Epson BOSSTX2 CE 5.0 User Manual
BOSSTX2 CE 5.0 User's Manual
Windows-Based Terminal
User’s Manual
BOSSTX2 CE 5.0 User's Manual
TABLE OF CONTENTS
CHAPTER 1 License Agreement ……………………………………….………………………….……..….
CHAPTER 2 Product Review………………………………………….………………….……….……….….5
2.1 WBTs………………………………………………………………………….….…………….….5
2.2 Terminal Specifications…………………………………………………….…………………….5
2.3 Terminal Features……………………………………………………………….…………….….6
2.4 Terminal Overview……………………………………………………….……………………….6
2.4.1 Connecting the Terminal……………………………………………………………..….6
2.4.2 Connector Descriptions………………………………………………….……………….7
CHAPTER 3 Initial Terminal Setup................................................................................................ …..10
3.1 Hot Keys Functions ..................................................................................................... …..10
3.2 Setup Wizard...............................................................................................................…..10
3.2.1 Network Configuration ....................................................................................... …..11
3.2.1.1 Use the IP information supplied by DHCP.................................................…..11
3.2.1.2 Specify a static IP address......................................................................... …..12
3.2.2 Enable/Disable Name Resolution Services .....................................................…..12
3.2.3 Alternative Display Settings ............................................................................. …..13
3.2.4 Local Printer Setup...........................................................................................…..14
3.2.5 Select the Printer Port ...................................................................................... …..14
3.2.6 Select the Printer Model................................................................................... …..16
3.2.6.1 Select the Printer Model ..........................................................................…..16
3.2.6.2 User Define ..............................................................................................…..18
3.2.7 Finish the Setup Wizard ................................................................................... …..20
2
CHAPTER 4 Connections Management ....................................................................................... …..21
4.1 Using the Connections Properties Sheet .................................................................... …..21
4.2 Using the Configure Properties Sheet ........................................................................…..21
4.3 Creating New Connections ......................................................................................... …..22
4.3.1 Choosing a Connection Protocol .......................................................................…..22
4.4 RDP Connection.......................................................................................................... …..23
4.4.1 General Tab………………………………………………………..…………………….24
4.4.2 Display Tab………………………….……………………………...…………………25
4.4.3 Local Resource Tab………………………………………………………………….25
4.4.4 Programs Tab…………………………………………………………………………26
4.4.5 Experience Tab……………………………………………………………………….26
4.5 ICA Connection ........................................................................................................... …..27
4.5.1 Creating a New ICA Connection Entry .............................................................. …..27
4.5.2 Connecting to a Citrix Server ............................................................................. …..30
4.5.3 Changing a Connection Entry ............................................................................ …..30
4.5.3.1 To change the properties of a connection entry ........................................…..31
4.5.3.2 Specifying an Application to Run after Connecting to a Citrix Server ....... …..31
4.5.3.3 Specifying Logon Information ....................................................................…..32
4.5.3.4 Changing the Window Properties .............................................................. …..32
4.5.3.5 Setting Connection Entry Options.............................................................. …..33
4.5.3.6 Changing the Title of the Connection Entry ............................................... …..34
4.5.3.7 Configuring Firewall Settings ..................................................................... …..34
4.6 Remote Dial-Up/ Direct Cable Connection/ VPN Operations / PPPOE...................... …..36
4.6.1 Remote Dial-Up Connection .............................................................................. …..36
4.6.2 Direct Connection............................................................................................... …..41
4.6.3 Virtual Private Network Connection ................................................................... …..42
4.6.4 PPP over Ethernet Connection (PPPoE)………………………………………….43
BOSSTX2 CE 5.0 User's Manual
4.7 Microsoft Internet Explorer Connection....................................................................... …..44
4.7.1 To Make a New Microsoft Internet Explorer Connection ................................... …..44
4.7.2 To Start a Microsoft Internet Explorer Connection............................................. …..48
4.8 Microsoft Media Player………………………………………………………………………48
4.8.1 To Make a New Microsoft Media Player Connection..……………………………48
4.8.2 The MediaPlayer Editor V2.0………….…………………………………………….48
4.8.3 To Start a Microsoft Media Plays Connections…….…………...…………………49
CHAPTER 5 Advanced Function for Connections ...................................................................... …..50
5.1 Multiple Auto Start-Up ................................................................................................. …..50
5.2 Multiple Auto Reconnect ............................................................................................. …..50
CHAPTER 6 Terminal Properties................................................................................................... …..51
6.1 General Tab ................................................................................................................…..51
6.1.1 Reset the terminal to factory default property settings ......................................…..51
6.2 Display Configuration .................................................................................................. …..52
6.2.1 Enable Screen Saver ........................................................................................... …..52
6.3 Control Panel Tab .......................................................................................................…..53
6.3.1 Printers Properties .............................................................................................…..53
6.3.1.1 Select the Printer Model............................................................................. …..54
6.3.2 Keyboard Input................................................................................................... …..55
6.3.3 Owner Properties ............................................................................................... …..55
6.3.4 System Properties..............................................................................................…..56
6.3.5 Mouse Properties ............................................................................................... …..58
6.3.6 Volume & Sound Properties............................................................................... …..58
6.3.7 Date/Time Properties ......................................................................................... …..60
6.3.8 Storage Manager Properties..............................................................................…..60
6.3.9 Regional and Language Setting......................................................................... …..60
6.3.10 Network Status Properties ................................................................................. …..62
6.3.11 Security Properties............................................................................................. …..63
6.3.12 Ping Properties ..................................................................................................…..64
6.3.13 Application Properties........................................................................................ …..65
6.3.14 Line Printer Daemon Setup ...............................................................................…..65
6.3.14.1 Setup for LPD .............................................................................................. …..65
6.3.14.2 Add a remote printer.................................................................................... …..68
6.3.14.3 LPD Printing................................................................................................. …..70
6.3.15 Global ICA Client Settings .................................................................................…..70
6.3.15.1 Configuring Hotkeys .................................................................................... …..71
6.3.15.2 Configuring Global Preferences ..................................................................…..72
6.3.15.3 Sever Location............................................................................................. …..73
6.3.15.4 Firewall Settings ..........................................................................................…..74
6.3.15.5 PNLite Settings ............................................................................................ …..75
6.3.16 FTP Update........................................................................................................ …..75
6.3.17 Certificates…………………….……………………………………………………….75
6.3.18 Terminal Service Client License……………………………………………………..76
6.3.19 Touch Panel Settings………………………………………………………………….77
6.3.20 Desktop Style…………………………………………………………………………..78
CHAPTER 7 Using ICA Local Printer ............................................................................................ …..79
7.1 Mapping Client Printers on MetaFrame for Windows .................................................…..79
7.1.1 To view mapped client printers when connected to a MetaFrame server ......... …..79
7.1.2 To manually map a client printer on a MetaFrame server ................................. …..79
BOSSTX2 CE 5.0 User's Manual
CHAPTER 8 Desktop Mode
8.1 Control Panel ………………………………………………………………………………….80
8.1.1 Display Properties ………………………………………………………………………80
8.1.2 General Properties ……………………………………………………………………..81
8.2 Add a Connection …………………………………………………………………………….81
8.3 Advanced Function on Desktop Mode…………………………………………………82
8.3.1 Task Manager…………………………………………………………………………..82
8.3.2 Task Bar………………………………………………………………………………….82
8.3.3 Hot Key Functions ..…………………………………………………………………….83
BOSSTX2 CE 5.0 User's Manual
Trademarks
ICA 3 is a registered trademark and MetaFrame is a trademark of Citrix Systems Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
All other products are trademarks and/or registered trademarks of their respective companies.
The Energy Star emblem does not represent endorsement of any product or service.
Specifications subject to change without notice.
FCC Statement
This equipment has been tested and found to comply with the limits for either Class A or Class B digital devices,
pursuant to Part15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
§ Reorient or relocate the receiving antenna.
§ Increase the separation between the equipment and the receiver.
§ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
§ Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according
to the manufacturer’s instructions.
BOSSTX2 CE 5.0 User's Manual
License Agreement
YOU SHOULD CAREFULLY READ THE FOLLOWING TERMS AND CONDITIONS BEFORE USING THIS EQUIPMENT WHICH
CONTAINS SOFTWARE IN A NON-VOLATILE FORMAT AND CERTAIN OTHER INTELLECTUAL PROPERTY (HEREAFTER
“FIRMWARE”). USING THIS EQUIPMENT INDICATES YOUR ACCEPTANCE OF THE FOLLOWING TERMS AND CONDITIONS.
Grant
You may use the Firmware in or in conjunction with the Equipment as provided to You. You may transfer ownership of the Equipment,
including the right to use the Firmware to another party so long as that party agrees to accept these terms and conditions.
YOU MAY NOT USE, COPY, MODIFY, TRANSLATE OR TRANSFER THE FIRMWARE, OR MODIFICATION THEREOF, IN WHOLE OR
IN PART, EXCEPT AS EXPRESSLY PROVIDED FOR IN THIS LICENSE. YOU MAY NOT DECOMPILE, REVERSE ENGINEER OR
OTHERWISE DECODE OR ALTER THE SOFTWARE CONTAINED IN THE FIRMWARE.
Limited Software Warranty and Disclaimer
We warrant that, for a period of ninety (90) days from the date of shipment, the Firmware will, under normal use, be free from defects in
materials and workmanship in the EPROM (or similar storage device). The foregoing warranty shall not apply to any Firmware that has been
used in violation of this Agreement. During this limited warranty period We will provide support by phone on a best-efforts basis. We may, in
addition to the above, replace any defective Firmware with a functionally equivalent product. The foregoing shall be Your exclusive remedy
for any breach of warranty hereunder. You assume responsibility for choosing the Equipment containing the Firmware to achieve your
intended results, and for the installation, use and results obtained from the Equipment and Firmware.
EXCEPT FOR THE ABOVE EXPRESS LIMITED WARRANTIES, WE MAKE AND YOU RECEIVE NO WARRANTIES ON THE FIRMWARE,
EXPRESS, IMPLIED, OR STATUTORY, OR IN ANY OTHER PROVISION OF THIS AGREEMENT OR COMMUNICATION WITH YOU,
AND WE DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT AND FITNESS FOR ANY
PARTICULAR PURPOSE. WE DO NOT WARRANT THAT THE FUNCTIONS CONTAINED IN THE PRODUCT WILL MEET YOUR
REQUIREMENTS OR THAT THE OPERATION WILL BE UNINTERRUPTED OR ERROR FREE.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH
VARY FROM STATE TO STATE.
Limit of Liability
UNDER NO CIRCUMSTANCES SHALL WE BE LIABLE FOR LOSS OF DATA, COST OF COVER, OR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY. THESE LIMITATIONS SHALL APPLY EVEN
IF WE OR OUR RESELLERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND NOTWITHSTANDING ANY
FAILURE OF ESSENTIAL PURPOSE OF ANY LIMITED REMEDY PROVIDED HEREIN.
YOU AGREE THAT THESE ARE THE ONLY APPLICABLE TERMS OF AGREEMENT BETWEEN US COVERING FIRMWARE AND THAT
THEY SUPERSEDE ANY OTHER COMMUNICATIONS (ORAL OR WRITTEN) BETWEEN US RELATING TO THE FIRMWARE.
U.S. Government Restricted Rights
The Firmware is provided with RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to restrictions as set
forth in subparagraph (c)(1)(ii) of the Rights in Technological Data and computer software clause at DFARS 252.227-7013 or in
subparagraphs (c)(1) and (2) of the Commercial Computer Software-Restricted Rights at 8 C.F.R. 52-227-19 as applicable.
BOSSTX2 CE 5.0 User's Manual
EULA for Microsoft® Windows® CE Operating System for Windows-based
Terminal Devices Version 1.5
IMPORTANT—READ CAREFULLY
This End User License Agreement (EULA) is a legal agreement between you (either an individual or a single entity) and the
manufacturer (MANUFACTURER) of the special purpose computing device (SYSTEM) you acquired which includes certain
Microsoft software product(s) installed on the SYSTEM and/or included in the SYSTEM package (SOFTWARE). The SOFTWARE
includes computer software, the associated media, any printed materials, and any online or electronic documentation. By
installing, copying or otherwise using the SOFTWARE, you agree to be bound by the terms of this EULA. If you do not agree to the
terms of this EULA, MANUFACTURER and Microsoft Licensing, Inc. (MS) are unwilling to license the SOFTWARE to you. In such
event, you may not use or copy the SOFTWARE, and you should promptly contact MANUFACTURER for instructions on return of
the unused product(s) for a refund.
Software License
The SOFTWARE is protected by copyright laws and international copyright treaties, as well as other intellectual property laws and treaties.
The SOFTWARE is licensed, not sold.
BOSSTX2 CE 5.0 User's Manual
1.Grant of License
SOFTWARE includes software already installed on the SYSTEM
(SYSTEM SOFTWARE) and, if included in the SYSTEM package,
software contained on the CD-ROM disk and/or floppy disk(s)
labeled "Desktop Software for Microsoft Windows CE" (DESKTOP
SOFTWARE). This EULA grants you the following rights to the
SOFTWARE:
SYSTEM SOFTWARE
You may use the SYSTEM SOFTWARE only as installed in the
SYSTEM.
DESKTOP SOFTWARE
DESKTOP SOFTWARE might not be included with your SYSTEM.
If DESKTOP SOFTWARE is included with your SYSTEM, you may
install and use the component(s) of the DESKTOP SOFTWARE in
accordance with the terms of the end user license agreement
provided with such component(s). In the absence of a separate
end user license agreement for particular component(s) of the
DESKTOP SOFTWARE, you may install and use only one (1) copy
of such component(s) on a single computer with which you use the
SYSTEM.
Server, Use of Windows CE Operating System for
Windows-Based Terminal Devices with Microsoft Windows NT
Server, Terminal Server Edition
If the SOFTWARE is Windows CE operating system for
Windows-Based Terminal devices, the following special provisions
apply. In order to use the SYSTEM in connection with Windows NT
Terminal Server Edition, you must possess (1) a Client Access
License for Windows NT Server, Terminal Server Edition and (2)
an end user license for Windows NT Workstation or an end user
license agreement for Windows NT Workstation for
Windows-Based Terminal Devices (please refer to the end user
license agreement for Windows NT Server, Terminal Server Edition
for additional information). MANUFACTURER may have included a
Certificate of Authenticity for Windows NT Workstation for
Windows-Based Terminal Devices with the SYSTEM. In that case,
this EULA constitutes an end user license for the version of
Windows NT Workstation for Windows-Based Terminal Devices
indicated on such Certificate of Authenticity.
Back-up Copy
If MANUFACTURER has not included a back-up copy of the
SYSTEM SOFTWARE with the SYSTEM, you may make a single
back-up copy of the SYSTEM SOFTWARE. You may use the
back-up copy solely for archival purposes.
You may not reverse engineer, de-compile, or disassemble the
SYSTEM SOFTWARE, except and only to the extent that such
activity is expressly permitted by applicable law notwithstanding
this limitation.
Single SYSTEM
The SYSTEM SOFTWARE is licensed with the SYSTEM as a
single integrated product. The SYSTEM SOFTWARE installed in
Read Only Memory (ROM) of the SYSTEM may only be used as
part of the SYSTEM.
Single EULA
The package for the SYSTEM SOFTWARE may contain multiple
versions of this EULA, such as multiple translations and/or multiple
media versions (e.g., in the user documentation and in the
software). Even if you receive multiple versions of the EULA, you
are licensed to use only one (1) copy of the SYSTEM SOFTWARE.
Rental
You may not rent or lease the SOFTWARE.
Software Transfer
You may permanently transfer all of your rights under this EULA
only as part of a sale or transfer of the SYSTEM, provided you
retain no copies, you transfer all of the SOFTWARE (including all
component parts, the media, any upgrades or backup copies, this
EULA and, if applicable, the Certificate(s) of Authenticity), and the
recipient agrees to the terms of this EULA. If the SOFTWARE is an
upgrade, any transfer must include all prior versions of the
SOFTWARE.
Termination
Without prejudice to any other rights, MANUFACTURER or MS
may terminate this EULA if you fail to comply with the terms and
conditions of this EULA. In such event, you must destroy all copies
of the SOFTWARE and all of its component parts.
3.Upgrades
If the SYSTEM SOFTWARE and this EULA are provided separate
from the SYSTEM by MANUFACTURER and the SYSTEM
SOFTWARE is on a ROM chip, CD ROM disk(s) or floppy disk(s),
and labeled "For ROM Upgrade Purposes Only" ("ROM Upgrade"),
you may install one copy of the ROM Upgrade onto the SYSTEM
as a replacement copy for the SYSTEM SOFTWARE originally
installed on the SYSTEM and use it in accordance with Section 1
of this EULA.
2.Description of Other Rights and Limitations
Speech/Handwriting Recognition
If the SYSTEM SOFTWARE includes speech and/or handwriting
recognition component(s), you should understand that speech and
handwriting recognition are inherently statistical processes; that
recognition errors are inherent in the processes; that it is your
responsibility to provide for handling such errors and to monitor the
recognition processes and correct any errors. Neither
MANUFACTURER nor its suppliers shall be liable for any damages
arising out of errors in the speech and handwriting recognition
processes.
Limitations on Reverse Engineering, Decompilation and
Disassembly
4.Copyright
All title and copyrights in and to the SOFTWARE (including but not
limited to any images, photographs, animations, video, audio,
music, text and "applets," incorporated into the SOFTWARE), the
accompanying printed materials, and any copy of the SOFTWARE,
are owned by MS or its suppliers (including Microsoft Corporation).
You may not copy the printed materials accompanying the
SOFTWARE. All rights not specifically granted under this EULA are
reserved by MS and its suppliers (including Microsoft Corporation).
5.Product Support
Product support for the SOFTWARE is not provided by MS, its
parent corporation, Microsoft Corporation, or their affiliates or
subsidiaries. For product support, please refer to
MANUFACTURER’s support number provided in the
documentation for the SYSTEM. Should you have any questions
BOSSTX2 CE 5.0 User's Manual
concerning this EULA, or if you desire to contact
MANUFACTURER for any other reason, please refer to the
address provided in the documentation for the SYSTEM.
6.Export Restrictions
You agree that you will not export or re-export the SOFTWARE to
any country, person, or entity subject to U.S. export restrictions.
You specifically agree not to export or re-export the SOFTWARE: (i)
to any country to which the U.S. has embargoed or restricted the
export of goods or services, which as of March 1998 include, but
are not necessarily limited to Cuba, Iran, Iraq, Libya, North Korea,
Sudan and Syria, or to any national of any such country, wherever
located, who intends to transmit or transport the products back to
such country; (ii) to any person or entity who you know or have
reason to know will utilize the SOFTWARE or portion thereof in the
design, development or production of nuclear, chemical or
biological weapons; or (iii) to any person or entity who has been
prohibited from participating in U.S. export transactions by any
federal agency of the U.S. government.
If the SOFTWARE is labeled "North America Only Version" above,
on the Product Identification Card, or on the SOFTWARE
packaging or other written materials, then the following applies:
The SOFTWARE is intended for distribution only in the United
States, its territories and possessions (including Puerto Rico,
Guam, and U.S. Virgin Islands) and Canada. Export of the
SOFTWARE from the United States is regulated under "EI
controls" of the Export Administration Regulations (EAR, 15 CFR
730-744) of the U.S. Commerce Department, Bureau of Export
Administration (BXA). A license is required to export the
SOFTWARE outside the United States or Canada. You agree that
you will not directly or indirectly, export or re-export the
SOFTWARE (or portions thereof) to any country, other than
Canada, or to any person or entity subject to U.S. export
restrictions without first obtaining a Commerce Department export
license. You warrant and represent that neither the BXA nor any
other U.S. federal agency has suspended, revoked or denied your
export privileges.
7.Note on Java Support
The SYSTEM SOFTWARE may contain support for programs
written in Java. Java technology is not fault tolerant and is not
PERFORMANCE OF THE SOFTWARE IS WITH YOU.
No Liability for Consequential Damages
MANUFACTURER OR MANUFACTURER’S SUPPLIERS,
INCLUDING MS AND ITS SUPPLIERS, SHALL NOT BE
HELD TO ANY LIABILITY FOR ANY DAMAGES
SUFFERED OR INCURRED BY THE END USER
(INCLUDING, BUT NOT LIMITED TO, GENERAL,
SPECIAL, CONSEQUENTIAL OR INCIDENTAL
DAMAGES INCLUDING DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS
OF BUSINESS INFORMATION AND THE LIKE), ARISING
FROM OR IN CONNECTION WITH THE DELIVERY, USE
OR PERFORMANCE OF THE SOFTWARE.
If you acquired this EULA in the United States, this EULA is
governed by the laws of the State of Washington.
If you acquired this EULA in Canada, this EULA is
governed by the laws of the Province of Ontario, Canada.
Each of the parties hereto irrevocably attorns to the
jurisdiction of the courts of the Province of Ontario and
designed, manufactured, or intended for use or resale as on-line
control equipment in hazardous environments requiring fail-safe
performance, such as in the operation of nuclear facilities, aircraft
navigation or communication systems, air traffic control, direct life
support machines, or weapons systems, in which the failure of
Java technology could lead directly to death, personal injury, or
severe physical or environmental damage.
8.Limited Warranty
Limited Warranty
MANUFACTURER warrants that the SOFTWARE will perform
substantially in accordance with the accompanying written
materials for a period of ninety (90) days from the date of receipt.
Any implied warranties on the SOFTWARE are limited to ninety (90)
days. Some states/jurisdictions do not allow limitations on duration
of an implied warranty, so the above limitation may not apply to
you.
Customer Remedies
MANUFACTURER’S and its suppliers’ entire liability and your
exclusive remedy shall be, at MANUFACTURER’S option, either (a)
return of the price paid, or (b) repair or replacement of the
SOFTWARE that does not meet the above Limited Warranty and
which is returned to MANUFACTURER with a copy of your receipt.
This Limited Warranty is void if failure of the SOFTWARE has
resulted from accident, abuse, or misapplication. Any replacement
SOFTWARE will be warranted for the remainder of the original
warranty period or thirty (30) days, whichever is longer.
No Other Warranties
EXCEPT AS EXPRESSLY PROVIDED IN THE LIMITED
WARRANTY SECTION ABOVE, THE SOFTWARE IS PROVIDED
TO THE END USER "AS IS" WITHOUT WARRANTY OF ANY
KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, WARRANTIES OF NON- INFRINGEMENT,
MERCHANTABILITY, AND/OR FITNESS FOR A PARTICULAR
PURPOSE. THE ENTIRE RISK OF THE QUALITY AND THE
PERFORMANCEOF THE SOFTWARE IS WITH YOU.
further agrees to commence any litigation which may
arise hereunder in the courts located in the Judicial
District of York, Province of Ontario.
If this EULA was acquired outside the United States, then
local law may apply.
Should you have any questions concerning this EULA,
please contact the MANUFACTURER of your SYSTEM.
U.S. GOVERNMENT RESTRICTED RIGHTS
The SOFTWARE and documentation are provided with
RESTRICTED RIGHTS. Use, duplication, or disclosure
by the Government is subject to restrictions as set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data
and Computer Software clause at DFARS 252.227-7013
or subparagraphs (c)(1) and (2) of the Commercial
Computer Software—Restricted Rights at 48 CFR
52.227- 19, as applicable. MANUFACTURER is Microsoft
Corporation/One Microsoft Way/Redmond, WA
98052-6399
A
A
A
A
BOSSTX2 CE 5.0 User's Manual
2 Product Overview
2.1 WBTs
WBTs (Windows-based Terminals) are designed to connect to WTS (Windows Terminal Server) servers via RDP (Remote
Desktop Protocol), or Windows NT applications server via ICA (Independent Computing Architecture). RDP is the Windows
CE-based protocol for connecting to Windows terminal servers. ICA is a distributed presentation services protocol for
Windows NT server, allowing an application's user interface to execute on a Windows-based terminal while the application's
logic executes on the server.
2.2 Terminal Specifications
CPU VIA Eden 533 MHz, expandable to 733 MHz
RAM 64MB SDRAM standard, expandable to 512MB
Flash Memory 32MB CF card standard, expandable to 512MB
Flash upgrade utility via Ethernet
Resolution
16 million palette supports all VESA monitors
Refresh Rate Flicker-free, up to 85Hz
Video Memory Graphics utilizes system RAM
udio Support Full 16 bit stereo FM synthesis, 8 bit mini Microphone in
Networking Protocols 10/100 Base T Fast Ethernet, Twisted Pair (RJ45)
TCP/IP with DNS, DHCP and PPP
Load balancing supported by Citrix ICA
Remote modem dial up with Citrix ICA
Communications Protocols MS RDP / Citrix ICA
One Parallel Port Bi-directional centronics compatible, DB-25
Two Serial Port DB-9 pin male connector with RS-232C, up to 115.2K bps
One Display Port
USB Port Two USB ports
udio Port
KB & Mouse Interface Enhanced PS/2 keyboard and mouse interface
Extensible Slot One PCMCIA slot
One PCI slot
One Smart Card Reader
Operation System Microsoft Windows CE.NET
Set-up & Configuration Local power-on boot, simple start-up wizard for set-up
Server Operating System
Support
Terminal Emulations Console ANSI, VT 420/320/220/100/52, Wyse 120/60/50+/325
Support TVI 925, TVI 910+, ADDS A2, IBM3270, IBM5250.
Resolution up to 1280x1024 / 60 Hz SVGA 32 bit to True color.
1600x1200 / 60 Hz SVGA 16 bit to High color.
nalogue VGA type video output (DB-15)
udio out, Microphone In
Configurable automatic login, Multi-language KB support,
Multiple auto-startup support
RDPΚ
Microsoft Windows NT4.0 + TSE.
Microsoft Windows 2000 Server Family.
Microsoft Windows 2003 Server Family.
Microsoft Windows XP with RDP protocol
ICAΚ
Citrix Winframe
Microsoft Windows NT4.0 + TSE+ Citrix Metaframe
Microsoft Windows 2000 + Citrix Metaframe.
Microsoft Windows 2000/ Windows 2003 + Citrix MetaframeXP
.
5
2.3 Terminal Features
Physical Characteristics
Height 232 mm (11.21 in)
Width 51 mm (2.08 in)
Depth 202 mm (10.41 in)
Net Weight 2.20 kgs (4.85 lbs)
Power Cord 6 ft (1.83m)
Environmental
Operating Temperature
Non-operating Temperature
Operating Humidity 20% to 80%, non-condensing
Operating Altitude 0 to 10,000 ft ASL
Nonoperating Altitude 0 to 40,000 ft ASL
Regulatory
EMC Terminal/Power Brick FCC B, CE, CB, CUL, C-TICK, BSMI,
Safety Power Brick UL1950, CB IEC60950.
5 to 40к (41 to 104л)
-40to 60к (-40 to 150л)
Installation
2.4 Terminal Overview
BOSSTX2 CE 5.0 User's Manual
2.4.1 Connecting the Terminal
Follow these instructions to connect the terminal to its peripheral devices:
A. Connect the keyboard to the keyboard connector.
B. Connect the mouse to the mouse connector.
C. Connect the 10/100-T network cable to the RJ-45 network connector.
D. Connect the power cord and the adapter to the power connector with AC outlet.
E. Connect the power cord to the power connector with AC outlet.
6
BOSSTX2 CE 5.0 User's Manual
Power Switch & LED
LAN Active
Smart Card LED Smart Card Slot
Keyboard
USB
Mouse
2.4.2 Connector Descriptions
LAN LED Indicators
This LED indicates the link (amber), activity (amber) status of network conditions. The detailed information is explained as
follows:
z Link Indicator (amber)
This LED lights to indicate a successful network connection.
z Activity Indicator (amber)
This LED lights when there is network packets sent or received through the RJ-45 port.
USB Port
These connectors can be used for the USB devices.
PS/2 Mouse Connector
This connector is for a mouse using a PS/2 plug (mini DIN).
PS/2 Keyboard Connector
This connector is for a standard keyboard using a PS/2 plug (mini DIN).
RJ-45 Network Connector
This connector can be used to connect the built-in 32-bit 10/100-T Ethernet network LAN Controller to a host or Hub.
Audio output Connector
This connector is used to connect to an outward speaker.
7
LAN
PCMCIA SLOT
BOSSTX2 CE 5.0 User's Manual
VGA
SERIAL 1
SERIAL 2
MIC
SPEAKER
VGA Connector
This connector is for displaying on a standard VGA compatible device.
PCI SLOT
PARALLEL
AC
Serial Port Connectors (COM1, COM2)
These connectors can be used for the serial device such as a modem device.
Parallel Port Connector
This connector can be used for a printer connection.
Power Connector
This connector is for connecting the power cord with the terminal and the AC outlet.
PCMCIA Slot
This slot is an optional slot, basically for Wireless LAN adapter.
PCI Slot
This slot is an optional slot for specific applications via standard PCI interface.
Smart Card Slot
This slot is an optional slot only for Smart Card-related applications.
8
BOSSTX2 CE 5.0 User's Manual
Before you use the CE5.0…
1. Get the device and Boot loader ready
For using the F/W of CE5.0, You must update the Boot loader for CE5.0 to ensure all of the devices and function normally.
2. The differences between CE4.2 and CE5.0
z Two user interface styles supported
a. The CE5.0 support two user’s modes, WBT mode and Desktop mode, Users can switch from one to
another in Control Panel.
z More device drivers have been supported in CE5.0
a. The CE5.0 F/W with CE5.0 Boot loader support Card Bus (WiFi, PB.).
b. The CE5.0 OS support Card Bus (32 bits/backward compatibility), 802.11g (Driver required),
USB2.0 (CLE only), RTL8169 (Giga bit), RTL8180 (WiFi/PCI), L2TP/PPPoE.
z More complete and friendly user interface have been supported in CE5.0
a. The new function L2TP and PPPoE have been supported in RAS in the Connection Manager.
b. Regional and Language Setting support the Regional setting in the program format, Number,
Currency, Time and Date; and also support the Input Language to select which keyboard layout
You want to use.
c. The new function Terminal License have been supported in Control Panel, and the user can view and
reset the terminal license there instead of reset it in Application Properties.
d. The new function Touch Panel Settings have been supported in Control Panel, and the user can set
the touch panel model and alignment the panel there instead of do it in Application Properties.
z The RDP version is upgraded from RDP 5.2 to RDP 5.5
z Complete update from CE4.2 to CE5.0
a. The CE4.2 OS could be upgraded to CE5.0 by using FTP Update.
9
BOSSTX2 CE 5.0 User's Manual
3 Initial Terminal Setup
The Setup Wizard is used for initial setup of the terminal's properties. The wizard runs when:
Γ You turn on your terminal for the first time.
Γ Your terminal has been restarted with selecting factory default setting.
Γ A new image has been downloaded to your terminal.
3.1 Hot-keys Functions
Ctrl+Alt+Up/Down Arrow
Use this function to switch between Active Connections
Ctrl+Alt+End:
Use this function to go back to the Terminal Connection Manager.
Ctrl+Alt+L:
Use this function to activate or deactivate the energy saver.
3.2 Setup Wizard
The Setup Wizard lets you set terminal network configuration and terminal display parameters. Any future changes can be
made using the Terminal Properties dialog box. You can launch this dialog box anywhere in the program at any time by
pressing the [F2] key.
There are seven dialog boxes that display in succession during the process. Each dialog box is self-explanatory. Some
dialog boxes are informational and require no user input. Other dialog boxes will prompt you for network and display
information.
.
Welcome
MAC ADDRESS
10
BOSSTX2 CE 5.0 User's Manual
3.2.1 Network Configuration
Network attached device must contain a unique network identifier. If the network is using TCP/IP as a communication
protocol, these identifiers are called IP addresses. The following series of screens will allow you to choose from two different
methods of assigning the IP addresses.
3.2.1.1 Use the IP information supplied by DHCP
If your network provides DHCP (Dynamic Host Configuration Protocol) service and you want it to provide the terminals IP
information, leave the first option selected.
The terminal can get its IP address through a DHCP service by default. The DHCP will automatically assign an IP address
that is drawn from a pool of available IP addresses, when a terminal unit is powered on and a request is broadcast over the
network.
Use the IP information supplied by DHCP
If you need to specify static IP address for the terminal, select the second option.
The option is selected automatically if your network does not provide a DHCP service, or if the unit is not properly connected
to the network. In these cases, leave the second option selected.
IP Address
Note: If your network does not provide a DHCP service but you get the screen shown above, make sure the terminal unit is
properly connected to the network. Then restart it by cycling the power off and then on.
11
BOSSTX2 CE 5.0 User's Manual
3.2.1.2 Specify a static IP address
If the method you selected on the prior screen was to enter a static IP address, the below screen will appear. You will be
required to enter the following information onto the screen.
IP address
Required for identifying this unit to the network. The format will follow the standard addressing format.
Subnet Mask
Required for designating which network the IP address is a part of.
Gateway
Optional address which identifies the machine through which a subnet communicates with another network.
Specify an IP Address
3.2.2 Enable/Disable Name Resolution Services
The screen shown below will appear only if you choose the Static IP Addressing method. The DHCP method will provide this
information required using a name resolution service.
Terminal servers typically support both DNS (Domain Naming Service) and WINS (Windows Internet Naming Service) name
resolution services. This screen allows the terminal unit to use one or both of these resolution services. To enable DNS,
WINS, or both, check the corresponding box. In the text boxes, enter the following information as appropriate for each. Click
Next.
Optional Information
12
BOSSTX2 CE 5.0 User's Manual
3.2.3 Alternative Display Settings
The monitor support several kinds of resolutions. If you want to test it, choose the desired resolution from the list box and
click Test.
Desktop Area and Refresh Frequency
If the screen image tests OK, the monitor will support the selected resolution.
After the system implement testing new mode as user set up.
The system will notify user “did you see the test image properly”.
13
BOSSTX2 CE 5.0 User's Manual
3.2.4 Local Printer Setup
The terminal supports Local Print. If you want to connect this terminal with a Local Printer, then click OPEN. If not, then click
NEXT.
Local Printer Setup
After click OPEN you can see the Add Printer page then click OPEN again you can see the Select the printer Port page.
3.2.5 Select the Printer Port
Select one of the ports, LPT1, COM1 or COM2 port that you want to use to communicate with your local printer. Or you can
select Network to set a network printer. When you select the COM1 or COM2 .You can also select the baud rate of COM1 or
COM2 port.
Select the Printer Port
14
Select the Printer Port (For LPT1)
Select the Printer Port & BAUD RATE (For COM1 or COM2)
BOSSTX2 CE 5.0 User's Manual
Select the Network Printer
15
BOSSTX2 CE 5.0 User's Manual
3.2.6 Select the Printer Model
Select the manufacturer and model of your printer. If your printer name is not listed, check with your printer document and
select one that is closer. The printer will then show on the dialog box of Printers Properties on Terminal Properties after
press [F2] as shown in chapter 6.5.
3.2.6.1 Select the Printer Model
User select the manufacturer and model of your printer then click Next.
Name Your Printer for COM1, COM2, LPT1
User must supply a name for this printer then click Next.
Name Your Printer for Network
Enter the Network path of your printer
16
BOSSTX2 CE 5.0 User's Manual
Configure Another Printer
The WBT will notify that “User has successfully configured the printer”
And ask if user want to configure another printer.
If does not please enable No and click Next. Or enable Yes to continue configure another printer.
The screen will go back to Select the Printer Port as shown on page 15,
Then follow the setup procedures again after selecting the printer port.
Finish
To apply the settings, click Finish after you have finished the Printer Setup Wizard.
After the printer setup finished then the added printer model would be showed up.
17
BOSSTX2 CE 5.0 User's Manual
3.2.6.2 User Defined
If your printer name is not listed, please enable” User Defined” to setup then click Next.
Note: User has to prior install the printer driver in server when performing the User Defined.
Enter your printer Model & Manufacture to setup then click Next. (Com1, Com2, Lpt1)
Enter your printer Model & Manufacture to setup then click Next. (For Network Printer)
Note: The model name, which you type in the column,
should be identical with what you select from the name list in the server
18
User must supply a name for this printer then click Next.
Set Default Printer
User can choose using this printer as the default printer or not.
Click Next to process.
BOSSTX2 CE 5.0 User's Manual
The WBT will notify that “User has successfully configured the printer”
And ask if user want to configure another printer.
If does not please enable No and click Next.
Or enable Yes to continue configure another printer.
19
BOSSTX2 CE 5.0 User's Manual
Then tap Finish to apply the setting.
After the printer setup OK then the added printer model would be showed up.
3.2.7 Finish the Setup Wizard
To review or change settings made on previous pages, click Back; to apply the settings, click Finish.
To change these settings after you have finished the Setup Wizard, press [F2] key to display the Terminal Properties sheet.
Finish
20
BOSSTX2 CE 5.0 User's Manual
4 Connections Management
The Terminal Connection Manager dialog box is designed to help you manage your terminal's network connections. The
dialog box displays after the terminal's initial splash screen, and consists of the Connections properties sheet and the
Configure properties sheet. The following figure shows the Terminal Connection Manager dialog box.
Terminal Connection Manager
4.1 Using the Connections Properties Sheet
The functions of the Connections properties sheet are used to make (connect to) terminal network connections.
The following figure shows the
Connections Properties Sheet
Connections properties sheet.
4.2 Using the Configure Properties Sheet
The Configure properties sheet allows the user to Add, Edit, Delete, and configure connections. The following figure shows
the Configure properties sheet.
Configure Properties Sheet
21
BOSSTX2 CE 5.0 User's Manual
4.3 Creating New Connections
The New Connection dialog box is used to create new network connections. This dialog box is invoked by:
Clicking on the Configure tab in the Terminal Connection Manager dialog box. Clicking on Add command button on the
Configure properties sheet. The following figure shows the New Connection dialog box.
New Connection Dialog Box
4.3.1 Choosing a Connection Protocol
Use the scroll list shown in the dialog box above to select the type of connection protocol you want. When you choose from
the list above, you are deciding which connection protocol you want to use to connect to a server. Six selections are
available:
Microsoft Remote Desktop Client
RDP (Remote Desktop Protocol) protocol, through which connects to a WBT (Windows-Based Terminal) server. Refer
to chapter 4.4 for RDP Connections.
Citrix ICA Client
ICA (Independent Computing Architecture) protocol, through which connects to an ICA (Winframe/Metaframe) server.
Refer to chapter 4.5 for ICA Connections.
Remote Dial-up / Direct Cable / VPN / PPPOE
Connects to remote server through PPP Dial-up applications or use direct RS232 cable connection. You can even
have VPN connection. Refer to chapter 4.6 for all details.
Microsoft Internet Explorer
Connects to the Internet directly via embedded Internet Explorer. This function doesn’t appear in all WBTs. Please
make sure your WBT contains embedded IE and has 64MB RAM at least. Refer to chapter 4.7 for the Internet
applications.
Microsoft Media Player
An applications winch you can connect to play a media & set the option in your WBT. Refer to chapter 4.8 for Media
Player.
Terminal Emulation
Connects to multiple terminal emulation applications.
IBM Terminal Emulation
Connects to IBM-related terminal emulation applications.
22
Loading...
