Safety Instructions
This rangehood must only be installed in accordance
with the instructions provided. Incorrect installation may
cause harm to persons, damage property and void the
product’s warranty.
Important
Please ensure that you read the entire instructions
before beginning the installation of your rangehood.
Warning
All electrical work must be done in accordance with local
and national electrical codes as applicable and should be
undertaken by licenced and qualified persons only.
– This rangehood is designed for domestic household
use only.
– This appliance is not intended to be used by children,
or persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning the use of the rangehood by a person
responsible for their safety.
– Young children should be supervised to ensure that
they do not play with the appliance.
– You must read the instructions concerning the method
and frequency of cleaning.
\
Unpacking
During transportation, protective packaging was used
to protect the appliance against any damage. After
unpacking, please dispose of all elements of packaging
in a way that will not cause damage to the environment.
All materials used for packaging the appliance are
environmentally friendly; they are 100% recyclable and are
marked with the appropriate symbol.
Caution! During unpacking, the packaging materials
(polythene bags, polystyrene pieces, etc.) should be kept
out of reach of children.
Disposal of the appliance
Old appliances should not simply be disposed of with
normal household waste, but should be delivered to a
collection and recycling centre for electric and electronic
equipment. A symbol shown on the product, the instruction
manual or the packaging shows that it is suitable for
recycling.
Materials used inside the appliance are recyclable and
are labelled with information concerning this. By recycling
materials or other parts from used devices you are
making a significant contribution to the protection of our
environment.
Important!
There is a risk of fire if cleaning isn’t carried out in
accordance with the instructions.
– Never flambé under the rangehood.
– Exhaust air must not be discharged into an existing
flue which is used by other appliances for exhausting
fumes.
– If the power supply cord of this rangehood is damaged
in any way, it must only be replaced by Residentia
Group or one of it’s authorised service agents.
Please call the Residentia Support Team for further
assistance.
– Your new rangehood is guaranteed against electrical
or mechanical defects, subject to certain exclusions
that are noted in the Warranty Terms and Conditions
(at the rear of this user manual). The foregoing does
not aect your statutory rights.
– The use of this rangehood for any other purpose or in
any other environment, without the express agreement
of Residentia Group, will invalidate any warranty or
liability claim.
– No modifications to the appliance are permitted by
Residentia Group.
– Repairs may only be carried out by authorised service
agents.
– Cleaning of the rangehood should be carried out on a
regular basis.
Information on appropriate disposal centres for used
devices can be provided by your local authority.
There shall be adequate ventilation of the room when the
range hood is used at the same time as appliances burning
gas or other fuels (not applicable to appliances that only
discharge the air back into the room) .
CAUTION: Accessible parts may become hot when used
with cooking appliances.
User Manual\05
Your angehood
Specifications
\
1018
Model Product dimensions (W,D,H mm)
RH60 600mm, 500mm, 638-1018mm
RH90 900mm, 500mm, 638-1018mm
600-900
Model Extraction Other features:
750m3/hr extraction – 3 speed push button control
RH60
750m3/hr extraction – 3 speed push button control
RH90
Rangehood components
– 1 x Rangehood
– 1 x Expandable 150mm ducting adapter
– 1 x Packet of fasteners and wall plugs
– 2 x Stainless Steel flue pieces (upper and lower)
– 1 x Wall Bracket (“hook”) for the rangehood
– 1 x Wall Bracket for the inside of the chimney pieces
– 1 x “Outside Chimney” bracket
Typical installation tools required You’ll most likely require the following tools/equipment (not supplied) for the
– Electrical drill
– Tape Measure
– Screw-driver
– Spirit Level
Your Residentia Canopy Rangehood is supplied with:
installation of your rangehood.
– 2 x LED lights
– 2 x baffle filters
– 2 x LED lights
– 3 x baffle filters
If ducting your rangehood, you’ll also most likely require:
– Jig saw
– Ladder
– Duct-tape
– Ducting
esidentia\06
Low
Mid
High
Ligh t
Stop
Low
Mid
High
Ligh t
Stop
Low
Mid
High
Ligh t
Stop
Operating Your Rangehood
Controls Your Residentia Canopy rangehood features Push button controls with three
speed levels of extraction.
– Push the ‘Low’ button, an audible buzzer will sound once, and the
rangehood will operate at low speed.
– Push the ‘Mid’ button, an audible buzzer will sound once, and the rangehood
will operate at a medium speed.
– Push the ‘High’ button, an audible buzzer will sound once, and the
rangehood will operate at a high speed.
– Push the ‘Light’ button and the two lights will come on. To turn the lights o,
simply push the ‘Light’ button again.
– To switch the rangehood motor or light o, simply press the button a
second time.
\
0
User Manual\07
Installation Instructions
It’s important to carefully read the following installation instructions before beginning the installation of your rangehood.
Important installation safety notes: – Always switch the power o prior to beginning the installation.
– Stainless steel is very easily damaged during installation. Wherever possible,
protect the rangehood with the cardboard box or plastic wrap during the
installation.
– For safety reasons, this Rangehood must be earthed.
– A power point must be located within 1.5m of the power cord exit from the
rangehood, and it should be always accessible to allow isolation from power
during cleaning or maintenance.
– A 150mm round ducting adapter is supplied, however all other ducting
accessories are not.
– All ducting must comply with building codes and local requirements.
– If you are re-circulating the air, rather than ducting, please ensure that
the side outlet grilles are not obstructed in any way as this will eect the
eciency of the rangehood.
– Ensure that the rangehood is mounted in a level position, both horizontally
and vertically. This is essential to ensure the rangehood operates correctly
and prevents grease build up at one end.
Ducting options Before beginning the installation of your rangehood, the method of ducting
should be considered and selected. The guide below illustrates the various
ducting options.
\
Note: This rangehood can be operated in recirculation mode
where required, although Residentia Group recommends
to duct wherever possible.
1. Into your ceiling cavity and then vented through your eaves.
2. Straight up and through your tiled or metal roof.
\
\Installation Instructions\
08
Through your wall
Further to your various ducting options, below are some tips on how to
correctly duct your rangehood:
– Always use correctly sized ducting – DO NOT reduce the size of the ducting
– Always use solid ducting
– Always use non-flammable ducting
– Always duct to the outside atmosphere
– Do not use flexible ducting
– Do not duct into the ceiling space- always vent to the outside atmosphere.
– Avoid sharp 90 degree bends as much as possible, use 45 degree bends
instead wherever possible
– Duct to the outside atmosphere using the shortest duct run possible
– Use cylindrical ducting whenever possible
Positioning the rangehood Installation heights
– Over gas and electric cookers, Residentia Group recommends our
rangehoods to be mounted at a height of between 600-800mm above the
cooking surface.
– Electric cooktops must have a minimum height of 600mm from the
underside of the rangehood to the cooktop face.
– Gas cooktops must have a minimum of 650mm from the burner to the
underside of the rangedhood.
– Over open flame grillers or barbecues, the Gas Regulations require the
filters of the rangehood to be at least 1200mm above the cooking surface.
Installing the rangehood – Once you’ve determined your installation height, install the mounting
bracket (hook) on to the wall ensuring that it’s secured in a level position.
The mounting bracket connects to the canopy at the top (i.e. where the
chimney connects into the canopy). Also install the wall bracket for the
chimney pieces. (2)
– Attach the expandable 150mm ducting adapter to the canopy. With the two
Chimney pieces together, fix the “outside chimney” bracket onto the outside
chimney (flue) piece. Ensure that the inner chimney piece can move freely
inside. Now attach the chimney pieces to the canopy. (3)
– Lift the canopy (including the chimney pieces) on to the wall bracket
(hook). (4)
– Adjust the height of the inside chimney piece and fix into place with the
screws. After adjusting the position of the canopy, fix into place with the
safety screws into the wall (you’ll need to remove the grease filters first).
Screw
(ST4mm x 30mm)
Screw
(ST4mm x 30mm)
Screw
(4mm x 8mm)
(ST4mm x 30mm)
Warning: Failure to install the screws or fixing device in accordance
with these instructions may result in electrical hazards.
The warning shall be in the same part of the instructions that include
details of how to mount the equipment.
User Manual\09
Cleaning & Maintenance
By ensuring proper cleaning and maintenance of your Residentia
rangehood, you can ensure that it will have a long and fault free operation.
Cleaning the grease filters Keeping this filter clean will keep the rangehood extraction performance at an
optimum. Please strictly follow the guidelines below.
– The grease filter mesh is made of high-density stainless steel. Please
ensure you never use a corrosive detergent during cleaning.
– Method 1: Put the mesh into 40-50°C clean water with a small amount of
regular dishwashing liquid, and soak for 2-3 mins. Wear gloves and clean
with a soft brush. Please do not apply too much pressure, as the mesh is
delicate and will damage easy.
– Method 2: You can wash your rangehood grease filters in your dishwasher,
however please ensure they aren’t washed at a temperature above 60°C
degrees.
Cleaning the cooker hood To protect the main body of your rangehood from corrosion or stains, the
cooker hood should be cleaned with hot water with a non-corrosive detergent
every two months. For stubborn stains or marks, you can try using a specific
stainless steel cleaner available from most supermarkets.
Warning! Please do not use a corrosive detergent, or abrasive
clothes, as it will damage the body.
\
– Keep the motor and other spare parts free from water, as this will cause
damage to the appliance.
– Before cleaning the rangehood, always switch the power o at the outlet
and unplug the rangehood.
– If your rangehood has a damaged plug or cord, please ensure your
rangehood remains unplugged and contact the Residentia Support team
for further assistance. Any electrical work should only be completed by a
suitably licenced and authorised person.
– If you’re using a carbon filter, it should never be exposed to heat.
esidentia\10
Troubleshooting & Technical Data
Operation in case of emergency In the event of an emergency you should:
– Switch o all rangehood controls.
– Switch the rangehood o at the power outlet and immediately unplug.
– Call the Residentia Support Team on 1300 11 HELP (4357).
Some minor faults can be fixed by referring to the instructions given in the
Troubleshooting section below. There is also a self-help section online at
http://www.residentiagroup.com.au.
Important! If your appliance appears to be operating incorrectly,
then you should disconnect it from your electrical supply
and then contact the Residentia Group Support team
on 1300 11 HELP (4357).
Warning! Do not attempt to repair the rangehood yourself.
Please note that if an engineer is asked to attend whilst the product is under
warranty and finds that the problem is not the result of an appliance fault, then
you may be liable for the cost of the call out charge.
The appliance must be accessible for the engineer to perform any necessary
repair. If your appliance is installed in such a way that an engineer is concerned
that damage will be caused to the appliance or your kitchen, then they will not
complete a repair. This includes situations where the rangehood has been tiled
in or sealed in with a sealant.
\
Please refer to the conditions of that appear on the warranty card at the rear
of this user manual.
Fault: Common Cause: Common Solutions:
The lights work, however the motor
does not work
Neither the lights or the motor works Beside the above mentioned, check the following:
The rangehood is vibrating against the
wall
Insucient suction The distance between the rangehood
The motor is blocked or jammed. Call the Residentia Support team
for further guidance.
The capacitor is damaged. Call the Residentia Support team
for further guidance.
Light globes are damaged or blown Replace the light globe(s)
The power cord is loose. Ensure that the rangehood is
correctly plugged in and the power
outlet is switched on.
The rangehood canopy is not fixed to
the wall correctly.
and your cooktop is too great.
Ensure that the internal safety
screws have been used and are
tight.
Have your installer re-adjust the installation position, ensuring that the
minimum distances are observed as
per the building code.
Technical data Electrical details Rated Voltage:
220-240V 50/60Hz
User Manual\11
Notes
\
esidentia\12
Warranty
Warranty terms and conditions
Cooking appliances (rangehoods)
This document sets out the terms and conditions of the
product warranties for Residentia Group Appliances. It is
an important document. Please keep it with your proof of
purchase documents in a safe place for future reference
should you require service for your Appliance.
\
1. In this warranty
(a) ‘acceptable quality’ as referred to in clause 10 of
this warranty has the same meaning referred to
in the ACL;
(b) ‘ACL’ means Trade Practices Amendment
(Australian Consumer Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Residentia Group
product purchased by you accompanied by this
document;
(d) ‘ASR’ means Residentia Group authorised
service representative;
(e) ‘Residentia Group’ means Residentia Group Pty
Ltd of 20 Yaltara Avenue, Bundoora Victoria
3083, ACN 600 546 656 in respect
of Appliances purchased in Australia;
(f) ‘major failure’ as referred to in clause 10 of
this warranty has the same meaning referred
to in the ACL and includes a situation when
an Appliance cannot be repaired or it is
uneconomic for Residentia Group, at its
discretion, to repair an Appliance during the
Warranty Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for
personal, domestic or household
use (i.e. normal single family use)
as set out in the instruction manual,
the Appliance is warranted against
manufacturing defects for 24 months,
following the date of original purchase
of the Appliance;
(h) ‘you’ means the purchaser of the Appliance not
having purchased the Appliance for re-sale, and
‘your’ has a corresponding meaning.
2. This warranty only applies to Appliances purchased
and used in Australia and is in addition to (and does
not exclude, restrict, or modify in any way) any nonexcludable statutory warranties in Australia.
3. During the Warranty Period Residentia Group or
its ASR will, at no extra charge if your Appliance
is readily accessible for service, without special
equipment and subject to these terms and
conditions, repair or replace any parts which it
considers to be defective. Residentia Group or its
ASR may use remanufactured parts to repair your
Appliance. You agree that any replaced Appliances or
parts become the property of Residentia Group. This
warranty does not apply to light globes, batteries,
filters or similar perishable parts.
4. Parts and Appliances not supplied by Residentia
Group are not covered by this warranty.
User Manual\13
\Warranty\
5. You will bear the cost of transportation, travel and
delivery of the Appliance to and from Residentia
Group or its ASR. If you reside outside of the service
area, you will bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance
to and from Residentia Group or its ASR, in all
instances, unless the Appliance is transported
by Residentia Group or its ASR, the Appliance is
transported at the owner’s cost and risk while in
transit to and from Residentia Group or its ASR.
6. Proof of purchase is required before you can make a
claim under this warranty.
7. You may not make a claim under this warranty unless
the defect claimed is due to faulty or defective parts
or workmanship. Residentia Group is not liable in the
following situations (which are not exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to
properly maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm
damage or incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate
operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional
instructions supplied with the
Appliance;
(b) the Appliance is modified without authority from
Residentia Group in writing;
(c) the Appliance’s serial number or warranty seal
has been removed or defaced;
(d) the Appliance was serviced or repaired by
anyone other than Residentia Group, an
authorised repairer or ASR.
8. This warranty, the contract to which it relates and the
relationship between you and Residentia Group are
governed by the law applicable where the Appliance
was purchased.
9. To the extent permitted by law, Residentia Group
excludes all warranties and liabilities (other than as
contained in this document) including liability for any
loss or damage whether direct or indirect arising
from your purchase, use or non use of the Appliance.
10. For Appliances and services provided by Residentia
Group in Australia, the Appliances come with a
guarantee by Residentia Group that cannot be
excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a
major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also
entitled to have the Appliance repaired or replaced
if the Appliance fails to be of acceptable quality and
the failure does not amount to a major failure. The
benefits to you given by this warranty are in addition
to your other rights and remedies under a law in
relation to the Appliances or services to which the
warranty relates.
11. At all times during the Warranty Period, Residentia
Group shall, at its discretion, determine whether
repair, replacement or refund will apply if an
Appliance has a valid warranty claim applicable to it.
12. To enquire about claiming under this warranty, please
follow these steps:
(a) carefully check the operating instructions, user
manual and the terms of this warranty;
(b) have the model and serial number of the
Appliance available;
(c) have the proof of purchase (e.g. an invoice)
available;
(d) telephone the numbers shown below.
IMPORTANT
Before calling for service, please ensure that the steps in
point 12 have been followed.
The Australian Consumer Law requires the inclusion of the following
statement with this warranty:
13. You accept that if you make a warranty claim,
Residentia Group and its ASR may exchange
information in relation to you to enable Residentia
Group to meet its obligations under this warranty.
Telephone contacts
► Service: Please call 1300 11 HELP (4357)
► Spare Parts: Please call 1300 11 SPARE (7727)
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a
major failure.
esidentia\14
Purchase Details
For your records, please record details of your purchase below and staple your
receipt on the opposite page.
Store details
Store name
Address
Telephone
Purchase date
Product details
Model no.
Serial no.*
|
|
|
|
|
|
\
* Note.
Your serial number can be found inside of the rangehood on the rating label.
User Manual\15
eceipt
\
Model Code\RH60\RH90
Loading...
