Epson iProjection Operating Guide

Epson iProjection Operation Guide
(Windows/Mac)

Contents

Introduction to the Epson iProjection Software ....................................................................................... 7
Setting Up the Software for the First Time .............................................................................................. 14
Epson iProjection Features .................................................................................................................. 7
Connection to Various Devices........................................................................................................ 7
Four-Panel Display.......................................................................................................................... 8
Change Presenters and Projection Position .................................................................................... 9
Screen Delivery and Thumbnail Display Function ......................................................................... 11
Easy Network Projection Using a USB Flash Drive (Windows Only) ............................................. 12
Installing the Software ........................................................................................................................ 14
Epson iProjection System Requirements ...................................................................................... 14
Epson iProjection Editions............................................................................................................. 16
Installing the Epson iProjection Software (Windows)..................................................................... 16
Installing the Epson iProjection Software (Mac) ............................................................................ 17
Selecting Projector Network Settings ................................................................................................. 17
Connection Methods for Various Network Environments .............................................................. 17
Recommended Wireless Environment for Multi PC Projection ...................................................... 19
Setting Up a Projector to Connect in Quick Connection Mode....................................................... 20
Setting Up a Projector to Connect in Advanced Connection Mode (Wireless) ............................... 21
Setting Up a Projector to Connect in Advanced Connection Mode (Wired) ................................... 22
Connecting to the Projector and Projecting Images .............................................................................. 23
Connection Methods .......................................................................................................................... 23
Connection Methods for Various Meeting Styles ........................................................................... 23
Connecting the Projector and a Computer Directly Using Wireless Communication ..................... 25
Connecting to the Projector from the Software over a Network System ........................................ 31
Selecting the Projector Search Method .............................................................................................. 35
Search Methods ............................................................................................................................ 36
Searching for Network Projectors Automatically............................................................................ 36
Searching for Network Projectors by Specifying an IP Address or Projector Name ....................... 37
Searching for Network Projectors Using a Profile .......................................................................... 39
3
Profiles for Search .................................................................................................................... 39
Performing a Profile Search ...................................................................................................... 39
Registering a Profile.................................................................................................................. 41
Exporting a Profile..................................................................................................................... 43
Importing a Profile..................................................................................................................... 43
Sharing a Profile over a Network............................................................................................... 44
Controlling the Projected Display ....................................................................................................... 45
Screen Types for Projection Control.............................................................................................. 45
Operating the Projected Display Status......................................................................................... 47
Changing the Number of Projected Panels.................................................................................... 47
Changing the Projection Position................................................................................................... 50
Disconnecting..................................................................................................................................... 51
Using Additional Functions...................................................................................................................... 54
Searching for Network Projectors Using a Shortcut ........................................................................... 54
Creating a Shortcut........................................................................................................................ 54
Connecting to Network Projector Using a USB Flash Drive (Windows Only) ..................................... 55
Creating a USB key on a USB Flash Drive (Windows Only) .......................................................... 55
Using a USB Key to Connect a Windows Computer ...................................................................... 56
Connecting to Multiple Projectors (Mirroring) ..................................................................................... 58
Outputting Audio from the Projector ................................................................................................... 59
Projecting Your Screen ...................................................................................................................... 60
Changing the Moderator..................................................................................................................... 61
Distributing the Projected Screen....................................................................................................... 63
Selecting the Participant's Screen to Project Using Thumbnails ........................................................ 64
Hiding the Projection Control Screen ................................................................................................. 65
Prohibiting Participant Operations...................................................................................................... 66
Controlling the Connection Bandwidth ............................................................................................... 67
Bandwidth Control Restrictions ..................................................................................................... 69
Solving Problems ...................................................................................................................................... 70
Solving Network Connection Problems .............................................................................................. 70
Solutions When You Cannot Connect Using Quick Connection Mode .......................................... 70
4
Solutions When You Cannot Connect Projectors Using Advanced Connection Mode (Wired)...... 73
Solving Problems During Projection................................................................................................... 75
Solutions When the Screen is Not Projected Properly................................................................... 75
Solutions When Audio is Not Played Properly ............................................................................... 76
Solutions When the Moderator Function Does Not Work .............................................................. 76
Solutions When the Projected Screen is Not Delivered ................................................................. 77
Error Messages List ........................................................................................................................... 77
Error Messages When Starting up the Epson iProjection Software ............................................... 78
Error Messages When Using a USB Key....................................................................................... 80
Error Messages When Searching for and Selecting Projectors ..................................................... 81
Error Messages When Projecting .................................................................................................. 82
Error Messages When Operating a Profile .................................................................................... 82
Error Messages When Using the Moderator Function ................................................................... 84
Event ID List ....................................................................................................................................... 85
Screen Summary ....................................................................................................................................... 87
Select Connection Mode Screen........................................................................................................ 88
Search Screen ................................................................................................................................... 89
Save Screen....................................................................................................................................... 92
Set options ......................................................................................................................................... 93
Set options - User Settings ............................................................................................................ 94
Set options - General settings ....................................................................................................... 95
Set options - Adjust performance .................................................................................................. 98
Set options - Audio Output........................................................................................................... 100
Set options - Deliver .................................................................................................................... 101
Toolbar............................................................................................................................................. 102
Projection Control Screen ................................................................................................................ 105
Thumbnail Screen ............................................................................................................................ 109
Viewer Screen.................................................................................................................................. 111
Appendix .................................................................................................................................................. 113
Updating and Uninstalling the Software ........................................................................................... 113
Getting the Latest Version of the Software .................................................................................. 113
Uninstalling the Epson iProjection Software (Windows 7) ........................................................... 113
5
Uninstalling the Epson iProjection Software (Windows 8.x/Windows 10) .................................... 114
Uninstalling the Epson iProjection Software (Mac)...................................................................... 114
Supported Resolutions and Colors................................................................................................... 114
Supported Resolutions ................................................................................................................ 115
Display Color ............................................................................................................................... 115
Limitations........................................................................................................................................ 115
Connection Limitations ................................................................................................................ 116
Limitations when Projecting from Windows Photo Gallery or Windows Live Photo Gallery ......... 116
Limitations in Windows Aero........................................................................................................ 117
Limitations when Projecting from Windows Media Center ........................................................... 118
Notices ............................................................................................................................................. 118
Copyright Notice.......................................................................................................................... 118
About Notations........................................................................................................................... 119
General Notice............................................................................................................................. 119
Copyright Attribution.................................................................................................................... 120
6

Introduction to the Epson iProjection Software

See the information here to learn more about the Epson iProjection software.

Epson iProjection Features

Epson iProjection Features
The Epson iProjection software is an application that allows you to hold interactive meetings or lessons by projecting images from network projectors. You can use a variety of display options for your environment.
Connection to Various Devices Four-Panel Display Change Presenters and Projection Position Moderator Function Screen Delivery and Thumbnail Display Function Easy Network Projection Using a USB Flash Drive (Windows Only)
Parent topic: Introduction to the Epson iProjection Software

Connection to Various Devices

You can connect up to 50 devices to a projector simultaneously, such as computers, smartphones and tablets using the Epson iProjection software. (Up to four devices can project at one time.)
7
You can also hold remote meetings over a network by simultaneously projecting the same image on up to four projectors on the network.
Parent topic: Epson iProjection Features
Related tasks
Connecting to Multiple Projectors (Mirroring)
Related topics
Connection Methods

Four-Panel Display

You can simultaneously display up to four screens in separate projected panels, which is useful in both business and educational environments.
8
For example, you can compare and analyze data while simultaneously projecting screens from multiple devices. In an educational environment, you can project lesson material on one part of the screen and student answers on another to enhance the learning experience.
Parent topic: Epson iProjection Features
Related tasks
Changing the Number of Projected Panels

Change Presenters and Projection Position

Using the Epson iProjection software, you can easily change the screen being projected and the projection position by simply dragging and dropping user names in panels on the projection control screen.
9
You can share the projector with other users on the same network without having to change cable connections, allowing users to take turns giving presentations.
Note: The projection control screen is available only on the Standard Edition of the software.
Parent topic: Epson iProjection Features
Related tasks
Changing the Presenter Changing the Projection Position

Moderator Function

When using the moderator function, only one person plays a role of moderator who can control the projected display. This function is suitable for meetings in which one user is the moderator and the other users are participants, and the moderator must control the projected display.
This can also be useful in a classroom environment where the moderator must control the lesson without interruption.
10
Note: This function is available only for supported models.
Parent topic: Epson iProjection Features
Related tasks
Changing the Moderator
Related topics
Connection Methods

Screen Delivery and Thumbnail Display Function

You can distribute the currently projected screen images to the participant's devices. The participants can then add notes to the received images using drawing software, which the moderator can check as
11
thumbnails. This feature is suitable for environments where the moderator wants to provide questions for the participants to answer, and then select which answers or ideas to project in response.
Note: This function is available only for supported models.
Parent topic: Epson iProjection Features
Related tasks
Distributing the Projected Screen Selecting the Participant's Screen to Project Using Thumbnails

Easy Network Projection Using a USB Flash Drive (Windows Only)

You can use a commercially available USB flash drive as a USB key to transfer the projector's network information to a Windows computer. Creating the USB key allows you to quickly project images from the network projector.
12
When you change the presenter, you can switch the projected screen by inserting the USB key to a new presenter's computer.
Note:
• This function is available only for supported models. See your projector User's Guide for more details.
• You cannot use the USB key as a projector's wireless LAN module.
Parent topic: Epson iProjection Features
Related topics
Connecting to Network Projector Using a USB Flash Drive (Windows Only)
13

Setting Up the Software for the First Time

Follow these instructions before connecting a computer to the projector over a network.
Installing the Software Selecting Projector Network Settings

Installing the Software

Install the Epson iProjection software by downloading it from the Epson Web site.
Note:
• If the language selected for the installation differs from the language of the operating system being used, the screens may not display correctly.
• If any earlier version of this software or EasyMP Multi PC Projection is installed on your computer, uninstall it first and then install the Epson iProjection software.
Epson iProjection System Requirements Epson iProjection Editions Installing the Epson iProjection Software (Windows) Installing the Epson iProjection Software (Mac)
Parent topic: Setting Up the Software for the First Time
Related tasks
Getting the Latest Version of the Software

Epson iProjection System Requirements

Your computer must meet the following system requirements to use the Epson iProjection software.
14
Requirement Windows Mac
Operating system Windows 7
• Ultimate (32- and 64-bit)
• Enterprise (32- and 64-bit)
• Professional (32- and 64-bit)
• Home Premium (32- and 64-bit)
• Home Basic (32-bit)
• Starter (32-bit)
Windows 8
• Windows 8 (32- and 64-bit)
• Windows 8 Pro (32- and 64-bit)
• Windows 8 Enterprise (32- and 64-bit)
Windows 8.1
• Windows 8.1 (32- and 64-bit)
• Windows 8.1 Pro (32- and 64-bit)
• Windows 8.1 Enterprise (32- and 64­bit)
Windows 10
OS X
• 10.11.x (64-bit)
macOS
• 10.12.x (64-bit)
• 10.13.x (64-bit)
• 10.14.x (64-bit)
• Windows 10 Home (32- and 64-bit)
• Windows 10 Pro (32- and 64-bit)
• Windows 10 Enterprise (32- and 64­bit)
CPU Intel Core2Duo or faster
(Intel Core i3 or faster recommended)
Memory 2GB or more
(4GB or more recommended)
Hard disk space 50 MB or more
15
Intel Core2Duo or faster
(Intel Core i5 or faster recommended)
Requirement Windows Mac
Display Resolution between 800 × 600 (SVGA) and 1920 × 1200 (WUXGA)
Note: Operation is not guaranteed for Windows 7 without any service packs installed.
Parent topic: Installing the Software

Epson iProjection Editions

You can choose the software edition to install that suits your role in the projection environment.
• Standard Edition
You can use all functions of the Epson iProjection software.
You can control the projected image and also function as a moderator.
• Participant Edition
You can connect to the projector only as a participant of the moderator function and cannot control the projected images.
Note: If you want to switch editions, uninstall and reinstall this software.
Parent topic: Installing the Software
16-bit color or greater (approximately 32,000 display colors)

Installing the Epson iProjection Software (Windows)

Install the Epson iProjection software on your computer.
Note: You need administrator authority to install the software.
1. Turn on your computer.
2. Make sure all running applications are closed.
3. Download the software from the Epson Web site.
4. Follow the on-screen instructions to install.
Parent topic: Installing the Software
16

Installing the Epson iProjection Software (Mac)

Install the Epson iProjection software on your computer.
1. Turn on your computer.
2. Make sure all running applications are closed.
3. Download the software from the Epson Web site.
4. Follow the on-screen instructions to install.
Parent topic: Installing the Software

Selecting Projector Network Settings

Follow these instructions to select a connection method between a computer and the projector, and then set up the projector.
Connection Methods for Various Network Environments Recommended Wireless Environment for Multi PC Projection Setting Up a Projector to Connect in Quick Connection Mode Setting Up a Projector to Connect in Advanced Connection Mode (Wireless) Setting Up a Projector to Connect in Advanced Connection Mode (Wired)
Parent topic: Setting Up the Software for the First Time

Connection Methods for Various Network Environments

You can choose a connection mode to suit your network environment.
Check how the projector is connected to the network system (wireless or wired) and the communication path from the computer to the projector.
17
Depending on your projector, some connection methods may not be available. See your projector User's Guide for more details.
• To connect the projector to the computer directly using wireless communication: Use Quick Connection Mode.
• To connect the projector to the computer using a wireless network system: Use Advanced Connection Mode.
18
• To connect the projector to the computer using a wired network system: Use Advanced Connection Mode.
Parent topic: Selecting Projector Network Settings

Recommended Wireless Environment for Multi PC Projection

When you connect multiple devices to a projector using the Quick connection mode, we recommend limiting the number of devices to six or less to maintain the projection performance. The number of devices that can connect to a projector at the same time differs depending on the wireless communication environment.
When you connect a projector to a wireless LAN and connect multiple devices wirelessly using the Advanced connection mode, note the following recommendations.
• Set up multiple access points so that one of the access points can connect up to 10 or 20 devices. See the access point manual for more information on the maximum number of devices that can be connected.
• When you use multiple access points, assign a different channel to each access point, and use different access points for the projector connection and the computer connection.
• Use a wireless LAN controller, if possible, to enhance the connection stability.
• Use an access point that supports 802.11n.
Contact your network administrator for help in setting up the wireless environment.
19
Note: If your projector supports a wired LAN connection, we recommend using a wired LAN connection
when you connect multiple devices to the projector.
Parent topic: Selecting Projector Network Settings

Setting Up a Projector to Connect in Quick Connection Mode

To connect a computer directly to the projector using wireless communication, you need to select network settings on the computer and the projector.
Note: The necessary settings vary depending on your projector. See your projector User's Guide for instructions.
1. Select the necessary settings to connect your computer to a wireless LAN. See the documentation
supplied with your computer for more details.
2. Install the wireless LAN unit in the projector, if necessary. See your projector User's Guide for
instructions.
3. Turn on the projector.
4. Press the Menu button on the remote control or the control panel, and select the Network menu.
5. Turn on wireless LAN support.
6. Select one of these settings to connect the projector to the computer directly using wireless
communication. The necessary settings vary depending on your projector.
• Turn on the Simple AP setting.
• Select Quick for Connection Mode.
7. Select other options as necessary for your network. See your projector User's Guide for instructions.
8. Select security settings. Check with your network administrator for more information on choosing the
correct settings.
9. When you have finished selecting settings, save your settings and exit the menus.
Parent topic: Selecting Projector Network Settings
Related tasks
Connecting the Projector and a Computer Directly Using Wireless Communication
20

Setting Up a Projector to Connect in Advanced Connection Mode (Wireless)

To connect a computer to the projector over a wireless LAN, you need to select network settings on the computer and the projector.
Note: The necessary settings vary depending on your projector. See your projector User's Guide for instructions.
1. Contact your network administrator and write down the settings for the access point, such as the
SSID and security settings.
2. Connect the computer to the network.
Note: To set up a network connection, if necessary, see the documentation supplied with your computer or network adapter.
3. Install the wireless LAN unit in the projector, if necessary. See your projector User's Guide for
instructions.
4. Turn on the projector.
5. Press the Menu button on the remote control or the control panel, and select the Network menu.
6. Turn on wireless LAN support.
7. Select one of these settings to connect the projector to a wireless LAN. The necessary settings vary
depending on your projector.
• Turn off the Simple AP setting.
• Select Advanced for Connection Mode.
8. Select other options as necessary for your network. See your projector User's Guide for instructions.
9. Select security settings as necessary for your network. Check with your network administrator for
more information on choosing the correct settings.
10. When you have finished selecting settings, save your settings and exit the menus.
Parent topic: Selecting Projector Network Settings
Related tasks
Connecting to the Projector from the Software over a Network System
21

Setting Up a Projector to Connect in Advanced Connection Mode (Wired)

To connect a computer to the projector using a wired LAN, you need to select network settings on the computer and the projector.
1. Contact your network administrator and check that DHCP is available under the current network
environment.
Note: If DHCP is not available, write down the following values that are available for your projector.
• IP Address
• Subnet Mask
• Gateway Address
2. Connect the computer to the network.
Note: To set up a network connection, if necessary, see the documentation supplied with your computer or network adapter.
3. Connect a LAN cable to the projector.
4. Turn on the projector.
5. Press the Menu button on the remote control or the control panel, and select the Network menu.
6. Select these IP settings for your wired LAN as necessary.
• DHCP is available: Set DHCP to On.
• DHCP is not available: Set DHCP to Off and enter the projector's IP Address, Subnet Mask, and Gateway Address values as necessary.
7. When you have finished selecting settings, save your settings and exit the menus.
Parent topic: Selecting Projector Network Settings
Related tasks
Connecting to the Projector from the Software over a Network System
22

Connecting to the Projector and Projecting Images

Follow these instructions to connect the computer and the projector over a network, and to project images from your computer's screen using the projector.
Make sure you have already set up the software and selected a connection mode for the projector.
Connection Methods Selecting the Projector Search Method Controlling the Projected Display Disconnecting
Related topics
Installing the Software Selecting Projector Network Settings

Connection Methods

You can select a suitable method to connect the computer and the projector over a network depending on your meeting style.
Connection Methods for Various Meeting Styles Connecting the Projector and a Computer Directly Using Wireless Communication Connecting to the Projector from the Software over a Network System
Parent topic: Connecting to the Projector and Projecting Images

Connection Methods for Various Meeting Styles

You can choose a connection method to suit the style of your meeting.
Decide how you want to hold your meeting. Depending on the connection method you selected, the connection procedure differs.
23
Note: Depending on your projector, some connection methods may not be available. See your projector
User's Guide for more details.
• All users can control the projected display and become presenters. (Holding discussions and interacting with other users in a business environment.)
24
• Only one user is the moderator and has full control over the meeting using the moderator function. (Holding a class or lesson using the participants' computer screens in an educational environment.)
Note: To start a meeting using the moderator function, one user must connect to the projector as the moderator and the other users must connect to the projector as participants.
Parent topic: Connection Methods
Related tasks
Changing the Moderator Connecting to the Projector from the Software over a Network System

Connecting the Projector and a Computer Directly Using Wireless Communication

When your projector is set up as indicated below, you can connect the projector and a computer directly using wireless communication to project the computer's screen.
• The wireless LAN unit is installed in the projector or the projector has built-in wireless LAN modules.
25
• You select one of these settings to connect the projector to the computer directly using wireless communication. The necessary settings vary depending on your projector.
• Turn on the Simple AP setting.
• Select Quick for Connection Mode.
Note:
• When you use the Participant Edition of the software, you must connect the projector and a computer over a network system.
• When you connect the projector and a computer directly using wireless communication, the connection between the computer and an access point is disconnected.
• Make sure you turn on your computer's wireless communication function.
1. Press the LAN button or Source Search button on the remote control to switch the input source to
LAN.
You see the network information screen.
2. Start the Epson iProjection software.
• Windows 7: Click Start, select Programs (or All Programs), EPSON Projector, Epson iProjection, and then click Epson iProjection Ver.X.XX.
• Windows 8 and Windows 8.1: Navigate to the Apps screen and select Epson iProjection Ver.X.XX.
• Windows 10: Select Start, EPSON Projector, and then select Epson iProjection.
26
• Mac: Double-click Epson iProjection from the Applications folder.
Note: You can also create a shortcut and use it to start the Epson iProjection software and to
automatically search for saved projectors.
3. Select Quick Connection Mode, and then click OK.
4. Search for the projector using one of the following methods.
• Automatic Search: Searches for the projector automatically.
• Profile: Searches for the projector based on a previously saved profile.
The projector search results are displayed.
5. Select the projector you want to connect to from the Projector List, and then select one of the following options.
• You want all users to be able to become participants in the moderator function: Make sure
Connect as a Moderator, or disable interrupt connections is not selected, and then click Join.
27
• You are the moderator user and you do not want other users to be able to interrupt the moderator
presentation: Select Connect as a Moderator, or disable interrupt connections, and then click
Join.
Note:
• The moderator function is available only for supported models and is available only on the
Standard Edition of the software.
• When one user connects as a moderator, the moderator function turns on.
When the Projector Keyword is set to On or the Moderator Password is set in the projector settings, the keyword entry screen is displayed.
6. Enter the Projector Keyword displayed on a screen, and then press OK.
28
7. When the following dialog box is displayed, enter the passphrase set on the projector, and then click
Connect.
Note: If you select Save the passphrase and don't show this dialog box again, the projector's
SSID and passphrase are saved on the computer and this dialog box is not displayed the next time you connect. You do not have to enter the passphrase again.
29
If the projector's passphrase has not been changed from the default, the following dialog box is displayed. Change the passphrase from the projector's Network menu.
When a connection is established, the computer screen is projected and the following toolbar is displayed on the computer screen.
The computer screen for the user who connects first is projected in full screen mode. Users who connect
later can project their own screen by clicking the button on the toolbar or can control the projected
display from the projection control screen by clicking the button on the toolbar.
Note:
• When a connection is established, the input source for the projector automatically switches to the LAN
source if no other signal is being input. If the input source does not automatically switch to the LAN source, press the LAN button or Source Search button on the remote control.
• The displayed toolbar varies depending on the connection method and the edition of the software.
30
Loading...
+ 90 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
