WorkForce DS-530
DATASHEET
The intelligent sheetfed document scanning choice,
revolutionising workflows with smart features for capturing a
wide range of documents
With powerful media handling and innovative smart features to ensure a high
level of data integrity, the WorkForce DS-530 is geared towards highly-efficient
and simple integration into an organisation’s workflow. With a 50-page ADF and
the ability to scan at up to 35ppm/70ipm, it offers a wide range of media
handling options that enable you to rapidly capture, index, store and share
business documents.
Intelligent features improve efficiency, accuracy and data reliability
With an industry-first slow mode1 for scanning crumpled or fragile documents,
the ability to scan challenging media has never been easier. The Active
Separation Roller System prevents tedious document double feeds ensuring
every piece of paper gets scanned and the Double Feed Detection Skip (DFDS)
means you can scan difficult media like envelopes or documents with post-it
notes. Auto Scan Mode enables the processing of a vast number of documents
as manageable amounts, enabling them to be scanned as one file.
Highly versatile
The optional flatbed scanner conversion kit allows effective document
processing from stamps to passports and books. Single-pass double-sided
scanning ensures rapid document processing, while it's possible to scan a
versatile array of media such as paper as thin as 27gsm, or thick card at
413gsm. The A3 carrier sheet speeds up the process by automatically stitching
larger documents back together digitally.
Flexible connectivity
High-speed USB 3.0 with TWAIN and ISIS drivers for enhanced compatibility
with Document Management Systems.
Image enhancement and document management software
Epson Scan 2.0 software makes it easy to edit images with features such as deskew and auto rotate, while Document Capture Pro is the easy to use solution
for capturing and storing electronic documents at the touch of a button.
KEY FEATURES
An industry first with Slow Mode
Scan crumpled, long or fragile
documents without increasing file sizes
Active Separation Roller System
Prevents tedious double feeds ensuring
every piece of paper gets scanned
Optional flatbed scanner conversion
kit
Enables scanning of items from stamps
to passports, books and more
Auto Scan Mode
Quickly process physical documents in
manageable amounts.
Optional Network Interface
Easy sharing between users with push
scan and pre-defined job profiles
1
PRODUCT SPECIFICATIONS
TECHNOLOGY
Scanner type Sheetfed Scanner
Scanning Resolution 600 dpi x 600 dpi (Horizontal x Vertical)
Optical Resolution Main 600 dpi x Sub 600 dpi
Color Depth Input: 24 Bits Color
SCANNER
Light Source ReadyScan LED technology
SCAN SPEED
Scanning Speed Monochrome: 35 Pages/min - Colour: 35 Pages/min measured with Size: A4 , Resolution: 200 /
SCANNING FEATURES
Features Skip blank page, A3 stitching, Punch holes removal, Automatic de-skew, Automatic multi-
Output formats JPEG, TIFF, multi-TIFF, PDF, searchable PDF, secure PDF, PDF/A
Advanced document
integration
CONNECTIVITY
Interfaces USB 3.0
GENERAL
Product dimensions 296 x 169 x 176 mm (Width x Depth x Height)
Product weight 3.7 kg
Included Software Epson Document Capture Pro (Windows only), Epson Scan
Compatible Operating
Systems
OTHER
Warranty 12 months On site service
300 dpi, Monochrome: 70 image/min - Colour: 70 image/min measured with Size: A4 ,
Resolution: 200 / 300 dpi
document recognition, Dual Image Output (Windows only), Auto-rotation, Text enhancement,
Unsharp Mask (USM), Descreening, Automatic Folder Creation, Barcode Recognition, Full
Zonal OCR
E-mail, FTP, Microsoft SharePoint®, Print, Web folders, Network folders
Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Mac OS X 10.6.8, Windows 10,
Windows 7, Windows 7 x64, Windows 8, Windows 8 (32/64 bit), Windows 8 RT, Windows 8.1,
Windows 8.1 x64 Edition, Windows Server 2008 (32/64bit), Windows Server 2008 R2, Windows
Server 2012 (64bit), Windows Server 2012 R2, Windows Vista, Windows Vista x64, Windows
server 2003 R2, XP Professional x64 Edition
WorkForce DS-530
WHAT'S IN THE BOX
Driver and utilities (CD)
Main unit
Power cable
Setup guide
USB cable
Warranty document
OPTIONAL ACCESSORIES
Network Interface Unit
B12B808451BY
LOGISTICS INFORMATION
SKU B11B226401BY
EAN code 8715946551913
Multiple Order Quantity 1 Units
Pallet Size Euro 49 Units
For more information please contact:
Telephone: 01952 607111 (UK)+
01 436 7742 (Republic of Ireland)
E-mail: enquiries@epson.co.uk
Chat: etalk.epson-europe.com
Fax: 0871 222 6740
+ Local call rate.
Trademarks and registered trademarks are the property of Seiko Epson Corporation or their respective owners.
Product information is subject to change without prior notice.
Web: www.epson.co.uk
www.epson.ie
1. Compared to sheet-fed scanners, within the speed
range of 25ppm to 39ppm, based on data from the websites
and brochures of the top five best-selling scanner models
in EMEA for the full year 2015 according to InfoSource
Document Management Scanner Sales Full Year 2015.
2. Requires download from Epson website
