Part List, Standard
Part List, Standard
Applicable for A2618s and A2618sc
Contents
1 Mounting Drawings ........................................................................................................2
2 Component List...............................................................................................................3
2.1 ROA 117 9219...................................................................................................3
3 Revision History............................................................................................................13
131 22-2/FEA 209 544/25 A Approved according to 1776-2/FEA 209 544
1 Mounting Drawings
The Mounting drawings show the components position on the printed board. The Mounting
drawings can be found in the document 1078-2/FEA 209 544/25.
Board Number Mounting Drawing
ROA 117 9219 R1A 1078-ROA 117 9219 Rev C
Part List, Standard
131 22-2/FEA 209 544/25 A 2(13)
2 Component List
• Pos.:
The components position number on the board.
• Description:
Type of component mounted on the position.
• Part Number:
The components part number (or reference to Board Revision Changes) is specified for all
components that can be replaced according to the Standard Repair Process.
• Comments:
Special soldering requirement.
Functions that are affected if the component is replaced. The specified verification should
be paid extra attention when testing the telephone.
For components that can be replaced only by using the Advanced Repair Process,
"Advanced" is written, and for components not possible to replace, "Not available".
Part List, Standard
2.1 ROA117 9219
ROA 117 9219
Pos. Description Part Number Comments
Shielding Box
Assembly, GSM
Sim Holder RNK 860 132
Antenna Connector SXA 134 063
Battery Connector,
Male
B320 Quartz Crystal Unit Advanced
B800 Quartz Crystal Unit RTM 501 677/01
C107 Not mounted
C108 Not mounted
C109 Not mounted
C110 Capacitor RJC 463 3022/22
C111 Not mounted
C112 Not mounted
C113 Not mounted
C114 Capacitor RJC 463 3022/22
C200 Capacitor RJC 463 3022/1
C201 Capacitor RJC 463 3022/1
C202 Capacitor RJC 463 3022/33
C203 Capacitor RJC 463 3022/1
C204 Capacitor RJC 463 3022/22
C205 Capacitor RJC 463 3022/33
C206 Capacitor RJC 463 3022/22
C207 Capacitor RJC 463 3022/1
C209 Capacitor RJC 463 3021/27
C210 Capacitor RJC 463 3021/27
C212 Capacitor RJC 463 3022/22
C214 Capacitor RJC 464 3024/1
SXK 107 7737
RPV 403 829/003
131 22-2/FEA 209 544/25 A 3(13)
ROA 117 9219
Pos. Description Part Number Comments
C215 Capacitor RJC 464 3024/1
C217 Capacitor RJC 463 3022/33
C300 Capacitor RJC 464 3025/1
C301 Capacitor RJC 463 3022/47
C302 Capacitor RJC 463 3023/1
C303 Not mounted
C304 Capacitor RJC 464 3047/1
C305 Capacitor RJC 463 3022/22
C306 Capacitor RJC 463 3022/22
C307 Capacitor RJC 463 3022/22
C310 Capacitor RJC 464 3024/22
C311 Capacitor RJA 532 4055/12
C312 Not mounted
C313 Not mounted
C320 Capacitor Advanced
C321 Capacitor Advanced
C322 Capacitor Advanced
C323 Not mounted
C324 Not mounted
C330 Capacitor RJC 464 3047/1
C331 Capacitor RJC 464 3025/1
C332 Capacitor RJC 463 3022/22
C333 Capacitor RJC 464 3025/1
C334 Capacitor RJC 463 3022/22
C335 Capacitor RJC 463 3021/27
C336 Capacitor RJC 463 3021/27
C337 Capacitor RJC 463 3022/27
C338 Capacitor RJC 463 3022/27
C340 Capacitor RJC 463 3022/22
C341 Capacitor RJC 463 3022/22
C342 Capacitor RJC 463 3022/22
C343 Capacitor RJC 463 3022/22
C344 Capacitor RJC 464 3025/1
C350 Capacitor RJC 464 3047/1
C351 Capacitor RJC 464 3025/1
C352 Capacitor RJC 463 3022/22
C353 Capacitor RJC 464 3024/22
C361 Capacitor Advanced
C362 Capacitor Advanced
C363 Capacitor Advanced
C364 Not mounted
C365 Capacitor RJC 464 3024/33
C370 Capacitor RJC 463 3022/22
C371 Capacitor RJC 463 3022/22
C372 Capacitor RJC 464 3025/1
C373 Capacitor RJC 464 3025/1
C374 Capacitor RJC 464 3025/1
C380 Capacitor Advanced
C381 Capacitor Advanced
Part List, Standard
131 22-2/FEA 209 544/25 A 4(13)
ROA 117 9219
Pos. Description Part Number Comments
C382 Capacitor RJC 464 3035/82
C383 Not mounted
C400 Capacitor RJE 599 1068/22A
C401 Capacitor RJC 464 3025/1
C402 Not mounted
C403 Capacitor RJC 463 3021/22
C404 Capacitor RJC 463 3021/18
C405 Capacitor RJC 463 3021/27
C406 Capacitor RJC 463 3022/1
C407 Capacitor RJC 463 3022/1
C408 Capacitor RJC 463 3022/33
C409 Capacitor RJE 599 1068/22A
C410 Capacitor RJC 463 3022/1
C411 Not mounted
C415 Capacitor RJC 464 3025/1
C417 Capacitor RJC 464 3025/1
C420 Capacitor RJC 464 3025/1
C421 Capacitor RJC 464 3025/1
C423 Capacitor RJC 464 3025/1
C495 Capacitor RJC 463 3022/22
C496 Capacitor RJC 463 3022/56
C497 Capacitor RJC 464 3024/33
C499 Capacitor RJC 464 3023/82
C500 Capacitor RJC 464 3035/33
C501 Capacitor RJC 516 3525/68
C502 Capacitor RJC 516 3525/68
C505 Capacitor RJC 516 3047/22
C506 Capacitor RJC 516 3525/68
C508 Capacitor RJC 516 3047/22
C509 Capacitor RJC 516 3525/68
C510 Capacitor RJC 516 3525/68
C511 Capacitor RJC 516 3525/68
C512 Capacitor RJC 516 3525/68
C514 Capacitor RJC 463 3022/22
C515 Capacitor RJC 463 3022/22
C516 Capacitor RJC 464 3024/1
C520 Capacitor Advanced
C522 Capacitor Advanced
C602 Capacitor RJC 464 3023/33
C603 Capacitor RJC 464 3025/1
C700 Capacitor RJC 464 3025/1
C701 Capacitor RJC 464 3025/1
C702 Capacitor RJC 516 3557/47
C703 Capacitor RJC 516 3058/1
C704 Capacitor RJC 516 3058/1
C705 Capacitor RJC 516 3058/1
C706 Capacitor RJC 516 3058/1
C708 Capacitor RJC 463 3022/22
C709 Not mounted
Part List, Standard
131 22-2/FEA 209 544/25 A 5(13)
ROA 117 9219
Pos. Description Part Number Comments
C710 Capacitor RJC 464 3025/1
C711 Not mounted
C712 Not mounted
C713 Not mounted
C714 Not mounted
C721 Capacitor RJC 464 3036/1
C722 Capacitor RJC 516 3557/47
C723 Capacitor RJC 516 3557/47
C725 Capacitor RJC 516 3557/47
C726 Not mounted
C727 Not mounted
C728 Not mounted
C729 Not mounted
C730 Capacitor RJC 464 3025/1
C731 Capacitor RJC 464 3025/1
C732 Capacitor RJC 464 3025/1
C733 Capacitor RJC 464 3025/1
C734 Capacitor RJC 464 3025/1
C735 Capacitor RJC 464 3025/1
C736 Capacitor RJC 516 3047/22
C737 Capacitor RJC 463 3023/1
C738 Capacitor RJC 516 3525/68
C739 Not mounted
C740 Capacitor RJC 464 3025/1
C741 Capacitor RJC 464 3025/1
C742 Capacitor RJC 464 3025/1
C743 Capacitor RJC 464 3025/1
C744 Capacitor RJC 464 3025/1
C745 Capacitor RJC 464 3025/1
C746 Capacitor RJC 464 3025/1
C747 Capacitor RJC 464 3025/1
C748 Capacitor RJC 464 3025/1
C751 Capacitor RJC 464 3025/1
C752 Capacitor RJC 464 3025/1
C753 Capacitor RJC 464 3025/1
C754 Capacitor RJC 464 3025/1
C755 Capacitor RJC 464 3025/1
C756 Capacitor RJC 464 3025/1
C757 Capacitor RJC 464 3025/1
C760 Capacitor RJC 464 3025/1
C761 Capacitor RJC 516 3525/68
C762 Capacitor RJC 464 3025/1
C771 Capacitor RJC 516 3525/68
C772 Capacitor RJC 464 3025/1
C773 Not mounted
C774 Not mounted
C775 Not mounted
C776 Not mounted
C777 Capacitor RJE 599 1068/22A
Part List, Standard
131 22-2/FEA 209 544/25 A 6(13)
Part List, Standard
ROA 117 9219
Pos. Description Part Number Comments
C778 Capacitor RJC 463 3022/22
C780 Not mounted
C781 Not mounted
C782 Not mounted
C800 Capacitor RJC 463 3022/15
C801 Capacitor RJC 463 3022/15
C803 Capacitor RJC 464 3046/22
C804 Capacitor RJC 464 3047/1
C805 Not mounted
C806 Not mounted
C807 Not mounted
C808 Not mounted
C809 Capacitor RJC 464 3047/1
C811 Not mounted
C812 Not mounted
C813 Not mounted
C814 Not mounted
C815 Not mounted
C816 Capacitor RJC 463 3022/22
C817 Not mounted
C818 Not mounted
C819 Not mounted
C820 Not mounted
C821 Not mounted
C827 Capacitor RJC 464 3047/1
C850 Capacitor RJC 464 3025/1
C851 Capacitor RJC 463 3022/22
C852 Capacitor RJC 463 3022/22
C853 Not mounted
C854 Not mounted
C855 Capacitor RJC 463 3022/22
C856 Capacitor RJC 463 3022/22
C857 Not mounted
C859 Not mounted
C861 Capacitor RJC 463 3022/22
C862 Capacitor RJC 463 3022/22
C863 Not mounted
C865 Not mounted
C866 Capacitor RJC 463 3022/22
D300 Resistor REP 015 136/3
D301 Resistor REP 015 136/3
D401 Resistor REP 015 136/2
D500 Functional Circuit RYS 105 639/2C
R4A
D600 Prod. Adapt.
Circuit
ROP 101 3018/2
R1A
D601 Microcircuit RYT 118 6157/1 uBGA component, Additional Soldering Process
D602 Microcircuit Not available
uBGA component, Additional Soldering Process
required
uBGA component, Additional Soldering Process
required
required
131 22-2/FEA 209 544/25 A 7(13)
ROA 117 9219
Pos. Description Part Number Comments
D800 Prod. Adapt.
Circuit
J800 Component Holder RNK 860 131
L200 Inductor REG 724 9342/47
L201 Inductor REG 724 9342/47
L202 Inductor REG 724 9342/15
L203 Inductor REG 724 9342/33
L204 Inductor REG 724 9301/47
L205 Inductor REG 724 9342/18
L206 Inductor REG 724 9341/82
L300 Inductor REG 704 494/22
L301 Not mounted
L302 Inductor REG 724 9332/47
L331 Inductor REG 724 9342/1
L340 Inductor REG 704 494/39
L360 Inductor Advanced
L361 Inductor Advanced
L401 Inductor Advanced
L402 Inductor REG 724 9301/33
L700 Inductor REG 724 222/22
N200 Microcircuit Advanced
N201 Transformer REG 135 99/2
N300 Prod. Adapt.
Circuit
N301 Microcircuit RYT 102 902/2
N330 Oscillator Advanced
N331 Oscillator Advanced
N332 Transformer REG 135 99/2
N333 Transformer REG 135 99/1
N390 Quartzcrystal Filter RTN 202 914/1
N391 Transformer REG 135 94/1
N392 Oscillator Advanced
N400 Amplifier Advanced
N500 Prod. Adapt.
Circuit
N501 Prod. Adapt.
Circuit
N700 Prod. Adapt.
Circuit
N701 Microcircuit RYT 113 6110/3C
N720 Microcircuit RYT 113 6157/1
R202 Resistor REP 622 453/27
R300 Resistor REP 622 452/1
R310 Resistor REP 622 454/33
R311 Resistor REP 622 452/1
R312 Resistor REP 622 452/1
R320 Resistor Advanced
R321 Resistor Advanced
R322 Resistor Advanced
Not available
Advanced
BGA Advanced
Not available
BGA Advanced
Part List, Standard
131 22-2/FEA 209 544/25 A 8(13)
ROA 117 9219
Pos. Description Part Number Comments
R331 Resistor REP 622 452/1
R340 Resistor REP 622 001/0
R350 Resistor REP 622 654/33
R360 Resistor Advanced
R361 Resistor Advanced
R362 Resistor REP 622 455/18
R363 Resistor REP 622 454/56
R380 Resistor Advanced
R381 Resistor REP 622 452/22
R382 Resistor REP 622 453/47
R390 Resistor REP 622 453/22
R391 Resistor REP 622 452/56
R392 Resistor REP 622 453/1
R401 Resistor REP 622 455/47
R403 Not mounted
R404 Not mounted
R497 Resistor REP 622 001/0
R498 Resistor REP 622 001/0
R499 Resistor REP 622 454/1
R500 Resistor REP 622 455/22
R501 Resistor REP 622 001/0
R502 Resistor REP 622 454/1
R503 Resistor REP 622 454/1
R504 Resistor REP 622 454/1
R505 Thermistor REZ 401 0064/47
R506 Resistor REP 622 654/47
R507 Resistor REP 622 456/1
R508 Resistor REP 622 456/1
R509 Resistor REP 622 456/1
R510 Resistor REP 622 001/0
R511 Resistor REP 622 454/1
R512 Resistor Advanced
R513 Resistor Advanced
R514 Resistor Advanced
R515 Resistor Advanced
R516 Resistor REP 622 455/1
R517 Resistor REP 622 455/1
R519 Resistor REP 622 454/1
R520 Resistor REP 622 001/0
R521 Resistor REP 622 456/1
R522 Resistor REP 622 456/1
R523 Resistor REP 622 456/1
R524 Resistor REP 622 001/0
R525 Resistor REP 622 655/22
R526 Resistor REP 622 456/1
R528 Resistor REP 622 001/0
R529 Resistor REP 622 001/0
R530 Not mounted
R600 Resistor REP 622 001/0
Part List, Standard
131 22-2/FEA 209 544/25 A 9(13)
ROA 117 9219
Pos. Description Part Number Comments
R601 Resistor REP 622 455/1
R602 Not mounted
R603 Resistor REP 622 001/0
R604 Resistor REP 622 001/0
R605 Not mounted
R701 Resistor REP 622 001/0
R702 Resistor REP 622 455/1
R703 Resistor REP 622 001/0
R704 Resistor REP 624 650/27
R705 Resistor REP 624 001/0
R706 Resistor REP 622 455/22
R707 Resistor REP 622 455/22
R708 Resistor REP 622 001/0
R709 Resistor REP 622 001/0
R710 Not mounted
R723 Resistor REP 622 456/1
R726 Resistor REP 622 001/0
R727 Resistor Advanced
R730 Resistor REP 622 001/0
R731 Resistor REP 622 001/0
R732 Resistor REP 622 001/0
R733 Resistor REP 622 001/0
R734 Not mounted
R735 Resistor REP 622 001/0
R736 Not mounted
R737 Not mounted
R800 Resistor REP 622 455/1
R801 Resistor REP 622 654/47
R802 Resistor REP 622 654/47
R803 Resistor REP 622 455/1
R804 Resistor REP 622 455/1
R805 Resistor REP 622 452/33
R806 Resistor REP 622 452/33
R807 Resistor REP 622 452/33
R808 Not mounted
R809 Resistor REP 622 452/33
R810 Resistor REP 622 456/1
R811 Not mounted
R812 Resistor REP 622 456/1
R814 Not mounted
R850 Resistor REP 622 001/0
R851 Resistor REP 622 454/1
R852 Resistor REP 622 001/0
R854 Resistor REP 622 454/1
R855 Resistor REP 622 454/15
R856 Resistor REP 622 452/36
R858 Resistor REP 622 452/22
R859 Resistor REP 622 001/0
R860 Resistor REP 622 453/15
Part List, Standard
131 22-2/FEA 209 544/25 A 10(13)
ROA 117 9219
Pos. Description Part Number Comments
R861 Resistor REP 622 001/0
R862 Not mounted
R863 Resistor REP 622 455/33
R864 Resistor REP 622 454/1
V321 Diode Advanced
V322 Diode Advanced
V330 Transistor RYN 901 634/1
V332 Transistor RYN 901 634/1
V335 Transistor RYN 901 634/1
V347 Transistor RYN 120 665/1
V348 Transistor RYN 121 6069/1
V349 Transistor RYN 901 634/1
V350 Not mounted
V400 Transistor Advanced
V401 Transistor RYN 121 6107/1
V402 Transistor RYN 120 647/1
V403 Transistor RYN 121 6070/1
V404 Diode RKZ 323 673/1
V500 Diode RKZ 123 646/1
V501 Diode RKZ 123 646/1
V502 Diode Advanced
V503 Not mounted
V504 Diode RKZ 123 646/1
V505 Diode RKZ 123 646/1
V600 Transistor RYN 121 6069/1
V701 Transistor RYN 901 634/1
V702 Transistor RYN 121 6069/1
V703 Transistor RYN 901 634/1
V705 Diode RKZ 123 654/1
V720 Transistor RYN 122 641/1
V721 Diode RKZ 123 646/1
V801 Transistor RYN 121 6069/1
V804 Not mounted
V805 Diode RKZ 223 901/1
V806 Diode RKZ 123 646/1
V807 Transistor RYN 121 6091/1
V850 Diode RKZ 123 647/1
V851 Transistor RYN 121 1621/1
V853 Transistor RYN 121 6086/1
V854 Transistor RYN 121 6086/1
V855 Diode RKZ 123 646/1
V856 Diode RKZ 123 646/1
V857 Diode RKZ 123 646/1
X1 Pin Connector Unit RPV 403 829/003
Z200 Quartzcrystal Filter RTN 201 910/1
Z201 Quartzcrystal Filter RTN 201 805/01
Z300 Filter REG 706 06/1
Z350 Filter REG 706 06/1
Z400 Filter REG 706 05/9
Part List, Standard
131 22-2/FEA 209 544/25 A 11(13)
ROA 117 9219
Pos. Description Part Number Comments
Z501 Not mounted
Z502 Not mounted
Z701 Filter REG 706 06/1
Z702 Filter REG 706 06/1
Part List, Standard
131 22-2/FEA 209 544/25 A 12(13)
3 Revision History
Rev. Date Changes / Comments
A 2000-06-13
Part List, Standard
131 22-2/FEA 209 544/25 A 13(13)
Loading...
