ETS DBDR-01C, DBDR-02C User Manual

CONTENTS

2

1. Parts description

2. Cautions

2-1 Caution ! Operation Guide .............................................. 6

2-2 Use of SD memory card ................................,,,,,,........... 8

3. Functions

4. Installation instructions

4-1. Installation order of the product ................................ 12

4-2. Installation order for viewer program ......................... 14

4-3. Viewing saved images in SD Card ............................. 20

5. Specifications

1. Parts description

Main body

3

Camera Lens

Recording button

SD Memory Card Slot

Power LED

On indicates enough
battery power to operate

REC LED

On indicates recording

Main body

4

1. Parts description

DC power connection

Video Output(Audio Output:Optional)

Data In

Camera Case

Mounting
Bracket

Contents of the product

5

1. Parts description

Automobile Video Black
Box, SD card & Reader

Power cable

Video output cable Holder & Adhesive

Tape

Remote Controller
(Optional)

• User Manual and program
installation CD

• RemoteController(Optional)

If any of these items is missing
or damaged, contact your
dealer or installer immediately
for repair or replacement.
Keep the package for future
storage or shipping.

2. Cautions

2-1 CAUTION! OPERATION GUIDE

6

Do not use water or any solvent when cleaning the
device or inside the car. (It may cause damage to the
product, fire or electric shock.)

Tunnels, backlight and nighttime may prevent from
optimal recording.

Do not attempt to open, repair or modify device
(Manufacture will not be responsible for any problems
caused by user.)

Do not operate the device while driving. (It can lead to
accident)

After a severe vibration or shock is applied to the
device, please recheck and readjust device setup
location while vehicle is still and relatively flat
location. (Device might have trouble receiving GPS
signal, image or voice signal.)

Be sure the device has clear view to sky inside of
windshield and not covered while mounted inside of
car. (It may cause trouble in receiving GPS signal.)

Our device is produced and designed mainly for recording and saving
audio and video signals of the front and rear view (optional), but it does
not guarantee recording and saving of all video and audio signal.

Manufacture doesn't provide a warranty for any damamge made by
mechanical problem or loss of DATA. Instructions below are guidance for
user's safety to prevent any financial loss or inconvenience caused by
accident. Read the instructions below before using the device.

7

Avoid severe shock and do not try to insert or put
unknown object into unit. ( It might cause a fire or
electric shock.)

Do not change product Installation location
frequently. (It may cause trouble receiving GPS
signal.)

Avoid heavy sun shade. (Image will be faint or
distorted. After out of shade, user need to check
recording result for proper operation)

Avoid dust and direct sunlight into the lens.
(It may cause trouble in normal recording.)

Use only provided cable and indicated 12V DC Car
Power Accessory Outlet. (It may cause damage, fire
and trouble.)

Replace with a new product if the G sensor value is
lower than what is set for drive and parking. (Do not
use anymore when see failure in operation or smoke
from the unit and contact your dealer or installer for
support.)

Replace with a new product when unit is not turn on
due to car accident. (Do not use anymore when see
failure in operation or smoke from the unit and
contact your dealer or installer for support.)

Instrutions below are guidance for user’s safety and prevent any financial
loss or inconvenience caused by accident. Read the installations below before
using the device.

2. Cautions

2-2 Use of SD memory card

8

2. Cautions

Instructions below is for proper use of SD memory card as storage device.

Insertion or removal of SD card

① Turn off the car's ignition. ② Turn off the power from device.
③ Insert or remove SD card from device.

* If SD card inserted or removed while the unit is on, it might

cause of loss of data.

Managing SD card

◆ Use well known brand SD card or the one came with device.

◆ Check disk or format SD card once or more per week for reliable data
storage.

◆ Replace with a new SD card monthly.
* Based on 9 hour sequence record per day ,using 2G SD card
* 4G : 2 months, 8G : 4 months : 16G : 8 months
* Operation setting can fluctuate usage duration of SD card.

◆ Avoid hot and humid environment
Store card in a case when moving or keeping in order to avoid static
electricity or external electrical shock.

◆ The manufacture is not responsible for the lose of data, damage
caused by user.

◆ Please keep a copy of any important data in other storage unit.

◆ SD card includes user manual and video managing program.
