Offering a wider choice than any other
manufacturer – and spanning every
duty cycle, from light to heavy duty –
the Epson dot matrix range enables
you to strike exactly the right balance
between capability, performance and
cost. And built to the standards which
have made the Epson brand synony­mous with reliability, Epson dot matrix
printers are not only competitively
priced, but extremely economical to run.

Epson 9-pin dot matrix printers

Featuring durable, heavy and medium
duty printers for continuous data pro­cessing and high speed drafting tasks –
while offering competitively priced low
cost printers – the Epson 9-pin dot
matrix range offers exceptional value.

Outstanding performance combined with
high precision alignment and sophisticated
paper handling enables this truly com­prehensive range of narrow and wide
carriage printers to tackle the widest
range of high speed printing tasks with
supreme accuracy, making them ideal for
commercial, industrial and logistic applica­tions – including data processing, in­voicing, stock requisitions, cheque runs,
label printing etc.

Epson 24-pin dot matrix printers

Offering all the features available across
the Epson 9-pin range, but with the
addition of scalable fonts and letter
quality, for superior print quality, Epson
24-pin printers are ideal for front desk
applications in the retail and service
industries, and for tasks such as invoice
and order printing.

The range is further enhanced with flat­bed printers that enable 24-pin printing to
be achieved on less flexible materials and
a wide variety of non-standard stationery
such as receipts and label printing.

Epson is the world’s largest manufacturer of dot matrix
printers with a product range that offers the ultimate
in high speed, low cost, reliable and durable printing
across all stationery types. Ideal for drafting, high
volume data processing, and multi-part stationery –
for which there is simply no alternative – no other
technology offers such broad capability from a single
machine.

Epson LX 300+II

• USB interface

• larger input buffer

• added flash ROM
for firmware updates

Epson LX 1170 II

• USB interface

• added flash ROM
for firmware updates

Epson LQ 300+II

• USB interface

• larger input buffer

• added flash ROM
for firmware updates

NEW NEW NEW

Epson DFX-9000

The flagship model Epson DFX-9000 is the fastest
9-pin heavy duty dot matrix printer in its class. Built to bring
your business speed and reliability, it gives you the power to handle
the most demanding workloads quickly and at exceptional value.

DFX-9000

PLQ-20/20M

•••

•••

•

•••

•••

•••

•••

••

•

•

•

••

•••

•••

•

•

LQ-630

■

■

■

■

■

■

■

■

■

■

■

■

•••

•••

•••

••

••

••

LX-300+II

LX-1170II

FX-890

FX-2190

LQ-300+II

LQ-590

LQ-680/680 Pro

LQ-2090

LQ-2180

DLQ-3500

•••

•••

•••

•••

•••

••

••

•••

••

••

••

•••

•••

•

•••

■

PLQ-20D/20DM

•

•

•••

■

9-PinDuty 24-Pin POS

Instore Accounting Listing

Product Index

Passbook

Light

Medium

High
High

Heavy

Light

Medium

Light

Medium
Medium

High
Heavy
Heavy
Heavy

Motorised sheet feeders

For high volume cut sheet printing,
optional motorised cut sheet feeders
are available for selected products, like
the 150 sheet cut sheet feeder for the
Epson LQ-2180. Equipped with produc­tivity enhancing, independent motor
drives, these feeders reduce paper
handling time and ensure optimum paper
throughput.

Paper feed tractors

A choice of push, pull, and push/ pull
combined tractors not only enable more
than one stationery type to be per­manently loaded for delivery on demand,
but handle continuous and multi-part
stationery more efficiently.

Roll paper holder

This provides an inexpensive alternative
to using continuous roll paper for
applications requiring variable paper
lengths.

*Using Epson paper handling options

In their paper handling versatility, Epson dot matrix
printers really excel. Advanced models offer paper
feeding from up to six paper sources*, and enable up
to four types of stationery to be held ‘on call.’ What’s
more, when space is at a premium, multi-path paper
feed gives you flexibility to position your printer with­out compromising its functionality.

• Cut sheet manual feed front in –
front out

• Optional 150 sheet cut sheet feeder

• Optional 50 sheet cut sheet feeder

• Tractor fed continuous

Typical Paper Paths

Optional equipment

A comprehensive range of Epson
paper handling options includes:

Cut sheet feeders

Tractor unit

Cut sheet feeders

Offering 50, 150 and 250 sheet,
for automatic selection of forms
and plain stationery.

Flat

paper path

• Three continuous paper paths – front,
rear, and bottom

• Two cut sheet paper paths – front
and top

Compatibility – ESC/P2

ESC/P (Epson Software Command /
Printers) is the defacto standard dot
matrix printer control language, world­wide. Adopted in the vast majority of
popular software packages, ESC/P
enables you to plug straight in – and
print. The versatility and quality of Epson
impact printing is further extended by
ESC/P2 which enables Epson 24-pin
printers to achieve scalable fonts and
high resolution graphics.

Fully compatible with existing software,
ESC/P2 is designed for use with non
Windows

®

operating systems, enabling
you to achieve font manipulation without
the need for costly on-board processors.
If you are working within the Windows

®

environment you will be able to achieve
your printer’s maximum speed by using
printer resident fonts.

Connectivity

Epson connectivity goes far beyond USB,
parallel and serial interfaces. Where
Epson impact printers are required to
serve either as a shared resource or as a
personal printer within IBM or mainframe
environments, we offer Ethernet and
Wireless 802.11b. Epson discontinued
our Twinax, Coax and LocalTalk last
year due to non ROSHH compliance.

For full details of interfacing options
please refer to the options and
specifications tables at the back of this
brochure.

Epson supplies

Your Epson dot matrix printer demands
Epson ribbons for high performance.
Designed to withstand the stresses
of everyday use, Epson ribbons come
in three types – fabric, film and colour.

Epson fabric ribbons are highly durable
and hold an exact charge of ink to ensure
clear characters with no splattering.
To minimise printhead wear, Epson ink
includes lubricating oils.

Epson film ribbons are plastic, coated
on one side with ink to give clear, crisp
characters of letter quality output.

Colour printing

Colour printing highlights important
information and gives clarity to forms.
Epson colour ribbons are ultra tough
and produce colourful results without
bleed or smudging. An easily installed
colour upgrade is available for selected
printers. For full details of printing
options please refer to the options
and specifications tables at the back
of this brochure.

Because of its compact dimensions, the Epson LX-300+II
is the ideal 9-pin printer for front and back office
applications where space is limited. But also as a printer
for measurement and control systems the Epson LX-300+II
is a low cost solution. Auto switching USB, serial and
parallel interfaces are included allowing flexible standalone
connectivity.

Key features

• Compact 9-pin narrow carriage
printer

• Up to 337 characters per second
(12 cpi)

• Prints up to 5-part forms (1 original
+ 4 copies)

• Versatile top, bottom and rear
paper paths

• 8 built-in Bar code fonts

• Auto switching USB, parallel and
serial interfaces

Options

• 50 sheet cut sheet feeder

• Roll paper holder

• Colour upgrade kit

• Push/ Pull tractor unit

• Wired and Wireless network
interfaces

Standard Optional

Cut sheet

Standard Optional

Continuous

Dot Matrix Printer

9-Pin

LX-300+ II

Epson

Dot Matrix Printer Dot Matrix Printer

This narrow carriage printer combines high speed with
the highest reliability. A mean volume between failure
of 52 mill. lines makes it ideal for medium and large
print volumes. Paper can be fed from front, top, rear
or bottom and an optional push /pull tractor can store
a second continuous form – perfect for warehouses,
wholesalers, freight forwarders and finance departments.

The Epson LX-1170 II is the ideal 9-pin printer for light
duties. The copy capability of one original plus four
copies makes the Epson LX-1170 II suitable for a variety
of environments including data reporting (e.g. telephone
statistics and call log in, helpdesk and computer systems
reporting), listings, shipping documents and measurement
and control systems.

Key features

• Wide carriage 9-pin printer

• Up to 337 characters per second
(12 cpi)

• Prints up to 5-part forms (1 original
+ 4 copies)

• Versatile top, bottom and rear
paper paths

• 8 built-in Bar code fonts

• USB, parallel and serial interfaces
as standard

• USB interface

Options

• 50 sheet cut sheet feeder

• Roll paper holder

• Push/ Pull tractor unit

• Wired and Wireless network
interfaces

Key features

• Fastest printer in its class up to
680 cps (12 cpi)

• High copy capability of 6-part
forms

• Extremely robust printer with a
MTBF of 20,000 POH

• Reliable print head life of 400 mill.
characters

• Long lasting ribbon of 7.5 mill.
characters

• Versatile front, top, bottom and rear
paper paths

Options

• Wired and Wireless network
interfaces, Serial interfaces

• 150 or 50 sheet cut sheet feeders

• Front sheet

• Front paper guide

• Push/ pull tractor unit

• Roll paper holder

Standard Optional

Cut sheet

Standard Optional

Continuous

9-Pin

9-Pin

LX-1170 II

Epson

FX-890

Epson
