Page 1
EXPAND 80 | EXPAND 80 Mic
Bluetooth® Speakerphone | Expansion microphone
User Guide
Page 2
Contents1
Contents
The EXPAND 80 speakerphone | EXPAND 80 Mic expansion microphone .....................................................................2
Package contents and further information ..............................................................................................................................................3
Package contents EXPAND 80 speakerphone .................................................................................................................................................................................. 3
Package contents EXPAND 80 Mic ..............................................................................................................................................................................................................4
Safety instructions, software and accessories ....................................................................................................................................................................................4
Product overview ........................................................................................................................................................................................................5
Overview of the speakerphone ....................................................................................................................................................................................................................... 5
Overview of the dongle ..........................................................................................................................................................................................................................................7
Overview of expansion microphone .............................................................................................................................................................................................................8
Overview of the icons ...............................................................................................................................................................................................................................................8
Getting started .............................................................................................................................................................................................................9
Positioning the speakerphone and the expansion microphone(s) ................................................................................................................................... 9
Connecting the expansion microphone(s) ..........................................................................................................................................................................................10
Connecting the speakerphone to the mains power supply ...................................................................................................................................................11
Connection possibilities .......................................................................................................................................................................................................................................12
A: Connecting via USB cable ...........................................................................................................................................................................................................................12
B | C | D About pairing and using with wireless Bluetooth
B: Pairing the speakerphone and a mobile device via NFC™ ..............................................................................................................................................14
C: Pairing the speakerphone and a mobile device via Bluetooth
D: Connecting the Bluetooth
®
dongle to a computer and pairing the speakerphone .................................................................................. 16
Installing EPOS software ......................................................................................................................................................................................................................................17
Changing Audio settings for the speakerphone – Microsoft
®
devices ..............................................................................................................................13
®
................................................................................................................................ 15
®
Windows .....................................................................................................................17
Using the speakerphone .................................................................................................................................................................................... 18
Turning the speakerphone and the expansion microphone(s) on ...................................................................................................................................18
Connecting / disconnecting Bluetooth
Turning the speakerphone and the expansion microphone(s) o .................................................................................................................................. 19
Adjusting the volume ............................................................................................................................................................................................................................................20
Muting the microphone(s) ................................................................................................................................................................................................................................20
®
devices ...........................................................................................................................................................................18
Making calls using the speakerphone ......................................................................................................................................................21
Making a call ...................................................................................................................................................................................................................................................................21
Accepting/rejecting/ending a call................................................................................................................................................................................................................21
Redialing ..........................................................................................................................................................................................................................................................................22
Using the voice assistant ................................................................................................................................................................................................................................... 22
Managing multiple calls .......................................................................................................................................................................................................................................23
Merging calls – Conference ............................................................................................................................................................................................................................ 25
Listening to music using the speakerphone – media playback .............................................................................................26
Good to know ............................................................................................................................................................................................................. 27
Switching between Bluetooth® personal and shared mode .................................................................................................................................................27
Waking up from standby ......................................................................................................................................................................................................................................27
Enabling / disabling voice prompts .......................................................................................................................................................................................................... 28
Using an optional Kensington
Bluetooth
®
transmission range ..................................................................................................................................................................................................................... 29
Storing the dongle and the expansion microphone ................................................................................................................................................................... 29
®
lock ......................................................................................................................................................................................................... 28
Maintaining and updating the products ................................................................................................................................................. 30
Cleaning the products ........................................................................................................................................................................................................................................ 30
Updating the rmware of the products ...................................................................................................................................................................................................31
If a problem occurs ... ............................................................................................................................................................................................33
Frequently asked questions ............................................................................................................................................................................................................................33
Clearing pairing list .................................................................................................................................................................................................................................................34
Restoring default settings ................................................................................................................................................................................................................................. 35
Specications ............................................................................................................................................................................................................. 36
EXPAND 80 Bluetooth Speakerphone
Page 3
The EXPAND 80 speakerphone | EXPAND 80 Mic expansion microphone2
The EXPAND 80 speakerphone | EXPAND 80 Mic expansion microphone
The EXPAND 80 speakerphone
Unite colleagues with a premium, scalable
Bluetooth® speakerphone for up to 16 in-room
participants.
Thanks to six adaptive, beamforming microphones
that isolate the human voice from room reverb and
ambient noise, everyone in the room can be heard
and colleagues out of the office are closer to the
conversation.
Connect easily via Bluetooth, USB-C or NFC and listen
as the room fills up with rich, natural sound – perfect for
dynamic conferences and audio-visual presentations.
Crafted with high-quality materials and fabric by Kvadrat,
you get enhanced sound and a professional aesthetic of
your workplace.
For even larger meetings, expansion microphones allow
you to adapt to the demands of your business.
EXPAND 80 offers a space to meet and align in real
time – enabling the confidence and clarity that boosts
collective performance.
Key benets & features
Get your message through with EPOS Voice™
Six adaptive, beamforming microphones and DSP
intelligently isolate voices from room reverb and
ambient noise
Rich, natural sound
Powerful ultra-low distortion speaker in a unique
patent pending suspended speaker box fills the room
with outstanding sound
Superior craftsmanship, statement Scandinavian
design
Crafted with high-quality materials and
sound-enhancing fabric by Kvadrat with a premium,
minimalist aesthetic
Expand your meetings
Attach up to two expansion microphones for larger
meetings
Set up your conference call in seconds
Enjoy multiple connectivity options, an intuitive user
interface and one touch access to your preferred
Voice Assistant or Microsoft Teams
The EXPAND 80 Mic
Boost the range of your EXPAND 80 speakerphone with
expansion microphones that enable superb call clarity
optimized for UC and certified for Microsoft Teams.
Attach one or two microphones to fit the size of your
meeting room and optimize your collaborations.
Ensure effective communication where all participants
are close to noise-cancelling microphones that deliver
excellent voice clarity.
Maintain a professional, stylish conference table with
smart cable management developed for optimal system
function and ease of use.
Crafted from the same high-quality materials as
EXPAND 80, EXPAND 80 Mic creates a unified look
and feel to your meeting room and elevates the interior
design.
Extend the range and possibilities of your EXPAND 80
conference solution and empower the performance of
your entire team.
Key benets & features
Larger meetings UC optimized, and Microsoft
Teams certified
For larger meetings attach up to two expansion
microphones for a UC optimized and Microsoft Teams
certified experience
Ensure everyone is heard clearly
Each EXPAND 80 Mic contains 4 beamforming
microphones, so every in-room participant is always
close to a microphone
Smart cable management for professional, stylish
meetings
Customize cable length to your meeting room with
smart cable management for an optimal system setup
Plug and play conferencing
Simply plug into the EXPAND 80 and start your
meeting. Once connected the entire set-up acts as
one integrated system
Statement Scandinavian design
With sleek, minimal aesthetic and high-quality
materials that match EXPAND 80
EXPAND 80 Bluetooth Speakerphone
Page 4
Package contents and further information3
Package contents and further information
Package contents EXPAND 80 speakerphone
EXPAND 80
Bluetooth speakerphone
Power supply unit
Country adapters
EU, AU, UK
USB-C® cable
BTD 800 USB
Bluetooth® dongle
USB-C® to USB-A adapter
Quick Guide
Safety Guide
Compliance sheet
EXPAND 80 Bluetooth Speakerphone
Page 5
Package contents and further information4
§
§
Package contents EXPAND 80 Mic
EXPAND 80 Mic
Expansion microphone
USB-C® cable
Quick Guide
Safety Guide
Compliance sheet
Safety instructions, software and accessories
For safety instructions, consult the Safety Guide.
The free EPOS software EPOS Connect allows you to add value to your EPOS products.
i
A list of accessories can be found on the product page at www.eposaudio.com.
EXPAND 80 Bluetooth Speakerphone
Page 6
Product overview5
Product overview
Overview of the speakerphone
Multi-function
NFC area
Bluetooth LED
Microphones
Activity LED
Hook on (end call), Power on/o
Hook o (call)
Speaker
Status LEDs
Volume up
Microphone muteBluetooth
Volume down
Overview of the bottom
Expansion microphone socket
Cable channel
Kensington lock,
power, microphone
Call & status LED
USB socket
Kensington lock slot
Cable channel USB
Cable channel expansion microphone
Expansion microphone socket
EXPAND 80 Bluetooth Speakerphone
Cable channel USB
Power supply socket
Page 7
Product overview6
3x
3x
3x
3x
3x
3x
3x
3x
3x
LED overview
Call & status LED Meaning
Speakerphone turned on
3x
Speakerphone turning o
Speakerphone turned o
Incoming call
Active call
Call on hold
Second call on hold
Activity LED Meaning
Media playback
Voice assistant activating
Voice assistant activated
Status LEDs Meaning
Microphone muted
Volume level; eight step indication
Bluetooth LED Meaning
Speakerphone in pairing mode
Bluetooth device connected
No Bluetooth device connected
Searching for paired Bluetooth devices
EXPAND 80 Bluetooth Speakerphone
Page 8
Product overview7
3x
3x
3x
3x
3x
3x
3x
3x
3x
3x
3x
Overview of the dongle
Link LED
USB-A connector
LED overview
LED Meaning
Dongle in pairing mode:
searching for Bluetooth devices to pair and connect
3x
3x
Pairing successful
Pairing failed
Dongle tries to connect to a Bluetooth device
Dongle and Bluetooth device connected
Incoming call
• Outgoing / active call
• Media playback
Microphone of the connected Bluetooth device is muted
Link button
EXPAND 80 Bluetooth Speakerphone
Page 9
Product overview8
3x
3x
3x
3x
Overview of expansion microphone
The expansion microphone EXPAND 80 Mic is available as an accessory. A list of accessories can be found on the
product page at www.eposaudio.com.
Microphone mute
LED overview
Microphones
Cable holder
Cable holder
Status LED
LED Meaning
• Expansion microphone turned on
white dimmed
• Media playback
USB-C socket
Cable holder
Cable
Jack plug
Overview of the icons
Tap the button
2x
3s
Press the button twice LED indications
Press and hold the button Voice prompt is announced
Incoming call
• Active call
• Voice assistant active
Call on hold
Microphone muted
i
Notes: Good to know
EXPAND 80 Bluetooth Speakerphone
Page 10
Getting started9
Getting started
Positioning the speakerphone and the expansion microphone(s)
You can use the speakerphone in small, medium and large meeting rooms with up to 16 participants.
X Place the speakerphone in the middle of the table for optimal sound.
max. 16
< 3 m
For larger rooms you can connect expansion microphones. With each microphone you can cover up to 8 additional
participants.
X Place the expansion microphone in the middle of the table and connect it – see next page.
max. 24
< 3 m
max. 32
EXPAND 80 Bluetooth Speakerphone
Page 11
Getting started10
Connecting the expansion microphone(s)
1
A
B
X Connect the microphone plug to one of the expansion microphone sockets.
The expansion microphone turns on or o automatically with the speakerphone.
2
X Put the cable into the cable channel to secure it.
3
X Rotate the expansion microphone so that the mute
button faces away from the speakerphone.
5
A
4
X Align the cable length on the table and roll up the
excess cable.
X Secure the cable in the holders.
B
EXPAND 80 Bluetooth Speakerphone
Page 12
Getting started11
Connecting the speakerphone to the mains power supply
1
X US: Flip out the two pins.
X EU/UK/AU: Select a suitable country adapter and slide
it in.
US EU/UK/AU
3
2
X Connect the power supply to the power supply socket.
X Put the cable into the cable channel to secure it.
4 5
X Plug the power supply unit into a wall socket. The speakerphone switches on. The LED lights up white
EXPAND 80 Bluetooth Speakerphone
Page 13
Getting started12
A B
C D
Connection possibilities
The speakerphone can be connected via:
USB NFC™ Bluetooth
A: USB cable B: Bluetooth via NFC C: Bluetooth D: Bluetooth via dongle
®
BTD 800 USB
A: Connecting via USB cable
1
X Connect the USB plug to the USB socket.
2
A
B
X Put the cable into the cable channel (A or B) to secure it.
3
X Connect the USB connector directly to a USB-C port or to a USB-A port using the included adapter.
The speakerphone turns on automatically. The LED lights up white.
EXPAND 80 Bluetooth Speakerphone
®
USB-AUSB-C
Page 14
Getting started13
B | C | D About pairing and using with wireless Bluetooth® devices
CAUTION
Danger of malfunction!
The transmitted radio waves of mobile phones can impair the operation of sensitive and unprotected devices.
X Only make calls with the speakerphone in locations where wireless Bluetooth transmission is permitted.
The speakerphone complies with the Bluetooth 5.0 standard. In order to transmit data wirelessly, you have to pair your
speakerphone with Bluetooth devices that support “hands free profile” (HFP), “headset profile” (HSP) or “advanced audio
distribution profile” (A2DP).
The speakerphone can be paired to:
• a mobile device: via NFC™ (B, see page 14) or via Bluetooth (C, see page 15) or
• the BTD 800 USB dongle: via Bluetooth (D, see page 16).
The speakerphone can be set to personal or shared mode (see page 27). The default setting is shared mode. In this
mode pairing must be performed every time when connecting a device via Bluetooth.
Default functionality (shared mode):
The speakerphone can save up to eight paired Bluetooth
devices. If you pair the speakerphone with a ninth
Bluetooth device, the saved connection profile of the least
recently used device will be overwritten. If you want to
re-establish a connection with this device, you have to pair
the speakerphone again.
The speakerphone can be wirelessly connected to two
devices at the same time.
You can only connect another device by disconnecting
one of the already connected devices.
The speakerphone can be used wirelessly with a computer.
You can use:
• the computer’s built in Bluetooth functionality or
• the BTD 800 USB dongle.
EXPAND 80 Bluetooth Speakerphone
Page 15
Getting started14
i
B: Pairing the speakerphone and a mobile device via NFC™
1
Bluetooth®
NFC™
X Activate Bluetooth and NFC (Near Field Communication)
on your mobile device – see instruction manual of your
mobile device.
3
2
X Move the mobile device in small circles directly above
the NFC area of the speakerphone.
Once the speakerphone is paired with the mobile device, the LED lights up blue.
If required: Confirm the speakerphone on your mobile devices.
EXPAND 80 Bluetooth Speakerphone
Page 16
Getting started15
C: Pairing the speakerphone and a mobile device via Bluetooth®
1
2s
X Press and hold the Bluetooth button until the LED
ashes blue and red.
The speakerphone is in pairing mode.
3
...
...
EPOS EXPAND 80
...
2
X Enable the Bluetooth visibility on your mobile device –
see instruction manual of your mobile device.
X Start a search for Bluetooth devices.
All available devices in the proximity of the mobile
device are displayed.
4
X Select “EPOS EXPAND 80”* to establish a Bluetooth
connection to the speakerphone.
* You can change the default name via EPOS Connect.
Once the speakerphone is paired with the mobile device,
the LED lights up blue.
EXPAND 80 Bluetooth Speakerphone
Page 17
Getting started16
i
D: Connecting the Bluetooth® dongle to a computer and pairing the speakerphone
To connect the speakerphone wirelessly with a computer, use the BTD 800 USB dongle. The dongle and the
speakerphone in the bundle are already paired.
1
X Release the dongle from the storage. X Plug the dongle into the USB port of your computer.
3
2
USB-A
The dongle and speakerphone LED flashes blue while
searching.
Once the speakerphone is connected with the dongle,
the speakerphone LED lights up blue and the dongle LED
switches to dimmed blue.
To manually pair the speakerphone and the dongle, activate the pairing mode for both:
X Press and hold the speakerphone’s Bluetooth button and the dongle’s button until the LEDs alternately ash
blue and red. Once the dongle and the speakerphone are connected, the speakerphone lights up blue and
the dongle lights up dimmed blue.
EXPAND 80 Bluetooth Speakerphone
Page 18
Getting started17
Installing EPOS software
The free EPOS software allows you to add value to your EPOS products. It enables easy set-up, conguration and update
of your speakerphone.
Examples of supported settings and congurations in EPOS Connect:
• Bluetooth on/o,
• Device name
• Personal/shared mode,
• Manage pairing list
• Sounds and notications including voice prompt language
• Factory reset
EPOS Connect oers further congurations and additional settings – see options in the software.
X Download the software from
www.eposaudio.com/connect.
EPOS Connect
EPOS Connect
x
X Install the software.
You need administrator rights on your computer – if
necessary, contact your IT department.
To make calls via the computer:
X Install a softphone (VoIP Software) or ask your admin for
support.
www.eposaudio.com/connect
Changing Audio settings for the speakerphone – Microsoft® Windows
Windows usually changes the Audio settings automatically
if you connect a new device.
Audio settings
EXPAND
EXPAND
x
If the speakerphone is connected but you hear no sound:
X Right-click the Audio icon.
X Select under output EXPAND 80 as speaker.
X Select under input EXPAND 80 as microphone.
EXPAND 80 Bluetooth Speakerphone
Page 19
Using the speakerphone 18
i
Using the speakerphone
Turning the speakerphone and the expansion microphone(s) on
X Press the Power on/o button.
The LED lights up white. The expansion microphone turns on automatically and the LED lights up dimmed.
Connecting / disconnecting Bluetooth® devices
Connecting Bluetooth devices
Depending on the setting for personal/shared mode (see page 27).
A: Shared mode
The speakerphone is by default in shared mode. In this mode pairing must be performed every time when connecting a
device via Bluetooth.
• B NFC see page 14 or
• C Bluetooth see page 15 or
• D Dongle see page 16
B: Personal mode
The speakerphone will by default attempt to connect to the two last connected Bluetooth devices.
3x
X Activate Bluetooth on the paired device(s).
The LED ashes blue while the speakerphone attempts to connect to previously paired Bluetooth device(s). Once the
connection is successfully established, the LED lights up blue.
If the Bluetooth LED does not ash blue (automatic search after switch-on):
X Press the Bluetooth button to connect manually.
Only two out of the maximum eight paired Bluetooth devices can be simultaneously connected to the
speakerphone.
The search for paired devices will timeout if no devices are found. After this, connections must be established
manually on the paired Bluetooth device or by pressing the Bluetooth button on the speakerphone
EXPAND 80 Bluetooth Speakerphone
Page 20
Using the speakerphone 19
Disconnecting Bluetooth device(s)
X Press the Bluetooth button. The LED turns o. OR Deactivate Bluetooth on the connected device.
To re-connect paired Bluetooth devices (personal mode only):
X Press the button again.
Turning the speakerphone and the expansion microphone(s) o
2s
X Press and hold the Power on/o button.
The LED ashes red 3 times and turns o. All volume settings are saved. The expansion microphone turns o.
3x
EXPAND 80 Bluetooth Speakerphone
Page 21
Using the speakerphone 20
Adjusting the volume
You can adjust three independent volume settings for the
1
2
speakerphone:
1. Call volume: during an active call
2. Audio volume: during audio streaming
3. Volume for ring tone, tones and voice prompts:
in idle mode – no active call or audio streaming
3
Increasing the volume Decreasing the volume
X Press the button + X Press the button –
LEDs and volume will be increased or reduced by half step with each button press.
Muting the microphone(s)
Muting the microphone Unmuting the microphone
X Press the Microphone mute button.
The LEDs light up red.
X Press the button again.
The LEDs turn o.
If you use one or two expansion microphone(s):
X Press the Microphone mute button on the
speakerphone or on the expansion microphone.
All microphones will be muted or unmuted.
EXPAND 80 Bluetooth Speakerphone
Page 22
Making calls using the speakerphone 21
Making calls using the speakerphone
Making a call
X Initiate the call on your connected device.
Softphone
x
Accepting/rejecting/ending a call
The LED lights up green.
If your call is not automatically transferred to the
speakerphone:
X Press the speakerphone’s hook o button , or use call
transfer functionality on the mobile device.
When you receive a call: You hear a ring tone and the LED ashes green.
Accept/hold a call
Reject/end a call
LED
2x
LED
LED
Accepts a call
Puts an active call on hold (pause)
Rejects a call
Ends a call
EXPAND 80 Bluetooth Speakerphone
LED
Page 23
Making calls using the speakerphone 22
i
Redialing
2x
Redials the last number
LED
Cancels redialing
LED
Using the voice assistant
Voice assistant will only be supported for device(s) connected via Bluetooth. Available functionality depends on the
connected device.
3x
2s
Activates voice assistant
Cancels voice assistant
The last connected Bluetooth device will be used
for voice assistant.
EXPAND 80 Bluetooth Speakerphone
Page 24
Making calls using the speakerphone 23
Managing multiple calls
Softphone
x
You can use the speakerphone with up to three connected devices, one connected via USB and two via Bluetooth. Two
calls can be managed simultaneously. If you receive a call during an active call, a knock on tone will be played.
Accept second call
Softphone
x
Active call 2nd incoming call
Accepts the incoming call and
puts the active call on hold
LED
Reject second call
Softphone
Active call 2nd incoming call
x
Rejects the incoming call and
continues the active call
LED
EXPAND 80 Bluetooth Speakerphone
Page 25
Making calls using the speakerphone 24
Toggle between calls
Softphone
Active call 2nd held call
End call
Softphone
x
Toggles between the
active and held call
LED
x
Active call 2nd held call
Ends the active call and
makes the held call active
LED
EXPAND 80 Bluetooth Speakerphone
Page 26
Making calls using the speakerphone 25
Merging calls – Conference
Two calls – one via USB, the other via Bluetooth – can be merged in a conference.
Merge/unmerge calls
Softphone
Active call 2nd held call
End merged calls
Softphone
x
Merges the active call and
2s
the held call
LED
Unmerges the calls;
2s
puts the previously held call on hold again
LED
x
Call 1 Merged call 2
Ends all calls
LED
EXPAND 80 Bluetooth Speakerphone
Page 27
Listening to music using the speakerphone – media playback26
i
Listening to music using the speakerphone – media playback
You can listen to media playback via USB or Bluetooth connected device.
Softphone
Control active media playback
x
Plays audio
Pauses audio
2x
Skips to the next track
If you receive and accept a call, media playback is paused and restarts after the call – if supported by the
connected device.
EXPAND 80 Bluetooth Speakerphone
Page 28
Good to know27
i
Good to know
Switching between Bluetooth® personal and shared mode
A
2s
Activating Personal mode
If the speakerphone is used as a personal device it will
automatically attempt to connect to the last eight paired
devices.
In this setup the Personal Mode should be used.
X Press the Bluetooth and + button.
A voice prompt is announced.
After change of mode, the pairing list is cleared and you have to pair devices again (see page 16).
B
2s
Activating Shared mode
If the speakerphone is used as a shared device automatic
connection to previously paired devices may not be
desired.
In this setup the Shared Mode (default) should be used.
In this mode pairing must be performed every time when
connecting a device via Bluetooth.
X Press the Bluetooth and – button.
A voice prompt is announced.
Waking up from standby
zzz
The speakerphone enters standby mode automatically
after some time to save energy – depends on connection
status, activity etc.
While in standby the Call & status LED is dimmed and all
other LEDs are o.
X Press any button to end the standby mode.
EXPAND 80 Bluetooth Speakerphone
Page 29
Good to know28
Enabling / disabling voice prompts
In idle mode (no active call or music reproduction):
X Press and hold the mute button until the speakerphone
announces a voice prompt for on or o.
If the voice prompts are deactivated you hear tones
instead.
You can also change this setting via
EPOS Connect.
5s
Using an optional Kensington® lock
You can secure your speakerphone e. g. on a table of a meeting room with an optional Kensington lock.
You can connect the Kensington lock both inside A or outside B the product.
A
The Kensington lock slot inside the speakerphone is optimized for combination locks with T-bar interface and wire with
less than Ø 5 mm.
X Mount the cable – see instructions of Kensington lock.
X Rotate the lock and insert into the Kensington slot.
X Put the cable into the cable channel to secure it.
B
The Kensington slot outside the product supports most common Kensington locks.
X Mount the cable – see instructions of Kensington lock.
X Insert the lock into Kensington slot.
EXPAND 80 Bluetooth Speakerphone
Page 30
Good to know29
Bluetooth® transmission range
Calling and media playback is only possible in the Bluetooth transmission range of the devices. The transmission range
largely depends on environmental conditions such as wall thickness, wall composition etc. With a free line of sight, the
transmission range of most mobile phones and Bluetooth devices is up to 25 meters.
5 min
If you leave the Bluetooth transmission range, the audio
quality deteriorates first and later connected devices will
be disconnected.
If you re-enter the Bluetooth transmission range within
short period of time, the speakerphone will attempt to
restore the connection(s) – in personal mode only.
If you spend a longer period of time outside the Bluetooth
transmission range:
X Press the Bluetooth button to connect manually.
Storing the dongle and the expansion microphone
X Place the dongle in the storage slot. X Disconnect the plug from the speakerphone.
X Unlock the cable from the holders, roll it up and x it in
the holder.
EXPAND 80 Bluetooth Speakerphone
Page 31
Maintaining and updating the products30
Maintaining and updating the products
Cleaning the products
CAUTION
Liquids can damage the electronics of the product!
Liquids entering the housing of the device can cause a short circuit and damage the electronics.
X Keep all liquids far away from the product.
X Do not use any cleansing agents or solvents.
X Do not vacuum clean the top cover of the product.
X Before cleaning, disconnect the speakerphone from the mains power supply.
X Only use a dry cloth to clean the product.
X Clean the fabric with a lint roller.
EXPAND 80 Bluetooth Speakerphone
Page 32
Maintaining and updating the products31
Updating the rmware of the products
You can update the rmware of your speakerphone, expansion microphone and dongle by using the free EPOS Connect
software.
X Download the software from www.eposaudio.com/connect.
X Install the software.
To install the software, you need administrator rights on your computer. If necessary, contact your IT department.
Updating the rmware of the speakerphone
1
X Connect the USB connector to the USB socket at the bottom.
2 3
EPOS Connect
®
X Connect the USB connector directly to a USB-C port or to a USB-A port using the included adapter.
X Start EPOS Connect. EPOS Connect checks if the installed rmware is the latest version available on the EPOS server.
USB-AUSB-C
If required, upgrade to the latest version.
x
EXPAND 80 Bluetooth Speakerphone
Page 33
Maintaining and updating the products32
Updating the rmware of the Bluetooth dongle BTD 800 USB
1
USB-A
X Plug the Bluetooth USB dongle into the USB port of
your computer.
Updating the rmware of the expansion microphone
1 3
2
EPOS Connect
X Start EPOS Connect.
EPOS Connect checks if the installed rmware is the
latest version available on the EPOS server. If required,
upgrade to the latest version.
EPOS Connect
x
x
2
®
X Open the cover at the bottom.
X Connect the USB connector to the USB socket.
X Connect the USB connector directly to a USB-C port or to a USB-A port using the adapter.
X Start EPOS Connect.
EPOS Connect checks if the installed rmware is the latest version available on the EPOS server. If required, upgrade
to the latest version.
USB-AUSB-C
EXPAND 80 Bluetooth Speakerphone
Page 34
If a problem occurs ...33
If a problem occurs ...
Frequently asked questions
Problem Possible cause Solution Page
Speakerphone cannot be
turned on
Expansion microphone
cannot be turned on
No audio signal USB connector not inserted
Bad audio quality Bluetooth transmission range is
Speakerphone cannot be
paired/connected
Activity LED is dimmed
and all other LEDs o
No voice prompts
announced (tones only)
Speakerphone does not
react to any button press
No Bluetooth connection
via dongle BTD 800 USB
Speakerphone/dongle
does not accept new
devices (Pairing)
Expansion microphone
does not react
Speakerphone is not connected to
the mains power supply
Plug not connected properly
correctly in the computer or
adapter
Speakerphone is not paired with
the mobile device or dongle
Volume is adjusted too low
Speakerphone is turned o
Computer connection:
Speakerphone not selected as
audio device
exceeded
Pairing does not work
Speakerphone’s pairing list was
cleared but it is still in the list of
paired devices of the Bluetooth
device
Distance too high while pairing
Bluetooth not enabled
Speakerphone in standby mode
Voice prompts are disabled
Operation of the speakerphone is
faulty
Dongle not inserted correctly in the
computer
Dongle and speakerphone not
connected
Pairing list disturbed
Expansion microphone disturbed
X Connect the speakerphone to the mains
11
power supply.
X Plug in again. 17
X Plug in again. 12
X Check if the speakerphone is paired. If
13
necessary, pair the speakerphone again.
X Increase the volume. 20
X Turn the speakerphone on. 18
X Change the audio settings of your
computer.
X Reduce the distance between
29
speakerphone the connected Bluetooth
device.
X Check if your Bluetooth device supports
the Handsfree or Headset prole.
X Remove the speakerphone from the
list of paired devices in your Bluetooth
device.
X Pair devices again.
X Reduce the distance between
speakerphone the Bluetooth device.
X Make sure Bluetooth is enabled on
the speakerphone and the device
connecting to.
X Press any button or plug in USB to end
27
the standby mode.
X Enable the voice prompts. 21
X Press and hold the Power on/o
button for 10 seconds to reboot the
speakerphone.
X Restore factory default settings. 34
X Insert the dongle again. 16
X Pair the dongle and your speakerphone. 16
X Clear the speakerphone’s list of
30
previously paired devices.
X Clear the dongle’s list of previously
34
paired devices.
X Unplug and plug it in again. –
–
–
–
–
–
–
If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed
solutions, please contact your local EPOS partner for assistance. To nd an EPOS partner in your country, search at
www.eposaudio.com
EXPAND 80 Bluetooth Speakerphone
Page 35
If a problem occurs ...34
Clearing pairing list
Clearing the speakerphone’s pairing list
5s
Clearing the dongle’s pairing list
X Press and hold the multi-function button and Bluetooth
button until you hear a voice prompt.
The LED ashes blue three times to indicate that pairing
list is cleared.
3x
1
2
3s
USB-A
X Plug the dongle into the USB port of your computer. X Press and hold the button until the LED ashes blue
and red.
X Double tap the button.
3
2x
The LED ashes purple three times to indicate that
pairing list is cleared.
The dongle automatically enters pairing mode.
3x
EXPAND 80 Bluetooth Speakerphone
Page 36
If a problem occurs ...35
Restoring default settings
Restoring speakerphone’s factory default settings
5s
X Press and hold the mute button and multi-function
button until the device restarts.
All settings and the pairing list will be cleared.
If the voice prompt “Unavailable” is announced, Factory
Reset is disabled in EPOS Connect:
X Activate Factory Reset in EPOS Connect or contact
your IT department.
EXPAND 80 Bluetooth Speakerphone
Page 37
Specications36
Specications
EXPAND 80 speakerphone
Dimensions (L x W x H)
Weight
Speaker type
Speaker frequency response
Microphone type
Microphone frequency response
Microphone coverage
Sound Pressure
Connectors
Power supply unit
Nominal input voltage
Nominal input current
Mains frequency
Nominal output voltage
Nominal output current
Weight
315.6 x 118.6 x 46.1 mm / 12.4 x 4.7 x 1.8 in
980 g / 34.57 oz
Neodymium magnet
Communication (USB / Bluetooth) 150 – 7,500 Hz
Media streaming (USB / Bluetooth) 50 – 20,000 Hz
Beamforming digital MEMS omnidirectional microphones (6 microphones)
150 – 7,500 Hz (USB / Bluetooth)
360 degrees
max. 85 dB
• Power supply socket
• USB-C socket
• 2x jack socket 3.5 mm for microphones
• 2x Kensington lock slot
100 – 240 V
max. 0.5 A
50 – 60 Hz
5.0 V
2.4 A
approx. 110 g / 3.88 oz / 0.24 lbs
BTD 800 USB Bluetooth dongle
Dimensions (W x H x D)
Weight
Bluetooth
Bluetooth
Range
Transmission frequency
Proles
Output power
Typical sensitivity
22 x 16 x 6 mm / 0.87 x 0.63 x 0.24 in
2 g / 0.07 oz / 0.004 lbs
Speakerphone: version 5.0/ class 1
Dongle: version 4.2/ class 1
up to 30 m (device-dependent)
2402 – 2480 MHz
• HSP Headset Prole (version 1.2)
• HFP Handsfree Profile (version 1.7)
• A2DP Advanced Audio Distribution Profile (version 1.3.1)
• AVR CP Audio Video Remote Control Prole (version 1.6)
Speakerphone: max. 10 dBm
Dongle: max. 8 dBm
-89 dBm
EXPAND 80 Bluetooth Speakerphone
Page 38
Specications37
EXPAND 80 Mic expansion microphone
Dimensions (Ø x H) 97 x 26.5 mm / 3.82 x 1.04 in
Weight 980 g / 2.16 lbs / 34.57 oz
Microphone type Beamforming digital MEMS omnidirectional microphones (4 microphones)
Microphone frequency response 150 – 7,500 Hz
Microphone coverage 360 degrees
Connector 2.5 mm jack
General data
Temperature range
operation: +10 °C to +40 °C / +50 °F to +104 °F
storage: -20 °C to +60 °C / -4 °F to +140 °F
Relative humidity
operation: 20% to 85%
storage: 10% to 95%
Trademarks
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks
by Sennheiser Communications A/S is under license.
The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries.
®
USB Type-C
and USB-C® are trademarks of USB Implementers Forum.
Kensington is a registered trademark of ACCO Brands. Kensington The Professionals’ Choice is a trademark of ACCO
Brands. All other registered and unregistered trademarks are the property of their respective owners.
EXPAND 80 Bluetooth Speakerphone
Page 39
Specications38
Sennheiser Communications A/S
Industriparken 27, DK-2750 Ballerup, Denmark
www.eposaudio.com
EXPAND 80 Bluetooth Speakerphone
Publ. 07/20, A01
Loading...
