pin)
24
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Ordering information and accessories

Designation Version Order
Field evaluation unit CES-FD-AP-M-01-USI-115534
Field evaluation unit CES-FD-AP-U-01-USI-119865
Extension for connection cable with M12 plug connector, 5-pin
Extension for read head cable with M8 plug connector, 3-pin
Read head CES-A-LMN-SC
Actuator CES-A-BMB
Insertion tool
Key adapter CKS-A-L1B-SC-113130
Key CKS-A-BK1-RD-113461
Multicode, connection cable PUR with M12 plug connector,
5-pin, pin 5 not used
Unicode, connection cable PUR with M12 plug connector, 5-pin,
pin 5 not used
5 m, PVC 100183
10 m, PVC 100184
20 m, PVC 100185
0.4 m, PUR
M12x1, length 38 mm with plug connector M8, 3-pin 077790
M12x0.25, depth 6 mm 077791
For actuator CES-A-BMB 037662
Screw clamp elements included 113130
for key adapter CKS,
color red
no.
115534
119865
115464
113461
25
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Inspection and service

Warning!
Loss of the safety function because of damage to the system. In case of damage, the related component must be replaced completely. Only accessories or spare parts that can be ordered from EUCHNER may be replaced.
Regular inspection of the following is necessary to ensure trouble-free long-term operation:
Ì Check the switching function (see section Functional check)
Ì Check the secure fastening of the devices and the connections
Ì Check for soiling
No servicing is required; repairs to the device are only allowed to be made by the manufacturer.
Note!

Service

The year of manufacture can be seen in the lower right corner of the rating plate. The current version number in the format (V X.X.X) can also be found on the device.
The safety door must be re-adjusted when the device indicates that the actuator is in the limit range.
If service support is required, please contact:
EUCHNER GmbH + Co. KG
Kohlhammerstraße 16
D-70771 Leinfelden-Echterdingen
Service telephone:
+49 711 7597-500
E-mail:
info@euchner.de
Internet:
www.euchner.de
26
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…

Declaration of conformity

27
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
28
Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-…
29
More than safety.
Euchner GmbH + Co. KG Kohlhammerstraße 16 D-70771 Leinfelden-Echterdingen
info@euchner.de www.euchner.de
Edition: 116267-03-05/14 Title: Operating Instructions Field Evaluation Unit CES-FD-AP-.-01-… (translation of the original operating instructions) Copyright: © EUCHNER GmbH + Co. KG, 05/2014
Subject to technical modifications, no responsibility is accepted for the accuracy of this informa­tion.
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
