Epson 703C User Manual
EPSON® PowerLite® 703c
Multimedia Projector
User’s Guide
Important Safety Information
WARNING: Never look into the projector lens when the lamp is turned on; the bright light can damage your eyes.
Never let children look into the lens when it is on. Never open any cover on the projector, except the lamp and
filter covers. Dangerous electrical voltages inside the projector can severely injure you. Except as specifically
explained in this
personnel.
WARNING: The projector and its accessories come packaged in plastic bags. Keep plastic bags away from small
children to avoid any risk of suffocation.
Caution: When you replace the lamp, never touch the new lamp with your bare hands; the invisible residue left by
the oil on your hands may shorten the lamp life. Use a cloth or glove to handle the new lamp.
User’s Guide
, do not attempt to service this product yourself. Refer all servicing to qualified service
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of SEIKO EPSON CORPORATION. The information contained herein is designed only for
use with this EPSON product. EPSON is not responsible for any use of this information as applied to other
products.
Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or third
parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse,
or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the
U.S.) failure to strictly comply with SEIKO EPSON CORPORATION’s operating and maintenance instructions.
SEIKO EPSON CORPORATION shall not be liable for any damages or problems arising from the use of any
options or any consumable products other than those designated as Original EPSON Products or EPSON
Approved Products by SEIKO EPSON CORPORATION.
EPSON is a registered trademark of SEIKO EPSON CORPORATION.
EPSON Extra Care is a service mark; EPSON Store and SizeWise are trademarks; and PrivateLine, Presenters
Club, and PowerLite are registered trademarks of Epson America, Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of
their respective owners. EPSON disclaims any and all rights in those marks.
CPD-11727
Copyright © 2001 by Epson America, Inc. 2/01
ii
Contents
C
1
Welcome
Getting the Most from Your Projector . . . . . . . . . . . . . . . . . 2
Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . 3
Reading This Manual Online . . . . . . . . . . . . . . . . . . . . 3
Getting More Information . . . . . . . . . . . . . . . . . . . . . . 4
Registration and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Additional Components . . . . . . . . . . . . . . . . . . . . . . . . 7
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting Up the Projector
Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting to a Laptop Computer . . . . . . . . . . . . . . . . . . 12
Connecting the Computer Cable . . . . . . . . . . . . . . . . 12
Connecting the Cable for Remote Mouse Control . . . 13
Amplifying Computer Audio . . . . . . . . . . . . . . . . . . . 14
Connecting to Video Sources . . . . . . . . . . . . . . . . . . . . . . 15
Connecting the RCA AV Cable . . . . . . . . . . . . . . . . . 15
Connecting S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . 16
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
. . . . . . . . . . . . . . . . . . . . . 9
iii
2
Using the Projector
Turning On Your Equipment . . . . . . . . . . . . . . . . . . . . . . . 18
Turning On the Projector . . . . . . . . . . . . . . . . . . . . . . . 18
What To Do If You See a Blank Screen . . . . . . . . . . . . 20
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Focusing and Zooming Your Image . . . . . . . . . . . . . . . 23
Adjusting the Height of Your Image . . . . . . . . . . . . . . . 23
Adjusting the Image Shape . . . . . . . . . . . . . . . . . . . . . . 24
Shutting Down the Projector . . . . . . . . . . . . . . . . . . . . . . . . 25
. . . . . . . . . . . . . . . . . . . . . . . . . . 17
3
Using the Remote Control
Turning On and Using the Remote Control . . . . . . . . . . . . 28
Installing Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Turning On the Remote Control . . . . . . . . . . . . . . . . . 28
Using the Remote Control . . . . . . . . . . . . . . . . . . . . . . 29
Controlling the Picture and Sound . . . . . . . . . . . . . . . . . . . 30
Switching Between Picture Sources . . . . . . . . . . . . . . . . 30
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Turning Off the Picture and Sound . . . . . . . . . . . . . . . 31
Stopping Action . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Zooming Your Image . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Resizing the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Displaying Picture-in-Picture Video . . . . . . . . . . . . . . . 32
Highlighting Your Presentation . . . . . . . . . . . . . . . . . . . . . . 33
Using the Pointer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using Box Highlights . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Drawing Horizontal and Vertical Lines . . . . . . . . . . . . . 35
Drawing Freehand Lines . . . . . . . . . . . . . . . . . . . . . . . . 35
Using the Remote Control as a Wireless Mouse . . . . . . . . . 36
. . . . . . . . . . . . . . . . . . . 27
iv
4
Fine-tuning the Projector
Using the Projector’s Menu System . . . . . . . . . . . . . . . . . . . 38
Changing Menu Settings . . . . . . . . . . . . . . . . . . . . . . . 39
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Repositioning the Image . . . . . . . . . . . . . . . . . . . . . . . . 40
Adjusting Image Appearance . . . . . . . . . . . . . . . . . . . . 41
Adjusting the Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Customizing the Highlighting Tools . . . . . . . . . . . . . . . . . . 43
Creating Your Own Startup Screen . . . . . . . . . . . . . . . . . . . 44
Capturing the Image . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Setting Up When the Image Displays . . . . . . . . . . . . . 45
Customizing Projector Features . . . . . . . . . . . . . . . . . . . . . 46
Setting Advanced Features . . . . . . . . . . . . . . . . . . . . . . 48
Viewing Lamp Usage and Other Information . . . . . . . . . . . 49
Restoring the Default Settings . . . . . . . . . . . . . . . . . . . . . . . 50
. . . . . . . . . . . . . . . . . . . 37
5
6
Maintaining and Transporting
the Projector
Cleaning the Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Cleaning the Projector Case . . . . . . . . . . . . . . . . . . . . . . . . 52
Cleaning and Replacing the Air Filter . . . . . . . . . . . . . . . . . 53
Replacing the Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Transporting the Projector . . . . . . . . . . . . . . . . . . . . . . . . . 56
Solving Problems
Using On-Screen Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
What To Do When the Lights Flash . . . . . . . . . . . . . . . . . . 59
Solving Problems with the Image or Sound . . . . . . . . . . . . . 62
Solving Problems with the Remote Control . . . . . . . . . . . . 68
Where To Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Telephone Support Services . . . . . . . . . . . . . . . . . . . . . 69
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
v
A
Appendix A: Connecting to Additional
B
Equipment
Installing the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Connecting to an External Audio System . . . . . . . . . . . 72
Connecting to a PC Desktop Computer . . . . . . . . . . . . . . . 73
Connecting the Computer Cable . . . . . . . . . . . . . . . . . 74
Connecting the Mouse Cable . . . . . . . . . . . . . . . . . . . . 75
Connecting the Audio Cable . . . . . . . . . . . . . . . . . . . . . 76
Connecting to a Desktop Macintosh . . . . . . . . . . . . . . . . . . 77
Connecting the Computer Cable . . . . . . . . . . . . . . . . . 77
Connecting the Mouse Cable . . . . . . . . . . . . . . . . . . . . 78
Connecting the Audio Cable . . . . . . . . . . . . . . . . . . . . . 79
Connecting to a High-End Workstation . . . . . . . . . . . . . . . 79
Appendix B: Notices
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . 81
Remote Control Information . . . . . . . . . . . . . . . . . . . . . . . 83
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . 84
FCC Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . 85
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
. . . . . . . . . . . . . . . . . . . . . . . . . 81
vi
C
Appendix C: Technical Specifications
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Projection Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Mouse Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Compatible Video Formats . . . . . . . . . . . . . . . . . . . . . . . . . 90
Computer Video Port Pin Assignments . . . . . . . . . . . . . . . . 92
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
. . . . . . . 87
-
Welcome
W
The
EPSON® PowerLite® 703c is a super-portable projector that
offers 1000 ANSI lumens of brightness. From boardrooms to
auditoriums, your full-color presentations and videos will be bright
and visible even in ordinary room lighting.
Images are displayed at a resolution of 1024 × 768 pixels. Three
0.9-inch LCDs provide a 320:1 contrast ratio for incredibly vivid
images and clear text. Support for S-video contributes to
theater-quality performance.
With EPSON’s patented SizeWise
supports computer displays ranging from VGA through UXGA.
You can connect the projector to a wide range of computers, including
®
IBM
compatible PCs and laptops, Apple® Macintosh,® Power
Macintosh
computers, many iMac
workstations such as the Sun
™
series (including G3 and G4 systems), PowerBook®
™
technology, the projector
™
and iBook™ series systems, and high-end
®
SPARCstation.
™
You can use any of the following video sources: VCR, DVD player,
camcorder, digital camera, or laser disc player, supporting NTSC,
PAL, or SECAM video.
Welcome
1
Getting the Most from Your Projector
Depending on your presentation, you can take advantage of any or all
of these options:
■
Connecting to a laptop or other computer
If you want to connect to a PC laptop or Macintosh PowerBook,
see page 12. To connect to a desktop computer or workstation,
see Appendix A.
■
Connecting to video sources
You can connect a DVD player, VCR, camcorder, laser disc
player, digital camera, or any other video source to your projector.
You can connect both computer and video sources at the same
time and easily switch between them. See page 15 for instructions.
■
Using the remote control
The remote control lets you switch from computer to video
source, with access to picture-in-picture, pointer, zoom, and
many other projector features. For details, see Chapter 3.
By connecting an additional cable, you can also use the remote
control as a wireless mouse. This lets you click through
computer-based presentations (such as PowerPoint
30 feet away. For more information, see page 36.
®
) from up to
2
Welcome
■
Including sound in your presentation
If your presentation includes sound, you can connect an audio
cable to use the projector’s built-in stereo speakers. For details, see
page 14 (for laptops) or Appendix A (for other systems).
You can also connect external speakers or a public address system
to the projector’s
Audio Out
port; see page 72.
Using Your Documentation
To connect the projector to your laptop and get your presentation
running fast, see the Quick Setup sheet that came in your Owner’s Kit.
This book contains all the information you need to set up and use
your projector. Please follow these guidelines as you read through it:
■
Warnings must be followed carefully to avoid bodily injury.
■
Cautions must be observed to avoid damage to your equipment.
■
Notes contain important information about your projector.
Reading This Manual Online
Your PowerLite 703c CD-ROM includes an electronic copy of this
manual. You may find it convenient to copy it onto your laptop’s hard
drive so it’s always with you—for example, when taking your
presentation on the road.
To view your electronic manual, you need to use Adobe
Reader. Just insert the PowerLite CD-ROM in your CD-ROM drive,
select the
Guide
Install/View User’s Guide
View User’s Guide
or
button and click
.
When you open the manual, you see this toolbar:
®
Acrobat®
Install User’s
note
If you do not have Acrobat
Reader, you can install it
from the CD-ROM.
show navigation
pane
first page
last page
next pageprevious page
You have several ways to navigate through the manual:
■
Click in the table of contents on the left side of the screen to move
quickly to the topic of your choice.
■
Use the arrow buttons in the toolbar or on the vertical scroll bar
on the right side of the screen to move through the manual.
Welcome
3
■
If you hold your mouse pointer over text and the hand changes to
an index finger, you can click to jump to a related topic.
For more information, see your Acrobat Reader online guide.
Getting More Information
Need tips on giving presentations? Quick steps for setting up your
projector? Here’s where you can look for help:
■
www.presentersonline.com
Includes a library of articles covering presentation tips, tricks, and
technology. The site provides templates, clip art and sound clips,
as well as Presenters Services to use on the road. Even more
resources and services are available if you register to join the
Presenters Club
■
Owner’s Kit envelope
Includes your Quick Setup sheet, warranty brochures, CD-ROMs,
and EPSON PrivateLine
the envelope and keep the envelope with your projector at all
times.
■
Quick Setup sheet
Gives you all the instructions you need to get your projector set
up and connected to a laptop or PowerBook computer.
®
—and it’s free.
®
Support card. Store this User’s Guide in
note
You don’t need to install any
software to use your projector.
4
Welcome
■
Built-in help system
Provides assistance for common problems. Available from the
Help
button on the projector or the remote control. See page 58
for details.
■
support.epson.com
Download FAQs and e-mail your questions to EPSON support.
■
CD-ROM
The PowerLite 703c CD-ROM lets you register electronically and
includes the electronic copy of this book as well as a link to
Presenters Online.
If you still need help after checking this User’s Guide and the sources
listed above, you can use the EPSON PrivateLine Support service to
get help fast. Call (800) 637-7661 and enter the PIN on the card in
your Owner’s Kit. Or take advantage of EPSON’s automated support
services 24 hours a day. See page 69 for more information.
Registration and Warranty
Your projector comes with a basic carry-in warranty and an
international warranty that let you project with confidence anywhere
in the world. For details, see the warranty brochures included in your
Owner’s Kit.
In addition, for customers who register their projectors, EPSON offers
free Extra Care
failure, you won’t have to wait for your unit to be repaired. Instead,
EPSON will ship you a replacement unit anywhere in the United
States or Canada, usually via overnight delivery. See the brochure in
your Owner’s Kit for details.
To register, simply insert the PowerLite 703c CD-ROM in your
computer’s CD-ROM or DVD drive and select
Registering also lets you receive special updates on new accessories,
products, and services. You can register through the Internet, by
e-mail or 800-number modem connection, or by printing out the
form to fax or mail.
SM
Road Service. In the unlikely event of an equipment
Register Online
.
Welcome
5
Unpacking the Projector
After unpacking the projector, make sure you have all the parts shown
below:
EPSON PowerLite 703c CD-ROM (not
Power
Freeze
A/V Mute
R/C ON
E-Zoom
OFF
3
4
2
5
1
Enter
Esc
needed to use your projector)
projector
computer cable
batteries
power cord
remote control
PS/2 MOUSE
RCA AV cable
USB mouse cable PS/2® mouse cable
Save all packaging in case you need to ship the projector. Always use
the original packaging (or the equivalent) when you need to send the
projector to another location.
If you are moving the projector by hand, use a carrying case (such as
the optional cases available from EPSON). See page 8 for more
information about cases.
6
Welcome
Additional Components
Depending on how you plan to use the projector, you may need
additional components:
■
To receive an S-video signal, you need an S-video cable. (One is
usually provided with your video device.)
■
To amplify your computer’s audio through the projector’s sound
system, you need a computer audio cable (male-to-male 3.5-mm
stereo miniplug cable). See your computer or electronics dealer to
obtain this cable.
■
Some older PowerBooks and Macintosh desktop models may
need the Macintosh adapter set shown on page 77 (available from
EPSON; see page 8). Older iMac systems may need a special
adapter to provide a VGA output port; see your computer dealer.
■
Some systems may need an additional cable to use the remote
control as a wireless mouse. If your Macintosh doesn’t have a USB
port, you’ll need a Macintosh mouse cable. See your projector
dealer to obtain the correct cable.
Welcome
7
Optional Accessories
To enhance your use of the projector, EPSON provides the following
optional accessories:
Product
Product
Replacement lamp and air filter ELPLP14
number
Soft carrying cases:
Samsonite
Slimline soft shoulder bag
Notebook/projector soft shoulder bag
ATA molded hard shell case
Ceiling mount ELPMB32
Suspension adapter for ceiling mount (1-inch pipe) ELPMBAPS
Suspension adapter for ceiling mount (1.5-inch pipe) ELPMBAST
Kensington
Portable projection screens:
50-inch screen
60-inch Insta-Theatre screen
80-inch Insta-Theatre screen
Wireless microphone and two satellite speakers ELPCVS1
Presentation audio system ELPPAS1
Macintosh adapter set (includes monitor adapter
and desktop adapter)
VGA to 13W3 video cable (for connecting to certain
high-end workstations)
®
wheeled soft case
®
MicroSaver® security lock ELPSL01
ELPKS35
ELPKS31
ELPKS32
ELPKS30
ELPSC06
ELPSC07
ELPSC08
ELPAP01
ELPKC06
You can purchase these accessories from your dealer or by
calling EPSON at (800) 873-7766; or visit the EPSON Store
at www.epson.com (U.S. sales only). In Canada, please call
(800) 873-7766 for dealer referral.
™
8
Welcome
1
Setting Up the Projector
This chapter tells you how to set up the projector and connect it to a
laptop computer or video source. If you need to connect the projector
to a desktop or workstation computer, see Appendix A.
You’ll find instructions for the following in this chapter:
Positioning the projector
■
Connecting to a laptop computer
■
Connecting to video sources
■
Setting Up the Projector
9
caution
p
y
p
Don’t hold or lift the
rojector by the lens, or
ou may damage it.
note
It’s easier to position the
rojector when the screen is
directly in front of the room.
If the screen is placed
diagonally in a corner, it’s
much more difficult to aim
the projector correctly at the
screen and get a square
image.
Positioning the Projector
Before connecting the projector, you need to decide where to place it.
The location you choose depends on the size of the room and what
you are projecting.
■
Place the projector on a sturdy, level surface, between
3.6 and 45.5 feet from the screen.
■
Make sure there is plenty of space for ventilation around and
under the projector.
■
Make sure the projector is within 6 feet of a grounded electrical
outlet or extension cord and within 5 feet of your computer
and/or video source.
■
Place the projector directly in front of the center of the screen,
facing it toward the screen squarely. Otherwise, your image will
not be square.
Most presenters find it convenient to place the projector in front of
the audience, leaving as much space as possible between the projector
and the screen to get a good-sized image. This lets the presenter stand
in the front of the room, face the audience, and remain close enough
to the equipment to be able to control it.
Use the figure below as a guideline to help you determine how far
from the screen to place the projector. Image size generally increases
with distance, but may vary depending on how you position the lens
ring and whether you have adjusted the image size with other settings.
10
Setting Up the Projector
3.6 to 4.3 ft7 to 9 ft38 to 45 feet distance from screen
If you place the projector below the level of the screen, you’ll have to
A
p
M
p
p
tilt it up by extending the feet as shown. Tilting the projector upward
causes the image to lose its square shape, but you can correct the
distortion by pressing the
Keystone
button as described in the next
chapter.
ideal
height
If you place the projector level with the bottom of the screen, the
image will be square and you won’t have to adjust it. If you place the
projector higher than the bottom of the screen, the image will still be
square, but you won’t be able to fill the whole screen with the image.
note
fter positioning the
rojector, you may want to
connect a Kensington
icroSaver anti-theft device
to the lock port on the
rojector’s left side. You can
urchase this from EPSON;
see page 8
Setting Up the Projector
.
11
Connecting to a Laptop Computer
A
note
To connect to desktops and
other computer systems, see
ppendix A. If you have an
iBook with an RCA videoout port, follow the
instructions for connecting to
a video device on page 15.
note
Laptop configurations vary.
See your computer manual for
the location of the ports
needed to connect your
projector.
You can connect the PowerLite projector to any computer that has a
standard video output (monitor) port, including PC notebook and
laptop computers, Macintosh PowerBooks, and hand-held devices.
Connecting the Computer Cable
Before you start, make sure your computer and the projector are
turned off.
1. Connect one end of the computer cable to the projector’s
Computer
2. Connect the other end of the computer cable to your laptop’s
video-out or monitor port.
port.
If you’re using a PowerBook and you can’t connect the cable, you
may need to use the Macintosh desktop adapter as shown on
page 77 (available from EPSON; see page 8).
3. Tighten the screws on the connectors.
12
Setting Up the Projector
If you don’t need to make any other connections, you can plug in
your projector and turn it on. See page 18 for instructions.
Connecting the Cable for Remote Mouse Control
Using the remote control as a wireless mouse lets you click through
slideshow-style presentations, such as PowerPoint, from up to 30 feet
away (for details, see page 36). This gives you more flexibility in
delivering your presentation, since you won’t need to stand near your
computer.
You’ll use different cables and different ports on the projector,
depending on whether your laptop has a round mouse port or a flat
USB mouse port.
Mouse/Com
Mouse/Com port
PS/2 mouse cable
USB port
USB mouse cable
1. Locate the cable you need, depending on whether your laptop has
a round PS/2 mouse port or a flat USB port.
note
If you’re using a PowerBook
that has a round mouse port,
you’ll need a Macintosh
mouse cable. See your
projector dealer to obtain the
correct cable.
2. Connect one end of the appropriate mouse cable to the projector’s
Mouse/Com
connecting PS/2 mouse cable
port, as shown.
connecting USB mouse cable
3. Connect the other end of the cable to the external mouse port or
USB port on your laptop.
Setting Up the Projector
13
4. If necessary, configure your laptop to work with an external
mouse.
If you don’t need to make any other connections, you can plug in
your projector and turn it on. See page 18 for instructions.
Amplifying Computer Audio
Your laptop probably has its own sound system; however, it may not
be adequate for your presentation. If you need more volume or better
sound quality, you can connect a computer audio cable to take
advantage of the projector’s built-in amplifier and speaker. You can
obtain a computer audio cable (3.5-mm stereo miniplug cable) from a
computer or electronics dealer.
1. Connect one end of the audio cable to the
Audio In
jack on the
projector.
2. Connect the other end of the audio cable to your laptop’s
headphone jack or audio-out jack. (Jack locations vary; see
your computer manual if you’re not sure of which jack to use.)
If you don’t need to make any other connections, you can plug in
your projector and turn it on. See page 18 for instructions.
14
Setting Up the Projector
Connecting to Video Sources
You can connect a DVD player, VCR, camcorder, laser disc player,
digital camera, or any other compatible video source to your projector.
The projector supports NTSC, PAL, and SECAM, and automatically
detects the video format.
A standard RCA A/V cable is included with the
projector. If your video source also has an S-video
2
1
4
3
jack (as shown with an S-video plug at the right),
you can use it to provide a higher quality video image. However,
you’ll need an S-video cable, which may be included with your video
source, or may be purchased from an electronics store or video dealer.
Follow the instructions below for your type of connection.
Connecting the RCA AV Cable
Before starting, make sure the projector and your DVD player or
other video source are turned off.
1. Connect the yellow plug on one end of the AV cable to the
projector’s yellow
2. Connect the other end of the cable to the video-out jack on your
video source.
Video
jack.
note
The projector does not
support TV antenna cable
F connectors.
Video jack
RCA AV cable
Setting Up the Projector
15
3. Connect the AV cable to the left and right Audio jacks on the
projector (insert the white plug into the
into the
R
port).
L
port and the red plug
4. Connect the plugs at the other end of the cable to the audio
output jacks on your video source.
Connecting S-Video
If your video source has an S-video jack, you can use it to project a
higher quality video image. However, you’ll need an S-video cable,
which may be included with your video source, or may be purchased.
Before starting, make sure the projector and your DVD player or
other video source are turned off.
1. Insert one end of an S-video cable into the projector’s
S-Video
connector.
2. Insert the other end into the S-video output port of your video
source.
S-Video cable
3. Connect the RCA AV cable to the left and right
Audio
jacks on
the projector. (Match the red and white plugs to the red and
white jacks; you won’t need to use the yellow plug.)
4. Connect the plugs at the other end of the cable to the audio
output jacks on your video source.
16
Setting Up the Projector
Using the Projector
2
Once you’ve set up the projector, you’re ready to turn it on, adjust
the image, and give your presentation.
Although you can operate the projector without it, the remote control
lets you use additional features. See Chapter 3 for instructions on
using the remote. This chapter covers the following:
Turning on the projector and other equipment
■
Adjusting the image
■
Shutting down the projector
■
Using the Projector
17
Turning On Your Equipment
Make sure your projector and other equipment are set up and
connected correctly, as described in Chapter 1 or Appendix A. Then
turn on your projector, as described below, followed by any
equipment you’ve connected to it. You can turn on your computer
and video equipment in any order, but if you have both a computer
and video source connected, you may have to switch to the desired
source as described on page 20.
Turning On the Projector
Follow these steps to plug in and turn on the projector:
1. Connect one end of the power cord to the projector’s power inlet.
power light
18
Using the Projector
2. Connect the other end to a grounded electrical outlet.
The power light on top of the projector turns orange, indicating
that the projector is receiving power but not yet turned on.
3. Use the tab on the lens ring to rotate the ring and extend the lens.
tab
4. Squeeze the lens cap tabs and remove the lens cap.
Squeeze here
caution
Do not use the projector with
the lens cap in place. The
heat generated by the lens can
damage the cap.
5. Press the red
Power
button
Power
button on top of the projector.
power light
The power light flashes green as the projector warms up, and the
projection lamp comes on in about 30 seconds. The power light
stays green.
warning
Never look into the lens when
the lamp is on. This can
damage your eyes, and is
especially dangerous for
children.
Using the Projector
19
6. Do one of the following:
■
If you’re using a computer, turn it on or restart it. In a few
moments, you should see your computer display projected.
®
(Windows
only: If you see a message saying that it has found
a plug-and-play monitor, click
Cancel
.)
■
If you’re projecting a video, press the
Source
button on top
of the projector to switch to your video source, and press the
Play
button on your DVD player or other device.
If a projected image fails to appear, see the next section for help.
Once you see your image, turn to page 22 for instructions on focusing
and making other image adjustments.
When you’re done with your presentation, shut down the projector as
described on page 25. Shutting down the projector correctly prevents
premature lamp failure and possible damage from overheating.
What To Do If You See a Blank Screen
If you see a blank screen or a blue screen with the message
after turning on your computer or video source, try the following:
■
Make sure the cables are connected correctly, as described on
page 12 (for laptops) or in Appendix A (for other systems).
■
Make sure the power light is green and not flashing and the lens
cover is off.
■
Try restarting your computer.
No Signal
20
Using the Projector
■
Press the
Source
button on top of the projector to select the
correct source. (Allow a few seconds for the projector to sync up
after pressing the button.)
If you’re using a PowerBook:
You may need to set up your system to display on the projector screen
as well as the LCD screen. Follow these steps:
1. From the Apple menu, select
Monitors and Sound.
2. Click the
Drag one
monitor icon on
top of the other
Arrange
Click here
icon.
Control Panels
, then click
3. Drag one monitor icon on top of the other.
If this option isn’t available, you may need to select one of the
Simulscan resolution settings:
1. Click the
Monitor
icon.
Click here
2. Select a
Simulscan
resolution as shown. (Allow a few seconds for
the projector to sync up after making the selection.)
Select a
Simulscan
resolution
Using the Projector
21
If you’re using a PC laptop:
■
Hold down the Fn key and press the function key that lets you
display on an external monitor. It may have an icon such as
or it may be labelled
CRT/LCD
. Allow a few seconds for the
projector to sync up after pressing it. Check your laptop’s manual
or online help for details.
On most systems, the key lets you toggle between the LCD
screen and the projector, or display on both at the same time.
■
Depending on your computer’s video card, you might need to use
the Display utility in the Control Panel to make sure that both the
LCD screen and external monitor port are enabled. See your
computer’s documentation or online help for details.
Adjusting the Image
Once you see your image, you’ll need to make certain adjustments:
■
To focus or zoom your image, see page 23.
■
If the image is too high or too low, you can reposition it. See
page 23.
22
Using the Projector
■
If the image isn’t square, see page 24.
Focusing and Zooming Your Image
p
Rotate the focus ring to sharpen the image.
lens
ring tab
focus ring
Use the tab to rotate the lens ring and reduce or enlarge the image.
You can also change the image size by moving the projector closer to
or farther away from the screen. You can use the
E-Zoom
button on
the remote control to zoom in on a portion of the image. See page 31
for instructions.
Adjusting the Height of Your Image
If the image is too low, you can raise it by extending the projector’s feet.
1. Stand behind the projector. Pull up the blue foot release levers
and lift the front of the projector. This unlocks the feet.
2. Once the image is positioned where you want it, release the levers
to lock the feet in position.
3. To fine-tune the height of the image, rotate the thumb wheels
attached to the projector’s feet.
If the image is no longer square after raising it, see the next section.
caution
Do not hold the
rojector by the lens;
this can damage it.
Using the Projector
23
Adjusting the Image Shape
If the projected image isn’t square or has a “keystone” shape, do one or
more of the following:
■
If your image looks like or , you’ve placed the
projector off to one side of the screen, at an angle. Move it directly
in front of the center of the screen, facing the screen squarely.
■
If your image looks like or , press the + or — side of
Keystone
the
correction, your image will be slightly smaller.
button to correct the shape of the image. After
Keystone button
24
Using the Projector
You can also perform electronic keystone correction using the
projector’s Setting menu. See page 46.
Loading...
