Emotiva USP-1 User Manual

2



TABLE OF CONTENTS

Safety Precautions 5
NEC (National Electrical Code) Standards 6

A Note for the Cable Television (CATV) Installer
Antenna Grounding Outside the House

Thank You for Your USP-1 Purchase 7
Unpacking the USP-1 7
Inventory 7

Emotiva USP-1 Preamplifier
Audiophile 2 Channel Preamplifier Features

USP-1 Front Panel Layout 9
USP-1 Rear Panel Layout 11

USP-1 Remote 13
Changing the Battery

13

6

8

Bass Management – Low Pass/High Pass Filters 14

Connecting To Audio Source Units 16
Connecting To Amplifiers and Speakers 17
Trigger Connections 17

Troubleshooting Guide

No Sound (from one or more full range speakers)
No Low Frequency (or poor output)
Sound Drops Out with CD or DVD Playback
Remote Not Working
External Amplifier(s) Shut Down (Often or Prematurely)
Remotely Connected External Amplifier(s) Do Not Turn Off with USP-1
"Hum" Noises
Other Probable Cause of Noise

18
18
18
18
18
19
19
19

3



Problems with the whole A/V System

USP-1 Technical Specifications 21

Emotiva Disclosure 22

Limited Warranty 23

20

Service Assistance for the USP-1

Front Panel Diagram (Full Page)
Back Panel Diagram (Full Page)

23

24
25

4



SAFETY PRECAUTIONS

Read this User's Guide thoroughly before attempting to install and configure the USP-1 Preamplifier. All
the safety and operation instructions should be read before any operation of the component(s) begin.
After successful installation and configuration of the USP-1 Preamplifier, be sure to retain this manual in
a safe place for any future reference needs.

All warnings on the USP-1 Preamplifier and in these operating instructions should be followed. Safety is
a key component to a long lasting and trouble free installation. The vast majority of the subsequent
safety precautions involve simple common sense. If you are not comfortable with the installation of
audio/video entertainment equipment, it will be to your benefit to seek the services of a qualified
installation professional.

The Emotiva USP-1 Preamplifier should NEVER be used near water such as a bathtub, washbowl,
kitchen sink, laundry tub, in a wet basement or near a swimming pool etc.

The Emotiva USP-1 Preamplifier should be situated so that its location or installation position does not
interfere with proper ventilation.

The Emotiva USP-1 Preamplifier should not be situated on a bed, sofa, rug or similar surface that may
block any ventilation openings; or placed in a built-in installation such as a bookcase, cabinet, or closed
equipment rack that may impeded the flow of air through ventilation openings. If installed in a closed
equipment rack for custom installations, be sure to add forced air ventilation so that it has adequate air
circulation.

The Emotiva USP-1 Preamplifier should be situated away from heat sources such as radiators, or any
other devices which produce heat.

The Emotiva USP-1 Preamplifier should be connected to a power supply only of the type described in
this User's Guide and what is labeled on the Emotiva USP-1 Preamplifier component. Power supply
cords should be routed to that they are not in high foot traffic areas or pinched by item placed upon or
against them, paying particular attention to cords at the wall plugs, convenience receptacles, and the
point where they connect into the Emotiva USP-1 Preamplifier. The power cord for the Emotiva USP-1
Preamplifier should be unplugged from the outlet when unused for a long period of time.

When it's time for cleaning the Emotiva USP-1 Preamplifier, it should be cleaned only as recommended
in this User's Guide Never spray liquids directly into the component's vent openings. Care should be
taken so that small objects do not fall into the inside of the Emotiva USP-1 Preamplifier.

The following situations require that your Emotiva USP-1 Preamplifier be serviced only by qualified
service personnel;

1. The power-supply cord or the plug has been damaged; or

2. Objects have fallen, or liquid has spilled into the component; or

3. The USP-1 has been exposed to rain; or

4. The USP-1 does not appear to operate normally or exhibits a marked change in performance; or

5. The USP-1 has been dropped, or its enclosure or chassis is damaged.

The user should not attempt to service the USP-1 Preamplifier beyond the means described in this
User's Guide. All other servicing should be referred to Emotiva.

5



To prevent electric shock, do not use this polarized plug with an extension cord, receptacle or other
outlet unless the blades can be fully inserted to prevent blade exposure.

Grounding or Polarization - Precautions should be taken so that the grounding or polarization means of
the component is not defeated.

For questions regarding service, please contact:

Emotiva Audio Corporation
131 Southeast Parkway Court
Franklin, TN 37064
Tel - [phone] | (877) EMO-TECH | Fax - [phone]
www.emotiva.com

WARNING - TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.
CAUTION - TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT,

FULLY INSERT.

NEC (National Electrical Code) Standards

A Note for the Cable Television (CATV) Installer

This reminder is to call the CATV system installer's attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to
the grounding system of the building as close to the point of cable entry as practical.

Antenna Grounding Outside the House
If an outside antenna is connected to the receiver, be sure the antenna system is grounded so as to

provide some protection against voltage surges and built-up static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the lead-in wire
to an antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding
electrode.

Cable TV Coaxial Cable, Satellite Dish Cables and Television Antennas should be grounded BEFORE
the point of entry into the house.

Always observe proper antenna or satellite dish grounding techniques. When lightning strikes there is
always the possibility that your antenna or dish (mounted high on the roof) can become a conduit for
lightning and electrically damage any equipment to which it is connected. Additionally, proper grounding
offers safety to the people using the audio/video system in the event of an electrical problem.

6



Thank You for your USP-1 Purchase

Dear Music Enthusiast,
Thank you for purchasing the Emotiva USP-1 Preamplifier. We sincerely believe that it offers you

outstanding performance and value. Emotiva products are engineered and produced with the highest
quality materials and incorporate the latest technology. We think you will find the USP-1 Preamplifier
meets or exceeds your expectations.

The Emotiva USP-1 Preamplifier features an array of leading edge technologies and all the features
necessary to perform the functions expected of a high end stereo preamplifier. At Emotiva, we believe in
creating home audio products that are easy to use while delivering unparalleled performance.

UNPACKING THE USP-1

The Emotiva USP-1 Preamplifier Player should reach you in flawless condition. If you notice any shipping
damage or other issues upon unpacking the unit, please contact Emotiva immediately.

INVENTORY

Contained in the box should be the Emotiva USP-1 Preamplifier, the remote control, AAA batteries, an
IEC standard power cord, and user manual.

Gently lift out the unit and remove all the packaging material and accessories. The USP-1 is a delicate
instrument so please unpack it carefully to avoid unnecessary damage to the preamplifier. It is important
to save all the packing materials and the boxes in case your USP-1 ever needs to be moved or shipped
back to the factory for service.

78

Emotiva USP-1 Preamplifier

Audiophile 2 Channel Preamplifier Features

• Precision low noise phono input with moving magnet or moving coil capability

• Seven stereo inputs with precision instrumentation grade relay switching

• Microprocessor controlled pure analog signal path

• Full remote control operation

• Completely integrated bass manager for 2.1 operation with variable frequency stereo high pass

and mono low pass outputs

• Independent full range outputs (available simultaneously with 2.1 output)

• Gold plated discrete RCA connectors for all inputs and outputs

• Low Pass / High Pass filters 12dB /Octave slope

• Tape monitor loop

• Home Theater Bypass

• Stereo / Mono switching

• Large format precision film volume potentiometer with motorized control

• Headphone output

• Illuminated input indicators (Halo Backlit)

• 12V trigger output

• IEC power inlet, 120/230 VAC user configurable


