Emotiva S8, S12, S10 User Manual
Important Safety Precautions and Explanation of Symbols
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important installation, operation, and service instructions in this manual.
!
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltages within the enclosure that may be of sucient magnitude to
constitute a risk of electrical shock to the user.
Please read this manual thoroughly before attempting to install, congure, or operate the Emotiva BasX
Subwoofer. After successful installation and conguration of the BasX Subwoofer, be sure to retain this
manual in a safe place for future reference.
Safety is a key component to a long lasting and trouble free installation. Please read and follow all
instructions and heed all warnings on the BasX Subwoofer and in this manual. The vast majority of the
subsequent safety precautions are common sense. If you are not comfortable with the installation of audio/
video entertainment equipment, you should seek the services of a qualied installation professional or call
us for help.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THE BASX SUBWOOFER
NEAR WATER OR IN WET LOCATIONS, DO NOT EXPOSE IT TO RAIN OR MOISTURE, DO NOT EXPOSE IT
!
TO DRIPPING OR SPLASHING FROM OTHER SOURCES, AND ENSURE THAT NO OBJECTS FILLED WITH
LIQUIDS SUCH AS VASES ARE PLACED ON IT. DOING SO MAY RESULT IN DAMAGE TO THE UNIT AND
THE RISK OF ELECTRIC SHOCK, WHICH MAY RESULT IN BODILY INJURY OR DEATH.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE AMPLIFIER PLATE OR
DRIVERS FROM THE BASX SUBWOOFER. THERE ARE NO USERSERVICEABLE PARTS INSIDE THE UNIT.
REFER ALL SERVICE TO QUALIFIED SERVICE PERSONNEL.
Do not install the BasX Subwoofer near or above any heat sources such as radiators, heating vents, or other
apparatus’ that produce heat. Do not block any ventilation openings or heat sinks. Avoid installing the
unit directly above other heat-producing equipment unless sucient ventilation or forced-air cooling is
provided.
Do not install the BasX Subwoofer in locations without proper ventilation. The BasX Subwoofer should not
be operated on a bed, sofa, rug, or similar surface that may block vents. The unit should not be installed
in an enclosed location such as a bookcase, cabinet, or closed equipment rack unless sucient forced-air
ventilation is provided, and clearance should be maintained between the rear-mounted heat sinks and
objects like drapes that may reduce ventilation.
Always install your BasX Subwoofer according to the manufacturer’s instructions and only use attachments
or accessories specied by the manufacturer.
Do not install the BasX Subwoofer on any stand, shelf, or other piece of furniture that is unable to support
its weight. If a cart is used to move the unit, use caution to avoid injury from tip-over.
Connect the BasX Subwoofer only to power sources of the correct voltage (as shown in this manual and on
the BasX Subwoofer unit).
Protect power supply cables from being pinched, walked on, or otherwise damaged. Be especially careful
where the power cable enters the power outlet and the unit.
Only connect the BasX Subwoofer to an electrical outlet or extension cord of appropriate type and rating.
DO NOT defeat the safety purpose of a grounding or polarized plug by removing ground pins or using
unsafe adapters. A polarized plug has two blades - one wider than the other. A grounding plug has a
third ground prong in addition to the two main conductors. The wide blade or third groundling prong is
provided for your safety. If the provided plug does not t your outlet, consult an electrician to replace your
obsolete outlet. If you replace the power cord, only use one of similar type and equal or greater current
rating.
The power cable for the BasX Subwoofer should be unplugged from the outlet during severe electrical
storms, or when unused for a long period of time.
Only replace the fuse(s) in the BasX Subwoofer with fuse(s) of proper value and voltage rating.
The BasX Subwoofer should only be cleaned as directed in the manual. Avoid spraying liquids directly onto
the unit or drivers.
You should seek service for your BasX Subwoofer by qualied service personnel if any of the following
occur:
!
1. The power-supply cord or the plug has been damaged.
2. Objects or liquid have fallen or spilled into the vents.
3. The unit has been exposed to rain.
4. The unit exhibits a marked change in performance.
5. The unit has been dropped, or its enclosure or chassis is damaged.
NOTE: TO COMPLETELY DISCONNECT THE BASX SUBWOOFER FROM THE AC POWER MAINS, DISCONNECT
THE AC POWER CORD FROM THE AC RECEPTACLE.
NOTE: THE POWER CORD ON THE BASX SUBWOOFER MUST REMAIN READILY ACCESSIBLE AT ALL TIMES.
CAUTION
CAUTION: TO REDUCE THE RISK
OF ELECTRICAL SHOCK, DO
NOT REMOVE COVER. NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
BasX Subwoofers
Emotiva BasX Subwoofers
Contents
Important Safety Precautions and Explanation of Symbols
Emotiva BasX Subwoofers ............................................................................................1
Introduction ......................................................................................................................3
About This Manual .......................................................................................................... 4
Features ..............................................................................................................................5
Unpacking ..........................................................................................................................6
Quick Start .........................................................................................................................7
Setting The AC Line Voltage on Your BasX Subwoofer ......................................7
BasX Subwoofer Controls ............................................................................................ 8
BasX S12........................................................................................................................... 11
BasX S10........................................................................................................................... 12
BasX S8 ............................................................................................................................ 13
Subwoofer Placement and Conguration ........................................................... 14
Connections ................................................................................................................... 16
Care and Maintenance ............................................................................................... 17
Emotiva Audio Corporation Three-Year Limited Warranty ............................ 18
Accessories ..................................................................................................................... 21
Notes ................................................................................................................................. 22
Page 1
BasX Subwoofers
Page 2
BasX Subwoofers
Introduction
Thank you for purchasing one of our new Emotiva BasX™ Subwoofers.
Our Emotiva BasX™ Subwoofers were designed to reproduce the lowest frequencies in the audio
spectrum accurately and with exceptionally low distortion - even at high listening levels. This means
that our BasX Subwoofers can deliver the dynamics and raw power you need to make a modern
movie sound-track sound truly monumental, but still oer the precision and musicality you need to
get the most from well recorded music. With our BasX Subwoofers, you don’t have to compromise;
you really can have it all.
Our BasX Subwoofers come in three models: the S8, the S10, and the S12. Each model includes a
heavy duty high excursion bass driver, powered by a high-eciency Class D amplier, and oers
controls that allow you to congure it to work perfectly in conjunction with your main speakers. The
various models oer identical controls and similar features; the main dierence is that the larger
models can produce higher output levels, and their frequency response extends slightly lower.
The cabinets, which are quite compact for the performance they deliver, are built of heavy,
acoustically inert MDF, and are covered in attractive yet practical textured vinyl. Sculpted removable
grill cloths perfectly match the outline of the cabinets, and heavy duty integral feet provide support
and minimize vibration. All controls and connections are conveniently located on the rear panel,
which also provides cooling for the internal ampliers.
We’re very proud of our new BasX Subwoofers, and we hope you’ll enjoy listening to them as much
as we enjoyed designing and manufacturing them.
Happy listening!
The Emotiva Team
Page 3
BasX Subwoofers
About This Manual
This manual will provide you with all the information you need to enable you to get great
performance, accurate sound, and many years of reliable service from your BasX Subwoofer.
We suggest that you read through the entire manual; we kept things as short and direct as
possible. Even if you’re an expert user, you will probably nd some interesting information and
useful suggestions.
If you’re really in a hurry to get started, please read the Quick Start section (on page 7); you may
then read the remainder of the manual at your leisure.
You may wish to record serial numbers or other purchase information on the Notes page at the
back of this manual.
Page 4
BasX Subwoofers
Features
Our Emotiva BasX™ Subwoofers were designed to oer excellent performance and great sound
quality; and they’re also priced to t perfectly into your budget. Their design and performance
features were carefully chosen to appeal to both home theater bus and audiophiles, with a
choice of input options and operating modes well suited to a wide variety of applications, and the
controls needed to perfectly match them to any system or room.
The following are a few of the feature highlights of our BasX Subwoofers:
• High performance, compact size, and great sound - all of our BasX Subwoofers oer
excellent sound quality, low distortion, and high output in a relatively compact form factor.
• 8 inch, 10 inch, and 12 inch models to t a wide variety of needs - While all of our BasX
Subwoofers oer the same combination of high output, low distortion, and precise sound
delivery, not everyone has room for a full-sized subwoofer. That’s why our BasX subs are
available in three dierent models - 8 inch, 10 inch, and 12 inch - so you can choose the
perfect t for your room and your system.
• Advanced long throw bass drivers - with mineral lled injection molded polypropylene
cones, large rubber roll surrounds, forced air cooling, and all copper voice coils with solid
aluminum formers for excellent performance.
• Carefully tunes ported cabinets - allow our drivers to deliver plenty of output, while
providing the precise control necessary to minimize distortion and deliver low frequencies
with power and authority.
• Heavy, acoustically inert MDF cabinets - minimize vibration and ensure that you hear only
the music and sound eects you’re supposed to hear - with no contribution from the cabinet.
• Tough yet attractive exterior - our tough yet attractive vinyl covering protects the cabinets
on our BasX subs from damage and ngerprints, and blends easily with your decor.
• Removable grilles (on the S10 and S12) - provide a convenient way to keep your
technology under wraps, and are easily removed for cleaning - or for showing your BasX sub
o to your audiophile friends.
• Ecient Class D ampliers - oer the ideal combination of excellent sound quality, great
long-term reliability, and high eciency.
• Useful Controls and Features- The BasX subwoofers all include Volume, Phase, and Crossover
controls so you can adjust them to integrate perfectly with your main speakers. They can
be turned on manually, or set to turn on automatically when the music starts playing, and
include advanced protection circuitry to prevent damage if you accidentally overdrive them.
• Full three year warranty - ensures that you’ll be able to enjoy your BasX subs for years to
come.
You can nd more information about the Emotiva BasX subwoofers on our website at
www.emotiva.com.
Page 5
