EMU Trike MAX Owner's Manual

BEING GREEN HAS NEVER LOOKED SO COOL!

American Scooter Company

American Scooter Company LLC, EMU Trikes™

Please note that due to continuing improvements to our products and services, pictures

and/or descriptions may differ from the model and/or parts depicted in this manual.

READ THIS MANUAL COMPLETELY BEFORE ASSEMBLING AND RIDING

EMU Trike™

Electric Multi Use Trike

Owners

Manual

2013-2014

Models – EMU-Max

Page 2

Table of Contents

Front Cover-----------------------------------1

Table of Contents---------------------------2

Technical Information----------------------3

Warning Statement-------------------------4

Safety Warning------------------------------5

EMU Parts List-------------------------------6

Tool Kit & Assembly------------------------7

Installing the Handlebar-------------------9

Connecting Electric Plugs----------------10

Removal of Battery Cover---------------11

Folding the Handlebar--------------------12

Installing Basket----------------------------13

Charging Batteries-------------------------14

Riding your EMU---------------------------15

Adjusting Brakes---------------------------17

Maintenance---------------------------------18

Trouble Shooting---------------------------19

Warranty--------------------------------------20

Page 3

Technical Information

Type of Motor 48V Permanent Magnet Brushless DC Motor

Motor Power 500W

Battery Type Lithium ion

Battery 10AH 48V

Charger UL Approved 110v

Charging Time 4-6 hours

Rated Speed (2 speed) 0-8mph & 0-21mph *

Single Charge distance Max up to 20 miles*

Maximum Capacity 265 lbs

EMU. Net Weight Max around 70 lbs

*Note: Speed and distance may vary depending upon the terrain and weight

load.

Page 4

Warning Statement

STOP ----- IMPORTANT!

Before you ride your EMU please read this carefully:

Your existing insurance policy may not provide coverage for your
EMU trike of electric vehicles. You should contact your insurance
company to confirm if coverage is provided.

Please do not ride your EMU until you have read this owners manual
completely and you fully understand all its contents. This manual
contains critical information for your safety. If you have any questions
about the safe operation of your EMU, you should contact your
authorized EMU dealer.

It is very important that you follow all the safety instruction within this
manual in order to ensure maximum safety.

Failure to comply with all the standards outlined in this manual could
result in fire/ or serious injury.

American Scooter Company or authorized dealers will not be liable
for any damage or injuries whatsoever caused when riding, faulty
assembly or unauthorized repairs or modifications. Any repairs
carried out by unauthorized service technicians are the sole
responsibility of the owner and the Warranty becomes void.

Our EMU range of products are designed to be ecologically
conscious, please dispose of used batteries in compliance with local
laws.

Page 5

Safety Warning

(Please read before riding your EMU)

Before riding your EMU please read and be sure you understand this manual
completely. The EMU is not a toy and should always be operated in a safe
manner. American Scooter Company will not be liable for any damages or
injuries to any person. Any questions you may have about the safe operation of
your EMU should be directed to your authorized dealer.

Failure to comply with the safety warnings and operating instructions included in
this manual could result in serious injury to the operator and to others.

The EMU is not designed for all user repairs. An authorized EMU repair
technician should carry out major repairs. American Scooter Company will not be
liable for any damage or injuries due to repairs by unauthorized individuals.

The EMU should only be operated by individuals 16 years of age or older.

The EMU is not a toy and should always be used responsibly.

Safety Instructions

! Always wear approved safety equipment when operating the EMU.

! Observe the maximum weight capacity of 265 lbs.

! No more than one person should ride the EMU at a time.

! The EMU should always be operated in a safe manner under safe

conditions.

! Never lean back on your EMU.

! Before riding, inspect the EMU to insure all quick releases and pivot points

are secured properly. Make sure handlebars are secured and hand brake

is in operating condition.

! Check the battery to insure it is properly charged.

! The power ignition must be off when charging.

! Remove your EMU from charge once it is charged. Do not leave charger

plugged in any longer that 8 hours.

! Charge the battery after each use or when required.

! Do not expose the EMU, batteries or charger to wet conditions.

! Always drive on paved surfaces.

! Be careful when riding on wet or uneven surfaces.

Page 6

12

EMU Parts List

!" #$%&'()*++,(

-" .$/0(1$23+(
4" 5,+6'$76(0%'%$(
8" 9+2:,7;*'(<=%:>(
?" #$%&'(@%$3(
A" 12B3+'(<%='7%&2,>(
C" #%,:7&;(92&:,+D2$(E%&&+6'7%&(
F" G;&7'7%&(H+I(<=%:>(
J" K*$%'',+(
!L" (9+2:,7;*'(MN7'6*(

!!" O$++&(1/''%&(@%$(9%$&(
!-" 92&:,+D2$(*+7;*'(2:P/B'0+&'(
!4" Q%N+$(G&:762'%$(<=%:>(
!8" M+2'(Q%B'(<R='7%&2,>(
!?" M+2'(9+7;*'(S:P/B'0+&'(
!A" 92&:D$23+(
!C" M2@+'I()*++,B(
!F" T+2$()*++,B(
!J" 12''+$I(E%U+$(

-L" 5,+6'$762,(E%&&+6'%$B(

1

2

3 4 5

6

7

8 9 10/ 13

11

16

14

15

17

18

19

20

Page 7

Tool Kit

Charger

Tool Kit

Assembling the EMU

Help me be required to assemble your new EMU

1/ Unpack the E.M.U. and
inspect all the parts to insure
all are included. Please
contact your E.M.U. dealer
immediately if any parts are
missing or damaged when
shipped.

Place your E.M.U. on a flat,
clean surface. Place a block

3.5” under the front, by the
battery. This will make it
easier for the next step.
