Projector Features

Direct Power On and Instant Off

Use the Direct Power On function to turn the projector on simply by plugging the power cable into an electrical outlet. See page 36

When you’re done using the projector, just turn it off, unplug it, and place it in the carrying case. The projector’s Instant Off design means you don’t have to let it cool down first.

Ease of Use

◗ Lens cover

Temporarily stop projection by closing the lens cover.

◗ Single foot design

Make height adjustments quickly with one hand.

◗ Easy to use, big button control panel

◗ On-screen Help

Quickly answer questions about common projection problems. See page 45

Color Modes

Project movies, photos, presentations, and games in the optimum color tone by choosing the most suitable mode for your surroundings. See page 14

Security Function

◗ Set up a password to restrict use of the projector. See page 24.

◗ Disable all control panel buttons except for the Power button to prevent

your settings being changed when the projector is used in a public place. See page 26

◗ Automatic source search

Press the Source Search button to automatically detect and display the connected picture signal.

Setting Up the Projector

The projector supports the following four projection methods, allowing you to choose the best method for displaying your images.

• For ceiling mount installation (suspending from the ceiling), a special

◗ Front projection (Front projection)

installation procedure is required. Failure to install correctly may result in injury or damage if the projector falls.

• Do not turn the projector on its side during projection, or malfunctions may occur.

• To prolong the life of the projector, turn it off when not in use.

◗ Front/ceiling projection (Front/Ceiling projection)

◗ Rear/ceiling projection using a translucent screen

(Rear/Ceiling projection)

◗ Rear projection using a translucent screen (Rear projection)

• The optional ceiling mount is required when installing the projector on a ceiling. See page 58

• When using ceiling projection or projection using a translucent screen, set the "Projection" command in the "Extended" menu to match the installation method. See page 35

Part Names and Functions

Front/Top

Control panel

Lamp cover

Open this cover when replacing the projector's lamp.

Air exhaust vent

Front adjustable foot

Raises the projector to adjust the projection angle.

Security lock

Focus ring

Adjusts the image focus.

Remote control light-receiving area

Receives signals from the remote control.

Lens cover

Slide shut when not using the projector to protect the lens. If you close it while projecting, the image and sound are termporarily stopped.

Foot release lever

Extends the front foot.

Part Names and Functions

Control Panel

[Menu] button Displays and closes the configuration menu.

[Power] button

Turns the projector power on or off.

LED indicators

The color of the indicators and whether they are flashing or lit shows the state of this projector.

[Source Search] button

The input source is automatically searched for in the following order, and the input image from the connected equipment is projected.

[Enter] button

Automatically adjusts analog RGB images from computers and RGB video images to the optimum images. If a configuration menu or help screen is displayed, it accepts and enters the current selection.

[Esc] button

Stops the current function. Displays the previous screen or menu while viewing a configuration menu.

[Help] button

Displays and closes the help, which shows solutions if a problem occurs.

Computer port

S-Video port

Video port

[ ] [ ] button

Press to correct keystone distortion. If a configuration menu or help screen is displayed, it selects menu items and setting values.

[Wide] [Tele] button

Adjusts the image size. If a configuration menu or help screen is displayed, it selects menu items and setting values.

Part Names and Functions

Rear

Computer port

Inputs analog RGB video signals from a computer and RGB video signals and component video signals from other video sources.

Monitor Out port

Outputs the projected computer's analog RGB signals or RGB video signals to an external monitor from the source that is connected to the Computer port. This feature is not available for video equipment signals.

Power inlet

Connects to the power cable.

Rear adjustable foot

Lets you level the image.

S-Video port

Inputs S-video signals to the projector from other video sources.

Audio input

Input audio signals from connected external equipment. When you are connecting two or more pieces of external equipment that use the same input port, you need to disconnect one before connecting the other, or use an audio selector.

Video port

Inputs component video signals to the projector from other video sources.

USB port

Connects the projector to a computer via the USB cable when using the wireless mouse function. Computer images cannot be projected by using the USB cable to connect the computer.

Remote control light-receiving area

Receives signals from the remote control.

Speaker

Part Names and Functions

Base

Front adjustable footFoot adjust lever

Air intake vent

Clean the air intake vent periodically.

Air filter (air intake vent)

This prevents dust and other foreign particles from getting inside the projector when air is drawn in. It should be cleaned and replaced periodically.

Suspension bracket fixing points (3 points)

Attach the optional ceiling mount here when suspending the projector from a ceiling.

Part Names and Functions

Remote Control

[E-Zoom] button ( ) ( ) (see page 21

[Page down] [Page up] buttons (see page 22

[Enter] and [Esc] button (see page 22)

[A/V Mute] button (see page 19)

[Pointer] button (see p.21)

[Computer] button (see page 18)

[S-Video] button (see page 18

[Video] button (see page 18

[Auto] button (see p.12)

)

) )

[Power] button (see Quick Setup sheet)

[ ] button (see page 22

[Freeze] button (see page 20)

[Num] button and numeric buttons (see page 24

[Color Mode] button (see page 14

[Menu] button (see page 31

[Help] button (see page 45

[Resize] button (see page 20

)

[Search] button (see page 17)

[Volume] buttons (see page 17

)

Adjusting the Image Quality

Adjusting and Changing the Image

Adjusting the Image Quality

Adjusting Computer Images and RGB Video Images

Automatic Setup

Automatic setup detects analog RGB signals coming from a connected computer, and automatically adjusts these signals so that the optimum images can be obtained.

Automatic setup involves adjustment of Tracking, Position, and Sync (synchronization).

If "Auto Setup" in the "Signal" menu is set to "Off", automatic setup is not carried out. In this case, press the [Auto] button on the remote control or the [Enter] button on the projector's control panel to make the adjustment while computer or RGB video images are being projected.

Using the remote control

Using the control panel

• If you try to make the adjustment while other functions such as E-zoom or

Freeze are in use, these functions are canceled and then the adjustment is made.

• Sometimes the signals may not be adjusted correctly depending on the type of computer or RGB video signals being input. In such cases, use the configuration menu commands to adjust the tracking and sync settings manually. See page 33.

Adjusting the Tracking

If vertical stripes appear in the projected computer or RGB video images, and this cannot be fixed using automatic setup, you will need to adjust the Tracking manually using the following procedure.

1 Select "Signal" from the configuration

menu, and then select "Tracking".

Check the buttons you can use and the operations they perform in the guide at the bottom of the screen.

Using the remote control

Using the control panel

Adjusting the Image Quality

Adjusting the Sync

If flickering, fuzziness or interference appear in computer or RGB video images, and this cannot be fixed using automatic setup, you will need to adjust the Sync (synchronization) manually using the following procedure.

1 Select "Signal" from the configuration

menu, and then select "Sync.".

2 Adjust the tracking until the vertical stripes disappear from the

image.

Using the remote control

The tracking value increases or decreases each time a button is pressed.

3 Press the [Menu] button to exit the configuration menu.

The image will flash when continuous tracking adjustment is carried out,

but this is normal.

Using the control panel

Check the buttons you can use and the operations they perform in the guide at the bottom of the screen.

Using the remote control

2 Adjust the synchronization until the horizontal noise disappears

from the image.

Using the control panel

Adjusting the Image Quality

Using the remote control

The sync value increases or decreases each time a button is pressed.

3 Press the [Menu] button to exit the configuration menu.

• If you adjust the sync without adjusting the tracking first, it will not be

possible to get the best adjustment results. Incorrect tracking adjustment may not be noticeable with some types of images. However, images with lots of lines and shading will tend to show incorr ect tracking adjustments more clearly, so check the tracking adjustment first.

• Flickering and fuzziness may also occur when the brightness, contrast, sharpness, zoom, and keystone correction settings are adjusted.

Using the control panel

Selecting the Projection Quality (Color Mode)

The following seven preset color modes are available for use depending on the characteristics of the images that are being projected. You can easily obtain the optimum image quality simply by selecting the color mode that corresponds to the projected images. The brightness of the images will vary depending on which color mode is selected.

Mode Application

Photo (When computer and RGB video images are being input)

The images are vivid and contrast is increased. Ideal for projecting still pictures, such as photos, in a bright room.

Sports (When component video, S-video, or composite video images are

being input) The images are vivid and brought to life. Ideal for watching TV

programs and so on in a bright room. Presentation Ideal for giving presentations in a bright room Theatre Gives images a natural tone. Ideal for watching films in a dark

room. Game Excels at emphasizing dark gradations. Ideal for playing video

games in a bright room. sRGB Ideal for images that conform to the sRGB color standard Blackboard Even if you are projecting onto a blackboard (green board), this

setting gives your images a natural tint, just like when projecting

onto a screen

Adjusting the Image Quality

Each time you press the button, the color modes change in the following order.

The current setting appears in the top-right corner of the screen each time the color mode is changed. While the color mode name is displayed on the screen, it does not change to the next color mode setting unless you press the button.

The color mode can also be set using the "Color Mode" command in the "Image" menu. See page 32.

Adjusting the Projection Position (Image Shift)

When you cannot setup this projector directly in front of the screen, the projection position can be finely tuned without moving this projector.

1 Using the button on the projector, perform zoom adjustment or

keystone correction. See the Quick Setup sheet.

The Image Shift adjustment screen is displayed after you finish making adjustments.

2 Adjust projection position.

Using the Remote Control Using the Control Panel

3 Press the [Esc] button to close the adjustment screen.

The screen closes automatically if no operations are performed for about 10 seconds.

• The projection position cannot be adjusted when zoom is set to

maximum "wide".

• Even if you turn the power supply off, the "Image Shift" settings you make are kept. When either the projector position or the angle of the projector is changed, you can readjust or perform the following operations.

Control Panel

Press and hold down the [Wide] and [Tele] buttons for more than one second.

• You can also make adjustments from the configuration menu. See page

33.

Adjusting the Volume

The volume of the projector's built-in speaker can be adjusted as follows.

Remote control

When the button is pressed to the [ ] side, the volume increases, and when it is pressed to the [ ] side, the volume decreases.

The volume gauge appears on the screen when the volume is being adjusted.

• If the value displayed in the gauge on the screen stops changing when the

volume is being adjusted, it indicates that the limit for volume adjustment has been reached.

• The volume can also be adjusted using the configuration menu. See page

34.

Selecting the Image Source

The image source is the projector port to which your video equipment is connected. You can select the image source automatically, using Source Search as described below. Or you can select a source yourself as described on page 18

Automatically Detecting the Source (Source Search)

Source Search automatically detects the picture signal from connected equipment and projects the image.

1 Turn on your computer or video equipment. If you are viewing a

2 Press the Source Search button.

tape or DVD, start playback.

Using the Remote Control Using the Control Panel

Selecting the Image Source

3 The projector searches for an active source and displays the

image.

Unused sources are skipped, as shown below. When two or more pieces of equipment are connected, press the [Source Search] button repeatedly to select the desired source.

Computer S-Video Video

Skip

You see this screen if no picture signal is available. You can use the screen to choose the input source.

Selecting the Source from the Remote Control

You can use the remote control to select a specific image source.

Remote Control

Changes to the image from the Computer port.

Changes to the image from the S-Video port.

Changes to the image from the Video port.

Functions for Enhancing Projection

Additional Projector Functions

This chapter explains functions used when giving presentations and for using the projector’s security functions.

Functions for Enhancing Projection

Muting the Image and Sound (A/V Mute)

For example, this can be used if you want to pause the projection for a moment and focus the audience’s attention on what you are saying. Or if you are making a computer presentation and you do not want to show details, such as selecting different files.

Using the projector

Using the remote control

You can temporarily turn off the image and sound in two ways:

◗ When you close the lens cover, projection and sound are turned off. Open

the lens cover to restore projection and sound.

◗ When you press the A/V Mute button on the remote control, projection and

sound are turned off. If you saved a user’s logo (see page 28 it to display when you press the A/V Mute button (see page 35 A/V Mute button again to restore projection and sound.

• If you’re watching a moving picture, the video source continues to play

while the screen is dark. You should pause the video if you wish to resume playback where you stopped it.

• The screen display in A/V mute can be chosen from black, blue, or a logo by using "Extended" -"Display" - "A/V Mute" in the configuration menu.

), you can set

). Press the

Closing the lens cover stops projection and sound.

Pressing the [A/V Mute] button stops projection and sound.

Functions for Enhancing Projection

Freezing the Image

The source image continues to project even when the screen is frozen. You can still perform operations such as changing files, without projecting any images.

Remote control

You can turn this function on or off by pressing the [Freeze] button.

• Sound does not stop.

• Even though the image on the screen is froz en, the image source continues to project, and so it is not possible to resume projection from the point where it was paused.

• Pressing the [Freeze] button also clears configuration menu displays and help messages.

• The freeze function still works while the E-Zoom function is being used.

Changing the Aspect Ratio

This function changes the aspect ratio of images from 4:3 to 16:9 when component video, S-video, or composite video images are being projected. Images which have been recorded in digital video or onto DVDs can be viewed in 16:9 wide-screen format.

When images in Squeeze Mode are projected at 4:3

Remote control

When images in Squeeze

Mode are projected at 16:9

The display is changed whenever you press the button.

You can also make this setting using the "Resize" command in the

"Signal" menu.

Functions for Enhancing Projection

Displaying the Pointer

This allows you to move a pointer icon on the projected image, and helps you draw attention to the area you are talking about.

1 Display the pointer.

Remote control

Each time you press the button the pointer appears or disappears.

You can use the "Pointer Shape" command in the "Settings" menu to

change the shape of the pointer to one of three differ ent shap es. See page

34.

Enlarging Part of the Image (E-Zoom)

This is useful when you want to see images in greater detail, such as graphs and details in a table.

1 Start E-Zoom.

Remote control

2 Move the pointer icon.

Remote control

Pointer icon

Functions for Enhancing Projection

2 Move the cross to the area of the image that is to be enlarged or

reduced.

Remote control

Cross

3 Enlarge.

Remote control

Using the Remote Control as a Mouse

If the USB terminal of a computer and the USB terminal on the back of this projector are connected by a commercially available USB A-B cable, you can use the projector’s remote control like a wireless mouse to control the computer’s mouse pointer.

Computer

Windows 98/2000/Me/XP Home Edition/XP Professional Macintosh (OS 8.6–9.2/10.0–10.4)

You can reduce the enlarged image by pressing the [-] button.

To cancel the E-Zoom, press the [Esc] button.

• The enlargement ratio will appear on the screen.

• You can scroll the screen by tilting the [ ] button.

• The selected area can be enlarged up to 4 times, in 25 incremental steps.

To USB port

USB cable

(commercially-available)

Functions for Enhancing Projection

• The USB cable can only be connected to computers with a standard USB

Once the connection has been made, the mouse pointer can be operated as follows.

interface. If using a computer which is running Windows, the computer must have had a full version of Windows 98/2000/Me/XP Home Edition/ XP Professional installed. If the computer is running a version of Windows 98/2000/Me/XP Home Edition/XP Professional that has been upgraded from an earlier version of Windows, correct operation cannot be guaranteed.

• It may not be possible to use the mouse function under some versions of both the Windows and Macintosh operating systems.

• Some computer settings may have to be changed in order for the mouse function to be used. Consult the documentation for the computer for further details.

Moving the mouse pointer Mouse clicks

Left click Right click

Double-click: Press twice in rapid succession.

Drag and drop

1. Hold down the [Enter] button and tilt and drag the [ ] button.

2. Release the [Enter] button to drop at the desired location.

• If the mouse button settings are set to reverse on the computer, the

operation of the remote control buttons will also be reversed.

• The wireless mouse function cannot be used while the following functions are being used.

•While a configuration menu is being displayed

•While a help menu is being displayed

•While the E-Zoom function is being used

•While a user's logo is being captured

•Pointer function

•While adjusting sound volume

•While Image Shift is being used

This is useful for displaying the previous or next slide in a PowerPoint slideshow.

To previous slide

To next slide

Security Functions

Preventing theft (Password Protect)

When the Password Protect function is activated, people who do not know the password will not be able to use the projector to project images, if the power has been disconnected since the password was last entered correctly. Furthermore, the user's logo that is displayed on the background of the screen cannot be changed. This is effective against theft. At the time of purchase, the password protection function is not enabled.

When Password Protect is Enabled

When "Power On Protect" is enabled (On)

When the power is turned on for the first time after the projector's power cable is connected to an electrical outlet, or when Direct Power On is carried out, the following password entry screen will be displayed.

Remote control

the first time after the power cable has been disconnected and then reconnected. If Direct Power On is set to "On" and you are using a circuit breaker or similar to centrally control the power, the password entry screen will be displayed the first time the projector is turned on after the power supply is restored.

• If an incorrect password is entered three times in succession, the

message "The projector’s operation will be locked." will be displayed for approximately five minutes, and then the projector will switch to standby mode. If this happens, disconnect the power plug from the electrical outlet and then reinsert it and turn the pr ojector's power back on. A window requesting you to enter the passwor d will be displayed, so enter the correct password. If you happen to forget the password, make a note of the "Request Code: xxxxx" number that appears in the Password screen and contact Epson (see page 57

• If you continue to repeat the above operation and input the wrong password thirty times, the following message will be displayed and the projector will not accept password entries any more. “The projector’s operation will be locked.” Contact Epson (see page

57).

Keep

Pressed

Numeric buttons

While holding down the [Num] button, press the numeric keypad buttons to enter the password. If the password is entered correctly, projection will start.

If you leave the power cable connected to the electrical outlet and turn the projector's power on when it is in standby mode, projection will start without the password entry screen appearing. The password entry screen will only be displayed when the power is turned on for

Security Functions

When "Password Timer" is set to "On" and "Timer" is used

The password entry screen will not be displayed at all when the power is turned on until the length of time that has been set has elapsed. When the set length of time has elapsed, the password entry screen will be displayed each time the power is turned on. The length of time referred to here is the total illumination time for the projector's lamp from the point when the projector's menu is closed.

If "Password Timer" is set to "Off", the password entry screen will be displayed each time the power plug is disconnected and reinserted from the electrical outlet. If the projector’s power is on when it is in standby mode, the password entry screen will not be displayed.

When "User’s Logo Protect" is enabled (On)

If an attempt is made to carry out any of the following user logo operations, a message is displayed and the setting cannot be changed. To change the setting, set "User’s Logo Protect" to "Off" first. See page 35

◗ Capturing a user's logo

◗ When the "Extended" - "Display" - "Display Background" menu, or the

"Extended" - "Display" - "A/V Mute" menu, is changed from "Logo" to "Black" or "Blue", or changed from "Black" or "Blue" to "Logo".

Setting Password Protect

Use the following procedure to set Password Protect.

1 Hold down the [Freeze] button for approximately 5 seconds.

The "Password Protect" menu will be displayed.

Remote control

• If Password Protect has already been enabled, the "Password" screen

will be displayed. If the password has been entered correctly, the "Password Protect" menu will be displayed. See “

page 24.

• If Password Protect is set to "On", attach the accessory Password Protect sticker to your preferred position on the projector as a theftprevention measure.

When Password Protect is Enabled” on

◗ When the "Extended" - "Display" - "Startup Screen" menu ("On" or

"Off") is changed.

2 Turn "Power On Protect" on.

(1) Select "Power On Protect", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button.

3 Turn "Password Timer" on.

If you don't use this setting, proceed to step 4.

(1) Select "Password Timer", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button. (4) Select "Timer" and then press the [Enter] button. (5) While holding down the [Num] button, use the numeric keypad

buttons to enter the setting time within the range of 1 to 9999 hours and then press the [Enter] button. If you make a mistake entering the time, press the [Esc] button

Security Functions

and re-enter the time. When you have finished using the "Password Protect" menu, the countdown for the elapsed time will start.

4 Turn "User’s Logo Protect" on.

(1) Select "User’s Logo Protect", and then press the [Enter] button. (2) Select "On", and then press the [Enter] button. (3) Press the [Esc] button.

5 Enter the password.

(1) To set a password, select "Password" and then press the

[Enter] button.

(2) The message "Change the password?" will be displayed, so

select "Yes" and then press the [Enter] button. The default setting for the password is "0000", but you should change this to your own desired password. If you select "No", the screen shown at step 1 will be displayed again.

(3) While holding down the [Num] button, use the numeric keypad

buttons to enter a 4-digit number. The number entered will be displayed as "* * * *". Once four digits have been entered, the confirmation screen will be displayed.

(4) Re-enter the password.

The message "The new password is stored." will be displayed. If you enter the password incorrectly, a message will be displayed prompting you to re-enter the password.

Using the remote control

2 Set to "On".

If set to "On", none of the buttons on the control panel except the [Power] button can be operated.

Using the control panel

Using the Operation Lock

This function locks the buttons on the projector's control panel. You can use it when projecting at tradeshows or in schools, so that projection can be carried out without interruption.

1 From the configuration menu, select "Settings" - "Operation

Lock".

Check the buttons you can use and the operations they perform in the guide at the bottom of the screen.

Security Functions

Using the remote control

3 When the confirmation message is displayed, select "Yes".

The control panel buttons will be locked in accordance with the selected setting.

There are two methods to cancel the projector's control panel lock.

• Using remote control, change the "Settings" - "Operation Lock" in the configuration menu to "Off".

• Hold down the projector's [Enter] button continuously for about 7 seconds. A message will be displayed and the lock will be cancelled.

Using the control panel

Saving a User's Logo

You can record the image that is currently being projected as a user's logo.

1 Project the image you would like to use as the user’s logo, and

When a user's logo is recorded, the previous user's logo will be erased.

then display the configuration menu.

Using the remote control

Using the control panel

2 Select "Extended" from the configuration menu, and then select

"User’s Logo".

Check which buttons on the remote control or the control panel you can use, and the operations they perform, in the guide at the bottom of the screen.

• If the "User’s Logo Protect" function of "Password Protect" is set to

"On", a message is displayed and the user's logo can not be recorded. To record a user's logo, set "User’s Logo Protect" to "Off" first. See

When "User’s Logo Protect" is enabled (On)” on page 25.

“

• If keystone correction, Zoom adjustment, or E-Zoom and so on, have been carried out, the function currently being performed is cancelled when the "User’s Logo" menu is selected.

Saving a User's Logo

3 When "Choose this image as the User's Logo?" appears, select

"Yes".

When you press the [Enter] button, the image will be displayed at its

4 The image to be recorded and a selection marquee box will be

original resolution. For example, if a video image or an image with a resolution that is different from the projector’s native resolution is being displayed, the image size will change.

displayed. Move the marquee box to select the part of the image to use.

5 When "Select this image?" appears, select "Yes".

6 Select the zoom rate from the Zoom rate setting screen.

User's logos can be saved at up to 400 × 300 dots in size.

Using the remote control

Using the control panel

7 When "Save this image?" is displayed, select "Yes".

The image will then be saved. Once the image has been saved, the message "Completed." will be displayed.

• Saving the user's logo may take a few moments (about 15 seconds). Do

not use the projector or any other sources which are connected to the projector while the user's logo is being saved, otherwise it may result in errors in projector operation.

• Once a user's logo has been saved, the logo setting cannot be returned to the factory default.

Displaying Projected Images on an External Monitor

When projecting from a computer (analog RGB or RGB video source), you can connect an external monitor to view the projected image.

Monitor port

• Component video and S-Video images cannot be output to an external

• The setting gauge for keystone correction and the configuration menus

Cable provided with monitor To Monitor Out port (black)

monitor. and help menus are not output to the external monitor.

Using the Menu System

Configuration Menus

Using the Menu System

Buttons used

Select from the main menu

Select from the sub menu

Change the selected item

Control panel

Remote control

"Image" Menu

The items that can be set will vary depending on the input source that is currently being projected. Setting details are saved separately for each source.

Computer/RGB video Component video/composite video/S-video

Sub-menu Function

Color Mode Select the quality of the image to suit your surroundings. See page 14. Brightness Adjusts the image brightness. Contrast Adjusts the difference between light and dark in the images. Color Saturation Adjusts the color saturation for the images. Tint Adjusts the image tint. (Adjustment is only possible when component video or NTSC signals are being input.) Sharpness Adjusts the image sharpness. Color Temp. You can adjust the overall tint of images. If you select "High", images appear bluish, and if you select "Low", images appear reddish.

(This item cannot be selected if "sRGB" has been selected as the "Color Mode" setting in the "Image" menu.)

Color Adjustment

Reset Resets all adjustment values for the "Image" menu functions to their default settings.

Adjusts the red, green, and blue color strength of the image. Red: Adjusts the saturation of the red component. Green: Adjusts the saturation of the green component. Blue: Adjusts the saturation of the blue component. (This item cannot be selected if "sRGB" has been selected as the "Color Mode" setting in the "Image" menu.)

If you would like to return all menu items to their default, see "Reset All" on page 38

"Signal" Menu

The items that can be set will vary depending on the input source that is currently being projected. Setting details are saved separately for each source.

Computer/RGB video Component video Component video/S-video

Sub-menu Function

Auto Setup Turns on or off the function for automatically optimizing images when the input source is changed. Tr ac k in g Adjusts computer images when vertical stripes appear in the images. See page 12. Sync. Adjusts computer images when flickering, fuzziness or interference appear in the images. See page 13. Position Moves the image display position vertically and horizontally. Progressive (Adjustment is only possible when composite Video or S-Video signals are being input.)

Off: IP conversion is carried out for each field in the screen. This is ideal when viewing images with a large amount of movement. On: Interlaced (i) signals are converted into progressive (p) signals. This is ideal when viewing still images.

Computer1 Input

Video Signal (Adjustment is only possible when composite video/S-Video signals are being input.)

Resize Sets the aspect ratio for projected images. See page 20. Reset All the adjustment values on the "Signal" menu, except "Computer Input", are returned to their default values. Press the [Enter] button on the remote control or

Selects the input signal in accordance with the equipment that is connected to the Computer port. If set to "Auto" the input signal is set automatically in accordance with the connected equipment. If the colors do not look correct when you select "Auto", select the appropriate signal for the connected equipment manually.

Sets the video signal format. With the "Auto" function, image signals are recognized automatically. If interference appears in the projected images or no images appear when you select

"Auto", select the appropriate signal manually.

on the projector's control panel. If you would like to return all menu items to their default, see "Reset All" on page 38

"Settings" Menu

Sub-menu Function

Keystone Corrects vertical keystone distortion in images. See the Quick Setup sheet. Zoom Adjusts the size of the projected image.

Wide: Larger Tele: Smaller Image Shift Adjusts the projection position. See page 16. Operation

Lock Pointer Shape The shape of the pointer can be selected. See page 21.

Brightness Control

Volume Adjusts the volume. See page 17. Reset Adjustment values for the "Settings" menu functions are returned to their default settings, except for "Image Shift" and “Zoom".

When set to "On", the operation of all buttons on the projector's control panel except for the [Power] button will be disabled. See page 26.

Pointer 1: Pointer 2: Pointer 3:

This lets you set the lamp brightness to one of two settings.

Select "Low" if the images being projected are too bright such as when projecting images in a dark room or onto a small screen.

When "Low" is selected, image brightness is reduced. This also reduces fan noise and electrical consumption while extending the lamp's operating life.

If you would like to return all menu items to their default, see "Reset All" on page 38

"Extended" Menu

Sub-menu Function

Display This lets you make settings related to the projector's display.

Message:

Sets whether on-screen messages are displayed. Messages include the input source, color mode, and "No Signal" message.

Display Background:

Determines the background screen displayed when no image signals are input. Options include "Black", "Blue" or "Logo".

Startup Screen:

Sets whether the startup screen is displayed (the image projected when the projector is started).

A/V Mute:

Determines the background screen displayed when the [A/V Mute] button on the remote control is pressed. Options include "Black", "Blue" or "Logo". User’s Logo Change the user's logo that is displayed as a background or during A/V Mute. See page 28. Projection Sets the image orientation, depending on where you place the projector relative to the screen. See page 6.

"Front" "Front/Ceiling" "Rear" "Rear/Ceiling"

By holding down the [A/V Mute] button for about 5 seconds, you can change the projection setup in the following ways.

Front Front Ceiling

Rear Rear Ceiling

"Extended" Menu

Sub-menu Function

Operation Direct Power On:

Sets whether direct power on is enabled ("On") or disabled ("Off").

When you set to "On" and leave the power cable connected to a wall socket, the projector may turn on by itself when electricity is restored after a power

outage.

Sleep Mode:

Sets whether projection stops automatically in the following situations:

- When no image signals are input for approximately 30 minutes.

- When the lens cover is shut and no operations are carried out for approximately 30 minutes.

When Sleep Mode is "On" the power turns off after about 30 minutes.

When Sleep Mode is "Off" the power and the lamp remain on continuously. When you finish using the projector, turn off the power and disconnect the cable.

High Altitude Mode:

When using above an altitude of about 1,500m, set to "On". Link 21L Sets whether the EMP Link 21L utility software is being used or not.

To enable the EMP Link 21L, turn the projector's power off and wait until the cool down period has finished. Language Sets the language for the menu system and on-screen messages. Reset Returns "Display" and "Operation" settings in the "Extended" menu (except for "High Altitude Mode") to their default settings.

If you would like to return all menu items to their default, see "Reset All" on page 38

"Info" Menu

Lets you check the type of image signal being projected and the status of the projector.

Computer/RGB video/component video Composite video/S-video

Sub-menu Function

Lamp Hours Shows the cumulative lamp operating time.

If it reaches the lamp warning time, the characters are displayed in yellow. The cumulative operating time from 0 to 10 hours will be displayed as "0H". From

"10H" onwards, the display will be in units of 1 hour. Source Displays the input source currently being projected. Input Signal Displays the Input Signal setting.

(Does not appear when the input source is composite video or S-video.) Resolution Displays the input resolution.

(Does not appear when the input source is composite video or S-video.) Video Signal Shows the video signal format.

(Not displayed for computer, RGB video, or component video images.) Refresh Rate Displays the refresh rate.

(Does not appear when the input source is composite video or S-video.) Sync. Info Information from this menu may be required when you ask for service from your dealer or from Epson.

(Does not appear when the input source is composite video or S-video.)

"Reset" Menu

Sub-menu Function

Reset All Resets all items in all menus to their default settings.

The "Computer1 Input", "Zoom", "Image Shift", "User’s Logo", "Lamp Hours" and "Language" settings will not be reset to their defaults. Reset Lamp

Hours

Clears the cumulative lamp operating time and resets it to "0H". Perform this procedure when you replace the lamp.

Cleaning

Maintenance

This section describes maintenance tasks such as cleaning the projector and replacing consumable parts.

Cleaning

You should clean the projector if it becomes dirty or if the quality of projected images starts to deteriorate.

Cleaning the Projector

Clean the projector's surface by wiping it gently with a soft cloth.

If the projector is particularly dirty, moisten the cloth with water containing a small amount of neutral detergent, and then firmly wring the cloth dry before using it to wipe the projector's surface. Then wipe it again with a soft, dry cloth.

Do not use volatile substances such as wax, alcohol or thinner to clean

the projector's surface. These can cause the projector to warp and make the coating finish peel off.

Cleaning the Air Filters and Air Intake Vent

If dust collects on the air filter or the air outlet, it can cause the internal temperature of the projector to rise, and this can lead to problems with operation and shortening of the optical engine's service life.

It is recommended that you clean these parts at least once every three months. Clean them more often than this if using the projector in particularly dusty environments.

Cleaning the Lens

Use a commercially-available air blower, or use a lens cleaning paper to gently wipe the lens.

Do not rub the lens with harsh materials or subject the lens to shocks, as

it can easily become damaged.

If the air filters are broken or if the warning message reappears after they have been cleaned, they should be replaced. Replace with a new air filter. See “

Replacing the Air Filter” on page 44.

Replacing Consumables

This section explains how to replace the remote control batteries, the lamp, and the air filters.

Replacing the Batteries

If delays in the responsiveness of the remote control occur or if it does not operate after it has been used for some time, it probably means that the batteries are getting low. Replace the batteries. Have two spare AAA-size alkali batteries ready to use when required.

1 Remove the battery cover.

While pushing the catch of the battery compartment cover, lift the cover up.

Catch

3 Replace the battery cover.

Press the battery compartment cover until it clicks into place.

Lamp Replacement Period

It is time to replace the lamp when:

• The message "Replace the Lamp." appears on the screen when projection starts

2 Insert the batteries.

Check the positions of the (+) and (–) marks inside the battery holder to ensure that the batteries are inserted the correct way.

A message will be displayed.

• When the Lamp indicator is flashing orange

Flashing orange

Replacing Consumables

• The projected image gets darker or starts to deteriorate

• The lamp replacement message is set to appear after the following

periods of time in order to maintain the initial brightness and quality of the projected images.

·When used at high brightness: Approx. 2000 hours

·When used at low brightness: Approx. 3000 hours

• If you continue to use the lamp after this period, the possibility of the lamp breaking becomes gr eater. When the lamp replacement message appears, replace the lamp with a new one as soon as possible, even if it is still working.

• Depending on the characteristics of the lamp and on the way it has been used, the lamp may become darker or stop working before the lamp warning message appears. You should always have a spare lamp ready in case it is needed.

• Contact Epson for a spare lamp (see page 57

• Lamp life results vary depending on mode selected, environmental conditions, and usage. Lamp brightness decreases over time. Turn off this product when not in use to prolong the life of the projector.

Replacing the Lamp

2 Wait until the lamp has cooled down, then remove the lamp

cover from the base of the projector.

Loosen the lamp cover screw with the screwdriver that is supplied with the spare lamp (or your own Phillips head screwdriver).

Then slide the lamp cover straight back and lift it off.

3 Loosen the two lamp screws.

Loosen the two screws that secure the lamp.

• If you are replacing the lamp, it is possible that the glass around the

1 Turn off the projector’s power, wait until it beeps twice, and

lamp is broken.

• If replacing the lamp on a ceiling-mounted projector, be careful when removing the lamp cover; broken glass could fall out of the lamp area and get in your eyes.

• Wait until the lamp has cooled down sufficiently (about one hour) before removing the lamp cover.

disconnect the power cable.

Replacing Consumables

4 Take out the lamp.

Hold the lamp as shown in the illustration below and lift it up and out of the projector.

If the lamp is broken replace it with a new lamp, or contact Epson for further advice (see page 57 be careful to avoid pieces of broken glass.

5 Install the new lamp.

). If replacing the lamp yourself,

• Install the lamp securely . If the lamp cover is r emoved, the lamp turns off automatically as a safety precaution. The lamp will not turn on if the lamp or the lamp cover is not installed correctly.

• This product includes a lamp component that contains mercury (Hg). Please consult your state and local regulations regarding disposal or recycling. Do not put in the trash.

Insert the new lamp so that the lamp fits in place correctly. After inserting it fully, tighten the two screws.

6 Install the lamp cover.

Slide on the lamp cover and tighten its screw.

Replacing Consumables

Resetting the Lamp Operating Time

The projector has a built-in counter which keeps track of the lamp operating time. When the cumulative operating time reaches a certain point, it causes the replacement warning message to be displayed. The counter needs to be reset after the lamp has been replaced with a new one. You can do this using the configuration menu.

Do not reset the lamp operating time except after the lamp has been

1 Connect the power cable and turn on the projector.

2 Select "Reset" from the configuration menu, and then select

replaced, otherwise the lamp replacement period will not be indicated correctly.

"Reset Lamp Hours".

3 When "Execute?" appears, select "Yes".

The lamp operating time will then be reset.

Check the buttons you can use, and the operations they perform, in the guide at the bottom of the screen.

Using the remote control

Using the control panel

Replacing Consumables

Replacing the Air Filter

If the air filter is broken or if a warning message reappears after it has been cleaned, it should be replaced.

The air filter can be replaced even if the projector is installed on a ceiling.

1 Turn off the projector’s power, wait until it beeps twice, and

disconnect the power cable.

2 Remove the air filter.

Put your finger into the recess of the air filter and slide it out to remove it.

3 Install the new air filter.

Slide in the new air filter and press until it clicks into place.

Dispose of used air filters properly in accordance with your local

regulations. Air filter frame: Polycarbonate, ABS plastic Filter: Polyurethane foam

Recess

Using the Help Menu

Troubleshooting

Using the Help Menu

If a problem occurs with the projector, you can use the Help function to assist you in solving the problem. It uses a series of menus in a question and answer format. If the Help function does not provide a solution to the problem, see “

Problem Solving” on page 47.

1 Display the Help menu.

Using the remote control

2 Select a menu item.

Using the control panel

Using the remote control

3 Confirm the selection.

Using the remote control

Using the control panel

Using the Help Menu

4 Repeat the operations in steps 2 and 3 to proceed through the

menu to more detailed items.

5 Press the [Help] button to exit the help menu.

Problem Solving

If you are having a problem with the projector, first check the projector's indicators and refer to "Reading the Indicators" below.

If the indicators do not show clearly what the problem might be, see “

When the Indicators Provide No Help” on page 50.

Reading the Indicators

The projector is provided with the following three indicators which indicate the operating status of the projector.

Indicates the operating status of the projector.

Orange: Standby condition

Projection starts again when the [Power] button is pressed. You can disconnect the power plug from the electrical outlet when the status light is in this condition.

Green : Warm-up in progress

Warm-up time is approximately 30 seconds. After warm-up is complete, the indicator will stop flashing.

Green : Projection in progress

Indicates the projection lamp status.

Indicates the internal temperature status.

The following tables show what the indicators mean and how to remedy problems that they indicate.

If all indicators are switched off, check that the power cable is connected correctly and that power is being supplied normally.

Power indicator lights red

Status Cause Remedy or Status

Power

Red

Internal error Stop using the projector, disconnect the power cable from the electrical outlet, and contact Epson (see

page 57).

Problem Solving

Status Cause Remedy or Status

Power

Red

Fan related error/ Sensor error

Stop using the projector, disconnect the power cable from the electrical outlet, and contact Epson (see

page 57

Power

Red

High temperature error (overheating)

Lamp problem Lamp timer failure Lamp cover is open

Lamp or Temp indicator flashes orange

Status Cause Remedy or Status

Power

Red

Orange

High temperature warning (This is not an abnormality, but if the temperature rises too high again, projection will stop automatically.)

The lamp will turn off automatically and projection will stop. Wait for about 5 minutes until the projector switches to standby mode, then do the following:

• Make sure the air filter and air exhaust vent are clear, and the projector is not positioned against a wall.

• If the air filters are blocked, clean or replace them. See page 44

Press the [Power] button to turn the power back on. If this does not solve the problem and the projector continues to overheat or the indicators continue to show a problem when the power is turned on, stop using the projector, disconnect the power cable from the wall outlet, and contact Epson (see page 57

Take out the lamp and check if it is broken. See page 41. If the lamp is not broken, put it back in and then turn the power on. If the lamp still does not turn on, replace it with a new lamp.

If this does not solve the problem, stop using the projector and disconnect the power cable from the electrical outlet. Then contact Epson (see page 57

If the lamp is broken replace it with a new lamp, or contact Epson for further advice (see page 57). If replacing the lamp yourself, be careful to avoid pieces of broken glass. (Projection cannot be carried out until the lamp is replaced.)

Check that the lamp and the lamp cover are securely installed. If the lamp or lamp cover is not securely installed, the lamp will not switch on.

When using above an altitude of about 1,500m, make sure you set the "High Altitude Mode" to "On".

Check that the air filter and air exhaust vent are clear and that they are not up against a surface such as a wall.

If the air filter is clogged, clean or replace it. See page 44

Problem Solving

Status Cause Remedy or Status

Power

Orange

• If the projector is not operat ing properly even though the indicators are all showing normal, refer to "When the Indicators Pro vide No Help" on the fo llowing pa ge.

• If an indicator is showing a status which does not appear in the previous tables, contact Epson (see page 57

Lamp replacement notification Replace the lamp with a new one. See page 41.

If you continue to use the lamp after it has passed the replacement period, the possibility that the lamp may break will increase. Replace the lamp with a new one as soon as possible. The Power indicator status will vary depending on the projector status at the time.

Problem Solving

When the Indicators Provide No Help

If any of the following problems occur and the indicators do not offer a solution, refer to the pages given for each problem.

Problems relating to images Problems when projection starts

No images appear page 51

Projection does not start, the projection area is completely black, the projection area is completely blue, and so on.

Projection stops automatically page 51

The message "Not Supported." is displayed page 51

The message "No Signal." is displayed page 52

Images are fuzzy or out of focus page 52

Interference or distortion appear in images page 53

Problems such as interference, distortion or black & white checked patterns appear.

Image is cut off or too small page 53

Only part of the image is displayed.

Image colors are not right page 54

The whole image appears purplish or greenish, images are black & white, colors appear dull, and so on. (Computer monitors and LCD screens have different color reproduction performance, so that the colors projected by the projector and the colors appearing on the monitor may not necessarily match, but this is not a sign of a problem.)

Power does not turn on page 55

Where To Get Help

Epson provides these technical support services:

Internet Support

Visit Epson’s support website for solutions to common problems. You can download drivers and documentation, get FAQs and troubleshooting advice, or e-mail Epson with your questions.

Visit Presenters Online successful presentations.

Speak to a Support Representative

To use the Epson PrivateLine Support service, call (800) 637-7661 and enter the PIN on the included Epson PrivateLine Support card. This is the fastest way of speaking to a live representative, and it’s free. This service is available 6

AM to 6 PM, Pacific Time, Monday through Friday, for the duration of your

warranty period.

You may also speak with a projector support specialist by dialing one of these numbers:

to access tips, templates, and training for developing

Purchase Supplies and Accessories

You can purchase screens, carrying cases, or other accessories from an Epson authorized reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766). Or you can purchase online at www.epsonstore.com (U.S. sales) or www.epson.ca

(Canadian sales).

◗ U.S.: (562) 276-4394, 6

◗ Canada: (905) 709-3839, 6

Friday.

Toll or long distance charges may apply.

Before you call for support, please have the following information ready:

◗ Product name (Epson PowerLite S4)

◗ Product serial number (located on the bottom of the projector)

◗ Proof of purchase (such as a store receipt) and date of purchase

◗ Computer or video configuration

◗ Description of the problem

AM to 6 PM, Pacific Time, Monday through Friday.

AM to 6 PM, Pacific Time, Monday through

Optional Accessories and Consumables

Appendix

Optional Accessories and Consumables

You can purchase screens, carrying cases, or other accessories from an Epson authorized reseller. For product information and to find the nearest authorized reseller, please call 800-GO-EPSON (800-463-7766) or browse our catalog of products at www.epson.com, select the product you are interested in, and click “Where to Buy.” To purchase online, please visit the Epson Store at www.epsonstore.com (U.S. sales only). In Canada, please call 800-463-7766 for a reseller referral. This list of optional accessories is current as of January 2005. Details of accessories are subject to change without notice.

Part Number Part Name

V13H010L36 Replacement lamp V13H134A08 Air filter set (2) ELPSC06 50" Portable screen (4:3 aspect ratio) ELPSC07 60" Portable pop-up screen (4:3 aspect ratio) ELPSC08 80" Portable pop-up screen (4:3 aspect ratio) ELPSC09 83.6" Hanging pull-down screen (4:3 aspect ratio) ELPMBUNI Ceiling mount ELPMBFCP False ceiling plate ELPMBSEC Ceiling mount secure cable kit ELPMBAPL Suspension adapter ELPMBACC Adjustable Ceiling Channel ELPSV01 S-Video cable ELPKC19 Component video cable (9.8 feet/3 m) for mini D-Sub 15-pin/RCA×3 ELPDA01 Distribution amplifier ELPKS35-S Samsonite wheeled softcase ELPKS43 Samsonite soft shoulder case for projector and notebook ELPKS54 ATA molded hardshell case V12H162020 ELPDC05 High resolution document imager ELPSL01 Kensington security lock

Screen Size and Projection Distance

See the following table to choose the best position for your projected image. The values are only a guide.

Units: cm (in.) Units: cm (ft.) Units: cm (in.)

Projection Distance Offset

4:3 Screen Size

(Zoom Adjustment Wide) to (Zoom Adjustment Tele)

30” 61 × 46 (24 × 18) 87 to 119 (2.9 to 3.9) 4 to -2 (1.7 to -0.9) 40” 81 × 61 (32 × 24) 117 to 159 (3.8 to 5.2) 6 to -3 (2.3 to -1.1) 50” 100 × 76 (39 × 30) 147 to 200 (4.8 to 6.6) 7 to -4 (2.8 to -1.4) 60” 120 × 90 (47 × 35) 177 to 240 (5.8 to 7.9) 9 to -4 (3.4 to -1.7)

80” 160 × 120 (63 × 47) 237 to 321 (7.8 to 10.5) 12 to -6 (4.5 to -2.3) 100” 200 × 150 (79 × 59) 297 to 402 (9.7 to 13 .2) 14 to -7 (5.7 to -2.9) 120” 240 × 180 (94 × 71) 357 to 483 (11.7 to 15.9) 17 to -9 (6.8 to -3.4) 150” 300 × 230 (118 × 91) 447 to 605 (14.7 to 19.8) 22 to -11 (8.5 to -4.3) 200” 410 × 300 (161 × 118) 597 to 807 (19.6 to 26.5) 29 to -15 (11.3 to -5.7) 300” 610 × 460 (240 × 181) 897 to 1212 (29.4 to 39.8) 43 to -22 (17.0 to -8.6)

Minimum Maximum

(Zoom Adjustment Wide) to (Zoom Adjustment Tele)

90°

Screen

Center of lens

Glossary

The following is an explanation of some of the terms used in this guide which may be unfamiliar or which are not explained in the text of this guide itself. Further information can be obtained by referring to other commercially available publications.

Aspect ratio The ratio between an image's length and its height. HDTV images have an aspect ratio of 16:9 and appear elongated. The aspect ratio for

Color Temp. The temperature of an object that is emitting light. If the color temperature is high, the colors take on a bluish tinge. If the color temperature

Component video Video signals which have the video brightness signals and color signals separated, in order to provide better image quality.

Composite video Video signals which have the video brightness signals and color signals mixed together. The type of signals commonly used by household

Contrast The relative brightness of the light and dark areas of an image can be increased or decreased in order to make text and graphics stand out

Dolby Digital A sound format developed by Dolby Laboratories. Normal stereo is a 2-channel format which uses two speakers. Dolby Digital is a 6-channel

HDTV An abbreviation for High-Definition Television. It refers to high-definition systems which satisfy the following conditions.

Interlaced A method of image scanning whereby the image data is divided into fine horizontal lines which are displayed in sequence starting from left to

Progressive A method of image scanning whereby the image data from a single image is scanned sequentially from top to bottom to create a single

Refresh rate The light-emitting element of a display maintains the same luminosity and color for an extremely short time. Because of this, the image must

SDTV An abbreviation for Standard Definition Television. It refers to standard television systems which do not satisfy the conditions for High-

Security lock A commercially available cable that can be attached to the projector to prevent theft. This projector is compatible with the Microsaver

Squeeze mode In this mode, wide-screen images in 16:9 mode are compressed in the horizontal direction so that they are stored on the recording medium

sRGB An international standard for color intervals that was formulated so that colors which are reproduced by video equipment can be handled

standard images is 4:3.

is lower, the colors take on a reddish tinge.

In high-definition TV (HDTV), it refers to images which consist of three independent signals: Y (luminance signal), and Pb and Pr (color difference signals).

video equipment (NTSC, PAL and SECAM formats). The carrier signal Y (luminance signal) and chroma (color) signal which are contained in the color bar are overlapped to form a single signal.

more clearly, or to make them appear softer.

(5.1-channel) system which adds to this a center speaker, two rear speakers, and a sub-woofer.

Vertical resolution of 750p or 1125i or greater (p = progressive, i =interlaced) Screen aspect ratio of 16:9 Dolby Digital audio reception and playback (or output)

right and then from the top to the bottom of the screen. The even-numbered lines and odd-numbered lines are displayed alternately.

image.

be scanned many times per second in order to refresh the light-emitting element. The number of refresh operations per second is called the "refresh rate", and is expressed in hertz (Hz).

Definition Television.

Security System manufactured by Kensington.

as 4:3 images. When these images are played back by the projector in squeeze mode, they are restored to their original 16:9 format.

easily by computer operating systems (OS) and the Internet. If the connected source has an sRGB mode, set both the projector and the connected signal source to sRGB.

Glossary

SVGA A type of video signal with a resolution of 800 (horizontal) × 600 (vertical) dots which is used by IBM PC/AT-compatible computers. S-Video A video signal which has the luminance component and color component separated in order to provide better image quality.

It refers to images which consist of two independent signals: Y (luminance signal), and C (color signal). SXGA A type of video signal with a resolution of 1280 (horizontal) × 1024 (vertical) dots which is used by IBM PC/AT-compatible computers. Sync (synchronization) The signals output from computers and RGB video equipment have a specific frequency. If the projector frequency does not match this

frequency, the resulting images will not be of a good quality. The process of matching the phases of these signals (the relative position of the

crests and troughs in the signal) is called "synchronization". If the signals are not synchronized, problems such as flickering, blurriness and

horizontal interference can occur. Tr ac ki n g The signals output from computers and RGB video equipment have a specific frequency. If the projector frequency does not match this

frequency, the resulting images will not be of a good quality. The process of matching the frequency of these signals (the number of crests in

the signal) is called "tracking". If tracking is not carried out correctly, wide vertical stripes will appear in the projected images. USB An abbreviation for Universal Serial Bus. USB is an interface for connecting personal computers to peripheral devices which only support

relatively low data transmission speeds. VGA A type of video signal with a resolution of 640 (horizontal) × 480 (vertical) dots which is used by IBM PC/AT-compatible computers. XGA A type of video signal with a resolution of 1024 (horizontal) × 768 (vertical) dots which is used by IBM PC/AT-compatible computers.

List of ESC/VP21 Commands

Command List

When a power on command is sent to the projector, the power will turn on and the projector will change to warm-up mode. When the power has turned on, a colon ":" (3Ah) will be returned.

When the projector executes a command, it returns a ":" and waits for the next command to be sent.

If command processing terminates with an error, the projector outputs an error message and then returns the ":" code.

Item Command

Power ON/OFF On PWR ON

Off PWR OFF

Signal selection Computer (Auto) SOURCE 1F

Computer1 SOURCE 11 Component Video SOURCE 14 Video SOURCE 41 S-Video SOURCE 42

A/V Mute ON/OFF On MUTE ON

Off MUTE OFF

A/V Mute Selection Black MSEL 00

Blue MSEL 01 User’s Logo MSEL 02

Cable Layouts

USB connection

Connector shape: USB (type B)

(type B)

* When issuing any of the above commands, tack a Carriage Return (CR) code (0Dh) on to the end.

List of Supported Monitor Displays

The projection of some signals not listed in the table may still be possible. However, some functions may not be supported.

Computer/RGB Video

Source

Signal Refresh rateg (Hz)

Resolution

(dots)

VGA 60 640×480 800×600 VGAEGA 640×350 800×438 VESA 60/72/75/85,iMac*

SVGA 56/60/72/75/85,iMac*

XGA 60/70/75/85,iMac*

SXGA 70/75/85 1152×864 800×600 SXGA 60/75/85 1280×960 800×600 SXGA 60/75/85 1280×1024 750×600 MAC13" 640×480 800×600 MAC16" 832×624 800×600 MAC19" 1024×768 800×600 MAC19" 60 1024×768 800×600 MAC21" 1152×870 794×600 SDTV(625i) 50 720×576 800×600 SDTV(525i) 60 720×480 800×600 SDTV(525p) 60 640×480 800×600 HDTV(750p) 60 1280×720 800×450 HDTV(1125i) 60 1920×1080 800×450

640×480 800×600

800×600 800×600 1024×768 800×600

Projected

Resolution*

(dots)

Component Video/RGB Video

Resolution (dots)*

Signal Refresh rateg (Hz)

Aspect ratio

4:3

SDTV(525i) (D1) SDTV (625i) 50 800×600 800×450

SDTV (525p) (D2) HDTV(750p) 16:9 (D4) 60 800×600 800×450 HDTV (1125i) 16:9

(D3)

60 800×600 800×450

16:9

Composite Video/S-Video

Resolution (dots)*

Signal Refresh rateg (Hz)

Aspect ratio

4:3

TV (NTSC) 60 800×600 800×450 TV (PAL, SECAM) 50 800×600 800×450

16:9

*1: Connection is not possible if the equipment does not have a VGA output port.

*2: The value when zoom is set to maximum.

Specifications

Dimensions 15.3 (W) × 6.5 (H) × 13.9 (D) inches

327 (W) × 87 (H) × 247 (D) mm (not including feet) Display method Polysilicon TFT active matrix Resolution SVGA 480,000 pixels (800 (W) × 600 (H) dots) × 3 Contrast ratio 500:1 Brightness 1800 ANSI lumens (high brightness)

1500 ANSI lumens (low brightness) Focus adjustment Manual Zoom adjustment Electronic (approx. 1:1.35) Lamp UHE lamp, 170 W Lamp life 2000 hours (high brightness)

Speaker 1W monaural Power supply 100/240VAC 50/60Hz 2.2/1.0A Power consumption Operating: 250W (100 to 120V area)

Operating altitude 0 to 2,286 m (0 to 7,500 ft) Operating

temperature

Storage temperature -10 to +60ºC (14 to 140ºF) (No condensation)

Weight Approx. 2.6 kg (5.7 lb) Fan noise 36 db (high brightness)

Connectors Computer 1 Mini D-Sub 15-pin (female)

3000 hours (low brightness)

240W (220 to 240V area)

Standby:5W (100 to 120V area)

6W (220 to 240V area)

+5 to +35ºC (41 to 95ºF) (No condensation)

30 db (low brightness)

Blue S-Video 1 Mini DIN 4-pin Video 1 RCA pin jack Audio Input 1 RCA pin jack×2 (L,R) USB* 1 USB connector (B series) Monitor Out 1 Mini D-Sub 15-pin (female)

Black

Lamp life results vary depending on mode selected, environmental

conditions, and usage. Lamp brightness decreases over time. T urn off this product when not in use to prolong the life of the projector.

Pixelworks DNXTM ICs are used in this Projector.

Angle of tilt

0°- 30° 0°- 30°

If you use the projector when it is tilted more than 30°, it could fall or be damaged.

* The USB interface complies with the USB 1.1 standard. The USB connector is not guaranteed to operate correctly with all USB-compatible devices.

Specifications

Safety

USA

UL60950-1

Canada

CSA C22.2 No.60950-1

The Low Voltage Directive (73/23/EEC) IEC/EN60950-1

EMC

USA

FCC Part 15B Class B (DoC)

Canada

ICES-003 Class B

European Community

EMC Directive (89/336/EEC) EN55022, Class B EN55024 IEC/EN61000-3-2 IEC/EN61000-3-3

Australia/New Zealand

AS/NZS CISPR 22:2002 Class B

Dimensions

86.8

3-M4×9

Center of lens

83.7

327

*Distance from center of lens to suspension bracket fixing point

7.7

50.1* 12

104.7

69.7

247

115127

Units: mm

Declaration of Conformity

DECLARATION of CONFORMITY

According to 47CFR, Part 2 and 15

Class B Personal Computers and Peripherals; and/or

CPU Boards and Power Supplies used with Class B

Personal Computers

We :EPSON AMERICA, INC. Located at :3840 Kilroy Airport Way

MS: 3-13 Long Beach, CA 90806

Tel :562-290-5254

Declare under sole responsibility that the product identified herein, complies with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device. Each product marketed, is identical to the representative unit tested and found to be compliant with the standards. Records maintained continue to reflect the equipment being produced can be expected to be within the variation accepted, due to quantity production and testing on a statistical basis as required by 47CFR 2.909. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause interference to radio and television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING

The connection of a non-shielded equipment interface cable to this equipment will invalidate the FCC Certification or Declaration of this device and may cause interference levels which exceed the limits established by the FCC for this equipment. It is the responsibility of the user to obtain and use a shielded equipment interface cable with this device. If this equipment has more than one interface connector, do not leave cables connected to unused interfaces. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

Trade Name :EPSON Type of Product :Projector Model :EMP-S4

Important Safety Instructions

Please read the following important information about your projector.

• Never look into the projector lens when the lamp is switched on as the

Follow these safety instructions when setting up and using the projector:

◗ Do not place the projector on an unstable cart, stand, or table.

◗ Do not stand on the projector or place heavy objects on it.

◗ Do not use the projector near water or sources of heat.

◗ Use attachments only as recommended.

◗ Use the type of power source indicated on the projector. If you are not sure

of the power available, consult your dealer or local electricity company.

◗ Place the projector near a wall outlet where the plug can be easily

unplugged.

◗ If the projector has a three-prong plug, insert the projector’s three-pin

grounding-type plug into a properly grounded outlet. If you have a twoprong outlet, contact an electrician to replace it.

bright light can damage your eyes. Never let children look into the lens when it is on.

• Never open any covers on the projector except the lamp cover. Dangerous electrical voltages inside the projector can cause severe injury. Except as specifically directed in the User’s Guide supplied, do not attempt to service this product yourself. Refer all servicing to qualified service personnel.

• Keep the plastic bags for the projector, accessories and optional parts out of the reach of children. Childr en covering their heads with bags may result in death by suffocation. Be particularly careful around small children.

• When you replace the lamp, never touch the new bulb with your bare hands. The invisible residue left by the oil on your hands may be shorten the bulb life. Use a cloth or gloves to handle the new bulb.

◗ Do not insert the plug into an outlet with dust present.

◗ Insert the plug firmly into the outlet.

◗ Do not overload wall outlets, extension cables or power strips. This can

cause fire or electric shock.

◗ Do not place the projector where the cable can be stepped on. It may

result in fraying or damage to the plug.

◗ Do not handle the plug with wet hands.

◗ Unplug the projector from the wall outlet before cleaning. Use a damp cloth

for cleaning. Do not use liquid or aerosol cleaners.

◗ Do not block the slots and opening in the projector case. They provide

ventilation and prevent the projector from overheating. Do not place the projector on a sofa, rug or other soft surface, or in a closed-in cabinet unless proper ventilation is provided.

◗ Never push objects of any kind through cabinet slots. Never spill liquid of

any kind into the projector.

◗ Unplug the projector when it will not be used for extended periods.

◗ Do not place the projector and remote control on top of heat producing

equipment or in a heated place, such as a car.

◗ Unplug the projector from the wall outlet and refer servicing to qualified

service personnel under the following conditions:

◗ When the power cable or plug is damaged or frayed

◗ If liquid has been spilled into the projector, or it has been exposed to

rain or water

◗ If it does not operate normally when you follow the operating

instructions, or if it exhibits a distinct change in performance, indicating a need for service

◗ If it has been dropped or the housing has been damaged

◗ The internal projector components consist of many glass parts such as the

lens and projection lamp.

◗ Take the following precautions when handling the plug. Failure to comply

with these precautions could result in sparks or fire or electric shock.

Important Safety Instructions

◗ The lamp is fragile, and can easily break. If the lamp breaks, handle the

projector with extreme care to avoid injury from broken glass, and contact Epson for repairs (see page 57

). Particular care should be taken when the projector is installed to a ceiling, as small pieces of glass may fall down when the lamp cover is removed. Be very careful not to allow such pieces of glass to get into the eyes or mouth.

◗ Material or paper may get stuck against the air filter underneath the

projector while it is in use. Remove anything from underneath the projector that might get stuck against the air filter in this way.

◗ Never try to remove the lamp immediately after use. Doing so will result in

serious burns. Before removing the lamp, turn off the power supply and wait the time specified in the User’s Guide to allow the lamp to cool completely.

◗ A mercury lamp with high internal pressure is used as the projector's light

source. Mercury lamps may make a loud noise when they break. Handle the lamp with extreme care while observing the following. If the following points are not observed, injury or poisoning may result.

◗ Do not damage the lamp or subject it to any impacts.

◗ Do not use the lamp after the lamp replacement period has elapsed.

Once the lamp replacement period has elapsed, the possibility of the lamp breaking becomes greater. When the lamp replacement message appears, replace the lamp with a new one as soon as possible.

◗ The gases inside mercury lamps contain mercury vapor. If the lamp

breaks, immediately ventilate the room to prevent the gases that are released when the lamp breaks from being inhaled or coming into contact with the eyes or mouth.

◗ Do not bring your face close to the projector while it is in use, in order to

prevent the gases that are released when the lamp breaks from being inhaled or coming into contact with the eyes or mouth.

◗ If the lamp breaks and needs to be replaced with a new lamp, contact

Epson for information on replacement (see page 57

). If the lamp breaks, pieces of broken glass may get scattered around inside the projector.

◗ Particular care should be taken when the projector is installed to a

ceiling, as small pieces of glass may fall down when the lamp cover is removed. If cleaning the projector or replacing the lamp yourself, be very careful not to allow such pieces of glass to get into the eyes or mouth. In addition, consult your local regulations regarding proper disposal and do not place in the trash.

◗ If the lamp breaks and gas from the lamp or fragments of broken glass are

inhaled or get into the eyes or mouth, or if any other ill effects are noticed, immediately seek medical advice.

◗ This product includes a lamp component that contains mercury (Hg).

Please consult your state and local regulations regarding disposal or recycling. Do not put in the trash.

◗ If there is an electrical storm, do not touch the power plug, otherwise you

may receive an electric shock.

◗ If using a remote control that takes batteries, keep these batteries out of

the reach of children. Batteries are choking hazards and can be very dangerous if swallowed.

◗ If the batteries are swallowed, seek medical assistance immediately.

◗ When replacing batteries, take the following precautions.

◗ Replace the batteries as soon as they run out.

◗ If the batteries leak, wipe away battery fluid with a soft cloth. If fluid gets

on your hands, wash immediately.

◗ Do not expose batteries to heat or flame.

◗ Dispose of used batteries according to your local regulations.

◗ Remove the batteries if you won’t be using the projector for a long

period of time.

WARNING: The cords included with this product contain chemicals, including lead, know to the State of California to cause birth defects or other reproductive harm. Wash hands after handling. (posted in accordance with

Proposition 65 in Cal. Health & Safety Code § 25249.5 et seq)

Epson PowerLite S4 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Projector Features

Setting Up the Projector

Part Names and Functions

Front/Top

Control Panel

Rear

Base

Remote Control

Adjusting the Image Quality

Adjusting and Changing the Image

Adjusting Computer Images and RGB Video Images

Selecting the Projection Quality (Color Mode)

Adjusting the Projection Position (Image Shift)

Adjusting the Volume

Selecting the Image Source

Automatically Detecting the Source (Source Search)

Selecting the Source from the Remote Control

Functions for Enhancing Projection

Additional Projector Functions

Muting the Image and Sound (A/V Mute)

Freezing the Image

Changing the Aspect Ratio

Displaying the Pointer

Enlarging Part of the Image (E-Zoom)

Using the Remote Control as a Mouse

Security Functions

Preventing theft (Password Protect)

Using the Operation Lock

Saving a User's Logo

Displaying Projected Images on an External Monitor

Using the Menu System

Configuration Menus

"Image" Menu

"Signal" Menu

"Settings" Menu

"Extended" Menu

"Info" Menu

"Reset" Menu

Cleaning

Maintenance

Cleaning the Projector

Cleaning the Air Filters and Air Intake Vent

Cleaning the Lens

Replacing Consumables

Replacing the Batteries

Lamp Replacement Period

Replacing the Lamp

Resetting the Lamp Operating Time

Replacing the Air Filter

Using the Help Menu

Troubleshooting

Problem Solving

Reading the Indicators

When the Indicators Provide No Help

Where To Get Help

Internet Support

Speak to a Support Representative

Purchase Supplies and Accessories

Optional Accessories and Consumables

Appendix

Screen Size and Projection Distance

Glossary

List of ESC/VP21 Commands

List of Supported Monitor Displays

Specifications

Dimensions

Declaration of Conformity

FCC Compliance Statement

Important Safety Instructions
