Emerson TOUCH SCREEN EMP588-4 User Manual

User Guide

EMP588-4

Touch Screen

IN THE BOX

MP3 Music and Video Player

USB 2.0 Cable

(for battery charging

and high speed data transfer)

CD Quick Start Guide

Stereo Headphones

1

4 GB

Quick Start and Media Transfer

EMP588-4

record

music

ebook

video

browser

settings

photos

record

music

ebook

video

browser

settings

photos

FCC Part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications
Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:

● Re-orient or relocate the receiving antenna.

● Increase the separation between the equipment and receiver.

● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

● Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

2

FCC INFORMATION

3

Congratulations on purchasing the Emerson MP3 Music & Video Player.

Before using the player, read this manual thoroughly and keep it for future reference.

This manual contains important safety information and correct operation instructions.

Copyright Information

Trademarks and trade names used in this instruction manual are owned by their respective
companies or organizations.

Unauthorized duplication of any recordings whether downloaded from the internet or made from audio
CDs is a violation of copyright laws and international treaties.

The making of unauthorized copies of copy-protected material, may be an infringement of copyrights
and constitute a criminal offence. This equipment should not be used for such purposes.

INTRODUCTION

Always follow these basic safety precautions when using your player. This will reduce the risk of product damage and personal injury.

Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel.
This device contains a built- in battery, do not dispose of in fire.
In the event that the battery is leaking, do not handle the device with your bare hands. Contact the service center for help since the liquid may
remain in the player. If your body or clothes had contact with the battery liquid, wash it off thoroughly with water. Also, if some liquid gets into
your eyes, do not rub your eyes but immediately wash them with clean water, and consult a doctor.
Keep the player away from direct sunlight and any direct heat source.
Do not expose the unit to rain or moisture.
Do not use the player in dry environments to avoid static.
Never apply heavy impact on the player, or place it on a magnet.
Route the USB cable so that people and pets are not likely to trip over it.
Disconnect the USB cable from the computer when you do not use the player for a long time.
Clean only with a dry cloth. Make sure the player is turned off before cleaning. Do not use a liquid cleanser.
Be sure to back up your files to avoid data loss.

Precautions in using the headphones

Do not use the headphones while driving an automobile or riding a bicycle. It is dangerous, and against the
law. To avoid an accident, do not turn up the volume of the headphones too high while walking.
It is not recommended that you use the headphones at a high volume for an extended time, as this may
cause hearing damage.

4

IMPORTANT SAFETY PRECAUTIONS

4 GB internal memory

 2.8” Touch screen

 USB 2.0 high speed connection
 Stores and plays music, video, and pictures
 Text reading (txt format)

 Digital voice recording (built-in microphone)





Built-in stereo speaker



Mini SD card slot (add up to 8 GB additional memory, mini SD card not included)

 Folder navigation
 Li-ion rechargeable battery
 Supports MP3 / WMA / WAV music formats
 MPEG - 4 (AVI) movie / video files
 JPEG format picture browsing

5

FEATURES

6

Headphone jack

2. [ POWER ] - Power ON/Off switch / lock

3. Mini-USB jack

4. Speaker (listen to music or video without headphones)

10.

Touch Screen display

9. [+] - Volume up
Reset hole

5.

6. [ M ] - Select an option / Return / Menu

7. [−] - Volume down

8.

Mini SD card slot

1.

10

9

8

7

6

5

4

3

2

1

LOCATIONS OF CONTROLS

System requirements

You computer system must meet the following specifications:

Pentium 200MHz or above
Microsoft Windows 2000/ME/XP/Vista
USB port supported

7

CONNECTING TO A COMPUTER

PC

USB High Speed Connection Cable MP3 Player

PC connection

In order to enjoy the multimedia capabilities of your MP3 Player, you have to first copy your favorite files from your PC to it’s internal memory.
Connect your MP3 Player to the computer using the included USB 2.0 cable. The device will be detected automatically without installing any driver.

Once detected, you can read/write to the device’s memory just as if you where using a regular disk drive.

Important: To avoid any data loss, always perform a safe USB device extraction before disconnecting the USB cable from the PC.

In Windows XP, for example, you can find the safe extraction icon in the task bar next to the system clock.

Make sure your computer is powered on, and follow the steps below to connect the player to your computer.

1. Plug the larger USB connector of the USB cable into the USB port on the computer.

2. Plug the other end (small) of the USB cableto the player.

3. The computer system detects “New hardware” and starts to install the driver automatically. Wait for the system to finish the installation.
When it has finished, “Emerson MP3” willbecreatedin“My Computer”.

record

music

ebook

video

browser

settings

photos

8

Disconnecting the USB cable

After completing the file transfer, please disconnect the USB cable the following way:

1. Double click the green arrow “Safely Remove Hardware” in the task bar on the bottom right of the window.

2. Select “USB Device” and click “Stop”.

3. When the “Stop a Hardware device” appears, click “OK” to disconnect the USB mass storage device, and unplug the player safely.

9

Your MP3 Player has an integrated rechargeable Li-ion battery. It is recommended to fully charge the player before using it for the first time.
Recharge the battery by connecting the player to a computer using the included USB 2.0 cable.

Charging time is between 3-5 hours, depending if the player is powered off or working. To keep the battery in good condition, we recommend not
charging it for more than 8 hours.

Battery level indication:

Important:

● Fully charge it before you use the player for the first time or when you haven’t used it for a long time.

● Charge the player immediately when the “Low battery” message is displayed.

● Do not over charge or discharge the player. Over charging or discharging will shorten the battery life.

● The battery could be over discharged if the player is not used for a long time (over three months). To avoid over discharge, fully charge the player
every three months and always keep the voltage of the battery above 50 %.

CHARGING THE BATTERY

MINI SD

Full Two-thirds full Half full Low Empty

The player supports MINI SD cards which enable you to add up to 8 GB of additional memory to your player
(mini SD card not included).

1. Insert the MINI SD card into the card slot with the metallic contacts facing towards the back of the player, and gently push it in
until it clicks.

2. To access the MINI SD card, select “browser” > mini SD.

3. Touch a file or folder to select it, and press the [ M ] or button.

4. Press and HOLD the or [ M ] button to get back to the main menu.

5. To remove the card, gently push it in until it pops out.

Note: ●

Do not use force while inserting the memory card

●

Do not remove the card during data transfers

INSERT MINI SD CARD

record

music

ebook

video

browser

settings

photos

Enter

Return

Turning on/off

Lock / unlock buttons

This feature prevents you from accidentally pressing the buttons while using the player on
the move.

● To lock the player slide the [POWER] switch to the left.

● To unlock the player slide the [POWER] switch back to the right.

NOTE: The player’s backlit display will dim after a certain period of inactivity. To turn on the display, touch the screen.

To adjust, select: Settings > Display > BLight Time.

Reset the player

If a malfunction of the player occurs, take a metal pin, or use the end of a paper

clip, and press it into the RESET hole to re-initialize the system of your player.

10

BASIC OPERATION

Make sure the player is charged, and the headphones are connected correctly.

RESET hole

VOLUME DOWN

VOLUME UP

[POWER] switch

ON / OFF

● To turn on the player, slide and HOLD the [ POWER ] switch to the right until the
display turns on.

● To turn the player off, slide and HOLD the [ POWER ] switch to the right until the
display turns off.

Adjusting the volume

● Press the [+] button to increase the volume, or the [−] button to decrease the volume.

record

music

ebook

video

browser

settings

photos

Slide the switch this way
and HOLD until the player
turns on or off

11

The MP3 Player is capable of storing, displaying, and playing your favorite music, pictures, and video.

Transferring media to the player

To transfer media from your computer, perform the following steps:

1. Connect the MP3 player to the USB port of your computer.

2. Open “Windows Explorer” or “My Computer”, and locate “Emerson MP3” .

3. Select the files on your computer, and simply move it into “Emerson MP3”
in the usual way (drag-and-drop, copy-and-paste). After copying
is completed, the data will be available on the MP3 player.

We recommend using Windows Media Player to organize and transfer music, pictures, and videos to your
player. For more information regarding Windows Media Player, please refer to the Quick Start and Media Transfer Guide, or the
included CD

Note: Please do not disconnect the USB cable during loading, it may cause malfunction of the player and the files.

Emerson MP3 (G:)

Emerson MP3

Drag or copy

files here

Locate “Emerson MP3”

Find your music, picture, or video
files on your computer

Connect the MP3 player to your
computer, and locate “Emerson MP3”.
Drag the files into the area shown below.

TRANSFERRING MEDIA TO THE PLAYER

music

video

pictures

MP3 Player

record

music

ebook

video

browser

settings

photos

12

Once you turn on the player, the main menu appears. You may also use the

or [ M ] button to return to the main menu from the other modes.

1. Touch the icon you wish to select: “music”, “video”, “photos”, “ebook”,

“record”, “browser”, “settings”.

2. Touch an option and press the

[ M ] button.

3. Press and HOLD the or [ M ] button to go back to the main menu.

ICON MAIN MENU ITEMS DESCRIPTION ICON MAIN MENU ITEMS DESCRIPTION

music Play songs

video Play videos browser

photos View pictures settings

ebook View TXT files

record Record voice

View files and folders of the
player
Customize the settings of
your player

MAIN MENU

record

music

ebook

video

browser

settings

photos

Return

Return

13

music

Store and playback your favorite songs and organize them by playlists, atrist, and
other options. See “TRANSFERRING MEDIA TO THE PLAYER” (page 11) and follow the
steps below to transfer, playback and organize your music.

1.

Select “music” from the main menu. Use the [▲] or [▼] buttons from the

scroll bar or touch an option to select it, and press the or [ M ] button.

2. Choose from the submenu options below:

● “Music Play”: Displays the music player screen.

● “All Music”: With this option you will see, sorted alphabetically by file name,
all the songs you have stored in your MP3 Player.

● “Artist”, “Album”, and “Title”: See listings of your favorite music sorted by

artist, album or title respectively.

Note: In order for the music files to be displayed in these listings, their artist,
album and title information must be stored into the file (information
known as ID3-Tag). You can find freeware utilities to create or modify
ID3-Tags like MP3Tag or ID3 Renamer.

● “Favorite”: With this option you can listen to your favorite music that you already marked as favorite. To add a song to your “Favorite” list,
choose the song you wish to mark as favorite. Press the [ ] button to save song in the “Favorite” folder.

● “Record”: Listen to the clips you recorded using this option.

● “Dir List”: With this option you can explore the file tree in the memory of the MP3 Player just as it would be displayed on your computer.

● “Update”: Use this option whenever you store or delete songs so the artist, album and title listings are recreated accurately.

3. Press and HOLD the button to get back to the main menu.
Note: When the player is unplugged from the PC via the safe USB device removal, the MP3 Player will run an update automatically.

SCROLL BAR

[ ▲] OR [ ▼]

FAVORITE

BUTTON

Enter

ENTER BUTTON

Enter

Return

Listening to music

Music player interface

If the song has lyrics (LRC file), they will be shown on screen, otherwise the display will show the equalizer.

A-B repeat function

You can loop play a segment of a song with this function.

1. Press the [

] button during playback to set the A point and press the [ ] button again to set the B point.

2. To cancel this function, press the [

] button again.

3. To exit the current playback and return to the file list press the [ ] button.

4. To return to the main menu, press and HOLD the button.

Skipping tracks

1. Select “music” from the main menu.

2. Use the [ ▲] or [ ▼] buttons from the scroll bar to select “Music Play”, and press the button.
Or select “All Music” to view the music file list. Use the [ ▲] or [ ▼] buttons from the scroll bar to select
the music file you wish to listen to and press the or [ M ] button.

3. Press the [ ►] button to begin playback.

4. While a song is playing, press the [ ıı ] button to pause the playback. To resume playback, press the
[ ►] button once again. Press the [ ] button to return to the music file list.

5. To return to the main menu, press and HOLD the or [ M ] button.

 Briefly press the [] button to go to the previous track.

Adjusting the volume

 In the play mode press the [ ] or [+] button to increase the volume, and the [ ] or [-] button

to decrease the volume.

 Briefly press the [] button to skip to the next track.

Searching backward or forward within a track

 Press and HOLD the [] button to search backward within a track.
 Press and HOLD the [] button to search forward within a track.

14

Enter

Enter

A-B A-B

A-B

A-B

A-B

A-B REPEAT

MENU

[ M ]

PREVIOUS

[]

NEXT

[]

BACK

PLAY

[ ►]

PAUSE

[ ıı ]

VOLUME

CONTROL

UP DOWN

Return

Return

Music player settings

You can choose the equalization mode that fits your preferences. To do so, browse to “settings” > “Music” > “EQ Select” and choose one of
the 6 available modes: “Normal”, “MS PlayFX”, “Rock”, “Pop”, “Classic”, and “Jazz”.

The playing order of the tracks depends on the selected mode. By default, the mode is set to “Normal”. You can change to a different mode
browsing to “settings” > “Music” > “ Play Mode”, and choosing “Order” (sequential order) or “Shuffle” (random).

You can also set the repeat mode by browsing to “settings” > “Music” > “Repeat Mode” and selecting your preferred mode:

“Once” - Plays the current file and stops.
“Repeat One” - Repeat current track.
“Folder Once” - Plays files inside the current folder and stops.
“Folder Repeat” - Repeats the files inside the current folder.
“All Once” - Plays all the files once.
“All Repeat” - Plays all the files continuously.
“Intro” - Plays the first 10 seconds and skips to the next file.

To know the amount of free memory, browse to “settings” > “System” > “About”.
To return to the main menu press and HOLD the button.

15

Return

Playing videos

Searching backward or forward

You can play AVI / WMV / MPG / VOB / ASF videos that you previously
converted to the AVI format (XVID with MP2 audio and 320 x 240 resolution),
using the easy software tool included inside the bundled CD.

NOTE: You must convert a video to the correct format before transferring
to the player.

1. Select “video” from the main menu.

2. Touch the video file you would like to watch, and press the
or [ M ] button to begin playback.

NOTE: Use the [ ▲] or [ ▼] buttons from the scroll bar to move to the next
or previous page of files or folders.

3. Press the [ I I ] button to pause playback, to resume playback press the [ ►] button.

4. To return to the previous screen, press the [ ] button.

5. Press and HOLD the or [ M ] button to go back to the main menu.

16

1. Use the [] or [] buttons to skip to the previous/next video.

2. You can fast forward or rewind a video by pressing and holding
the [] or [] buttons.

3. To return to the video file list, press the [ ] button.

4. To return to the main menu, press and HOLD the or [ M ] button.

NOTE: To delete a file press the [ ] button.

Enter

Return

Return

video

BACK

[ ]

Return

RETURN
BUTTON

DELETE

ENTER BUTTON

Enter

SCROLL BAR

[ ▲] OR [ ▼]

(PAGES)

VOLUME DOWN

[−]

VOLUME UP

[+]

PREVIOUS [] NEXT []

PLAY

[ ►]

PAUSE

[ ıı ]

17

Before transferring video files to the MP3 player, you must convert them to the correct format.
With the AVI Converter software tool you can easily convert your AVI / WMV / MPG / VOB / ASF videos to the AVI format (XVID with MP2 audio and
320 x 240 resolution) so you can enjoy them on your MP3 Player.

To install the AVI converter on your computer follow the steps below:

1. Insert the provided CD to the CD-ROM drive of your computer, and click on “Video Converter”.

2. Click “Install” and then “Next”.

3. Follow installation instructions to download the converter to your computer.

4. Click “Install” when you see the screen below, and then click “Finish”.

5. Click the icon on your “Desktop” to open the Video Converter.

AVIConverter

Click on “Video
Converter”

Click “Install”

Click “Next”

Click “Install”

Click “Finish”

“AVI

Converter”

icon on your

“Desktop”

CREATING AVI VIDEOS

18

1. Connect the MP3 Player to the USB port of your computer

(optional).

2.

Click on “AVI Converter ”from the “Start ” menu, or the
icon on your desktop.

3. Click on the “Add” button and select 320 x 240 resolution.

4. Select the video file that you want to convert by clicking on the
“Source File” drop down window.

AVIConverter

320 x 240

Click “Ad d ”

Click on the “Resolution”

drop down window

and select “320 x 240”

Converting videos

Click “Open”

Click on a video

“Source File”

drop down

window

19

Converting videos

5.

Click on the “Target File Path” drop down window to select the destination for the converted video. You can send it directly to your player by
selecting “Emerson MP3”, and clicking “OK”, or if you would like to save the video to your computer, we recommend sending it to your “Desktop”
where you can easily find the video, and transfer it to your player. (See “TRANSFERRING MEDIA TO THE PLAYER” on page 11)
NOTE: To send a converted video directly to your player, it must be connected to the computer’s USB port at time of conversion.

320 x 240

OR

Desktop

Emerson MP3 (H:)

Click on the

“Target File Path”

drop down
window

Select where you
would like to send
the converted video

Choose “Desktop” and save the converted video
to the “Desktop” on your computer. After saving
the converted video to your desktop, you can
transfer it directly to your player
(see “TRANSFERRING MEDIA TO THE PLAYER”
on page 11).

Choose “Emerson MP3” and save the
converted video directly to your MP3 Player.

Note: Your MP3 Player must be connected to
the USB port of your computer during the
conversion for this option.

Emerson MP3 (H:)

Emerson MP3 (H:)

320 x 240

20

11.

Click “Convert Now” to start the job queue. If more than one job is present they will be performed sequentially.

12.

Once finished, press “Close” to exit the application.

13. Copy the new AVI file(s) to your player. See “TRANSFERRING MEDIA TO THE PLAYER” (page 11).

Click “Convert Now”

Lake.avi Lake.avi

Emerson MP3

320 x 240

Click “Save”

“Target File Name”

Click “Close”

then

320 x 240

Lake.avi
Emerson MP3

Lake.avi

6. Write the name of the new AVI video file to be created (”Target File Name”).

7. Choose the image quality of the new video. High quality will use more memory and the output file will be bigger.

8. Select the format of the output video (”Aspect Ratio”). Choose “Full” if you want the output video to include the whole original image. Black
bands will be added if necessary. “4:3” will fill the whole screen, but some part of the image may be removed from the video. “16:9” for
panoramic option.

9.The “Scope” section allows you to determine the start and end of the input video. By default, the input video will be converted from start to end.

10. Click “Save” to add the video recording to the list of pending jobs.

Note: You can add as many conversion jobs as you like in order to convert several videos automatically. When you are done adding jobs, press
the “Close” button.

Converting Videos

21

photos

Viewing pictures

PREVIOUS [] NEXT []

BACK

[ ]

PLAY

[ ►]

PAUSE

[ ıı ]

Enter

MENU

[ M ]

Return

RETURN
BUTTON

DELETE

Return

ENTER BUTTON

Enter

Enter

1. Select “photos” from the main menu.

2. Touch the photo file you wish to view, and press the or [ M ] button.

3. Use the [] or [] buttons to skip to the previous or next picture.

4. Press the [ ►] button to enable, or the [ I I ] button to disable the slideshow
(timing can be set from the “settings” > “Auto Play Set” > “Image” menu).

5. To delete a photo file, touch it and press the [ ] button.

6. To return to the main menu, press the and HOLD the [ M ] or button.

The MP3 Player is capable of storing and displaying your favorite pictures.
See “TRANSFERRING MEDIA TO THE PLAYER” (page 11) and follow the steps below:

View and enjoy your electronic books (e-book in TXT format) anywhere with the
high resolution LCD screen of your MP3 Player.

1. Select “ebook” from the main menu.

2. Touch the file you wish to select, and press the button to open it.

3. While reading the e-book, use the [ ▲] or [ ▼] buttons from the scroll bar
to go to the previous or next page.

4. Press and HOLD the [

] button to display the “Save BookMark” list. Use the

[ ▲] or [ ▼] buttons to select the bookmark location, and press the button to save it.

5. Press the [

] button to display the “Load BookMark” list. Use the [▲] or [▼] buttons

to select the bookmark location, and press the button to view it.

6. While reading the E-book, press the [ ] button to return to the file list.

7. To delete files, select the file you wish to delete and press the [ ] button.

8. To return to the main menu, press and HOLD the or [ M ] button.
NOTE: The bookmark is only available to the current file, and has to be reset while

reading the other files.

22

Viewing TXT files

ebook

Enter

Tex t

Tex t

BACK
[ ]

BOOKMARK ICON
[ ]

Yes

Yes

Return

Return

RETURN
BUTTON

DELETE

ENTER BUTTON

Enter

SCROLL BAR

[ ▲] OR [ ▼]

(PAGES)

23

record

Recording

1. Select “record” from the main menu.

2. Press the [

] button to begin recording, and press the [ ] button again to

pause recording.

3. Press and HOLD the [

] or [ I I ] button to stop recording, and save the recorded file.

4. To return to the main menu, press the [ ] button.

Playing back recorded files

1. Select “music” or “browser” from the main menu.

2. Use the [ ▲] or [ ▼] buttons from the scroll bar to select the “Record ” folder, and
press the button.

3. Touch the file you wish to play, and press the or [ M ] button to begin playback.

4. Press the [ I I ] button to pause the playback. To resume playback, press the [ ►] button.

5. To return to the previous screen, press the [ ] button.

6. Press and HOLD the [ ] or button to get back to the main menu.

Your MP3 Player is able to perform voice recordings with its integrated microphone.
The sound files that you record are stored inside the “Record” folder. The files are in WAV format.

You can listen to these files while being at the “music” mode or “browser” mode, and selecting
the “Record” folder.

RECORD

BACK

MENU

[M]

VOLUME

CONTROL

Enter

Enter

UP DOWN

Return

24

browser

This handy function allows you to directly choose the music / video / image / e-book folder or file you
want to play or view.

1. Select “browser” from the main menu.

2. Touch the file or folder you wish to select, and press the or [ M ] button to enter the selected folder.

3. Select a file by touching it, and press the or [ M ] button to start playback or open the file.

Deleting Files

● From the player

1. Select “browser” from the main menu.

2. Touch the file you wish to delete.

3. Press the [

] button, and press the button to confirm and delete the file.

4. Press the button to get back to the previous screen, or press and HOLD the
the or [ M ] button to get back to the main menu.

OR

● From your computer

You can easily delete music, picture, or video files by connecting your MP3 Player to the computer and
selecting “Emerson MP3” from Windows Explorer or “My Computer”, or click on “Open Folder” to
view files from the “AutoPlay” option window. Simply select the file and delete it as you would delete any
other file from your computer.

Enter

Enter

Yes

Return

Return

ENTER BUTTON

Enter

Return

RETURN BUTTON

DELETE

Browser

The player’s settings can be customized by accessing “settings” in the main menu. The settings
menu consists of several items where various functions can be selected concerning music, power,
language, display, recording, system, etc.

Navigating the settings menu

1. Select “settings” from the main menu.

2. Use the [ ▲] or [ ▼] buttons from the scroll bar to select from the following
settings options:

● Music

● Record

● Display

● Auto Play Set

● System

● PowerOff Time

● Default Set

3. Press the or [ M ] button.

4. Use the [ ▲] or [ ▼] buttons from the scroll bar to
select the option, and press the or [ M ] button to confirm.

5. To return to the previous directory, press the button.

6. To return to the main menu, press and HOLD the or [ M ] button.

25

settings

Enter

Enter

Enter

Return

Return

Return

SCROLL BAR

[ ▲] OR [ ▼]

ENTER BUTTON

RETURN BUTTON

If you have problems while operating your player, please check the points below before sending it to the service center

Can not power on

 The battery may be exhausted, please recharge the battery

Files can not be transferred to the player

 Check if the driver is installed correctly in the computer by disconnecting and then reconnecting the player to the computer
 Check the connection between the player and PC, and confirm the USB cable is properly connected

No sound from the headphones

 Please ensure the volume is turned up, and the headphones are properly connected
 Check if the format of music file is supported by the player

Can not record

 Check if there is enough memory and battery capacity

Display is in the wrong language

 Please ensure you selected the correct language from the “Settings ” menu

The buttons do not work





The player may be locked. Unlock it by sliding the [POWER] switch to the right.
Press the reset hole with a metal pin to re-initialize the system of the player

TROUBLESHOOTING

My computer is not detecting the MP3 Player with Windows Vista

 There is a USB mass storage devices recognition issue with Windows Vista acknowledged by Microsoft. A solution is available in the

Service Pack 1 which may be downloaded from Microsoft’s website

I cannot display my .jpg files

 Many digital cameras and image editing softwares add hidden data to the .jpg files. This data can prevent your MP3 from loading the images.

Try to eliminate them by saving the file with another name.

The Video converter is not converting videos or is not functioning properly

 Right-click on the converter icon and select “Run as administrator”.

AVIConverter

26

Display 2.8 inch 320 x 240 touch screen display

USB 2.0 (HIGH SPEED)
4GB
Built-in Lithium battery

Connect with PC
Built-in memory
Power source

Sampling rate 8 KHz/16KHz

Recording Recording format WAV (32Kbps/64Kbps)

Recording time 8 hours (128M Flash)

MP3, WMA

WMA bit rate

Earphone Max output
MP3 bit rate

(L) 5mW+ (R) 5mW (32ohm)
8Kbps - 320Kbps
32Kbps - 384Kbps
20Hz to 20KHz

Operating temperature

Music file format
Video file format

Frequency response

Language
OS

-5 - 40

0

C
English, Spanish, French
Windows SE/ME/2K/XP

MP1, MP2, MP3, WMA, WAV
AVI

27

SPECIFICATIONS

In the unlikely event that this product is defective, or does not perform properly, you may within ninety (90) days from your
original date of purchase return it to the authorized service center for repair or exchange.

TO OBTAIN WARRANTY SERVICE:

- Provide proof of the date of purchase within the package (Dated bill of sale)

- Prepay all shipping costs to the authorized service center, and remember to insure your return.

- Include a return shipping address (no P.O. Boxes), a telephone contact number, and the defective unit within the package.

- Describe the defect or reason you are returning the product.
Your product will be repaired or replaced, at our option, for the same or similar model of equal value if examination by the

service

center determines this product is defective. Products received damaged as a result of shipping, will require you to

file a claim with the carrier.

28

LIMITED WARRANTY

The shipping address of the authorized

service center is:

Southern Telecom Inc.

ATTN: Returns Department

14-C 53rd Street

Brooklyn, NY 11232

Should you have any questions or problems concerning this
product, please contact our customer service department at:

1-877-768-8483 (Toll Free)

Monday - Thursday: 9AM - 5PM (EST)

Friday: 9AM - 3PM (EST)

or

via e-mail at

[e-mail]

29

To obtain service after the warranty period, please e-mail [e-mail] with product information, date of
purchase and nature of the problem. Customer service will reply to the e-mail with service instructions.

Warranty service not provided:

This warranty does not cover damage resulting from accident, misuse, abuse, improper installation or operation, lack of
reasonable care, and unauthorized modification. This warranty is voided in the event any unauthorized person opens, alters
or repairs this product. All products being returned to the authorized service center for repair must be suitably packaged.

Limitation of Warranty:

•

THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL OTHER WARRANTIES,

EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE)
ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY SOUTHERN TELECOM INC. IT’S AGENTS, OR
EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.

•

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER,

SOUTHERN TELECOM INC. SHALL NOT BE LIABLE FOR INCIDETAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF
THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER
OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF NEW YORK. EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON
THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.

How state law relates to this warranty:

• Some states do not allow the exclusion nor limitation of incidental, consequential damages, or limitations on how long an
implied warranty lasts so the above limitations or exclusion may not apply to you..

• This

warranty gives you specific legal rights, and you also may have other rights that vary from state to state.

Manufactured by: AIT Inc. Brooklyn, NY 1123

2

Emerson and the G-Clef logo are registered trademarks of Emerson Radio Corp. Parsippany, New Jersey USA

© 2009 AIT Inc. All rights reserved

Microsoft, the Windows logo, and Windows Media are either registered trademarks or trademarks of Microsoft

Corporation in the United States and / or other countries.
