ETCnomad PuckETC
Eos Series
GENERAL INFORMATION
The ETCnomad Puck lighting controller is a full-featured minicomputer with an embedded ETCnomad
capable of running Eos and Element applications. It provides lighting
control with conventional and moving lights, media servers and LED
luminaires. The ETCnomad Puck lighting controller can be used in
primary, backup, client and offline environments.
Optional fader wings, programming wings, X-keys and compatibility
with USB–MIDI panels allow extended and customizable control.
FEATURES
• The base unit is 1,024 outputs. This can be upgraded to
6,144 outputs
• The ETCnomad Puck lighting controller makes an ideal tech
table RVI
• Operates in stand-alone, primary, backup and
client environments
• When connected as a client, output capacity is determined by
the system to which it is connected
• Net3/ACN/sACN and Artnet Ethernet lighting protocols
• DMX/RDM via ETC Gadget or Gadget 2
• DMX/RDM via Net3 DMX/RDM Gateways
• One HDMI and one Mini Display Port (Mini Display Port to
HDMI converter included)
• Four USB ports
• OSC Transmit/Receive
• UDP Transmit/Receive
See Eos and Element datasheets and operation manuals for ETCnomad lighting
control features
ACCESSORIES
• Eos Programming Wing
• Eos Motorized Fader Wings (10 or 20)
• Eos Standard Fader Wings (20 or 40)
• ETCpad
• aRFR/iRFR remote controls
• Alphanumeric keyboard
• USB mouse
lighting control key
ORDERING INFORMATION
ETCnomad Puck Lighting Controller
MODEL DESCRIPTION
ETCnomad Puck Base ETCnomad Puck Lighting Controller Kit,
1,024 outputs and RVI
ETCnomad Puck
Unlocked
ETCnomad Up After-sale output upgrade
IMPORTANT ETCNOMAD LIGHTING CONTROLLER ORDERING
INFORMATION
Local DMX output may be distributed using an Gadget 2 USB to
DMX/RDM converter. Up to four DMX outputs are supported.
Additional or all outputs may be distributed via Ethernet protocols
directly (Net3/ACN/sACN, or ArtNet) or by compatible Ethernetdistribution hardware, such as Net3 DMX/RDM Gateways. The
Gadget and network equipment must be purchased separately from
the ETCnomad Puck lighting control kit.
Note: The ETCnomad Puck lighting controller does not support
ETCNet2/EDMX protocol.
Note: Eos software 2.8.X or below unlocks the base dongle at 512
outputs. Eos software 2.9 or higher unlocks the base dongle to 1,024
outputs.
Note: ETCnomad Puck is also compatible with Cobalt.
Important Note: The original Puck (with three USB ports) can be
upgraded to 2,048 outputs only. Use ETCnomad 1.5K Up to order an
after-sale upgrade for this unit.
Ships with:
• US power cord
• Mini Display Port to HDMI adapter
• VESA mounting bracket
ETCnomad Puck Lighting Controller Kit,
6,144 outputs
1 of 2
ETCnomad PuckETC
(119 mm)
Eos Series
ORDERING INFORMATION
ETCnomad Puck Accessories
MODEL DESCRIPTION
Eos PGW Eos Programming Wing
Eos MFW 20 Eos Motorized Fader Wing 20
Eos MFW 10 Eos Motorized Fader Wing 10
Eos FW 40 Eos Standard Fader Wing 40
Eos FW 20 Eos Standard Fader Wing 20
ETCpad ETC Portable Access Device
GADGET 2 ETC Gadget 2 USB to DMX/RDM Converter
ETCnomad lighting control software is available for download from etcconnect.com/Products/Consoles/Eos-Family/ETCnomad-ETCnomad-Puck/
ETCnomad-Puck.aspx
The ETCnomad Puck lighting controller does not support the ETCNet2/EDMX protocol.
PHYSICAL
4.43 in.
(112 mm)
4.70 in.
1.42 in.
(36 mm)
.07 in.
(1.7 mm)
ETCnomad Puck Lighting Controller Shipping Dimensions
MODEL WIDTH HEIGHT DEPTH
in mm in mm in mm
ETCnomad Puck 15.50 394 3.00 77 11.75 299
ETCnomad Puck Lighting Controller Shipping Weights
MODEL WEIGHT SHIPPING WEIGHT
lb kg lb kg
ETCnomad Puck 2.00 0.91 3.50 1.59
